Detail Specification
Product Brief
CPU
Memory
Expansion Slot
Graphics
Audio
LAN
Rear Panel I/O
Connector
BIOS Feature
Support CD
Accessories
Hardware Monitor
OS
Certifications
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Chipset
Platform
- Supports AM3 Socket
- Phenom II X6, 6-Core CPU Ready
- Supports ASRock UCC - Unlock CPU Core
- Supports Dual Channel DDR3 1600
- Integrated NVIDIA®GeForce 7025 graphics,
DX9.0 VGA, Pixel Shader 3.0
- Gigabit LAN 10/100/1000 Mb/s
- Supports ASRock XFast USB, Instant Boot,
Instant Flash, OC Tuner, IES, OC DNA, APP
Charger, SmartView
- Micro ATX Form Factor: 8.5-in x 7.0-in, 21.6 cm x 17.8 cm
- Support for Socket AM3 processors: AMD PhenomTM II X6 / X4 / X3
/ X2 (except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron processors
- Supports Six-Core CPU
- Supports UCC feature (Unlock CPU Core)
- Supports AMD's Cool 'n' Quiet Technology
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport Technology
- NVIDIA®GeForce 7025 / nForce 630a
- Dual Channel DDR3 memory technology
- 2 x DDR3 DIMM slots
- Supports DDR3 1600/1333/1066/800 non-ECC, un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express x16 slot
- 1 x PCI slot
- Integrated NVIDIA®GeForce 7025 graphics
- DX9.0 VGA, Pixel Shader 3.0
- Max. shared memory 256MB
- Supports D-Sub with max. resolution up to 1920x1440 @ 60Hz
- 5.1 CH HD Audio (VIA®VT1705 Audio Codec)
- Gigabit LAN 10/100/1000 Mb/s
- Giga PHY RTL8211CL
- Supports Wake-On-LAN
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
- 4 x Serial ATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1,
RAID 0+1, RAID 5 and JBOD), NCQ and "Hot Plug" functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Print Port header
- 1 x COM port header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 4Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU, VCCM Voltage Multi-adjustment
- Drivers, Utilities, AntiVirus Software (Trial Version),ASRock Software
Suite (CyberLink DVD Suite - OEM and Trial; Creative Sound Blaster
X-Fi MB - Trial)
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
- Microsoft®Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP / XP
64-bit compliant
- FCC, CE, WHQL
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables (Optional)
NVIDIA®GeForce 7025 + nForce 630a
Unique Feature
- ASRock OC Tuner
- ASRock Intelligent Energy Saver
- ASRock Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- ASRock AIWI
- ASRock APP Charger
- ASRock SmartView
- ASRock XFast USB
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
N68-VGS3 UCC
www.asrock.com

NVIDIA®GeForce 7025 + nForce 630a
N68-VGS3 UCC
www.asrock.com
ASRock XFast USB Technology -
Faster Than Your Imagination!
ASRock XFast USB Technology -
Faster Than Your Imagination!
ASRock XFast USB Technology redefines the new standard in high performance computing. Proving once
again to be the pioneer in motherboard industry, ASRock XFast USB Series Motherboards integrate with
the latest XFast USB Technology which delivers the world's fastest USB data transfer speed. According to
below graph, it shows that the ASRock XFast USB Technology can even boost USB 2.0 performance up to
259.79% faster!
APP Charger - Fast Charge & Charge Anytime!APP Charger - Fast Charge & Charge Anytime!
If you desire a faster, less restricted way of charging your Apple devices,
such as iPhone/iPod/iPad Touch, ASRock has prepared a wonderful solution
for you – ASRock App Charger. Simply installing the App Charger driver, it
makes your iPhone charged much quickly from your computer and up to
40% faster than before*. ASRock App Charger allows you to quickly charge
many Apple devices simultaneously and even supports continuous charging
when your PC enters into Standby mode (S1), Suspend to RAM(S3),
hibernation mode (S4) or power off (S5)**. With App Charger driver installed,
you can easily enjoy the marvelous charging experience than ever.
* The charging capability may vary with different power supply design. The more +5V standby current provided, the better charge efficiency you get.
** Please connect the devices to the PC USB ports before the PC enters S1/S3/S4/S5 mode to enable a fast charge.
ATTO Disk Benchmark - 4k Write
Other Motherboard without XFast USB Technology
ASRock Motherboard with XFast USB Technology
29474 KB/s
8192 KB/s 259.79%
Faster
ATTO Disk Benchmark - 4k Read
Other Motherboard without XFast USB Technology
ASRock Motherboard with XFast USB Technology
22032 KB/s
8192 KB/s 168.95%
Faster

NVIDIA®GeForce 7025 + nForce 630a
N68-VGS3 UCC
www.asrock.com
Step 1 Step 2
Step 3 Step 4
Step 5 Step 6
Press “F2 or DEL” to enter the BIOS.
CPU Information Under OS Before and After UCC
“ASRock UCC” set to Enabled.
Press “F10” to save change and exit.
Choose the “OC Tweaker” page and
“ASRock UCC” option!
Press “F2 or DEL” to enter the BIOS.
Processor Type unlock to “AMD Phenom II X4 05e”
under “Main” page.
880GM Pro3
World's First NVIDIA Chipset Motherboard
Supports Unlock CPU Core
Unlock
100%
CPU potential
up to 6 Cores
CPU Performance Boost!
ASRock UCC
(Unlock CPU Core)
With ASRock UCC , one simple click in BIOS can unlock CPU core to enjoy an instant performance boost.
AMD CPU Core X2/X3AMD CPU Core X2/X3
AMD CPU Core X4
AMD CPU Core X4
X4X4
X6
X6
Unlock
100%
CPU potential
up to 6 Cores
CPU Performance Boost!
Before -
UCC not enabled, Cores: 4 After - UCC enabled, Cores: 6
Simply enables UCC
function in BIOS

NVIDIA®GeForce 7025 + nForce 630a
N68-VGS3 UCC
www.asrock.com
ASRock Instant Flash is an exclusive and the most user-
friendly BIOS flash utility developed by ASRock. It is embed-
ded in Flash ROM which is used to update the system BIOS
without having to enter operating systems like MS-DOS or
Windows.
Once executing ASRock Instant Flash, the utility will automatically detect all devices such as USB, hard
disk or even floppy drive to find the exact BIOS for your system. Instead of giving you all BIOS in your
devices, the Instant Flash just list BIOS versions that apply to your motherboard model only. For
example, if you have many different BIOS of different motherboards saved in your devices, but you just
need to flash your P45 motherboard, the Instant Flash will just list the P45 BIOS versions for you. This
unique function allows you to easily select the suitable BIOS version instead of browsing through all data.
Features
ASRock Instant Flash
Instant Flash just list
BIOS versions that
apply to your
motherboard model.
Click and start
Flashing!
Simple!Simple! Quick!Quick!
ASRock Instant Boot
ASRock Instant Boot is a new feature invented exclusively by ASRock.
It can boot up system in an amazing speed,
which is 10 times faster than traditional boot up. For home users or office
PC users, ASRock Instant Boot can also
guarantee a clean Windows OS, and consumed less power! For details:
http://www.asrock.com/feature/InstantBoot/index.asp
10 Times Faster, Only 4 Secs to Boot Up to Windows!
ASRock YouTube
http://tw.youtube.com/watch?v=BucIjXZVxXo
* This function is applicable ONLY to single user that does not secure ID and Password to their
systems.
* The boot up time depends on the hardware configuration.

NVIDIA®GeForce 7025 + nForce 630a
N68-VGS3 UCC
www.asrock.com
The Major Features of SmartView
Visual thumbnail images which categorize
and rank your frequently visited websites, as
well as provide a chronological view of your
browser history.
A persistent, real-time Facebook newsfeed
located within the Internet Explorer sidebar.
A "Friend Wall" that conveniently alphabet-
izes your Facebook friends by profile photo,
allowing immediate access to your friends'
profile pages.
Two mode options that allow you to choose your favored view style.
A "share this" button which allows you to
instantly and immediately share webpage posts
and links to your friends' Facebook pages.
A persistent search box from best-in-class search engines
such as Google, Yahoo, Baidu (China only) and Yandex
(Russia only).
Flow Mode Flow Mode
Experience the Brand New Browser Now
SmartView is the smart start page for IE that combines your most visited web sites, your history, your
Facebook friends and your real-time newsfeed into an enhanced view for a more personal Internet
experience. ASRock motherboards are exclusively equipped with the SmartView utility that helps you keep
in touch with friends on-the-go.
System Requirements
OS version: Win7 32/64 bit, Vista 32/64
bit�Browser version: IE8

NVIDIA®GeForce 7025 + nForce 630a
N68-VGS3 UCC
www.asrock.com
CyberLink Power2Go 6.1 LE OEM
Power2Go 6 lets you burn and backup videos, photos, music and data onto Blu-ray
Discs and DVDs.
CyberLink MediaShow 4.1 SE OEM
Photo and video management software MediaShow edits videos and photos
instantly, creates slideshow, and allows publishing directly to YouTube and Flickr.
CyberLink PowerDVD 8.0 DTS Trial
World-renowned PowerDVD 8 DTS delivers outstanding DVD movie playback quality
on your PC.
CyberLink PowerDirector 8.0 Trial
PowerDirector - Video Editing software – edits high-definition videos including
AVCHD, allows output to PSP iPod and Blu-ray Disc.
CyberLink PowerBackup 2.5 Trial
PowerBackup backups valuable data on your PC.
Creative Sound Blaster X-Fi MB Trial
The Sound Blaster X-Fi MB solution provides premium audio quality, effects and
features for PC systems equipped with onboard audio.
For gamers, the EAX®ADVANCED HD 4.0, with its state-of-the-art Multi-Environment
rendering and reverb modelling, delivers a much more realistic and immersive 3D
gaming experience than your motherboard audio ever will.
