AsahiAV H-A077-E-00 User manual

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
Serial No. H-A077-E-00
Table of contents
1.
Be sure to read the following warranty clauses
of our product ······································· 1
2. General operating instructions ·················· 2
3.
General instructions for transportation,
unpacking and storage ··························· 4
4. Name of parts ······································· 5
5. Maximum working pressure vs. temperature 7
6. Specifications of valves ··························· 7
7. Specifications of actuator ························ 8
8. Installation procedure ··························· 10
9. Support setting procedure ····················· 17
10. Electric wiring procedure ······················· 18
11. Operating procedure ···························· 20
12. Adjustment of limit switches procedure ····· 23
13. Actuator removal procedure ··················· 24
14.
Method of adjusting face pressure between ball
and seat ············································ 25
15. Disassembling method for replacing parts · 26
16. Inspection items ·································· 28
17. Troubleshooting ·································· 28
18.
How to inquire about defects or replacement
························································· 30
19. Handling of residual and waste materials ·· 30
3
-
Way B
all
valve Type 2
3
Electric actuated Type Z
(15〜50mm [ ½ ”-2”])
User
ʼ
s Manual

Installation, Operation and Maintenance Manual
【H-A077-E-00】3-Way Ball valve Type 23 Electric actuated Type Z 15～50mm (½”-2”)
1
This User’s Guide contains very important information for the proper installation, maintenance and safe
use of the ASAHI AV Product store in an easily accessible location.
- Warning & Caution signs -
This remark expresses the user to take caution due to the potential for serious
injury or death.
This remark expresses the user to take caution due to the potential for damage
to the valve if used in such a manner.
- Prohibition & Mandatory Action Signs -
Prohibited: When operating the valve, this symbol indicates an action that should not be taken.
Mandatory action: When operating the valve, this sy
mbol indicates mandatory actions that
must be adhered to.
1. Be sure to read the following warranty clauses of our product
- Always observe the specifications of and the precautions and instructions on using our product.
- We always strive to improve product quality and reliability, but cannot guarantee perfection.
Therefore, should you intend to use this product with any equipment or machinery that may pose
the risk of serious or even fatal injury, or property damage, ensure an appropriate safety design or
take other measures with sufficient consideration given to possible problems. We shall assume
no responsibility for any inconvenience stemming from any action on your part without our written
consent in the form of specifications or other documented approval.
- The related technical documents, operation manuals, and other documentation prescribe
precautions on selecting, constructing, installing, operating, maintaining, and servicing our
products. For details, consult with our nearest distributor or agent.
- Our product warranty extends for one and a half years after the product is shipped from our
factory or one year after the product is installed, whichever comes first. Any product abnormality
that occurs during the warranty period or which is reported to us will be investigated immediately
to identify its cause. Should our product be deemed defective, we shall assume the responsibility
to repair or replace it free of charge.
- Any repair or replacement needed after the warranty period ends shall be charged to the
customer.
- The warranty does not cover the following cases:
(1) Using our product under any condition not covered by our defined scope of warranty.
(2) Failure to observe our defined precautions or instructions regarding the construction,
installation, handling, maintenance, or servicing of our product.
(3) Any inconvenience caused by any product other than ours.
(4) Remodeling or otherwise modifying our product by anyone other than us.
(5) Using any part of our product for anything other than the intended use of the product.
(6) Any abnormality that occurs due to a natural disaster, accident, or other incident not stemming
from something inside our product.
* Note that damage induced by a defect of our product is not covered by warranty.
- This guarantee applies to the use of our product only in Japan. If it is used overseas, please
inquire with us separately.

Installation, Operation and Maintenance Manual
【H-A077-E-00】3-Way Ball valve Type 23 Electric actuated Type Z 15～50mm (½”-2”)
2
2. General operating instructions
- Never attempt to disassemble an actuator.
- Keep hands and other extremities away from moving parts under all circumstances.
(Any such practice may get your hand, arm, or other part of your body caught.)
- Using a positive-pressure gas with our plastic piping may pose a dangerous condition due to
the repellent force particular to compressible fluids even when the gas is under similar
pressures used for liquids. Therefore, be sure to take the necessary safety precautions such
as covering the piping with protective material. For inquiries, please contact us.
- For conducting a leak test on newly installed piping, be sure to check for leaks under water
pressure. If absolutely necessary to use a gas in testing, please consult your nearest service
station beforehand.
- Before using the product, check the operating power supply and the voltage specification on
the nameplate. Using an improper voltage may cause equipment damage or malfunction.
- Do not step on or apply excessive weight on valve. (It can be damaged.)
- Do not use the valve to fluid containing slurry. (The valve will not operate properly.)
- Do not use AV valves in a place where they may become submerged in water.
- Do not apply a great impact or vibration to the actuator.
- The surface temperature of the actuator may rise during operation. This is due to the heat
generated by the internal equipment and is not a malfunction, but do not use it beyond the
allowable range of ambient temperature of -10 to 55°C. (It may cause a malfunction)
- Do not use the valve in conditions where the fluid may have crystallized. (The valve will not
operate properly.)
- Keep the valve away from excessive heat or fire. (It can be damaged, or destroyed.)
- Be careful of the environment where the valve is installed. In particular, avoid places exposed
to salty wind, corrosive gas, chemical solution, seawater, steam, etc.
- Use the valve working pressure, working temperature, ambient temperature within an allowable
range. (The valve can be damaged or deformed by operating beyond the allowable range.)
- Allow sufficient space for maintenance and inspection.
- Select a valve material that is compatible with the media. For chemical resistance information,
refer to “CHEMICAL RESISTANCE ON ASAHI AV VALVE”. (Some chemicals may damage
incompatible valve materials.)
- Keep the valve out of direct sunlight, water and dust. Use cover to shield the valve. (The valve
will not operate properly.)
- Perform periodic maintenance. (Leakage may develop due to temperature changes or over
periods of prolonged storage, rest or operation.)

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
3
2. General operating instructions (continued)
- When installing the valve, provide an appropriate support. (Failure to do so may cause
breakage due to excessive force applied to the valve body and pipes.)
- The AV valves must be used within the specifications specifically applicable to the product.
(May not work.)
- If there is a strange odor, heat generation, or smoke, immediately shut off the power supply.
(If you use the product while feeling an abnormality, a fire may occur. If any abnormality is
found, be sure to contact the store where you purchased the product or our nearest sales
office for inspection.)
- Keep the equipment connected to the limit switch (non-voltage contact) for the left open / right
open signal within the contact capacity (1A). (May be damaged.)
- Use a commercially available Allen wrench for manual operation.
- Keep the ambient temperature of the installed location within the range -10°C to 55°C.
- Avoid locations with corrosive gas or otherwise bad atmospheres, install a cover or something
similar that covers the entire area.
- When removing the actuator, be sure to use the "Base plate removing jig". (Failure to so may
cause, damage the Base plate.)
- Regarding the ball valve type, we recommend that you use left fully open or right fully open.
This is because the edge of the ball opening remains on the seat (PTFE) when used at an
intermediate opening, so that the sealing performance temporarily deteriorates at the time of
left fully closing and right fully closing.
- The “P1”, “P2”, “P3” stickers showing the ports are an
affixed to the side of the valve body.
“P1” is the left opening side, “P2” is the right opening
side, and “P3” always shows open side.

Installation, Operation and Maintenance Manual
【H-A077-E-00】3-Way Ball valve Type 23 Electric actuated Type Z 15～50mm (½”-2”)
4
3. General instructions for transportation, unpacking and storage
- When suspending and supporting the valve, do not stand under the suspended valve.
- This valve is not designed to handle impacts of any kind. Avoid throwing or dropping the valve.
- Avoid scratching the valve with any sharp object.
- Do not over-stack cardboard shipping boxes. Excessively stacked packages may collapse.
- Do not contact with any coal tar, creosote, insecticides, vermicides or paint etc. (These
chemicals may cause damage to the valve.)
- Store products in their corrugated cardboard boxes. Avoid exposing products to direct
sunlight, and store them indoors (at room temperature). Also avoid storing products in areas
with excessive temperatures. (Corrugated cardboard packages become weaker as they
become wet with water or other liquid. Take care in storage and handling.)
- After unpacking the products, check that they are defect-free and meet the specifications.
- A desiccant (silica gel) is put in the actuator for the purpose of adjusting the humidity. Do
not discard the desiccant, but use it as it is.
- If the indicator of desiccant changes from blue to pink, it's time to replace it. Please contact
the store where you purchased the product or our nearest sales office.

Installation, Operation and Maintenance Manual
【H-A077-E-00】3-Way Ball valve Type 23 Electric actuated Type Z 15～50mm (½”-2”)
5
4．Name of parts
15 - 50mm [½”-2”]
1 Body 8 O-ring (A) 18 Bolt
2 Ball 9 O-ring (B) 19 Connector plate
3 Carrier 10 O-ring (C) 20 Bolt
4b End connector (Flanged end) 11 O-ring (D) 21 Rubber cap
4c End connector (Socket end) 12 O-ring (E) 22 Rubber cap
4d End connector (Threaded end) 13 Stop ring 23 Nut
4e End connector (Spigot end) 14 Adaptor 24 Stopper
5 Union nut 15 Bush 25 Tapping screw
6 Stem 16 Bolt 26 Actuator
7 Seat 17 Base plate

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
6
Appearance and internal structure
No. Name No. Name
1 Cover 10-1
Cable gland for power input
Attachment: Dust seal (sponge-like)
2 Body 10-2
Cable gland for signal output
Attachment: Sealing plug (NBR rubber)
3 LED lamp 11 Space heater
4 Indicator 12 Terminal block for grounding
5 Bush for manual operation 13 Terminal block for power input
6 Bolt cap 14 Terminal block for signal output
7 Auto/Manual Changeover switch 15 Limit switch cam for left opened/right opened
8 Base plate 16 Limit switch for Limit/Output
9 Valve 17 Shaft for manual operation (with hexagonal hole)
10-1
1
11
12
13
10-2
2
3
4
5
6
8
7
9
14
15
16
17

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
7
5. Maximum working pressure vs. temperature
6. Specifications of valves
Model code
- Body material PP JIS socket 32mm is not produced.
- Body material PVDF JIS socket is not produced.
- The spigot type is DIN standard only, and the body material C-PVC is not produced.
N
OTE
AAutomatic 23 Type 23 ZType Z U95～240VAC UU-PVC EEPDM FFlanged JJIS 015 15mm (½")
CC-PVC VFKM SSocket 1JIS10K 020 20mm (¾")
PPP NThreaded 5JIS5K 025 25mm (1")
FPVDF PSpigot DDIN 032 32mm (1¼")
AANSI 040 40mm (1½")
050 50mm (2")
＊ ＊ ＊ ＊＊＊Ａ ２３ Ｚ Ｕ ＊
Actuation Valve
type
Actuator
type Voltage Body material
Seal
material Connection Standard Size

Installation, Operation and Maintenance Manual
【H-A077-E-00】3-Way Ball valve Type 23 Electric actuated Type Z 15～50mm (½”-2”)
8
7. Specifications of actuator
List of specifications
Actuator type AV-Z-025
Rated torque *1. 10 N-m
Maximum output torque 25 N-m
Rated voltage *2. 95～240VAC ± 10% 50/60Hz (Universal power supply)
Power consumption 17VA
Motor protection *3. Overcurrent protection element
Operating range (Min-Max) 0°～90° （Maximum operating angle 110°: -10°～100°）
Opening and closing time 8 sec. / 90° (No load), 9 sec. / 90° (Loaded)
External dimensions W175(145)×D120×H150mm *(145) Excluding cable gland
Weight 1.7kg
Usage
environment
Installation
environment *4. Indoor and outdoor (with restrictions and conditions)
Protection class IP67
Pollution level 2
Ambient
temperature -10～55°C (There should be no freezing or condensation)
Duty cycle *1. 30%
Wiring port
Cable gland For power input &signal output: 1 place each, CE / VDE standard
Terminal block Screw type, Applicable wire:
Outer diameter φ7～13mm, Wire diameter 0.75～2.0mm2
Housing material Cover: Polycarbonate (blue) flame retardant UL94V-0
Body: Polycarbonate with glass (black) flame retardant UL94V-0
Function
State output *5. Left open & Right open output: 1 place each (Non-voltage contacts),
Contact capacity: Max. 250VAC–1A
Status display Indicator / LED Lamp (Green: Left open, Red: Right open)
Manual operation
With Auto/Manual changeover switch.
9 rotations / 90° with a Allen wrench
Space heater Rated output: 5W * It works only when the power is on.
Insulation resistance 500VDC, 10MΩor more
Withstand voltage 1500VAC , 1 minuite
(Note)
*1. The load and duty cycle conform to S4 (see IEC60034-1), which is equivalent to the valve load.
*2. As a guide, the length of the power cable should be within 100 meters.
*3. In the event of an overload, the thermistor will function and the power to the motor will be cut off.
(It will self-recover when the power supply is cut off.)
*4. This actuator can be used in an IP67 environment, but when opening the housing for maintenance
or adjustment, do so in a pollution level 2 environment (for example, indoors and other dust-free
and moisture-free environments).
*5. Keep the equipment connected to the limit switch (non-voltage contact) for the left open / right
open signal within the contact capacity (1A). (May be damaged)

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
9
Wiring diagram
- Reference connection example
Switching chart
- The contact limit switch is set approximately 8 degrees before the motor stop position.
- If the valve stops operating with the contact limit switch, the valve will not close completely and may
cause a leak.
- Do not stop the power supply by operating the contact limit switch. (The valve may not be “left
fully closed” or “right fully closed” and may leak.)
The wiring diagram shows the end
of the left open operation
OLS-1： Left open limit switch
SLS-1 ： Right open limit switch
OLS-2： Left open contact switch
SLS-2 ： Right open contact switch
M： Motor
Right open Left open
SLS-2
OLS-2
Contact capacity: Max. 250VAC–1A
OLS-1 SLS-1
PCB
Space heater
Thermistor
Le
ft open
Right open
OLS
-
2
Left open contact
O
LS
-
1
Left open limit
S
LS
-
1
Right open limit
S
LS
-
2
Right open contact
Off by right fully open
By a little before right fully open
⑤-⑥ ON
Off by left fully open
By a little before left fully open
⑧-⑨ ON
Middle open

Installation, Operation and Maintenance Manual
【H-A077-E-00】3-Way Ball valve Type 23 Electric actuated Type Z 15～50mm (½”-2”)
10
８. Installation procedure
Flanged end
- When suspending and supporting a valve, take care and do not stand under a suspended
valve.
- Do not to over-tighten the Union nut. (The valve can be damaged.)
- Do not use a pipe wrench when tightening the union nut. (The valve can be damaged.)
- Do not tighten the bolts and nuts with more than the torque shown in Table 8-2. (The valve can
be damaged or leaks.)
- Be sure to conduct a safety check on all hand and power tools to be used before beginning
work.
- When conducting piping work, wear personal protective equipment appropriate to the contents
of work. (Failure to do so may cause an injury.)
- When installing pipes and valves, ensure that they are not subjected to tension, compression,
bending, impact, or other excessive stress.
- When installing, disassembling, or reassembling the piping, fix the End connector.
- When installing a piece of equipment at the end of the piping line, be sure to keep the
secondary (Downstream) End Connector and Union nut installed on the valve.
- When connecting a ASAHI AV Valve to metal piping, take care not to let the pipe stress on the
ASAHI AV Valve.
- Use flat faced flanges for connection to AV Valves.
- Ensure that the mating flanges are of the same standards.
- Be sure to use sealing gaskets (AV Gasket), bolts, nuts, and washers and tighten them to
specified torques. (When a non-AV gasket is used, a different tightening torque instruction
should be followed.)
- The parallelism and axial misalignment of the flange surface should be under the values shown
in the Table 8-1 to prevent damage the valve. (A failure to observe them can cause destruction
due to stress application to the pipe.)
- Tighten the bolts and nuts of the connection flange diagonally to the specified torque value.
(There is a risk of leakage or damage)

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
11
[Procedure]
1) Clean each other's flange surface with a waste cloth.
2) Set the AV gasket between the flanges.
3) Insert washers and bolts from the pipe side, insert washers and nuts
from the valve side, then temporarily tighten by hand.
4) Set the parallelism and axial misalignment of the flange surface
to the values shown in Table 8-1 or less. (Refer to Fig. 8-1.)
5) Tighten the bolts and nuts gradually with a torque wrench to the
Table 8-2 torque level in a diagonal manner. (Refer to Fig.8-2.)
6) In addition, tighten it more than 2 turns clockwise with
specified torque. (Refer to Fig.8-2.)
* When Union nut is loosen or remove, please install in the
following way.
[Procedure]
1) Make sure that the O-ring (A) is properly mounted to the body.
2) Set the End connector directly on the body without allowing the
O-ring (A) to come off.
3) Tighten Union nut on each valve until hand tight.
4) Using a strap wrench tighten Union nuts uniformly on each side
approx. 90°- 180° turns (1/4 to 1/2 turns).
Necessary
items
● Torque wrench ● Spanner wrench or box wrench
● Bolts, nuts and washers for piping ● AV gasket ● Waste cloth
Size Axial
misalignment
parallelism
(a-b)
15mm (½”)
1.0mm 0.5 mm
20mm (¾”)
25mm (1”)
32mm (1¼”)
40mm (1½”)
1.0 mm 0.8mm
50mm (2”)
Size PTFE
coated
PVDF
coated
Rubber
15mm (½”) 17.5
{179}
17.5
{179}
8.0
{82}
20mm (¾”)
25mm (1”) 20.0
{204}
20.0
{204}
20.0
{204}
32mm (1¼”)
40mm (1½”)
50mm (2”) 22.5
{230}
22.5
{230}
22.5
{230}
Fig.8-1
（
Axial misalignment
）
（
Parallelism
）
b
a
Table 8-1
Parallelism and axial misalignment
Fig.8-2
Table 8-2 Recommended torque value
Unit: N-m {kgf/cm2}
O-ring (A)

Installation, Operation and Maintenance Manual
【H-A077-E-00】3-Way Ball valve Type 23 Electric actuated Type Z 15～50mm (½”-2”)
12
Threaded end
- When suspending and supporting a valve, take care and do not stand under a suspended
valve.
- Do not to over-tighten the Union nut. (The valve can be damaged.)
- Do not use a pipe wrench when tightening the union nut. (The valve can be damaged.)
- Be sure to conduct a safety check on all hand and power tools to be used before beginning
work.
- When conducting piping work, wear personal protective equipment appropriate to the
contents of work. (Failure to do so may cause an injury.)
- When installing pipes and valves, ensure that they are not subjected to tension, compression,
bending, impact, or other excessive stress.
- The Union nut of this product is fastened lightly so that it can be loosened easily. Be sure to
remove the end connector before carrying out the work. (Failure to so may cause external
leakage.)
- When installing, disassembling, or reassembling the piping, fix the End connector.
- When installing a piece of equipment at the end of the piping line, be sure to keep the
secondary (Downstream) End Connector and Union nut installed on the valve.
- When connecting a ASAHI AV Valve to metal piping, take care not to let the pipe stress on the
ASAHI AV Valve.
- Make sure that the threaded connections are plastic x plastic. (Metallic thread can cause
damage.)
- Wrap the threaded joints on our plastic piping with sealing tape. Using a liquid sealing agent
or liquid gasket may cause stress cracks (Environmental Stress Cracking). Our product
warranty shall not apply in case of said use, even when said use is unavoidable.

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
13
[Procedure]
1) Wind a sealing tape around the external thread of joint, leaving
the end (about 3mm) free.
2) Loosen the Union nut with a hand.
3) Remove the Union nut and the end connector from the body.
4) Tighten the external thread of the joint and the end connector
hardly with hand.
5) Using a spanner wrench or motor wrench, screw in the end
connector by turning 180° -360° (1/2 to 1 turns) carefully
without damaging it.
6) Make sure that the O-ring (A) is properly mounted to the body.
7) Set the End connector directly on the body without allowing
the O-ring (A) to come off.
8) Tighten Union nut on each valve until hand tight.
9) Using a strap wrench tighten Union nuts uniformly on each
side approx. 90°- 180° turns (1/4 to 1/2 turns).
Necessary
items ● Sealing tape ● Strap wrench ● Spanner wrench or Motor wrench
Sealing tape
E
n
d
connector
Union nut
Fitting joint
O-ring (A)

Installation, Operation and Maintenance Manual
【H-A077-E-00】3-Way Ball valve Type 23 Electric actuated Type Z 15～50mm (½”-2”)
14
Socket end (For U-PVC, C-PVC)
- When suspending and supporting a valve, take care and do not stand under a suspended
valve.
- When using an adhesive, ventilate the space sufficiently, prohibit the use of a fire in the vicinity,
and do not inhale adhesive vapors directly.
- Do not to over-tighten the Union nut. (The valve can be damaged.)
- Do not use a pipe wrench when tightening the union nut. (The valve can be damaged.)
- Do not apply more adhesive than necessary. (The valve can be damaged due to solvent
cracking.)
- Do not under any circumstances try to insert a pipe into another fitting or valve by striking it.
(Which may break the piping.)
- Be sure to conduct a safety check on all hand and power tools to be used before beginning
work.
- When conducting piping work, wear personal protective equipment appropriate to the contents
of work. (Failure to do so may cause an injury.)
- When installing pipes and valves, ensure that they are not subjected to tension, compression,
bending, impact, or other excessive stress.
- The Union nut of this product is fastened lightly so that it can be loosened easily. Be sure to
remove the end connector before carrying out the work. (Failure to so may cause external
leakage.)
- When installing, disassembling, or reassembling the piping, fix the End connector.
- When installing a piece of equipment at the end of the piping line, be sure to keep the
secondary (Downstream) End Connector and Union nut installed on the valve.
- If an adhesive gets into contact with your skin, wash it off immediately. If you feel sick or find
anomaly, receive a physician's diagnosis and take appropriate measures promptly.
- Take care in doing work at low temperatures. Solvent vapors are hard to evaporate and are
likely to remain. (Solvent cracks may occur, damaging the equipment.)
- After assembling the piping system, open both ends of the piping and use a fan (of the Low-
Voltage Type) or something similar to ventilate the space, thus removing the solvent vapors.
- Use the appropriate Asahi AV cement.
- Conduct a water test at least 24 hours after joining the pipes with an adhesive.

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
15
[Procedure]
1) Loosen the Union nut with a hand.
2) Remove the Union nut and the end connector from the body.
3) Lead the Union nut through the pipe.
4) Make sure the hub part of the End connector is clean with waste
cloth.
5) Apply adhesive evenly to the hub part of the End connector and
the pipe spigot.（Refer to Table 8-3.）
6) After applying adhesive, insert the pipe quickly to the End
connector and leave it alone for at least 60 seconds.
7) Wipe away overflowing adhesive.
8) Make sure that the O-ring (A) is properly mounted to the body.
9) Set the End connector directly on the body without allowing
the O-ring (A) to come off.
10) Tighten Union nut on each valve until hand tight.
11) Using a strap wrench tighten Union nuts uniformly on each
side approx. 90°- 180° turns (1/4 to 1/2 turns).
Necessary
items ● Asahi AV cement ● Strap wrench ● Waste cloth
Size Quantity (g) [oz]
15mm (½”) 1.0 [0.035]
20mm (¾”) 1.3 [0.046]
25mm (1”) 2.0 [0.071]
32mm (1¼”) 2.4 [0.085]
40mm (1½”) 3.5 [0.123]
50mm (2”) 4.8 [0.169]
Table 8-3 Adhesive quantity (guideline)
O-ring (A)

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
16
Socket end (For PP, PVDF)
Spigot end (For PP, PVDF)
[Procedure]
1) Loosen the Union nut with a hand.
2) Remove the Union nut and the end connector from the body.
3) Lead the Union nut through the pipe.
4) For the next step, refer to the user’s manual for the sleeve
welder or the automatic welding machine.
5) Make sure that the O-ring (A) is properly mounted to the body.
6) Set the End connector directly on the body without allowing
the O-ring (A) to come off.
7) Tighten Union nut on each valve until hand tight.
8) Using a strap wrench tighten Union nuts uniformly on each
side approx. 90°- 180° turns (1/4 to 1/2 turns).
- When suspending and supporting a valve, take care and do not stand under a suspended
valve.
- Do not to over-tighten the Union nut. (The valve can be damaged.)
- Do not use a pipe wrench when tightening the union nut. (The valve can be damaged.)
- Be sure to conduct a safety check on all hand and power tools to be used before beginning
work.
- When conducting piping work, wear personal protective equipment appropriate to the contents
of work. (Failure to do so may cause an injury.)
- When installing pipes and valves, ensure that they are not subjected to tension, compression,
bending, impact, or other excessive stress.
- The Union nut of this product is fastened lightly so that it can be loosened easily. Be sure to
remove the end connector before carrying out the work. (Failure to so may cause external
leakage.)
- When installing, disassembling, or reassembling the piping, fix the End connector.
- When installing a piece of equipment at the end of the piping line, be sure to keep the
secondary (Downstream) End Connector and Union nut installed on the valve.
Necessary
items
● Strap wrench ● Sleeve welder or automatic welding machine
● User’s manual for sleeve welder or automatic welding machine
O-ring (A)

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
17
9. Support setting procedure
[Level plumber]
1) Spread the rubber sheet on the pipe or flange, and secure pipe with U-type clamp.
[Perpendicular plumber]
1) Spread the rubber sheet on the pipe or flange,
and secure pipe with U-type clamp.
2) Spread the rubber sheet under the actuator, and
support with stand.
- When installing a pipe support by means of a U-type clamp or something similar, take care
not to over-tighten. (Excessive force may damage the pipe.)
- Do not subject the valve to pump vibrations. (The valve may be damaged.)
- Be sure to conduct a safety check on all hand and power tools to be used before beginning
work.
- When valve supporting work, wear personal protective equipment appropriate to the contents
of work. (Failure to do so may cause an injury.)
Necessary
items ● Spanner wrench ● U-type clamp (with bolt) ● Rubber sheet
U-type clamp
Stand
Rubber seat
- Supporting example
(Socket end, Threaded end, Spigot end)
- Supporting example (Flanged end)
U-type clamp
Stand
Rubber seat
U-type clamp
Stand
Rubber seat
- Supporting example
Stand

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
18
10. Electric wiring procedure
- Do not wire while the power is on. (There is a possibility of electric shock.)
- Do not touch any parts on actuator circuit board or terminal block. (There is a possibility of
electric shock or equipment damage.)
- Do not exceed the rated capacity of contact limit switch.
- Do not connect two or more motor-driven valves in series.
- Do not use the product near high-voltage wire, inverter, or any other equipment that produces
electrical noise or magnetism. (The presence of such nearby may cause malfunction or
breakdown.)
- If you do not wire the signal lines, do not remove the sealing plug that came with the cable
gland.
- Install a switch (or a relay contact) for each motor-driven valve.
- Make sure to ground the earth line. (Electrical leakage could occur, leading to electrical shock,
fire, or other accident.)
- At the working, ensure that your hands are free of water and oil. (There is a possibility of electric
shock or equipment damage.)
- Follow the wiring diagram and wire correctly.
- Check the integrity of wiring insulation before connecting to the actuator.
- Tighten the terminal block with the recommended tightening torque (0.15 to 0.18 N-m) so that
it will not come loose. (There is a risk of electric shock or malfunction)
- Be careful not to let the conductors of the lead wires come into contact with each other. (There
is a risk of short circuit and fire)
-Tighten the cable gland securely with the recommended tightening torque (3 N-m). (There is a
risk of electric leakage or electric shock due to the ingress of rainwater, etc.
-The base cover is sealed with an O-ring. If you remove the base cover and reattach it, make
sure the O-ring is set correctly. (If the seal is insufficient, rainwater may enter the inside of the
actuator, resulting in electric shock or malfunction.)
-When using the product outdoors or in a place exposed to moisture such as rainwater, be sure
to tighten the cable connector of the actuator against the ingress of rainwater and all other
moisture. (Rainwater, etc. may enter the actuator and cause electric shock or malfunction.)
- The actuator supports a free power supply. Use it within the specified source voltage range. (If
it is used with a voltage out of the range, it may not work or it could break down.)
-The contact limit switch does not support minute loads (1mA to 100mA, 5V to 30V, when
connecting to a PLC, etc.) as a standard product, so select an optional product to use.
- Keep the equipment connected to the contact limit switch for the open / close signal within the
contact capacity (1A). (May be damaged)
- The length of the power supply cable to be connected should be 100 meters or shorter. (If the
cable length is longer than 100 meters, the actuator could malfunction.)
- If the distance from the operation panel to the actuator exceeds 100 meters, install a relay
between them. The distance from the relay to the actuator should be 100 meters or shorter.
Control
panel
100 meters or less
Relay box

Installation, Operation and Maintenance Manual
【H-A077-E-00】 3-Way Ball valve Type 23 Electric actuated Type 15～50mm (½”-2”)
19
[Procedure]
1) Remove the bolt cap. (Refer to Fig.10-1. Be careful not to lose the bolt cap.)
2) Loosen the four cover fixing screws by Phillips head screwdriver, and remove the cover.
3) Remove the dust seal and sealing plug from the cable gland, and thread the cable through. (Refer to
Fig.10-2.)
4) Strip cable sheath and lead wire insulator with the electric works knife and wire stripper.
5) Attach rod type solderless terminals to the tips of lead wires with a terminal crimper. To connect them
without using rod type solderless terminals, twist tips of wires not to protrude.
6) Use a Precision screwdriver (Flathead) to connect the Rod type solderless terminal (or the tip of the
lead) to the terminal block with the recommended tightening torque of 0.15 to 0.18 N-m according to
the wiring diagram. (Refer to Fig.10-3. It doesn't matter which of the two ground terminals is used.)
7) Tighten the cable gland with a spanner to the recommended tightening torque of 3N-m to secure the
cable.（Refer to Fig.10-4.）
8) Attach the cover using the "manual operation axis alignment position" as a guide.
9) After tightening the four screws that secure the cover with a Phillips screwdriver, attach the bolt cap.
Necessary
items
● Phillips head screwdriver ● Precision screwdriver (Flathead) ● Wire stripper
● Electric works knife ● Spanner wrench ● Terminal crimping tool
● Rod type solderless terminal
Bolt cap
Fig.10-1
Sealing plug Dust seal
Fig.10-2
Signal
output
terminal
Fig.10-3
Power input terminal
Ground terminal
Fig.10-4
Recommended
3 N-m
