aspenhome Queen Panel HB I34-412-SNA User manual

11-16-2017
Page1/4
ITEMNO:I34-412-SNAQueenPanel HB
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
I34-402-SNAQueenRails
I34-403-SNAQueenLowProfile FB
I34-403
I34-402
I34-412
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
COMPONENTS LIST:I34-403
No. Description Sketch Quantity
1Footboard 1PC
2Supportleg(forslats) 4PCS
COMPONENTS LIST:I34-412
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
COMPONENTS LIST:I34-402
No. Description Sketch Quantity
1Bedrails 2PC
2Slats 4PC
HARDWARELIST:I34-402
No. Description Sketch Quantity
IHangerBolt5/16"*3" 8PCS
JHalfMoonWasher5/16" 8PCS
KHexNut5/16" 8PCS
LHexWrench90*25*2mm 1PC
MWoodScrewM4*1-1/4" 8PCS
HARDWARELIST:I34-412
No. Description Sketch Quantity
ABolt 5/16"*2" 6PCS
BBolt5/16"*1-1/2" 4PCS
CBolt1/4"*1-1/4" 4PCS
DLockWasher 5/16"10PCS
EFlatWasher 5/16"*3/4" 10PCS
FLockWasher 1/4"4PCS
GFlatWasher 1/4"*3/4" 4PCS
HAllenWrench4mm 1PC

11-16-2017
Page2/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP4:Thesiderailsmaybeusedon eitherside.
Arrangethesiderailssotheslatbearersarein
LOWERPOSITIONprior toattachmentinSTEP5.
Slatbearerin
upperposition
Slatbearerin
lowerposition
ITEMNO:I34-412-SNAQueenPanel HB
I34-402-SNAQueenRails
I34-403-SNAQueenLowProfile FB
HBBackside
LeftLeg
Right Leg
HBBackside
WoodStretcher
Center SupportLeg
A
D
E
H
D
E
BH
C
F
G
HHBBackside
STEP1:Puttheheadboardfacedownon a
softsurface.Attachtheleftlegand right
legtoheadboardbyusing6bolts(A), lock
washers(D)and flat washers(E).
STEP2:Attachthewoodstretcher
tothelegsbyusing4bolts(B), lock
washers(D)and flat washers(E).
STEP3:Attachthecentersupport leg
toheadboardandwood stretcherby
using4bolts(C),lockwashers(F)and
flat washers(G).

11-16-2017
Page3/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
Makesuretheslatbeareris
intheLOWERposition.
STEP6:Attachthesupportlegswithlevelertotheslats.
Adjustthelevelersonbottom ofsupportlegswhennecessary.
SupportLeg
Leveler
ThisEndUp
Slat
STEP7:Arrangetheslatsontheslat bearer
equallyandattachtotheslat bearerwith
wood screws (M).
STEP5:Screwthebolts(I)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderails
andattachthesiderailstoHB&FBusinghalfmoonwashers(J)and nuts(K).Thenuseahex
wrench(L)totightenall thenuts.
Headboard
Slatbearer
SideRail
SideRail
SideRail
I
JKL
ITEMNO:I34-412-SNAQueenPanel HB
I34-402-SNAQueenRails
I34-403-SNAQueenLowProfile FB
M

11-16-2017
Page4/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
FUNCTIONALITY INSTRUCTION
1PoweredUSBPortfor
Charging on bothsides
ITEMNO:I34-412-SNAQueenPanel HB
I34-402-SNAQueenRails
I34-403-SNAQueenLowProfile FB
I34-403
I34-402
I34-412

11-16-2017
Page1/5
ITEMNO:I34-412-SNAQueenPanel HB
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
I34-402-SNAQueenRails
I34-403D-SNAQueenStorageFB
I34-403D
I34-412
COMPONENTS LIST:I34-412
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
COMPONENTS LIST:I34-402
No. Description Sketch Quantity
1Bedrails 2PC
2Slats 4PC
COMPONENTS LIST:I34-403D
No. Description Sketch Quantity
1Footboard 1PC
2SupportLeg(forcenterrail) 2PCS
3Decking 4PCS
4Center rail 1PCS
I34-402
HARDWARELIST:I34-402
No. Description Sketch Quantity
IHangerBolt5/16"*3" 8PCS
JHalfMoonWasher5/16" 8PCS
KHexNut5/16" 8PCS
LHexWrench90*25*2mm 1PC
MWoodScrewM4*1-1/4" 8PCS
HARDWARELIST:I34-403D
No. Description Sketch Quantity
NBolt1/4"*1-1/4" 8PCS
OLockWasher5/16" 8PCS
PFlatwasher 5/16x3/4" 8PCS
QAllenWrench4mm 1PC
RWoodScrewM4*1 8PCS
HARDWARELIST:I34-412
No. Description Sketch Quantity
ABolt 5/16"*2" 6PCS
BBolt5/16"*1-1/2" 4PCS
CBolt1/4"*1-1/4" 4PCS
DLockWasher 5/16"10PCS
EFlatWasher 5/16"*3/4" 10PCS
FLockWasher 1/4"4PCS
GFlatWasher 1/4"*3/4" 4PCS
HAllenWrench4mm 1PC

11-16-2017
Page2/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP1:Puttheheadboardfacedownon a
softsurface.Attachtheleftlegand right
legtoheadboardbyusing6bolts(A), lock
washers(D)and flat washers(E). HBBackside
STEP2:Attachthewoodstretcher
tothelegsbyusing4bolts(B), lock
washers(D)and flat washers(E).
LeftLeg
Right Leg
HBBackside
WoodStretcher
STEP3:Attachthecentersupport leg
toheadboardandwood stretcherby
using4bolts(C),lockwashers(F)and
flat washers(G).
Center SupportLeg
Slatbearerin
upperposition
Slatbearerin
lowerposition
STEP4:Thesiderailsmaybeusedon eitherside.
Arrangethesiderailssotheslatbearersarein
UPPERPOSITIONpriortoattachmentinSTEP5.
A
D
E
H
D
E
BH
C
F
G
HHBBackside
ITEMNO:I34-412-SNAQueenPanel HB
I34-402-SNAQueenRails
I34-403D-SNAQueenStorageFB

11-16-2017
Page3/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP5:Screwthebolts(I)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderails
andattachthesiderailstoHB&FBusinghalfmoonwashers(J)and nuts(K).Thenuseahex
wrench(L)totightenall thenuts.
STEP6:Attachcenterrailtothefootboard andcentersupportlegofheadboardusing 4bolts(N),
lockwashers(O)andflatwashers(P).
Makesuretheslatbeareris
intheUPPERposition.
Headboard
Slatbearer
SideRail
SideRail
SideRail
I
JKL
NOP
Q
ITEMNO:I34-412-SNAQueenPanel HB
I34-402-SNAQueenRails
I34-403D-SNAQueenStorageFB
Centerrail
Centerrail

11-16-2017
Page4/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP7:Attach2supportlegs(for centerrail)tothecenter
railusing4bolts(L),lockwashers(M)andflatwashers(N).
UsetheAllenWrench(O)totightenall ofthebolts.
CenterRail
SupportLeg
(forcenterrail)
Leveler
LMN
O
M
ITEMNO:I34-412-SNAQueenPanel HB
I34-402-SNAQueenRails
I34-403D-SNAQueenStorageFB
STEP8:Arrangeslatsontheslatbearers
and thenlaydeckingontop oftheslats.
Makesuretheslatsarepositionedalongthe
seamsofthedeckingasshowninthedetail
inSTEP10underthepre-drilledhole.
Removethedeckingandattachslatstothe
slatbearerswithwoodscrews(M).
STEP9:Putthedeckingovertheslats,securedeckingtotheslatswithwood screws (P)through the
pre-drilledholesinthedeckingasshownbelow.
Slat
Decking
Decking
Theslat shouldsupport
bothpiecesofdecking.
Decking
Pre-drilledhole
Makesurethatthereisaslat
underthepre-drilledhole.
P

FUNCTIONALITY INSTRUCTION
11-16-2017
Page5/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
1PoweredUSBPortfor
Charging on bothsides
I34-412
I34-402
I34-403D
ITEMNO:I34-412-SNAQueenPanel HB
I34-402-SNAQueenRails
I34-403D-SNAQueenStorageFB
Cedar-linedStorageDrawers

11-16-2017
Page1/4
ITEMNO:I34-415-SNAKingPanel HB
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
I34-406-SNAKingRails
I34-410-SNACalKing Rails
I34-407-SNAKingLowProfile FB
I34-407
I34-410
I34-406
I34-415
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
UTILITYKNIFE(FORCALKING)
COMPONENTS LIST:I34-415
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
COMPONENTS LIST:I34-406
No. Description Sketch Quantity
1Bedrails 2PC
2Slats 5PC
COMPONENTS LIST:I34-410
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 5PCS
3Centerrail(Long) 1PC
COMPONENTS LIST:I34-407
No. Description Sketch Quantity
1Footboard 1PC
2Supportleg(forslats) 5PCS
HARDWARELIST:I34-406/410
No. Description Sketch Quantity
IHangerBolt5/16"*3" 8PCS
JHalfMoonWasher5/16" 8PCS
KHexNut5/16" 8PCS
LHexWrench90*25*2mm 1PC
MWoodScrewM4*1-1/4" 10PCS
NWoodCap(Onlyfor410) 8PCS
HARDWARELIST:I34-415
No. Description Sketch Quantity
ABolt 5/16"*2" 6PCS
BBolt5/16"*1-1/2" 4PCS
CBolt1/4"*1-1/4" 4PCS
DLockWasher 5/16"10PCS
EFlatWasher 5/16"*3/4" 10PCS
FLockWasher 1/4" 4 PCS
GFlatWasher 1/4"*3/4" 4PCS
HAllenWrench4mm 1PC

11-16-2017
Page2/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP4:Thesiderailsmaybeusedon eitherside.
Arrangethesiderailssotheslatbearersarein
LOWERPOSITIONprior toattachmentinSTEP5.
ITEMNO:I34-415-SNAKingPanel HB
I34-406-SNAKingRails
I34-410-SNACalKing Rails
I34-407-SNAKingLowProfile FB
HBBackside
LeftLeg
Right Leg
HBBackside
WoodStretcher
Center SupportLeg
A
D
E
H
D
E
BH
C
F
G
HHBBackside
Slatbearerin
upperposition
Slatbearerin
lowerposition
STEP1:Puttheheadboardfacedownon a
softsurface.Attachtheleftlegand right
legtoheadboardbyusing6bolts(A), lock
washers(D)and flat washers(E).
STEP2:Attachthewoodstretcher
tothelegsbyusing4bolts(B), lock
washers(D)and flat washers(E).
STEP3:Attachthecentersupport leg
toheadboardandwood stretcherby
using4bolts(C),lockwashers(F)and
flat washers(G).

11-16-2017
Page3/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
Makesuretheslatbeareris
intheLOWERposition.
STEP6:Attachthesupportlegswithlevelertotheslats.
Adjustthelevelersonbottom ofsupportlegswhennecessary.
SupportLeg
Leveler
ThisEndUp
Slat
STEP7:Arrangetheslatsontheslat bearer
equallyandattachtotheslat bearerwith
wood screws (M).
STEP8:ForCalKingbed,insertwoodcaps(N)intotheholeson
headboardandfootboard.For regularKingbed,skipthisstep. Wood Cap
ITEMNO:I34-415-SNAKingPanel HB
I34-406-SNAKingRails
I34-410-SNACalKing Rails
I34-407-SNAKingLowProfile FB
STEP5:Screwthebolts(I)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderails
andattachthesiderailstoHB&FBusinghalfmoonwashers(J)and nuts(K).Thenuseahex
wrench(L)totightenall thenuts.
Headboard
Slatbearer
SideRail
SideRail
SideRail
I
JKL
M
Theoutsideholesmatchto6/6bedrails(-406 rails),
theinsideholesmatchto6/0bedrails(-410 rails).

11-16-2017
Page4/4
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
FUNCTIONALITY INSTRUCTION
ITEMNO:I34-415-SNAKingPanel HB
I34-406-SNAKingRails
I34-410-SNACalKing Rails
I34-407-SNAKingLowProfile FB
1PoweredUSBPortfor
Charging on bothsides
I34-410
I34-406
1PoweredUSBPortfor
Charging on bothsides
I34-407
I34-415
I34-407
I34-415

11-16-2017
Page1/5
ITEMNO:I34-415-SNAKingPanel HB
Thankyou for purchasing thisqualityproduct.Besuretocheckallpacking material carefullyfor
small partsthatmaycomelooseinsidethecartonduringshipment.
UNITSHOULDBEINSTALLEDBY2ORMOREPERSONS.
BEFOREUSINGTHISPRODUCTPLEASEREAD,UNDERSTAND,ANDFOLLOWTHESEINSTRUCTIONS.
Savetheseinstructionsforfuturereference.
All Bedsneedtobeset upintheexact final
locationsothatafterfullassemblyit will not
needtobemoved. Moving thebedwill cause
thesupport legstomoveoutof perpendicular
(90 degree),weakenthesupportsystem, and
mayallowthebedtocollapse.
FORINDOORUSEONLY
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
I34-406-SNAKingRails
I34-410-SNACalKing Rails
I34-407D-SNAKingStorageFB
I34-407D
I34-415
COMPONENTS LIST:I34-415
No. Description Sketch Quantity
1Headboard 1PC
2LeftLeg 1PC
3RightLeg 1PC
4WoodStretcher 1PC
5CenterSupportLeg 1PC
TOOLSREQUIRED(NOTPROVIDED)
PHILLIPS SCREWDRIVER
UTILITYKNIFE(FORCALKING)
HARDWARELIST:I34-406/410
No. Description Sketch Quantity
IHangerBolt5/16"*3" 8PCS
JHalfMoonWasher5/16" 8PCS
KHexNut5/16" 8PCS
LHexWrench90*25*2mm 1PC
MWoodScrewM4*1-1/4" 10PCS
NWoodCap(Onlyfor410) 8PCS
HARDWARELIST:I34-407D
No. Description Sketch Quantity
OBolt1/4"*1-1/4" 8PCS
PLockWasher5/16" 8PCS
QFlatwasher 5/16x3/4" 8PCS
RAllenWrench4mm 1PC
SWoodScrewM4*1 6PCS
COMPONENTS LIST:I34-406
No. Description Sketch Quantity
1Bedrails 2PC
2Slats 5PC
COMPONENTS LIST:I34-410
No. Description Sketch Quantity
1Bedrails 2PCS
2Slats 5PCS
3Centerrail(Long) 1PC
COMPONENTS LIST:I34-407D
No. Description Sketch Quantity
1Footboard 1PC
2SupportLeg(forcenterrail) 2PCS
3Decking 3PCS
4Centerrail(Short) 1PCS
5Filler 2PCS
I34-406
I34-410
HARDWARELIST:I34-415
No. Description Sketch Quantity
ABolt 5/16"*2" 6PCS
BBolt5/16"*1-1/2" 4PCS
CBolt1/4"*1-1/4" 4PCS
DLockWasher 5/16" 10PCS
EFlatWasher 5/16"*3/4" 10PCS
FLockWasher 1/4"4PCS
GFlatWasher 1/4"*3/4" 4PCS
HAllenWrench4mm 1PC

11-16-2017
Page2/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP1:Puttheheadboardfacedownon a
softsurface.Attachtheleftlegand right
legtoheadboardbyusing6bolts(A), lock
washers(D)and flat washers(E). HBBackside
STEP2:Attachthewoodstretcher
tothelegsbyusing4bolts(B), lock
washers(D)and flat washers(E).
LeftLeg
Right Leg
HBBackside
WoodStretcher
STEP3:Attachthecentersupport leg
toheadboardandwood stretcherby
using4bolts(C),lockwashers(F)and
flat washers(G).
Center SupportLeg
Slatbearerin
upperposition
Slatbearerin
lowerposition
STEP4:Thesiderailsmaybeusedon eitherside.
Arrangethesiderailssotheslatbearersarein
UPPERPOSITIONpriortoattachmentinSTEP5.
ITEMNO:I34-415-SNAKingPanel HB
I34-406-SNAKingRails
I34-410-SNACalKing Rails
I34-407D-SNAKingStorageFB
A
D
E
H
D
E
BH
C
F
G
HHBBackside

11-16-2017
Page3/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP5:Screwthebolts(I)intoHB&FB.Aligntheboltswiththeholesintheend ofsiderails
andattachthesiderailstoHB&FBusinghalfmoonwashers(J)and nuts(K).Thenuseahex
wrench(L)totightenall thenuts.
STEP6:Attachcenterrailtothefootboard andcentersupportlegofheadboardusing 4bolts(O),
lockwashers(P)andflatwashers(Q).
Theshortcenterrailthat is
packedinstorageFBworks
with-406Kingrails(6/6); The
Longcenterrailthat ispacked
inCalKingsiderailsworks
with-410CalKingrails(6/0).
Makesuretheslatbeareris
intheUPPERposition.
Headboard
Slatbearer
Theoutsideholesmatchto6/6bedrails(-406 rails),
theinsideholesmatchto6/0bedrails(-410 rails).
SideRail
SideRail
SideRail
ITEMNO:I34-415-SNAKingPanel HB
I34-406-SNAKingRails
I34-410-SNACalKing Rails
I34-407D-SNAKingStorageFB
I
JKL
OPQ
R
Centerrail

11-16-2017
Page4/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
STEP7:Attach2supportlegs(for centerrail)tothecenter
railusing4bolts(O),lockwashers(P)andflatwashers(Q).
UsetheAllenWrench(R)totightenall ofthebolts.
CenterRail
SupportLeg
(forcenterrail)
Leveler
STEP8:Arrangeslatsontheslatbearers
and thenlaythedecking on topof theslats.
Makesurethetopand bottomslatsare
situatedunderneaththepre-drilledholesas
shownbelow inSTEP10. Removethe
deckingandattachslatstotheslat bearers
withwoodscrews(M).
Filler Notch
STEP9:ForCalKingbed,useautilityknifetocut off thesmall
pieceat thenotchanddiscard.ForregularKing bed, skipthisstep.
STEP10:Putthedeckingovertheslats,securedeckingtotheslatswithwood screws (S)through
thepre-drilledholesinthedecking asshownbelow.
Decking
Filler
STEP11:ForCalKing bed, insertwoodcaps(N)intotheholeson
headboardandfootboard.For regularKingbed,skipthisstep. WoodCap(N)
ITEMNO:I34-415-SNAKingPanel HB
I34-406-SNAKingRails
I34-410-SNACalKing Rails
I34-407D-SNAKingStorageFB OPQ
R
M
Filler
Decking Decking
Makesurethatthereisaslat
underthepre-drilledhole.
S
Decking
Pre-drilledhole Decking Decking Decking
Filler
Filler

FUNCTIONALITY INSTRUCTION
11-16-2017
Page5/5
aspenhomeRASSEMBLYINSTRUCTIONS
MADEIN VIETNAM
ITEMNO:I34-415-SNAKingPanel HB
I34-406-SNAKingRails
I34-410-SNACalKing Rails
I34-407D-SNAKingStorageFB
1PoweredUSBPortfor
Charging on bothsides
I34-407D
I34-415
I34-406
I34-410
I34-407D
I34-415
Cedar-linedStorageDrawers
1PoweredUSBPortfor
Charging on bothsides
Cedar-linedStorageDrawers
