Astraada DRV-24 User manual

Operation Manual
The owner of Astraada brand is ASTOR Sp. z o.o.
Astraada DRV-24
Frequency inverters

DRV-24 frequency inverters Content
1
1 Safety Precautions ...............................................................................................................................3
1.1 Safety definition ...............................................................................................................................3
1.2 Warning symbols ..............................................................................................................................3
1.3 Safety guidelines...............................................................................................................................3
2 Product Overview................................................................................................................................5
2.1 Quick start-up...................................................................................................................................5
2.1.1 Unpacking inspection .....................................................................................................................5
2.1.2 Application confirmation.................................................................................................................5
2.1.3 Environment..................................................................................................................................6
2.1.4 Installation confirmation.................................................................................................................6
2.1.5 Basic commissioning.......................................................................................................................6
2.2 Product specification.........................................................................................................................7
2.3 Name plate ......................................................................................................................................9
2.4 Type designation key.........................................................................................................................9
2.5 Rated specifications ..........................................................................................................................9
2.6 Structure diagram...........................................................................................................................10
3 Installation Guidelines........................................................................................................................12
3.1 Mechanical installation....................................................................................................................12
3.2 Standard wiring ..............................................................................................................................14
3.3 Layout protection ...........................................................................................................................20
4 Keypad Operation Procedure ..............................................................................................................21
4.1 Keypad introduction........................................................................................................................21
4.2 Keypad displaying ...........................................................................................................................23
4.3 Keypad operation............................................................................................................................24
5 Function Parameters..........................................................................................................................25
6 Fault Tracking....................................................................................................................................83
6.1 Maintenance intervals.....................................................................................................................83
6.1.1 Cooling fan..................................................................................................................................85
6.1.2 Capacitors ...................................................................................................................................86
6.1.3 Power cable.................................................................................................................................87
6.2 Fault solution .................................................................................................................................87
6.2.1 Alarm and fault indications............................................................................................................87

DRV-24 frequency inverters Content
2
6.2.2 How to reset................................................................................................................................87
6.2.3 Fault instruction and solution ........................................................................................................88
6.2.4 Other states.................................................................................................................................91
7 Communication Protocol....................................................................................................................92
7.1 Brief instruction to Modbus protocol ................................................................................................92
7.2 Application of the inverter ...............................................................................................................92
7.3 Command code and communication data illustration..........................................................................97
7.4 The definition of data address ........................................................................................................103
7.5 Example of writing and reading ......................................................................................................109
7.6 Common communication fault ....................................................................................................... 113
Appendix A Technical Data .................................................................................................................. 113
A.1 Ratings........................................................................................................................................ 113
A.2 CE............................................................................................................................................... 114
A.3 EMC regulations........................................................................................................................... 114
Appendix B Dimension Drawings.......................................................................................................... 115
B.1 External keypad structure .............................................................................................................. 115
B.2 Inverter chart............................................................................................................................... 116
Appendix C Peripheral Options and Parts .............................................................................................. 119
C.1 Peripheral wiring .......................................................................................................................... 119
C.2 Power supply ...............................................................................................................................120
C.3 Cables .........................................................................................................................................120
C.4 Breaker and electromagnetic contactor ...........................................................................................121
C.5 Reactors ......................................................................................................................................122
C.6 Filter ...........................................................................................................................................123
C.7 Braking components .....................................................................................................................125
Appendix D Further Information ..........................................................................................................127

DRV-24 frequency inverters Safety precautions
3
1 Safety Precautions
Please read this manual carefully and follow all safety precautions before moving, installing,
operating and servicing the inverter. If ignored, physical injury or death may occur, or damage may
occur to the devices.
If any physical injury or death or damage to the devices occurs for ignoring to the safety precautions
in the manual, our company will not be responsible for any damages and we are not legally bound
in any manner.
1.1 Safety definition
Danger:
Serious physical injury or even death may occur if not follow
relevant requirements
Warning:
Physical injury or damage to the devices may occur if not
follow relevant requirements
Note:
Physical hurt may occur if not follow relevant requirements
Qualified
electricians:
People working on the device should take part in
professional electrical and safety training, receive the
certification and be familiar with all steps and requirements
of installing, commissioning, operating and maintaining the
device to avoid any emergency.
1.2 Warning symbols
Warnings caution you about conditions which can result in serious injury or death and/or damage to
the equipment, and advice on how to avoid the danger. Following warning symbols are used in this
manual:
Symbols
Name
Instruction
Abbreviation
Danger
Danger
Serious physical injury or even
death may occur if not follow
the relative requirements
Warning
Warning
Physical injury or damage to
the devices may occur if not
follow the relative
requirements
Do not
Electrostatic
discharge
Damage to the PCBA board
may occur if not follow the
relative requirements
Hot sides
Hot sides
Sides of the device may
become hot. Do not touch.
Note
Note
Physical hurt may occur if not
follow the relative
requirements
Note
1.3 Safety guidelines
Only qualified electricians are allowed to operate on the inverter.
Do not carry out any wiring and inspection or changing components
when the power supply is applied. Ensure all input power supply is
disconnected before wiring and checking and always wait for at least
the time designated on the inverter or until the DC bus voltage is less

DRV-24 frequency inverters Safety precautions
4
than 36V. Below is the table of the waiting time:
Inverter module
Minimum waiting time
1PH 230V
0.4kW-2.2kW
5 minutes
3PH 400V
0.75kW-110kW
5 minutes
Do not refit the inverter unauthorized; otherwise fire, electric shock or
other injury may occur.
The base of the radiator may become hot during running. Do not
touch to avoid hurt.
The electrical parts and components inside the inverter are
electrostatic. Take measurements to avoid electrostatic discharge
during relevant operation.
1.3.1 Delivery and installation
Please install the inverter on fire-retardant material and keep the
inverter away from combustible materials.
Connect the braking optional parts (braking resistors, braking units or
feedback units) according to the wiring diagram.
Do not operate on the inverter if there is any damage or components
loss to the inverter.
Do not touch the inverter with wet items or body, otherwise electric
shock may occur.
Note:
Select appropriate moving and installing tools to ensure a safe and normal running of the
inverter and avoid physical injury or death. For physical safety, the erector should take some
mechanical protective measurements, such as wearing exposure shoes and working
uniforms.
Ensure to avoid physical shock or vibration during delivery and installation.
Do not carry the inverter by its cover. The cover may fall off.
Install away from children and other public places.
The inverter cannot meet the requirements of low voltage protection in IEC61800-5-1 if the
sea level of installation site is above 2000m.
The leakage current of the inverter may be above 3.5mA during operation. Ground with
proper techniques and ensure the grounding resistor is less than 10Ω. The conductivity of PE
grounding conductor is the same as that of the phase conductor (with the same cross
sectional area).
R, S and T are the input terminals of the power supply, while U, V and W are the motor
terminals. Please connect the input power cables and motor cables with proper techniques;
otherwise the damage to the inverter may occur.
1.3.2 Commissioning and running
Disconnect all power supplies applied to the inverter before the
terminal wiring and wait for at least the designated time after
disconnecting the power supply.
High voltage is present inside the inverter during running. Do not carry
out any operation except for the keypad setting.
The inverter may start up by itself when P01.21=1. Do not get close to
the inverter and motor.
The inverter can not be used as “Emergency-stop device”.
The inverter can not be used to break the motor suddenly. A
mechanical braking device should be provided.

DRV-24 frequency inverters Safety precautions
5
Note:
Do not switch on or off the input power supply of the inverter frequently.
For inverters that have been stored for a long time, check and fix the capacitance and try to
run it again before utilization (see Maintenance and Hardware Fault Diagnose).
Cover the front board before running, otherwise electric shock may occur.
1.3.3 Maintenance and replacement of components
Only qualified electricians are allowed to perform the maintenance,
inspection, and components replacement of the inverter.
Disconnect all power supplies to the inverter before the terminal
wiring. Wait for at least the time designated on the inverter after
disconnection.
Take measures to avoid screws, cables and other conductive matters
to fall into the inverter during maintenance and component
replacement.
Note:
Please select proper torque to tighten screws.
Keep the inverter, parts and components away from combustible materials during
maintenance and component replacement.
Do not carry out any isolation and pressure test on the inverter and do not measure the
control circuit of the inverter by megameter.
1.3.4 What to do after scrapping
There are heavy metals in the inverter. Deal with it as industrial
effluent.
2 Product Overview
2.1 Quick start-up
2.1.1 Unpacking inspection
Check as follows after receiving products:
1. Check that there are no damage and humidification to the package. If not, please
contact with local agents or ASTOR offices.
2. Check the information on the type designation label on the outside of the package
to verify that the drive is of the correct type. If not, please contact with local dealers
or ASTOR offices.
3. Check that there are no signs of water in the package and no signs of damage or
breach to the inverter. If not, please contact with local dealers or ASTOR offices.
4. Check the information on the type designation label on the outside of the package
to verify that the name plate is of the correct type. If not, please contact with local
dealers or ASTOR offices.
5. Check to ensure the accessories (including user’s manual and control keypad)
inside the device is complete. If not, please contact with local dealers or ASTOR
offices.
2.1.2 Application confirmation
Check the machine before beginning to use the inverter:
1. Check the load type to verify that there is no overload of the inverter during work
and check that whether the drive needs to modify the power degree.
2. Check that the actual current of the motor is less than the rated current of the
inverter.

DRV-24 frequency inverters Product Overview
6
3. Check that the control accuracy of the load is the same of the inverter.
4. Check that the incoming supply voltage is correspondent to the rated voltage of
the inverter.
2.1.3 Environment
Check as follows before the actual installation and usage:
1. Check that the ambient temperature of the inverter is below 40°C. If exceeds,
derate 1% for every additional 1°C. Additionally, the inverter can not be used if the
ambient temperature is above 50°C.
Note: for the cabinet inverter, the ambient temperature means the air temperature
inside the cabinet.
2. Check that the ambient temperature of the inverter in actual usage is above -10°C.
If not, add heating facilities.
Note: for the cabinet inverter, the ambient temperature means the air temperature
inside the cabinet.
3. Check that the altitude of the actual usage site is below 1000m. If exceeds,
derate1% for every additional 100m.
4. Check that the humidity of the actual usage site is below 90% and condensation is
not allowed. If not, add additional protection inverters.
5. Check that the actual usage site is away from direct sunlight and foreign objects
can not enter the inverter. If not, add additional protective measures.
6. Check that there is no conductive dust or flammable gas in the actual usage site. If
not, add additional protection to inverters.
2.1.4 Installation confirmation
Check as follows after the installation:
1. Check that the load range of the input and output cables meet the need of actual
load.
2. Check that the accessories of the inverter are correctly and properly installed. The
installation cables should meet the needs of every component (including reactors,
input filters, output reactors, output filters, DC reactors, braking units and braking
resistors).
3. Check that the inverter is installed on non-flammable materials and the calorific
accessories (reactors and brake resistors) are away from flammable materials.
4. Check that all control cables and power cables are run separately and the
routation complies with EMC requirement.
5. Check that all grounding systems are properly grounded according to the
requirements of the inverter.
6. Check that the free space during installation is sufficient according to the
instructions in user’s manual.
7. Check that the installation conforms to the instructions in user’s manual. The drive
must be installed in an upright position.
8. Check that the external connection terminals are tightly fastened and the torque is
appropriate.
9. Check that there are no screws, cables and other conductive items left in the
inverter. If not, get them out.
2.1.5 Basic commissioning
Complete the basic commissioning as follows before actual utilization:

DRV-24 frequency inverters Product Overview
7
1. Autotune. If possible, de-coupled from the motor load to start dynamic autotune.
Or if not, static autotune is available.
2. Adjust the ACC/DEC time according to the actual running of the load.
3. Commission the device via jogging and check that the rotation direction is as
required. If not, change the rotation direction by changing the wiring of motor.
4. Set all control parameters and then operate.
2.2 Product specification
Function
Specification
Power
input
Input voltage (V)
AC 1PH 220V (-15%)~240V(+10%)
AC 3PH 220V (-15%)~240V(+10%)
AC 3PH 380V (-15%)~440V(+10%)
Input current (A)
Refer to the rated value
Input frequency (Hz)
50Hz or 60Hz Allowed range: 47~63Hz
Power
output
Output voltage (V)
0~input voltage
Output current (A)
Refer to the rated value
Output power (kW)
Refer to the rated value
Output frequency
(Hz)
0~400Hz
Technical
control
feature
Control mode
SVPWM, SVC
Motor
Asynchronous motor
Adjustable-speed
ratio
Asynchronous motor 1:100 (SVC)
Speed control
accuracy
±0.2% (SVC)
Speed fluctuation
± 0.3% ( SVC)
Torque response
<20ms (SVC)
Torque control
accuracy
10%
Starting torque
0. 5Hz/150% ( SVC)
Overload capability
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
Running
control
feature
Frequency setting
method
Digital setting, analog setting, pulse frequency
setting, multi-step speed running setting,
simple PLC setting, PID setting, MODBUS
communication setting
Shift between the set combination and set
channel.
Auto-adjustment of
the voltage
Keep a stable voltage automatically when the
grid voltage transients
Fault protection
Provide comprehensive fault protection
functions: overcurrent, overvoltage,
undervoltage, overheating, phase loss and
overload, etc.
Start after speed
tracking
Smoothing starting for running motor
Peripheral
Analog input
1 (AI2) 0~10V/0~20mA and 1 (AI3) -10~10V

DRV-24 frequency inverters Product Overview
8
Function
Specification
interface
Analog output
2 (AO1, AO2*) 0~10V/0~20mA
* AO2 for devices with power input ≥4kW
Digital input
4 common inputs, the Max. frequency: 1kHz;
1 high speed input, the Max. frequency:
50kHz
Digital output
1 Y1 terminal output
Relay output
2 programmable relay outputs
RO1A NO, RO1B NC, RO1C common terminal
*RO2A NO, RO2B NC, RO2C common terminal
Contact capacity: 3A/AC250V
* for devices with power input ≥4kW
Others
Temperature of the
running
environment
-10~50°C, derate 1% for every additional 1℃
when above 40℃
DC reactor
Standard embedded DC reactor for the
inverters (≥18.5kW)
Installation mode
Wall and rail installation of the
inverters(single phase 220V/three phase
380V, ≤2.2KW)
Wall and flange installation of the
inverters(three phase 380V, ≥4KW)
Braking unit
Standard for the inverters≤37kW and optional
for the inverters of 45~110kW
Protective degree
IP20
Note: The inverter with plastic casing should
be installed in metal distribution cabinet,
which conforms to IP20 and of which the top
conforms to IP3X.
Cooling
Air-cooling
EMI filter
Embedded C3 filters for the inverters(three
phase 380V, ≥4kW and three phase 220V,
≥1.5kW) ; external C2 filter is optional for all
series;
Optional filter: meet the degree requirement
of IEC61800-3 C2, IEC61800-3 C3
Safety
Meet the requirement of CE

DRV-24 frequency inverters Product Overview
9
2.3 Name plate
Figure 2-1 Name plate
Note: This is the example for the standard products. And the CE/TUV/IP20 will be marked according
to the actual.
2.4 Type designation key
The type designation contains information on the inverter. The user can find the type designation on
the type designation label attached to the inverter or the simple name plate.
AS24DRV 4 2C2
①②③
Figure 2-2 Product type
Key
No.
Detailed
description
Detailed content
Product
abbreviation
①
Product
abbreviation
Astraada AS24DRV
AS24DRV is short for Astraada DRV-24
Voltage
degree
②
Voltage degree
2: AC 1PH 220V(-15%)~240V(+10%)
4: AC 3PH 380V(-15%)~440V(+10%)
Rated power
③
Power range +
Load type
2C2—2.2kW
2.5 Rated specifications
Model
Voltage
degree
Rated
output
power(kW)
Rated input
current(A)
Rated output
current(A)
AS24DRV20C4
Single phase
230V
0.4
6.5
2.5
AS24DRV20C7
0.75
9.3
4.2
AS24DRV21C5
1.5
15.7
7.5
AS24DRV22C2
2.2
24
10
AS24DRV40C7
Three phase
0.75
3.4
2.5

DRV-24 frequency inverters Product Overview
10
Model
Voltage
degree
Rated
output
power(kW)
Rated input
current(A)
Rated output
current(A)
AS24DRV41C5
400V
1.5
5.0
4.2
AS24DRV42C2
2.2
5.8
5.5
AS24DRV44C0
4
13.5
9.5
AS24DRV45C5
5.5
19.5
14
AS24DRV47C5
7.5
25
18.5
AS24DRV4011
11
32
25
AS24DRV4015
15
40
32
AS24DRV4018
18.5
47
38
AS24DRV4022
22
51
45
AS24DRV4030
30
70
60
AS24DRV4037
37
80
75
AS24DRV4045
45
98
92
AS24DRV4055
55
128
115
AS24DRV4075
75
139
150
AS24DRV4090
90
168
180
AS24DRV4110
110
201
215
2.6 Structure diagram
Below is the layout figure of the inverter (Three phase 400V, ≤2.2kW) (take the inverter of 0.75kW
as the example).
6
12
8
10
7
3
2
5
1
9
11
4
Figure 2-3 Product structure (Three phase 400V, ≤2.2kW)

DRV-24 frequency inverters Product Overview
11
Serial
No.
Name
Illustration
1
External keypad port
Connect the external keypad
2
Port cover
Protect the external keypad port
3
Cover
Protect the internal parts and components
4
Hole for the sliding
cover
Fix the sliding cover
5
Trunking board
Protect the inner components and fix the cables
of the main circuit
6
Name plate
See Product Overview for detailed information
7
Potentiometer knob
Refer to the Keypad Operation Procedure
8
Control terminals
See Electric Installation for detailed information
9
Main circuit terminals
See Electric Installation for detailed information
10
Screw hole
Fix the fan cover and fan
11
Cooling fan
See Maintenance and Hardware Fault Diagnose
for detailed information
12
Fan cover
Protect the fan
13
Bar code
The same as the bar code on the name plate
Note: The bar code is on the middle shell which
is onder the cover
Note: In above figure, the screws at 4 and 10 are provided with packaging and
specific installation depends on the requirements of customers.
Below is the layout figure of the inverter (Three phase 400V, ≥4kW) (take the inverter of 4kW as the
example).
Figure 2-3 Product structure(Three phase 400V, ≥4kW)
Serial
No.
Name
Illustration
1
External keypad port
Connect the external keypad
2
Cover
Protect the internal parts and components
3
Keypad
Refer to the Keypad Operation Procedure
4
Cooling fan
See Maintenance and Hardware Fault Diagnose
for detailed information
5
Name plate
See Product Overview for detailed information
6
Cover for the heat
emission hole
Optional, enhancement of the protective degree.
It is necessary to derate the inverter because the

DRV-24 frequency inverters Product Overview
12
Serial
No.
Name
Illustration
internal temperature is increasing
7
Control terminals
See Electric Installation for detailed information
8
Main circuit terminals
See Electric Installation for detailed information
9
The cable entry of the
main circuit
Fix the cables
10
Simple name plate
Refer to Type Designation Key
11
Bar code
The same as the bar code on the name plate
Note: The bar code is on the middle shell which
is onder the cover
3 Installation Guidelines
The chapter describes the mechanical installation and electric installation.
Only qualified electricians are allowed to carry out what described in
this chapter. Please operate as the instructions in Safety Precautions.
Ignoring these may cause physical injury or death or damage to the
devices.
Ensure the power supply of the inverter is disconnected during the
operation. Wait for at least the time designated after the
disconnection if the power supply is applied.
The installation and design of the inverter should be complied with the
requirement of the local laws and regulations in the installation site. If
the installation infringes the requirement, our company will exempt
from any responsibility. Additionally, if users do not comply with the
suggestion, some damage beyond the assured maintenance range
may occur.
3.1 Mechanical installation
3.1.1 Installation environment
The installation environment is the safeguard for a full performance and long-term stable functions
of the inverter. Check the installation environment as follows:
Environment
Conditions
Installation site
Indoor
Environment
temperature
-10°C~+50°C, and the temperature changing rate is less than
0.5°C/minute.
If the ambient temperature of the inverter is above 40°C,
derate 1% for every additional 1°C.
It is not recommended to use the inverter if the ambient
temperature is above 50°C.
In order to improve the reliability of the device, do not use
the inverter if the ambient temperature changes frequently.
Please provide cooling fan or air conditioner to control the
internal ambient temperature below the required one if the
inverter is used in a close space such as in the control
cabinet.
When the temperature is too low, if the inverter needs to
restart to run after a long stop, it is necessary to provide an
external heating device to increase the internal temperature,

Astraada DRV-24 frequency inverters Installation guidelines
13
Environment
Conditions
otherwise damage to the devices may occur.
Humidity
RH≤90%
No condensation is allowed.
Storage
temperature
-40°C~+70°C, and the temperature changing rate is less than
1°C/minute.
Running
environment
condition
The installation site of the inverter should:
keep away from the electromagnetic radiation source;
keep away from contaminative air, such as corrosive gas, oil
mist and flammable gas;
ensure foreign objects, such as metal power, dust, oil, water
can not enter into the inverter(do not install the inverter on
the flammable materials such as wood);
keep away from direct sunlight, oil mist, steam and vibration
environment.
Altitude
Below 1000m
If the sea level is above 1000m, please derate 1% for every
additional 100m.
Vibration
≤ 5.8m/s2(0.6g)
Installation
direction
The inverter should be installed on an upright position to
ensure sufficient cooling effect.
Note:
Astraada DRV-24 series inverters should be installed in a clean and ventilated environment
according to enclosure classification.
Cooling air must be clean, free from corrosive materials and electrically conductive dust.
3.1.2 Installation direction
The inverter may be installed on the wall or in a cabinet.
The inverter needs be installed in the vertical position. Check the installation site according to the
requirements below. Refer to chapter Dimension Drawings in the appendix for frame details.
3.1.3 Installation manner
(1) Wall and rail mounting for the inverters(single phase 230V/three phase 400V, ≤2.2KW)
a) Wall mounting b) Rail mounting
Figure 3-1 Installation
Note: the miniumum space of A and B is 100mm if H is 36.6mm and W is 35.0mm.

Astraada DRV-24 frequency inverters Installation guidelines
14
(2) Wall and flange mounting for the inverters(three phase 400V, ≥4KW)
Figure 3-2 Installation
(1) Locate the position of the installation hole.
(2) Fix the screw or nut on the located position.
(3) Put the inverter againse the wall.
(4) Tighten up the screws.
3.2 Standard wiring
3.2.1 Connection diagram of main circuit
Figure 3-3 Connection diagram of main circuit
Note:
The fuse, braking resistor, input reactor, input filter, output reactor, output filter are
optional parts. Please refer to Peripheral Optional Parts for detailed information.
Remove the yellow waring labels of PB, (+) and (-) on the terminals before connecting the
braking resistor; otherwise poor connection may be occur.

Astraada DRV-24 frequency inverters Installation guidelines
15
3.2.2 Terminals figure of main circuit
Figure 3-4 1PH terminals of main circuit (single phase)
Figure 3-5 3PH terminals of main circuit (400V, ≤2.2kW)
Figure 3-6 3PH terminals of main circuit (400V, 4-22kW)
Figure 3-7 3PH terminals of main circuit (30-37kW)
Figure 3-8 3PH terminals of main circuit (45-110kW)
Terminal
Function
L, N
Single phase AC input terminals which are generally
connected with the power supply.
R, S, T
Three phase AC input terminals which are generally
connected with the power supply.
PB, (+)
External dynamic braking resistor terminal

Astraada DRV-24 frequency inverters Installation guidelines
16
(+), (-)
Input terminal of the DBU or DC bus
U, V, W
Three phase AC input terminals which are generally
connected with the motor.
PE
Protective grounding terminal
Note:
Do not use asymmetrically motor cables. If there is a symmetrically grounding
conductor in the motor cable in addition to the conductive shield, connect the
grounding conductor to the grounding terminal at the inverter and motor ends.
Route the motor cable, input power cable and control cables separately.
3.2.3 Wiring of terminals in main circuit
1. Fasten the grounding conductor of the input power cable with the grounding terminal of the
inverter (PE) by 360 degree grounding technique. Connect the phase conductors to L1, L2 and L3
terminals and fasten.
2. Strip the motor cable and connect the shield to the grounding terminal of the inverter by 360
degree grounding technique. Connect the phase conductors to U, Vand Wterminals and fasten.
3. Connect the optional brake resistor with a shielded cable to the designated position by the same
procedures in the previous step.
4. Secure the cables outside the inverter mechanically.
3.2.4 Wiring diagram of control circuit
Figure 3-9 Wiring of control circuit

Astraada DRV-24 frequency inverters Installation guidelines
17
3.2.5 Terminals of control circuit
S1 S2 S3 S4 HDI AI2 AI3 +10V
+24V PW COM COM Y1 AO1 485+ 485-
+24V H1
+24V H2
RO1B RO1C
RO1A RO1C
Connection terminal diagram for inverters ≤2.2kW
S1 S2 S3 S4 HDI Y1 AI2 AI3
+24V PW COM COM GND AO1 AO2 485+
RO1A RO1B RO1C
RO2A RO2B RO2C
+10V
485- +24V H1 +24V H2
Connection
terminal diagram for inverters ≥ 4kW
Figure 3-10 Terminals of control circuit
Type
Terminal
name
Function
description
Technical specifications
Communication
485+
485
communication
485 communication interface
485-
Digital
input/output
S1
Digital input
1. Internal impedance:3.3kΩ
2. 12~30V voltage input is
available
3. The terminal is the
dual-direction input terminal
4. Max. input
frequency:1kHz
S2
S3
S4
HDI
High frequency
input channel
Except for S1~S4, this
terminal can be used as high
frequency input channel.
Max. inputfrequency:50kHz
Duty cycle:30%~70%
PW
Digital power
supply
To provide the external
digital power supply
Voltage range: 12~30V
Y1
Digital output
1. Contact capacity:
50mA/30V;
2. Output frequency range:
0~1kHz;
3. Default is STO state output
indicator.
24V power
supply
+24V
24V power
supply
External 24V±10% power
supply and the
maximum output
current is 200mA。
Generally used ad the
operation powersupply
of digital input and
output or external
COM

Astraada DRV-24 frequency inverters Installation guidelines
18
Type
Terminal
name
Function
description
Technical specifications
sensor power supply
STO function
input
24V-H1
STO input 1
1. Safety torque stop (STO)
redundant input,
externally connected to
NC contact, STO acts
when the contact is
open, and the drive
stops output;
2. The safe input signal cable
should be shield cable
within 25m.
3. When employing STO
function, please
disassemble the short
circuit plate on the
terminals shown in fig
3.10 and fig 3.11.
24V-H2
STO input 2
Analog
input/output
+10V
External 10V
reference
power supply
10V reference power supply
Max. output current: 50mA
As the adjusting power
supply of the external
potentiometer
Potentiometer resistance:
5kΩ above
AI2
Analog input
1. Input range: AI2 voltage
and current can be chose:
0~10V/0~20mA;
AI3:-10V~+10V.
2. Input impedance:voltage
input:
20kΩ; current input: 500Ω.
3.Voltage or current input
can be
setted by dip switch.
4. Resolution: the minimum
AI2/AI3 is 10mV/20mV when
10V corresponds to 50Hz.
AI3
GND
Analog
reference
ground
Analog reference ground
AO1
Analog output
1. Output range:0~10V or
0~20mA
2. The voltage or the current
output is depended on the
dip switch.
3. Deviation±1%,25°C when
full range.
4. *There is only one AO1 for
inverters ≤ 2.2kW.
AO2*
