Rack Pool Tables T401G User manual

RACK LUXOR 7.5-FOOT 4-IN-1 MULTI-GAME SWIVEL BILLIARD/POOL
TABLE-GREEN FELT WITH BROWN BODY
T401G

RACK LUXOR 7.5-FOOT 4-IN-1 MULTI-GAME SWIVEL BILLIARD/POOL TABLE
ASSESSORISS
HARDWARE
1 piece
1 piece 1 piece 1 piece
1 piece
2 pieces
2 pieces
36 pieces 24 pieces 8 pieces 8 pieces
16 pieces
2 pieces 2 pieces
2 pieces
2 pieces
2 pieces 2 pieces

INSTRUCTIONS FOR THE 7.5FT SWIVEL 4-IN-1 MULTIGAMES TABLE
Please keep these instructions for future reference. Adult assembly required.
This table is not a toy & is intended for use by or under the
supervision of adults.
Tools required
Philips Screwdriver-not included
Standard (flat head)Screwdriver- not included
Allen Wrench -included
Note: electric screwdrivers may be helpful during assembly however please set a low torque
& use extreme caution.
Assembly Tips
Make sure you understand the following before you begin to assemble your games table.
1. Save all packing materials until the parts have been inspected & the table is
assembled.
2. Lay the box on a flat surface (the floor). You may want this near your area of assembly.
3. If any parts are missing please contact RACK POOL TABLES immediately.
4. Note that some parts are stored inside the table top.

Table Body Air Hockey Playsurface
1 piece
Locker
Pre-Installed Rotational Bolt Pre-Installed Pre-Installed
Leg Base Board
5
4 pieces
4 pieces 4 pieces
Air Blower
Pre-Installed
1 piece
2 pieces 2 pieces 6 pieces
4 pieces 4 pieces 2 pieces 1 piece 1 piece
DISTRIBUTION DIAGRAM OF ALL THE PARTS
ASSEMBLY PARTS
4 pieces

6
ASSEMBLY VIEW

Lift the air hockey table top off the pool table & Keep it aside safe for the time being, be careful not
to damage the fan motor.
Remove all accessories and boxes from the inside of the pool table cabinet.
7

8
Attach the Leg B ( #3) to the Leg A ( #2) using the Screw ( #28) as shown
Attach the Leg Base Board (#14) to the bottom of the leg using the Screw (#27) as shown
The nut for leg leveler is on this side

9
Attch the 4 assembled legs to the corners of the Table Body (#1) using the Bolt (#30) and Washer (#31).
Attach the Leg Leveler (#13) to the bottom of the leg as shown.
Place it in the ground in such a way that all the 4 legs hit the ground at the same time to avoid damages

10
Unlock the Switch and rotate the table so that the cross-support beam faces up.
If the locks are not working properly,
please lift the corner of the table body
(#1) from the corners gently with your
hand so that the table can be locked
easily.
Lock the table
Unlock

11
Now replace the air hockey table top back onto the table frame and at the same time thread the fan
motor cable through the pre drilled hole located on the cross-support beam and carefully connect
the connectors 11C & 11B as shown.
Carefully connect the connectors 11C & 11B
together and lock it!
Thread the fan motor cable (11C)
through the pre drilled hole located
on the cross-support beam.
Connecting the 11C & 11B
6

12
Carefully replace the air hockey table top back onto the table frame.
Keep the table locked
6

13
Please unlock the table and rotate the table cabinet a little, and attach the air hockey table
top to the pool table cabinet by using the screw (#27).
Unlock
7

14
Keep the table unlocked
7
Rotate the air hockey table to attach the other side to the pool table cabinet by using the Screw ( #27)
as shown

15
Plug the fan motor cable #11a to the connector in the side panel when you are playing the air
hockey table.
Lock the table
8
If the locks are not working properly,
please lift the corner of the table body
(#1) from the corners gently with your
hand so that the table can be locked
easily.

16
Please first unplug the fan motor cable (#11a) and unlock the table when you want to rotate the
air hockey table to change it to pool table.
Unlock
Unplug
9

10
17
Now that you have completed the assembly successfully, you can now enjoy hours of endless fun with
your new RACK 4 - in - 1 Table
Lock the table
If the locks are not working properly,
please lift the corner of the table body
(#1) from the corners gently with your
hand so that the table can be locked
easily.

11
12
18
Keep the table locked
Place the Table Tennis Top ( 4A & 4B) onto the pool table using the Top Alignment Pin (#12) and the
table tennis top support board (#5) placed underneath. Install the Net Posts (#16) and Net (#15). See
Step 11 and Step 12.
Place 6 PCS EVA Pads (#10) as shown for table tennis flatness purpose if required.

19
13
