Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the reason
they are greatly appreciated throughout the world.
To get the most from your new dishwasher, we recommend that you read the
operating instructions before using the dishwasher. The operating instructions
also include information on how you can help protect the environment.
Operating Instructions
Dishwasher
ASKO D5894 XXL

Contents
2Front panel
3Safety instructions
4Before washing for the first time
5Loading the dishwasher
9Using the dishwasher
14Special settings
16Care and cleaning
18Troubleshooting
21Technical information
23Installation
29Service
30Program chart
31Your notes
Front panel
The panel is fitted with touch buttons with audible feedback (see the chapter Special settings).
S TA R T
P R O G S T O P
1 2 3 4 5
1 On/Left-on mode 2 Program selector
3 Display
4 Navigation buttons
5 Start/Stop
NOTE!
•Two minutes after the last button press, the panel backlight enters energy saving mode. Press the On/Left-on mode button once to
reactivate the panel.
2

Safety instructions
General
•Read the operating instructions and keep them in a safe place!
•Never use the dishwasher for any purpose other than that
specified in these operating instructions.
•Do not load the dishwasher door or dishwasher baskets with
anything other than dishes.
•Never leave the dishwasher door open as someone may trip
on it.
•Use only dishwasher detergent!
•Place knives and other sharp items so that they cannot harm
anyone or damage the dishwasher.
•The machine is not designed to be used by persons (even
children) that are physically or mentally handicapped or lack
experience and knowledge. Such persons must receive
instruction in how to use the machine from the person
responsible for their safety.
•Damaged mains cables must only be replaced by a qualified
electrician.
•This dishwasher is for household or similar use, such as:
- staff kitchens in shops, offices and other workplaces.
- farms.
- for guests at hotels, motels and other types of
accommodation.
- bed & breakfast hotels.
•Never place dishes with solvent residues in the dishwasher
due to the risk of explosion. Nor may dishes that contain ash,
wax or lubricants be washed in the dishwasher.
•Young children should be supervised to ensure that they do
not play with the appliance.
•The appliance is not intended for use by young children or
infirm persons without supervision.
Installation
See the section Installation.
Child safety
•Use the knife basket, or knife stand, for all long/sharp items.
•Always close the door and start the program immediately after
you have added the detergent.
•Keep children away from the dishwasher when the door is
open. Some detergent may remain inside!
•Do not allow children to use or play with the dishwasher. Be
especially vigilant when the door is open.
WARNING!
Children must be supervised –dishwasher detergent is
corrosive!
Store detergent and rinse aid out of the reach of children! If
anyone swallows dishwasher detergent, they should
immediately drink one or two glasses of milk or water. Do not
attempt to induce vomiting. Contact a doctor! If anyone gets
dishwasher detergent in their eyes, rinse (for at least 15
minutes) with plenty of water.
WARNING!
Dishwasher detergents are strongly alkaline. They can be
extremely dangerous if swallowed. Avoid contact with skin and
eyes and keep children away from the dishwasher when the
door is open.
Check that the detergent compartment is empty after
completion of the wash cycle.
Activate the child safety lock (Kid Lock™)
(only certain models)
A child safety lock is fitted to prevent children from opening the
dishwasher door. To activate the child safety lock, press in the
door latch and use a screwdriver to turn the screw slot (top
left-hand corner) to a vertical position. To open the door, you
must press the white plastic catch (illustrated below) to the left
while pressing the door latch up. Reset by turning the screw slot
back to a horizontal position.
Locked
Open
Activate child lock (Kid Safe™)
You can activate the child lock (button lock) to prevent children
from starting the dishwasher (see the section Special settings).
Winter storage/Transport
•Store the dishwasher where the temperature remains above
freezing.
•Avoid long transport distances in very cold weather.
•Transport the dishwasher upright or laying on its back.
Overflow guard function
The overflow protection starts pumping out the machine and turns
off the water supply if the water level in the dishwasher exceeds
the normal level. If the overflow protection is triggered, turn off
the water supply and call the service division.
Cleaning
When cleaning the edge around the door, use only a slightly
damp cloth. Do not spray water around the edge! Moisture can
make its way into the lock, which contains electrical components.
Packing material
Sort waste materials in accordance with local guidelines.
3

Disposal
•When the dishwasher has reached the end of its service life
and is to be disposed of, it should immediately be made
unusable. Pull out the power cable and cut it as short as
possible.
•The dishwasher is manufactured and labelled for recycling.
•Contact your local authority for information about where and
how your dishwasher should be correctly recycled.
Before washing for the
first time
Checking water hardness
Contact the local water utility to check the water hardness in your
area. This is important with regard to how much detergent and
rinse aid to use.
Top up with rinse aid
Drying is faster if you use rinse aid.
1 Open the rinse aid compartment lid.
2 Carefully top up with rinse aid. Only add rinse aid to the level
marked max.
3 Wipe up any splashes of rinse aid around the compartment.
4 Close the lid firmly.
Selecting the rinse aid dosage
Rinse aid dispensing can be set from 0 (Off) to 6 (High dose).
(Factory settings: 5)
Increase the rinse aid dosage:
•If the dishes have water marks.
Decrease the rinse aid dosage:
•If the dishes have a sticky white/blue film.
•If the dishes are streaked.
•Build-up of foam. If you have very soft water, the rinse aid can
be diluted 50:50 with water.
For water with a hardness greater than 10–12 °dH, you ought to
use rinse aid with citric acid (known as acid rinse aid).
Setting the rinse aid dosage
The section Special settings describes how to set the rinse aid
dosage.
Refill rinse aid indicator
When the rinse aid needs topping up, the above symbol lights
on the display.
NOTE!
After topping up, it may take a while before the symbol goes
out.
4

Loading the dishwasher
Economic dishwashing
Run programs only with a full load
Wait to run a program until the dishwasher is full. This way you
save energy. Use the Rinse & Hold program to rinse the dishes
if there are any unpleasant odours while you wait for the
dishwasher to become fully loaded.
Run programs at a lower temperature
If the dishes are only slightly dirty, you can select a lower
temperature with certain programs. See also the section Selecting
Options in the chapter Using the dishwasher.
Select a program with Short dry
To save energy, use Short dry. The drying result will be better if,
once the program is finished, you leave the door slightly open.
Do not rinse under running water
Simply scrape off large food particles before loading the
dishwasher.
Choose a green detergent
Read the environmental declaration on the packaging!
Connect to cold water...
If you use oil or electricity to heat your home.
Connect to hot water (max. 70 °C)...
If you use district heating, solar power or geothermal power to
heat your home. Choosing a hot water connection cuts program
times and reduces the dishwasher's electricity consumption.
Fragile dishes
Some cookware is not dishwasher safe. This can be for several
reasons. Some materials cannot withstand strong heat, others
can be damaged by dishwashing detergent.
Fragile decoration
Porcelain with decoration on top of the glazing (the items feel
rough) should not be washed in a dishwasher.
Crystal/Glass
Position items so that they do not touch each other during the
wash. Use the lowest possible wash temperature and the shortest
possible program. Select No dry. Antique and very fragile items
should not be washed in a dishwasher.
Glass washed in a dishwasher at high temperatures can gradually
develop a grey film that cannot be removed. Wash fragile glasses
at a low temperature and with a small amount of detergent.
Silver
Silver and stainless steel items should not come into contact, as
the silver can become discoloured.
Cutlery with glued handles
Some types of glue are not dishwasher safe. In such cases, the
handles may loosen.
Wood
Wooden items should only be washed in a dishwasher if marked
dishwasher safe.
Aluminium
Aluminium can lose its shine if washed in a dishwasher. However,
good quality aluminium pans can be washed in a dishwasher,
even if some of the shine will be lost.
Plastic items
Avoid washing plastic items that cannot withstand high
temperatures.
Your machine is equipped with a turbo drying function (Turbo
Drying Express™), which improves the drying of plastic objects
and other items.
NOTE!
Plastic items should not be placed in the circled area of the
lower basket as they can be damaged by the heat.
Upper basket and knife basket
Place glasses, cups, bowls, side plates and saucers in the upper
basket. Wine glasses are placed on the wine glass shelf (if fitted).
Place sharp knives in the special knife basket at the top of the
dishwasher, or in the knife stand on the right (if fitted).
NOTE!
All dirty surfaces should face inwards and downwards!
5

Foldable tines
The foldable tines can be folded up or down to make it easier to
load pots, bowls and glasses.
1
2
21
Raising the upper basket
1 Pull out the upper basket.
2 Grab the sides of the upper basket with both hands and lift it
up.
Lowering the upper basket
1 Pull out the upper basket.
2 Pull out the two locking handles on either side to lower the
upper basket.
Knife basket
Middle basket
The middle basket's wire basket with spray pipes is suitable for
low objects. The middle basket's utensils basket has space for
ladles, whisks, serving cutlery and similar items.
The wire basket can be replaced with another utensils basket.
Wire basket
Utensils basket
Washing larger items
The two baskets in the middle basket can be removed, or the
entire middle basket can be removed to create more space
between the upper and lower baskets if larger items are being
washed.
NOTE!
Fit the supplied protective cap (in the enclosed plastic bag) if
the wire basket with spray pipes or the entire middle basket is
removed. Don't forget to remove the protective cap when the
wire basket with spray pipes or the entire middle basket is
refitted.
Protective cap
Lower basket
Place plates, side plates, serving dishes, pots and cutlery (in the
cutlery basket) in the lower basket.
Place pots and pans in the rear of the lower basket to best utilise
dishwashing performance from the two rear spray nozzles (Double
Power Zone™Pots & Pans), which are intended for these types
of dishes.
6

Wine glass shelf
Fold-down plate supports
Lower the fold-down plate supports when washing pots.
1
2
Forward mount for plate support
Used for plates with a diameter greater than 25 cm.
4
3
1
2
Cutlery basket
Place cutlery with the handles facing down, except for knives,
and spread them out as much as possible. Ensure that spoons
do not stack inside each other.
The cutlery basket is best placed in the middle at the front of the
lower basket to best utilise dishwashing performance from the
unique spray nozzle (Power Zone™Cutlery), which is intended
for the cutlery basket.
NOTE!
Do not place cutlery made of different materials, such as silver
and stainless steel, in the same place (risk of discolouration).
WARNING!
Knives and other pointed items must be placed with the points
down in the cutlery basket or horizontally in other baskets.
Fold-down section for small items
The cutlery basket has a fold-down section in the middle for small
items, or small shafts, such as electric whisk attachments.
ac
b
Cutlery basket with lid
ac
b
Positioning of cutlery basket lid (in upper basket)
The cutlery basket lid can be removed and used, for example,
as an extra cutlery basket in the upper basket (see below).
ab
7

Extra cutlery basket (disassembly)
a
d
2
1
b
2
1
c
Extra cutlery basket (assembly)
a
c
b
d
x 4
x 2
x 4
x 2
TIP!
The disassembled parts can also be mounted on the large
cutlery basket to make an even larger cutlery basket.
Positioning of extra cutlery basket
a b
a
c
b
8

Using the dishwasher
Add detergent
1 Prewash detergent compartment
2 Main wash detergent compartment
Detergent is added according to water hardness.
Follow the instructions on the detergent packaging.
Too much detergent can result in less effective dishwashing and
also entails greater environmental impact.
Add the detergent to the detergent compartment. There is one
compartment for the prewash and one for the main wash. If tablets
are not used, add a small amount of the detergent to the prewash
compartment. Contact the detergent manufacturer if you have
any questions about the detergent.
WARNING!
Children must be supervised –dishwasher detergent is
corrosive!
NOTE!
Use only dishwasher detergent! Washing up liquid must not
be used as the foam that forms prevents the dishwasher from
operating effectively.
Dishwasher tablets
Halve the tablet if it is difficult to close the dispenser lid. There is
a risk that the detergent will not be released properly if the lid is
tight and will not open correctly.
NOTE!
Dishwasher tablets are not recommended for short programs
(less than 75 minutes). Use powder or liquid dishwasher
detergent instead.
3–in–1/All-in-one detergent
Read through the directions for these products carefully. If
anything is unclear, contact the detergent manufacturer.
Program selection
Press the Program selector one or more times until the desired
program appears on the display.
Daily wash
A program suitable for day-to-day dishwashing. This program
can also clean dried leftovers, but is not intended for burnt food,
such as on oven dishes.
Time program
The program adapts to the specified running time or finish time.
With this program it is important to choose a time suited to how
dirty the dishes are.
Slightly dirty dishes0:30-1:15
Normally dirty dishes1:30-2:00
Very dirty dishes2:15-3:00
Heavy wash
Program for very dirty dishes, such as pans, casserole dishes
and oven dishes. If these dishes do not completely fill the
dishwasher, you can add plates and the like.
Normal wash
Use to wash normally dirty dishes, such as plates, serving dishes,
cups, glasses and so on.
For washing normally soiled mixed loads, with the best energy
and water performance, use the Normal wash program with
temperature 50 °C and short drying .
If you want to improve the dishwashing and drying result select
the options 65 °C and long drying . This causes a slight
increase in energy consumption.
Mixed wash
This dishwashing program is used when you have lightly soiled
dishes in the upper basket and heavily soiled dishes in the lower
basket. This program has a longer program time than Lower half
wash.
Upper half wash
You can use this program if you only have cups and glasses that
need washing in the upper basket. Slightly dirty dishes can also
be placed in the lower basket.
Lower half wash
You can use this program when you only want to wash plates
and cutlery in the lower basket. Slightly dirty dishes can also be
placed in the upper basket.
Eco wash
Use when you want to save water. For normally dirty dishes.
Plastic wash
A program intended for washing plastic items that are dishwasher
safe. This program has an extra long drying cycle. Porcelain and
glasses can also be washed.
Delicate wash
If the dishes are not very dirty, you can select Delicate wash. This
program is intended for glasses and porcelain that have just been
used and as such do not require such a powerful program.
This program can be used for fragile dishes. Select No dry if you
want to be especially cautious. See also the section Fragile dishes
in the chapter Loading the dishwasher.
Quick wash
This program is used for glasses and porcelain that is slightly
dirty, such as coffee cups.
Super Quick wash
Short program lasting about 15 minutes with acceptable results
for very slightly dirty dishes.
9

Rinse & Dry
This program comprises a rinse with heating and drying. This is
a suitable program if, for example, you plan to make jam and
want to rinse and heat clean glass jars.
Rinse & Hold
Used to rinse dishes while you wait for the dishwasher to become
fully loaded.
Crockery warming
Used to warm plates. See below for how to place the plates.
10

Selecting Options
If you do not want to select any more options, press the Program selector to exit the options menu.
P R O G
Description
This option activates both spray arms and enables you to wash both
the upper and lower baskets. This option can be used with all pro-
grams except Lower half wash, Upper half wash, Mixed wash and
Crockery warming.
Full load
Loading the baskets
You can use this option if you only have cups and glasses that need
washing in the upper basket. This option can be used with all pro-
grams except Lower half wash, Upper half wash, Mixed wash and
Crockery warming.
Upper half load
You can use this option when you only want to wash plates and
cutlery in the lower basket. This option can be used with all programs
except Lower half wash, Upper half wash, Mixed wash and Crockery
warming.
Lower half load
When you select Delayed start, the dishwasher will start 30 minutes
to 24 hours after you press the Start/Stop button.
1is shown on the display. Press the
button to set the desired start time.
2 Press the Start/Stop button or select fur-
ther options. The dishwasher now counts
down the time every minute until the pro-
gram starts. Then the remaining program
time appears on the display.
Delayed start
Press and hold Start/Stop for three seconds if you want to cancel
the Delayed start option.
With this option, you can choose the temperature used in the main
wash. Select a high temperature if you want to improve dishwashing
efficiency. You can choose a temperature from cold to 70 °C with
all programs except Delicate wash (from cold to 60 °C) and Plastic
wash (from cold to 65 °C). The number of available temperatures
is reduced if the Time saver option is activated.
Press to choose the temperature used in the
main wash.
Temperature
This option can be used with all programs except Time program,
Rinse & Dry, Rinse & Hold and Crockery warming.
A higher temperature in the final rinse and a longer drying phase
improves the drying result if you select Long dry. This causes a
slight increase in energy consumption. If you want a program without
drying, press the option button again and the symbol turns off. To
save energy, select Short dry or No dry.
Long dry
Drying
No dry
Short dry
You can select the drying performance for all programs except Time
program, Rinse & Dry, Rinse & Hold and Crockery warming.
This option shortens the program time, but uses more energy and
water. This option can be selected with the programs Heavy wash,
Normal wash, Mixed wash, Upper half wash and Lower half wash.
OffTime saver
On
11

Description
This option can be activated when using 3-in-1/all-in-one detergents.
The dishwashing program automatically adapts to provide the best
possible dishwashing and drying results every time. If you deactivate
this option, the dishwasher will return to ordinary function for all
programs. This option can be used with all programs except Rinse
& Dry, Rinse & Hold and Crockery warming.
If this setting is activated there is no need to add rinse aid since this
option disables rinse aid dispensing.
NOTE!
In order to achieve good dishwashing results, it is essential to
check which type of detergent or all-in-one product best suits your
needs! Read the detergent packaging carefully for information on
proper use. Always follow the directions for use or information on
the detergent packaging!
OffTab
On 3in1
Super rinse adds two extra rinses. This option can be used with all
programs except Time program, Rinse & Dry, Rinse & Hold and
Crockery warming.
OffSuper rinse
On
The fan runs for another 30 minutes to cool the dishes before you
unload them. This option can be used with all programs except Time
program, Rinse & Dry, Rinse & Hold and Crockery warming.
OffCool touch
(Cool Touch™)
On
See the section Special settings.YesSpecial settings
Exit
12

Start the dishwasher
Press and hold Start/Stop until the display shows "Program
started". Close the door properly, otherwise the dishwasher will
not start.
Time remaining
Once you have selected a program and options, the display
indicates how long the program took the last time it was used.
This may differ somewhat from time to time depending on the
temperature of the water supply, the amount of dishes, the
ambient temperature and other factors.
NOTE!
During the first run of each program, the remaining time
displayed can be slightly misleading, as the dishwasher is
estimating the time. When you run the program a second time,
the dishwasher will calculate the remaining time based on the
previous duration of the program.
Status light™
The status light at the bottom on the dishwasher provides
information by means of 3 different colours.
Status light
Blue
Load more. The program has started, but you can still load more
dishes.
Red
Do not load. You should not load more dishes (risk of poorer
dishwashing result).
Flashing red
This indicates a fault. See further in the section Troubleshooting.
Green
Unload. The dishwashing program is finished. Standby light for
two hours.
Stopping or changing a program
If you want to change program after starting the dishwasher,
open the door then press and hold Start/Stop for three seconds.
Add more detergent if the lid of the detergent dispenser has
opened. Then choose a new program, press Start/Stop and close
the door.
Do you want to add more dishes?
Open the door. The dishwasher stops automatically. Add the
dishes, close the door and the dishwasher continues the program.
If the dishwasher is turned off using
the On/Left-on mode button or due
to a power failure
If the dishwashing program was not finished, the interrupted
program continues when power is restored.
NOTE!
During drying, the program is interrupted if the power is cut or
the door is open for more than 2 minutes.
Once the program has finished
Once the program has finished and the door is opened "End"
appears on the display.
A buzzer also sounds at the end of the program. See the section
Special settings, which describes how to change this function.
A status light also indicates the end of the program. See the
section Status light™in the chapter Using the dishwasher.
Once the dishwasher has finished, it uses only standby power.
Turn off the water supply valve after each use.
Drying
For additional drying the door should be opened 35 mm upon
completion of the drying cycle. For more information, see page
21 in the chapter Technical information.
13

Special settings
How to open the special settings menu:
Press the button until Special settings appears on the display.
Press the button once.
How to save a selection:
Press
P R O G
or
S TA R T
S T O P
to save and exit the special settings menu.
Description
You can choose the language used for the display.English
Language
To open the language menu directly:
Svenska
1. Press and hold the and On/Left-on mode buttons simultaneously.
Dansk
Norsk
2. Press the
P R O G
button to set your preferred language.
Suomi
Français
3. Press the button to save your selection.
Deutsch
Italiano
Espanol
Русский
Nederlands
You can activate the child lock (button lock) option to prevent children from
starting the dishwasher.
Off
Child lock
(Kid Safe™)
On
Press the and buttons simultaneously to temporarily deac-
tivate the button lock when you want to start the dishwasher. The button lock is
automatically reactivated after 3 minutes.
The dishwasher uses a buzzer to indicate when a program is finished or when a
fault has occurred.
0 (Off), 1–4
Buzzer volume
This sound is used to confirm each button press.0 (Off), 1–4Operation volume
Temperatures can be displayed in °C (Celsius) or °F (Fahrenheit).°C
Temperature unit °F
Rinse aid dosage setting.
0 (Off), 1–6
Rinse aid
Shows the water consumption of the last program, as well as the total number of
program cycles the dishwasher has run.
No. of cycles
Water consumption
14

Description
Finally, press to save and exit the menu.
15

Care and cleaning
Coarse filter
The coarse filter traps larger food particles, which cannot get
past the drainage pump. Empty the coarse filter as necessary.
1 Lift the coarse filter by the handle.
2 Empty the coarse filter. Remember to replace it!
Coarse filter
Fine filter
Debris that collects on the fine filter is automatically rinsed away
during each wash. However, the fine filter and its pipe section
should be cleaned a couple of times a year.
1 Turn the handle anticlockwise once.
1x
Fine filter
2Lift the pipe section straight up by the handle. Free the coarse
filter to clean the pipe section.
3 Remove and clean the fine filter.
4 Replace in reverse order. Check that the edges seal properly
when replacing the fine filter.
Pipe section
5 Lock the filter in place by turning the handle clockwise to the
stop position. The handle should point straight out from the
dishwasher.
1x
NOTE!
The dishwasher must not be used without the filter in place!
Diswashing efficiency can be affected if the course filter is
incorrectly fitted. After cleaning ensure that filter handle is fully
locked with the handle pointing out of the dishwasher.
Drainage pump
The pump can be accessed from inside the dishwasher.
1 Cut the power to the dishwasher by pulling out the plug from
the wall socket!
2 Remove the coarse filter and pipe section.
3 Remove the small yellow fitted piece at the left of the bottom
drain (see illustration below).
4 By inserting your finger into the hole you can turn the pump
blade to release anything blocking it.
5 Reinstall the fitted piece and filters.
6 Plug the machine in again.
If the dishwasher still does not start and a whirring sound is
heard, the overflow protection has been activated.
•Shut off the water.
•Remove the plug from the wall socket.
•Call the service division.
NOTE!
Do not forget to reinstall the fitted piece.
Lower spray arm
Holes and bearings can sometimes become blocked.
1 Pull the lower spray arm straight up to release it.
2 Remove any debris using a needle or the like. The spray arms
also have holes underneath.
16

Upper spray arm
1 Pull out the basket.
2 Unscrew the spray arm bearings as illustrated to remove the
spray arm from the upper basket.
Spray arm bearings
3 Clean the upper spray arm in the same manner as the lower
spray arm.
4 Replace the spray arm and screw the spray arm bearings
firmly back into place.
Cleaning the middle basket
1 Pull out the basket.
2 Check the holes in the spray pipe.
Spray pipes
3 Clean with a needle or the like.
Door
When cleaning the edge around the door, use only a slightly
damp cloth (with a little cleaner if necessary).
WARNING!
Do not use a spray bottle or the like around the door lock. This
is to ensure that water does not penetrate the door catch and
come into contact with the electrical components.
Limescale deposits
The dishwasher tub is made of stainless steel and is kept clean
through normal use. However, if you have hard water, limescale
deposits may form in the dishwasher. If this happens, run the
Normal wash program with high temperature and two tablespoons
of citric acid in the detergent compartment (with no dishes in the
machine).
Front panel
Keep the touch buttons clean and free from grease. Wipe them
clean with a dry or slightly damp cloth. Never use cleaners –they
can scratch the surface. Use the On/Left-on mode button to turn
off the dishwasher before cleaning the touch buttons to avoid
activating any buttons unintentionally.
17

Troubleshooting
ActionDisplay
Call the service division.Overfilling
See "Water remains in the dishwasher" in the table below.Water outlet fault
Check that the water tap is on.Water inlet fault
Check whether dishwasher inlet hose is connected to a pressure
limiting valve (some pressure limiting valves may restrict the supply
of water to the dishwasher).
Turn off the water tap and call the service division.Inlet valve leakage
Clean the filters. See the section Care and cleaning.Clean filter
Turn off the machine with the On/Left-on mode button and then turn it on again to clear the error message from the display.
ActionPossible causesProblem
Remove the arms and clean them.The spray arms do not rotate.The dishes are not clean.
Check that the dishes are not blocking the
spray arms.
Avoid large packages.Old detergent. Detergent is a perishable
product.
Dose according to water hardness. Far too
much or far too little detergent results in
poorer dishwashing results.
Incorrect detergent dosage.
Select a higher temperature or a more pow-
erful program.
Dishwashing program too weak.
Do not cover porcelain with large bowls or
the like. Avoid placing very tall glasses in the
corners of the baskets.
Dishes loaded incorrectly.
Place dishes to sit steady.Glasses and cups have toppled over during
the program.
Screw the filter firmly into place. See the
section Care and cleaning.
The filter is not correctly fitted.
See the sections Before washing for the first
time and Special settings.
Incorrect rinse aid dosage setting.Spots or films on the dishes.
Wash crystal at a low temperature and with
a conservative amount of detergent. Contact
the detergent manufacturer.
Too high temperature and/or too much deter-
gent can cause etching on crystal. Unfortu-
nately, this cannot be repaired, only prevent-
ed.
Reduce the amount. See the sections Before
washing for the first time and Special set-
tings. If you have very soft water, you may
want to dilute the rinse aid 50:50 with water.
Rinse aid dosage setting too high.The dishes have a sticky white/blue film.
Rinse off these types of foodstuffs if not
starting the dishwasher immediately. Why
not use the Rinse & Hold program.
Some foodstuffs, such as mustard, mayon-
naise, lemon, vinegar, salt and dressings,
can mark stainless steel if left for too long.
Spots on stainless steel or silver.
Silver and stainless steel items should not
come into contact during dishwashing.
All stainless steel can cause spots on silver
if they come into contact during dishwashing.
Aluminium can also cause spots on dishes.
Use a detergent with a bleaching agent.Lipstick and tea can be difficult to wash off.Spots left after washing.
18

ActionPossible causesProblem
Check that the dishes are placed securely.
Spin the spray arms to make sure they can
rotate.
The dishes are not correctly placed or the
spray arms are not rotating.
Rattling sound when dishwashing.
Press and hold Start/Stop until the display
shows "Program started".
The Start/Stop start button has not been
pressed for long enough.
The dishwasher does not start.
Check.The door is not properly closed.
Check.A fuse/circuit breaker has been tripped.
Check.The plug is not plugged into the wall socket.
Check.The water tap is turned off.
Check.Overflow/leaks
Turn off the water tap. Pull out the plug and
call the service division.
A whirring sound (the drainage pump) is
heard from the dishwasher and does not stop
when the power is cut with the On/Left-on
mode button.
Press and hold Start/Stop for three seconds
if you want to cancel the Delayed start option.
Check that the Delayed start option has not
been selected.
Loosen the drainage hose where it connects
to the sink unit's water trap. Check that no
debris has fastened. Is the cone-shaped part
of the pipe cut to an inner diameter of at least
14 mm?
Blocked drainage hose.Water remains in the dishwasher.
Check that the hose is free from kinks and
sharp bends.
Kink in drainage hose.
Clean the coarse and fine filters.The filters are blocked.
Ensure filter is completely locked with handle
pointing towards the door.
The filter is not locked in completely.
Clean the drainage pump. See the section
Care and cleaning.
Debris in the drainage pump.
Clean with washing-up brush and low foam-
ing cleaner.
Dirt around the seals and in corners.Bad odour in dishwasher.
Run a program with a higher temperature
about once a month.
Low temperature programs have been select-
ed for a prolonged period.
Activate the Long dry option.Drying power too low.The dishes are not dry enough.
Fully load the dishwasher.The dishwasher is not fully loaded.
Top up with rinse aid or increase the rinse
aid dosage. See the sections Before washing
for the first time and Special settings.
Rinse aid needs topping up or dosage is set
too low.
Open the door a little once the program has
finished.
19

ActionPossible causesProblem
Check that the baskets are correctly posi-
tioned horizontally, and that the middle bas-
ket's water connector is in line with its spray
pipe.
The baskets are not correctly positioned.Cannot close door.
Check that the dishes are not blocking the
baskets from sliding properly into place.
Wait a moment then try again.You have pressed the touch buttons too soon
after opening the door.
The touch buttons do not react when
pressed.
Clean with a dry or slightly damp cloth.Dirt on the touch buttons.
Open the door. The touch buttons only react
to use when the door is open.
The door is closed.
See the section Special settings.Child lock (button lock) activated.
20
