Aseko ASIN AQUA User manual

www.asekopool.com
ASIN AQUA ASIN AQUA Net
CLF, REDOX, DOSE CLF, REDOX, DOSE
USER‘S MANUAL
EN

EN
2
General safety information
This user manual contain basic information that should be observed during assembly,
start-up, operation, and maintenance. Therefore, this user manual must be read by
installers and operators prior to assembly and start/up, and must be accessible to
every user of this unit. Additionally, all further safety information in this document
absolutely must be observed. Read and follow all instructions. In order to minimize
the danger of injury, do not allow children to use this product. Hazards from non-
compliance with safety information. Non-compliance with safety information can result
in hazards to persons, the environment, and the equipment. Non-compliance with
safety information will result in a forfeit of any potential right to damage compensation.
Insufficient personnel qualification
Hazards in the event of insufficiently qualified personnel,
potential consequence: Injury, heavy material damage.
•
The system operator must ensure compliance with the required qualification level.
•
Any and all work may only be performed by correspondingly qualified personnel.
•
Access to the system must be prevented for insufficiently
qualified persons, e.g. via access codes and passwords.
Potential overdosing of chemical agents
Despite ASIN Aqua® comprehensive safety functions, it is possible that
a probe failure and other errors could lead to an overdosing of chemical
agents. Potential consequence: Injury, heavy material damage.
•
Design your installation such that uncontrolled dosage is not possible in
the event of a probe failure or other errors, and/or such that uncontrolled
dosage is recognized and halted before damage is incurred.
•
Uncontrolled overdose of chemicals can cause harm to health and property.
Even though the device contains a number of security elements can not
be ruled out that in case of failure of the measuring probes, or the whole
device may result in overdose of chemical agents. Install the equipment
so that uncontrolled overdose of chemicals was not possible and that
uncontrolled overdose has been detected in time before causing any
harm. It is necessary to use chemicals in such quantities that an overdose
will not cause dangerous concentration of chemical agents. Do not use
chemicals in too large packages or with too high concentration.
Gaseous chlorine produced from dosing in standing water
if dosing outputs are not closed via the filter pump
If the flow switch is stuck or experiences another error, there is a risk
of dosing into standing water. Poisonous chlorine gas can be yielded
when sodium hypochlorite and pH minus come together.
Non compliance with informational text
There is a great deal of informational text indicating hazards and their
avoidance. Not observing informational text may lead to hazards. Potential
consequence: gravest degree of injury, heavy material damage.
•
Read all informational text carefully.
•
Cancel the process if you are unable to exclude all potential hazards.

EN 3
Use of new functions
Because of the continued development, a ASIN Aqua® unit may contain
functions, which are not completely described in this version of the user
manual. The use of such new or extended functions without a profound and
secure understanding by the operator may result in malfunctions and severe
problems. Potential consequence: Injury, heavy material damage.
•
Make sure to get a profound and secure understanding of a function
and relevant boundary conditions, before you start to use it.
•
Check for an updated version of the user manual or additional
documentation available for the relevant functions.
•
Make use of the integrated help function of the ASIN Aqua® to get
detailed information on functions and their parameter settings.
•
In case it should not be possible to get a profound and secure understanding
of a function based on the available documentation, do not use this function.
Overdosing if pH value is wrong
If disinfection is enabled before the pH value is stable in the ideal
range of 7.0 to 7.4, then it may lead to heavy overdosing of chlorine or
bromine. Potential consequence: Injury, heavy material damage.
•
Do not start disinfection with chlorine until the pH value is
stable in the ideal range between 7.0 and 7.4.
Conditions before using
Make sure you have a newest and updated version of the user manual
and other documentation for all functions of the unit. Use and read the
integrated help features. In case of not understanding the information
about certain features of the unit, do not use these features.
Handling chemicals for pool water treatment
The chemicals used with the ASIN Aqua must be handled in a safe manner
to prevent damage or personal harm. Aseko recommends you always
use personal protective safety equipment when handling the pH and
chlorine agents. Refer to the Materials Safety Data Sheet (MSDS).
WARNING:
Never mix the pH agent with the chlorine agent. When
carrying out maintenance on the clear plastic tubes or valves always rinse
with clean water to prevent mixing of the pH and chlorine agents.

EN
4
What’s in the box
Dowels and screws
#12125
ASIN AQUA
or
UA Net
ASIN AQUA Net
ická
Peristaltická
čerpadla
#12093
Water valves 2 pcs
#12006
Injection valve 2 pcs
#12005
Suction tube weight
2 pcs
#12023
Thermometer holder 1 pcs
#12044
(only for ASIN AQUA Net)
PE Tube 1/4” (6.35 mm)
transparent
#12008
Wrench socket for probes
#13046
CLF probe
#12052
or
Redox probe Long Life
# 12016
Flowmeter
with filter
#12106
Thermometer
#13192
N AQUA Net)
(only for ASIN AQUA Net)
#12052
pH probe Long Life
# 12012
# 12012
# 12016

EN 5
Available optional accessories
Volume 20l
Volume 5l
pH MINUS #12131
pH MINUS #12131
CHLOR PURE #12059
CHLOR PURE #12059
pH MINUS #12130
pH MINUS #12130
CHLOR PURE #12075
CHLOR PURE #12075
ASEKO original chemical solution
Inserting DN50 plug 1/4” threaded
for easy installation
#12134
pH 7.00 Buffer #12065
Redox Buffer #12063
Pool Lab Photometer
for accurate calibration #13076
External touch screen
(only for ASIN AQUA Net)
(only for ASIN AQUA Net)
#12048

EN
6
ASIN AQUA
ASIN AQUA CLF
# 12001
ASIN AQUA Redox
# 12144
ASIN AQUA Dose
# 12022
ASIN AQUA Net CLF
# 12036
ASIN AQUA Net Redox
# 12035
ASIN AQUA Net Dose
# 12034

EN 7
ASIN AQUA
ASEKO’s ASIN AQUA gives you pool clean and sparkling water with the
minimum amount of chemicals. By directly measuring and controlling the
free chlorine content or redox potential of your pool water with advanced CLF
(freechlorine) or redox probe. ASIN AQUA tunes your pool water using the
minimum amount of chlorine, eliminating the smell and burning of overtreated
pools. With a touch screen interface, you have complete control over
measurement andregulation of your pool.
Pool water treatment
Chlorine control and dosing
Highly effective disinfection treatment of pool water for public and private
pools. Extraordinary precise measuring of chlorine content in the pool water by
ASEKO CLF - free chlorine probe combined with the system digital intelligence
is able to control the preset disinfection level by usage of minimum necessary
chemical aids.
pH control and dosing
ASIN AQUA Net is adjustable to dose pH MINUS or pH PLUS. Treatment for
stabilizing of pool water acidity at the optimum level. Precise measuring by
pH probe combined with the system digital intelligence controls the preset
pH level of the circulating pool water in all pool operation modes and variable
environment conditions.

EN
8
40 °C
max.
5 °C
min.
3
0
c
m
3
0
c
m
3
0
c
m
3
0
c
m
1
5
0
c
m
8,1 cm
ø
8 mm
ø
8 mm
m
a
x
2 m
m
a
x
8 m
ASIN AQUA installation
ASIN AQUA is to be wall mounted in dry and dust-free environment with
temperature ranging from +5 °C to +40 °C. The location must be selected so
that there is at least 30 cm of free space on all sides and a height above the floor
was max. 150 cm. Use the screws supplied with ASIN AQUA for fastening.
Maximum distance of injection valves
from peristaltic
ASIN AQUA pumps must not exceed
8 m.
Vertical distance between
ASIN AQUA and the bottom
of the tanks must not exceed a distance of
2 m.
WARNING
The temperature at the installation site should be permanently between
+5 ° and + 40 ° C. Humidity max 70% RH.
Direct sunlight, high humidity and dust can lead to damage ASIN AQUA.
SWIMMING POOL WATER
ASIN AQUA must be installed on
fresh water
reated by
ter
reated by
INORGANIC
superchlorination agent (
SUPERCHLOR
# 13120).
Do not use organic chlorine!
Ensure that the water in the pool
DOES NOT CONTAIN STABILIZERS
(CYANURIC ACID)
and other impurities!

EN 9
CLF probe
# 12052
pH probe
Long Life
#12012
Redox probe
Long Life
#12016
Probe wrench
Probe installation
Carefully insert the
CLF or Redox probe
into the well on the left.
Tighten by hand or with the included plastic probe wrench.
Connect the connector (marked in yellow)
Carefully insert the
pH probe
into the well on the right. Tighten by hand or with
the included plastic probe wrench. Connect the connector (marked in blue).
WARNING
Tighten the probes only by hand or with the enclosed plastic wrench.
Do not use pliers or other tools!
1
1 2
2

EN
10
ASIN AQUA Net
MEASURED WATER
DRAINAGE
OL
TO POOL
Heating
FROM
POOL
POOL
Pump
Pump
MEASURED
WATER
SUPPLY
SUPPLY
INLET
OUTPUT
Coagulation
mixer
Besgo
Filtration
Thermometer
1
2
3
4

EN 11
Pool Water Connection
The pool water to be measured must be brought to the ASIN AQUA probes.
We place the
shut-off valve
in the plug D = 50 with thread G1 / 4 “# 12134,
glued to the T-piece.
Tighten by hand only. Do not use pliers or other tools.
Connect the
MEASURED WATER SUPPLY
to the pipe
PLY
to the pipe
behind the pump,
in front of the filter
and the coagulation mixer.
lter
and the coagulation mixer.
Connect the
MEASURED WATER DRAINAGE
to the pipe
GE
to the pipe
behind the filter
and heating or into the overflow tank or skimmer
.
Use to connect the measured water to your ASIN AQUA PE tube 1/4 “(6.35 mm)
#12008, which is part of the delivery.
The measured water is easily connected to your ASIN AQUA using the
Speedfit
push-in fitting.
CONNECTION
Push the connecting pipe into the Speedfit fitting
and then pull on the hose to secure.
DISCONNECT
push and hold the Speedfit round collet
CT
push and hold the Speedfit round collet
and pull out the connecting pipe.
INLET
of the measured water to the ASIN AQUA Connect to the Speedfit
LET
of the measured water to the ASIN AQUA Connect to the Speedfit
fitting on the inlet filter.
OUTPUT
of the measured water from ASIN AQUA connect to the Speedfit
UT
of the measured water from ASIN AQUA connect to the Speedfit
fitting on the probe well.
Once connected, your ASIN AQUA is ready to measure disinfectant content and
pH value in your pool.
Water valve fitting
Plug with
D = 50 with
thread 1/4“
T-joint
Water valve
fi t t i n g
G1/4” thread
CONNECTION
LOCKING
DISCONNECTION
Pull out
PE tube 1/4 “(6.35 mm)
90°
PE tube 1/4 “(6.35 mm)
WARNING
To ensure that the joints are tight, cut the PE tube at an angle of 90 °.
Usespecial pliers # 13325 to cut plastic tubes. The cut must be clean
andsmooth. Do not use ordinary scissors or knives!
1
3
2
4

EN
12
Max 8 m
Max 8 m
Max 8 m
Max 8 m
Max 2 m
ASIN AQUA Net
CHLOR
PURE
pH
MINUS
1 2
3
4
OL
TO POOL
Heating
FROM
POOL
POOL
Pump
Pump
Coagulation
mixer
Besgo
Filtration
Thermometer

EN 13
Pool Chemicals
Connection
Screw the
injection valves
into the plug D = 50 with thread G1 / 4 “# 12134,
glued to the T-piece.
Tighten by hand only. Do not use pliers or other tools.
Connect the
pH INJECTION VALVE
to the piping behind the filter and behind
VE
to the piping behind the filter and behind
drainage of the measured water.
Connect the
CHLOR PURE INJECTION VALVE
behind the INJECTION VALVE,
VE
behind the INJECTION VALVE,
this prevents scale formation.
to connect reagents to ASIN AQUA use PE pipe 1/4 “(6.35 mm) # 12008,
whichis part of the delivery.
CANISTER CONNECTION
Drill 6.35 mm and 1 mm diameter holes in the
canister cap. Pass the pipe through the cap so that it reaches to the bottom
of the canister. Place the suction basket at the end of the pipe.
PUMP CONNECTION
connect the suction of the pump on the left to the
canister connect the pump discharge on the right to the injection valve.
INJECTION VALVE CONNECTION
Pass the pipe through the nut, thread
the pipe onto the injection valve and tighten the nut firmly by hand.
Ø 1 mm Ø 6,35 mm
1
2
3
4
5
5
4
3
WARNING
To ensure that the joints are tight, cut the PE tube at an angle of 90 °.
Usespecial pliers # 13325 to cut plastic tubes. The cut must be clean
andsmooth. Do not use ordinary scissors or knives!
WARNING
NEVER CONNECT pH minus reagent to disinfection pump or
disinfectant to pH pump! In the case of a cross-connection, after ten doses
ASIN AQUA displays an error message. Repair the piping installation and then
you can continue to operate your ASIN AQUA.
Plug with
D = 50 with
thread 1/4“
T-joint

EN
14
Power Supply
Connection to the mains:
Connect the 230 V / 50 Hz main cable to ASIN AQUA .
After device has been switched on, the display will come on and the ASIN AQUA
Net starting screen will appear.
Disconnection from the mains:
Disconnect the ASIN AQUA Net mains cable from the 230 V / 50 Hz
socket outlet.
RCD
Timer
Current
protector
30 mA
230 V / 50 Hz
230 V / 50 Hz
Filter pump
The mains socket outlet must be protected by
aresidual current device (RCD).
WARNING
If device is used in the manner different from that specified by the
manufacturer, protection provided by cevice may get damaged.

EN 15
Installation Test
Before commencing the operation, test ASIN AQUA installation.
Most problems result from incorrectly performed installation.
Test
In the “Test of Outputs” menu, gradually start all the pumps and while they are
running, check tightness of all the PE tube connections. Check the injecting
valves for blockage and air bubbles in the PE tube.
Check tightness of all the
connections.
Liquid must reach spraying
andsubsequently the tube.
If bubbles occur here, the
pump draws air in. Repair
theconnection - disconnect
the tube, cut the end carefully
in90° angle and plug it back.
Monitor level in the
transparent plastic tube.
WARNING
Any obstacles, bubbles or leaks in the connecting tube will prevent
ASIN AQUA Net from correct operating. The clear plastic tube allows you
to monitor flow of liquid to the injecting valves.
1
2
3

EN
16
Control principles
Home screen
The home screen displays measured, required values and status information.
E.g. click on the
Chlorine
tab to enter the setting of the required chlorine
value in pool water.
Required value
Water temperature
Help
mV output signal
from the CLF probe
Settings
Measured
value
The disinfection
pump doses
Decrease value
Increase value
Back to home
screen
Back to previous
screen
Select
Settings
Back to home
screen
Back to previous
screen
Start the dosing test

EN 17
Settings
Configuration -
pool volume, pool type, water hardness
Pool volume -
set pool volume
Calibration -
pH probe, CLF probe, thermometer
Chose the type of probe -
Chose the type of desinfection probe
Dosing test -
test pump and manual dosing
Language -
Set the language of the ASIN AQUA Net
Setting pool parameters
Each pool is unique. Temperature, size, location, and hardness of water all
affect how ASIN AQUA monitors and tunes your pool water. For optimum
performance, you must set your pool properties in ASIN AQUA.
Pool volume
To ensure the correct function of ASIN AQUA Net, enter the correct volume of
your. Calculate your pool volume in m
3
: Length (L) times width (W) times depth
(D) is volume (V) - (L×W×D=V). Enter the value using + and - buttons.
Pool type
Choose a type of your pool.
Hard water
Set the pool water hardness in dH, 0-9 is soft, 9-21 is hard and 21+ is very hard.
Flowmeter
The flowmeter detects flow of measured water. Dosing of chemicals will take
action only if flow of measured water to probes is detected.
Wash the check flowmeter strainer on a regular basis.
WARNING
The pool volume has effect on the maximum safe dose, enter the
correct value!
WARNING
Only switch off the flowmeter in case of a failure!

EN
18
Setting Values
Commissioning procedure
1. Ensure the filtration system runs NONSTOP
for 24 hours
•
Set the required values via the main screen by pressing the appropriate tab
(see the chapter Control):
•
If you have the CLF probe, set the disinfection to 0.0 mg/l. If you have the
REDOX probe, set the disinfection to 000 mV.
•
pH values leave at the factory setting for the time being (pH 7.0).
2. Close the water supply to the probes
ASIN AQUA Net displays „No water supply to the probes“ notification.
3. Perform superchlorination
Perform superchlorination of pool water with Super CHLOR
(inorganic active chlorine without stabilizers). Follow the instructions
on the packaging (1 kg = 80m³).
Choosing the disinfection probe
1.
CLF free chlorine probe
Free chlorine measurement, CHLOR PURE dosing
2.
Redox probe
of the RX potential
Measurement of redox potential, CHLOR PURE dosing
DOSE ml/m
3
time dose per hour
Without a probe
Free chlorine measurement, CHLOR PURE dosing
Measurement of redox potential, CHLOR PURE dosing
SWIMMING POOL WATER
ASIN AQUA must be installed on
fresh water
reated by
ter
reated by
INORGANIC
superchlorination agent (
SUPERCHLOR
# 13120).
Do not use organic chlorine!
Ensure that the water in the pool
DOES NOT CONTAIN STABILIZERS
(CYANURIC ACID)
and other impurities!

EN 19
4. Wait at least 1 hour. Optimally up to 24 hours.
Before opening the water supply
to the probes, the water must be
ply
to the probes, the water must be
clean
and the
chlorine concentration
measured by the colorimeter or Pool Tester
must be within the range
0.3 to 1.2 mg/l
.
If the
concentration is lower
, repeat superchlorination. If the
concentration
is higher
, wait till the chlorine concentration in the water drops down.
5. Open the water supply to the probes
The „No water supply to the probes“ notification will disappear from the ASIN
AQUA display.
6. pH adjustment
•
Set the required pH value ideally close to the pH value of the incoming
water.
•
ASIN AQUA Net adjusts the pH automatically according to the preset
required value.
•
The ideal pH value should be between 6.8 and 7.5.
7. Depending on the type of a probe you have,
proceed according to the chapter:
•
If you have the CLF probe
•
If you have the REDOX probe

EN
20
If you use the CLF probe
For the correct functionality of the CLF probe you must observe the
following conditions:
pH of the pool water
The ideal pH value should be between
6.8 and 7.5.
The pH of the pool water must be stabilized.
If the pH value fluctuates, the value of the chlorine in pool water changes
accordingly.
Determination of the required chlorine value in pool
water
The required concentration of chlorine in pool water varies with the temperature
of the pool water. However, it should never be less than 0.3 mg/l. Determine the
required value using the table located on the left.
How to set the required chlorine value
Use a colorimeter or Pool Tester to measure the chlorine value in pool water
sample.
If the chlorine concentration (measured with a colorimeter or Pool
Tester) is:
• ADEQUATE
to the value shown on the ASIN AQUA Net display
, your
device is ready to maintain the required concentration of chlorine in pool
water.
• BELOW
the required value shown on the ASIN AQUA Net display,
increase
the required value over the current setting by 0.1 (by 0.2 mg/l
max) (regardless of the required value according to the table).
Repeat the measurement after the water in the pool is mixed thoroughly and
the required value shown on the ASIN AQUA Net display is settled. Repeat
the process until the
chlorine concentration in pool water matches the
required value
then set the correct required value according to the table.
Subsequently you can calibrate the CLF probe (see the chapter CLF Probe
Calibration).
• HIGHER
than the required value shown on the ASIN AQUA Net
display
- you can calibrate the CLF probe (see the chapter CLF Probe
play
- you can calibrate the CLF probe (see the chapter CLF Probe
Calibration).
NOTIFICATION:
Fix the low chlorine value in pool water by
increasing required disinfection
value
.
RECOMMENDATION:
Check the chlorine content in the pool once a week using the colorimeter or
tester.
Chlorine
Level mg/l
Water
Temperature
0,3 – 0,5
24 – 26 °C
0,5 – 0,8
26 – 32 °C
0,8 - 1
higher than 32 °C
