ASI 90-2115 Installation and operating instructions

ASI MEDICAL INC. | 8811 American Way, Suite 130, Englewood, CO 80112
Advanced Dental Systems® & Advanced Endodontic Systems®
Customer Support Team | www.asisupport.com | 303-407-6072
ADVANCED SELF-CONTAINED
DENTAL SYSTEM
Operation & Service Manual
Document No. 65-OS08, Rev-B, April 27, 2021
Dental Operative Unit
Models: 90-2115 | 90-2125
This guide provides important steps for setup, use, and maintenance of the ASI delivery system.
It includes important details which must be followed to ensure safety and proper use.
This document includes sections for optional components that may or may not be included in your
system. Your system may contain built-in accessory instruments from other manufacturers.
Please refer to the original manufacturer’s instructions for operation and maintenance for those
instruments.

Contents
Operation & Service Manual, Advanced Self-Contained Dental System
www.asisupport.com 65-OS08 Rev-B (04/27/21)
1SYMBOLS & SAFETY PRECAUTIONS
2OPERATING ENVIRONMENT & CLASSIFICATION OF EQUIPMENT
3PRODUCT DESCRIPTION, SPECIFICATIONS & WARRANTY
Intended Use
Product Description / Theory of Operation
Dimensions, Specifications & Technical Data
Warranty Information
4UNPACKING & INSTALLATION
5START UP, OPERATION & SHUT DOWN
6CLEANING/DISINFECTING, STORAGE & SHIPPING
7TROUBLESHOOTING
8SERVICING & PREVENTATIVE MAINTENANCE
9SCHEMATICS, DIAGRAMS & PARTS LISTING
10 REFERENCES OR SUPPLEMENTAL INFORMATION (OPTIONAL)

Section 1 Contents
Symbols & Safety P
recautions
www.asisupport.com 65-0047 Rev-A | 11/12/20
SYMBOLS
DESCRIPTION OF DANGER LEVELS
GENERAL SAFETY PRECAUTIONS
IDENTIFICATION OF SYMBOLS
65-OS01 Rev-A | 11/12/20

ASI Dental Special
ties
1
−
SYMBOLS & SAFETY PRECAUTIONS
www.asisupport.com Page 1 65-0047 Rev-A | 11/12/20
SYMBOLS
These symbols are used in this manual.

Important information for users and technicians
⚠
Warning Symbol
DESCRIPTION OF DANGER LEVELS
⚠
⚠DANGER
DANGER indicates a maximum hazardous situation that can directly cause serious injury of death.
⚠
⚠WARNING
WARNING indicates a hazardous situation that can lead to serious injury of death.
⚠
⚠CAUTION
CAUTION indicates a hazardous situation that can lead to property damage or minor to moderate injury.
GENERAL SAFETY PRECAUTIONS
In addition to observing the normal precautions associated with standard dental practices and procedures, the
following precautions should be strictly noted and observed during the set-up, operation, and maintenance of
this system.
⚠
⚠WARNING
COMPRESSED AIR
The compressed air system that operates this unit is under pressure. Compressed air can propel dust or loose particles and
can
cause bodily injury or damage. Always turn the system off and bleed off air pressure before attaching or removing air lines o
r
accessories or servicing this unit. All air lines should be periodically inspected and replaced if worn or damaged.
If an o
utside compressed air supply is used to power this unit, the air supply must be regulated to 80 psi or below. Excessive air
pressure could cause certain components to rupture.
⚠
⚠
WARNING
ELECTRICAL VOLTAGE
This system is powered by high voltage
electricity. Like any other electrically powered device, if it is not used properly, it can
cause electrical shock. Always plug the power cord into an electrical outlet with adequate fuse protection and proper grounding.
In the event of a short circuit, gr
ounding reduces the risk of shock by providing an escape wire for the electric current. Improper
grounding of the unit can result in a risk of electric shock. Always unplug the unit before doing any service or repair to the unit.
⚠
⚠WARNING
PRESENCE OF HEAVY METALS/AMALGAM
This
system may be equipped with optional suction instruments. As part of dental procedures, particles of amalgam may be
suctioned into the dental suction handpieces and collected within the system and trap filter.
Recycle amalgam in accordance
with local guidelines.
65-OS01 Rev-A | 11/12/20

ASI Dental Specialties
1
−
SYMBOLS & SAFETY PRECAUTIONS
www.asisupport.com Page 2 65-0047 Rev-A | 11/12/20
⚠
⚠WARNING
INFECTIOUS MATERIALS
Infectious disease workplace safety protocols to safeguard against cross contamination of infectious disease should always
be
observed. When maintaining the suction system or emptying the contents of the suction waste
container, safe precautions and
practices including the wearing of face mask, eye protection and gloves are to be followed.
⚠
⚠WARNING
QUALIFIED PERSONNEL ONLY
The
product should only be operated by qualified personnel only. The operator bears responsibility for the correct settings and
proper use of the system. ASI Medical, Inc. (ASI) cannot be held liable for any malfunction of this product, or performance
failure and/or its designed or desired utility, nor can ASI be held liable for injuries
to persons or animals, in any case when the
device is misused or not operated, applied or maintained in strict accordance with user/owner instructions set out in the
operation manual. In the event of any doubt or question, the user is to contact ASI for clarification or assistance.
⚠
⚠
WARNING
ELECTROMAGNETIC COMPATIBILITY (EMC)
Changes or modifications to this product not expressly approved by the manufacturer may result in increased emissions or
decreased immunity performance of the product and could
cause EMC issues with this or other equipment. This product is
designed and tested to comply with applicable regulation regarding EMC and shall be installed and put into service according
to
the EMC information stated below:
⚠
WARNING
Use of portable phon
es or other portable or mobile radio frequency (RF) emitting equipment near the product may cause
unexpected or adverse operation.
⚠
WARNING
The use of accessories, transducers
, and cables other than those supplied may result in increased emissions or decreased
immunity performance of the product. The product shall not be used adjacent to, or stacked with, other equipment. If adjacent
or stacked use is necessary, the user shall be responsible to test to verify normal operation in the configuration in which
it is
being used.
⚠
⚠
CAUTION
DAMAGE FROM UNSUITABLE ACCESSORIES
Responsibility for the use of accessories, parts or assemblies from other manufacturers rest solely with the user.
⚠
⚠CAUTION
CAUSTIC OR CORROSIVE CHEMICALS
The irrigation system
may contain chemicals that are caustic or corrosive. Always verify with the operator of the system to
determine which chemicals they are using within the system. Always follow workplace safety protocols when doing
maintenance or service of the system inclu
ding the wearing of face mask, eye protection and gloves for proper protection of
exposed skin, breathing and eyes.
⚠
⚠
CAUTION
CORRECT OPERATING VOLTAGE
Check the correct operating voltage on the rating plate and ensure that the product is correctly
configured for the voltage
before plugging in and energizing.
⚠
⚠CAUTION
SUCTION CANISTER PURGE
LED turns on when suction canister overfills.
⚠
⚠CAUTION
POWER SUPPLY CORD
The power supply cord is not replaceable by service personnel.

ASI Dental Special
ties
1
−
SYMBOLS & SAFETY PRECAUTIONS
www.asisupport.com Page 3 65-0047 Rev-A | 11/12/20
IDENTIFICATION OF SYMBOLS
The table below defines symbols that may be included on/in this delivery system.
Symbol
Description
Conforms to UL STD 60601-1; Certified to CSA STD C22.2 NO. 601.1
Recognized by Underwriters Laboratories Inc. with respect to electric shock, fire, and mechanical hazards only in
accordance with UL 61010-1 (2601-1) and under mutual recognition agreement with CAN/CSA C22.2, No.601-1.
Protective earth (ground)
Functional earth (ground)
Attention, consult accompanying documents. No user serviceable parts. Attention, line voltage. Only licensed electrician
should remove cover.
Type B applied part
Type BF applied part
Class II Equipment
Caution: Metal surfaces can be hot during and following the dry cycle.
Marking on the outside of Equipment or Equipment parts that include RF transmitters or that apply RF electromagnetic
energy for diagnosis or treatment.
Manufacture
Consult user information
65-OS01 Rev-A | 11/12/20

Section 2 Contents
Operating Environment & Classification of Equipment
www.asisupport.com 65-0048 Rev-B (04/01/21)
CLASSIFICATION OF EQUIPMENT (EN-60601-1)
ENVIRONMENTAL SPECIFICATIONS
ELECTROMAGNETIC COMPATIBILITY (EMC)

ASI
Dental Specialties 2 –
OPERATING ENVIRONMENT & CLASSIFICATION OF EQUIPMENT
www.asisupport.com Page 1 65-0048 Rev-B (04/01/21)
CLASSIFICATION OF EQUIPMENT (EN-60601-1)
Type/Mode
Classification
Types of shock protection
Class I Equipment
Degree of shock protection
TYPE B and/or TYPE BF APPLIED PART depending on order configuration
Degree of protection against water ingress
ORDINARY EQUIPMENT
Mode of operation
Intermittent
Flammable Gasses:
Not suitable for use in the presence of a flammable anesthetic mixture with air,
oxygen, or nitrous oxide, where such gasses may accumulate in concentration
(closed spaces).
ENVIRONMENTAL SPECIFICATIONS
Temperature/Humidity
Specification
Storage/Transportation Temperature:
-40˚C to 70˚C (-40˚F to 158˚F) - Relative humidity 80%
Operating Temperature:
10˚C to 40˚C (40˚F to 104˚F) - Relative humidity 80%
Indoor Use:
Altitude up to 2,000M (6,563 ft.), installation category II, pollution degree 2. (UL
61010A-1 and CAN/CSA C22.2, No. 1010.1-92 only)
Exclusions
Hospitals except for near active HF surgical equipment and the RF shielded room of a
medical equipment system for magnetic resonance imaging, where the intensity of
electromagnetic disturbances is high.
ELECTROMAGNETIC COMPATIBILITY (EMC)
Although this dental equipment conforms to the intent of the 2004/108/EC EMC Directive, all medical
equipment may produce electromagnetic interference or be susceptible to electromagnetic interference. The
following are guidance and manufacturer’s declarations regarding EMC for this equipment.
This equipment needs special precautions regarding EMC and needs to be installed and put into service
according to the EMC information provided in the following pages.
⚠
⚠
WARNING
ELECTROMAGNETIC COMPATIBILITY
As with all electrical medical equipment, this equipment may cause radio interference or may disrupt the operation of nearby
equipment. It may be necessary to take mitigation measures such as re
-orienting or relocating this equipment unit or shielding
the location.
•Portable and Mobile RF communications equipment can affect the performance of this equipment,
and should be used no closer than 30cm (12inches) to any part of the ASI dental system. Please use
the guidelines and recommendations specified in IEC 60601-1-2, Edition 4.0.
•Other medical equipment or systems can produce electromagnetic emissions and therefore can
interfere with the functionality of this equipment. Care should be used when operating the system

ASI
Dental Specialties 2 –
OPERATING ENVIRONMENT & CLASSIFICATION OF EQUIPMENT
www.asisupport.com Page 2 65-0048 Rev-B (04/01/21)
adjacent to or stacked with other equipment. If adjacent or stacked use is necessary, this equipment
should initially be observed to verify normal operation in the configuration in which it will be used.
•The electrical cables, external power supplies and accessories listed or referenced in this manual
have been shown to comply with the test requirements listed in the following tables.
Care should be taken to use only manufacturer-recommended cables, power supplies and electrical
accessories with this equipment.
If the user or a third-party supplier offers cables, external power supplies and electrical accessories
for use with this equipment and they are not listed or referenced in this manual, it is the
responsibility of that third-party supplier to determine compliance with the standards and tests in
the following tables.
•The use of electrical cables and accessories other than those specified in this manual or referenced
documents may result in increased electromagnetic emissions from this equipment or decreased
electromagnetic immunity of this equipment.
Guidance and Manufacturer's Declaration Electromagnetic Emissions
This equipment is intended for use in the electromagnetic environment specified below. The customer or the end user of this
equipment should assure that it is used in such an environment.
Emissions Test
Compliance
Electromagnetic Environment - Guidance
RF Emissions - CISPR 11
(Radiated & Conducted)
Group 1
This equipment uses RF energy only for its internal function. Therefore, its RF
emissions are very low and are not likely to cause any interference in nearby
electronic equipment.
RF Emissions - CISPR 11
(Radiated & Conducted)
Class A
The emissions characteristics of this equipment make it suitable for use in
industrial areas and hospitals. If it is used in a residential environment this
equipment might not offer adequate protection to radio-frequency
communication services. The user might need to take mitigation measures, such
as relocating or re-orienting the equipment.
Harmonic Emissions
EN/IEC 61000-3-2
Class A
Voltage fluctuations/
Flicker Emissions
EN/IEC 61000-3-3
Complies

ASI
Dental Specialties 2 –
OPERATING ENVIRONMENT & CLASSIFICATION OF EQUIPMENT
www.asisupport.com Page 3 65-0048 Rev-B (04/01/21)
Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
This equipment is intended for use in the electromagnetic environment specified below. The customer or the end user of this
equipment should assure it is used only in such an environment.
Immunity Test
EN/IEC 60601
Test Level
Compliance Level
Intended Electromagnetic
Environment
Electromagnetic Discharge (ESD)
EN/IEC 61000-4-2
± 8kV contact
± 2kV, ± 2kV, ± 8kV, ±
15kV air
± 8kV contact
± 2kV, ± 2kV, ± 8kV, ±
15kV air
Floors should be wood, concrete or ceramic
tile. If floors are covered with synthetic
material, the relative humidity should be at
least 30%.
Electrical fast transient/burst
EN/IEC 61000-4-4
± 2kV for power supply
lines
± 1kV for input/output
lines
± 2kV for power supply
lines
± 1kV for input/output
lines
Mains power quality should be that of a
typical commercial or hospital environment.
Surge
EN/IEC 61000-4-5
± 1kV differential mode
(line-line)
± 2kV common mode
(line-earth)
± 1kV differential
mode (line-line)
± 2kV common mode
(line-earth)
Mains power quality should be that of a
typical commercial or hospital environment.
Voltage dips, short interruptions
and voltage variations on power
supply input lines
EN/IEC 61000-4-11
0 % UT; 0,5 cycle at 0°,
45°, 90°, 135°, 180°, 225°,
270° and 315°
0 % UT; 1 cycle and 70 %
UT; 25 cycles Single
phase: at 0°
0 % UT; 250 cycle
0 % UT; 0,5 cycle at 0°,
45°, 90°, 135°, 180°,
225°, 270° and 315°
0 % UT; 1 cycle and 70
% UT; 25 cycles Single
phase: at 0°
0 % UT; 250 cycle
Mains power quality should be that of a
typical commercial or hospital environment. If
the user of this equipment requires continued
operation during power mains interruptions,
it is recommended that this equipment be
powered from an uninterruptible power
supply or a battery.
Power frequency (50/60Hz)
magnetic field
EN/IEC 61000-4-8
3A/m
3A/m
Power frequency magnetic fields should be at
levels characteristic of a typical location in a
typical commercial or hospital environment.
NOTE: UT is the a.c. mains voltage prior to application of the test level.

ASI
Dental Specialties 2 –
OPERATING ENVIRONMENT & CLASSIFICATION OF EQUIPMENT
www.asisupport.com Page 4 65-0048 Rev-B (04/01/21)
Guidance and Manufacturer’s Declaration – Electromagnetic Immunity
This equipment is intended for use in the electromagnetic environment specified below. The customer or the end user of this
equipment should assure it is used in such an environment.
Immunity Test
EN/IEC 60601
Test Level
Compliance
Level
Intended Electromagnetic Environment
Conducted RF
EN/IEC 61000-4-6
Radiated RF
EN/IEC 61000-4-3
3Vrms between
0.15MHz to 80MHz
6V/m in ISM bands
between 0.15MHz
and 80MHz
80MHz to 2.7GHz
3Vrms between
0.15MHz to 80MHz
6V/m in ISM bands
between 0.15MHz
and 80MHz
80MHz to 2.7GHz
Portable and mobile RF communications equipment should be
used no closer to any part of this equipment, including cables,
than the recommended separation distance calculated from
the equation applicable to the frequency of the transmitter.
Recommended separation distance
d = 1.2√P
d = 1.2√P 80MHz to 800 MHz
d = 2.3√P 800MHz to 2.5GHz
where P is the maximum output power rating of the
transmitter in watts (W) according to the transmitter
manufacturer and d is the recommended minimum separation
distance in meters (m).
Field strengths from fixed RF transmitters, as determined by
an electromagnetic site survey (a), should be less than the
compliance level in each frequency range (b).
Interference may occur in the vicinity of equipment marked
with the following symbol:
Proximity fields me
the minimum
requirement of
Test Frequency
(MHz)
Band
(MHz)
Immunity Test Level
(V/m)
385
380-390
27
450
430-470
28
710
704-787
9
745
780
810
800-960
28
870
930
1720
1700-1990
28
1845
1970
2450
2400-2570
28
5240
5100-5800
9
5500
5785
NOTE 1: At 80MHz and 800MHz, the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from objects, structures
and people.
a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and
FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which this equipment is used
exceeds the applicable RF compliance level above, this equipment should be observed to verify normal operation. If abnormal performance is observed,
additional measures may be necessary, such as re-orienting or relocating this equipment.
b Over the frequency range 150kHz to 80MHz, field strengths should be less than 3V/m.

ASI
Dental Specialties 2 –
OPERATING ENVIRONMENT & CLASSIFICATION OF EQUIPMENT
www.asisupport.com Page 5 65-0048 Rev-B (04/01/21)
Recommended Separation Distances Between Portable and
Mobile RF Communications Equipment and This Equipment
This equipment is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer
or the user of this equipment can help prevent electromagnetic interference by maintaining a minimum distance between the portable
and mobile RF communications equipment (transmitters) and this equipment as recommended below, according to the maximum
output power of the communications equipment.
Rated maximum output
power of transmitter in
watts (W)
Separation distance according to frequency of transmitter in meters (m)
150kHz to 80MHz
d = 1.2√P
80MHz to 800MHz
d = 1.2√P
800MHz to 2.5GHz
d = 2.3√P
0.01
0.12
0.12
0.23
0.1
0.38
0.38
0.73
1.0
1.2
1.2
2.3
10
3.8
3.8
7.3
100
12
12
23
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in meters (m) can be estimated using the
equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the
transmitter manufacturer.
NOTE 1: At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects
and people.

Section 3 Contents
Product Description, Specifications and Warranty
www.asisupport.com 65-0104 Rev-A (04/01/21)
INDICATIONS FOR USE STATEMENT – DENTAL DELIVERY SYSTEMS
PRODUCT DESCRIPTION
MODELS AVAILABLE
THEORY OF OPERATION
OVERVIEW OF COMPONENTS AND HOW THEY WORK
Handpiece Control and Operation
Tandem Water Disinfection System
Air Compressor
Air Tanks Clean Regulated Air
Vacuum Pump
Sediment Separator and Holding Tank
Purge System
ADVANCED MODEL COMPARISON
LIMITED WARRANTY

ASI Dental Specialties
3 – PRODUCT DESCRIPTION, SPECIFICATIONS AND WARRANTY
www.asisupport.com Page 1 65-0104 Rev-A (04/01/21)
INDICATIONS FOR USE STATEMENT – DENTAL DELIVERY SYSTEMS
The ASI Advanced Series is a self-contained dental treatment unit. It is designed to provide air, water, vacuum
and electricity to operate various dental handpieces, accessories and attachments and to serve as a base for
other dental devices and accessories.
The device is intended for use to provide general dental restorative care and hygiene procedures in both
traditional dental office settings and/or mobile applications by or under the supervision of a licensed dentist or a
hygienist if permitted by applicable law.
PRODUCT DESCRIPTION
The Dental System product is a cart-based operative dental treatment unit requiring connection to an AC
electrical power supply. The product is constructed of aluminum chassis with powder coat paint finish, high-
grade dual wheel type casters, and composite work surface top. The product is hard wired with the appropriate
type mains plug provided for the electrical specification model as listed.
The system functions to operate dental handpieces and to serve as an integrated base for other dental devices
and accessories. Use of the system is intended only to support dental treatment and hygiene procedures, and
operation of dental instruments by or under the supervision of a licensed dentist. All model configurations
include up to three handpiece connections, air/water syringe, air-only syringe and water supply with two 1-liter
bottles. The system does not include dental handpieces which are to be separately supplied by the operator.
MODELS AVAILABLE
See Model Specification Sheet for available models and features provided. Model Package Configurations may
include select models that are combined with handpieces and instruments.
THEORY OF OPERATION
The Dental Delivery System is a fully self-contained dental delivery unit that only requires a standard electrical
outlet for operation. The Advanced Delivery System is a pneumatically-controlled system that uses standard
compressed air for operation of dental tools and accessories and for pressurizing a closed water supply. The
system uses air pressure from a foot control to operate air driven tools and also to provide a signal to turn
electric instruments on and off. This pneumatic control capability provides flexibility in that additional
instruments can be included on the system for operation from the same foot control. The water system provides
two liters of clean water capacity that is used for handpiece coolant spray and irrigation for the air/water
syringe.

ASI Dental Specialties
3 – PRODUCT DESCRIPTION, SPECIFICATIONS AND WARRANTY
www.asisupport.com Page 2 65-0104 Rev-A (04/01/21)
OVERVIEW OF COMPONENTS AND HOW THEY WORK
•Handpiece Control and Operation
•Tandem Water System
•Compressed Air System
oAir Compressor
oAir Tanks and Clean Regulated Air
•Suction System

ASI Dental Special
ties 3 – HANDPIECE CONTROL & OPERATION
www.asisupport.com Page 1 65-0049 Rev-A, (11/12/20)
HANDPIECE CONTROL AND OPERATION
The system utilizes common dental industry type technology for selection and activation of air-driven drills and
instruments via a multi-position control block. The block contains individual gasket diaphragms that are held in
the closed position by compressed air supplied by the handpiece holders. When a dental handpiece is removed
from its holder, the compressed air is relieved off the gasket diaphragms for that particular instrument thereby
allowing compressed air and water to flow to the handpiece when the foot control is depressed. The flow rate of
this compressed air is controlled by individual stems on the top of the block and the flow of water by individual
needle valves with knobs located on the front and side of the unit.
Electric instruments, such as the ultrasonic handpiece and electric motor, are controlled via the same control
block. However, the compressed air that flows from the block is routed to an air/electric switch that uses an air-
driven piston to close contacts when activated to thereby send an electric signal for the ultrasonic and electric
motor to operate. When the foot control is released, these instruments will then turn off.
The system uses an air-driven poppet style foot-control valve that when depressed, will send compressed air to
the control block to operate whichever handpiece is removed from its holder. The foot control also features a
toggle valve for selecting water to spray from the handpieces. When the toggle is activated and the foot control
is depressed, it will allow an air signal to travel through the foot-control tubing to open a water relay valve
allowing water to flow to the selected handpiece. When the foot control is released, it will exhaust off the air to
the water relay valve and allow it to shut.

ASI Dental Special
ties 3 – T
ANDEM WATER DISINFECTION SYSTEM
www.asisupport.com Page 1 65-0050 Rev-A (11/12/20)
TANDEM WATER DISINFECTION SYSTEM
The system features a tandem supply of two 1-liter bottles providing two liters of water for patient procedures.
This system includes a DentaPure water line cartridge that disinfects and treats the dental unit water to prevent
the formation of biofilm in the dental tubing. The tandem supply increases the volume of water available but
also saves costs by only requiring the use of one water line cartridge. The system works by allowing water in the
second bottle to flow into the first where it then flows through the disinfection cartridge. The water system uses
two 1-liter plastic bottles designed for holding pressure. The bottles can be filled with clean tap or distilled water
for the source of water supply to the dental handpieces and air/water syringe. The system works by supplying
regulated compressed air which pressurizes the water within the bottle and forces it up through the pick-up
tubing in the bottle.

ASI Dental Special
ties 3 –
COMPRESSED AIR SYSTEM
www.asisupport.com Page 1 65-0051 Rev-A (11/12/20)
The ASI Compressed Air System is designed to deliver oil-free air to run handpieces. This system is ideal for
mobile dental systems due to the small footprint, oil-less design, quiet sound level, and airflow output that it
provides.
AIR COMPRESSOR
A motor drives a two-stage piston design. Air is drawn into the first piston chamber where it is initially
compressed and then sent into the second piston chamber where it is compressed further. A pressure switch
controls the operation of the compressor that turns it on and off.
Due to the oil-less design, the compressor requires no lubrication and no maintenance.
The pistons are dynamically balanced to high tolerances that enable a smooth running and quiet design.
The portable dental air compressor is controlled by an air pressure switch that senses when the pressure drops
in the air tank to activate the motor and then once air consumption ceases, it will sense when the air pressure
has reached a pre-set point and then will turn off the motor. This keeps the motor from running when the
system is not in use.
The air compressor is mounted on special spring type isolators that allow it to float and thereby reduce vibration
to the chassis. A proprietary multi-stage intake muffler design attenuates and muffles sound waves to dampen
sound.
AIR TANKS CLEAN REGULATED AIR
This system uses a dual air tank design. The tanks are constructed of non-corroding aluminum that are
lightweight. Compressed air is sent to an in-line air regulator and moisture separator. The regulator is connected
to a manual purge valve that can be opened to allow moisture condensation to escape.

ASI Dental Special
ties 3 –
SUCTION SYSTEM
www.asisupport.com Page 1 65-0052 Rev-A (11/12/20)
The ASI dental suction system is designed to provide suction to perform dental procedures and features a high-
volume suction and saliva ejector attached to a solid collector filter.
VACUUM PUMP
A motor drives a two-headed oil-less piston pump.
The pistons require no lubrication due to their oil-less design. The pistons are dynamically balanced to high
tolerances that enable a smooth running and quiet design.
SEDIMENT SEPARATOR AND HOLDING TANK
Equally important to the suction design of mobile dental equipment is how the liquid contents are handled. The
suction system has a holding tank to provide capacity for a normal day of procedures and is able to handle
caustic chemicals and can be purged and cleaned at the end of the day.
The system separates the air stream from the liquid and provides a sediment bowl that can be removed.
Built into the top of the holding tank is a float switch to prevent over filling of the canister. Once the liquid rises
to a pre-set level, the float switch will cut off the power to the vacuum pump.
PURGE SYSTEM
The system uses an electric purge pump that can be turned on that will siphon the liquid from the holding tank
and empty out though the purge hose at the back of the system. At the end of the day’s procedures, the purge
hose can be placed into a sink drain or quick connected to a sink’s P-trap and then the pump turned on to purge
the tank. Once complete, water with evacuation cleanser can be suctioned up through the high volume
evacuator (HVE) and saliva ejector to rinse the tubes and the holding tank.
The pump squeezes the specially designed tubing to pull and push contents through the tube. This pump design
allows it to pull granular or sticky paste-like materials.

ASI Dental Special
ties 3 –
WARRANTY
www.asisupport.com Page 1 65-0053 Rev-A, (10/01/20)
LIMITED WARRANTY - REVISION OCT 2020
ASI Medical, Inc., dba ASI Dental Specialties (ASI) warrants this product against defects in material and/or
workmanship for one year for parts, 90 days for labor, from the time of delivery. During this coverage period,
ASI’s sole obligation will be to repair, adjust, or replace defective parts only. ASI is not responsible for any time
lost, inconvenience caused, or for any other incidental or consequential damages. The warranty shall be voided
by alteration, tampering, improper installation or maintenance, accidental damage, or misuse of the product.
This warranty is made in lieu of all other warranties, expressed or implied, including any implied warranty of
merchantability of fitness for a particular purpose. No employee, agent, franchise, dealer, or other person is
authorized to give any warranties of any nature on behalf of ASI, except as provided herein.
ASI shall have no liability or responsibility to the customer, any other person, or entity with respect to any
liability, loss, or damage caused directly or indirectly by the product. Notwithstanding the above limitations and
warranties, ASI’s liability hereunder for damages incurred by the customer or others shall not exceed the
amount paid by the customer for the particular product involved.
ASI shall not be responsible for any warranty work done without first obtaining consent from ASI.
Specific Warranty Modifications
The following items and/or occurrences are not covered under the warranty:
•Accidental Damage & Theft, including but not limited to the following:
oDamage from accident or misuse including cuts, tears, and crushes to tubing, cracks in suction solids
trap filters, housings, broken casters, etc.
oDamage from use including scratches, dings, dents, and deterioration to paint and overlays
oTheft or vandalism
•Damage from Neglect or Improper Maintenance, including but not limited to the following:
oO-ring lubrication to all valves including the air-water syringes and foot controls
oFlushing of handpieces or micro-irrigation lines
oRemoval of condensation from air lines
oObstructions in water lines and handpiece tubing caused by foreign particles or chemical agents
dispensed through the lines
oObstructions in suction lines caused by foreign particles or improper maintenance of trap filters
•Disposable Type Items including but not limited to the following:
oLight bulbs, all filters, gaskets, O-rings, and certain types of tubing.
Specific Warranty Modifications for Self-Contained Systems
The following items and occurrences are not covered under warranty for Self-Contained Systems with Internal
Air Compressor and Suction Systems:
•Damage, Clogs, or Malfunctions to Canister and Purging System. The warranty coverage excludes the
suction canister, its components, the purge pump of the suction system, and the tubing due to the
inability of ASI to control items and solutions that the user may pull into the suction system (adhesives,
