Astro Pneumatic Tool 100SL User manual

Product Type:Model: 100SL 1000 LUMEN WIRELESSLY RECHARGEABLE
MINI LED FLOOD LIGHT
Page 1
Study, understand and follow all instructions provided
with this product. Read these instructions carefully
before installing, operating, servicing or repairing this
tool. Keep these instructions in a safe accessible place.
INTENDED USE OF THE TOOL
The 100SL is design to be used as an area work light to
illuminate dark work areas. Only use the charging cable,
wall adapter and or wireless charging pad designed for
this product. Do not use this tool outside of the designed
intent. Never modify the tool for any other purpose or use.
Caution: To help prevent personal injury
• Use of this product can expose you to chemicals
such as phthalates which are known to the State
of California to cause cancer, and birth defects or
other reproductive harm. For more information go
to www.P65Warnings.ca.gov/product.
Always wear ANSI approved safety equipment,
safety glasses and clothing when using this
product. Study, understand, and follow all
instructions provided with this product. Failure to
read and follow all warnings and operating
instructions may result in damages and serious
injury or death.
• Always wear ANSI approved goggles when using this
product. (Users and By standers).
• Never use this tool for any application other than for
which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
• Improper operation and/or maintenance of the tool,
modification of the tool, or use of the tool with
accessories not designed for it could result in
serious injury or death.
• Always select the correct accessories of the correct
size and design for the job that you are attempting to
perform.
• Always work in a clean, safe, well-lit, organized and
adequately equipped area.
• Do not begin repairs without assurance that vehicle
is in secure position, and will not move during repair.
WARNING
WARNING
www.astrotools.com
1 YEAR LIMITED WARRANTY
• Astro Pneumatic Tool Co. warrants our products to the
original user against defective material or workmanship
for a period of 1 year (except where noted on our price
schedule) from the date of 1st use. Astro reserves the
right to determine whether the product failed because of
defective material, workmanship or other causes and to
charge back for missing parts. Astro Pneumatic Tool
Co., at its discretion, will repair products covered under
this warranty free of charge. The distributor should
direct the original user to return the product (with the
exceptions listed below) with the distributor’s name,
address, adequate proof of date of purchase or a copy
of warranty card, and a short note explaining the
problem. Failures caused by accident, alteration, or
misuse are not covered by this warranty.
• Astro Pneumatic Tool Co. or its authorized service
representatives must perform all warranty repairs. Any
repair to the product by unauthorized service represen-
tatives voids this warranty. The rights under this warran-
ty are limited to the original user and may not be trans-
ferred to subsequent owners.
• This warranty is in lieu of all other warranties, expressed
or implied, including warranties of merchantability and
fitness for a particular purpose. Some states do not
allow the exclusion of limitations of incidental or conse-
quential damages so the above limitations may not
apply to you.
PLEASE DO NOT RETURN ANY PRODUCT WITHOUT CALLING
1-800-221-9705 FOR INSTRUCTIONS
PRODUCT INFORMATION
BEFORE USE
DO NOT DISCARD – GIVE TO USER
• Adjustable light output, press and hold dimming
power button for 100-1,000 lumens
• Includes USB-C style charging cable and adapter for
direct charging or wirelessly with 52SL-WCP magnetic
dual charging pad to charge one or two at a time
• Massive 21700 cell lithium battery, 4,500mAh
capacity for 3-18hrs of runtime
• Features foldable magnetic base, charge level
indicator light, IP65 and IK07 watter and impact
resistance
When unpacking, check the parts diagram and part
number listing on page 3 to make sure all parts are
included. If any parts are missing or damaged,
please call your distributor.

Product Type:Model: 100SL 1000 LUMEN WIRELESSLY RECHARGEABLE
MINI LED FLOOD LIGHT
Page 2
SPECIFICATION
100 Lumen 10%
Brightness for highest level 1000 Lumen 10%
Operation Time for lowest level 18 H 10%
Operation Time for highest level 3 H 10%
Battery 21700 3.6V 4500mAh
Charging Time Via Type-C(5V 2A adaptor) 2.5 H
Charging Time Via charging pad 5-6 H
IP Rating 65
IK Rating 07
Storage Temperature
Working Temperature
Charging
Discharging
Switch sequence
Battery indicator light
minus 20°C to 50°C
minus 10°C to 35°C
Green LED flashes when charging,
green LED on when fully charged
100%~40% green LED on,
40% yellow LED on
Main light (Press and hold to
enter dimming function)
/ /
/
/
/ /
/ /
/ /
/ /
/
Brightness for lowest level
>
ITEM RANGE UNIT TOLERANCE

Product Type:Model: 100SL 1000 LUMEN WIRELESSLY RECHARGEABLE
MINI LED FLOOD LIGHT
PARTS BREAKDOWN
Parts List
Call 1.800.221.9705 for questions concerning performance of the product
or other inquiries.
Page 3
Qty
1
2
3
4
5
6
7
100SL-01
100SL-02
100SL-03
100SL-04
100SL-05
100SL-06
100SL-07
Front Housing with Transparent Lens
Reflector
COB LED
Switch Button
Switch Holder
Bracket
USB End Cap
Index Part No. Description
1
1
1
1
1
1
1
12 3 4 5 6
7
