ASL INTERCOM V2000 User manual

Installation Guide
ASL Document Ref.: U-0623-0291.docx
Issue: 04 complete, approved - Date: 10/07/15
Part Number: M0623_26
V2000
Modular Amplifier Mainframe
(LSZDC and V2000-STBY Interface Cards shown as example.)
(Silver front panel with silver annotation on a black background / black annotation on a silver background)

V2000 – Installation Guide
Copyright © 2015 Application Solutions (Safety and Security) Limited
Application Solutions (Safety and Security) Limited
Unit 17 Cliffe Industrial Estate
Lewes - East Sussex
BN8 6JL - UK
Tel: [phone] Fax: [phone]
www.asl-control.co.uk
All rights reserved.
Information contained in this document is believed to be accurate, however no representation or warranty is given and Application
Solutions (Safety and Security) Limited assumes no liability with respect to the accuracy of such information.
U-0623-0291.docx – Issue: 04 complete, approved
Page 2 of 40
This equipment is designed and manufactured to conform to the following EC standards:
EMC: EN 55103-1/E1, EN 55103-2/E5, EN 50130-4, EN 50121-4, EN 61000-6-2 and EN 61000-6-3
Safety: EN 60950-1 (Class I, Over-voltage category 2, pollution degree 2)
Professional equipment (not intended for sale to the general public) with rated power greater than 1 kW.
A ‘Declaration of Conformity’ statement to the above standards is available on request.
Failure to use the equipment in the manner described in the product literature will invalidate the warranty.
This product must be disposed of in accordance with the WEEE directive.
Contents
1Introduction ................................................................................................................................................................. 3
2Safety and Precautions............................................................................................................................................... 4
3Preparation ................................................................................................................................................................. 7
4Unpacking and Handling............................................................................................................................................. 8
5Installation................................................................................................................................................................... 9
6Connections.............................................................................................................................................................. 26
7Technical Specification ............................................................................................................................................. 31
8Mechanical Dimensions ............................................................................................................................................ 34
9Storage and Preservation ......................................................................................................................................... 35
10 Packing for Return .................................................................................................................................................... 36
Additional User Documentation:
1) V2000 User’s Manual (ASL U-0623-0383)
2) ASL System Design Guide (ASL T-0667-0185)
3) Additional reference information is available from the ASL’s website: www.asl-control.co.uk

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 3 of 40
1 Introduction
This document describes how to install the V2000 Amplifier Mainframe and associated Interface Cards into a
pre-wired equipment rack.
The diagram below provides an overview of the installation sequence.
Summary of Task Section Step(s) Page
Safety and Precautions Read the safety and precautions instructions and guidelines. 2 All 4
Preparation Gather documentation, tools, equipment and rack. 3 All 7
Unpacking and Handling Unpack equipment. 4 All 8
Installation 1. Place the required equipment close to the rack. 5 1 9
2. Remove the front panel. 2 10
3. Remove the lid. 3 10
4. Check the DIP switch settings. 4 11
5. Set the Earth Lift Switch. 5 11
6. Remove the LSZDC Surveillance Blanking Plates. 6 11
7. Install V2000-STBY Interface Cards (if used). 7 12
8. Cover unused standby interface card slots with blanking plate. 8 13
9. Set standby links. 9 14
10. Cover unused surveillance interface card slots with blanking plate. 10 16
11. Install LSZDC Interface Cards. 11 17
12. Re-fit the lid. 12 18
13. Check rotary switch settings. 13 19
14. Isolate power supplies. 14 19
15. Install mainframe into the rack. 15 20
16. Switch the mainframe MAINS and POWER switched off. 16 20
17. Fit Amplifier Modules. 17 21
18. Connect field wiring to interface cards and control ports. 18 23
19. Connect auxiliary DC power supply cable. 19 23
20. Connect AC mains supply cable. 20 24
21. Connect battery supply cable. 21 24
22. Connect thermistor cable. 22 25
23. Commission V2000 mainframe. 23 25
No commissioning instructions are provided in this document.
Refer to V2000 User’s Manual (ASL U-0623-0383).
24. Fit the front panel. 24 25

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 4 of 40
2 Safety and Precautions
Observe all safety information both on the equipment and in this section.
Environmental
Always ensure adequate ventilation is provided for the equipment by following the rack design
rules and guidelines provided in the ASL System Design Guide.
The temperature and humidity ranges shown in the specifications for this equipment must not be
exceeded.
This equipment must not be installed in an area that is subject to a corrosive atmosphere,
excessive moisture or may allow water or other liquids to come into contact with the unit or its
external connections.
Objects containing liquids should not be placed upon the equipment.
Weight Safety
The V2000 mainframe with amplifier and interface cards fitted is heavy (max. 15 kg). Move and
handle with care to avoid strain or impact injuries. Install amplifier modules after mounting
mainframe into the equipment rack.
Do not use the handles to lift or carry the mainframe. The handles are designed for sliding the
unit into and out of the equipment rack, and not to support its weight.
Use the underside edges of the mainframe to lift and carry it.
The supporting rails must be capable of safely bearing the weight of the equipment (max. 15 kg).
ESD Precautions
The V2000 mainframe, interface cards and amplifier modules contain static-sensitive devices.
Observe ESD precautions when handling the mainframe with the lid removed, the interface cards
or amplifier modules.
Battery Handling
Work on the batteries should be carried out by qualified personnel only.
Always use insulated tools.
Batteries shall not be exposed to excessive heat such as sunshine, fire etc.
EMC
In the close proximity of some radio frequency transmitters, the signal to noise ratio of this equipment may be
reduced. If this occurs, re-location of the equipment or the signal cables is recommended.

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 5 of 40
Electrical Safety
The V2000 is designed for professional use only and must be installed in a restricted access
location such that there is no operator access to the V2000 equipment, wiring or battery.
Ensure power supply cabling is adequately rated for the unit’s operating current and
temperature, and is protected against short-circuit by a correctly rated fuse or circuit breaker.
This is particularly important for supply feeds from the 24 V backup batteries which can deliver
short-circuit currents exceeding 1000 amps.
Using too thin a cable can cause a safety hazard and will give excessive voltage drop and
operational failure.
Always ensure that the equipment is correctly earthed by connection to an AC mains supply with
a protective earthing connection.
Note that if the V2000 is connected as a system which is permanently connected to the mains,
then an all-pole mains isolator with a separation of 3 mm in each pole shall be incorporated in
the electrical installation.
The V2000 is protected from overload by single pole phase fusing. If connected to an
unpolarised mains the building installation must provide double pole phase/neutral fusing of
appropriate rating.
Always replace blown fuses with the correct type and rating.
This equipment contains wiring that is energised to 230 V AC mains and 100 V RMS audio
signals at up to 20 kHz.
Terminals marked with the symbol are hazardous, and the external wiring connected to these
terminals requires installation by instructed personnel.
External 24 V DC batteries connected to this unit can deliver very high currents that could cause
fire or burns.
Take care to avoid short-circuits of the battery supply by tools or jewellery.
Do not allow tools or unconnected cables to rest on top of batteries.
The V2000 may be energised after operation of a fuse or power off by the front panel MAINS
and BATTERY supply switches.
Always isolate the mains and battery supplies by switching off the rack mains and battery supply
isolation switches before installation, servicing or maintenance. In installations where the rack
mains and/or battery supply isolation switches are not accessible, unplug the power supply
cables from the V2000.
The V2000 may still be energised after isolating the mains and battery supplies.
After the mainframe ‘processor’ LED has stopped flashing leave the V2000 for another 5 minutes
before attempting internal servicing.
The D150 and D500 amplifier modules may be plugged or unplugged with power still connected.
To protect against electric shock and damages to the equipment:
•Always use the ejector lever and the slot guides (bottom and top of mainframe) to plug or
unplug an amplifier module.
•Do not touch the circuit board, any component or adjacent hardware.
•Do not allow the amplifier module to come in contact with any adjacent hardware.

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 6 of 40
The LSZDC Surveillance Card may be plugged or unplugged with power still connected if
necessary. Wherever possible, to avoid the risk of short-circuit with adjacent hardware,
disconnect the power supply to the V2000 backplane before plugging or unplugging the LSZDC
card.
Disconnect power supply to the V2000 backplane by switching off the MAINS and BATTERY
switches on the mainframe front panel behind the removable front panel.
Fire / Burn Safety
Batteries contained within the rack can deliver very high currents that could cause fire or burns.
Take care to avoid short-circuits of the battery terminals by tools or jewellery.
Do not allow tools or unconnected cables to rest on top of batteries.
Use caution when working with the V2000 mainframe. The mainframe case temperature can
exceed 70°C.
Ground Loops
It is possible to form a ground loop (earth loop or hum loop) when connecting pieces of audio equipment
using unbalanced connections that provide alternative earth connections via their cable screens.
Such ground loops result in audible ‘hum’ from the system.
Never disconnect the mains earth from the plug to attempt to cure a ground loop. In the event of
a fault, the equipment casing could become live.
Blanking Plate Disposal
Any blanking plates removed from the V2000 as part of the installation process ideally should be
recycled as metal or otherwise responsibly disposed of by following WEEE protocols.

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 7 of 40
3 Preparation
1.
Read and observe the safety instructions and guidelines in Section ‘2 Safety and Precautions’
(page 4).
Failure to follow these instructions and guidelines may cause personal injury and/or damage to
the
equipment.
2.
Gather the following documentation and tools:
•The system design documentation of the specific location
•A small flat-bladed screwdriver
•Pozidriv screwdrivers (No 1, 2 and 3)
•A pair of wire cutters/strippers
•19-inch rack-mount fixing screws as required by the system design
•Ferrules and crimping tool
•ESD wrist strap or other grounding device
•Antistatic mat or antistatic foam
3.
Gather the equipment (in their original packing):
•The V2000 Amplifier Mainframe
•D500 and/or D150 amplifier module(s) as required by the system design
•Interface cards as required by the system design: LSZDC V2000 Line Surveillance Interface
Card and V2000-STBY V2000 Standby Interface Card
•Surveillance blanking plates as required by the system design
•Thermistor cable assembly as required by the system design (if not part of the rack build)
4.
A standard 19-inch rack is required for the installation.
The rack should be fitted with battery backup system (if used), supporting rails for the V2000
mainframe, fan trays (if required), cooling ducts (if required), ventilation panels (if required) and wired
with power supply, signal, and control wiring to suit the requirements of the specific system design
and
should meet the rules and guidelines provided in the ASL System Design Guide
(ASL T-0667-0185).
Note that the installation of fan trays, cooling ducts, and/or ventilation panels depend on the system
design; refer to the ASL System Design Guide for further details.

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 8 of 40
4 Unpacking and Handling
1. Observe any markings or warnings on the package prior to handling and opening.
Do not use the handles to lift or carry the mainframe. The handles are designed for sliding the
unit into and out of the equipment rack, and not to support its weight.
Use the underside edges of the mainframe to lift and carry it.
2.
Check the equipment package for signs of damage during transport. Report problems to the carrier or
supplier.
3. Unpack the equipment in a dry area handling the equipment with care.
The V2000 mainframe, interface cards and amplifier modules contain static
-sensitive devices.
Observe ESD precautions when handling the mainframe with the lid removed, the interface
cards or amplifier modules.
4.
Check the equipment package contents for completeness. Report any missing items immediately.
V2000 package contents:
•1 x V2000 mainframe (fitted with handles)
•1 x V2000 front panel
•3 x Surveillance Blanking Plates (fitted)
•2 x Standby Blanking Plates (fitted)
•1 x mains cable (one end terminated IEC 60320 C19 female connector with and
one unterminated
end)
•1 x IEC 60320 C20 straight cable mount connector (16 A / 250 V AC)
•1 x 2-way Phoenix plug
•1 x V2000 Installation Guide
5.
It is advisable to retain the original equipment packing (containers and materials) in the event that the
equipment ever needs returning for service.
6.
If the packing is not to be retained, the packing materials should be either recycled or disposed of
according to local regulations.
7.
Ensure that the name and address of the Authorised Distributor from whom you purchased the
product
is recorded on the ‘Service and Warranty’ page of this document for future reference.
8. Repacking instructions are provided in Section ‘10 Packing for Return’ (page 36).

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 9 of 40
5 Installation
1. Place the mainframe, amplifier modules, interface cards and the required connectors and fixings on
the floor or on a sturdy table as close as possible to the rack.
The main components are shown in the illustration below. Note that types and quantities depend on
the system design of the specific location.
Do not use the handles to lift or carry the mainframe. The handles are designed for sliding
the unit into and out of the equipment rack, and not to support its weight.
Use the underside edges of the mainframe to lift and carry it.
Do not connect cables or other wiring to the V2000 until instructed.
Observe precautions for
handling electrostatic
sensitive devices.
V2000
V2000-STBY
D500 /D150 Amplifier Module
(Illustrations not to scale. Only main components shown, screws,
connectors and cable omitted for clarity.)
LSZDC
(Blanking plates fitted to
the rear panel.)
(Front panel shown fitted, but normally supplied loose.)
Surveillance Blanking Plate
(Handles supplied fitted.)
Thermistor Assembly Cable

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 10 of 40
2. If fitted, remove the V2000 front panel by undoing the 2 x captive screws on the right-hand side of
the front panel.
Note that the V2000 Build Standard (BS) is the last section of the product’s barcode which is located
on the mainframe front panel (behind the removable front panel); see example below. The Build
Standard should be quoted in all enquiries regarding the unit.
3. Remove the lid by undoing 12 x screws.
Captive M3
Pozidriv screw
(V2000 front panel removed)
V2000 front panel
Mains
Battery
Aux Supply
Processor
Comms
Fault
Mainfram
ID
x1
x10
The last section of the barcode indicates
the Build Standard (BS) of the unit.
Example: 1510 000036 002 BS = 002
Barcode label
The white insulating sheet must not be
damaged or tampered with in any way
for safety reasons.
Observe precautions for handling
electrostatic sensitive devices
when handling the mainframe with
the lid removed
.
M3 (4 mm) Pozi
countersunk
screw
Front
Mainframe Top View (lid fitted)
Mainframe Top View (lid removed)

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 11 of 40
4. Ensure all DIP switches on the mainframe
controller board are in the UP position.
The mainframe controller board is located
on the rear left-hand corner.
5. Set the rear-panel EARTH LIFT switch to
the DOWN ( , ON) ‘grounded’ position.
Set the EARTH LIFT switch to the
UP ( , OFF) position to remove the mains
earth from the signal circuit if a +ve ground
battery system is used, or it is necessary to
avoid a ground loop problem.
Never disconnect the mains earth
from the plug to attempt to cure a
ground loop. In the event of a fault,
the equipment casing could
become live.
6. Remove all Surveillance Blanking Plates from the rear panel by undoing 2 x screws.
All switches in
the UP position
Earth Lift switch down
(factory default)
M3 (6 mm)
Pozidriv
pan head
screw
Surveillance
Blanking Plate
SLOT 1

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 12 of 40
7. If used, fit one or two V2000-STBY Interface Cards to the rear panel standby interface card slots as
required by your system design.
If the mainframe is to be fitted with a single V2000-STBY Interface Card, the interface card
should be fitted into the right-hand side standby interface card slot as illustrated below.
a. Remove the Standby Blanking Plate by undoing 1 x screw at the bottom of the mainframe.
b. Insert the V2000-STBY Interface Card so that its rear connector mates the matching
connector on the backplane.
STANDBY BLANKING PLATE
STANDBY BLANKING PLATE
Remove the screw on the
bottom of the mainframe.
M3 (4 mm) Pozi
countersunk
screw
SLOT 1
SLOT 10
Single V2000-STBY Interface Card
should be fitted into the right-hand
side standby interface card slot.
Matching connector
on the backplane.
Observe precautions for
handling electrostatic
sensitive devices.

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 13 of 40
c. Ensure that the interface card is fully pushed, and secure the interface card in position using
1 x screw at the bottom of the mainframe.
Do not fit the top 3 x screws as they are used to secure the LSZDC Surveillance
Interface Card (or the Surveillance Blanking Plate).
d. If used, repeat the above procedure for the second V2000-STBY Interface Card.
8. Ensure that all unused standby interface card slots are covered with a Standby Blanking Plate.
Any blanking plates removed from the V2000 as part of the installation process ideally
should be recycled as metal or otherwise responsibly disposed of by following WEEE
protocols.
Fully push the interface card
and secure it using a screw at
the bottom of the mainframe.
M3 (4 mm) Pozi
countersunk
screw
Do not fit the top
3 x screws.
Second V2000-STBY
Interface Card slot
Fit a Standby Blanking Plate (ASL PN M0623_08)
to all unused standby interface card slots.
Secure the blanking plate using a screw at the
bottom of the mainframe.

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 14 of 40
9. Set the standby links on the rear side of the backplane according to the number of V2000-STBY
Interface Cards fitted to the mainframe.
Ensure the standby links are correctly set on the V2000 backplane. If incorrectly set,
amplifiers may get damaged when a standby amplifier changes over.
a. No V2000-STBY Interface Card fitted: factory default link settings
Standard 2-way shortening link,
2.54 mm pitch
ASL PN 200028
(1 x 2.54 mm link)
‘Handbag’ style
2-pin shortening link,
5.08 mm pitch
(Harwin PN D3086-99)
ASL PN 208949
(4 x ‘handbag’ style links)
LINKS FITTED
(Top rear panel bar and bottom middle blanking plate not shown for clarity.)
Observe precautions for
handling electrostatic
sensitive devices.
LINKS FITTED

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 15 of 40
b. 1 x V2000-STBY Interface Card fitted:
Standard 2-way shortening link,
2.54 mm pitch
ASL PN 200028
(1 x 2.54 mm link)
‘Handbag’ style
2-pin shortening link,
5.08 mm pitch
(Harwin PN D3086-99)
ASL PN 208949
(4 x ‘handbag’ style links)
LINKS FITTED
(Top rear panel bar and bottom middle blanking plate not shown for clarity.)
Observe precautions for
handling electrostatic
sensitive devices.
LINKS FITTED
LINKS NOT FITTED
Ensure these links are NOT FITTED.
If fitted, amplifiers may get damaged when
the standby amplifier switches over.

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 16 of 40
c. 2 x V2000-STBY Interface Cards fitted:
10. Cover all unused LSZDC Interface Card slots with a V2000 Surveillance Blanking Plate as specified
in your system design.
The example below shows a blanking plate covering slots 2, 4, 6, 8 and 10.
Any blanking plates removed from the V2000 as part of the installation process ideally
should be recycled as metal or otherwise responsibly disposed of by following WEEE
protocols.
LINKS NOT FITTED
(Top rear panel bar and bottom middle blanking plate not shown for clarity.)
Observe precautions for
handling electrostatic
sensitive devices.
LINKS NOT FITTED
Ensure that all standby links are NOT FITTED.
If fitted, amplifiers may get damaged when a
standby amplifier switches over.
SLOT 2
SLOT 10
SLOT 8
SLOT 6
SLOT 4
M3 (6 mm)
Pozidriv
pan head
screw
Surveillance
Blanking Plate
(ASL PN M0623_11)
Secure the blanking plate
using 2 x screws.
Only use zinc-plated
steel screws.

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 17 of 40
11. Fit the LSZDC Interface Cards to the rear panel surveillance interface card slots as required by your
system design.
The illustrations below show a LSZDC Interface Card being fitted into slot 1.
a. Insert the LSZDC Interface Card so that its rear connector mates the matching connector on
the backplane by seating the tab at the bottom of the interface card in the appropriate notch
on the midline rear support.
LSZDC (top view).
MIDLINE REAR SUPPORT
LSZDC
Seat the interface card tab
in the appropriate notch on
the midline rear support.
Observe precautions for
handling electrostatic
sensitive devices.

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 18 of 40
b. Ensure that the interface card is fully pushed, and then secure it using 2 x screws.
Ensure all securing screws are fully tightened to bond the interface card to the
amplifier mainframe chassis. It is important to make sure the screws are fully
tightened to prevent dangerous voltages being present on the panel.
c. Repeat the procedure for the remaining LSZDC Interface Cards.
12. Re-fit the lid using 12 x screws.
Ensure all tools and debris are removed from the mainframe case before re-fitting the lid.
SLOT 10
M3
(6 mm)
Pozidriv
pan head
screw
Secure the LSZDC using 2 x screws.
Fully tighten the screws
Only use zinc-plated
steel screws.
The white insulating sheet must not be
damaged or tampered with in any way
for safety reasons.
Mainframe Top View (lid removed)
M3 (4 mm) Pozi
countersunk
screw
Front
Mainframe Top View (lid fitted)

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 19 of 40
13. Ensure that the mainframe ID is set to ‘01’
(factory default).
14. Ensure that the mains and battery supplies
to the mainframe are isolated.
a. Isolate the AC mains supply to the
unit by switching off the rack mains
isolator.
In racks fitted with ASL MDIST-
V2000 (Mains Power Distribution
Assembly), switch off the appropriate
16 A switch on the MDIST-2000; see
example on the right.
b. Isolate the DC supply to the unit by
switching off the battery supply circuit
breaker (if used).
In racks fitted with ASL BDIST-V2000
(Battery Power Distribution
Assembly), switch off the circuit
breaker on the BDIST-V2000; see
example on the right.
Mains
Battery
Aux Supply
Processor
Comms
Fault
Mainfram
ID
x1
x10
0
1
Mainframe ID: for future use
Mains supply isolator: example using ASL MDIST-V2000
DC supply isolator: example using ASL BDIST-V2000

V2000 – Installation Guide
U-0623-0291.docx – Issue: 04 complete, approved
Page 20 of 40
15. Fit the mainframe into a 19-inch standard equipment rack on supporting rails, and secure the
mainframe in position using fixing screws and washers.
The V2000 mainframe with amplifier and interface cards fitted is heavy (max. 15 kg).
Move and handle with care to avoid strain or impact injuries.
Do not use the handles to lift or carry the mainframe. The handles are designed for sliding
the unit into and out of the equipment rack, and not to support its weight.
Use the underside edges of the mainframe to lift and carry it.
16. Ensure that the MAINS and BATTERY
switches on the mainframe front are
switched off.
The MAINS and BATTERY
switches do not isolate the power
supply to the unit.
Isolate the power to the unit by
using the rack mains and battery
power isolation switches; see step
14 above.
MAINS switch:
OFF
BATTERY switch:
OFF
Mains
Battery
Aux Supply
Processor
Comms
Fault
Mainfram
ID
x1
x10
The mainframe power switches
do not isolate the power supply
