Asus PA32UCR Series User manual

PA32UCR Series
LCD Monitor
User Guide

ii
First Edition
November 2021
Copyright © 2021 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM
ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN
THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.

iii
Contents
Contents ...................................................................................................... iii
Notices......................................................................................................... iv
Safety information ...................................................................................... vi
Care & Cleaning......................................................................................... vii
Takeback Services.................................................................................... viii
Product information for EU energy label................................................ viii
Chapter 1: Product introduction
1.1 Welcome! .................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Monitor introduction .................................................................... 1-2
1.3.1 Front view ....................................................................... 1-2
1.3.2 Back view........................................................................ 1-3
1.3.3 Other Function(s) ............................................................ 1-4
Chapter 2: Setup
2.1 Attaching the arm/base ............................................................... 2-1
2.2 Detaching the arm/base (for VESA wall mount)........................ 2-1
2.3 Adjusting the monitor.................................................................. 2-2
2.4 Connecting the cables................................................................. 2-4
2.5 Turning on the monitor................................................................ 2-5
Chapter 3: General instructions
3.1 OSD (On-Screen Display) menu ................................................ 3-1
3.1.1 How to recongure.......................................................... 3-1
3.1.2 OSD function introduction ............................................... 3-2
3.2 Specicationssummary............................................................ 3-13
3.3 Outline dimensions.................................................................... 3-15
3.4 Troubleshooting (FAQ).............................................................. 3-16
3.5 Supported operating modes ..................................................... 3-17

iv
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modications
to this unit not expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment.

v
ENERGY STAR complied product
ENERGY STAR is a joint program of the U.S. Environmental
Protection Agency and the U.S. Department of Energy helping us all
save money and protect the environment through energy efcient
products and practices.
All ASUS products with the ENERGY STAR logo comply with the ENERGY
STAR standard, and the power management feature is enabled by default. The
monitor and computer are automatically set to sleep after 10 and 30 minutes of
user inactivity. To wake your computer, click the mouse or press any key on the
keyboard. Please visit http://www.energystar.gov/powermanagement for detail
information on power management and its benets to the environment. In addition,
please visit http://www.energystar.gov for detail information on the ENERGY STAR
joint program.
NOTE: Energy Star is NOT supported on FreeDOS and Linux-based operating
system.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio
noise emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
This Class B digital apparatus meets all requirements of the Canadian
Interference - Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du
Réglement sur le matériel brouiller du Canada.

vi
Safety information
• Before setting up the monitor, carefully read all the documentation that came
with the package.
• To prevent re or shock hazard, never expose the monitor to rain or moisture.
• Never try to open the monitor cabinet. The dangerous high voltages inside the
monitor may result in serious physical injury.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied
service technician or your retailer.
• Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.
• Slots and openings on the back or top of the cabinet are provided for
ventilation. Do not block these slots. Never place this product near or over a
radiator or heat source unless proper ventilation is provided.
• The monitor should be operated only from the type of power source indicated
on the label. If you are not sure of the type of power supply to your home,
consult your dealer or local power company.
• Use the appropriate power plug which complies with your local power standard.
• Do not overload power strips and extention cords. Overloading can result in re
or electric shock.
• Avoid dust, humidity, and temperature extremes. Do not place the monitor in
any area where it may become wet. Place the monitor on a stable surface.
• Unplug the unit during a lightning storm or if it will not be used for a long period
of time. This will protect the monitor from damage due to power surges.
• Never push objects or spill liquid of any kind into the slots on the monitor
cabinet.
• To ensure satisfactory operation, use the monitor only with UL listed
computers which have appropriate configured receptacles marked between
100-240V AC.
• If you encounter technical problems with the monitor, contact a qualified
service technician or your retailer.
• Adjustment of the volume control as well as the equalizer to other settings
than the center position may increase the ear-/headphones output voltage and
therefore the sound pressure level.
This symbol of the crossed out wheeled bin indicates that the product (electrical,
electronic equipment, and mercury-containing button cell battery) should not
be placed in municipal waste. Please check local regulations for disposal of
electronic products.
AEEEyönetmeliğineuygundur

vii
Care & Cleaning
• Before you lift or reposition your monitor, it is better to disconnect the cables
and power cord. Follow the correct lifting techniques when positioning the
monitor. When lifting or carrying the monitor, grasp the edges of the monitor.
Do not lift the display by the stand or the cord.
• Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor
surface with a lint-free, non-abrasive cloth. Stubborn stains may be removed
with a cloth dampened with mild cleaner.
• Avoid using a cleaner containing alcohol or acetone. Use a cleaner intended
for use with the monitor. Never spray cleaner directly on the screen, as it may
drip inside the monitor and cause an electric shock.
The following symptoms are normal with the monitor:
• You may find slightly uneven brightness on the screen depending on the
desktop pattern you use.
• When the same image is displayed for hours, an afterimage of the previous
screen may remain after switching the image. The screen will recover slowly or
you can turn off the Power Switch for hours.
• When the screen becomes black or ashes, or cannot work anymore, contact
your dealer or service center to x it. Do not repair the screen by yourself!
Conventions used in this guide
WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying
to complete a task.
IMPORTANT: Information that you MUST follow to complete a task.
NOTE: Tips and additional information to aid in completing a task.

viii
Wheretondmoreinformation
Refer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS websites worldwide provide updated information on ASUS
hardware and software products. Refer to http://www.asus.com
2. Optional documentation
Your product package may include optional documentation that may have
been added by your dealer. These documents are not part of the standard
package.
Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest
standards for protecting our environment. We believe in providing solutions for
our customers to be able to responsibly recycle our products, batteries and other
components as well as the packaging materials.
Please go to http://csr.asus.com/english/Takeback.htm for detail recycling
information in different region.
Product information for EU energy label

1-1ASUS PA32UCR Series LCD Monitor
1.1 Welcome!
Thank you for purchasing the ASUS®LCD monitor!
The latest widescreen LCD monitor from ASUS provides a broader, brighter and
crystal-clear display, plus a host of features that enhance your viewing experience.
With these features, you can enjoy the convenience and delightful visual
experience that the monitor brings to you!
1.2 Package contents
Check your package for the following items:
LCD monitor
Monitor base
Quick start guide
Warranty card
Power cord
HDMI cable (optional)
USB Type C cable
DisplayPort cable (optional)
Color Calibration Testing Report
Input/Output port cover
ProArt welcome card
Color Calibrator (for PA32UCR-K only)
If any of the above items is damaged or missing, contact your retailer
immediately.

1-2 Chapter 1: Product introduction
1.3 Monitor introduction
1.3.1 Front view
6
2
7
4
5
3
1
Menu
Close
InputSelect
QuickFit
Brightness
HDR
1. Menu (5-way) button:
• Press this button to enter the OSD menu.
• Enacts the selected OSD menu items.
• Increases/Decreases values or moves your selection up/down/left/right.
2. Close button:
• Exits the OSD menu.
• Toggles the Key Lock function between on and off with a long press for
5 seconds.
3. Input select button:
• Selects an available input source.
Press button (Input Select button) to display HDMI-1, HDMI-2, HDMI-3,
DisplayPort, USB Type-C signals after you connect HDMI/DisplayPort/USB
Type-C cable with the monitor.
4. QuickFit Plus button:
• This is a hotkey to open the QuickFit Plus menu.
5. Shortcut
• Default: Brightness hotkey
• To change the hotkey function, go to the Shortcut > Shortcut 1 menu.

1-3ASUS PA32UCR Series LCD Monitor
6. Shortcut
• Default: HDR hotkey
• To change the hotkey function, go to the Shortcut > Shortcut 2 menu.
7. Power button/power indicator
• Turns the monitor on/off.
• The color denition of the power indicator is as the below table.
Status Description
White On
Amber Standby mode
Off Off
1.3.2 Back view
10 1235
4 6 79
8
1. AC-IN port. This port connects the power cord.
2. Power switch. Press the switch to turn on/off power.
3. HDMI ports. These ports are for connection with an HDMI compatible
device.
4. DisplayPort in. This port is for connection with a DisplayPort compatible
device.
The default setting of DisplayPort Stream in the OSD menu is DisplayPort
1.2. You can change it to DisplayPort 1.1 when your device output signal is
DisplayPort 1.1.
5. USB 2.0 Type A. This port is for service only.
6. USB 3.2 Gen1 Type-C (supports DP Alt mode). This port is for connection
with a DisplayPort/USB Type-C compatible device. This port is also for
connection with a USB Type-C cable, which supports USB power and data
delivery.
This monitor is Super-Speed USB 3.2 Gen1 compatible(5Gbps). The port offer
80W power delivery with output voltage of 5V/3A, 9V/3A, 12V/3A 15V/3A,
20V/4A.
7. USB 3.2 Gen1 Type-C. This port is for connection with a USB Type-C device.
The connection supports USB power and data delivery.

1-4 Chapter 1: Product introduction
This monitor is Super-Speed USB 3.2 Gen1 compatible (5Gbps).
8. USB 3.2 Gen1 Type A: These ports are for connection with USB devices, such
as USB keyboard/mouse, USB ash drive, etc.
Port with icon is BC1.2 compliant (5V/1.5A).
9. Earphone jack.
10. Kensington lock slot.
1.3.3 Other Function(s)
1. HDR
The monitor supports HDR format. When detecting HDR content, an "HDR ON"
message will pop up and display in the Information page.
HDR content is not supported when PIP/PBP mode is on.

2-1ASUS PA32UCR Series LCD Monitor
2.1 Attaching the arm/base
To assemble the monitor base:
1. Have the front of the monitor face down on a table.
2. Remove the input/output port cover (Figure 1).
3. Attach the base into the arm, making sure the tab on the arm ts into the
groove on the base (Figure 2).
1
2
(Figure 1) (Figure 2)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
2.2 Detaching the arm/base (for VESA
wall mount)
The detachable arm/base of this monitor is specially designed for VESA wall
mount.
To detach the arm/base:
1. Have the front of the monitor face down on a table.
2. Remove the input/output port cover (Figure 1).
3. Press the release button, and then detach the arm/base from the monitor
(Figure 2).
2
1
(Figure 1) (Figure 2)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.

2-2 Chapter 2: Setup
• The VESA wall mount kit (100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg (Screw size: M4 x 10 mm).
2.3 Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
• You can adjust the monitor’s angle from +23˚ to -5˚, and it allows 30˚ swivel
adjustment from either left or right. You can also adjust the monitor’s height
within +/- 130 mm.
30° 0°
30°
130mm
+23° ~ -5°
(Tilt) (Swivel) (Height adjustment)

2-3ASUS PA32UCR Series LCD Monitor
Pivoting the monitor
1. Lift the monitor to the highest position.
2. Tilt the monitor to its maximum angle.
3. Pivot the monitor to the angle you need.
+23° ~ -5°
It is normal that the monitor slightly shakes while you adjust the viewing angle.
4. The OSD menu item will automatically rotate when the monitor rotates.
Menu
Close
Input Select
QuickFit
Brightness
HDR
Menu
Close
Input Select
QuickFit
Brightness
HDR

2-4 Chapter 2: Setup
2.4 Connecting the cables
1. Connect the cables as the following instructions:
For service only
• To connect the power cord: Connect one end of the power cord securely to
the monitor’s AC input port, the other end to a power outlet.
• To connect the HDMI/DisplayPort/USB Type-C cable:
a. Plug one end of the HDMI/DisplayPort cable to the monitor’s HDMI/
DisplayPort/USB Type-C jack.
b. Connect the other end of the HDMI/DisplayPort/USB Type-C cable to
your device's HDMI/DisplayPort/USB Type-C jack.
• To use the earphone: connect the end with plug type to the monitor’s
earphone jack when an HDMI/DisplayPort/USB Type-C signal is fed.
• To use the USB 3.2 Gen1 ports:
»Upstream: Take the supplied USB 3.2 Gen1 Type-C cable, and plug
one end to the monitor’s USB upstream port, and the other end to your
computer’s USB 3.2 Gen1 port. Make sure your computer is installed
with the latest Windows 7/Windows 10/Windows 11 operating system.
That will enable the USB ports on the monitor to work.
»Downstream: Plug the USB Type A/Type-C cable of your device to the
monitor's USB Type A/Type-C jack.
When these cables are connected, you can choose the desired signal from the
Input Select item in the OSD menu.

2-5ASUS PA32UCR Series LCD Monitor
2. Arranging the cables
We recommend that you follow the order below to route the cable through the
cable management slot on the stand.
1 3 3 3 2 55 4 4 6
3. Attach the input/output port cover if needed.
2.5 Turning on the monitor
Press the power button . See page 1-2 for the location of the power button. The
power indicator lights up in white to show that the monitor is ON.

2-6 Chapter 2: Setup

3-1ASUS PA32UCR Series LCD Monitor
3.1 OSD (On-Screen Display) menu
3.1.1 How to reconfigure
ASUS PA32UCR
Standard Mode DisplayPort 3840 x 2160@ 60Hz
Standard Mode
sRGB Mode
Adobe RGB Mode
Rec 2020 Mode
DCI-P3 Mode
DICOM Mode
Rec. 709 Mode
ProArt Preset
1. Press the Menu (5-way) button to activate the OSD menu.
2. Move the Menu (5-way) button up/down/left/right to navigate through
the functions. Highlight the desired function and press the Menu (5-way)
button to activate it. If the function selected has a sub-menu, move the
Menu (5-way) button up/down to navigate through the sub-menu functions.
Highlight the desired sub-menu function and press the Menu (5-way)
button or move the Menu (5-way) button to activate it.
3. Move the Menu (5-way) button up/down to change the settings of the
selected function.
4. To exit and save the OSD menu, press the button or move the Menu
(5-way) left repeatedly until the OSD menu disappears. To adjust other
functions, repeat steps 1-3.

3-2 Chapter 3: OSD (On-Screen Display) menu
3.1.2 OSD function introduction
1. ProArt Preset
This function contains 13 sub-functions you can select for your preference.
Each mode has the Reset selection, allowing you to maintain your setting or
return to the preset mode.
To activate this function, you need to do the following: turn off Ambient
Effect and disable HDR on your device.
ASUS PA32UCR
Standard Mode DisplayPort 3840 x 2160@ 60Hz
Standard Mode
sRGB Mode
Adobe RGB Mode
Rec 2020 Mode
DCI-P3 Mode
DICOM Mode
Rec. 709 Mode
ProArt Preset
• Standard Mode: Best choice for document.
• sRGB Mode: Compatible with sRGB color space, sRGB mode is the best
choice for document editing.
• Adobe RGB Mode: Compatible with Adobe RGB color space.
• Rec. 2020 Mode: Compatible with Rec. 2020 color space.
• DCI-P3 Mode: Compatible with DCI-P3 color space.
• DICOM Mode: Compliant with DICOM standard, best choice for medical
image checking.
• Rec. 709 Mode: Compatible with Rec.709 color space.
• HDR_PQ DCI: Presents ST2084 with DCI-P3 color gamut and D65 white
point.
* PQ Optimized: Delivers the optimized HDR performance of this
display with as much accuracy as with ST2084 in terms of display
luminance capability.
* PQ Clip: Preserves PQ curve till displaying maximum luminance
with accuracy. ST2084 code value with higher than display
maximum will be mapped to the maximum luminance. We also
provide a maximum of 300 nits for your use.
* PQ Basic: Presents HDR performance of general HDR supported
displays.
• HDR_PQ Rec2020: Presents ST2084 with Rec.2020 color gamut and
D65 white point.
