AstroStart DSP625 User manual

GUIDE DE L'UTILISATEUR
OWNER'S GUIDE
Directed s'engage à offrir des produits et services
de qualité de classe mondiale qui raviront les
clients.
Directed is committed to delivering world class
quality products and services that excite and
delight customers.
www.astrostart.com
MODÈLE
MODEL
The company behind the
AstroStart®Integrated Digital
Platform is Directed.
Since its inception, Directed has
had one purpose, to provide
consumers with the finest vehicle
security and accessories available.
The recipient of nearly 100 patents
and Innovations Awards in the field
of advanced electronic technology.
Quality Directed products are sold
and serviced throughout North
America and around the world.
Call [phone] for more infor-
mation about our products and
services.
La compagnie derrière la
Plateforme numérique intégrée
d'AstroStart®.
Depuis sa créaction, le but
premier de Directed est d'offrir
aux consommateurs les meilleurs
systèmes de sécurité et accessoires
automobiles. Bénéficiaire de
près de 100 brevets et de Prix
d'Innovation dans l'industrie de la
technologie électronique avancée.
Les produits de qualité Directed
sont vendus et entretenus partout
en Amérique du Nord et dans le
monde entier.
Appelez au [phone] pour
avoir plus d'information au sujet
de nos produits et services.
©2017 Directed. Tous droits réservés. / All rights reserved.
Systèmes de démarrage à distance et de sécurité
Remote Start & Security Systems
tout est à votre portéeMD
nothing comes remotely closeTM
590-10099 (2017-05)
DSP625
DSP615

Congratulations
Congratulations on the purchase of your state-of-the-art AstroStart Digital System.
Reading this Owner’s Guide prior to using your system will help maximize the
use its many features. For more information please visit us online (see back cover
for URL). For any additional questions please contact your authorized Directed
dealer.
Note: Your system is configurable and may or may not include features such
as remote start or security. This guide also covers optional features which may
not be applicable to your system. Please speak with your installation special-
ist to find out which features are applicable.
Important Information
Government Regulations and Safety Information
Read the Government Regulations and Warning! Safety First
sections of this manual prior to operating this system.
WARNING! Failure to heed this information can result in death,
personal injury or property damage and may also result in the illegal
use of the system beyond its intended purpose.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at the end
of this guide. Make sure that you receive the proof of purchase from your dealer,
indicating the product was installed by an authorized AstroStart dealer.
Replacement Remote Controls
Please see your authorized dealer to order additional remote controls. Remote
control part number are typically found on the back of the device.
500-10702-01 2017-04-20

3
© 2017 Directed. All rights reserved.
Table of Contents
Congratulations .................................................................................................. 1
Important Information ......................................................................................... 1
Government Regulations and Safety Information ..................................... 1
Your Warranty..................................................................................... 1
Replacement Remote Controls................................................................ 1
2-way communication .......................................................................... 4
Getting Started.................................................................................................... 4
Keys to using this manual...................................................................... 4
Introduction ........................................................................................................ 5
2625-TX 2-Way/2615-TX 1-Way Remote Control.................................... 5
Using the System................................................................................................. 6
Commands and Confirmations .............................................................. 6
Performing Commands ......................................................................... 6
Remote Control Command Table ........................................................... 7
Basic Commands................................................................................................. 8
Arm/Lock ........................................................................................... 8
Panic Mode ........................................................................................ 8
Disarm/Unlock.................................................................................... 8
Status ................................................................................................. 8
Trunk.................................................................................................. 8
Remote Start........................................................................................ 9
Valet Modes........................................................................................ 9
Manual Valet Modes .......................................................................... 10
Emergency Override .......................................................................... 10
Battery Information............................................................................................ 10
Battery Replacement........................................................................... 11
Battery Disposal ................................................................................ 11
Patent Information ............................................................................................. 11
Government Regulations .................................................................................... 12
Warning! Safety First......................................................................................... 13
Limited Lifetime Warranty................................................................................... 15

4© 2017 Directed. All rights reserved.
2-way communication
Throughout this guide, there are references to 2-way communication and/or
confirmation of commands via the 2-way remote control. Please note that your
system may not be equipped with a 2-way remote control so such feedback will
not apply. If you would like to upgrade to a 2-way remote control, please see
your authorized AstroStart dealer. Additional parts and labor may apply.
Getting Started
Keys to using this manual
• Specific actions (in bold type) and style conventions are used consistently
throughout this manual, they are as follows:
• Press: implies pushing in and the remote will play the transmit beep to
send the command.
• Hold: is used after Press actions. The remote will play a second set of
transmitter beeps to inform the user that the other sets of command will be
transmitted.
• An asterisk (*) when used after a word or phrase denotes that additional
details can be found in related sections usually noted at the bottom of the
page or end of the section.
• Confirmation LED’s are identified by the command/function button they
are associated with.

5
© 2017 Directed. All rights reserved.
Introduction
2625-TX 2-Way/2615-TX 1-Way Remote Control
Feature Description
Command buttons
(4)
Used to perform arming, disarming, utility channel and
remote start commands
P button Used to access function levels for commands, configuration
menus for programming, Car Selection, and to access other
advanced commands.
Confirmation
LED’s*
Each button has an associated LED next to it that are
active during related operations. These LED’s are labeled
respectively as:
Lock LED, Unlock LED, Remote Start LED and Trunk LED
* 2-way communication is only applicable to the 2625-TX remote control.
Antenna
Antenna
Status LED Button
The antenna sends and receives commands or messages to and from the system.
It consists of:
• The Status LED, as a visual indicator of the system’s status.
• Button, for accessing various feature, programming, and reporting
functions of the system.

6© 2017 Directed. All rights reserved.
Using the System
Commands and Confirmations
This quick reference guide only covers basic features. Advanced features and
more information on your system can be found in the full on-line guide. Please
visit us on-line, and search using your system’s model number (found on the front
cover, the URL is located on the back cover):
The remote control sends commands that control the features of your system.
Only the 2-way remote control confirms a command using LEDs, and tones, the
1-way does not.
If a command is sent for a feature that is not included in your system or not
available (example: runtime reset when remote start is off) the remote control
displays an alert by LED and tone.
If the system doesn’t respond to a command the remote control displays an
alert by LED and tone. You may be too far from your vehicle or “out-of-range”.
Change locations and retry until successful.
Performing Commands
Press any command button directly to send one of the Basic commands to your
system.
Press the button 1-4 times before pressing a command button to send an
Advanced command.
The following Remote Control Command table defines the button press actions
required for the Basic and Advanced commands that may be available for your
system.
Example: Performing an advanced command, Silent Arm/Lock
1. Press the button three times to access Function Level 3.
2. Then, press the button immediately to send the command.
3. The system arms/locks silently and the remote control confirms by tones
and LED (2625-TX only).

7
© 2017 Directed. All rights reserved.
Remote Control Command Table
Level
Button
Basic Com-
mands x1
LEVEL 1
x2
LEVEL 2
x3
LEVEL 3
x4
LEVEL 4
Arm/Lock
(Panic)* Utility 1 Utility 3 Silent Arm/Lock Car Finder
Disarm/Unlock Utility 2 Utility 4 Silent Disarm/
Unlock
Combo Valet
(Start/Alarm
Valet)**
Remote Start**
(Remote Stop)*
Runtime Remaining
(2-way only)**
Alarm
Valet
Low Temperature
Mode**
Timer Start
Mode**
Status (Trunk)*
(2-way only) Defogger** Battery Check (2-way only)
Advance Level,
Change Car (Hold
1.5 sec.),
Enter Programming
(Hold 5 sec.)
* Commands in brackets requires to press and hold the button in order to
transmit.
** Remote Start commands are available only on systems with remote start
features.
Shortcut Commands Table:
Commands Button Combinations
Car Finder +
Low-Temp Mode +
Alarm Valet +
Start Valet +

8© 2017 Directed. All rights reserved.
Basic Commands
Arm/Lock
Press and release
The vehicle doors lock, siren/horn sound, parking lights flash, and alarm*
features are enabled. The 2-way remote control confirms by using LED and tone.
If an alarm zone is active (e.g. door is open) an alert message will follow. If
a Valet mode is enabled the 2-way remote control confirms by using LED and
tones accordingly.
Panic Mode
Press and hold
The system arms/locks, then two seconds later begins the Panic output. The
2-way remote control confirms by using LED and tones. Press the or button
to stop the panic output anytime.
Disarm/Unlock
Press and release
The vehicle doors unlock, siren/horn sound, parking lights flash, and alarm*
features are disabled. The 2-way remote control confirms by using LED and tone.
If an alarm trigger has occurred an alert message will follow. If a Valet mode is
enabled the 2-way remote control confirms by using LED and tones accordingly.
Status
Press and release (2-way remote control 2625-TX only)
The remote will generate a report status using the confirmation LED and tones
once to display the system’s current status (Lock, Unlock, Engine is running).
Trunk
Press and hold
The trunk opens (if connected) when this button is pressed for
4 seconds. The 2-way remote control (2625-TX) confirms by LED and tones.
* Available for systems with security features only.

9
© 2017 Directed. All rights reserved.
Remote Start
Press and release
Activates the remote starter. The engine and parking lights turn On and the
Remote start LED and On tones play, or the engine and parking lights turn
Off and the Remote start LED and Off tones play to confirm. If a Remote start
configuration issue prevents the engine from starting, a fault tone plays while the
parking lights flash to identify the fault.
Press and hold for at least 4 seconds to remotely stop the engine.
Alert Conditions:
Parking Light Flashes Possible Cause Solution
5 Brake ON Release Foot Brake.
6 Hood Open Close Hood.
7After performing Remote Start
command MTS not enabled. Enabled MTS Mode.
9 Start Valet on Turn Start Valet off
Valet Modes
Remote Valet Modes. The Valet commands in the remote command table turn
on/off the Alarm Valet, Start Valet, or Combo Valet Modes (both Alarm & Start
Valet).
• Alarm Valet ( + )
The Alarm Valet mode will disable included alarm features when armed/
locked. It also disables any passive arm/lock settings if programmed on.
The 2-way remote control confirms by using LED and tones.
• Start Valet ( + )
The Start Valet mode will disable remote start features until turned off. The
2-way remote control confirms by using LED and tones.
