Astivita ASTCOOKE90 Installation and operating instructions
461307793_03/2015
INSTRUCTIONSANDADVICE
FOR INSTALLING, USINGAND SERVICING
OF COOKERS
2
The appliance was designed and made in accordance with the European standards listed below:
=> EN 30-1-1, EN 30-2-1 and EN 437 plus subsequent amendments (gas)
=> EN 60 335-1 and EN 60 335-2-6 (electrical) plus relative amendments
The appliance complies with the prescriptions of the European Directives as below:
=> 2006/95 EC concerning electrical safety (BT).
=> 2004/108 EC concerning electromagnetic compatibility (EMC)
=> 2009/142 EC concerning gas safety.
Oven accessories that could come into contact with foodstuffs are made with materials that comply
with the provisions of the 89/109 EC directive dated 21/12/88.
This product complies with EU Directive 2002/96/EC.
The crossed-out dustbin symbol reported on the appliance indicates that the appliance must be
disposed of separately from other domestic refuse at the end of its useful life. It must therefore be
delivered to a waste recycling centre specically for electric and electronic equipment or returned to
the retailer at the moment of purchase of a new equivalent appliance.
The user is responsible for delivering the appliance to the appropriate collection
centre at the end of its useful life, Failure to do so may result in a ne, as provided
for by laws governing waste disposal.
Differential collection of waste products for eventual recycling, treatment and environmentally friendly
disposal helps reduce possible negative effects on the environment and health, and also enables the
materials making up the product to be recycled.
For more detailed information on the available refuse collection systems, refer to the local Municipal
Solid Waste disposal centre or the shop where the product was purchased.
Producers and importers are responsible for fullling their obligations as regards recycling, treatment
and environmentally friendly disposal by directly or indirectly participating in the collection system.
ASSISTANCE AND SPARE PARTS
Before this appliance left the factory it was tested and set by specialized, expert personnel in order to guarantee
the best functioning results.
Any subsequent repairs or adjustments that may be necessary must be done with the maximum of care and
attention by authorised personnel.
Forthisreasonwerecommendyoualwayscontactus(referbelow),specifyingthebrand,model,serialnumberand
type of problem you are having with it. You will nd the relative data printed on a label afxed on the appliance and
on the label afxed to the packing box.
IMPORTANT NOTICE
The manufacturer shall not be held responsible for any damage to persons or property caused by incorrect
installation or use of the appliance.
For prompt warranty service, please ensure that the warranty registration form is completed and return posted
to us.
A duplicate data label and wiring diagram are contained in this booklet. Please attach these labels to an accessible
surface near by the appliance for easy reference.
You can purchase original spare parts from authorised dealers or direct from us.
3
ASSISTANCE AND SPARE PARTS 3
IMPORTANT NOTES AND PRECAUTIONS FOR USE 4-6
DESCRIPTION OF THEAPPLIANCE 7-11
INSTRUCTIONS FOR THE USER 12-21
TROUBLESHOOTING 22
INSTRUCTIONS FOR THE INSTALLER 23-30
TECHNICAL FEATURES 31-36
CONTENTS
SPACE FOR DATALABEL
4
IMPORTANT NOTES AND PRECAUTIONS FOR USE
You have purchased one of our
products for which we thank you. We
are condent that this new appliance,
modern, functional and practical, made
with top quality materials, will meet all
your demands. This new appliance
is easy to use but before installing
and using it, it is important to read
this handbook through carefully.
It provides information for a safe
installation,useandmaintenance.Keep
this handbook in a safe place for future
reference.
The manufacturer reserves the right
to make all the modications to its
products that it deems necessary
or useful, also in your interests,
without prejudicing its essential
functional and safety characteristics.
The manufacturer cannot be held
responsible for any inaccuracies due to
printing or transcription errors that may
be found in this handbook.
N.B.: the pictures shown in the gures in
this handbook are purely indicative.
• The installation, adjustments,
conversions and maintenance
operations listed in section
«INSTRUCTIONS FOR THE
INSTALLER»mustonlybecarriedout
byauthorised personnel .
• The installation of all-gas and combi
appliances must comply with the
standardsin force.
• The appliance must only be used for
its original purpose, that is, cooking
for domestic use. Any other use is
considered improper and, as such,
dangerous.
• The manufacturer cannot be held
responsibleforanydamagetopersons
or property resulting from an incorrect
installation,maintenance oruse ofthe
appliance.
• Once the packaging has been
removed from the outer surfaces and
the various inner parts, thoroughly
check that the appliance is in perfect
condition. If you have any doubts do
not use the appliance and call in an
authorisedperson.
• The packaging materials used
(cardboard, plastic bags, polystyrene
foam, nails, etc.) must not be
left within easy reach of children
because they are a potential hazard
source. All packaging materials used
are environmentally-friendly and
recyclable.
• The electrical safety of this appliance
is only guaranteed if it is correctly
connected to a suitable earth system,
as prescribed by the electrical safety
standards.Themanufacturerdisclaims
all responsibility if these instructions
are not followed. Should you have
any doubts, seek the assistance of an
authorisedperson.
• Before connecting the appliance
ensure that the rating plate data
corresponds to that of the gas
and electricity supply (see section
«TECHNICALFEATURES»).
• NOT FOR USE IN MARINE CRAFT,
CARAVANS OR MOBILE HOMES
UNLESS EACH BURNER IS FITTED
WITHA FLAME SAFEGUARD.
• DO NOT MODIFY THIS APPLIANCE
• DOMESTIC USE ONLY
WARNING - The appliance and its
accessible parts become hot during
use. Care should be taken to avoid
touching heating element. Children
less than 8 years of age shall be kept
away unless continuosly supervised.
5
• The oven door glass and the
accessible parts will become hot
when in use. To avoid burns and
scalds young children should be
kept away.
• Do not use this appliance as a space
heater.
• Do not touch any electrical appliance
ifhands or feetarewet ordamp.
• Do not use the appliance bare
footed.
• Do not pull the power lead to take the
plug out of the socket.
• Do not leave the appliance outside
underthe sun, rain,etc.
• Young children should be supervised
to ensure that they not play with the
appliance.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of esperience
and knolegde if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.Children shall not
play with the appliance. Cleaning
and user maintenance shall not
be made by children with out
supervision.
• WARNING - ln order to prevent
accidental tipping of the appliance, for
example by a child climbing over the
open oven door, or too high weights
are leant on the open oven door, two
chains must be screwed on the back
on the cooker and xed to the wall
with hooks .Ensure the chains are
taut .Please refer to instructions for
installation..
• Before cooking for the rst time,
ensure the oven is empty and its door
closed, heat the oven at maximum
temperature for two hours. This will
allow the protective coating on the
interior of the oven to be burnt off
anddissipatetheassociatedsmells.
Ensure adequate ventilation in the
kitchen whilst burning off and don’t
be alarmed by a little bit of smoke
during this process.
• Unattended cooking on a hob with
fatoroilcanbedangerousandmay
result in re.
• Never try to extinguish a re with
water, but switch of the appliance
and then cover ame e.g. with a
lide or a re blanket .
• Danger of re: Do not store items
on the cooking surfaces
• Donotuseharshabrasivecleaners
or sharp metal scrapers to clean
the oven glass door since they can
scratch the surface, which may
result in shattering of the glass.
• NEVER use sponges or abrasive
products, and solvents to remove
stains or adhesives on the painted
or stainless steel surfaces.
• Switchofftheovenbeforeremoving
the fan guard for cleaning. Replace
the guard after cleaning in
accordance with the instructions.
• The oven can be equipped with
temperature probe. Only use the
temperature probe recommended
for this oven by our Service
Centre.
• Remove any spillage from the lid
before opening.
• The appliance is not intended to be
operated by means of an external
timer or separate remote-control
system
• Ensure that the appliance is
switched off before replacing the
lamp to avoid the possibility of
electric shock..
IMPORTANT NOTES AND PRECAUTIONS FOR USE
6
IMPORTANT NOTES AND PRECAUTIONS FOR USE
• The cookers can be equipped with
a small compartment under the
oven that can be used for storing
things Remember that the surfaces
becomehot,itisstrictlyforbiddento
place inammable materials inside.
• Donotuseasteamcleanertoclean
a hob, oven or range.
• The appliance is to be placed directly
on the oor and shall not be mounted
ona base.
• If the appliance is tted with a glass
lid, this can shatter when heated.
Turnoffalltheburnersordisconnect
alltheplates,andallowthemtocool
before closing the lid (g.3)
• Avoidusingthe ovenas alarder oras
a saucepan cupboard when you are
not using it for cooking: if the oven is
turned on accidentally it could cause
damageand accidents.
• If you are using an electrical socket
near the appliance, make sure that
the cables are not touching the cooker
and are far enough away from all hot
parts.
• When you have nished using the
appliance check that all the controls are
in the off or closed position, checking
that the “0” of the knob corresponds to
the“•”symbolserigraphedonthefront
panel.
• Switch off the electrical supply before
you start cleaning or servicing the
appliance.
• In the case of a failure or malfunction,
turn the appliance off and switch off
theelectricalsupplyanddonottamper
withit.Allrepairs oradjustments must
becarriedoutwithmaximumcareand
the proper attention of an authorised
person.
• For this reason we recommend you
callour Service Centre.
7
1 2
1
PRESENTATION
GENERAL
There are 2 different hobs that can be used on our
cookers: all gas and all electrical (with heating
elements in ceramic glass).
Each knob on the front panel has a diagram printed
above it showing to which burner it refers.
The combination of the different sized burners offers
the possibility of various types of cooking.
Our cookers are equipped with an electronic programmer,
which makes it possible to use the left oven without
supervision.
To guarantee the customer a good and safe use of
the appliance,
the cookers have equipped with a
safety temperature device
(1 for each oven)
which
automatically turns on in case the main thermostat
fails to work.
In such an event, the electricity is interrupted temporarily:
do not attempt to repair it yourself but turn the
appliance off and contact your nearest Assistance
Centre.
DESCRIPTION OF THEAPPLIANCE
The oven walls are tted with various guide bars or
runners (g. 1) on which the following accessories can
be placed. Supply and quantities vary from model
to model (g. 2):
• oven shelf rack. Ensure shelf is located with dish
and tray stop pointing upwards and at rear of oven.
• drip tray (*)
• handle (*)
• drip tray grid
(*) Only certain versions.
The cookers are equipped with a small compartment
under the oven that can be used for storing things.
Remember that the surfaces become hot, it is
strictly forbidden to place inammable materials
inside.
8
CONTROLS
HOB GAS BURNER KNOB (A)
By rotating the knob in an anticlockwise direction, the
following symbols appear:
0= Closed position
= “Full on” position
= “Reduced rate or Low” position
OVEN THERMOSTAT KNOB (B)
By turning the oven knob clockwise we will nd the
different oven temperature values (from 50°C to
Max).
FAN OVEN FUNCTION SELECTOR KNOB (8) (C)
By turning the knob to the right or to the left we will nd
the following symbols:
0= Oven off
= Oven light on, which stays on for all functions
= Fan on
= Top and bottom heating elements on
= Top and bottom heating elements and fan on
= Bottom heating element and fan on
= Rear heating element and fan on
= Grill heating element on
= Grill heating element and fan on
THERMOSTAT KNOB FOR GAS OVENAND
ELECTRIC GRILL (D)
By rotating the knob in an anticlockwise direction, the
following functions appear:
0= Closed position
from Min to Maxi (260°C) = Oven temperatures
Turn the knob clockwise if you want to use the electric
grill .
DESCRIPTION OF THEAPPLIANCE
A
B
D
C
9
DESCRIPTION OF THEAPPLIANCE
G
OVEN FUNCTION SELECTOR KNOB (4) (G)
By turning the knob to the right or to the left we will nd
the following symbols:
0= Oven off
= Oven light on, which stays on for all functions
= Defrost
= Fan forced heating element and fan
= Grill heating element
E
F
ENERGY REGULATOR KNOB (E-F)
By turning the knob to the right we nd the following
symbols:
0= heating elements off
from 1 to 12 = minimum and maximum power for single
cooking zone
from 12 to 0 = maximum power for double cooking zone
10
DESCRIPTION OF THEAPPLIANCE
ELECTRONIC CLOCK
This accessory functions as a clock and a minute
counter. The digital display always shows the time but
will display the minute counter time when this function
is set.
Setting the time (from 0.01 to 24.00 - hh,mm)
Afterconnecting to theelectricity mainsor subsequent
to a power cut the gures “0.00” will ash on the display.
Press push button 1 and start setting the current time
by pressing push button 2 or 3. The function will start 7
seconds after setting.
Minute counter (from 0.01 to 0.99 = hh,mm)
By selecting the time on the minute counter with push
button 3, this function will be active all of the time (time is
set in 10 second units). The time will disappear leaving
the minute counter time showing on the display and the
symbol lights up. Time is given in seconds during
countdown. At the end of the set time the buzzer goes
off, the symbol disappears and the time reappears.
You can see the time while the minute counter is
functioning by pressing push button 1.
Buzzer
The buzzer goes off at the end of the minute counter
function and lasts about 7 minutes. The buzzer can be
stopped by pressing button 3.
Buzzer intensity
There are three different buzzer intensities: to select
the one you want press push button 2 when the time
is displayed.
Correcting/cancelling the minute counter function
Tocorrectorcancelthetimesetontheminutecounter,
press keys 2 and 3 simultaneously and then release
key 3 rst. The time can be corrected at any moment
by pressing push button 1 followed by 2 or 3.
SWITCHING THE HEATING ELEMENTS
The cooking zones are clearly visible on the hob, being
circular.
Only the inside of the circles traced on the glass is
heated.
Thehobhasabuilt-inwarninglightthatswitchesonwhen
the temperature in the cooking zone exceeds 60°C. This
warning light will only switch off when the temperature in
the cooking zone has gone below this value and it is for
thisreason itis calledthe “residual heat warning”.
The heating elements with a single ccoking zone, are
controlled by energy regulators with 12 positions (E) that
permitto obtaina bigrange of different temperatures.
The heating element with a double cooking zone, are
controlled by12-position energy regulators(F).
By turning the knob from 1 to 12, the powers of the rst
zone of cooking “1” are regulated. By turning besides the
number12,areleaseitiswarnedthatsignalstheinsertion
of the second zone of cooking “2”
In this position, both work the zone of cooking to the
maximum power. By turning the knob counterclockwise
to regulateits power.
Only returning on the position “0” the second zone of
cooking is disconnected.
A red coloured warning light signals that the heating
elementsare on.
H
RED WARNING LIGHT
When lit it indicates that the electric grill or one of the
oven electric components is on.
YELLOW WARNING LIGHT
When lit it indicates that either the electric oven or
electric grill is working. While the oven is being used
the light will switch off when the set temperature is
reached. During baking it is normal for the yellow light
to switch on and off several times as the oven tempe-
rature is controlled.
OVEN FAN BUTTON
OVEN LIGHT SWITCH
11
DESCRIPTION OF THEAPPLIANCE
ELECTRONIC PROGRAMMER
The programmer can select the following functions:
- Clock (set by keys 2 and 3)
- Minute counter (set by key 1)
- Cooking time (set by key 2)
- End of cooking (set by key 3)
- Manual operation mode (set by key 4)
- Setting time backwards (set by key 5)
- Setting time forward (set by key 6)
The digital display (N) always shows the time and
can display cooking and end of cooking time or the
minute counter time by pressing the corresponding
push button.
N.B.: At the end of each setting session (except
for the minute counter) the programmer turns the
oven off. Check when next using the oven, if the
programmer is not going to be used, that the latter
is set on manual operation (see the instructions
given further on).
Setting the time (from 0.01 to 24.00 = hh,mm)
Afterconnecting to theelectricity mainsor subsequent
to a power cut, AUTO and “0.00” will both ash
simultaneously on the display.
Press push buttons 2 and 3 simultaneously and start
setting the current time by pressing push button 5 or 6.
Once set the AUTO symbol will turn off and
the symbol, for manual operation, will turn on.
Minute counter (from 0.01 to 0.59 = hh,mm)
Press push button 1 and select cooking time with push
button 5 or 6. The symbol turns on. At the end of
the set time the buzzer will go off and the symbol
turns off.
Semi-automatic operation
(with cooking time from 0.01 to 23.59 = hh,mm)
By pressing push button 2 and setting the length of
cooking time with push button 5 or 6, the AUTO and
symbols will light up and stay on all the time. At
the end of the set time the symbol will turn off, the
AUTO symbol will ash and the buzzer will go off.
Semi-automatic operation
(withend of cooking timefrom 0.01 to 23.59 =hh,mm)
By pressing push button 3 and setting the end of
cooking time with push button 6, the AUTO and
symbolswillturnonandstayonallthetime.At the end
of the set time the symbol will turn off, theAUTO
symbol will ash and the buzzer will go off.
Automatic operation
(with the start of cooking time delayed)
First programme cooking time (both the AUTO and
symbol will turn on) and then the end of cooking time
(the symbol will turn off) as described previously.
The symbol will turn on again when baking in the
oven starts. At the end of cooking time the symbol
will turn off, the AUTO symbol will ash and the buzzer
will go off.
Manual operation
Manual operation is only possible when the automatic
programming has nished or after having cancelled
it by pressing push button 4. The AUTO symbol
disappears and the symbol turns on.
Buzzer
The buzzer will go off at the end of a programme or at
the end of the minute counter function and lasts about
7 minutes. The buzzer can be stopped by pressing
one of the function push buttons.
Programme start and control
The programme starts after setting. The programme
set can be controlled at any time by pressing the
corresponding push button.
Correcting/cancelling the programme setting
An automatic function programming error will occur if
the time shown on the clock is between the cooking start
time and cooking end time. This error will be signalled
immediately by a buzzer and the AUTO symbol will
ash. A setting error can be corrected by altering the
duration or end of cooking time. Any programme that
has been set can be corrected at any time by pressing
the corresponding programming key and then key 5 or
6. To cancel a programme, correct the time set bringing
it to a value of “0.00”. If functioning time is cancelled
the end of functioning is cancelled too and vice versa.
Theoven turnsoffautomaticallyandtheAUTOsymbol
ashes. Press key 4 to set the programmer on manual
operation. The right time cannot be corrected when
the automatic operation programme is working.
12
HOB: GENERAL NOTES ON SAFETY
• Make sure that pan handles are positioned correctly
and supervise the cooking of foods which use oils
and fats, as these are highly inammable.
• Do not use aerosols or sprays near the appliance
when it is in use.
• Even after use, the burners remain hot for a long
period; to avoid burning, do not place hands or
other objects on them.
AUTOMATIC ELECTRIC IGNITION OF COOKTOP
BURNERS
Push lightly the knob which corresponds to burner
to be ignited and turn anti clockwise to the “Full On”
position, then depress the control knob.
Automatically the ignition spark shoots. If there is no
electric power the burner may be lit with matches.
OPTIMUM USE OF COOKTOP BURNERS
In order to achieve maximum efciency with minimum
gas consumption it is useful to remember:
• Donotuselargeburnerswithpansofsmalldiameter
in order to avoid ames spreading wider than pans
(consult the following table) and always use pans
with lids (g. 3).
• When the boiling point is reached, it is best to turn
the knob to the “Low position”.
• Avoid using over sized pans that may radiate
excessive heat and cause damage to surrounding
surfaces such as bench tops and glass lid.
• Do not place anything, e.g. ame tamer, asbestos
mat, between pan and pan support, as serious
damage to the appliance may result (g. 4).
• Locatepancentrallyovertheburnersothatisstable
and does not overhang the appliance (g. 5).
• If gas burns with a yellow ame, do not continue to
use burner and arrange for service.
• Do not use burners without the proper pan support or
wok stand, as this will concentrate and deect the heat
onto the hotplate (g. 6) and surrounding surfaces.
• Use only a wok support supplied or recommended
by the manufacturer of the appliance (g. 7).
Warning: Servicing should be carried out only
by authorised personnel.
INSTRUCTIONS FOR THE USER
5
4
67
3
Burners Ø pan cm
Wok 22 - 24
Large 20 - 22
Medium 16 - 18
Small 12 - 14
13
INSTRUCTIONS FOR THE USER
GENERAL INFORMATION AND INSTRUCTIONS
FOR USING CERAMIC GLASS HOBS
• Ceramic glass is a natural product and, like any other
material in ceramic, can have an uneven surface. You
might evensee somebubbles inside theceramic glass
itself: these will not inuence cooking or the lifetime of
thehob.
• Illumination of the single cooking zones might differ.
This depends on the technical characteristics of the
heating elements. This has absolutely no effect on
quality oroperation.
• According to how you look at it, the incandescent
heating might appear to go over the edge of the cooking
zone.
• Donot put veryhot pans onthe outeredge of thehob.
• Do not use pans with aluminum bottom.
• Do not use the hob as a work top and take care not
to let hard or sharp objects fall on it. The top could be
damaged.
• Do not put empty enamelled pans on the heat. Both
the bottom of the pan and the ceramic glass could be
damaged.
• Do not drag pans or other objects over the glass top
whichcould get scratched.
• Clean anddry thebottom ofthe panbefore puttingit on
the hob.Salt, sugaror grains ofsand, forexample, that
couldbe in greens,can scratch.
• Cleanoffimmediately any spilledliquid.
• Do not cook or reheat food wrapped in tin foil or plastic
containers. Both the tin foil and the plastic containers
would melt, sticking to the hob.
Position of knobs Heat intensity Possible cooking processes
0Off
1-2 Low To dissolve butter, chocolate, etc. To heat small amounts of liquid.
3-4 Moderate To heat greater quantities of liquid.
5-6 Slow Thawing frozen food and preparing stews, boiling or simmering.
7-8 Medium Bringing foods to boiling point. For delicate roasts and sh.
9-10 Strong For roasts, chops and steaks. For large amounts of boiled meat.
11-12 Hot Bringing large amounts of water to the boil. Frying.
GOOD QUALITY
FLAT BASE CONVEX
BASE TOO CONCAVE
BASE TOO
SMALL TOO
LARGE
NO PAN
ELEMENT
N.B.: Usingthe glass scraper, push immediatelyaway
from thecooking zone,any piecesof tin foilor plastic
objects that could have melted or stuck; likewise
sugar or sugary food spilled over during cooking.
HOW TO SAVE ELECTRICITY
To get the maximum yield with the minimum
consumption of electricity it is recommended to keep
the following points in mind:
• Switch the hob heating element on only after you
have put the pan on the cooking zone or plate
• Thoroughly dry the bottom of the pan before putting
it on the cooking zone or plate.
• Donotusepanswithadiameterthatislessthanthat
of the cooking zone or plate. When you are buying
saucepans keep in mind that the manufacturer
usually gives the largest diameter of the pan which
is normally bigger than the base diameter.
• Use pans with at, thick bottoms. Bottoms that are
not at will make cooking times longer.
• Always put a lid on the pan.
• If cooking time is longer than 40 minutes you can
switch the plate off 5 to 10 minutes before the end
of cooking time and make use of the residual heat.
• For your information only, the table gives hints on
how to use the cooking zones and plates.
14
OVEN: GENERAL SAFETY INSTRUCTIONS
• Alwaysgripthecentreofthe ovendoorwhenopening.
Donot practiceexcessivepressuresonthe doorwhen
it is open.
• Do not worry if condensation forms on the door and
on the internal walls of the oven during cooking. This
does not compromise its efciency.
• When opening the oven door, be very careful of
scalding vapours.
• During use the appliance becomes hot. Care should
be taken to avoid touching heating elements inside
the oven. Wear oven gloves when placing or removing
pans from the oven or use the handle (D) (g. 2)
provided. Hook the handle to the edge of the tray and
pull it out, slightly lifting it as you do so.
• When inserting or removing food from the oven,
check that excess juices do not overow onto the
oven base (oils and fats are highly inammable when
overheated).
• Use containers that will resist the temperatures
indicated on the thermostat knob.
• Never coverthe base ofthe oven orthe ovenshelf with
aluminium foil or other materials, as this creates a re
hazard.
• When grilling always put a little water in the grill pan.
The water prevents the grease from burning and from
giving off bad smells and smoke. Add more water
during grilling to compensate for evaporation.
• After using the appliance ensure that all the controls
are in the off position.
IMPORTANT!! Always keep the oven door closed
during baking or grilling.
INSTRUCTIONS FOR THE USER
8
WHAT TO DO THE FIRST TIME YOU USE THE OVEN
• Remove all protective wrapping materials from the
appliance and labels from the oven door.
• Remove combustible materials from the warming
compartment before commissioning the cooker.
• Before cooking for the rst time, heat the oven at
maximum temperature for 2 hours. This will allow the
protectivecoatingontheinterioroftheoventobeburnt
off and expel the associated smells. Ensure adequate
ventilation in the kitchen whilst burning off and don't be
alarmed by a little bit of smoke during this process. At
the end of this time period, allow the appliance to cool
down and then clean the interior using hot water and
a delicate detergent. Also wash all the accessories
(grills, trays, spit roast, etc.) before use.
Prior to any cleaning, disconnect the appliance
from the electricity mains.
HOW TO USE GAS OVEN AND ELECTRIC GRILL
The appliance is equipped with an aluminium
shield (B), which works in order to obtain a
burnishing uniform above all during the baking
of cakes and biscuits. During oven operation, the
shield must be correctly positioned on the oven
bottom plate (g. 8)
15
INSTRUCTIONS FOR THE USER
9
AUTOMATIC ELECTRIC IGNITION OF THE OVEN
BURNER
Open the oven door, push lightly the oven knob
and turn anti clockwise to the maximum temperature
position, then then depress the control knob.
Automatically the ignition spark shoots.
Check through the opening that it has ignited. Continue
to push gas control knob for 15 seconds after ignition
has occurred. If ignition does not occur, turn gas
control knob off, open the warming compartment door
and wait 60 seconds to allow gas to disperse, then
repeat ignition procedure. Note: At the end of this
operation, correctly put again the shield (S) (g. 8).
Take care to not scratch the enamel of the bottom
plate, moving this shield.
MANUAL IGNITION OF THE OVEN BURNER
In the event of power failure or component malfunction,
manual ignition of the oven can be obtained by repeating
the above steps, but instead of pushing ignition button,
placing alit matchat theaccess hole (B)in thebase plate
(g. 9).
USING THE OVEN
Having ignited the oven, the gas control knob should be
adjusted to the desired temperature and gently close the
door to avoid extinguishing the ame. Preheat the oven
forapproximately 15minutes
Your appliance’s heat circulation pattern is quite different
to many other cookers. It employs an ingenious, natural,
“Rapid Draught” convection system. Hot air is efciently
circulated through the oven very quickly producing relatively
evenheatzoning.
With planning and a clear understanding of your
appliance’s characteristics and capabilities you will
be able to produce superb results and larger than
normal quantities. Howeverin order to obtain maximum
efciency it is useful to remember:
• Cooking times and shelf positions will probably be
different from your previous oven. The size and type
of dishes used will affect cooking times and the use
of aluminium foil will increase cooking times. We
recommend doing a test bake, and comparing the times
in the time and temperature chart to some of your
favourite recipes. Add 10 to 15 degrees C when
cooking larger quantities. Shelves are numbered
from the bottom (g. 1).
• Be sure to remove the enamelled grill tray when the
oven is in use. It is not intended to be used for baking
or roasting purposes and it can interfere with heat
distribution in the oven.
• The larger capacity ovens of the cookers 90 x 60, will
require slightly higher cooking temperatures than a
smaller oven.Add between 5-10 degree C.
• Slightlymoreheatisgeneratedfromthebottomofthe
ovenupwards,withthetopshelf being themarginally
cooler zone. This is the reverse of other ovens you
may have used and some minor adjustment to your
cooking methods with some dishes may be required.
Most baking would be done on the middle shelves,
with the lower shelves being used for a greater
degree of base browning.
• Always preheat the oven when cooking frozen or
chilled foods.
• Best results are achieved when preparing large
quantities or using two shelves simultaneously by
positioning serves with an "air space" around. More
even cooking can be made possible if two medium
sized baking trays are used per shelf, leaving a 3-4
cm "air space" between the trays and from the trays
to the oven wall. A single larger tray may divert or
block the usual ow of hot air around the oven. When
usingtwoshelvessimultaneouslyallowan"airspace"
by leaving one shelf space empty between.
• You can plan batch baking to make the most efcient
use of the hotter and cooler zones, by cooking a
different food requiring slightly different temperature
on each shelf e.g. small cakes and slab cakes, or two
different types of biscuits (see COOKING / BAKING
TIMETABLE paragraph)
• Light weight, uncoated aluminium trays and pans
are recommended for general cooking. Heavy gauge
and dark coloured utensils do attract extra heat and
may be unsuitable for some foods.
Contact our Service if assistance is required with
cooking results or thermostat operation appears
incorrect.
16
INSTRUCTIONS FOR THE USER
10
SWITCHING THE ELECTRIC GRILL
Turn the oven knob round to the symbol or .
The top heating element is turned on and it distributes
heat directly onto the food.
The red warning light will come on to indicate that the
grill heating element has been activated.
An automatic thermostat regulates the inner
temperature.
Besides grilling, it can be used to slightly brown
cooked food.
USING THE GRILL
• The grill is located in the top of the oven and makes
for an extremely versatile and controllable method
of cooking.
• Preheat the grill for a few minutes for quicker
cooking and more succulent results. Preferably add
seasonings after cooking is completed
• The food should be seasoned before cooking. Oil
or melted butter should also be spread on the food
before it is cooked.
• Foods to be grilled should be placed directly on the
shelf. Then place this on the oven shelf required.
Use the oven tray to collect any meat juices (g.
10)
• With electric grill the oven door must be kept
closed.
• The grill offers a xed heat setting but, a great
degree of heat control is possible by selecting the
most suitable oven shelf position for grilling the
particularfood. The lower theshelf, the less intense
the heat. This ability to adjust shelf positions also
allows for a range of bulky foods to be prepared
under the grill which ordinarily couldn't be prepared
in a standard grill compartment. Use Shelf 3 or 4 for
thick cuts of meat, sh llets or chicken pieces.
Use Shelf 2 for larger portions of foods, such as
half chicken, whole sh or browning the tops of
casserole dishes etc.
• Thegrill tray allows an array of foodstobeprepared
under the grill. The most intense heat is directly
beneath the grill burner. Foods requiring more
gentle heat can be placed around the perimeter
of the tray where heat is not quite as intense, for
example, seafood or vegetable kebabs, savouries,
warming hamburger buns or keeping foods warm.
Cooking with the aid of the fan
Some cookers can be equipped with a fan installed
in the rear part of the oven compartment. This can be
activated by pressing the fan switch .
After the fan has been activated, the heat will be
quickly and regularly distributed throughout the oven,
thus allowing different foods to be evenly cooked on
several shelves at the same time, also reducing the
cooking times.
17
HOW TO USE THE FANNED OVEN
DEFROSTINGAT ROOM TEMPERATURE
Turn the selector knob to the symbol and place the
food you want to defrost inside the oven.
The length of time required depends on the quantity
and type of food.
Selecting this function will only activate the fan. Mild
air circulation around frozen food will slowly defrost it.
It is particularly suitable for fruit and cakes.
FAN FORCED COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature, then
place your food inside the oven.
If pre-heating is recommended wait till the thermostat
yellow warning light turns off before placing foods
inside oven. This function activates the rear heating
unit and the fan distributes the heat produced. This
combination allows for a fast and even cooking of
several different foods placed on the diverse levels of
the oven.
CONVETIONAL GRILL COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature.
Selecting this function the top central heating element
turns on and heat is distributed directly on food
surface.
Apartfromgrilling,thisfunctionisidealtoaddagolden
roast to your recipes or to toast bread slices.
When you use the grill, do not forget to place the
drip pan beneath it to collect any sauce dripping, as
suggested in the “USEFUL COOKING TIPS “ section.
INSTRUCTIONS FOR THE USER
18
INSTRUCTIONS FOR THE USER
HOW TO USE THE MULTIFUNCTION OVEN
DEFROSTINGAT ROOM TEMPERATURE
Turn the selector knob to the symbol and place the
food you want to defrost inside the oven.
The length of time required depends on the quantity
and type of food.
Selecting this function will only activate the fan. Mild
air circulation around frozen food will slowly defrost it.
It is particularly suitable for fruit and cakes.
TRADITIONAL COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature.
If pre-heating is recommended wait till the thermostat
yellow warning light turns off before placing foods
inside the oven. This option turns on both bottom and
top heating units, evenly distributing heat on your
foods.
This type of cooking is ideal for all kind of foods (meats,
sh, bread, pizzas, cakes..).
COMBINED TRADITIONAL + FAN COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature.
If pre-heating is recommended wait till the thermostat
yellow warning light turns off before placing foods
inside the oven. This option turns on both bottom
and top heating units, and heat is distributed by fan
ventilation.
This combination is suitable for rapid cooking and
allows for the use of more plates positioned on the
different levels of the oven.
DEFROSTING + WARM UP BY HOTAIR
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature, then
place the food inside the oven. Selecting this function
will activate the bottom heating unit and its heat is
distributed by the fan. This function is particularly
recommended to defrost and warm up ready-made
meals.
FAN + REAR HEATING COMBINED COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature, then
place your food inside the oven.
If pre-heating is recommended wait till the thermostat
yellow warning light turns off before placing foods
inside oven. This function activates the rear heating
unit and the fan distributes the heat produced. This
combination allows for a fast and even cooking of
several different foods placed on the diverse levels of
the oven.
CONVETIONAL GRILL COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature. Selecting
this function the top central heating element turns on
and heat is distributed directly on food surface.
Apartfrom grilling, thisfunctionisidealtoaddagolden
roast to your recipes or to toast bread slices.
The grill function automatically activates the spit.
When you use the grill, do not forget to place the
drip pan beneath it to collect any sauce dripping, as
suggested in the “USEFUL COOKING TIPS “ section.
FAN GRILL COOKING
Turn the selector knob to the symbol and adjust the
thermostat knob to the desired temperature (MAX
200°C).Selecting this function the top central heating
element turns on and heat is distributed by the fan.
This procedure mitigates the direct heat on food
surface and uses milder temperatures. It is therefore
recommended for an even golden and crispy nish
touch, ideal for whole sh and poultry.
When you use the grill, do not forget to place the
drip pan beneath it to collect any sauce dripping, as
suggested in the “USEFUL COOKING TIPS “ section.
19
INSTRUCTIONS FOR THE USER
USEFUL COOKING TIPS
Cakes and bread:
• Heat the oven for at least 15 minutes before you
start cooking bread or cakes.
• Do not open the door during baking because the
cold air would stop the yeast from rising.
• When the cake is cooked turn the oven off and
leave it in for about 10 minutes.
• Do not use the enamelled oven tray or drip pan,
supplied with the oven, to cook cakes in.
• How do you know when the cake is cooked? About
5 minutes before the end of cooking time, put a
cake tester or skewer in the highest part of the
cake. If it comes out clean the cake is cooked.
• And if the cake sinks? The next time use less
liquids or lower the temperature 10°C.
• If the cake is too dry: Make some tiny holes
with a toothpick and pour some drops of fruit
juice or spirits on it. The next time, increase the
temperature 10°C and set a shorter cooking
time.
• If the cake is too dark on top: the next time put
the cake on a lower shelf, cook it at a lower
temperature and longer.
• If the top of the cake is burnt: cut off the burnt layer
and cover with sugar or decorate it with cream,
jam, confectioner’s cream, etc..
• If the cake is too dark underneath: the next time
place it on a higher shelf and cook it at a lower
temperature.
• If the cake or bread is cooked nicely outside but
is still uncooked inside: the next time use less
liquids, cook at a lower temperature and longer.
• If the cake will not come out of the tin: slide a
knife around the edges, place a damp cloth over
the cake and turn the tin upside down. The next
time grease the tin well and sprinkle it with our or
bread crumbs.
• If the biscuits will not come away from the baking
tray: put the tray back in the oven for a while and
lift the biscuits up before they cool. The next time
use a sheet of baking parchment to prevent this
happening again.
Meat:
• If, when cooking meat, the time needed is more
than 40 minutes, turn the oven off 10 minutes
before the end of cooking time to exploit the
residual heat (energy saving).
• Your roast will be juicier if cooked in a closed pan;
it will be crispier if cooked without a lid.
• Normally white meat, poultry and sh need
medium temperatures (less than 200°C).
• To cook “rare” red meats, high temperatures (over
200°C) and short cooking times are needed.
• For a tasty roast, lard and spice the meat.
• If your roast is tough: the next time leave the meat
to ripen longer.
• If your roast is too dark on top or underneath: the
next time put it on a higher or lower shelf, lower
the temperature and cook longer.
• Your roast is underdone? Cut it in slices, arrange
the slices on a baking tray with the gravy and
nish cooking it.
Grilling:
• Sparingly grease and avour the food before
grilling it.
• Always use the grillpan to catch the juices thatdrip
from the meat during grilling.
• Always put a little water in the drip pan. The water
prevents the grease from burning and from giving
off bad smells and smoke. Add more water during
cooking because it evaporates.
• Turn the food half way through cooking.
• If you are grilling fatty poultry (goose) pierce the
skin so the fat can drip away.
The aluminium can be easily corroded if it
comes into contact with organic acids present
in the foods or added during baking (vinegar,
lemon juice). Therefore it is advised not to put
directly the foods on aluminium or enamelled
trays, butALWAYS use the proper oven paper.
20
INSTRUCTIONS FOR THE USER
COOKING / BAKING TIMETABLE
FOODS Weight
kg
Position of the oven shelf
from the bottom COOKING BY
NATURAL CONVECTION COOKING BY
FORCED CONVECTION (WITH FAN)
with 5
runners with 3
runners Temperature
in °C Cooking Time
in minutes Temperature
in °C Cooking Time
in minutes
MEAT
Roast veal
Roast beef
Roast pork
Roast lamb
1
1
1
1
1-2
1-2
1-2
1-2
2
1
2
1
200-225
200-225
200-225
200-225
100-120
40-50
100-120
100-120
190
190
190
190
100-120
40-50
100-120
100-120
GAME
Roast hare
Roast pheasant
Roast partridge
1
1
1
1-2
1-2
1-2
2
2
2
200-Max
200-Max
200-Max
50-60
60-70
50-60
200-Max
200-Max
200-Max
50
60
50
POULTRY
Roast chicken
Roast turkey
Roast duck
1
1
1
1-2
1-2
1-2
2
2
2
200-225
200-225
200-225
80-90
100-120
90-110
190
190
190
70-80
90-110
80-100
FISH
Roast sh
Casseroled sh 1
12-3
2-3 1
1200
175
30-35
20-25 170-190
160-170
25-30
15-20
BAKED PASTA
Lasagne
Cannelloni 2,5
2,5 3
31
1210-225
210-225 60-75
60-75 225-Max
225-Max 30-40
30-40
PIZZA 131 225-Max 25-30 225-Max 20-25
BREAD 131 225-Max 20-25 220 20
PASTRIES
Biscuits in general
Shortcrust pastry
Victoria sponge 0,8
2
2
2
1
1
1
190
200
200
15
20
40-45
170-190
190-200
190-200
15
20
40-45
CAKES
Angel cake
Fruit cake
Chocolate cake
0,8
0,8
0,8
2
2
2
2
2
2
190
200
200
52
65
45
170-190
190-200
190-200
45
65
45
The values given in the tables (temperatures and cooking times) are approximate and may vary according to each person’s cooking habits. THIS
TABLE GIVES COOKING TIMES ON ONLY ONE SHELF. If you are cooking with a fan oven and you are using more than one shelf (placing the
shelves on the 1st or 3rd position or on the 2nd and 4th position) cooking time will be about 5 to 10 minutes longer).
GRILLING TIMETABLE
FOODS Weight
kg
Position of the
oven shelf from the
bottom
COOKING BY NATURAL
CONVECTION COOKING BY FORCED
CONVECTION (WITH FAN)
with5
runners with3
runners Temperature
in °C
Cooking Time
in minutes Temperature
in °C
Cooking Time
in minutes
1st side 2nd side 1st side 2nd side
MEAT
Chop
Beefsteaks
Half chicken (each half 0.500 kg)
0,50
0,15
1
3
3-4
3-4
2
1-2
1-2
225-Max
200-225
225
12-15
5
20
12-15
5
20
200
=
=
15
=
=
10
=
=
FISH
Trout
Sole 0,42
0,20 4
4
2-3
2-3 225-Max
225-Max =
==
=200
200 10
710
7
BREAD
Toast 4-5 3 225-Max 2-3 2-3 200 2-3 2-3
The values given in the tables (temperatures and cooking times) are approximate and may vary according to each person’s cooking habits. In
particular, temperatures and times for grilling meat will greatly depend on the thickness of the meat and on personal tastes.
