OWNER’S MANUAL
Safety, Assembly, Operating, and Maintenance
Instructions
Models
LSH-High Output and LSC- Classic series
WALK-BEHIND BLOWERS
Debris Blowers for the professional
Please Read all safety and
operating instructions before
using machine.
1-866-399-5562
www.asphaltkingdom.com
Blow the Competition Away...
TM

Table of Contents
1) Applications and uses_______________________________________________________________1
2) Service information ________________________________________________________________2
3) Safety Information ________________________________________________________________2,3,4
4) Warnings (Do Not) __________________________________________________________________4
5) Warnings (Do) ______________________________________________________________________ 4
6) Engine and Fuel Warnings __________________________________________________________4
7) Blower Assembly ___________________________________________________________________ 5
8) Operating Instructions ______________________________________________________________6
9) Maintenance _________________________________________________________________________6
10) Exploded View _____________________________________________________________________7,8
11) Parts List _________________________________________________________________________9,10
1) Applications and uses:
The versatility of the LandShark Blower makes it ideal for a wide range of uses.
Blowing leaves, Drying Tennis courts, Blowing grass clippings, Cleaning parking lots,
cleaning driveways, preparing roof surfaces before repairs are made, blowing thatch
from golf course greens and tees.
This manual provides information for safe and efficient operation and service. It is
important that you read and understand this manual before operating your blower.
Warning: The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
page
Page 1

WARNING DANGER
TO REDUCE THE POTENTIAL FOR ACCIDENTS, ALWAYS COMPLY WITH
THE SAFETY INSTRUCTIONS IN THIS MANUAL. FAILURE TO DO SO
MAY RESULT IN PERSONAL INJURY AND / OR EQUIPMENT AND
PROPERTY DAMAGE.
2) Service information
Engine: Refer to the enclosed Engine Manual provided by the engine manufacturer or
an authorized repair facility for replacement parts and engine warranty.
Blower Components: Contact your local LandShark dealer.
3) Safety Information
WARNING DANGER
This symbol indicates important safety instructions
When you see this symbol, pay special attention to its
warning!!
Stay Alert!!
WARNING DANGER
IMPROPER USE OR CARE OF THE BLOWER, FAILURE TO WEAR PROPER
SAFETY PROTECTION CAN RESULT IN SERIOUS INJURY.
READ AND UNDERSTAND THE RULES FOR SAFE OPERATION AND ALL
INSTRUCTIONS IN THIS MANUAL.
WEAR HEARING AND EYE PROTECTION AT ALL TIMES WHEN
OPERATING THIS BLOWER
Page 2

Safety Decals
An important part of
the safety
information for this
blower are the safety
decals found on
various parts of the
blower. These
decals must always
remain visible and in
good condition. It is
your responsibility to
replace the decals if
they become worn,
damaged or hard to
read. A sample of the
decal is shown.
General safety Rules
A) Read and understand the operators manual. Pay specific attention to all areas
pertaining to safety. Keep your operators manual in a secure place.
B) WARNING --- KEEP CHILDREN, PETS, and BYSTANDERS AWAY ---Do not permit
children to touch blower. Keep children a safe distance away from work area. Never
allow a person under the influence of alcohol or drugs to operate the blower.
C) DO NOT OVERREACH OR STAND ON UNSTABLE SURFACES when operating the
blower. Keep good footing at all times.
D) WHEN OPERATING MULTIPLE MACHINES ---Keep a safe distance between
operators when working simultaneously.
WARNING DANGER
Misuse of blower or failure to follow all safety precautions may result in serious
injury to the operator or others.
read and understand the following before attempting to operate this blower!!!
Caution:
Thrown Objects.
Keep Bystanders
away
Always wear Eye
and Ear
protection
IMPORTANT
Before performing any
service or maintenance,
disconnect the spark
plug wire and make sure
the throttle and kill
switch is in the off
position.
Read and understand the
owners manual. Pay
particular attention to
ALL sections regarding
safety. Keep your
owners manual in a
secure place for future
reference.
Keep hands and
feet away from
discharge areas.
Rotating fan will
cause serious
injury.
P/N 1100-074
Warning Label
Page 3

4) WARNINGS --- DO NOT DO!
A) DANGER ROTATING FAN --- KEEP HANDS AWAY. DO NOT attempt to
clear debris of any sort from the intake area or discharge area of the
blower while the engine is running.
B) DO NOT POINT THE BLOWER DISCHARGE OUTLET in the direction of
people, cars, glass, or other items which could be injured or damaged by
flying debris.
C) DO NOT ATTEMPT TO REPAIR BLOWER --- repairs should be made by
an authorized LandShark dealer. Make sure that only LandShark and
recommended engine manufacturer’s parts are used.
5) WARNINGS --- DO!
A) BE SURE BLOWER IS PROPERLY ASSEMBLED --- Never operate the
blower without all guards and deflectors in place. Make sure all
hardware is properly tightened and secure.
B) KEEP HANDS AWAY FROM AIR INTAKE AND AIR OUTLET CHUTE ---
Keep both hands on handle at all times when operating the blower.
C) ALWAYS KEEP THE THROTTLE (if equipped) IN THE “STOP” POSITION
WHEN NOT IN USE.
D) DRESS PROPERLY --- Do not wear loose clothing or jewelry. These
items can be pulled into moving parts. Safety glasses and ear protection
are recommended.
E) MAINTENANCE IS IMPORTANT --- Follow the routine maintenance
instructions provided in this manual and your engine manual..
6) ENGINE / FUEL WARNINGS
WARNING DANGER
HANDLE FUEL WITH CARE, IT IS HIGHLY FLAMMABLE. FUELING A HOT
ENGINE OR NEAR AN IGNITION SOURCE CAN CAUSE FIRE AND RESULT
IN SERIOUS PERSONAL INJURY AND / OR PROPERTY DAMAGE.
A) Do not smoke when handling fuel.
B) Do not refuel an engine that is hot or running.
C) Do not refuel indoors.
D) Do not start or run indoors as poisonous carbon monoxide is emitted.
E) Do not operate in un-ventilated area.
F) Avoid spilling fuel or oil.
Page 4

WARNING - All debris blowers are shipped without oil. When filling with oil,
refer to the engine manufacturers operating instructions for proper type and
amount.
7) Blower Assembly Instructions
Note: Numbers in brackets refer to exploded view and parts list.
1) Attach front wheel bracket assembly (36) secure with 5/16x3/4 (6) and flat washers
(14). Insert axle sleeve (31) into Pneumatic / Flat Free wheel hub, place wheel
between brackets and secure with 3/8 x5” cap screw(17) and flange nut(25).
2) Attach lower handle tubes (3) to anti-vibration mounts (2) secure with 3/8 x 1 3/4
hex bolt (23) and flat washers (24).
3) Place lower handle brace plate (16) on lower handle assembly and attach handle
(3) using 5/18-18 X 1 3/4” bolt (15), 5/16” washers (14) and 5/16” nylon lock nuts (33).
Note: Handle height and orientation should be observed at this time.
4) Place front discharge baffle (26) into opening in blower housing so hinged bracket
is inside square opening. Secure with two ¼ x 3/4” hex bolts (21), two 1/4-20 flange
nuts (28) and two 1/4” flat washers. Make sure baffle opens and closes freely.
5) Secure spring (27) through top hole in front discharge baffle.
6) Place discharge flap (29) on blower output and secure with two 5/16 x 3/4” thumb
screws (37).
7) Tighten all fasteners securely.
Fan Removal
(This procedure should only be performed at a qualified dealer)
1. Remove intake guard and ring.
2. Remove 3 bolts securing fan to tapered bushing. Place a 1 1/8” socket or spacer
over crank shaft and tap with hammer to drive bushing back toward engine. (8 Hp
and above only) This will release fan and allow easy removal. Note: On 6Hp models,
the socket or spacer will vary in size according to the crankshaft.
3) When re-installing, replacement of the taper bushing is recommended. Be sure to
follow All tightening and torque specifications.
Page 5
TM

front discharge position is used to
8) Operating Instructions
remove debris from along walls, fences,
Refer to Engine Manual for Engine
etc., the side discharge position is used
Operation.
to form windrows or piles. The
horizontal deflector directs air downward
Follow directions in the engine manual
to “chisel” under wet, heavy leaves and
for operating oil type and quantity.
litter. The velocity is regulated by the
throttle control. Slight changes in
Leaves, thatch or other debris can be
deflector will have a big effect on air
directed into windrows or piles, by
flow. Experiment until you find the best
simply maneuvering the unit and
position for your needs. For best
directing the flow of air accordingly.
performance, be sure engine recoil
starter assembly, the blower intake and
Air flow can be directed to the side or
outlet areas are clear and free of leaves
front by the two-position deflector. The
or other debris.
fuel recommendations and additional
9) Maintenance Instructions
information.)
1. keep all nuts, bolts and screws tight.
5. Tires - Tubeless. Inflate to air
2. Never store the Blower with fuel in its
pressure of 30 P.S.I.
fuel tank inside a building or in a
6. Labels should be inspected before
confined space where fumes may reach
each use. Replace damaged labels
an open flame or sparks.
immediately.
3. Always refer to the instruction
7. To prevent accidental starting,
manual for important details if the
remove spark plug wire when servicing
product is to be stored for an extended
engine or equipment.
period.
8. Check oil level regularly.
4. Engine - 4 cycle. (Refer to engine
manufacturer’s operating instructions for
Warning: The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
1-866-399-5562
www.asphaltkingdom.com
Specifications, illustrations and descriptions are as accurate as
known at the time of publication and are subject to change Page 6
TM

Page 7

Page 8
ITEM QTY PART NUMBER DESCRIPTION
21 2 1100-020 1/4-20 X 3/4" HHCS
22 2 1100-073 1/4" USS FLAT WASHER
26 1 1100-022 FRONT DISCHARGE ASSEMBLY
27 1 1100-021 LOOP END EXTENSION SPRING
28 2 1100-019 1/4-20 FLANGE NUT
35 1 1100-014 12-24 x 3/4" DRILL AND TAP SCREW
38 2 11900 1/4" SAE WASHER
Parts List - Complete LSH Blower - Discharge Detail

Page 9
ITEM QTY PART NUMBER DESCRIPTION
1 1 1100-062 17" HOUSING ASSEMBLY
2 4 1100-044 RUBBER VIBRATION MOUNT
3 2 1100-061 SQUARE TUBE HANDLES
4 1 1100-007 17" IMPELLER
5 2 1100-045 MOTOR MOUNT
6 16 1100-075 5/16-18 x 3/4" HHCS
7 1 1100-051 AXLE
8 2 1100-049 REAR TIRE ASSEMBLY
9 2 1100-050 .625" EXTERNAL RETAINING RING
10 1 1100-006 TAPER LOCK BUSHING
11 3 1100-006-SH1 1/4-20 x 1 3/8" HHCS
12 1 1100-012 1/4" KEY STOCK
13 1 1100-038 HANDLE WELDMENT
14 12 1100-031 5/16 USS FLAT WASHER
15 4 1100-072 5/16-18 x 1 3/4" HHCS
16 1 1100-033 HANDLE BRACE
17 1 1100-026 3/8-16 x 5" HHCS
18 1 1100-04A INTAKE GUARD
19 6 1100-003 STAND OFF
20 1 1100-04B INTAKE RING
21 2 1100-020 1/4-20 x 3/4" HHCS
22 12 1100-073 1/4" USS FLAT WASHER
23 4 1100-083 3/8-16 x 1 3/4" HHCS
24 4 1100-043 5/16 USS FLAT WASHER
25 5 1100-047 3/8-16 FLANGE NUT
26 1 1100-022 FRONT DISCHARGE ASSEMBLY
27 1 1100-021 LOOP END EXTENSION SPRING
28 2 1100-019 1/4-20 FLANGE NUT
29 1 1100-018 DISCHARGE FLAP
30 1 1100-058 ENGINE HOUSING SPACER
31 1 1100-056 SPANNER BUSHING
32 4 11815 5/16-18 x 1" HHCS
33 8 11905 5/16-18 NYLON LOCK NUT
34 2 1100-037 FOAM HANDLE GRIP COVER
35 1 1100-014 12-24 x 3/4" DRILL AND TAP SCREW
36 1 1100-027 FRONT WHEEL BRACKET
37 2 1100-016 5/16-18 x 3/4" THUMB SCREW
38 2 11900 1/4" SAE WASHER
39 1 1100-078 IMPELLER RING
40 1 1100-085 FRONT TIRE ASSEMBLY
41** 4 11916 5/16-24 x 1" HHCS
42 4 11904 5/16 SPLIT LOCK WASHER
43 6 11493 5/8" UNGROUND FLANGED BEARING
44 2 1100-090 HANDLE BAR PLUGS
45** 4 1100-057 ENGINE SPACER
46 1 1100-074 WARNING LABEL
47 1 1100-087 LABEL RECTANGULAR
48 3 1100-006-SH2 1/4" LOCK WASHER
49 1 1100-086 LABEL ROUND
Parts List - Complete LSH- Blower

Page 10
Note: All other parts are common with the LSH Series Blowers
ITEM QTY PART NUMBER DESCRIPTION
1B 1 1100-063 14" BLOWER HOUSING
2B 1 1100-007S 14" IMPELLER
***3B 1 1100-006S JA x * BUSHING
**4B 1 1100-012S 3/16" or 1/4" KEY STOCK
5B 3 1100-005-JA1 SHCS #10-24 x 1 1/4 BOLT
6B 3 1100-006SH2 #10 SPLIT LOCK WASHER
7B 1 1100-04BS INTAKE RING
8B 4 1100-003 STAND OFF
9B 1 1100-04AS INTAKE GUARD
10B 8 1100-075 5/16-18 x 3/4" HHCS
11B 4 1100-031 1/4" USS WASHER
*** NOTE: Designate Crankshaft Size / Engine Model
Parts List - Complete LSC- BLOWER
**NOTE: 11916 , 1100-057 and 1100-012 are Model Specific
*NOTE: 1100-058 not on all models
TM
