Asetek Tony Kanaan Direct Drive Wheelbase User manual

Direct Drive
Wheelbase Manual

Thank you for purchasing the
Asetek SimSports®Tony Kanaan Wheelbase.
You have made an excellent choice!
We are sure the Asetek SimSports®Tony Kanaan
direct drive wheelbase will help you take your sim
racing career to the next level. Whether you are a
beginner or an experienced racer, you will now be
able to reach ultimate immersion.
Prepare for the sensation of being in a real race car.

3
Table of contents
Foreword................................................................................................................................................................................................... 4
About This Document ................................................................................................................................................................... 4
Other Relevant Documents........................................................................................................................................................ 5
Symbols Used.................................................................................................................................................................................... 5
Copyright............................................................................................................................................................................................. 5
1. Introduction ......................................................................................................................................................................................... 6
1.1 Box contents................................................................................................................................................................................. 6
1.2 Videos ............................................................................................................................................................................................. 6
1.3 Manual version............................................................................................................................................................................ 6
1.4 Support & Contact .................................................................................................................................................................... 6
2. Product...................................................................................................................................................................................................7
2.1 Intended Use................................................................................................................................................................................7
2.2 Reasonably Foreseeable Unintended Use ....................................................................................................................7
2.3 Compatibility.............................................................................................................................................................................. 8
2.4 General Specifications........................................................................................................................................................... 8
2.5 Warnings and guidelines for safe operation................................................................................................................. 9
2.6 Safe usage instructions......................................................................................................................................................... 10
3. Product Overview ............................................................................................................................................................................ 11
4. Getting Started ..................................................................................................................................................................................12
4.1 Mounting Instructions.............................................................................................................................................................12
4.2 Getting started...........................................................................................................................................................................13
5. RaceHub™ software ........................................................................................................................................................................14
5.1 RaceHub Download.................................................................................................................................................................14
5.1.1 RaceHub Installation.............................................................................................................................................................14
5.1.2 RaceHub Updating...............................................................................................................................................................14
5.2 RaceHub Introduction...........................................................................................................................................................14
6: Troubleshooting................................................................................................................................................................................15
6.1 Spare Parts....................................................................................................................................................................................15
7. Safety ......................................................................................................................................................................................................16
8. De-commissioning & Sustainability..........................................................................................................................................17
8.1 Packaging .....................................................................................................................................................................................18
8.2 Product .........................................................................................................................................................................................18
9. Declaration of Conformity............................................................................................................................................................19

4
Foreword
About This Document
This manual is written for the end-user of the Asetek SimSports®Tony Kanaan Direct
Drive Wheelbase (hereon after: “wheelbase”) and contains all information required to
correctly and safely install, use and maintain the following models:
This manual was authored in English. All other languages are translations of the original
document.
Please make sure that you have thoroughly read and understood all contents of this
manual before installing or using the wheelbase.
If anything in this manual is unclear, please contact Asetek SimSports®Support (available
on www.asetek.com/simsports/support/).
Please note the serial number on your product before contacting the support. The
serial number can be found on the bottom of the wheelbase and written here for your
convenience:
Model Name WB-1
Product Name Tony Kanaan Direct Drive Wheelbase 12Nm
Product Code 40-092-0092002
Asetek Denmark A/S
Assensvej 2
9220 Aalborg East
Denmark
www.asetek.com
Serial Number

5
Other Relevant Documents
These documents may assist you in your quest for faster lap times:
- Mounting patterns
- Software
- DoC
- and other installation manuals can be found here:
www.asetek.com/simsports/knowledge-base/
Symbols Used
Make sure you pay attention to all warnings and symbols on the product and packaging.
Copyright
The content of this manual is protected by copyright and other international intellectual
property laws. The contents of this manual or any parts thereof may only be made public,
copied, modified, reproduced, translated with express written permission from Asetek.
This manual or any parts thereof may only be published, transmitted, displayed, or made
available to a third party with express written permission from Asetek SimSports®.

6
1. Introduction
1.1 Box Contents
The box contains the following components and accessories:
•Wheelbase
•Power supply
•Power supply AC-cable (EU)
•Power supply AC-cable (UK)
•Power supply AC-cable (US)
•On/Off button
•USB Type-A to USB Type-C cable (Two (2) meters)
1.2 Videos
On the Asetek SimSports®YouTube channel (https://www.youtube.com/aseteksimsports),
you can find tutorial videos which, in detail, demonstrate numerous ways the wheelbases
can be set up and used.
1.3 Manual version
This manual is version 1.0.
You will always be able to find the latest version of the manual at:
www.asetek.com/simsports/knowledge-base/
1.4 Support & Contact
Should you stumble upon further questions that are not covered in this manual or any of
our detailed instruction videos, we encourage you to contact our friendly support staff at
[e-mail]

7
Recommended ages 15 and above
The wheelbase is intended for indoor use only
2. Product
2.1 Intended Use
Thank you for purchasing a Tony Kanaan Wheelbase; you have made an excellent
choice! The Tony Kanaan Wheelbase will bring you to the next level of your Sim Racing
career. Whether you are a beginning or experienced gamer, you will feel the immersion
of being in a real race car while racing the tracks across the globe in the virtual space.
The Tony Kanaan Wheelbase is designed to be used in competitive sim racing and
simulate the feel of a real race car. The wheelbase can be directly connected to any
PC with a USB port and is intended to be mounted in a sim racing cockpit. All Asetek
SimSports®wheelbases feature our own unique quick release that is as easy as shifting
gears – literally. To disconnect the wheel from the base, all you have to do is press the
paddle on the wheel and the wheel will be in your hands. Needless to say, we are not
relying on wireless signals, batteries that need to be charged, or cables that can break or
fall off. Everything is included in our easy-to-use no-play quick release.
The Tony Kanaan Wheelbase is compatible with all Asetek SimSports®wheels. The
wheels can be bought in our webshop or at an Asetek SimSports®authorized dealer.
Information on the wheels can be found on:
https://www.asetek.com/simsports/product-category/steering-wheels/
2.2 Reasonably Foreseeable Unintended Use
The following is considered misuse and may void the warranty:
• Use of adaptors or extension sets for cables;
• Use of other cables than provided with the product;
• Use in an environment that varies from or exceeds the given
environmental conditions;
• Use that varies from or exceeds the given operating conditions;
• Failure to comply with the instructions in this manual;
• Failure to eliminate faults, malfunctions, or defects of the product
that impose safety risks;
• Unauthorized removal or modification of parts or safety devices of the product;
• Use of spare parts or accessories that Asetek SimSports®has not approved;
• Mounting and/or use of any parts in a vehicle;
• Operation in a flammable and/or explosive environment.

8
2.4 General Specifications
Tony Kanaan
Asetek SimSports®
Quick Release Wheelbase side only
Max Torque 12 Nm
Max torque
slew rate 4 Nm/ms
Angle sensor 22 bit absolute
Power supply 180 W
Wheelbase
dimensions 133 x 132 x 293 Mm
Mounting
holes T-nuts M6 x 4 pcs threaded hole
Mounting hole
pattern width 87 mm
Mounting hole
pattern length Variable length 30 mm to 160 mm
Wheelbase weight 8.5 Kg
Standard warranty 24 months
Operating
Temperatures 15°C to 35°C, room temperature
2.3 Compatibility
Platform(s) PC (Windows 10, 11)
Games Assetto Corsa
Assetto Corsa Competizione
DiRT Rally
DiRT Rally 2.0
F1 Series
iRacing
Project Cars 2
rFactor 2
+ many other games that accept direct input devices

9
2.5 Warnings and guidelines for safe operation
• Asetek SimSports®wheelbases are intended for professional use. Usage under other conditions
is under user’s own responsibility.
• Do not grab, hold, or insert fingers and/or objects to the rotating parts in a way where letting go
immediately is not always possible.
• When operating the quick release, always disable torque by pressing the Torque off button
before removing or attaching a wheel.
• Do not enable torque before a wheel has been securely attached.
• On La Prima and Tony Kanaan Series do not operate the quick release while the wheelbase is
powered ON. Do not turn ON the wheelbase before a wheel has been securely attached.
• Do not set torque level higher than the level the user can safely hold with a single hand grip.
• If torque gets too high to control safely, let both hands off the wheel and press the Torque off
button.
• Preventing motion by the means of RaceHub or simulator software are not reliable ways to
prevent motion.
• Wheelbase user must be an adult and physically and mentally fit person.
• Usage of the wheelbase is allowed only by an instructed person who understands and follows
the above safety instructions.
• If the wheelbase becomes damaged in any way, stop using it immediately and contact Asetek
support or the reseller from who you have bought the wheelbase.
• Using the vibration and force feedback may cause damage to your health.
• Do not open the casing of the wheelbase or the power supply. There are no user serviceable
parts inside, and disassembling will void manufacturer’s warranty.
• Do not use the wheelbase with a power source other than the power supply packaged with the
wheelbase or received from an authorized reseller.
• Do not use the wheelbase with any cables other than the cables packaged with the wheelbase
or received from an authorized reseller.
• The wheelbase has magnets which may interfere with pacemakers, defibrillators and
programmable shunt valves or other medical devices. Do not put this product close to these
medical devices and the person who use any of these medical devices. Consult your doctor
before using this product if you have any concerns.
• Asetek SimSports®power supply is not intended to withstand physical stress. Do not damage or
mishandle the power supply.
• Operating environment:
• ο15°C – 35°C room temperature, non-condensing humidity
• Do not expose the wheelbase to direct sunlight
• Indoor use only
• Rotating high torque parts:
• οShaft torque up to 12 Nm
• Hot surface:
• Wheelbase surface temperature may reach 70C or 158F.
• Sudden rotation / vibration
• Wheelbase may start producing motion unexpectedly.
• Please note that the wheelbase can get hot when used
which is normal operating procedure.
Hot surface
Heisse Oberfläche
Surface chaude
Superficie caliente
High torque
Hohes Drehmoment
Couple élevé
Torque alto
Rotating shaft
Rotierende Welle
Arbre rotatif
Eje giratorio

10
2.6 Safe Usage Instructions
A: Read the user manual before installing and operating the wheelbase.
B: Mount the wheelbase securely to a rigid platform before use. Use a bracket that is compatible
with your Asetek SimSports®Tony Kanaan Wheelbase. Never operate the product without
mounting it first.
C: Use the power off button to stop and prevent motion.
D: Keep your hands away from a freely rotating wheel. If the torque gets too high to control safely,
let both hands off the wheel and press the torque off button.
E: Keep hair, cables, clothing, and other loose items clear from the rotating parts.
F: Children under the age of 15 years are not allowed to use the wheelbase in high torque mode.
G: Inform other users of the wheelbase about safe usage.
If you are in doubt about any of the above listed items, please reach out to our customer service at
[e-mail] with any questions you may have.
OFF
0-15
