ASROCK FP6D4-P1 User manual

Version 1.0
Published September 2020
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”

AUSTRALIA ONLY
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage caused by our goods. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
e terms HDMI® and HDMI High-Denition Multimedia Interface, and the
HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.

Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Motherboard Layout 5
1.4 Front Panel 7
1.5 Rear Panel 8
Chapter 2 Installation 9
2.1 Installing Memory Modules (SO-DIMM) 10
2.2 Onboard Headers and Connectors 11
2.3 Smart Switch 12
2.4 M.2 WiFi/BT Module Installation Guide 13
2.5 M.2_SSD (NGFF) Module Installation Guide (M2_1) 15
Chapter 3 Software and Utilities Operation 17
3.1 Installing Drivers 17
Chapter 4 UEFI SETUP UTILITY 18
4.1 Introduction 18
4.1.1 UEFI Menu Bar 18
4.1.2 Navigation Keys 19
4.2 Main Screen 20
4.3 OC Tweaker Screen 21
4.4 Advanced Screen 23

4.4.1 CPU Conguration 24
4.4.2 Onboard Devices Conguration 25
4.4.3 Storage Conguration 27
4.4.4 ACPI Conguration 28
4.4.5 Trusted Computing 29
4.5 Tools 30
4.6 Hardware Health Event Monitoring Screen 31
4.7 Security Screen 32
4.8 Boot Screen 33
4.9 Exit Screen 35

PB 1
English
FP6D4-P1
Because the motherboard specications and the BIOS soware might be updated, the
content of this documentation will be subject to change without notice.
Chapter 1 Introduction
ank you for purchasing FP6D4-P1 motherboard. In this documentation, Chapter
1 and 2 contains the introduction of the motherboard and step-by-step installation
guides. Chapter 3 contains the operation guide of the soware and utilities. Chapter
4 contains the conguration guide of the BIOS setup.
1.1 Package Contents
• FP6D4-P1 Motherboard
• FP6D4-P1 Quick Installation Guide
• FP6D4-P1 Support CD
• 1 x Screw for M.2 Socket (M2*2) (Optional)
• 1 x Screw for WiFi Module (M2*2) (Optional)
Because the motherboard specications and the BIOS soware might be updated, the
content of this documentation will be subject to change without notice.

2 3
English
1.2 Specications
Platform • 7.0-in x 5.7-in, 17.8 cm x 14.5 cm
CPU • Supports AMD FP6 Renoir
• 3 Power Phase design
Chipset • SOC
Memory • Dual Channel DDR4 Memory Technology
• 2 x DDR4 SO-DIMM Slots
• Supports DDR4 3200/2933/2800/2666/2400/2133 non-ECC,
un-buered memory
• Max. capacity of system memory: 64GB
Expansion
Slot
• 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
Graphics • Integrated AMD RadeonTM Vega Series Graphics in Ryzen
Series APU*
* Actual support may vary by CPU
• DirectX 12, Pixel Shader 5.0
• Shared memory default 2GB.
• Dual graphics output: support D-Sub and HDMI ports by
independent display controllers
• Supports HDMI with max. resolution up to 4K@ 60Hz
• Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant
HDMI monitor is required)
• Supports HDCP 2.3 with HDMI 1.4 Port

2 3
English
FP6D4-P1
Audio • Realtek ALC233 Audio Codec
• 1 x Headphone/Headset Jack
• 1 x MIC-In
LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s
• Realtek RTL8111H
• Supports Wake-On-LAN
• Supports Lightning/ESD Protection
• Supports Energy Ecient Ethernet 802.3az
• Supports PXE
Front
Panel I/O
• 1 x Power Button
• 2 x USB 3.2 Gen1 Type-A Ports (Support ESD Protection)
• 1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection)
• 2 x USB 2.0 Ports (Supports ESD Protection)
* USB_3_QC supports supports Quick Charge.
• 1 x SD Card Socket
Rear Panel
I/O
• 1 x DC Jack (Compatible with the 19V power adapter)*
• 1 x D-Sub Port
• 1 x HDMI Port
• 2 x USB 3.2 Gen1 Type-A Ports (Support ESD Protection)
• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
• 1 x Headphone Jack
• 1 x Microphone Input Jack
Storage • 1 x SATA3 6.0 Gb/s with Power Connector , support NCQ,
AHCI and Hot Plug*
• 1 x Ultra M.2 Socket (M2_1), supports type 2260/2280 M.2
SATA3 6.0 Gb/s module and M.2 PCI Express module up to
Gen3 x4 (32 Gb/s)*
* Supports NVMe SSD as boot disks
Connector • 1 x CPU Fan Connector (4-pin)
BIOS
Feature
• AMI UEFI Legal BIOS with multilingual GUI support
• ACPI 6.0 Compliant wake up events
• SMBIOS 2.7 Support

4 5
English
Hardware
Monitor
• CPU Temperature Sensing
• CPU Fan Tachometer
• CPU Quiet Fan (Auto adjust chassis fan speed by CPU
temperature)
• CPU Fan Multi-Speed Control
• Voltage monitoring: CPU Vcore, VCCM, +5V, +3.3V
OS • Microso® Windows® 10 64-bit
Certica-
tions
• FCC, CE
• ErP/EuP ready (ErP/EuP ready power supply is required)

4 5
English
FP6D4-P1
RJ-45
RoHS
1
Headphone
VGA1
2
HDMI1
BIOS
ROM
M.2 WLA N
SATA3_1
Mic In
Power
Button
DC Jack
FP6D4-P1
USB 3.2 Gen1
T: USB_2
USB2.0
B: USB_1
USB 3.2 Gen1
T: USB_4
USB2.0
B: USB_3
USB 3.2 Gen1
T: USB_6
B: USB_5
SD Card
USB 3.2 Gen1
B: USB3_TC_1
DDR4_A1 DDR4_B1
3
CPU_FAN1
1
1.3 Motherboard Layout
No. Description
1 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A1, DDR4_B1)
2 SATA3 Connector (SATA3_1)
3 CPU Fan Connector (CPU_FAN1)

6 7
English
M.2 SSD
Back Side View

6 7
English
FP6D4-P1
1.4 Front Panel
No. Description No. Description
1 SD Card Socket 4 USB 2.0 Port (USB_3)*
2 USB 3.2 Gen1 Type-C Port *Quick Charger Support
(USB3_TC_1) 5 USB 3.2 Gen1 Type-A Port (USB_2)
3 USB 3.2 Gen1 Type-A Port 6 USB 2.0 Port (USB_1)
(USB_4) 7 Power Button (SW1)
7
21 3
4 6
5

8 9
English
1.5 Rear Panel
No. Description No. Description
1D-Sub Port 4 LAN RJ-45 Port*
2 HDMI Port 5 DC Jack
3 USB 3.2 Gen1 Type-A Port 6 Headphone Jack
(USB_5_6) 7 Microphone Input
* ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection
Blinking Data Activity Green 100Mbps connection
On Link Orange 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port
1 43 5 6 7
2

8 9
English
FP6D4-P1
is is a Proprietary form factor motherboard. Before you install the motherboard,
study the conguration of your chassis to ensure that the motherboard ts into it.
Pre-installation Precautions
Take note of the following precautions before you install motherboard components
or change any motherboard settings.
• Make sure to unplug the power cord before installing or removing the motherboard
components. Failure to do so may cause physical injuries and damages to motherboard
components.
• In order to avoid damage from static electricity to the motherboard’s components,
NEVER place your motherboard directly on a carpet. Also remember to use a grounded
wrist strap or touch a safety grounded object before you handle the components.
• Hold components by the edges and do not touch the ICs.
• Whenever you uninstall any components, place them on a grounded anti-static pad or
in the bag that comes with the components.
• When placing screws to secure the motherboard to the chassis, please do not over-
tighten the screws! Doing so may damage the motherboard.
Chapter 2 Installation

10 11
English
2.1 Installing Memory Modules (SO-DIMM)
is motherboard provides two 260-pin DDR4 (Double Data Rate 4) SO-DIMM
slots.
1. Carefully insert the SO-DIMM memory modules into the slot at a 30-degree angle.
2. Push down until the modules snap into place.
e SO-DIMM only ts in one correct orientation. It will cause permanent damage to
the motherboard and the SO-DIMM if you force the SO-DIMM into the slot at incorrect
orientation.
It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot;
otherwise, this motherboard and SO-DIMM may be damaged.

10 11
English
FP6D4-P1
2.2 Onboard Headers and Connectors
Serial ATA3 Connector
(SATA3_1:
see p.5, No. 2)
is SATA3 connector
supports SATA data cables
for internal storage devices
with up to 6.0 Gb/s data
transfer rate.
CPU Fan Connectors
(4-pin CPU_FAN1)
(see p.5, No. 3)
is motherboard
provides a 4-Pin CPU fan
(Quiet Fan) connector. If
you plan to connect a 3-Pin
CPU fan, please connect it
to Pin 1-3.
Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these
headers and connectors. Placing jumper caps over the headers and connectors will cause
permanent damage to the motherboard.
FAN_VOLTAGE
GND
CPU_FAN_SPEED
FAN_SPEED_CONTROL
1 2 3 4

12 13
English
2.3 Smart Switch
e motherboard has one smart switch: Power Button.
Power Button
(SW1)
(see p.7, No. 7)
Power Button allows users
to quickly turn on/o the
system.

12 13
English
FP6D4-P1
2.4 M.2 WiFi/BT Module Installation Guide
e M.2, also known as the Next Generation Form Factor (NGFF), is a small size and
versatile card edge connector that aims to replace mPCIe and mSATA. e M.2 Socket (Key
E) supports type 2230 WiFi/BT module.
* e M.2 socket does not support SATA M.2 SSDs.
Installing the WiFi/BT module
Step 1
Prepare a type 2230 WiFi/BT module
and the screw.
PCB Length: 3cm
Module Type: Type2230
A
Step 2
Find the nut location to be used.
A
A20o
Step 3
Gently insert the WiFi/BT module
into the M.2 slot. Please be aware
that the module only ts in one
orientation.

14 15
English
A
Step 4
Tighten the screw with a screwdriver
to secure the module into place.
Please do not overtighten the screw as
this might damage the module.

14 15
English
FP6D4-P1
2.5 M.2_SSD (NGFF) Module Installation Guide (M2_1)
e Ultra M.2, also known as the Next Generation Form Factor (NGFF), is a small size
and versatile card edge connector that aims to replace mPCIe and mSATA. e Ultra M.2
Socket (M2_1) supports type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express
module up to Gen3 x4 (32 Gb/s).
Installing the M.2_SSD (NGFF) Module
Step 1
Prepare a M.2_SSD (NGFF) module
and the screw.
Step 2
Gently insert the M.2 (NGFF) SSD
module into the M.2 slot. Please
be aware that the M.2 (NGFF) SSD
module only ts in one orientation.
Step3
Tighten the screw with a screwdriver
to secure the module into place.
Please do not overtighten the screw as
this might damage the module.
20o
NUT1NUT2
