ASROCK E3C256D4ID2 User manual

E3C256D4ID2
E3C252D4ID2
User Manual
Version 1.0
Published June 2022
Copyright©2022 ASRock Rack INC. All rights reserved.

Version 1.0
Published October 2022
Copyright©2022 ASRock Rack INC. All rights reserved.
Copyright Notice:
No part of this documentation may be reproduced, transcribed, transmitted, or
translated in any language, in any form or by any means, except duplication of
documentation by the purchaser for backup purpose, without written consent of
ASRock Rack Inc.
Products and corporate names appearing in this documentation may or may not
be registered trademarks or copyrights of their respective companies, and are used
only for identication or explanation and to the owners’ benet, without intent to
infringe.
Disclaimer:
Specications and information contained in this documentation are furnished
for informational use only and subject to change without notice, and should not
be constructed as a commitment by ASRock Rack. ASRock Rack assumes no
responsibility for any errors or omissions that may appear in this documentation.
With respect to the contents of this documentation, ASRock Rack does not provide
warranty of any kind, either expressed or implied, including but not limited to
the implied warranties or conditions of merchantability or tness for a particular
purpose.
In no event shall ASRock Rack, its directors, ocers, employees, or agents be liable
for any indirect, special, incidental, or consequential damages (including damages
for loss of prots, loss of business, loss of data, interruption of business and the
like), even if ASRock Rack has been advised of the possibility of such damages
arising from any defect or error in the documentation or product.
is device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
is equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. ese limits are designed to provide
reasonable protection against harmful interference in a residential installation. is
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.

INTEL END USER SOFTWARE LICENSE AGREEMENT
IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING.
LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Soware
only in its unmodied and binary form, (with the accompanying documentation, the
“Soware”) for Licensee’s personal use only, and not commercial use, in connection with
Intel-based products for which the Soware has been provided, subject to the following
conditions:
(a) Licensee may not disclose, distribute or transfer any part of the Soware, and You agree
to prevent unauthorized copying of the Soware.
(b) Licensee may not reverse engineer, decompile, or disassemble the Soware.
(c) Licensee may not sublicense the Soware.
(d) e Soware may contain the soware and other intellectual property of third party
suppliers, some of which may be identied in, and licensed in accordance with, an enclosed
license.txt le or other text or le.
(e) Intel has no obligation to provide any support, technical assistance or updates for the
Soware.
OWNERSHIP OF SOFTWARE AND COPYRIGHTS. Title to all copies of the Soware
remains with Intel or its licensors or suppliers. e Soware is copyrighted and protected
by the laws of the United States and other countries, and international treaty provisions.
Licensee may not remove any copyright notices from the Soware. Except as otherwise
expressly provided above, Intel grants no express or implied right under Intel patents,
copyrights, trademarks, or other intellectual property rights. Transfer of the license termi-
nates Licensee’s right to use the Soware.
DISCLAIMER OF WARRANTY. e Soware is provided “AS IS” without warranty of
any kind, EITHER EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PUR-
POSE.
LIMITATION OF LIABILITY. NEITHER INTEL NOR ITS LICENSORS OR SUPPLIERS
WILL BE LIABLE FOR ANY LOSS OF PROFITS, LOSS OF USE, INTERRUPTION OF
BUSINESS, OR INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAG-
ES OF ANY KIND WHETHER UNDER THIS AGREEMENT OR OTHERWISE, EVEN
IF INTEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
LICENSE TO USE COMMENTS AND SUGGESTIONS. is Agreement does NOT
obligate Licensee to provide Intel with comments or suggestions regarding the Soware.
However, if Licensee provides Intel with comments or suggestions for the modication,
correction, improvement or enhancement of (a) the Soware or (b) Intel products or
processes that work with the Soware, Licensee grants to Intel a non-exclusive, worldwide,
perpetual, irrevocable, transferable, royalty-free license, with the right to sublicense, under
Licensee’s intellectual property rights, to incorporate or otherwise utilize those comments
and suggestions.

TERMINATION OF THIS LICENSE. Intel or the sublicensor may terminate this license
at any time if Licensee is in breach of any of its terms or conditions. Upon termination,
Licensee will immediately destroy or return to Intel all copies of the Soware.
THIRD PARTY BENEFICIARY. Intel is an intended beneciary of the End User License
Agreement and has the right to enforce all of its terms.
U.S. GOVERNMENT RESTRICTED RIGHTS. e Soware is a commercial item (as
dened in 48 C.F.R. 2.101) consisting of commercial computer soware and commercial
computer soware documentation (as those terms are used in 48 C.F.R. 12.212), consistent
with 48 C.F.R. 12.212 and 48 C.F.R 227.7202-1 through 227.7202-4. You will not provide
the Soware to the U.S. Government. Contractor or Manufacturer is Intel Corporation,
2200 Mission College Blvd., Santa Clara, CA 95054.
EXPORT LAWS. Licensee agrees that neither Licensee nor Licensee’s subsidiaries will
export/re-export the Soware, directly or indirectly, to any country for which the U.S.
Department of Commerce or any other agency or department of the U.S. Government
or the foreign government from where it is shipping requires an export license, or other
governmental approval, without rst obtaining any such required license or approval. In
the event the Soware is exported from the U.S.A. or re-exported from a foreign destina-
tion by Licensee, Licensee will ensure that the distribution and export/re-export or import
of the Soware complies with all laws, regulations, orders, or other restrictions of the U.S.
Export Administration Regulations and the appropriate foreign government.
APPLICABLE LAWS. is Agreement and any dispute arising out of or relating to it will
be governed by the laws of the U.S.A. and Delaware, without regard to conict of laws
principles. e Parties to this Agreement exclude the application of the United Nations
Convention on Contracts for the International Sale of Goods (1980). e state and federal
courts sitting in Delaware, U.S.A. will have exclusive jurisdiction over any dispute arising
out of or relating to this Agreement. e Parties consent to personal jurisdiction and venue
in those courts. A Party that obtains a judgment against the other Party in the courts iden-
tied in this section may enforce that judgment in any court that has jurisdiction over the
Parties.
Licensee’s specic rights may vary from country to country.

CALIFORNIA, USA ONLY
e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance
controlled in Perchlorate Best Management Practices (BMP) regulations passed by the
California Legislature. When you discard the Lithium battery in California, USA, please
follow the related regulations in advance.
“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/
perchlorate”
AUSTRALIA ONLY
Our goods come with guarantees that cannot be excluded under the Australian Consumer
Law. You are entitled to a replacement or refund for a major failure and compensation for
any other reasonably foreseeable loss or damage caused by our goods. You are also entitled
to have the goods repaired or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure. If you require assistance please call ASRock
Rack Tel : [phone] ext.123 (Standard International call charges apply)
ASRock Rack INC. hereby declares that this device is in compliance with the essential
requirements and other relevant provisions of related UKCA Directives. Full text of UKCA
declaration of conformity is available at: http://www.asrockrack.com
ASRock Rack INC. hereby declares that this device is in compliance with the essential re-
quirements and other relevant provisions of related Directives. Full text of EU declaration
of conformity is available at: http://www.asrockrack.com
ASRock Rack follows the green design concept to design and manufacture our products,
and makes sure that each stage of the product life cycle of ASRock Rack product is in line
with global environmental regulations. In addition, ASRock Rack disclose the relevant
information based on regulation requirements.
Please refer to https://www.asrockrack.com/general/about.asp?cat=Responsibility for
information disclosure based on regulation requirements ASRock Rack is complied with:
DO NOT throw the motherboard in municipal waste. is product has been
designed to enable proper reuse of parts and recycling. is symbol of the
crossed out wheeled bin indicates that the product (electrical and electronic
equipment) should not be placed in municipal waste. Check local regulations
for disposal of electronic products.

Contents
Chapter 1 Introduction 1
1.1 Package Contents 1
1.2 Specications 2
1.3 Unique Features 6
1.4 Motherboard Layout 7
1.5 Onboard LED Indicators 9
1.6 I/O Panel 10
1.7 Block Diagram 12
Chapter 2 Installation 14
2.1 Screw Holes 14
2.2 Pre-installation Precautions 14
2.3 Installing the CPU 15
2.4 Installing the Heatsink 17
2.5 Installation of Memory Modules (DIMM) 18
2.6 Expansion Slot (PCI Express Slot) 19
2.7 Jumper Setup 20
2.8 Onboard Headers and Connectors 21
2.9 ATX PSU / DC-IN Power Connections 26
2.10 Unit Identication purpose LED/Switch 27
2.11 Dual LAN and Teaming Operation Guide 28
2.12 M.2 SSD Module Installation Guide (M2_1/M2_2) 29
Chapter 3 UEFI Setup Utility 30

3.1 Introduction 30
3.1.1 UEFI Menu Bar 30
3.1.2 Navigation Keys 31
3.2 Main Screen 32
3.3 Advanced Screen 33
3.3.1 CPU Conguration 34
3.3.2 DRAM Conguration 37
3.3.3 Chipset Conguration 38
3.3.4 Storage Conguration 40
3.3.5 NVMe Conguration 41
3.3.6 ACPI Conguration 42
3.3.7 Super IO Conguration 43
3.3.8 Serial Port Console Redirection 44
3.3.9 H/W Monitor 47
3.3.10 Intel SPS Conguration 48
3.3.11 Driver Health 49
3.3.12 Network Stack Conguration 50
3.3.13 Tls Auth Conguration 52
3.3.14 RAM Disk Conguration 53
3.3.15 iSCSI Conguration 54
3.3.16 Instant Flash 55
3.4 Server Mgmt 56
3.4.1 BMC Network Conguration 57
3.4.2 System Event Log 59

3.4.3 Bmc self test log 60
3.4.4 BMC Tools 61
3.4.5 View FRU Information 62
3.5 Security 63
3.5.1 Key Management 64
3.6 Boot Screen 68
3.6.1 CSM Parameters 70
3.7 Event Logs 71
3.8 Exit Screen 72
Chapter 4 Software Support 73
4.1 Download and Install Operating System 73
4.2 Download and Install Software Drivers 73
4.3 Contact Information 73
Chapter 5 Troubleshooting 74
5.1 Troubleshooting Procedures 74
5.2 Technical Support Procedures 76
5.3 Returning Merchandise for Service 76

E3C256D4ID2
E3C252D4ID2
PB 1
English
Chapter 1 Introduction
ank you for purchasing ASRock Rack E3C256D4ID2 / E3C252D4ID2
motherboard, a reliable motherboard produced under ASRock Rack’s consistently
stringent quality control. It delivers excellent performance with robust design
conforming to ASRock Rack’s commitment to quality and endurance.
In this manual, chapter 1 and 2 contains introduction of the motherboard and step-
by-step guide to the hardware installation. Chapter 3 and 4 contains the conguration
guide to BIOS setup and information of the soware support.
1.1 Package Contents
• ASRock Rack E3C256D4ID2 /E3C252D4ID2 Motherboard
(Deep mini ITX Form Factor: 6.7-in x 8.2-in)
• Quick Installation Guide
• 1 x SATA Power Cable (80cm)
• 1 x ATX 4P to 24P Power Cable
• 1 x Oculink to 4 SATA Cable (60cm)
• 1 x Oculink to 4 SATA Cable (60cm) (Optional)
• 1 x I/O Shield
• 2 x Screws for M.2 Sockets
If any items are missing or appear damaged, contact your authorized dealer.
Because the motherboard specications and the BIOS soware might be updated, the con-
tent of this manual will be subject to change without notice. In case any modications of
this manual occur, the updated version will be available on ASRock Rack website without
further notice. You may nd the latest memory and CPU support lists on ASRock Rack
website as well. ASRock Rack’s Website: www.ASRockRack.com
If you require technical support related to this motherboard, please visit our website for
specic information about the model you are using.
http://www.asrockrack.com/support/

2 3
English
1.2 Specications
E3C256D4ID2 / E3C252D4ID2
Physical Status
Form Factor Deep mini ITX
Dimension 6.7" × 8.2"
Processor System
CPU Supports Intel® Xeon® E-2300 and 10th Gen Intel® Pentium®
series processors
Socket Single Socket H5 (LGA1200)
ermal Design
Power (TDP)
95W
Chipset E3C256D4ID2: Intel® C256
E3C252D4ID2: Intel® C252
System Memory
Supported DIMM
Quantity
4 DIMM slots (2DPC)
Supported Type DDR4 288-pin ECC/non-ECC UDIMM
Max. Capacity per
DIMM
ECC/non-ECC UDIMM: up to 32GB
Max. Frequency ECC/non-ECC UDIMM: max. 3200MHz*
Voltage 1.2V
Note *Up to DDR4 2666MHz when installing 10th Gen Intel® Pentium® Series
Processors
PCIe Expansion Slots
SLOT7 PCIe4.0* x16 [CPU]
Note *SLOT7 supports PCIe3.0 only when installing 10th Gen Intel® Pentium® Series
Processors
Other PCIe Expansion Connectors
M.2 slot 1 M-key* (PCIe4.0 x4); support 2280 form factor [CPU]
1 M-key (PCIe3.0 x4); support 2280 form factor [PCH]
OCuLink E3C256D4ID2:
3 (OCU1 & OCU2: PCIe3.0 x4 or 4 SATA 6Gb/s [PCH] ;
OCU3: PCIe3.0 x4 [PCH] )
E3C252D4ID2:
2 (OCU1: PCIe3.0 x2 or 4 SATA 6Gb/s [PCH] ; OCU2: 2 SATA
6Gb/s [PCH])
Note *M.2 from CPU will not fuction when installing 10th Gen Intel® Pentium®
Series Processors
SATA/SAS Storage
PCH Built-in Storage E3C256D4ID2: Intel® C256 (8 SATA 6Gb/s; RAID 0/1/5/10):
2 OCuLink
E3C252D4ID2: Intel® C252 (6 SATA 6Gb/s; RAID 0/1/5/10):
2 OCuLink

E3C256D4ID2
E3C252D4ID2
2 3
English
Ethernet
Additional Ethernet
Controller
2 RJ45 (1GbE) by Intel® i210
USB
Connectors/headers External:
2 Type A (USB3.2 Gen1)
Internal:
1 header (19-pin, 2 USB3.2 Gen1)
Graphics
Controller ASPEED AST2500:
1 DB15 (VGA)
Security
TPM 1 (13-pin, SPI)
Rear I/O
UID button/LED 1 UID button w/ LED
Video output 1 DB15 (VGA)
USB 2 Type A (USB3.2 Gen1)
RJ45 2 RJ45(10GbE), 1 dedicated IPMI
Hardware Monitor
Temperature CPU, PCH, MB, Card side Temperature Sensing
Fan Fan Tachometer
CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
Fan Multi-Speed Control
Voltage VCORE,VCCSA,VCCM,3V, 5V, 12V, +1.05V_PCH_
AUX,+BAT, 3VSB, 5VSB,VCCIO,+2.5V_VPP
Server Management
BMC Controller ASPEED AST2500: iKVM, vMedia support
IPMI Dedicated
GLAN
1 RJ45 Dedicated IPMI LAN port by Realtek RTL8211E
BIOS
BIOS type AMI 256Mb SPI Flash ROM
Features Plug and Play, ACPI 6.2 and above compliance wake up
events, SMBIOS 3.3 and above , ASRock Rack instant ash
Internal Connectors/Headers
PSU connector 1 (4-pin, ATX PSU signal) w/ ATX 24-pin adapter cable, 1 (8-
pin, ATX 12V) support 12V DC-in
Other power
connector
1 (4-pin) for HDD power when using 12V DC-in power
source
Auxiliary panel
header
1 (9-pin): chassis intrusion, system fault LED, LAN1/LAN2
activity LED, locate
System panel header 1 (9-pin): power switch, reset switch, system power LED,
HDD activity LED

4 5
English
COM header 1
Fan header 3 (4-pin)
ermal sensor
header
1
TPM header 1 (13-pin, SPI)
SGPIO header 1
SMbus header 1
PMbus header 1
IPMB header 1
UID header 1
Clear CMOS 1 (contact pads)
Others 1 NC-SI
LED Indicators
Standby Power LED 1 (5VSB)
Fan Fail LED 3
BMC Heartbeat LED 1
System BIOS
BIOS Ty pe 256Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
Support OS
OS Microso® Windows®
- Server 2019 (64 bit)
- Server 2022 (64 bit)
Linux®
- RedHat Enterprise Linux Server 8.6 (64 bit) / 8.3 (64 bit)
- CentOs 8.5 (64 bit) / 8.3 (64 bit)
- SUSE Enterprise Linux Server 15 SP3 (64 bit) / 15 SP2
(64 bit)
- Ubuntu 21.10 (64 bit)
Hypervisor:
- VMWare® ESXi 7.0U3d/ vSphere 7.0U3d
*Please refer to our website for the latest OS support list.
Operating Enviroment
Operating
temperature
10 - 35°C (50 - 95 degF)
Non-operating
temperature
-40 - 70°C (-40 - 158degF)
NOTE: Please refer to our website for the latest specications.

E3C256D4ID2
E3C252D4ID2
4 5
English
is motherboard supports Wake from on Board LAN. To use this function, please make
sure that the “Wake on Magic Packet from power o state” is enabled in Device Manager
> Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is
enabled in UEFI SETUP UTILITY > Advanced > ACPI Conguration. Aer that, onboard
LAN1&2 can wake up S5 under OS.
If you install Intel® LAN utility or Marvell SATA utility, this motherboard may fail Win-
dows® Hardware Quality Lab (WHQL) certication tests. If you install the drivers only, it
will pass the WHQL tests.

6 7
English
1.3 Unique Features
ASRock Rack Instant Flash is a BIOS ash utility embedded in Flash ROM. is con-
venient BIOS update tool allows you to update system BIOS without entering operat-
ing systems rst like MS-DOS or Windows®. With this utility, you can press the <F6>
key during the POST or the <F2> key to enter into the BIOS setup menu to access
ASRock Rack Instant Flash. Just launch this tool and save the new BIOS le to your
USB ash drive, oppy disk or hard drive, then you can update your BIOS only in a
few clicks without preparing an additional oppy diskette or other complicated ash
utility. Please be noted that the USB ash drive or hard drive must use FAT32/16/12
le system.

E3C256D4ID2
E3C252D4ID2
6 7
English
1.4 Motherboard Layout
17.0cm (6.7 in)
20.8cm (8.2 in)
PSU_SMB1
ATX12V2
CMOS Battery
NCSI1
ATX4PIN1
OCU1
OCU2
FAN2
FAN3
USB3_3_4
SATA_SGPIO1
ITX_AUX_PANEL1
PANEL1
T 1
SEC_OR1
R
BIOS
ROM
Intel
C256/
C252
PCIE7
BMC_SMB_1
IPMB_1
M2_1
M2_2
Intel
I210
LAN1 LAN2
(NCSI)
USB 3.2 Gen1
T: USB_1
B: USB_2
IPMI_LAN
VGA1
TPM_BIOS_PH1
COM1
FAN1
CHASSIS_ID0
UID1
DDR4_B1
DDR4_B2
DDR4_A1
DDR4_A2
OCU3
SATA_PWR1
ASPEED
AST2500
5
14
18
13
14
17
15
11
12
9
10
7
19
21 20
22
23
24
25
29
27
26
28
30
CLRMOS1
16
E3C256D4ID2
E3C252D4ID2
8
6
(E3C256D4ID2 only)
Intel
I210
(LAN1)
Intel
I210
Intel
I210
(LAN2)
(Bottom) (Top)
UID_HEADER
IPMI_LED1
23

8 9
English
No. Description
1NCSI Header (NCSI1)
2 UID Button Header (UID_HEADER)
3 IPMI LAN LED Header (IPMI_LED1)
4 Micro-Fit Power Connector (ATX4PIN1)
5 ATX 12V Power Connector (ATX12V2)
6 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
7 PSU SMBus Header (PSU_SMB1)
8 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
9 SATA Power Connector (SATA_PWR1)
10 M.2 Socket (M2_2) (Type 2280)
11 System Fan Connector (FAN2)
12 System Fan Connector (FAN3)
13 Auxiliary Panel Header (ITX_AUX_PANEL1)
14 System Panel Header (PANEL1)
15 OCuLink x4 Connector (OCU3) (E3C256D4ID2 only)
16 Clear CMOS Pad (CLRMOS1)
17 ermal Sensor Header (TR1)
18 Security Override Jumper (SEC_OR1)
19 USB 3.2 Gen1 Header (USB3_3_4)
20 SATA SGPIO Connector (SATA_SGPIO1)
21 OCuLink x4 Connector (OCU1)
22 OCuLink x4 Connector (OCU2)
23 PCI Express 4.0 x16 Slot (PCIE7)
24 BMC SMBus Header (BMC_SMB_1)
25 Intelligent Platform Management Bus Header (IPMB_1)
26 COM Port Header (COM1)
27 System Fan Connector (FAN1)
28 Chassis ID Jumper (CHASSIS_ID0)
29 SPI TPM Header (TPM_BIOS_PH1)
30 M.2 Socket (M2_1) (Type 2280)
*e M2_1 slot is not supported with the 10th Gen Intel® Pentium Series Processors installed.

E3C256D4ID2
E3C252D4ID2
8 9
English
1.5 Onboard LED Indicators
1
2
3
4
5
E3C256D4ID2
E3C252D4ID2
No. Item Status Description
1 SB_PWR1_LED Green STB PWR ready
2FAN_LED2 Red FAN2 failed
3FAN_LED3 Red FAN3 failed
4BMC_LED1 Green BMC heartbeat LED
5FAN_LED1 Red FAN1 failed

10 11
English
1.6 I/O Panel
2
5
163
4
No. Description No. Description
1 USB 3.2 Gen1 Ports (USB3_1_2) 4 1G LAN RJ-45 Port (LAN2)**
2 LAN RJ-45 Port (IPMI_LAN)* 5 VGA Port (VGA1)
3 1G LAN RJ-45 Port (LAN1)** 6 UID Switch (UID1)
LAN Port LED Indications
*ere are two LEDs on each LAN port. Please refer to the table below for the LAN port
LED indications.
Dedicated IPMI LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 10Mbps connection or
no link
Blinking Yellow Data Activity Yellow 100Mbps connection
On Link Green 1Gbps connection
ACT/LINK LED
SPEED LED
LAN Port

E3C256D4ID2
E3C252D4ID2
10 11
English
**ere are two LEDs on each LAN port. Please refer to the table below for the LAN port
LED indications.
LAN Port LED Indications
Activity / Link LED Speed LED
Status Description Status Description
O No Link O 100Mbps connection or no
link
Blinking Yellow Data Activity Yellow 1Gbps connection
On Link Green 10Gbps connection
ACT/LINK LED
SPEED LED
LAN Port

12 13
English
1.7 Block Diagram
E3C256D4ID2
PCI-E X16 SLOT 7
Ch ann el A
INTEL
C256
PCH-H
Ch ann el B
HSIO 26
BMC
AST2500
(HSIO 6)
RGB
ESPI
DDR4
256MB
PWM
RTL8211E
RGM II RGM I
I
FAN1
FAN2
FAN3
USB3.2 Gen15Gb/s
USB3.2 Gen1
2rear po rts T ype AHSIO 0-1
HSIO 4-5
USB 3.2 Gen1
2 Front ports USB3.2 Gen15Gb/s
Rear VGA
Port
AUX panel
header I2C
DDR4UDIMM
Max t o 32 00
Oculink 1
INTEL I210
(LAN1NCSI)
1G-Ba seT x2
SATA 3 / PCI E 6Gb/s
Oculink 2SATA 3 / PCI E 6Gb/s
HSIO 18-21
HSIO 22-25
SIO
NCT5585D-B
PCIE Gen2 *1
M.2_1 PCI -E Gen4BUS
80 Port
Oculink 3PCIE Gen36Gb/sHSIO 10-13
M.2_2PCI E Gen 36Gb/sHSIO 14-17
Switch SPI FLASH
SYSTEM BIOS
SPI TPM Header
ESPI
SPI
SPI
INTEL
Processor
LGA-1200 Pin Socket
DDR4UDIMM
Max t o 32 00
MNG RJ45
HSIO 29 PCI E Gen2 *1 INTEL I210
