Assa Abloy PDU8000 Series User manual

IMPORTANT: PLEASE READ BEFORE INSTALLING THE PANIC DEVICE
The following instructions will decrease your chances of experiencing problems during
the installation and ensure a smooth, trouble-free operation of the Panic Device.
PDU8000 Series Panic Device
Copyright © 2017, ASSA ABLOY Inc. All rights reserved. Reproduction in whole or in part
without the express written permission of ASSA ABLOY Inc. is prohibited.
The global leader in
door opening solutions

Copyright © 2017, ASSA ABLOY Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Inc. is prohibited.
The global leader in
door opening solutions
1
Table of Contents
1. Introduction ...................................................................................................................................................................................
1.1 Description ...........................................................................................................................................................................
1.2 Parts List ................................................................................................................................................................................
1.3 Tools and Supplies ...............................................................................................................................................................
1.4 Dogging Feature ...................................................................................................................................................................
2. Instructions for Rail Mount Doors ............................................................................................................................................
2.1 Detailed Parts List ...............................................................................................................................................................
2.2 Removal from Packaging ....................................................................................................................................................
2.2.1 Introduction ............................................................................................................................................................
2.2.2 Remove Panic Device from Shipping Board .......................................................................................................
2.2.3 Remove Horizontal Door Mount ........................................................................................................................
2.2.4 Remove Horizontal Door Mount (Deco End Cap Option) ...............................................................................
2.2.5 Remove Vertical Door Mount ...............................................................................................................................
2.2.6 Remove Actuator Post Assembly ...........................................................................................................................
2.3 Panic Device Installation .....................................................................................................................................................
2.3.1 Install Panic Device on Rail Mount Door ............................................................................................................
2.3.2 Install Door Bushings .............................................................................................................................................
2.3.3 Install C Bushing ......................................................................................................................................................
2.3.4 Install Mating Pull .....................................................................................................................................................
2.3.5 Install Actuator Post Assembly .............................................................................................................................
2.3.6 Install Vertical Door Mount ...................................................................................................................................
2.3.7 Install Horizontal Door Mount .............................................................................................................................
2.3.8 Install Horizontal Door Mount (Deco End Cap Option) .....................................................................................
2.3.9 Install Panic Device on Rail Mount Door .............................................................................................................
2.3.10 Horizontal End Threadlocker and Lube Application ......................................................................................
2.3.11 Align Actuator Gauge ...........................................................................................................................................
3. Instructions for All Glass Doors ....................................................................................................................................................
3.1 Detailed Parts List .................................................................................................................................................................
3
3
3
3
4
5
5
7
7
7
8
8
9
9
10
10
10
10
11
11
12
13
13
14
15
15
17
17

Copyright © 2017, ASSA ABLOY Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Inc. is prohibited.
The global leader in
door opening solutions 2
Table of Contents (Continued)
3.2 Removal from Packaging .....................................................................................................................................................
3.2.1 Introduction ............................................................................................................................................................
3.2.2 Remove Panic Device from Shipping Board ......................................................................................................
3.2.3 Remove Horizontal Door Mount ..........................................................................................................................
3.2.4 Remove Horizontal Door Mount (Deco End Cap Option) ..............................................................................
3.2.5 Remove Vertical Door Mount ...........................................................................................................................
3.2.6 Remove Actuator Post Assembly .........................................................................................................................
3.3 Panic Device Installation ..........................................................................................................................................................
3.3.1 Install Panic Device on All Glass Door .................................................................................................................
3.3.2 Install Door Bushings ..............................................................................................................................................
3.3.3 Install C Bushing ......................................................................................................................................................
3.3.4 Install Mating Pull ...................................................................................................................................................
3.3.5 Install Actuator Post Assembly ...........................................................................................................................
3.3.6 Install Vertical Door Mount ..................................................................................................................................
3.3.7 Install Horizontal Door Mount ..............................................................................................................................
3.3.8 Install Horizontal Door Mount (Deco End Cap Option) ...................................................................................
3.3.9 Install Panic Device on All Glass Door .................................................................................................................
3.3.10 Horizontal End Threadlocker and Lube Application .......................................................................................
3.3.11 Align Actuator Gauge .........................................................................................................................................
4. Strike Installation ..........................................................................................................................................................................
4.1 Header Preparation for Single and Double Manual Strikes with Adjustable Door Stops .......................................
4.2 Header Preparation for Single and Double Electrical Strikes with Adjustable Door Stops .....................................
5. Latch / Adjustable Door Stops Adjustment ................................................................................................................................
5.1 Installation and Adjustment of Door Stop-Strike ..........................................................................................................
5.2 Latch Adjustment for Proper Engaging with the Strike .................................................................................................
6. Cleaning and Maintenance ................................................................................................................................................................
6.1 General Maintenance Instructions .....................................................................................................................................
6.2 Finish Cleaning Instructions ................................................................................................................................................
6.3 Mechanical Maintenance .....................................................................................................................................................
19
19
19
20
20
21
21
22
22
22
22
23
23
24
25
25
26
27
27
28
28
30
32
32
34
36
36
36
37

Copyright © 2017, ASSA ABLOY Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Inc. is prohibited.
The global leader in
door opening solutions
1. Introduction
3
• The PDU8000 Series Panic Device offers superior functionality for egress and security needs.
• The Panic Device has an aesthetically pleasing design that is available in two configurations: one for Rail Mount Doors
and one for All Glass Doors.
• Depending on configuration, the system could include a Dogging Feature. Refer to Dogging Feature (Introduction, page 4).
• Please read the Installation Instructions in this manual carefully before installing the Panic Device.
• If you have questions, please contact us at [phone].
Description1.1
• The tools and supplies listed below are necessary to complete the installation of the Panic Device.
• Each configuration of the Panic Device has its own unique parts list . Please refer to the Detailed Parts List section for
the applicable parts lists shown below.
Parts List1.2
Tools and Supplies1.3
• Detailed Parts List - Rail Mount Doors: Refer to Section 2.1.
• Detailed Parts List - All Glass Doors: Refer to Section 3.1.
Tools
• Allen wrenches: 5/64”, 5/32”, 1/8”, 3/16”, 1/4”
• Latch and Actuator Gauge
• Spanner Wrench
• Wrench: 7/16”
Supplies included in kit
• Threadlocker
• Synthetic Multi-Purpose Grease
• Latch and Actuator Gauge
• Extra Door Bushings
Supplies Needed (not included in kit)
• Soft Cloth

Copyright © 2017, ASSA ABLOY Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Inc. is prohibited.
The global leader in
door opening solutions 4
Figure 1-1
Dogged Position
Figure 1-2
Un-dogged Position
Dog Button
Dog Button
• The Dogging Feature is located on the bottom of the Panic Device Assembly vertical tube, directly under
the Actuator Post Assembly.
• Engage the Horizontal Crash Bar and slide the Dog Button to the up position.
• The Panic Device Assembly is dogged when the Dog Button is in the up position. Refer to Figure 1-1.
• The Panic Device Assembly is un-dogged when the Dog Button is in the down position. Refer to Figure 1-2.
1.4 Dogging Feature
