ASEM HMI30 User manual

ASEM Open Automation Systems
USER’S GUIDE
Code 86060322
Version A01
Date 16.07.2012
HMI30 / HMI30-TF

ii
Revisions
Revisor
Date
Release
Thei
ES Draft
Thei –Mantovani - Fumagalli
22/11/2011
A00
Thei –Boscolo –Zamò -
Mantovani
16/06/2012
A01

iii
Summary
SECTION 1 ........................................................................................................................................................................................................... 1
1Preliminary Information............................................................................................................................................................................. 1
1.1 General notes ....................................................................................................................................................................................2
1.2 Trademarks........................................................................................................................................................................................2
1.3 Instructions on disposal .....................................................................................................................................................................2
1.4 Description of safety symbols.............................................................................................................................................................3
1.5 Qualified Personnel ...........................................................................................................................................................................4
1.6 Basic knowledge required ..................................................................................................................................................................4
1.7 Proper use of the product ..................................................................................................................................................................4
1.8 Purpose of the user’s guide................................................................................................................................................................4
1.9 The manual is a part of the system.....................................................................................................................................................4
1.10 Figures...............................................................................................................................................................................................4
1.11 Scope of the operating instructions....................................................................................................................................................5
1.12 Safety instructions .............................................................................................................................................................................5
1.12.1 Installation according to the instructions ..................................................................................................................................5
1.12.2 Hazardous areas .......................................................................................................................................................................5
1.12.3 Working on the control cabinet.................................................................................................................................................5
1.13 Notes about usage .............................................................................................................................................................................6
1.14 Applicable standard ...........................................................................................................................................................................6
SECTION 2 ........................................................................................................................................................................................................... 7
2Description ................................................................................................................................................................................................ 7
2.1 Product description............................................................................................................................................................................8
2.2 Key features.......................................................................................................................................................................................8
2.3 Package .............................................................................................................................................................................................8
2.4 Configuration.....................................................................................................................................................................................9
2.4.1 HMI30 (full aluminium front panel) ...............................................................................................................................................9
2.4.2 HMI30-TF (aluminium front panel with true flat technology) .........................................................................................................9
2.4.3 Main difference between full aluminium front panel and aluminium front panel with true flat technology..................................10
2.5 Front view .......................................................................................................................................................................................11
2.5.1 Full aluminium front panel .......................................................................................................................................................... 11
2.5.2 Aluminium front panel with True Flat technology ........................................................................................................................11
2.5.3 Widescreen.................................................................................................................................................................................12
2.6 Rear view.........................................................................................................................................................................................13
2.7 Side view .........................................................................................................................................................................................15
2.8 Connector view................................................................................................................................................................................16
2.8.1 Labels..........................................................................................................................................................................................16
2.9 Touchscreen ....................................................................................................................................................................................17
2.10 Putting in operation HMI30..............................................................................................................................................................18
2.10.1 Configuration and project creation ......................................................................................................................................... 18
2.10.2 Process management..............................................................................................................................................................18
2.11 Software options .............................................................................................................................................................................19
SECTION 3 ......................................................................................................................................................................................................... 21
3Installation and connection ...................................................................................................................................................................... 21
3.1 Preparation for installation ..............................................................................................................................................................22
3.1.1 Select the mounting location.......................................................................................................................................................22
3.2 Checking the package contents ........................................................................................................................................................22
3.3 Checking the operating conditions ...................................................................................................................................................22
3.4 Mounting position ...........................................................................................................................................................................23
3.4.1 Damage due to overheating ........................................................................................................................................................23
3.5 Checking installation distances.........................................................................................................................................................24
3.6 Preparing the mounting cut-out .......................................................................................................................................................24
3.6.1 Degrees of protection..................................................................................................................................................................25
3.6.2 Cut-out measures........................................................................................................................................................................ 25
3.7 Mounting the device........................................................................................................................................................................27
3.7.1 Position of the mounting clamps .................................................................................................................................................27
3.7.2 Tools to tighten the mounting clamps..........................................................................................................................................28
3.7.3 Procedure ...................................................................................................................................................................................29
3.8 Connecting the device...................................................................................................................................................................... 32
3.8.1 Notes on connection ...................................................................................................................................................................32
3.8.2 Grounding and bonding...............................................................................................................................................................32
3.8.3 Power supply connection ............................................................................................................................................................32
3.8.4 Switching on and testing the HMI Device.....................................................................................................................................33
3.9 Connecting the configuration PC ......................................................................................................................................................34
3.9.1 Procedure ...................................................................................................................................................................................37
SECTION 4 ......................................................................................................................................................................................................... 39
4Commissioning the device........................................................................................................................................................................ 39
4.1 Backup design..................................................................................................................................................................................40

iv
4.2 Internal memory..............................................................................................................................................................................40
4.3 Slot for memory card .......................................................................................................................................................................41
4.4 Installation/removal of a memory card ............................................................................................................................................41
SECTION 5 ......................................................................................................................................................................................................... 43
5Commissioning a project .......................................................................................................................................................................... 43
5.1 Overview .........................................................................................................................................................................................44
5.2 Transfer ...........................................................................................................................................................................................44
5.3 Configuring the serial port................................................................................................................................................................44
5.3.1 Connecting the serial port ...........................................................................................................................................................46
5.4 Managing the project.......................................................................................................................................................................46
5.4.1 Stopping the running project.......................................................................................................................................................47
5.4.2 Starting the project .....................................................................................................................................................................48
5.4.3 Debugging the project .................................................................................................................................................................49
5.4.4 Trasfer the project from HMI30 to the configuration PC...............................................................................................................51
5.5 Backup and restore ..........................................................................................................................................................................52
5.6 Updating the operating system ........................................................................................................................................................52
SECTION 6 ......................................................................................................................................................................................................... 53
6Maintenance and care.............................................................................................................................................................................. 53
6.1 Calibration of the touchscreen .........................................................................................................................................................54
6.2 Maintaining & cleaning ....................................................................................................................................................................55
6.2.1 Procedure ...................................................................................................................................................................................56
6.2.2 Backup battery replacement (CR2032 3V)....................................................................................................................................56
6.3 Technical support & repairs..............................................................................................................................................................59
6.4 Recycling and disposal .....................................................................................................................................................................59
SECTION 7 ......................................................................................................................................................................................................... 61
7Technical specifications............................................................................................................................................................................ 61
7.1 Technical specifications....................................................................................................................................................................62
7.1.1 5.7” display characteristics ..........................................................................................................................................................65
7.1.2 7” display characteristics............................................................................................................................................................. 65
7.1.3 8.4” display characteristics ..........................................................................................................................................................65
7.1.4 10.4” display characteristics ........................................................................................................................................................66
7.1.5 12.1” (SVGA) display characteristics.............................................................................................................................................66
7.1.6 12.1” (XGA) display characteristics .............................................................................................................................................. 66
7.1.7 15.0” display characteristics ........................................................................................................................................................67
7.2 Certificates and approvals................................................................................................................................................................67
7.3 Dimension drawings ........................................................................................................................................................................ 68
7.3.1 HMI30 5.7” (Full Aluminium front panel) .....................................................................................................................................68
7.3.2 HMI30-TF 5.7” (Aluminium front panel with True Flat technology)............................................................................................... 69
7.3.3 HMI30 7.0” (Wide Full Aluminium front panel) ............................................................................................................................70
7.3.4 HMI30-TF 7.0” (Wide Aluminium front panel with True Flat technology)...................................................................................... 71
7.3.5 HMI30 8.4” (Full Aluminium front panel) .....................................................................................................................................72
7.3.6 HMI30-TF 8.4” (Aluminium front panel with True Flat technology)............................................................................................... 73
7.3.7 HMI30 10.4” (Full Aluminium front panel) ...................................................................................................................................74
7.3.8 HMI30-TF 10.4” (Aluminium front panel with True Flat technology).............................................................................................75
7.3.9 HMI30 12.1” (Wide Full Aluminium front panel) ..........................................................................................................................76
7.3.10 HMI30-TF 12.1” (Wide Aluminium front panel with True Flat technology) ...............................................................................77
7.3.11 HMI30 15.0” (Full Aluminium front panel)............................................................................................................................... 78
7.3.12 HMI30-TF 15.0” (Aluminium front panel with True Flat technology) ........................................................................................79
7.4 Ports PINOUT................................................................................................................................................................................... 80
7.4.1 COM1 –DB15M Serial .................................................................................................................................................................80
7.4.2 LAN1 –LAN2 ...............................................................................................................................................................................80
7.4.3 USB1 / USB2................................................................................................................................................................................83
7.5 Technical support & repairs..............................................................................................................................................................83

v

1
HMI30 / HMI30-TF User’s guide
SECTION 1
1Preliminary
Information

2
SECTION 1 –Preliminary Informations
IT
EN
FR
1.1 General notes
a) The information in this manual is subject to change and is in no way
binding upon ASEM S.p.A.
b) ASEM S.p.A. is not responsible for technical errors or other omissions in
the manual, and shall not accept any responsibility deriving from its use.
1.2 Trademarks
a) All brands and product names mentioned in this manual are trademarks
of their respective owners.
1.3 Instructions on disposal
Il simbolo sul prodotto o sulla confezione indica che il prodotto non
deve essere considerato come un normale rifiuto domestico, ma deve
essere portato nel punto di raccolta appropriato per il riciclaggio di ap-
parecchiature elettriche ed elettroniche. Provvedendo a smaltire questo
prodotto in modo appropriato, si contribuisce a evitare potenziali conse-
guenze negative per l’ambiente e la salute, che potrebbero derivare da
uno smaltimento inadeguato del prodotto. Per informazioni più detta-
gliate sul riciclaggio di questo prodotto, contattare l’ufficio comunale, il
servizio locale di smaltimento rifiuti o il fornitore da cui è stato acquista-
to il prodotto.
The symbol on the product or in its packaging indicates that this
product may not be treated as household waste. Instead it shall be
handed over the applicable collection point for the recycling of electrical
and electronic equipment. By ensuring this product is disposed of cor-
rectly, you will help prevent potential negative consequences for the en-
vironment and human health, which could otherwise be caused by inap-
propriate waste handling of this product. For more detailed information
about recycling of this product, please contact your local city office, your
household waste disposal service or the supplier where you purchased
the product.
Le symbole sur le produit ou son emballage indique que ce produit
ne peut être traitè comme décher ménager. It doit être remis au point
de collecte dèdié à cet effect (collect et recyclage du matèriel èlectrique
et èlectronique). En procèdant à la mise à la casse règlementaire de
l’appareil, nous prèservons l’environnement et notre sécurité, s’assurant
ainsi que les dèchets seront traitès dans des conditions appropriées.
Pour obtenir plus de dètails sur le recyclage de ce produit, veuillez
prendre contact avec les services de votre commune ou le distributeur
où vous avez effectué l’achat.

3
HMI30 / HMI30-TF User’s guide
DE
ES
PT
Das Symbol auf dem Produkt oder seiner Verpackung weist darauf
hin, dass dieses Produkt nicht als normaler Haushaltsabfall zu behandeln
ist, sondern an einem Sammelpunkt für das Recycling von elektrischen
und elektronischen Geräten abgegeben werden muss. Durch ihren Bei-
trag zum korrekten Entsorgen dieses Produkts schützen Sie die Umwelt
und die Gesundheit Ihrer Mitmenschen. Umwelt und Gesundheit
werden durch falsches Entsorgen gefährdet. Weitere Informationen über
das Recycling dieses Produkts erhalten Sie von Ihrem Rathaus, Ihrer Mül-
labfuhr oder den Distributoren, in dem Sie das Produkt gekauft haben.
El simbolo en el producto o en su embalaje indica que este produc-
to no se puede tratar como desperdicios normales del hogar. Este pro-
ducto se debe entregar al punto de recolección de equipos eléctricos y
electrónicos para reciclaje. Al asegurarse de que este producto se dese-
che correctamente, usted ayudará a evitar posibles consequencias nega-
tivas para el ambiente y la salud pública, lo qual podria ocurrir si este
producto no se manípula de forma adecuada. Para obtener informació-
nes mas detalladas sobre el reciclaje de este producto, póngase en con-
tacto con la adMinistraciòn de su ciudad, con su servicio de desechos del
hogar o con el surtidor donde comprò el producto.
simbolo no produto ou na embalagem indica que este producto não
pode ser tratado como lixo doméstico. Em vez disso, deve ser entre-
gueado ao centro de recolha selectiva para a reciclagem de equipamen-
to electrico e electronico. Ao garantir uma eliminação adequada deste
produto, ira ajudar a evitar eventuais consequencjas negativas para o
meio ambiente e para a saude publica, que, de outra forma, poderiam
ser provocadas por un tratamento incorrecto do produto. Para obtener
informações mais detalhadas sobre a reciclagem deste produto, contac-
te os serviços municipalizados locais, o centro de recolha selectiva da
sua area de residência ou no distribuidor onde adquirir ou produto.
1.4 Description of safety symbols
Danger
This symbol indicates a danger to life or health of personnel.
Attention
This symbol indicates a danger to the hardware and / or the en-
vironment.
Note
This symbol indicates an additional information meant to provide
a better understanding.

4
SECTION 1 –Preliminary Informations
1.5 Qualified Personnel
a) HMI30 may be operated only by personnel qualified for the specific task
in accordance with the relevant documentation for the specific task, in
particular its warning notices and safety instructions.
b) Qualified personnel are those who, based on their training and experi-
ence, are able to identify risks and avoid potential hazards when working
with these systems.
1.6 Basic knowledge required
a) To understand operating instructions a general knowledge of automa-
tion technology is needed.
b) Knowledge of personal computers and the Microsoft operating system is
required to understand this user’s guide.
1.7 Proper use of the product
a) ASEM products may only be used for the applications described in the
catalogue and in the technical documentation.
b) If products and components from other manufacturers are used, these
must be approved by Asem.
c) Proper transport, assembly, installation, storage, commissioning, opera-
tion and maintenance are required to ensure that the product operates
safely.
d) The indicated environmental conditions must be observed.
e) The information in this user’s manual must be observed.
1.8 Purpose of the user’s guide
a) This user’s manual contains information based on the requirements de-
fined by DIN EN 62079 for mechanical engineering documentation.
b) These operating instructions are intended for:
1. Users.
2. Commissioning engineers.
3. Maintenance personnel.
c) Pay attention at the information in the chapter "Safety instructions".
d) More information such as operating instructions, examples and refer-
ence information, are available in the online help of Premium HMI 3
software and Ubiquity software.
1.9 The manual is a part of the system
a) This user’s guide belongs to HMI30 and is also required for commission-
ing.
b) Keep all supplied documentation for the entire service life of HMI30.
1.10 Figures
a) This manual contains illustrations of the described devices.
b) Some details of the illustrations may differ from the device provided.

5
HMI30 / HMI30-TF User’s guide
1.11 Scope of the operating instructions
c) The operating instructions apply to the HMI30 family devices in conjunc-
tion with the Premium HMI 3 software.
The devices are the following:
HMI30
5.7”
Full aluminum front panel
7.0” Wide
8.4”
10.4”
12.1”
15.0”
HMI30-TF
5.7”
Aluminum front panel with True
Flat technology
7.0” Wide
8.4”
10.4”
12.1”
15.0”
1.12 Safety instructions
1.12.1 Installation according to the instructions
Commissioning the HMI device is prohibited until it has been absolutely
ensured that the system in which the HMI device is to be installed com-
plies with all the applicable EU and international regulation.
1.12.2 Hazardous areas
Do not use HMI30 in hazardous areas.
1.12.3 Working on the control cabinet
Open equipment
The HMI device is open equipment. This means that the HMI30 may only
be integrated in housings or cabinets, where it can be operated from the
front panel.
The cabinet in which HMI30 is installed may only be accessed with a key
or tool and only by trained and authorized personnel.
Dangerous voltage
Opening the cabinet may expose high voltage parts. Before opening the
cabinet always disconnect the power.

6
SECTION 1 –Preliminary Informations
1.13 Notes about usage
HMI30 is approved for indoor use only.
HMI30 may be damaged if operated outdoors.
1.14 Applicable standard
Please refer to section 8 for details about the relevant standards.

7
HMI30 / HMI30-TF User’s guide
SECTION 2
2Description

8
SECTION 2 - Description
Table 1
Package
2.1 Product description
The HMI30 family is the HMI solution with RISC architecture that allows running
Premium HMI3 and Ubiquity software platforms.
Based on ARM Cortex A8 processor and Microsoft Windows Embedded Com-
pact 7 (C7P) operating system, HMI30 is available in BASIC or ADVANCED ver-
sion according to Premium HMI 3 runtime installed.
The systems can have standard (HMI30) or true flat (HMI30-TF) front frame.
2.2 Key features
CPU ARM CORTEX A8
Frontal IP 65
O.S. Microsoft Windows Embedded Compact 7 (C7P) installed on flash
memory.
Data and programs are contained in two different flash disk devices.
Asem Premium HMI software.
Asem Ubiquity software.
2.3 Package
HMI30 package consists of:
HMI30 system
User’s guide CD
Quick Installation guide
n.10 Clamps with grub
screw (depending of the
LCD size)
n.1 Power supply plug
Premium HMI software CD
Ubiquity software CD

9
HMI30 / HMI30-TF User’s guide
Figure 1
HMI30 5.7”
Figure 2
HMI30-TF 5.7”
2.4 Configuration
The following figures show the various configurations.
2.4.1 HMI30 (full aluminium front panel)
HMI30
5.7”
Full aluminum front panel
7.0” Wide
8.4”
10.4”
12.1”
15.0”
2.4.2 HMI30-TF (aluminium front panel with true flat
technology)
HMI30-TF
5.7”
Aluminium front panel with True
Flat technology
7.0” Wide
8.4”
10.4”
12.1”
15.0”

10
SECTION 2 - Description
Figure 3
Front panel “Step” detail
Figure 4
Front panel “No step” detail
2.4.3 Main difference between full aluminium front panel and
aluminium front panel with true flat technology
The aluminium front panel has a “step”between the front panel and
the touchscreen.
The front panel with true flat technology has no “step”between the
front panel and the touchscreen, therefore it can be easily cleaned.
The polyester top-film covers the resistive touchscreen up to the alu-
minium border.
Step
NO Step

11
HMI30 / HMI30-TF User’s guide
Figure 5
Full aluminium front panel detail
Figure 6
Aluminium front panel with
true flat technology detail
2.5 Front view
2.5.1 Full aluminium front panel
Full aluminium front panel
Touchscreen display
2.5.2 Aluminium front panel with True Flat technology
Aluminium front panel with top polyester film
Touchscreen display
1
2
1
2
1
2
1
2

12
SECTION 2 - Description
Figure 7
widescreen full aluminium
front panel detail
Figure 8
widescreen aluminium front panel
with true flat technology detail
2.5.3 Widescreen
In HMI30 family, the systems with 5.7” and 8.4” display have 4:3 aspect ratio,
while the system with 7.0” display has 15:9 (wide) aspect ratio.
The 7.0” wide display provides 25% more area than the smaller 5.7” size.
HMI30 7.0” is available with aluminium front panel or true flat and widescreen.
2.5.3.1 Widescreen Full aluminium front panel
Frame
Touchscreen display
2.5.3.2 Widescreen aluminium front panel with True Flat technology
Frame
Touchscreen display
2
1
2
1
1
2
1
2

13
HMI30 / HMI30-TF User’s guide
Figure 9
HMI30 5.7” rear view
Note: rear panels may be different
depending on display size.
Figure 10
HMI30 7.0” rear view
Note: the user manual refers to HMI
5.7” version. Other versions will be dis-
cussed only when necessary.
2.6 Rear view
Ventilation holes
Mounting seal
7.0”
Ventilation holes
Mounting seal
1
2
1
2
1
2
1
2

14
SECTION 2 - Description
Figure 11
HMI30 8.4” rear view
Ventilation holes
Mounting seal
1
2
1
2
