Asko DBI564I.S.U User manual

USER MANUAL
Dishwasher
EN
DBI564I.S.U
DBI564T.S.U
DBI564TH.S.U
DBI564PH.S.U

3Your dishwasher ........................................
4Important safety instructions ...................
4General ........................................................
5Child safety ..................................................
5Child lock .....................................................
5Installation ....................................................
5Overflow guard function ..............................
5Winter storage/Transport .............................
5Packing material ..........................................
6Disposal .......................................................
6Symbols .......................................................
7Before washing for the first time ..............
7Water hardness ............................................
7Basic settings ..............................................
8Add rinse aid ...............................................
9Greener dishwashing ................................
9Save energy and water ................................
10Loading the dishwasher ............................
10Fragile dishes ..............................................
10Loading affects the results ..........................
11The dishwasher's baskets ...........................
11Top cutlery tray ............................................
12Upper basket ...............................................
13Lower basket ...............................................
15Cutlery basket ..............................................
16Typical load .................................................
17Using the dishwasher ................................
17Add detergent ..............................................
18On/Off ..........................................................
18Select program ............................................
19Select program mode ..................................
19Select option ................................................
20Start/Stop .....................................................
21Status light ...................................................
21If you want to load more dishes ...................
21Power failure ................................................
21Once the program has finished ...................
22The best drying results ................................
22Unloading the dishwasher ...........................
23Program chart ............................................
24Settings .......................................................
26Care and maintenance instructions .........
26Add rinse aid ...............................................
26Clean the filters ............................................
27Cleaning the spray arms ..............................
28Clean the outside of the dishwasher ...........
29Run Self-cleaning .........................................
29Remove blockages ......................................
30Troubleshooting .........................................
36Installation instructions ............................
36Important safety instructions ........................
37Transport protection for the door .................
37Trim kit .........................................................
38Placing the dishwasher ................................
38Fit the protective film ....................................
39
Adjust the height and slide the dishwasher
into place .....................................................
40Drain connection ..........................................
41Connection to water supply .........................
42Electrical connection ...................................
43Screwing the dishwasher into place ............
45Dishwasher toe kick .....................................
46Service and warranty .................................
46Limited Warranty –Residential Appliances ..
46Items excluded from warranty .....................
46Disclaimer ....................................................
47ASKO Customer Care ..................................
47Service after expiration of limited warranty ...
47Number of cycles ........................................
48Technical information ................................
48Technical data .............................................
Contents

Welcome to our growing ASKO family!
We are proud of our appliances. We hope that this appliance will be an appreciated and dependable
device for many years to come.
Please read the operating instructions before use. They include general tips, information about the
settings and adjustments you can make, and the best way to take care of your appliance.
Display Start/Stop
Select program modeSelect program Auto door open
Delayed start
On/Off
Add rinse aid
Auto door open
Symbols on the display: Text on the display:
Clean the filters
Run Self-cleaning
See the chapter Care and
maintenance instructions.
Install the dishwasher; see the chapter Installation instructions. Then open the door and press .
"Welcome to your ASKO. First time setup." is shown on the display the first time the dishwasher
is switched on. It is important that you choose the right settings to ensure good dishwashing results.
See page 7.
3
Your dishwasher

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARNING!
When using your dishwasher, follow basic precautions, including the following:
•Read all instructions before using the dishwasher.
•Use the dishwasher only for its intended purpose.
•Use only detergents or rinse agents recommended for use in a dishwasher and keep them
out of the reach of children.
•When loading items to be washed:
–position sharp items so that they are not likely to damage the door seal, and
–load sharp knives with the handles up to reduce the risk of cut-type injuries.
•Do not wash plastic items unless they are marked “dishwasher safe”or the equivalent. For
plastic items not so marked, check the manufacturer’s recommendations.
•Do not operate the dishwasher unless all enclosure panels are properly in place.
•Do not tamper with controls.
•Do not abuse, sit on, or stand on the door or dish rack of the dishwasher.
•To reduce the risk of injury, do not allow children to play in or on a dishwasher.
•Under certain conditions, hydrogen gas may be produced in a hot water system that has not
been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water system
has not been used for two weeks, before using the dishwasher turn on all hot water faucets
and let the water flow from each for several minutes. This will release any accumulated
hydrogen gas. As the gas is flammable, do not smoke or use an open flame during this time.
•Remove the door of the dishwasher when removing the dishwasher from service or discarding
it (so that children cannot become trapped inside).
•Read the grounding instructions in the installation instructions.
General
•Do not run the dishwasher while you are out of the home.
•Do not store or use combustible materials, gasoline, or other flammable vapors and liquids in
the vicinity of this or any other appliance.
•Disconnect electrical power to dishwasher before servicing.
•Repairs should be done by a qualified technician.
WARNING!
PROPOSITION 65 FOR CALIFORNIA RESIDENTS
Cancer and Reproductive Harm –www.P65Warnings.ca.gov
4
Important safety instructions

Child safety
•Always keep small children away from the machine when it is open. There may be some detergent
residue left inside the machine.
•Always close the door and start the dishwasher as soon as you put in the detergent.
•If dishwasher detergent gets in someone’s eyes, rinse them with plenty of water for at least 15
minutes.
•Should a child swallow dishwasher detergent or rinse aid, give plenty to drink immediately, i.e.,
one or two glasses of milk or water. Do not try to induce vomiting. Seek medical advice
immediately: Call the National Poison Control Center at 1-800-222-1222.
WARNING!
Dishwasher detergents and rinse aids are corrosive, so always keep them out of reach of children.
Child lock
You can activate the Automatic child lock setting to prevent children from starting the dishwasher.
See the chapter Settings. You can also temporarily activate and deactivate the Child lock function.
Press and hold and for three seconds.
Installation
See the chapter Installation instructions.
Overflow guard function
The overflow guard starts pumping out the machine and turns off the water supply if the water level
in the dishwasher exceeds the normal level. If the overflow guard is triggered, F54 (Overfilling water)
appears on the display. Turn off the water supply valve and contact your nearest Customer Care
Center. (To avoid water leakage outside the dishwasher, do not remove the plug from the power
outlet until the water supply valve has been turned off!)
Winter storage/Transport
Store the dishwasher above freezing and avoid long transport distances in very cold weather.
Transport the dishwasher upright or laying on its back.
Before transporting a used dishwasher, or before prolonged storage, water must first be drained
from the machine.
Packing material
The outer packaging protects the product during transport. The packaging material is recyclable.
Separate the different packaging materials to help reduce raw material use and waste. Your dealer
can take the packaging for recycling or direct you to the nearest recycling center. The packaging
is comprised of:
•Corrugated cardboard made from up to 100% recycled material.
•Expanded polystyrene (EPS) with no added chlorine or fluorine.
•Supports made from untreated wood.
•Protective plastic made from polyethylene (PE).
5
Important safety instructions
