ASROCK P67 PRO3 - User manual

Detail Specification
Product Brief
CPU
Memory
Expansion Slot
Audio
LAN
SATA3
USB 3.0
Rear Panel I/O
Smart Switch
Connector
BIOS Feature
Support CD
Accessories
Hardware Monitor
OS
Certifications
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
Chipset
Platform
- ASRock DuraCap (2.5 x longer life time), 100%
Japan-made high-quality Conductive Polymer
Capacitors
- Supports Intel®K-Series unlocked CPU
- Supports Dual Channel DDR3 2133(OC)
- 2 x USB 3.0 ports, 2 x SATA3 connectors,
1 x eSATA3 connector
- Dr. Debug, Smart Swith Design: Power/Reset/
Clear CMOS Switch with LED
- Supports ASRock Extreme Tuning Utility (AXTU),
Instant Boot, Instant Flash, Good Night LED,
Multi-Fan Speed Control, AIWI, APP Charger,
SmartView
- Combo Cooler Option (C.C.O.)
- 7.1 CH HD Audio with Content Protection
(Realtek ALC892 Audio Codec), Premium Blu-ray
audio suppport
- ErP/EuP Ready
- Free Software : CyberLink DVD Suite - OEM and
Trial; Creative Sound Blaster X-Fi MB - Trial
- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
- All Solid Capacitor design (100% Japan-made high-quality
Conductive Polymer Capacitors)
- Supports 2nd Generation Intel®CoreTM i7 / i5 / i3 in LGA1155
Package
- Advanced V8 + 2 Power Phase Design
- Supports Intel®Turbo Boost 2.0 Technology
- Supports Intel®K-Series unlocked CPU
- Supports Hyper-Threading Technology
- Intel®P67
- Dual Channel DDR3 memory technology
- 4 x DDR3 DIMM slots
- Supports DDR3 2133(OC)/1866(OC)/1600/1333/1066 non-ECC,
un-buffered memory
- Max. capacity of system memory: 32GB
- Supports Intel®Extreme Memory Profile (XMP)
- 1 x PCI Express 2.0 x16 slot (blue @ x16 mode)
- 3 x PCI Express 2.0 x1 slots
- 3 x PCI slots
- 7.1 CH HD Audio with Content Protection (RealtekALC892 Audio
Codec)
- Premium Blu-ray audio support
- PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Supports Wake-On-LAN
- Supports LAN Cable Detection
- Supports Energy Efficient Ethernet 802.3az
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Coaxial SPDIF Out Port
- 1 x Optical SPDIF Out Port
- 6 x Ready-to-Use USB 2.0 Ports
- 1 x eSATA3 Connector
- 2 x Ready-to-Use USB 3.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- 1 x Clear CMOS Switch with LED
- HD Audio Jack: Side Speaker / Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone
- 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1,
RAID 10, RAID 5 and Intel®Rapid Storage), NCQ, AHCI and Hot Plug
functions
- 2 x SATA3 6.0 Gb/s connectors
- 1 x Floppy connector
- 1 x IR header
- 1 x COM port header
- 1 x HDMI_SPDIF header
- 1 x Power LED header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 8 pin 12V power connector
- Front panel audio connector
- 3 x USB 2.0 headers (support 6 USB 2.0 ports)
- 1 x Dr. Debug with LED
- 64Mb AMI UEFI Legal BIOS with GUI support
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- DRAM, PCH, CPU PLL, VTT, VCCSA Voltage Multi-adjustment
- 1 x Power Switch with LED
- 1 x Reset Switch with LED
- 1 x Clear CMOS Switch with LED
- Drivers, Utilities, AntiVirus Software (Trial Version),
ASRock Software Suite (CyberLink DVD Suite - OEM and Trial;
Creative Sound Blaster X-Fi MB - Trial)
- 2 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0, RAID 1,
RAID 10, RAID 5 and Intel®Rapid Storage), NCQ, AHCI and
"Hot Plug" functions (SATA3_1 connector is shared with eSATA3 port)
- 2 x USB 3.0 ports by Etron EJ168A, support USB 1.0/2.0/3.0 up to
5Gb/s
- CPU Temperature Sensing
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU/Chassis Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU or MB Temperature)
- CPU/Chassis Fan Multi-Speed Control
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
- Microsoft®Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP / XP
64-bit compliant
- FCC, CE, WHQL
- ErP/EuP Ready (ErP/EuP ready power supply is required)
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables (Optional)
Intel®P67 Chipset
Unique Feature
- ASRock ExtremeTuning Utility (AXTU)
- Instant Boot
- ASRock Instant Flash
- ASRock AIWI
- ASRock APP Charger
- SmartView
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- Combo Cooler Option (C.C.O.)
- Good Night LED
P67 Pro3
www.asrock.com

Intel®P67 Chipset
P67 Pro3
www.asrock.com
ASRock XFast USB Technology -
Faster Than Your Imagination!
ASRock XFast USB Technology -
Faster Than Your Imagination!
ATTO Disk Benchmark - 8M Write
151231 KB/s
76477 KB/s 97.7%
Faster
Other Motherboard with NEC USB 3.0 Chipset
ASRock XFast USB Motherboard with Etron USB 3.0 Chipset
CrystalDiskMark 3.0 - Read 512K
Other Motherboard with NEC USB 3.0 Chipset
ASRock XFast USB Motherboard with Etron USB 3.0 Chipset
264.5 MB/s
194.4 MB/s 36.1%
Faster
ATTO Disk Benchmark - 512K Write
148523 KB/s
76315 KB/s 94.6%
Faster
Other Motherboard with NEC USB 3.0 Chipset
ASRock XFast USB Motherboard with Etron USB 3.0 Chipset
CrystalDiskMark 3.0 - Read Seq
Other Motherboard with NEC USB 3.0 Chipset
ASRock XFast USB Motherboard with Etron USB 3.0 Chipset
276.6 MB/s
202.3 MB/s 36.7%
Faster
ASRock XFast USB Technology redefines the new standard in high performance computing. Proving once
again to be the pioneer in motherboard industry, ASRock XFast USB Series Motherboards integrate with
the latest XFast USB Technology which delivers the world's fastest USB data transfer speed. According to
the below graph, it shows that the ASRock XFast USB technology can even boost USB 3.0 performance up
to 97.7%!
(The rear I/O photo is example only)

Intel®P67 Chipset
P67 Pro3
www.asrock.com
C.C.O.C.C.O.
Combo Cooler Option
C.C.O. provides the flexible option to adopt three
different CPU cooler types, Socket LGA775*,
LGA 1155 and LGA 1156**
*C.C.O. may not be compatible with all Socket 775 CPU coolers.
**O is for Socket 1155 and Socket 1156 CPU cooler.
Support Intel®
K-Series unlocked CPU DuraCap
100% Japan-made high-quality
Conductive Polymer Capacitors

UEFI – The Revolutionary BIOS Interface
AXTU – The All-in-1 Tuning Software
Intel®P67 Chipset
P67 Pro3
www.asrock.com
AXTU – The All-in-1 Tuning Software
UEFI – The Revolutionary BIOS Interface
ASRock Extreme Tuning Utility (AXTU) is an all-in-one software to fine-tune different features in an user-
friendly interface, which includes Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In
Hardware Monitor, it shows the major readings of your system. In Fan Control, it shows the fan speed and
temperature for you to adjust. In Overclocking, you are allowed to adjust the CPU frequency, ratio and
some voltages for optimal system performance. In OC DNA, you can save your OC settings as a profile
and share with your friends. Your friends then can load the OC profile to their own system to get the same
OC settings. In IES (Intelligent Energy Saver), the voltage regulator can reduce the number of output
phases to improve efficiency when the CPU cores are idle without sacrificing computing performance.
Unified Extensible Firmware Interface (UEFI) is a
revolutionary BIOS utility which offers tweak-
friendly options in an advanced viewing interface.
Compared with traditional BIOS design, the latest
UEFI utility provides lots improved functions. The
major features of UEFI include:
1. Graphical Visual Experience – UEFI provides an
improved visual interface with colorful icons and
makes your computing environment more versatile
to replace the traditional dull BIOS page.
2. Mouse Enabling – Besides keyboard control,
you can freely use mouse to select your ideal
settings in UEFI as well.
3. Support bootable HDD over than 2TB – UEFI
breaks the limitation of 2TB bootable HDD on
traditional BIOS. With UEFI, you can enjoy the
bootable HDD size over than 2TB!*
*Windows Vista-64bit or Windows 7-64bit OS is required

Intel®P67 Chipset
P67 Pro3
www.asrock.com
The Major Features of SmartView
Visual thumbnail images which categorize
and rank your frequently visited websites, as
well as provide a chronological view of your
browser history.
A persistent, real-time Facebook newsfeed
located within the Internet Explorer sidebar.
A "Friend Wall" that conveniently alphabet-
izes your Facebook friends by profile photo,
allowing immediate access to your friends'
profile pages.
Two mode options that allow you to choose your favored view style.
A "share this" button which allows you to
instantly and immediately share webpage posts
and links to your friends' Facebook pages.
A persistent search box from best-in-class search engines
such as Google, Yahoo, Baidu (China only) and Yandex
(Russia only).
Flow Mode Flow Mode
Experience the Brand New Browser Now
SmartView is the smart start page for IE that combines your most visited web sites, your history, your
Facebook friends and your real-time newsfeed into an enhanced view for a more personal Internet
experience. ASRock motherboards are exclusively equipped with the SmartView utility that helps you keep
in touch with friends on-the-go.
System Requirements
OS version: Win7 32/64 bit, Vista 32/64
bit�Browser version: IE8

Intel®P67 Chipset
P67 Pro3
www.asrock.com
CyberLink Power2Go 6.1 LE OEM
Power2Go 6 lets you burn and backup videos, photos, music and data onto Blu-ray
Discs and DVDs.
CyberLink MediaShow 4.1 SE OEM
Photo and video management software MediaShow edits videos and photos
instantly, creates slideshow, and allows publishing directly to YouTube and Flickr.
CyberLink PowerDVD 8.0 DTS Trial
World-renowned PowerDVD 8 DTS delivers outstanding DVD movie playback quality
on your PC.
CyberLink PowerDirector 8.0 Trial
PowerDirector - Video Editing software – edits high-definition videos including
AVCHD, allows output to PSP iPod and Blu-ray Disc.
CyberLink PowerBackup 2.5 Trial
PowerBackup backups valuable data on your PC.
Creative Sound Blaster X-Fi MB Trial
The Sound Blaster X-Fi MB solution provides premium audio quality, effects and
features for PC systems equipped with onboard audio.
For gamers, the EAX®ADVANCED HD 4.0, with its state-of-the-art Multi-Environment
rendering and reverb modelling, delivers a much more realistic and immersive 3D
gaming experience than your motherboard audio ever will.
