Associated Electrics TC3 User manual

2
TOOLS
KIT TOOLS SUPPLIED
EXTRA STUFF NEEDED
Phillips screwdriver #2
needlenose pliers
soldering iron (40-50 watts) and a
small amount of Rosin core solder.
Pencil-type soldering iron is better
than the gun type. DANGER! Tip
is HOT!
Thread locking compound (#242
Blue Loctite© or equivalent)
Super glue (cyanoacrylic glue).
hobby knife WARNING! This knife
cuts plastic and fingers with equal
ease, so be careful.
precision ruler
electrician's tape
strapping tape
Allen wrenches, .050", 1/16",
3/32",
5/64"
molded tools
WARNING! Always
use hand and eye
protection with cyano-
acrylic glue!
TEAM KIT
#3030 RC10TC3 Team Kit
Shocks: Blue anodized aluminum-body
VCS Macro shocks.
Tires and Wheels: Pro-Line V-Rage
tires and Axis wheels.
Front & Rear Axles: Blue-anodized alloy
MIP CVD's.
Turnbuckles: Factory Blue titanium
turnbuckles.
Also includes: Precision stainless steel
PTFE/rubber-sealed ball bearings.
RACER KIT
RC10TC3 Racer Kit
Shocks: VCS Macro shock.
Tires and Wheels: Pro-Line V-Rage
tires and Axis wheels.
Front & Rear Axles: Composite MIP
CVD's.
Turnbuckles: Associated steel
turnbuckles
Choice of three Protoform bodies,
with matching
Protoform decal.
Also includes: Precision stainless-
steel rubber-sealed ball bearings.
EACH KIT INCLUDES
Pro-Line std. 12m Hex wheels & tires.
Aluminum motor mount with a built-in
heatsink.
Carbide ball aSSOC. differentials.
Adjustable caster, camber, toe-in, anti-
squat, kickup. Several tie-rod mounting
positions.
Foam bumper.
TC3 decal sheet
Rear bumper
HELPFUL TOOLS (NOT REQUIRED)
Allen drivers (straight Allen wrenches with hex shaped
handles)
such as the following made by Associated:
#6957 .050" driver
#6958 1/16" driver
#6959 5/64" driver
#6960 3/32" driver
#6961 2.5mm driver
Vernier calipers
Hobby scissors
Nut drivers (screwdriver-
handled hex socket tools)
3/16" nut driver
1/4" nut driver
11/32" nut driver
WARNING! Do not use a power screwdriver to install screws
into nylon, plastic, or composite materials. The fast rotation
speed can heat up the screws being installed. They can then
ITEMS NEEDED TO COMPLETE YOUR CAR
1R/C two channel surface frequency radio system.
2*Battery pack (6 cell).
3Battery charger (we recommend a peak detection charger).
4*Electronic speed control.
5*R/C electric motor.
6*Pinion gear, size to be determined by type and wind of motor you
will be using.
7*1:10 scale Lexan body (Team Kit only).
*Available from Team Associated. See your catalogs.
Revised 1/2000

STEERING RACK ASSEMBLY
Attach two #3858 short ball ends to the #3855
steering rack and one #3858 short ball end to the
#3855 steering rack arm.
Slide the #6587 spring and the #3855 rack shim onto
the #6918 screw. Slide the screw assembly through
the bottom of the steering rack.
Attach the #3855 rack arm to the rack with a #4449
locknut.
Tighten down the spring until the screw is flush with
the top of the nut.
Make sure the rack arm is facing
the rear when assembled on the
rack: The ball end on the rack arm
and the ball ends on the rack should
be pointing in opposite directions.
BAG A
REMOVE THESE
PARTS FOR:
Step 1
1:1
BEFORE BUILDING
OPEN THE BAGS IN ORDER
The assembly is arranged so that you will open and finish
that bag before you go on to the next bag. Sometimes you
will have parts remaining at the end of a bag. These will
become part of the next bag. Some bags may have a large
amount of small parts. To make it easier to find the parts, we
recommend using a partitioned paper plate for spreading out
the parts so they will be easier to find.
MANUAL FORMAT
The following explains the format of these instructions.
The beginning of each section indicates:
1Which bag to open ("BAG A") and which steps you'll be
using those parts for ("FOR STEPS 1-3").
2Which parts you will use for those steps. Remove only the
parts shown. "1:1" indicates an actual size drawing; place
your part on top and compare it so it does not get confused
with a similar part.
3Which tools you should have handy for that section.
4In some drawings, the word "REAR" with an arrow
indicates which direction is the rear of the car to help keep
you oriented.
5 The instructions in each step are ordered in the order you
complete them, so read the words AND follow the pictures.
The numbers in circles are also in the drawing to help you
locate them faster.
6When we refer to left and right sides of the car, we are
referring to the driver's point of view inside the car.
7Occasionally you will see an upside-down triangle next to a
part. This indicates that more information is given about
the part next to the matching triangle near the text.
SUPPLEMENTAL SHEETS
We are constantly developing new parts to improve our kits.
These changes, if any, will be noted in supplementary sheets
located in a parts bag or inside the kit box. Check the kit box
before you start and each bag as it is opened. When a
supplement is found, attach it to the appropriate section of the
manual.
REACHING US
ASSOCIATED ELECTRICS, INC.
3585 Cadillac Ave.
Costa Mesa, CA 92626
USA
©1998 Associated Electrics, Inc.
CUSTOMER SUPPORT
[phone]
FAX [phone]
web site: http://www.rc10.com
3
TOOLS USED
Match this number
to the text to find
your way faster
3858
black
4449, qty 1
4-40 locknut
3858
black
3855
steering rack
3855
steering rack arm
6587
black
3855
6918
4449
1:1
6918, qty 1
4-40 x 1/2
3858, qty 3
short special
ball end, black
3855, qty 1
steering rack arm
6587, qty 1
spring
black
3855, qty 1
steering rack
3855,qty 1
.125 x .250 rack
shim, black
3858
black
step 1
1:1 1:11:1
1/16"
4
3855,qty 2
spacer, black
1:1 See page 21 for
Ackerman setup
options using the
spacer supplied
in bag A.

BAG A TOOLS USED
4
3863
step 2 RACK TO CHASSIS ASSEMBLY
Install the two #3856 rack posts to the #3850 chassis with two
#6291 screws.
Slide one #3856 washer, one #3856 steering rack bushing, one
#3856 rack post shim and one #3856 steering rack bushing onto the
rack post. Repeat for the other post.
Place the rack assembly over the rack posts.
Add two #3856 washers, then the two #6222 nylon locknuts.
Tighten each nut down until the rack does not move
side-to-side freely. Then loosen the nuts 1/4 turn or until
the rack moves freely.
1:1
REMOVE THESE
PARTS FOR:
Step 2
3856, qty 2
rack post
6291, qty 2
4-40 X 1/4 screw
3856, qty 4
washer
3856, qty 4
1/8 x 1/4 steering
rack bushing
3856, qty 2
rack post shim
6222, qty 2
nylon locknut
3850, qty 1
chassis
NOT IN BAG A
3856 rack post
3850
6291
6291
3856 bushing
3856 shim
3856 bushing
6222
1:1
BAG B
REMOVE THESE
PARTS FOR:
Steps 1- 2
TOOLS USED
step 1
FRONT ARM ASSEMBLY
Attach the #3863 front arm rear mount (with the "F" molded into
mount--see below for location) to the chassis with two #6292
screws.
Attach the #3863 front arm front mount (with the "F+2" molded
into the mount) to the #3851 bumper with one #6292 screw.
Slide the #3866 inner hinge pins through the #3860 front arms.
Slide the pins with the arms into the front arm rear mounts.
Align the front arm front mount and bumper with the two hinge
pins and slide together. Tighten it down with two #6292 screws.
By changing arm mounts you can adjust for kickup and anti-
dive. For more information about kickup and anti-dive settings,
see the tuning section at the rear of the manual.
3863, qty 1, code (F)
front arm rear mount
3863, qty 1, code (F+2)
front arm front mount
3863, qty 1
code R+3+2
rear arm rear mount
3863, qty 1, code (R)
rear arm front mount
1:1
6292, qty 9
4-40 X 3/8 screw
3860, qty 2
front arm
3851, qty 1
front bumper
3890, qty 2
rear arm
3900, qty 1
rear bumper
3866, qty 4
inner hinge pin
3863
6292
3851
6292
6292
3866
3866
3860
3860
6292
6292
1:1
3856 washer
3856 washer
1:1
1/16"
1/16"
WHERE TO FIND THE ARM MOUNT CODE
(See page 20 for full explanation of arm mount codes)
F+2
F
REMOVE GRAY AREAS WHERE SHOWN
BE CAREFUL NOT TO REMOVE THE BALLS!!
Remove flashing so balls are perfectly smooth.
DO NOT REMOVE!!

5
step 2
REAR ARM ASSEMBLY
Attach the #3863 rear arm front mount (with the "R" molded into
mount--see below for location) to the chassis with two #6292 screws.
Slide the #3866 inner hinge pins through the #3890 rear arms. Slide
the pins with the arms into the #3863 rear arm front mount.
Place the #3863 rear arm rear mount (with the "R+3+2" molded into
the mount) on the #3900 rear bumper. Align the rear arm mount and
bumper with the two hinge pins and slide together. Tighten it down
with two #6292 screws.
By changing arm mounts you can adjust toe-in and anti-squat. For
more information about the rear toe-in and anti-squat settings, see
the tuning section at the rear of the manual.
3863
6292
6292
3866
3866
3890
3890
3863
3900
6292
6292
BAG C
REMOVE THESE
PARTS FOR:
Steps 1- 3
TOOLS USED
3912, qty 2
long outdrive hub
1:1
step 1
SET UP DIFFERENTIAL RING GEAR
Trim any burrs from the inside of the gear with a hobby knife.
Add a generous amount of #6591 diff lube to the #3914
differential ring gear holes and push in the twelve large #6581
diff balls. Then push back in the lube that came out.
Insert one #6909 bearing into the gear.
3912, qty 2
short outdrive hub
3914, qty 2
differential ring gear
6573, qty 4
diff thrust washer
6575, qty 2
diff bolt cover
6575, qty 2
diff bolt
6575, qty 2
T-nut
6581, qty 24
3/32 diff ball
large
6582, qty 2
diff spring,
silver
6909, qty 2
3/16 x 5/16 bearing
unflanged
6574, qty 12
5/64 thrust ball
small
3914
6581
6909
6591, qty 1
aSSOC. diff lube
step 2
SET UP LONG OUTDRIVE HUB
Push the #6582 spring and #6575 T-nut
into the #3912 long outdrive.
6575
6582
6591
6588, qty 1
black grease
1:1 1:11:1 1:1
1:1 1:11:1
5/64"
WHERE TO FIND THE ARM MOUNT CODE
(See page 20 for full explanation of arm mount codes)
3912 long
RR+3+2
REMOVE GRAY AREAS WHERE SHOWN
BE CAREFUL NOT TO REMOVE THE BALLS!!
Remove flashing so balls are perfectly smooth.
DO NOT REMOVE!!
Trim any burrs
from the inside
of the gear with
a hobby knife.

BAG C
REMOVE THESE
PARTS FOR:
Steps 4-5
TOOLS USED
step 3
ASSEMBLE THE SHORT OUTDRIVE HUB
Slide one #6573 washer onto the #6575 bolt.
Apply a generous amount of #6588 black grease to the washer
on the side facing away from the bolt head.
Place six #6574 balls into the grease against the #6575 bolt
and washer. Add the other #6573 washer. The grease will hold
the balls in place during assembly, sandwiched between the
washers. See figure for installed view.
Slide the thrust assembly into the #3912 short outdrive hub,
bearing careful not to lose any of the balls.
Insert the #6575 bolt cover.
6588
6575 bolt
6573 washer
6574
6575 cover
1:1
6909, qty 2
3/16 x 5/16 bearing
unflanged
6579, qty 4
diff drive ring
3976, qty 4
3/8 x 5/8 bearing
rubber sealed, unflanged
step 4
ASSEMBLE THE LONG OUTDRIVE HUB
Insert one #6909 bearing into the #3912 long hub.
Add a light coat of #6591 Assoc. lube to the long hub
face where shown.
Place a #6579 diff drive ring and then the gear assembly
on the hub.
ASSEMBLE THE HUBS
Add a light coat of #6591 Assoc. lube to the #3912 short hub face where shown.
Place a #6579 diff drive ring on the hub.
Push the #3912 short hub into the back side of the
differential ring gear. Center the diff bolt in the hub.
CHECK ALIGNMENT OF HUBS
Tighten the diff with your 5/64" Allen wrench, but not completely.
Rotate the diff hubs several times as you are tightening the bolt to check proper
alignment of the parts. Read step 9 carefully.
7
8
6909
3912 long
6591
6579
6591
6579
3912 short
step 5
FINAL OUTDRIVE ASSEMBLY
Press the #3926 outdrive dust cap into
the #3912 long outdrive.
Place one #3911 outdrive shim on both
the long and short hubs.
Place one #3976 bearing over each
outdrive hub.
3912 long
3912 short
3911
3911
1:1
6
3911, qty 4
outdrive shim
1:1 1:1
9
5/64
6573 washer
3912 short
1:1
3976, qty 4
3/8 x 5/8 bearing
rubber sealed, unflanged
3976
3976
back side
front side
3926, qty 2
long outdrive
dust cap
3926 dust cap
ADJUST THE DIFF
As you tighten the diff bolt, you will notice the T-nut ears moving closer to the bottom of the diff hub slot. This compresses the spring
behind the T-nut. The spring should be fully compressed at the same time the T-nut reaches the end of the slot. Caution: Pay close
attention to feeling when the spring is full compressed. Do not overtighten the bolt.
When you feel the spring fully compressed, loosen the diff bolt 1/8 to 1/4 of a turn. No more, no less. Your diff should now operate very
smoothly when turning the hubs in opposite directions. After you have driven the car once, recheck the diff adjustment. Never adjust
the diff any other way.
Now assemble the second diff the same way.
10
IMPORTANT NOTE: STEPS 5, 6, 7 AND 8 INVOLVE SETTING THE MESH OF THE BEVEL GEARS.
Be sure to use only one
shim on each side of the
differential

REMOVE THESE
PARTS FOR:
Steps 6-9
TOOLS USED
3914, qty 2
drive pinion
step 6
FRONT INPUT SHAFT ASSEMBLY
Install and center the #3919 dowel pin into the #3915 front
input shaft.
Trim burrs from the drive pinion edge where shown above.
Slide the #3914 drive pinion onto the input shaft. Make sure the
dowel pin aligns perfectly with the slot in the pinion.
Add the #3919 small E-clip.
Slide three #3911 input shaft shims and one #3977 or #6906 bearing
onto the #3915 input shaft.
3911 shim
3911, qty 6
input shaft
shim
1:1
3919, qty 2
small E-clip
3919, qty 1
large E-clip
3915, qty 1
front input shaft
3915, qty 1
rear input shaft
RACER KIT ONLY
3977, qty 4
3/16 x 3/8
bearing, rubber sealed
TEAM KIT ONLY
6906, qty 4
3/16 x 3/8
bearing, PTFE sealed
1:1
3917, qty 2
drive cup
6920, qty 2
4-40 x 3/16 screw
1:1
3919, qty 5
dowel pin
3917, qty 1
spur gear adapter
3919, qty 1
C-clip
1:1
RACER KIT ONLY
3977, qty 2
3/16 x 3/8
bearing, rubber sealed
TEAM KIT ONLY
6906, qty 2
3/16 x 3/8
bearing, PTFE-sealed
1:1
3915
input shaft
3919 pin
3914
drive pinion
3919
small E-clip
3917 drive cup 6920
step 7
REAR INPUT SHAFT
ASSEMBLY
Attach the #3919 C-clip to
the #3915 rear input shaft. (We've
included an extra C-clip in case you
lose one.)
Install the #3919 dowel pin into the input
shaft.
Slide on the #3917 gear adapter.
Add the #3919 large E-clip.
3919 C-clip
3915 rear input shaft
3919 pin
3917
3919 large E-clip
1:1
6288, qty 2
4-40 x 1/4
screw
7
step 8
Slide one #3977 or #6906 bearing and
three #3911 input shaft shims onto the
#3915 rear input shaft.
Install and center a #3919 dowel pin into the input
shaft.
Slide a #3914 drive pinion onto the end of the input
shaft. Make sure the dowel pin aligns perfectly with
the slot in the pinion.
Add a #3919 small E-clip.
RACER KIT ONLY
3977, qty 2
3/16 x 3/8
bearing, rubber sealed
TEAM KIT ONLY
6906, qty 2
3/16 x 3/8
bearing, PTFE sealed
1:11:1
3911 shims
3915 rear
input shaft
3919 pin
3914 drive pinion
3917 drive cup
6920
3922, qty 1
72T Kimbrough spur gear
1/16"
Slide the second #3977 or #6906 bearing onto the
input shaft.
Install and center the #3919 dowel pin into the input
shaft.
Slide a #3917 drive cup onto the end of the input
shaft.
Tighten it down with one #6920 screw.
3919 pin
front input shaft
assembled
PLEASE COMPARE
YOUR ASSEMBLY
CAREFULLY
REAR INPUT SHAFT ASSEMBLY
Slide one #3977 or #6906 bearing and one #3911
input shaft spacer onto the #3915 rear input
shaft.
Install and center one #3919 dowel pin into the
input shaft.
Slide a #3917 drive cup onto the input shaft.
Tighten it down with one #6920 screw.
3919
3919 pin
3915 rear input shaft
1:11:11:11:1
1:1
3911 spacer
5407
1:1
5407, qty 1
red O-ring
3911, qty 1
input shaft spacer, alum.
1:1
Trim any burrs from this
edge of the drive pinion
with a hobby knife.

step 9
REAR INPUT SHAFT ASSEMBLY
Slide the #3922 spur gear over the
drive cup and align it on the #3917
gear adapter.
Tighten down the spur gear with
two #6288 screws.
3922 spur gear
6288
6288
8
BAG C
REMOVE THESE
PARTS FOR:
Steps 10-12
TOOLS USED
1:1
6292, qty 8
4-40 x 3/8 screw
1:1
6924, qty 6
4-40 x 3/8 screw
3910, qty 2
lower transmission case
3910, qty 1
upper transmission case
FRONT TRANSMISSION
ASSEMBLY, LOWER HALF
Attach the #3910 lower
transmission case to the
chassis with four #6292
screws.
step 10 step 11 step 12
FRONT TRANSMISSION
ASSEMBLY
Install the diff assembly and front
input shaft assembly into the lower
transmission case.
Add a small amount of #6591 diff
lube to the front side of the ring rear
and pinion gear.
Attach the #3910 upper
transmission case to the lower case
with six #6924 screws.
REAR TRANSMISSION ASSEMBLY,
LOWER HALF
Attach the #3910 lower transmission
case to the chassis with four #6292
screws.
3910
6292
6292
6292
6292
6924
3910
6924
6924
6924
6924
6924
3910
6292
6292
6292
6292
1/16, 3/32
assembled
PLEASE COMPARE
YOUR ASSEMBLY
CAREFULLY
6591, qty 1
Assoc. diff lube
6591

step 13
REAR TRANSMISSION ASSEMBLY
Install the diff assembly into the lower
transmission case.
Place one end of the #3924 drive shaft
into the drive cup on the rear input shaft
assembly.
Install the opposite end of the drive shaft
into the front drive cup. Set the rear input
shaft into place.
Add a small amount of #6591 diff lube to
the front side of the ring gear and pinion
3924
drive shaft
REMOVE THESE
PARTS FOR:
Steps 13-14
TOOLS USED
1:1
6924, qty 8
4-40 x 3/8 screw
3924, qty 1
driveshaft
3910, qty 1
upper transmission case
3917, qty 1
drive bearing cap
step 14
REAR TRANSMISSION CASE
Attach the #3910 upper transmission
case to the lower case with six #6924
rear input shaft
drive cup
6924
6924
6924 6924
6924
9
3/32
step 15
DRIVE BEARING CAP
Align the #3917 drive bearing cap over
the bearing and attach with two #6924
screws where shown.
6924
3917
6924
6924
6591
front side
of gear
Do not overtighten the bearing
cap screws.
6591, qty 1
Assoc. diff lube

BAG D
REMOVE THESE
PARTS FOR:
Steps 1-4
TOOLS USED
1:1
3858, qty 4
long special
ball end, black
step 1
FRONT SHOCK TOWER ASSEMBLY
Install the two #7413 screws through the outer holes on the
#3881 front shock tower. Then thread on the #7260 nuts.
Attach the #3858 ball ends and #7260 nuts through the
lower inner holes on the shock tower.
Add a #6272 dust cover to the ball ends.
6272, qty 4
ball end dust cover
6924, qty 6
4-40 x 3/8 screw
7260, qty 8
4-40 plain nut
7413, qty 4
4-40 x 3/4 screw
3881, qty 1
front shock tower
3895, qty 1
rear shock tower
1:1 1:1 1:1
7413
7413
7260
7260
3858
3858
7260
7260
6272
6272
3881
step 2
FRONT SHOCK TOWER
ASSEMBLY
Attach the #3881 front
shock tower to the upper
transmission case with
three #6924 screws.
3881 6924
6924
6924
step 3
REAR SHOCK TOWER ASSEMBLY
Install the two #7413 screws through the outer holes on the
#3895 rear shock tower. Then thread on the #7260 nuts.
Attach the #3858 ball ends and #7260 nuts through the lower
inner holes on the shock tower.
Add a #6272 dust cover to the ball ends.
step 4 REAR SHOCK TOWER ASSEMBLY
Attach the #3895 rear shock tower to
the upper transmission case with
three #6924 screws.
7413
7413
7260
7260
3895
7260
7260
3858
3858
6272
6272
6924
6924
6924
10
1/16", 3/32"
1:1

BAG E
REMOVE THESE
PARTS FOR:
Steps 1-4
TOOLS USED
step 1
MIP CVD ASSEMBLY
Spread some Associated
#6588 black grease inside
the axle hole where shown,
then on the coupling and
insert the coupling into the
axle.
Slide the axle into the
dogbone, aligning the cross
holes.
Insert the cross pin, making
sure it is evenly spaced on
both sides of the bone.
Add the MIP thread lock to
the set screw. Angle and
turn the CVD so the set
screw can be screwed in
with the Allen wrench.
Repeat steps for the three
remaining CVD's.
3886 axle
7381, qty 4
CVD coupling
3886, qty 4
CVD axle
7381, qty 4
CVD cross pin
7381, qty 4
CVD set screw
3887 or 3888, qty 4
CVD bone
7260, qty 2
4-40 plain nut
1:1 1:1
6272, qty 2
ball end dust cover
6273, qty 2
long ball end
natural color
1:1
RACER KIT ONLY
3977, qty 4
3/16 x 3/8
rubber sealed bearing
TEAM KIT ONLY
6906, qty 4
3/16 x 3/8
PTFE sealed bearing
1:1
7368, qty 2
shim
7369, qty 2
CVD roll pin
3858, qty 2
long special
ball end, black
1:1
3875, qty 2
4-40 x 11/32 screw
with shoulder
3866, qty 2
front outer
hinge pin
3868, qty 2
front block carrier
(caster block)
3876, qty 2
front steering
block 6588, qty 1
black grease
step 2 STEERING BLOCK ASSEMBLY
Install one #3977 or #6906 bearing
on the axle. Slide the axle
assembly into the back of the
#3876 steering block.
Install the second #3977 or #6906
bearing into the steering block and
on the axle, followed by one #7368
thin spacer.
Insert the #7369 roll pin into the
axle.
Thread the natural color #6273
ball end into the bottom of the
#3876 steering block and add the
#7260 plain nut. Add a #6272 dust
cover over ball the end.
Repeat steps for the right side,
installing the steering block ball
end in the opposite way:
1:1
RACER KIT ONLY
3977, qty 4
3/16 x 3/8
rubber sealed bearing
TEAM KIT ONLY
6906, qty 4
3/16 x 3/8
PTFE-sealed bearing
1:1
5
6588
7381 coupling
3887 or 3888
dogbone
7381
cross pin
10
7381
set screw
7368
7369
7260
6273
6272
thread lock
3876
step 3
LEFT BLOCK CARRIER
ASSEMBLY
Break through and push out the
thin webbing in the holes with
your 2mm Allen wrench before
assembly.
Insert two #3874 steering block
bushings and steering block
assembly into the #3868 block
carrier as shown.
Make sure the CVD dogbone
goes through the hole of the
block carrier as shown.
Align the steering block and
block carrier and thread a
#3858 long special ball end
on top, and a #3875 screw on the
bottom. Add a #6272 dust cover
over the ball end.
Insert the 3862 5-40 set screw
into the bottom of the block carrier.
Do not thread it all the way in. We
will tighten it in the next step.
Repeat steps for the right side.
6
step 4
11
ATTACH BLOCK CARRIER ASSEMBLY
Place the left block carrier assembly between the
arm holes. Insert the #3866 front outer hinge pin
through the arm holes.
Tighten the set screw of step 3, locking the hinge
pin in place.
Insert the univeral dogbone into the slots of the
outdrive hub.
Now install the block carrier for the other side.
4
3866
3874
3874
3868
3858
3875
6272
1:1 1:1 1:1
1:1
1:1
1:11:1
3862, qty 2
5-40 set screw
gold
3874, qty 4
block carrier
bushings
1:1
1:1 1:1
3862
1/16", .050"
LONG NATURAL
COLOR BALL END.
DO NOT USE
THE BLACK BALL
END HERE!!

12
BAG E
REMOVE THESE
PARTS FOR:
Steps 5-6
TOOLS USED
7260, qty 2
4-40 plain nut
1:1 1:1
6272, qty 2
ball end dust cover
3858, qty 2
long special
ball end, black
7368, qty 2
3/16 axle shim
1:1
RACER KIT ONLY
3977, qty 4
3/16 x 3/8
rubber sealed bearing
TEAM KIT ONLY
6906, qty 4
3/16 x 3/8
PTFE sealed bearing
1:1
7369, qty 2
CVD roll pin
3862, qty 2
5-40 set screw, gold
4187, qty 4
washers, plastic
3866, qty 2
rear outer hinge pin
1:1
step 5
REAR HUB CARRIER ASSEMBLY
Break through and push out the thin webbing in the holes of
both hub carriers with your 2mm Allen wrench (as shown
above). Install one #3977 or #6906 bearing on to the axle. Slide
the axle assembly into the back of the #3876 rear hub carrier.
Install the second #3977 or #6906 bearing into the hub carrier
and onto the axle followed by one #7368 axle shim.
Insert the #7369 roll pin into the axle.
Thread on the #3858 long special ball end into the front of the
hub carrier as shown and add the #7260 plain nut. Add a #6272
dust cover over the ball end.
Repeat steps for the right side. See assembly picture at lower
right.
5
step 6
ATTACH REAR HUB CARRIER ASSEMBLY
Place the left hub carrier between the arm holes as shown and
add two #4187 spacers where shown. Insert the #3866 rear
outer hinge pin through the arm and hub carrier.
Thread in the #3862 5-40 set screw into the hub carrier.
Tighten down the set screw, locking the hinge pin in place.
Insert the universal dogbone into the slots of the outdrive hub.
Now install the hub carrier assembly for the right side.
4
1:1
RACER KIT ONLY
3977, qty 4
3/16 x 3/8
bearing
TEAM KIT ONLY
6906, qty 4
3/16 x 3/8
PTFE-sealed bearing
1:1
axle
3876
7368
3858
7260
6272
7369
4187
4187
4187
3866
3862
4187
BAG F
REMOVE THESE
PARTS FOR:
Steps 1-2
TOOLS USED
TEAM KIT ONLY
1356, qty 6
blue titanium turnbuckle
3879, qty 2
front chassis brace
3879, qty 2
rear chassis brace
6274, qty 12
ball cup
1:1
6923, qty 4
4-40 x 3/4 screw
1:1
6924, qty 8
4-40 x 3/8 screw
1:1
RACER KIT ONLY
3867, qty 6
steel turnbuckle
1:1 1:1
1:1
1:11:1
1/16"
1/16", 3/32"
hub carriers
assembled
3876, qty 2
rear hub carrier
1:1
1:1
LEFT REAR HUB
CARRIER SHOWN
LEFT REAR HUB
CARRIER SHOWN
Break through and
push out the thin
webbing in the
holes with your
2mm Allen wrench
before assembly.

step 1 TURNBUCKLE ASSEMBLY
Twist the #6274 ball cups onto the #1356 blue titanium
turnbuckle or #3867 steel turnbuckle until you get the dimension
shown for each part. Assemble all six turnbuckles.
Snap all six turnbuckles into place where shown, making sure
that all the universal bones are in the slots of the outdrive hubs.
62746274 1356 or 3867
front camber (X2)
1.53 in
62746274 1356 or 3867
steering (X2)
62746274 1356 or 3867
rear
camber
link (X2)
step 2 INSTALLING CHASSIS BRACE
Mount the #3879 left front and left rear chassis braces with two
#6924 screws and one #6923 screw for each brace as shown.
Repeat step for the right side.
Each chassis brace has a molded identification that indicates
where it goes on the car, as shown below.
2
6924
6924
6923
3879 6923
6924
6924
3879
43.7 mm
38.8 mm
LR
LF
BAG G
REMOVE THESE
PARTS FOR:
Steps 1-4
TOOLS USED
13
5407, qty 8
red O-ring 6465, qty 4
shock piston #2
5423, qty 1
40 wt
silicone oil
1:1 1:1
6469, qty 4
large O-ring
6299, qty 8
E-clip
1:1 1:1
TEAM KIT ONLY
8450B, qty 4
macro shock body
blue
8844, qty 4
shock shaft
8456, qty 4
VC foam
1:1
8456, qty 4
VC bobbin
6428, qty 4
shock cap
1:1
4187, qty 12
shock limiters
7217, qty 4
shock pivot ball
7217, qty 4
shock eyelet
RACER KIT ONLY
8458, qty 4
macro shock
body
1.72 in
FRONT
REAR
WHERE TO FIND THE CHASSIS BRACE I.D.
left front right front
right rear
left rear
(car shown
fully assembled)
1:1
1.72 in 43.7 mm
FRONT
REAR

step 1
6464
TRIM SHOCK PISTON
Burrs on the #6465 shock
piston interfere with smooth
shock action within the shock
body. To remove from tree
without creating burrs, twist up,
not down. Remove four #2
shock pistons.
Remove remaining burrs
carefully with a hobby knife.
burr
wrong
right
VC FOAM AND BOBBIN
Soak the #8456 VC foam
with #5423 40wt shock oil
and install it onto the
#8456 VC bobbin.
5423
OIL
8456
foam
8456
bobbin
assembled
step 2
step 3 Insert the assembly into the shock body
and pull the shaft through firmly to seat the
VC bobbin at the base of the shock bore.
Push the #7217 pivot ball and eyelet
together. As you hold the shaft with a rag
and needlenose pliers next to threads,
screw the eyelets onto the end of the
shock shaft.
TIP: Use a permanent marker to mark your
shocks with an F and R to designate front
and rear.
TEAM KIT ONLY: 8450B
RACER KIT ONLY: 8458
6469
5407
6299
6465
(#2)8844
7217 eyelet
7217
pivot ball
4187 front (4)
5423
OIL
6428
Holding the shock
upright, fill with oil
to the top of the body.
Slowly move the
shaft up and down
several times to
allow air bubbles
to escape to the top.
Refill with oil to the
top of the body.
Push the shaft up until
the piston is level with
the top of the body.
The oil will bulge up
above the shock body.
Fill The #6428 shock cap about
halfway with oil and install onto
the body. Try to retain as much
oil as possible during assembly.
The shaft will extend out as you
tighten the cap down.
step 4
SETTING THE
REBOUND
Move the shock shaft
in and out a few times
an then push it all the
way in. It should be
easy to push the shaft
in until the eyelet hits
the body
Then the
shaft should
push itself
out to its full
length very
slowly.
If the shock
does not push
out this far
there is not
enough oil in it.
Add just a little
oil and try
steps 6-7
again.
If the shock rebounds too
fast, or you cannot push the
shaft in until the eyelet hits
the body, there is too much
oil. Loosen the cap about a
full turn and pump out a small
amount of oil by pushing the
shaft in. Retighten the cap
and try steps 6-7 again.
4187
rear (2)
9
INTERNAL SHOCK
ASSEMBLY
(Assemble all four
shocks at once.) Install
the #6469 O-ring over
the threads of the
shock body.
On the #8844 shock shaft, install
a #6299 E-clip on both sides of a
#6465 (#2) piston from step #1.
Slide four #4187 limiters over two
front #8844 shock shafts and two
limiters over two rear #8844
shafts.
Slide the VC foam/
bobbin assembly over
the #8844 shaft and
then two #5407 O-
rings. Place a couple
drops of oil on the O-
rings.
6299
8844
OIL OIL
OIL
OIL
14

6472
BAG G
REMOVE THESE
PARTS FOR:
Steps 5-6
TOOLS USED
1:1
6925, qty 4
4-40 x 1/2 screw
6475, qty 4
spring collar
6475, qty 4
spring cup
3944, qty 2
spring, gold, front
3942, qty 2
spring, silver, rear
8846, spring preload spacer
qty 4 ea. 1/8"
qty 2 ea. 1/16"
1:1
6473, qty 4
shock bushing
15
step 5
FINAL SHOCK ASSEMBLY
Slide the 1/8" #8846 preload spacer
onto the body of the two front
shocks. Slide the 1/8" and 1/16"
preload spacers onto the rear
shocks.
Slide on the #6475 spring collar,
then #3944 gold spring on the front
shocks, and #3942 silver spring on
the rear shocks,.
Compress the spring to add the
8846
FRONT:1/8"
REAR:1/8" and 1/16"
6475
FRONT: 3944 gold
REAR: 3942 silver
6475
step 6
FRONT SHOCK MOUNTING
Add the #6473 shock bushing to the
shock tower.
Push the shock cap over the
bushing and add the #6472 nut. Do
not overtighten or the shock will
bind.
Fasten the lower shock into the arm
with the #6925 screw.
Do the other front shock.
step 7
6473
6472
6925
4
REAR SHOCK MOUNTING
Add the #6473 shock bushing to the
rear shock tower.
Push the shock cap over the
bushing and add the #6472 nut. Do
not overtighten or the shock will
bind.
Fasten the lower shock into the arm
with the #6925 screw.
Do the other rear shock.
4
6473
6925
BAG H
REMOVE THESE
PARTS FOR:
Steps 1-5
TOOLS USED
1:1
3858, qty 1
short special
ball end, black
3853, qty 1
battery brace
3930, qty 1
motor cam
3931, qty 1
motor clamp
(with heatsink)
3934, qty 2
3mm motor screw
4449, qty 2
4-40 locknut
6332, qty 2
battery clip
1:1
6917, qty 4
4-40 x 3/8 screw
1:1
6928, qty 1
4-40 x 1 screw
1:1
6916, qty 2
4-40 x 1/2 screw
with hole
7336, qty 2
servo mount
7336, offset spacer
qty 2, thin
qty 2, thick
1:1
7337, qty 4
steel washer
1:1
7673, qty 2
4-40 x 5/16 screw
9180, qty 4
servo horn
TEAM KIT ONLY
1356, qty 1
blue titanium turnbuckle
RACER KIT ONLY
3867, qty 1
steel turnbuckle
6727, qty 1
servo tape
6338, qty 1
antenna tube and cap
1:11:1
1:1 1:1
3848 qty 1
foam spacer
3/32"
1/16"
5/64"
3/32"
1:1
6272, qty 4
ball end dust cover
TEAM KIT ONLY
3902, qty 1
transponder mount
1:1
6472, qty 4
shock nut,
small
1:1
3939, qty 1
4-40 x 1.25 screw
3939, qty 1
motor clamp spring

16
step 1
ADD MOUNTS TO THE SERVO
Find the appropriate #9180 servo horn for your servo from the chart
at right. Install the #3858 ball end into the servo horn. Add the #6272
dust cover. Remove the servo horn from your servo and replace it
with the #9180 horn that you selected, then fasten with the stock
mounting screw that came with your servo in the position shown
below. DO NOT POINT IT STRAIGHT UP!See drawing for correct
dimension.
Find the appropriate #7336 offset spacer for your servo from the
chart at right. Attach the spacer, if any, in between the #7336 mount
and the servo with the #7337 washers and #6917 screws.
9180
SERVO TYPE SPACER SERVO ARM
Airtronics
94102 no spacer A
Airtronics
94155, 94156, 94157, 94158, 94257, thick spacer A
94258, 94737, 94738, 94741
Futaba
S3003, S9404, S9402, S9303, S3401, no spacer F
S9101, S9202
Hitec
S-300, HS-303, HS-525BB, HS-545BB, no spacer H
HS-422, HS-425, HS-605BB,
HS-615MG, HS-925MG, HS-945MG
JR
NES-4721, NES-4735, Z4750 no spacer J
JR
Z250, Z550, Z2750 thin spacer J
KO
PS-1012 FET, PS-2000 FET, no spacer J
PS-2001 FET, PS-2004 FET,
PS-2015 FET
On Futaba servo S3003 and on all KO servos you will need to trim a
little off the sides of the servo ears. We have not tested any servos that
were released after mid-1999.
3858
6272
7336
offset spacer
7336
servo mount
7337
6917
6917
7337
6917
6917
step 2
MOUNT THE SERVO
Mount the servo to the chassis with two #7673
screws.
Twist #6274 ball cups onto #1356 blue turnbuckle or
#3867 steel turnbuckle until you get the dimension
shown.
Use needle-nose pliers to attach the link to the ball
7673
1.56 in
6274 1356 or 3867
step 3
INSTALL YOUR MOTOR
Attach the #3930 motor cam to
the optional motor with two #3934
button head motor screws.
Install the optional pinion gear of your
choice. (Refer to the gearing chart on
page 19.)
Install the two #4449 locknuts to the
underside of the chassis. These fit tight,
so be sure to put them in straight and
all the way in.
Slide the motor and cam down into the
groove of the chassis.
3930
3934
3934
4449
4449
3931
6928 3928
6274
39.6 mm
trim edges
so servo
will fit
trim edges
so servo
will fit
Motor not included in kit.
Pinion gear not included in kit.
1/16" (1.5mm)
See page 19, Radio Adjustments,
for more info on correctly
setting steering linkage.
See page 19,
Radio Adjustments,
for more info on correctly
setting steering linkage.
3928
Screw down the #6928 inner
screw first until the #3931
motor clamp just touches the
chassis bulkhead.
Set your gear mesh.
Slide the #3929 spring onto the
#3929 screw and thread in only
until there is no free play
the screw and spring. Now tighten
the screw 2 to 3 turns. No more. It is
normal to have an approximately
.040"-.050" (1 to 1.2mm) gap remain
between the clamp and the
bulkhead, as shown.
6
Small gap,
.040-.050"
(1-1.2mm)
No gap
About .220"-.250" (5.5-6.5mm)
when correctly tightened

step 4
RADIO AND RECEIVER INSTALLATION
Cut a piece of #6727 servo tape and use it to
attach your optional ESC and switch where
shown.
Cut a piece of #6727 servo tape and use it to
attach your optional receiver where shown.
Connect the ESC and steering servo to your
receiver according to your radio or ESC
instructions. Then connect the motor to your
ESC.
Push your receiver wire through the built-in
antenna mount. Slide the wire through the
#6338 antenna and push the antenna firmly into
the chassis antenna mount hole. Cap the other
end of the antenna tube and wire with the black
rubber cap.
TEAM KIT ONLY
If needed, remove the transponder mount and
cut away all the gray areas as shown in
illustration.
Attach the mount to the servo where shown with
ESC
receiver
6338
3
step 5 BATTERY INSTALLATION
Install your battery pack. See
which figure, at left or right, best
represents your battery
orientation.
Thread on the two #6916
screws. Aim the body clip hole
across the chassis.
Add the #3848 foam spacer.
Add the #3853 battery hold
down strap, orienting it up or
down according to your battery
pack design. Adjust the screws
so the batteries are held tight,
but you are still able to push the
6916
6916
6916
6916
3853 3853
6332
6332
6332
6332
BAG I
REMOVE THESE
PARTS FOR:
Steps 1-2
6917, qty 2
4-40 x 3/8 screw
1:1
6922, qty 2
4-40 x 1/2 screw
3897, qty 4
pivoting body mount
8874, qty 2
rear body post
6332, qty 8
body clip
8818
6922
3848 3848
3852, qty 1
foam bumper
6338
8818
6922
1:1
switch
3902
TEAM KIT ONLY
cut out gray areas
TEAM KIT ONLY
attach mount here
17
8818, qty 2
front body post
TOOLS USED
1/16"
step 1
FRONT BODY
POSTS
Attach each
#8818 front body
post to the front
bumper with one
#6922 screw.

18
BAG J
REMOVE THESE
PARTS FOR:
Steps 1-2
TOOLS USED
6943, qty 4
8-32 locknut
step 1 step 2
TIRE ASSSEMBLY
Make a 1/8" hole in the #3951 TC3 wheel.
Insert the #3955 foam insert into the #3955 tire. Make
sure the insert is centered in the tire.
Install the #3955 tire and insert onto the #3951 wheel.
Glue the tire to the wheel with super glue (cyanoacrylic
glue) in four equally-spaced spots around the tire on
both sides. WARNING! Follow the adhesive
manufacturer's instructions for proper use and safety.
Wear eye and hand protection.
TIP: Place a rubber band around the tire to hold it tight to
the wheel while gluing.
Repeat steps for the three remaining tires.
MOUNT TIRES
Install the #3950 wheel hex adaptor to the axle, lining up the roll
pin with the slot in the hex adapter.
Slide the wheels over the axle and tighten it down with a #6943
lock nut.
Install the remaining tires.
3951
3950, qty 4
wheel hex adator
3951, qty 4
TC3 wheel
3955, qty 4
foam wheel insert
3955
3955
3950
6943
5
3
step 2 REAR BODY POSTS
Place the rear #8874 body post to the front side of the
rear shock tower. Align the tab and hole and attach it
with a #6917 screw.
Slide the #3897 pivoting body mount over the body
post so its holes line up with the fifth hole from the top.
(Adjust for proper hole later when you fit your body.)
Slide the #6332 body clip into the body post and
pivoting body mount. (You'll add another body clip after
you install your body.)
Do the other rear body post.
8
6332
3897
Line up the pivoting body mount
with the post holes
6917
3955, qty 4
TC3 tire
8874
FOAM BUMPER
Place the #3852 foam bumper
over the front body posts. (You
will trim it later to fit your body.)
Slide the #3897 pivoting body
mount over the body post so its
holes line up with the fourth
hole from the top. (Adjust for
proper hole later when you fit
your body.)
Slide the #6332 body clip into
the body post and pivoting
body mount. (You'll add
another body clip after you
install your body.)
Do both front posts.
6332
3897
3852
(after trimming)
4

FINAL ADJUSTMENTS
RADIO ADJUSTMENTS
Use the following steps to make the final adjustments
on your car.
1. Turn the transmitter on.
2. Make sure the motor is disconnected.
3. Connect your battery pack.
4. Turn the power switch on.
5. Move the steering control on the transmitter to the
right and left. Do the wheels move in the correct di-
rection? If not, you must reverse the steering servo
direction on your transmitter (see radio manual.)
6. Look at the servo horn mounted on the servo. It
should lean toward the centerline of the chassis about
1/8” (3mm).
7. Adjust the servo turnbuckle so that the steering
rack arm is EXACTLY in the center of the car.
8. Using the two steering turnbuckles, adjust the front
wheels so they are pointed straight ahead.
9. Adjust the ESC (electronic speed control) accord-
ing to the speed control manufacturer’s instructions.
Note: Some manufacturers have the motor connected
during adjustment and some do not. Now turn the
power switch off.
10. Connect the motor. Place your car on a block or
car stand so that all four wheels cannot touch any-
thing.Turn the power switch on again. Check the ESC
and steering settings you have made and then turn
the power switch back off.
10. Remember this! The transmitter is always the
FIRST TO BE TURNED ON and THE LAST TURNED
OFF.
CONGRATULATIONS!YOUR CAR IS NOW READY
TO RUN!
Make these adjustments before racing
MOTOR GEARING
To get the most from your motor, proper gearing is
important. The gear ratios listed in the chart are rec-
ommended starting gear ratios. Ratios can vary from
track to track, but you should not change the pinion
size more than one tooth from the recommended ra-
tio.
CAUTION! Increasing the pinion size by more
than one tooth can damage your motor from excess
heat.
FINAL OVERALL
MOTOR PINION SPUR DRIVE RATIO RATIO
24°ROAR stock motor 28 72 2.5:1 6.43
36°stock motor 26 72 2.5:1 6.92
16 turn modified motor 26 72 2.5:1 6.92
15 turn modified motor 25 72 2.5:1 7.2
14 turn modified motor 24 72 2.5:1 7.5
13 turn modified motor 23 72 2.5:1 7.83
12 turn modified motor 22 72 2.5:1 8.18
11 turn modified motor 21 72 2.5:1 8.57
10 turn modified motor 20 72 2.5:1 9.00
9 turn modified motor 19 72 2.5:1 9.47
MAINTENANCE
Follow these steps to keep your car in shape for racing
CHECK FOR FIT
You should periodically check all the moving parts:
front and rear end, suspension arms, steering blocks,
steering linkage, shocks, and so on. If any of these
should get dirty or bind then your car’s performance
will suffer.
MOTOR MAINTENANCE
Between runs, inspect the brushes to ensure they
are moving freely in the brush holder.This is done by
carefully removing the spring and sliding the brush in
and out of the holder. If there is any resistance or
rough spots, remove the brush and carefully wipe the
brush clean. This will clean off any buildup and lubri-
cate the brush so it slides smoothly in the brush
holder.
After every 3 to 5 runs, remove the brushes from
the holders and inspect the tips for wear and/or burn-
ing. If there is a noticeable amount of wear, replace
the brush with a new pair. If the tip is a burnt blue
color, then the lubricant in the brush has been burned
away and new brushes should be installed.
After every other battery charge you should care-
fully clean the motor. One recommended method is
to spray motor cleaner directly on the brush and com-
mutator area. Run the motor for approximately 15
seconds. Disconnect the motor and spray it again,
making sure the runoff is clear and clean. If the run-
off is still dirty, repeat the spraying action until clean.
After completing the cleaning, apply a small amount
of lightweight oil to each bushing or bearing for lubri-
cation. Be careful not to apply too much oil, for this
will pick up dirt and contaminate the commutator and
brushes. 19
FINISHING THE BODY
Before you start to mask and paint the inside of your
TC3’s body, wash it out with soap and water to re-
move any mold release residue or dirt that may show
up in your paint.
1. Mark the body post holes and rear wheel cutout
with a marker on the outside of the body.
2. Each body comes with pre-cut self-adhesive win-
dow masks for your convenience.
3. Be sure to use a paint that is specifically formu-
lated to adhere to Lexan. Spray several thin coats
(instead of one thick coat) to avoid runs. If possible,
spray your darker colors first.
4. After painting, trim the wheel wells with curved
scissors or a sharp hobby knife.
5. Trim out the rear wing and mount it to the body with
the supplied 4-40 button head screws and nylon nuts.
6. Finish by applying decals.

TUNING & SETUP TIPS
These tips prepare your car for maximum performance
DIFFERENTIAL ADJUSTMENT
1. Tighten the diff screw down until the T-nut reaches
the bottom of the diff hub slot and you feel the spring
fully compressed. Do not overtighten. When you feel
the spring fully compressed, loosen the diff bolt 1/8
to 1/4 of a turn. No more, no less.
2. Go ahead and run the car for approximately one
minute. Then recheck the diff adjustment by again
following step 1 above.Your diffs should be ready to
go now.
20
DIFFERENTIAL MAINTENANCE
You should rebuild the differentials when the action
gets somewhat “gritty”feeling. Usually cleaning the
diff parts and applying new lube per the instructions
will bring it back to new condition again. The stan-
dard 3/32”carbide balls rarely need replacing. Nor-
mally, as the parts seat, the diff will get smoother.
If the diff still feels gritty after carefully cleaning
and re-lubing the diff parts, the thrust balls, thrust
washers, and drive rings should be checked and pos-
sibly replaced.
The parts will normally wear out in the following
order:
1. #6575 5/64”diff thrust balls (qty 6).
2. #6573 diff thrust washers (2).
3. #6579 diff drive rings (2).
Refer to the differential section to correctly as-
semble the diff.
Your car is one of the most tunable on road cars on
the market. This section will try to explain the parts
and adjustments you can use to tune your car for
different track conditions.
CASTER describes the angle of the kingpin from
vertical when looked at from the side of the car. Posi-
tive caster means the kingpin leans rearward at the
top. Negative caster should never be used.
Associated makes block carriers for the TC3 with
0°(kit standard), 2°, and 4°of caster. Increasing caster
in the TC3 (with 2°or 4°block carriers) will give your
car more steering entering corners but less steering
exiting corners. It will also be more stable in bumpy
conditions.
Note: When figuring total caster in your car, add
the amount in the block carrier to the amount of kickup.
Example: 2°of kickup (kit standard) and 0°block
carrier equals total of 2°of caster.
Positive caster means the
kingpin leans rearward at
the top.
0°block carrier, #3868
2°block carrier, #3870
4°block carrier, #3872
FRONT
FRONT TOE-IN AND TOE-OUT is
adjusted by turning the steering turnbuckles. Toe-in
will make your car easier to drive by improving stabil-
ity during acceleration. Toe-out will increase steering
when entering corners but will be slightly more diffi-
cult to drive.We suggest using 0°to 1°toe-out on the
TC3.
Toe-in:
Easier to drive.
Improves stability during acceleration.
Toe-out:
Harder to drive.
Increases steering entering corners.
KICKUP AND ANTI-DIVE refers to the angle at which the front
suspension is mounted in relation to horizontal when looked from the side
of the car. Kickup and anti-dive are adjusted by changing the suspension
arm mounts, which have molded codes to help you tell them apart. The
three front arm mount combinations are as follows: The kit setting of 2° kickup
will work best in most con-
ditions, especially in bumpy
conditions.
0° kickup will have a more
aggressive steering feeling
but will not absorb bumps
as well as 2°.
2° anti-dive will have a very
aggressive steering feeling
and will improve front brak-
ing traction entering cor-
ners. However, this setting
will not work well in bumpy
conditions.
F F+2
F F-0
F-2 F-0
RECOMMENDED ARM MOUNT/BLOCK CARRIER COMBINATIONS
FOR THIS SETUP: USE THESE PARTS:
Arm Mounts Block Carrier
2°kickup, 2°caster F F+2 0°
2°kickup, 4°caster F F+2 2°
0°kickup, 0°caster F F-0 0°
0°kickup, 2°caster F F-0 2°
0°kickup, 4°caster F F-0 4°
2°anti-dive, 0°caster F-2 F-0 2°
2°anti-dive, 2°caster F-2 F-0 4°
EFFECTS OF ARM MOUNT/BLOCK CARRIER
COMBINATIONS
ARM MOUNT INFORMATION
code effect part #
F#3863 (std)
F+2 +2°kickup #3863 (std)
F-0 0°kickup #3864 (optional)
F-2 2°of anti-dive #3864 (optional)
BLOCK CARRIER INFORMATION
effect part #
0°caster #3868 (std)
2°caster #3870 (optional)
4°caster #3872 (optional)
BLOCK CARRIER/ARM MOUNTS PARTS
C
AB
A B C
A
B
C
1
2
FRONT
3
FRONT
B
A
BA
BA

21
REAR ANTI-SQUAT describes the angle
at which the rear suspension is mounted in relation
to horizontal when looked at from the side of the car.
The TC3 comes standard with 2°of rear anti-squat.
This provides good rear traction. Installing the #3864
(R3+0) rear arm mount reduces anti-squat to 0°and
will reduce rear traction. However, it will improve ac-
celeration in bumpy conditions and increase steering
slightly.
REAR ARM MOUNT INFORMATION
code effect part #
R#3863 (std)
R+3+2 3°toe-in & 2°anti-squat #3863 (std)
R+3+0 3°toe-in & 0°anti-squat #3864 (optional)
R+2+0 2°toe-in & 0°anti-squat #3864 (optional)
R+2+2 2°toe-in & 2°anti-squat #3864 (optional)
0°anti-squat will reduce
rear traction, but im-
prove steering slightly.
2°of anti-squat
is kit standard.
FRONT
REARTOE-INis adjusted by changing the rear
arm mounts.The TC3 comes standard with 3°of toe-
in on each side. This setting should work best in any
condition. However, if less toe-in is desired, install
the #3864 (R+2+2) or #3864 (R+2+0) rear arm
mounts. These mounts have 2°of toe-in and will de-
crease rear traction and add steering. (See rear anti-
squat details above for more info on the mounts.)
CAMBER describes the angle the wheels ride
relative to the ground when looked at from the front
or back. Negative camber means that the tire leans
inward at the top. Positive camber means just the
opposite, and should not be used. We suggest using
2°of negative camber at all times. However, more
negative camber can be used up to 4°for high trac-
tion conditions. Less than 2°can be used for low trac-
tion conditions.
Negative camber means
that the tire leans inward at
the top. Change camber by
turning the camber link.
CAMBER LINK LOCATIONS on the
TC3 have been thoroughly tested to find the best all
around positions. We suggest using the standard
setting for all conditions. However, if you must make
adjustments, the following guidelines should help you:
The longer or higher the link, the more traction and
less stability. The shorter or lower the link, the less
traction and greater stability.
Camber link possibilities for the rear tower and
hub carrier. Standard setup shown.
Camber link possibilities for the front tower. Standard
setup shown.
WHEELBASE ADJUSTMENT can be
made to theTC3 by moving the two #4187 1/32”plas-
tic spacers on the outer rear hinge pins (next to the
hub carrier).
Moving the spacers to the front of the hub car-
rier will lengthen the wheelbase and decrease rear
traction.
Moving the spacers to the rear of the hub car-
rier will shorten the wheelbase and increase rear trac-
tion.
RIDE HEIGHT describes the height of the
chassis in relation to the surface it is sitting on. This
adjustment must be made with the chassis ready-to-
run but with no body.The #8846 shock preload spac-
ers are used for raising and lowering the ride height.
We suggest starting with about 1/4”(6.3mm)
clearance between the chassis and ground. Try us-
ing a slightly lower right height for high traction con-
ditions such as carpet racing. Do not use a ride height
lower than 5/32”(4mm).
ACKERMAN is a term describing the effect of
the inside front wheel turning tighter than the outside
front wheel. The standard setup works best in most
conditions and will provide a very neutral driving feel-
ing.
By adding two .100”(2.5mm) spacers and the
longer #3858 ball ends to the steering rack, a more
aggressive steering feeling can be achieved. This is
because there will be less ackerman.
Ideal ride height is be-
tween 1/4”(6.3mm)
and 5/32”(4mm).
Optional ackerman.
For a more aggressive steering feeling.
Standard ackerman.
For a neutral steering feeling.
#3858
black
#3855
Adjust preload spacers to change
your ride height.
Spacers to rear
shorten your
wheelbase.
Spacers to front
lengthen your
wheelbase.
FRONT
#3858
black
short ball
end used
long ball
end used
