DRAWMER DMS-4
M-Clock Lite
AES GRADE 1 MASTER CLOCK
WordclockOutputs:
Two wordclock outputs conveniently
located on the front panel.
1 3
5 4
1OutputSample Rate:
Two buttons toggle through the wordclock output sample rates, setting the rate for
the eight rear panel outputs 5 and the two front panel outputs 1from 44.1kHz to
384kHz. An EXTernal wordclock input can also be selected that sets the clock output
rate to match that of the incoming external clock 4 .
3
WordclockInputs:
Sets the output sample rate when the Output Sample Rate
control 3 is set to EXT.
4WordclockOutputs:
In addition to the two front panel wordclock outputs eight more
are found on the rear.
5
CHAPTER 1
2
INTRODUCTION
Itis nowwidely accepted thatone ofthe essential requirements for highquality
digital recording is a first class, high stability master clock generator. These
canbe complicated deviceswith many addedfeatures, which although useful,
maybe surplusto requirements.The aimof M-ClockLite is to provide a simple,
highqualityclock generator, whichisforward compatiblewithhigh speed clocks
predicted for the future. M-Clock Lite features an AES Grade 1 master clock
generator,meaningthatthegeneratedclockhasa long term frequencyaccuracy
of +/- 1ppm.
Features:
M-Clock Lite offers clock rates of 44.1, 48, 88.2, 96, 176.4, 192, 352.8 and
384kHz at extremely low jitter.
An external clock input allows the user to select an alternative clock source
without having to re-route clock cables.
10Outputs areprovided, 8at therear and2 foreasy accesson thefront panel.
OnLed:
A power LED notifies that the unit is on.
2

5
TheDMS-4 is designed for standard19" rack mounting and occupies1U of rack space. Avoidmounting the unit directly
abovepower amplifiersor power suppliesthat radiatesignificant amounts ofheat.
If the unit is to be used in a mobile situation, it is strongly recommended that the rear of the unit is supported in the
carryingrack toavoid bendingthe front panel rack mounting‘ears’.
Use fibre or plastic washers to prevent the front panel becoming marked by the mounting bolts.
The unit will be supplied with a power cable suitable for domestic power outlets in your country. For your own safety it
is important that you use this cable. The unit should always be connected to the mains supply earth using this cable.
Poweredby a universalswitch mode powersupply, the DMS-4 M-ClockLite operates frommains voltages between 85
to250v, eliminating the need to makeany changes whentouring and allowingthe unit toremain fully operationalduring
large fluctuations in the mains power supply.
TheDMS-4 is fittedwith a mainsfuse that conformsto the IEC127-2
standardandisrated atT315mA.Ifthe fuse blowsitmust be replaced
withone ofidentical typeand value.To doso removethe mainscable
from the IEC connector and open the drawer that is located just
below, replace the fuse, close the drawer and re-attach the mains
cable.
INSTALLATION
AUDIO CONNECTIONS
Word Clock
Use only good quality 75Ωdigital or video coax (not aerial downlead) cable for the word-clock signals, terminated with
thecorrecttype of 75ΩBNCconnectors-inferiorcableswillintroducejitterandwill completely underminetheperformance
benefits which might be achieved by using a master clock in the first place!
SIMPLE WORDCLOCK DISTRIBUTION SETUP
Fuse

6
SPECIFICATION
Internal Clock Generator
2 x Temperature Compensated Xtal Oscillators (TCXOs)
AES11 GRADE 1 Stability, +/-1ppm (0-60 Celcius),
Tolerance <<+/-1ppm (15-30
Celcius)
Phase noise -130 dBc/Hz @ 1kHz
@ 24.5760 MHz to give Fs 48 kHz, 96 kHz,
192kHz & 384 kHz
@ 22.5792 MHz to give Fs 44.1 kHz, 88.2 kHz,
176.4 kHz & 352.8 kHz
Word Clock Inputs
1 x BNC (Rear Panel)
Input Impedance 75 Ohms
Word Clock Outputs
8 x BNC (Rear Panel)
2 x BNC (Front Panel)
Output impedance 33 ohms
All outputs selectable between 44.1, 48, 88.2, 96, 176.4,
192, 352.8 and 384kHz
General
Power Supply: Internal, Universal Input, 15 W
Fuse Rating T315mA for All voltages.
CONFORMING TO: IEC127-2
Fuse Type 20mm x 5mm, Class 3 Slow - Blow
250Volt working
Dimensions: 1u, 19" Rack Mount,
482mm(W) x 44mm(H) x 145mm(D)
Weight 1.755 kg
For warranty service please call Drawmer Electronics Ltd. or
their nearest authorised service facility, giving full details of
thedifficulty.
A list of all main dealers can be found on the Drawmer
webpages.
On receipt of this information, service or shipping instructions
will be forwarded to you.
No equipment should be returned under the warranty without
prior consent from Drawmer or their authorised representative.
For service claims under the warranty agreement a service
Returns Authorisation (RA) number will be issued.
Write this RA number in large letters in a prominent position
on the shipping box. Enclose your name, address, telephone
number, copy of the original sales invoice and a detailed
description of the problem.
Authorised returns should be prepaid and must be insured.
All Drawmer products are packaged in specially designed
containersforprotection.Iftheunitis to be returned,theoriginal
container must be used. If this container is not available, then
the equipment should be packaged in substantial shock-proof
material, capable of withstanding the handling for the transit.
CONTACTING DRAWMER
Drawmer Electronics Ltd., will be pleased to answer all
application questions to enhance your usage of this
equipment. Please address correspondence to:
Drawmer (Technical Help line)
Coleman Street
Parkgate
Rotherham
S62 6EL
UK
Alternatively contact us by E-mail on :
[email protected]
Furtherinformationonall Drawmer dealers, Authorised service
departments and other contact information can be obtained
from our web pages on:
http://www.drawmer.com
M-CLOCK Lite DMS-4 GENERAL INFORMATION
CHAPTER 2
IF A FAULT DEVELOPS

7
BLOCK DIAGRAM
Ref:1v01 A 11-02-08

8
