ASL INTERCOM DAX200 User manual

Installation Guide
ASL Document Ref.: U-0518-1201.doc
Issue: 02 complete, approved - Date: 01/06/09
Part Number: M0518_79
DAX200/DAX400
Intellevac Expansion Amplifier Units

DAX200/DAX400 – Installation Guide
Copyright © 2009 Application Solutions (Safety and Security) Ltd.
Application Solutions (Safety and Security) Ltd.
Unit 17 Cliffe Industrial Estate
Lewes - East Sussex
BN8 6JL - UK
Tel: [phone] Fax: [phone]
www.asl-control.co.uk
All rights reserved.
Information contained in this document is believed to be accurate, however no representation or warranty is given and Application
Solutions (Safety and Security) Ltd. assumes no liability with respect to the accuracy of such information.
Issue: 02 complete, approved
Page 2 of 28
This equipment is designed and manufactured to conform to the following EC standards:
EMC EN55103-1/E1, EN55103-2/E5, EN50121-4, EN50130-4, EN61000-6-3,
ENV50204
Safety EN60065
Failure to use the equipment in the manner described in the product literature will
invalidate the warranty.
A 'Declaration of Conformity' statement to the above standards, and a list of auxiliary
equipment used for compliance verification, is available on request.
This product must be disposed of in accordance with the WEEE directive.
Contents
1Installation ................................................................................................................................................ 3
2Connections ........................................................................................................................................... 14
3DAX and DAU Positioning..................................................................................................................... 19
4Product Specification ............................................................................................................................ 21
5Mechanical Dimensions ........................................................................................................................ 23
6Safety and Precautions ......................................................................................................................... 25
Additional User Documentation:
Intellevac system user documentation and additional reference information are available from the ASL
website: www.asl-control.co.uk

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 3 of 28
1 Installation
Figure 1 DAX200 – Main Components
BATTERIES
ELECTRONICS
MODULE
CHASSIS PLATE
DAX200 shown here.
(DAX400 has the same components)
BACK BOX
DOOR
INTERLINK ADAPTOR
ELECTRONICS MODULE TOP VIEW
MAINS ISOLATION
SWITCH
BATTERY ISOLATION
SWITCH
BATTERY FUSE
LThe battery pack may be provided by ASL, or by the customer according to the following specification:
• DAX200 (200 W Expansion Amplifier Unit): 2 x 12 V 24 Ah (Yuasa Part No.: NPL24–12IFR)
• DAX400 (400 W Expansion Amplifier Unit): 2 x 12 V 38 Ah (Yuasa Part No.: NPL38–12IFR)

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 4 of 28
Installation Requirements
• The DAX back box
• The Expansion Amplifier Unit electronics module
• The DAX Expansion Amplifier Unit’s batteries and straps:
DAX200: 2 x 12 V 24 Ah (Yuasa Part No.: NPL24–12IFR)
DAX400: 2 x 12 V 38 Ah (Yuasa Part No.: NPL38–12IFR)
• Electric drill
• Wall fixings
• Cable glands
• A small flat-bladed screwdriver
• Large pozidriv screwdrivers (for M3 and M4 screws)
• A M8 nut spanner
• Cable termination tools - cutters/strippers etc. to suit cable type
Site Specific Documentation and Information
Ensure that the engineer is equipped with information on the following:
• The physical location of the DAX units.
• DAX addresses and how their speaker outputs relate to zone names.
• Loudspeaker circuit: wiring, including number of End of Line resistors.
• Loudspeaker circuit: expected loudspeaker loading.
Cabling Requirements
• Mains power supply cabling protected by a dedicated Class C MCB (Miniature Circuit Breaker):
Standard fire resisting cable and should meet PH30 classification.
• Audio, audio monitoring, and CAN bus cabling:
Fire rated cable: 5 pair, twisted (minimum 4 pair twisted) and 0.5 mm2(min.) conductor size with overall
screen.
Recommended type: Fireshield Cable Systems Limited FSDATA/0.5/05P/RD or Draka Firetuf Data
equivalent.
If fireproof interlinking cables are not used, then the DAX must be positioned as described in Section
“3 DAX and DAU Positioning” (page 19) in order that the cabling do not leave the confines of the DAU
Distributed Amplifier Unit enclosure.
• 100 V line loudspeaker circuit cabling:
1 x 2 core, twisted, screened. 1.5 mm (min.)
Fire Rated. MICC, Pirelli FP200 or equivalent.
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 5 of 28
Recommended Installation Procedure
For Voice Alarm or any safety application if fireproof interlinking cables are not used, then the DAX must
be positioned as described in Section “3 DAX and DAU Positioning” (page 19).
Please read and observe the instructions and guidelines in Section “6 Safety and Precautions” (page 25)
prior to installation. Failure to follow these instructions and guidelines may cause personal injury and/or
damage to the equipment.
LPictures in the following procedure show the DAX200 200 W Expansion Amplifier Unit as standard.
The DAX400 400 W Expansion Amplifier Unit has similar components in the same positions. Pictures of
the DAU400 are also included when required for clarity.
1. Unlock and open the unit’s door.
2. Disconnect the earth strap connecting the
electronics module to the back box; see
Figure 2.
Figure 2 DAX200 – Remove Earth Strap
Disconnect
Earth Strap
BACK BOX
Avoid this area!
!
!
3. Remove the two transit brackets by undoing
the top two M8 securing nuts; see Figure 3.
Re-fit the securing nuts after removing the
transit brackets.
LDAX400 brackets have a different format,
but are fixed by securing nuts at similar
position.
Figure 3 DAX200 – Remove Transit Bracket
a) Remove nuts.
b) Remove transit
brackets.
c) Re-fit nuts.
!
!
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 6 of 28
4. Remove the electronics module, observing
the following precautions.
This equipment is very heavy. Please lift
and handle with care to avoid strain or
impact injuries.
Take the weight of the unit using one
hand at the lower right hand corner while
using the other hand to guide the top left
of the unit; see Figure 4.
Do not lift by the bottom left hand corner,
as this is likely to damage the exposed
electronics. Never lift the unit by the black
heatsink.
Figure 4 DAX200 – Remove Electronics Module
BACK BOX
Avoid this area!
!
!
5. Store the electronics module carefully in
order to avoid damage or dust ingress
during the installation procedure.
6. Remove the chassis plate from the back
box by undoing the M8 securing nuts (4 on
DAX200, and 6 on DAX400); see Figure 5.
Figure 5 DAX200 – Remove Chassis Plate
Remove nuts.
DAX400 has 2
nuts at these
positions.
BACK BOX
Remove nuts.
CHASSIS PLATE
7. Remove the gland plate located on the top
of the back box by undoing the ten M4
securing screws.
Figure 6 Back Box Top View – Gland Plate
KNOCK-OUTS (
φ
20mm)
SCREWS
8. Remove all knock-outs that are required for
the desired cable connections.
LAll removal of knock-outs should be
carried out before the electronics module
is fitted.
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 7 of 28
9. Prepare the wall mounting holes
appropriately.
Hole positions are shown in Figure 23
(page 23) for DAX200, and in Figure 24
(page 24) for DAX400.
If fireproof interlinking cables are not
used, then the DAX must be positioned as
described in Section “3 DAX and DAU
Positioning” (page 19).
10. Prepare any direct connection holes for
glanding to the DAU, if the DAX is to be
positioned as described in Section
“3 DAX and DAU Positioning” (page 19).
LNote that holes for glanding should be
prepared at matching positions on the
DAU.
The DAU must be removed from the back
box before preparing any hole. Also
ensure that all swarf is removed from the
back box before re-fitting the DAU.
The Intellevac Hardware Commissioning
Guide describes how to remove and re-fit
the DAU after the unit has been installed.
11. Secure the back box to the wall.
The wall and fixings must be capable of
safely bearing the weight of the
equipment – 51 kg for DAX200 and 70 kg
for DAX400. Ensure that the wall is made
of a suitable material (not stud walls for
example) and that adequately rated
fixings are used.
12. Ensure all swarf is removed from the back
box before proceeding.
13. Re-fit the chassis plate by reversing the
procedure carried out in step 6;
see Figure 5.
14. Fix the DIN rail that will support the Interlink
Adaptor to the back box using the fixings
provided.
L• Position the DIN rail so that the
Interlink Adaptor can be mounted at
the position shown in Figure 7.
Mounting the adaptor at this position
enables the ribbon cable from the
Electronics Module to be connected
straight to the adaptor.
Refer to Section “DIN Rail Interlink
Adaptor” (page 15) for details on the
Interlink Adaptor.
• Fixings positions are provided at a
similar height above the Electronics
Module on the DAX400 chassis plate.
Figure 7 DAX200 – Install DIN Rail
INTERLINK ADAPTOR
Position DIN rail so that adapto
r
can be mounted at position shown:
DAX200: d = ~ 28 cm
DAX400: d = ~ 31 cm
d
BACK BOX
EARTHING
BARS
15. Fit all glands to the gland plate, and re-fit
the gland plate to the back box.
Cables may be glanded, dressed, and cut
to approximately the correct length.
LThe top edge of the chassis plate has
provision for earthing bars for terminating
the incoming cable drain wires. See
example in Figure 7.
16. Fit any glands required by direct connection
to the DAU. These are to be fitted to the
holes drilled in step 10.
!
!
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 8 of 28
17. The remaining procedure explains the
installation of DAX units with default
configuration as follows:
• 4 inputs and 4 outputs: each output
configured for single speaker circuit.
If alternative configurations are required,
please refer to the Intellevac Hardware
Commissioning Guide.
These configurations require access to
the hardware within the Electronics
Module. Therefore we recommend that
alternative configurations be set at this
stage wherever it is possible.
The DAX’s amplifier configuration is
carried out in similar fashion to the DAU,
bearing in mind that the Router board and
the Network Interface Card are not
present in the DAX.
It is important to note that the unit address
switch SW6 should be set to the
appropriate address for the DAX as
described in step 24.
18. Carefully lift the Electronics Module into
place observing handling precautions
(see step 4) and offer up the 'hooks' to
mating slots.
19. Lower the Electronics Module until it is
securely seated.
20. Re-fit the transit brackets by reversing the
procedure carried out in step 3.
21. Re-connect the earthing strap from the
Electronics Module to the back box; see
Figure 2.
22. Mount the Interlink Adaptor provided on the
DIN rail, and secure it in place using EW35
end-stop terminals, as shown in Figure 8.
LMount the Interlink Adaptor on the DIN rail
with the 16-Way ribbon connector closest
to the DAX electronics module, as shown
in Figure 8.
Figure 8 DAX200 – Install DIN Rail Interlink
Adaptor
Mount adaptor with the
16-Way ribbon cable
connector closest to
the Electronics Module
INTERLINK
ADAPTOR DETAIL
16-Way Ribbon
Cable Connector
Screw-In
Terminals
End-Stop
Terminal
End-Stop
Terminal
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 9 of 28
23. Remove the top cover in order to gain
access to the boards, and to the mains and
battery input terminals.
a. Remove 5xM3 screws on the
DAX200; see Figure 9.
Figure 9 DAX200 – Remove Top Cover
SCREW POSITIONS
b. Remove 1xM4 screw, and slacken
four side thumb nuts on the DAX400.
Also disconnect the earthing strap
connecting the Electronics Module to
the top cover; see Figure 10.
Figure 10 DAX400 – Remove Top Cover
SCREW
Slacken thumb nuts
here and at the same
locations on the
o
pp
osite side
24. Set the unit’s address using the rotary
switch SW6 shown in Figure 11.
The unit’s address should be in sequence
starting at ‘2’, i.e. the first DAX connected
to a DAU should be set to address ‘2’; the
second DAX to address ‘3’, if connected;
and so on.
Unit Address ‘1’ is used by the DAU’s
built-in amplifier system.
Figure 11 DAX200 – Set Unit Address
A
DDRESS ROTAR
Y
SWITCH DETAIL
SW6
1. Set the unit address.
This should be ‘2’ if
this DAX is the only
Expansion Amplifier
Unit connected to
the DAU.
2. Do not make any
other adjustment.
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 10 of 28
25. Ensure that the power to the unit is
disconnected.
• Ensure that the mains and battery
isolator switches are in the off
position.
• Ensure that the mains supply to the
unit is isolated.
26. Ensure that the DAU is powered down.
27. Connect all speaker lines to the terminal
blocks. Refer to Section “2 Connections”
(page 14) for pinout details.
LBefore connecting the speaker lines to the
DAX it is advisable to check the speaker
lines to confirm that:
• the expected number of End of Line
resistors is attached, and the A and B
circuits are evenly loaded;
• the impedance is as expected and
does not exceed the capability of the
associated amplifier configuration;
• all speaker lines are isolated from
earth.
Ensure adequately rated cables are used
for power supply and loudspeaker
connections, and route interlinking cables
away from power and loudspeaker
cables.
Wago Cage Clamp Connection
Use one of the two methods shown in the diagram
below to terminate the 100 V power speaker
cabling in the Wago connectors.
When the screwdriver is removed, the bare end of
the wire will be held securely by the contact
spring. To remove the wire, reverse the process.
28. Connect the Electronics Module’s ribbon
cable and the field wiring to the DIN rail
Interlink Adaptor; see Figure 13.
The top edge of the chassis plate has
provision for earthing bars for terminating
the incoming cable drain wires.
For EMC compliance; see Figure 12:
• Connect the cable screen of ALL
external cabling to one of these
earthing bars.
• All screen tails to be < 3 cm.
The DAU can one or more Expansion
Amplifier Units, which are daisy-chained
to the DAU through the Audio-CAN bus;
see Figure 19 (page 17).
The ends of the Audio-CAN bus must be
terminated by 120 Ohm resistors.
If this DAX is the last unit connected to
the Audio-CAN bus, then an external
120 Ohm terminator must be fitted
between ‘CANH’ and ‘CANL’ terminals on
the DIN rail Interlink Adaptor.
Refer to Section “DIN Rail Interlink
Adaptor” (page 15) for terminal allocation
details.
Figure 12 Cable Screen Connection Example
EXTERNAL
CABLING
EARTHING BAR
FIELD CONNECTION
CABLE
SCREEN
SCREEN TAILS TO BE < 3 cm
!
!
!
!
!
!
!
!
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 11 of 28
Figure 13 DAX200 – Plug Ribbon Cable
Field wiring from host DAU
and other ‘daisy-chained’
DAX units (if any)
Right and left
connector clamps
fully ‘clicked’ into
place over the ribbon
connector.
16-way ribbon
cable
Earthing Bar
!
!
29. Carefully lift the batteries into position and
secure with the strap provided as shown in
Figure 14 for DAX200, and Figure 15 for
DAX400.
Ensure correct positioning of batteries:
DAX200: top side of batteries facing the
operator.
DAX400: front side of batteries facing the
operator.
30. Connect the battery cables (positive,
negative, and interlink) noting correct
polarity: Red=Positive, Black=Negative.
Note that the interlink cable is red.
The 24 V DC batteries can deliver very
high currents that could cause fire or
burns. Take care to avoid short-circuits of
the battery supply by tools or jewellery.
See Figure 14 for DAX200, and Figure 15
for DAX400.
Note the orientation of the ring terminals.
Ensure correct connection of battery
leads to the charger board.
Correct connection of batteries will
illuminate the LED located on the left of
the battery connection points on the
electronics module.
Figure 14 DAX200 – Battery Connection
TOP SIDE OF BATTERIES
LED
DAX200
BATTERY
INPUTS
POSITIVE POSITIVE NEGATIVE NEGATIVE
RED WIRE RED WIRE
BLACK WIRE
RED WIRE
DAX200
!
!
!
!
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 12 of 28
Figure 15 DAX400 – Battery Connection
FRONT SIDE OF BATTERIES
LED
DAX400
BATTERY
INPUTS
POSITIVE POSITIVE NEGATIVE NEGATIVE
RED WIRE
RED WIRE
BLACK WIRE
BLACK WIRE
DAX400
31. Connect the mains supply cabling; see
Figure 16.
Ensure that the mains supply is through a
dedicated cable entry.
Always ensure that the equipment is
correctly earthed by connection to an AC
mains supply with a protective earth
connection.
Note that this equipment is intended for
continuous operation and as such does
not contain an external mains switch. It is
considered as a system which is
permanently connected to the mains. An
all-pole mains isolator with a separation of
3 mm in each pole shall be incorporated
in the electrical supply spur feeding the
unit.
Figure 16 DAX200 – Connect Mains Supply
Harmonised Colours:
N = Blue
Earth = Green/Yellow
L = Brown
MAINS INPUT DETAILS
CHASSIS PLATE
!
!
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 13 of 28
32. Re-fit the top cover by reversing the
procedure carried out in step 23.
On DAX400, ensure that the earthing
strap is re-fitted to the top cover.
Figure 17 DAX200 – Complete Assembly
BATTERIES
ELECTRONICS MODULE
CHASSIS PLATE
BACK BOX
33. Connect the mains power supply to the unit.
34. Power the unit on by turning the mains
isolator switch on, and then turning the
battery isolator switch on.
When powering up the unit, the mains
isolator switch should be turned on before
turning on the battery isolator switch.
35. The unit is ready for commissioning.
Refer to the Intellevac System Software
Commissioning Guide.
LThe DAX unit is configured through the
DAU front panel:
1) Power the DAU on, starting with the
mains supply.
2) Perform a ‘Learn’ function in order
that the DAU can detect the DAX.
3) Commission the DAX in similar
fashion to the DAU amplifier system,
but selecting the DAX unit address
configured in step 24 for frame
number in place of Frame #01.
36. Close and lock the unit’s door when testing
and commissioning procedures have been
completed.
!
!
CHASSIS PLATE
ELECTRONICS MODULE
BATTERIES
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 14 of 28
2 Connections
Figure 18 DAX200 – Connectors
SPEAKER
OUTPUT 1
SPEAKER
OUTPUT 2
SPEAKER
OUTPUT 3
SPEAKER
OUTPUT 4
MAINS
INPUTS
TOP VIEW
DAX200
(DAX400 has the same connectors at same locations.)
MAINS
SWITCH
BATTERY
SWITCH
SPEAKER OUTPUT DETAIL
A–
A+ B–
B+
FAULT A
FAULT B

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 15 of 28
Speaker Outputs 1 to 4
Signal Description
A−Circuit A Zone Out−, 100 V RMS audio
A+ Circuit A Zone Out+, 100 V RMS audio
B−Circuit B Zone Out−, 100 V RMS audio
B+ Circuit B Zone Out+, 100 V RMS audio
LCabling connector: 4-Way pluggable Wago male cage clamp terminal (5.08 mm)
Mains Supply
Signal Description
N Neutral, 230 V +10, −6 % RMS 50 Hz AC
Protective earth
L Live, 230 V +10, −6 % RMS 50 Hz AC
DIN Rail Interlink Adaptor
The DIN rail Interlink Adaptor provides connections from the DAX amplifier system back to the DAU.
In order that the DAU can drive Expansion Amplifier Units, these units need to provide connections for the
low level audio from the DAU, the CAN bus, and the audio monitoring bus.
The low level audio, the CAN bus, and the audio monitoring bus connections are provided on a 16-way
ribbon cable connected to a box header underneath the amplifier motherboard of the DAX. By plugging this
16-way ribbon cable to the Interlink Adaptor, these connections are made available on screw-in terminals
suitable for the field cabling required to connect the DAX to the DAU.
16 14 12 10 8 6 4 2
15 13 11 9 7 5 3 1
16-WAY BOX HEADER
(To DAX 16-Way ribbon cable)
LABEL
2 x 8-WAY SCREW-IN
TERMINAL BLOCK (5 mm)
(Field Wiring – From DAU)

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 16 of 28
Terminal Signal Connect to DAU’s Description
1 Audio 1+ OUT5+
1) Balanced audio input +VE connection
2 Audio 1– OUT5- Same as above, but –VE connection
3 Audio 2+ OUT6+
1) Balanced audio input +VE connection
4 Audio 2– OUT6- Same as above, but –VE connection
5 Audio 3+ OUT7+
1) Balanced audio input +VE connection
6 Audio 3– OUT7- Same as above, but –VE connection
7 Audio 4+ OUT8+
1) Balanced audio input +VE connection
8 Audio 4– OUT8- Same as above, but –VE connection
9 GND N.C. 0 V reference. Alternative to pin 10.
10 GND GND 0 V reference. For CAN bus.
11 CANH CANH
2) Controller Area Network (High)
12 CANL CANL Controller Area Network (Low)
13 SLEEP DXN N.C. Not used. N.C. = Not Connected
14 SLEEP DXP N.C. Not used. N.C. = Not Connected
15 AUDIO_MON+ AUDIO_MON+
2) Audio Monitor Bus +VE connection
16 AUDIO_MON– AUDIO_MON– Same as above, but –VE connection
1) These outputs are example for a DAU and a DAX with standard configuration, and driving eight loudspeaker
zones. These connections vary according to each system configuration.
As standard the DAU is configured to have outputs 1 to 4 connected to its built-in amplifiers configured for single
speaker circuit, and outputs 5 to 8 to be connected to Extension Amplifier Units.
As standard the DAX is configured as follows:
Audio 1 ÆSpeaker Output 1
Audio 2 ÆSpeaker Output 2
Audio 3 ÆSpeaker Output 3
Audio 4 ÆSpeaker Output 4
All outputs configured for single circuit speakers.
See Section “DAU Connections (for reference only)” (page 17).
2) The Audio-CAN bus comprises the CAN bus pair and the AUDIO MON pair.
The DAU can host one or more Expansion Amplifier Units, which are daisy-chained to the DAU through the Audio-
CAN bus. Therefore, only the first item on the Audio-CAN bus has the CAN and AUDIO MON pairs directly
connected to the DAU; see Figure 19 (page 17).
The ends of the Audio-CAN bus must be terminated by 120 Ohm resistors.
If the DAX is the last unit connected to the Audio-CAN bus, then an external 120 Ohm terminator must be fitted
between ‘CANH’ and ‘CANL’ terminals on the DIN rail adaptor.
3) Field cabling: cable ends to be fitted with suitable bootlace ferrules.
4) 16-Way ribbon cable to DAX connector: 16-Way IDC female connector.

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 17 of 28
DAU Connections (for reference only)
Figure 19 Connection Diagram Example
DAU200
(Address=1)
DAX200
(Address=2)
CANL
CANH
AUDIO_MON+
AUDIO_MON-
A
UDIO 1+
A
UDIO 1-
OUT n1+
OUT n1-
DAX200
(Address=3)
CANL
CANH
AUDIO_MON+
AUDIO_MON-
A
UDIO 1+
A
UDIO 1-
DAX200
(Address=last)
CANL
CANH
AUDIO_MON+
AUDIO_MON-
A
UDIO 1+
A
UDIO 1-
OUT n2+
OUT n2-
OUT n3+
OUT n3-
120 Ohm
In the above example:
1) All DAX units configured as follows:
• one input and one speaker output (A and B)
• amplifiers paralleled: 100 W A, 100 W B
2) OUTn1 to OUTn3 can be any of DAU outputs requiring the above speaker circuit configuration.
AUDIO_MON-
AUDIO_MON+
CANL
CANH
A
UDIO-CAN BUS
LOW LEVEL AUDIO
Built-in terminator External terminator to
be fitted

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 18 of 28
Figure 20 DAU’s Connectors
CAN BUS
AUDIO MON
AUDIO OUT
1-4
AUDIO OUT
5-8
SUPPLY+ (N.C.)
A
UDIO_MON-
A
UDIO_MON+
GND CANL CANH
N.C. = Not Connected
AUDIO OUT RJ45 Connector
Signal Description
OUT'n'+ Balanced audio output +VE connection
0 dBu @ 600 Ωimpedance
OUT'n'−As above but –VE connection.
OUT5-
OUT5+
OUT6-
OUT7+
OUT7-
OUT6+
OUT8-
OUT8+
OUT4+ OUT4- OUT2+ OUT3- OUT3+ OUT2- OUT1+ OUT1-
12345678
12345678
PCB
TOP COVER
Signal Pin CAT5 Cable (EIA 568-B)
OUT1+ 2 orange
OUT1- 1 orange/white
OUT2+ 6 green
OUT2- 3 green/white
OUT3+ 4 blue
OUT3- 5 blue/white
OUT4+ 8 brown
OUT4- 7 brown/white
OUT5+ 2 orange
OUT5- 1 orange/white
OUT6+ 6 green
OUT6- 3 green/white
OUT7+ 4 blue
OUT7- 5 blue/white
OUT8+ 8 brown
OUT8- 7 brown/white

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 19 of 28
3 DAX and DAU Positioning
In Voice Alarm and any safety application, the cabling should not leave the confines of the unit’s enclosure.
Therefore if fireproof interlinking cables are not used, then DAU and DAX units must be located immediately
adjacent to each other and interconnected by a bushed link.
By mounting the two enclosures side by side (Figure 21) or one above the other (Figure 22), the cabling can
be directly passed between the two enclosures without compromising the integrity of the interlinking cables.
L• A 25 mm bushed link between the two enclosures is advisable, as a 20 mm link will not
allow easy passage of the RJ45 connector.
• Due to the door hinge requirements in the side-by-side mounting the enclosures must be
spaced by more than 15 mm to allow the door to open fully on the right-hand unit, see
Figure 21.
Figure 21 DAU and DAX Mounted Side by Side
DAU or DAX DAU or DAX
Due to door hinge displacement, ensure enclosures are
separated by a minimum of 15 mm.
Suitable link position with 25 mm diameter bush
(Observe earth strap connection)
!
!

DAX200/DAX400 – Installation Guide
Issue: 02 complete, approved
Page 20 of 28
Figure 22 DAU and DAX Mounted One Above the Other
DAU or DAX
DAU or DAX
Suitable link position with 25 mm diameter bush
(Observe battery support position)
