Asus INTEL CUW(E)-FX User manual

®
CUW(E)-FX
Intel®810 FlexATX Motherboard
USER’S MANUAL
Special Features
CUWE-FX
• Intel 810E Chipset with support for 133/100/66MHz FSB
• 4MB 32-bit 133MHz SDRAM display cache onboard
CUW-FX
• Intel 810 Chipset with support for 100/66MHz FSB
• Optional 4MB 32-bit 100MHz SDRAM display cache onboard

2 ASUS CUW(E)-FX User’s Manual
USER'S NOTICE
Product Name: ASUS CUW(E)-FX
Manual Revision: 1.01 E495
Release Date: January 2000
No part of this manual, including the products and software described in it, may be repro-
duced, transmitted, transcribed, stored in a retrieval system, or translated into any language in
any form or by any means, except documentation kept by the purchaser for backup purposes,
without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OR CONDITIONS OF MERCHANTABILITYOR FITNESS FORAPAR-
TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,
EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDEN-
TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF
PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-
NESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL
OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing byASUS; or (2)
the serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trade-
marks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.
• QuickStart and JumperFree are trademarks of ASUSTeK Computer Inc.
• Intel, LANDesk, and Pentium are registered trademarks of Intel Corporation.
• IBM and OS/2 are registered trademarks of International Business Machines.
• XGstudio and SoftSynthesizer are trademarks of Yamaha Corporation.
• Symbios is a registered trademark of Symbios Logic Corporation.
• Windows and MS-DOS are registered trademarks of Microsoft Corporation.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
The product name and revision number are both printed on the product itself. Manual revi-
sions are released for each product design represented by the digit before and after the period
of the manual revision number. Manual updates are represented by the third digit in the manual
revision number.
Forprevious orupdated manuals,BIOS, drivers, orproduct releaseinformation, contactASUS
at http://www.asus.com.tw or through any of the means indicated on the following page.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUALARE FUR-
NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT
ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-
MITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR
ANYERRORS ORINACCURACIESTHATMAYAPPEARINTHIS MANUAL, INCLUD-
ING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Copyright © 2000 ASUSTeK COMPUTER INC. All Rights Reserved.

3ASUS CUW(E)-FX User’s Manual
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC. (Asia-Pacific)
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel):[phone] (English)
Fax: [phone]
Email: [email protected]
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL (America)
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
BBS: [phone]
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com/Pub/ASUS
ASUS COMPUTER GmbH (Europe)
Marketing
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
Fax: [phone]
Email: [email protected] (for marketing requests only)
Technical Support
Hotline: MB/Others: [phone] Notebook: [phone]
Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

4 ASUS CUW(E)-FX User’s Manual
CONTENTS
1. INTRODUCTION ............................................................................. 7
1.1 How This Manual Is Organized .................................................. 7
1.2 Item Checklist ............................................................................. 7
2. FEATURES ........................................................................................ 8
2.1 The ASUS CUW(E)-FX Motherboard ....................................... 8
2.1.1 Specifications..................................................................... 8
2.1.2 Optional Components ........................................................ 9
2.1.3 Performance ..................................................................... 10
2.1.4 Intelligence....................................................................... 11
2.2 ASUS CUW(E)-FX Components ............................................. 12
2.3 Component Locations ............................................................... 13
3. HARDWARE SETUP ..................................................................... 14
3.1 Motherboard Layout ................................................................. 14
3.2 Layout Contents ........................................................................ 15
3.3 Hardware Setup Procedure ....................................................... 17
3.4 Motherboard Settings................................................................ 17
3.5 System Memory (DIMM) ......................................................... 22
3.5.1 General DIMM Notes ...................................................... 22
3.5.2 Memory Installation......................................................... 23
3.6 Central Processing Unit (CPU) ................................................. 24
3.7 Expansion Cards ....................................................................... 25
3.7.1 Expansion Card Installation Procedure............................ 25
3.7.2 Assigning IRQs for Expansion Cards .............................. 26
3.7.3 Audio Modem Riser (AMR) Slot .................................... 28
3.8 External Connectors.................................................................. 29
3.9 Starting Up the First Time ........................................................ 41
4. BIOS SETUP..................................................................................... 43
4.1 Managing and Updating Your BIOS ......................................... 43
4.1.1 Upon First Use of the Computer System ......................... 43
4.1.2 Updating BIOS Procedures.............................................. 44
4.2 BIOS Setup Program ................................................................ 46
4.2.1 BIOS Menu Bar ............................................................... 47
4.2.2 Legend Bar....................................................................... 47
4.3 Main Menu................................................................................ 49
4.3.1 Primary & Secondary Master/Slave ................................ 50
4.3.2 Keyboard Features ........................................................... 54
4.4 Advanced Menu ........................................................................ 56
4.4.1 Chip Configuration .......................................................... 60
4.4.2 I/O Device Configuration ................................................ 63
4.4.3 PCI Configuration............................................................ 65
4.4.4 Shadow Configuration ..................................................... 68

5ASUS CUW(E)-FX User’s Manual
CONTENTS
4.5 Power Menu .............................................................................. 69
4.5.1 Power Up Control ............................................................ 71
4.5.2 Hardware Monitor............................................................ 73
4.6 Boot Menu ................................................................................ 74
4.7 Exit Menu ................................................................................. 76
5. SOFTWARE SETUP........................................................................ 79
5.1 Operating Systems .................................................................... 79
5.2 Starting Windows For the First Time........................................ 79
5.3 ASUS Smart Motherboard Support CD.................................... 81
5.4 LDCM Local Setup................................................................... 82
5.5 LDCM Administrator Setup...................................................... 84
5.6 ASUS PC Probe ........................................................................ 87
5.7 ASUS LiveUpdate .................................................................... 88
5.8 Drivers ...................................................................................... 89
5.9 Other ......................................................................................... 90
5.10 Uninstalling Programs .............................................................. 96
6. SOFTWARE REFERENCE ............................................................ 99
6.1 Display Properties ..................................................................... 99
6.2 ASUS PC Probe ...................................................................... 103
6.3 ASUS LiveUpdate .................................................................. 108
6.4 Using Yamaha XGstudio Player ............................................. 109
6.5 Using Yamaha XGstudio Mixer .............................................. 110
6.6 Hardware Information............................................................. 112
7. APPENDIX...................................................................................... 113
7.1 ASUS LCD-I Controller Module............................................ 113
7.2 Modem Riser........................................................................... 115
7.3 Glossary .................................................................................. 117
INDEX ................................................................................................. 121

6 ASUS CUW(E)-FX User’s Manual
FCC & DOC COMPLIANCE
FederalCommunicationsCommission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with manufacturer's instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! Any changes or modifications to this product not expressly ap-
proved by the manufacturer could void any assurances of safety or performance
and could result in violation of Part 15 of the FCC Rules.
Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washing-
ton DC: Office of the Federal Register, NationalArchives and RecordsAdministra-
tion, U.S. Government Printing Office.
CanadianDepartmentof Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.
CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.

ASUS CUW(E)-FX User’s Manual 7
1.INTRODUCTION
Sections/Checklist
1.1 How This Manual Is Organized
This manual is divided into the following sections:
1) INTRODUCTION Manual information and checklist
2) FEATURES Product information and specifications
3) HARDWARE SETUP Instructions on setting up the motherboard
4) BIOS SETUP Instructions on setting up the BIOS software
5) SOFTWARE SETUP Instructions on setting up the included software
6) SOFTWARE REFERENCE Reference material for the included software
7) APPENDIX Optional items and general reference
1.2 Item Checklist
Check that your package is complete. If you discover damaged or missing items,
please contact your retailer.
1. INTRODUCTION
Package Contents
(1) ASUS Motherboard
(1) 40-pin 80-conductor ribbon
cable for internal UltraDMA/
66 or UltraDMA/33 IDE
drives
(1) 40-pin ribbon cable for inter-
nal UltraDMA/33 IDE drives
(1) Ribboncablefor(1)5.25” and
(2) 3.5” floppy disk drives
(1) Bag of spare jumper caps
(1) Support CD with drivers and
utilities
(1) This Motherboard User’s
Manual
Optional Items
Serial port connector with
bracket (optional)
ASUS LCD-I controller module
(for LCD model only)
ASUS TV-out controller module
(optional)
ASUS IrDA-compliant infrared
module (optional)
ASUS consumer infrared set (op-
tional)
Modem riser card (optional)
USB hub module (optional)

8 ASUS CUW(E)-FX User’s Manual
2. FEATURES
Specifications
2.FEATURES
2.1 The ASUS CUW(E)-FX Motherboard
The CUW(E)-FX motherboard fromASUS is carefully designed for the demanding
PC user who wants many smart features in a small package. So what’s so smart
about the ASUS CUW(E)-FX motherboard?
2.1.1 Specifications
•Latest Intel Socket 370 Processor Support! Supports Intel’s Pentium
®
III
Coppermine and Celeron™ Mendocino processors.
•Form Factor for Easy-to-Use PC! Designed for small-size easy-to-use PCs.
This new highly flexible form factor reduces the motherboard size by as much
as 25% over the microATX design.
•Latest Intel 810 Series Chipset! Features Intel’s 810 Series chipset with the
Accelerated Hub Architecture, which provides direct connections between the
810 chipset and subsystems such as IDE controllers, USB controllers, and PCI
add-on cards.
•Integrated Graphics! The 24-bit 230MHz RAMDAC graphics controller sup-
ports 3D hyper pipelined architecture, parallel data processing and compres-
sion, precise pixel interpolation, full 2D hardware acceleration, and motion video
acceleration. The CUWE-FX comes with 4MB 32-bit 133MHz SDRAM dis-
play cache onboard, and the CUW-FX comes with optional 4MB 100MHz
SDRAM display cache.
•ASUS Graphics Driver!You can gain about 12% performance over that of the
standard graphics driver (2D high-end graphicsWinMark) usingASUS’custom
graphics driver. ASUS custom graphics driver also provides more features and
provides selection of higher refresh rates and resolutions.
•3D PositionalAudio! Brings new levels of realism to games with sounds being
positioned interactively around the user, making them truly part of the 3D vir-
tual experience. Better music reproduction is possible with MIDI utilizing
Wavetable synthesis.
•Versatile MemorySupport! DRAM controller supports asymmetrical address-
ing and two DIMM sockets support Intel PC100-compliant SDRAMs (16, 32,
64, 128, or 256MB) up to 512MB. (supports a maximum of 4 sides)
• JumperFree™!Allows processor settings and easy overclocking of frequency
and Vcore voltage all through BIOS setup.
•Legacy Free! Provides one 32-bit PCI (rev 2.2) expansion slot with no ISA,
eliminating bottlenecks and system memory management issues. PCI supports
up to 133MB/s maximum throughput. Each PCI slot can support a Bus Master
PCI card (such as SCSI or LAN cards).
• Latest Low Pin Count Multi-I/O: Provides two high-speed UART compatible
serial ports and one parallel port with EPP and ECP capabilities.
• Integrated IDE! Controller supports UltraDMA/66 up to 66MB/s, UltraDMA/
33 up to 33MB/s, and PIO Mode 4 up to 17MB/s.
•Peripheral Wake-Up! Supports Wake-On-LAN, Wake-On-Ring, Keyboard
Wake-Up, and BIOS Wake-Up.

ASUS CUW(E)-FX User’s Manual 9
2. FEATURES
2.FEATURES
Specifications-Optional
•AMR Slot! Audio Modem Riser slot supports a very affordable audio and/or
modem riser card.
• Around-the-ClockIntrusionDetection!Chassis intrusioncircuitrycanlog chas-
sis panel open events into LDCM (available in near future for this motherboard).
The onboard battery supports detection even when normal power is removed
and through a new design, battery drain is even lower than the RTC used for
keeping time!
•Firmware Hub! Provides security and other latest power computing features.
•Monitoring for your PC’s Health! Provided ASUS PC Probe or Intel LDCM
allows PC health monitoring.
•Enhanced ACPI & Anti-Boot Virus Protection! Programmable BIOS (Flash
EEPROM),offeringenhancedACPI forWindows 98 compatibility, built-in firm-
ware-based virus protection, and autodetection of most devices for virtually au-
tomatic setup.
•Smart BIOS! 4Mbit firmware gives a new easy-to-use interface which provides
more control and protection over the motherboard. Provides Vcore and CPU/
SDRAM frequency adjustments, boot block write protection, and HD/SCSI/MO/
ZIP/CD/Floppybootselection.Hardware random number generator supportsnew
security software for data protection and secured Internet transactions.
•Onboard LED! The onboard LED will light up when there is standby power.
This acts as a reminder to the user to turn OFF the power before plugging and
unplugging devices so as not to damage the motherboard, peripherals, and/or
components.
2.1.2 Optional Components
The following onboard components are optional at the time of purchase:
•SmartAudio!SoftwareAudio and HardwareAC’97V2.1 codec compliant with
sample rate conversion form 7kHz to 48kHz. Full audio output can be directed
to the chassis’ internal speaker in order to save space and money while reducing
complications associated with external speakers.
• Smart Networking! Features the Intel 82559 Fast-Ethernet LAN Controller
(fully integrated 10BASE-T/100BASE-TX). Supports Wired for Management,
remote wake-up, and OnNow initiative to reduce the Total Cost of Ownership
(TCO).
•Space Savings! Digital Flat Panel (DFP) Interface (see 7.1ASUS LCD-I Mod-
ule) gives a direct digital connection for connecting a digital flat panel (analog
flat panel must be connected to the VGA-out connector) to your PC. This inter-
face transmits sharp, bright images by eliminating digital-to-analog and analog-
to-digital conversions, which can accumulate noise and degrade image quality.
•TV Out! Displays high quality graphics and video on any television (NTSC or
PAL) with an optional TV Out module.
•No Messy Wires! Integrated Consumer IR and Serial IR supports an optional
remote control package for wireless interfacing with external peripherals, per-
sonal gadgets, or an optional remote controller.
•More USB Ports!An optional USB hub module gives you a total of four USB
ports for fast Plug-and-Play connection to your computer.

10 ASUS CUW(E)-FX User’s Manual
2. FEATURES
Performance
2.FEATURES
2.1.3 Performance
•UltraPerformance! Onboard IDE Bus Master controller with two connectors
thatsupport fourIDEdevicesintwo channels.Supports UltraDMA/66, UltraDMA/
33 (IDE DMA Mode 2), PIO Modes 3 & 4, and supports Enhanced IDE devices,
such as Tape Backup, DVD-ROM, CD-ROM, CD-R/RW, and LS-120 drives.
• DoubleorQuadrupletheIDETransferSpeed!IDEtransfersusingUltraDMA/
33 Bus Master IDE can handle rates up to 33MB/s and up to 66MB/s using
UltraDMA/66 technology. The best of all is that these new technology is com-
patible with existing ATA-2 IDE specifications so there is no need to upgrade
current IDE devices or cables.
•Concurrent PCI! Concurrent PCI optimizes system performance with concur-
rent PCI and CPU bus activities.
• SDRAM Optimized Performance! ASUS smart series motherboards support the
newgenerationmemory,SynchronousDynamicRandomAccessMemory(SDRAM),
which increases the data transfer rate to 800MB/s max using PC100-compliant
SDRAM.
• ACPIReady!ACPI (AdvancedConfigurationandPower Interface) isalsoimple-
mented on all ASUS smart series motherboards. ACPI provides more Energy
Saving Features for future operating systems (OS) supporting OS Direct Power
Management (OSPM) functionality. With these features implemented in the OS,
PCs can be ready around the clock, yet satisfy all the energy saving standards.
To fully utilize the benefits of ACPI, an ACPI-supported OS, such as Windows
98, must be used.
• Suspend and Go! Suspend-To-RAM (STR) provides maximum power savings
as an alternative to leaving the computer ON and QuickStart™ so that you do
not fall asleep waiting for system bootup.
• New Compliancy! Both the BIOS and hardware levels of the motherboard meet
the stringent requirements for Microsoft PC’99 certification. The new PC’99
requirements for systems and components are based on the following high-level
goals:SupportforPlugand Play compatibility and power managementforconfig-
uring and managing all system components, and 32-bit device drivers and instal-
lation procedures for Windows 95/98/NT. Color-coded connectors and descrip-
tive icons make identification easy as required by PC’99.
•Highest Audio Quality! AC’97 DAC/ADC built into the audio CODEC reduces
noisetoimprove audio qualityandperformance for aSNR (signal to noise ratio)of
+90dB. These features greatly improve voice synthesis and recognition.
•Extreme Graphics! The integrated motion compensation allows for smooth
MPEG1 or MPEG2 video playback. Fast 3D graphics engine allows for an ex-
citing gameplay experience.

ASUS CUW(E)-FX User’s Manual 11
2.1.4 Intelligence
• Fan Status Monitoring and Alarm! To prevent system overheat and system
damage, the CPU, power supply, and system fans can be monitored for RPM
and failure. All the fans are set for its normal RPM range and alarm thresholds.
•Temperature Monitoring and Alert! To prevent system overheat and system
damage, this motherboard supports Socket 370 processor thermal sensing and
auto-protection.
•Voltage Monitoring andAlert! System voltage levels are monitored to ensure
stable current to critical motherboard components. Voltage specifications are
more critical for future processors, so monitoring is necessary to ensure proper
system configuration and management.
• System ResourcesAlert! (Requires the future release of LDCM v6.0) Today’s
operating systems such as Windows 98, Windows NT, and OS/2, require much
more memory and hard drive space to present enormous user interfaces and run
large applications. The system resource monitor will warn the user before the
system resources are used up to prevent possible application crashes. Sugges-
tions will give the user information on managing their limited resources more
efficiently.
• Dual Function Power Button! Through the BIOS, the power button can be
defined as the “Standby” (a.k.a. Suspend or Sleep) button or as the Soft-Off (see
ATX Power Switch Lead in 3.8 External Connectors for more information)
button. Regardless of the setting, pushing the power button for more than 4
seconds will enter the Soft-Off mode.
• Remote Ring On (requires modem)! This allows a computer to be turned on
remotely through an internal or external modem. With this benefit on-hand, users
can access any information from their computers from anywhere in the world!
• Message LED (requiresACPI OS support)! Message LEDs now act as infor-
mation providers. Through the way a particular LED illuminates, the user can
determine if a message has been received from a fax/modem.Asimple glimpse
provides useful information to the user. This function requires ACPI OS and
driver support.
• Peripheral Power Up! Keyboard and/or CIR power up can be enabled or dis-
abled through BIOS setup to allow the computer to be powered ON using your
keyboard and/or Consumer IR device.
2. FEATURES
Intelligence
2.FEATURES

12 ASUS CUW(E)-FX User’s Manual
2. FEATURES
2.2 ASUS CUW(E)-FX Components
See the opposite page for locations.
MB Components
2.FEATURES
Location
Processor Support Socket 370 for Coppermine/Mendocino Processors ................ 3
Chipsets Intel 810 Series Chipset............................................................ 4
Graphics and Memory Controller Hub (GMCH)
Intel I/O Controller Hub (ICH) ................................................ 8
4Mb Firmware Hub (FWH) ..................................................... 9
Low Pin Count Multi-I/O Chipset .......................................... 13
Main Memory Maximum 512MB support
2 DIMM Sockets ...................................................................... 5
PC100 SDRAM support
Expansion Slots 1 PCI Slot ............................................................................... 10
1 Audio Modem Riser (AMR) Slot ........................................ 19
System I/O 1 USB Header........................................................................... 1
1 Floppy Disk Driver Connector .............................................. 6
2 IDE Connectors (UltraDMA33/66 Support) ......................... 7
1 Serial COM2 Header ........................................................... 21
1 Parallel Port Connector ....................................................... 23
1 Serial COM1 Connector ...................................................... 24
2 USB Connectors .................................................. (Bottom) 25
1 PS/2 Mouse Connector .............................................. (Top) 26
1 PS/2 Keyboard Connector ................................... (Bottom) 26
3D Graphics Graphics and Memory Controller Hub (GMCH)
1 VGA Monitor Output Connector ......................................... 22
TV-Out/Digital LCD Module Headers ................................... 15
4MB onboard high-speed SDRAM (optional) ....................... 12
Audio AC’97 V2.1 Audio Codec ...................................................... 18
1 Joystick/MIDI Connector .......................................... (Top) 20
1 Line Out Connector (on audio model only) ........ (Bottom) 20
1 Line In Connector (on audio model only) ........... (Bottom) 20
1 Microphone Connector (on audio model only) ... (Bottom) 20
Network Features Intel 82559 Fast-Ethernet Chipset (on LAN model only) ...... 16
1 LAN (RJ45) Connector (optional) ............................ (Top) 25
Wake-On-LAN Connector...................................................... 17
Wake-On-Ring Connector ...................................................... 14
Hardware Monitoring System Voltage Monitoring (integrated in ASUS ASIC) ....... 11
3 Fan Power and Speed Monitoring Connectors
Power ATX Power Supply Connector ................................................. 2
Form Factor FlexATX

ASUS CUW(E)-FX User’s Manual 13
2.3 Component Locations
2. FEATURES
2.FEATURES
Component Locations
18
76532
26
23
22
20
1416 89
25
24
4
17
19
13 12
1
15 1011
21

14 ASUS CUW(E)-FX User’s Manual
3. HARDWARE SETUP
3.1 Motherboard Layout
Motherboard Layout
3.H/WSETUP
(Grayed items are optional at the time of purchase.)
DIMM Socket 2 (64/72-bit, 168-pin module) DIMM Socket 1 (64/72-bit, 168-pin module)
Row
23
01
Primary IDE
Secondary
IDE
ATX Power Connector
PANEL
PCI Slot 1
CR2032 3V
Lithium Cell
CMOS Power
CD1
VIDEO
MODEM
COM2
CPU_FAN
WOL_CON
SMB
WOR
FLOPPY
®
CUW(E)-FX
Super
I/O
Intel I/O
Controller
Hub (ICH)
4Mbit
Firmware
Hub
(FWH)
Audio
Codec
Intel
810 Series
GMCH
Chipset
ASUS
ASIC
with Hardware
Monitor
Audio Codec
Setting
Audio Modem Riser
(AMR) Slot
SAFE_MD
NO_REBOOT
PCI3VSBSEL
LANPWR
LAN_EN
IR_CON
JTPWR
CHA_FAN
PWR_FAN
LCDTV0
LCDTV1
COM1
PARALLEL PORT
VGA
PS/2
T: Mouse
B: Keyboard
GAME_AUDIO
Mic
In
Line
Out
Line
In
Intel
Fast
Ethernet
ACHA
MIC2
2 MB
SDRAM
2 MB
SDRAM
USBPWR
SPKR
Bottom:
USB1
USB2
Top:
RJ45
Socket 370
FRONTUSB
19.0cm (7.48in)
22.85cm (9.0in)
CHA
VPANEL
LED1

15
3. HARDWARE SETUP
ASUS CUW(E)-FX User’s Manual
3.2 Layout Contents
Motherboard Settings
1) CODEC p.18 Onboard Audio Codec Setting (Enable/Disable)
2) PCI3VSBSEL p.18 PCI 3Volt Setting (+3 VSB/+3 Volt)
3) SAFE_MD p.19 Safe Mode (Disable/Safe Mode)
4) NO_REBOOT p.19 Automatic Timeout Reboot (Disable/No Reboot)
5) LAN_EN p.20 Onboard LAN Setting (Enable/Disable)
6) LANPWR p.20 Onboard LAN Power Setting (+3 Volt/+3 VSB)
7) USBPWR p.21 USB Power Up (+5Volt/+5VSB)
Expansion Slots
1) DIMM1, DIMM2 p.23 168-Pin DIMM Memory Support
2) Socket 370 p.24 Central Processing Unit (CPU) Socket
4) PCI1 p.25 32-bit PCI Bus Expansion Slots
5) AMR p.28 Audio Modem Riser Slot
Connectors
1) PS2KBMS p.29 PS/2 Mouse Connector (6-pin female)
2) PS2KBMS p.29 PS/2 Keyboard Connector (6-pin female)
3) USB p.30 Universal Serial Bus Ports 1 & 2 (Two 4-pin female)
4) PRINTER p.30 Parallel Port Connector (25-pin female)
5) COM1 p.30 Serial Port COM1 Connector (9-pin male)
6) VGA p.31 Monitor (VGA) Output Connector (15-pin female)
7) GAME_AUDIO p.31 Joystick/MIDI Connector (15-pin female)(optional)
8) GAME_AUDIO p.31 Audio Port Connectors (Three 1/8” female)(optional)
9) RJ45 p.31 Fast-Ethernet Port Connector (RJ45) (optional)
10) PRIMARY IDE p.32 Primary/Secondary IDE Connectors (Two 40-1pins)
SECONDARY IDE
11) FLOPPY p.32 Floppy Disk Drive Connector (34-1pins)
12) WOL_CON p.33 Wake-On-LAN Connector (3 pins)
13) WOR p.33 Wake-On-Ring Connector (2 pins)
14) IDELED p.34 IDE Activity LED Lead (2 pins)
15) CHA_, CPU_, PWR_FAN p.34 Chassis,CPU,PowerSupplyFanConnectors(Three3-pin)
16) IR_CON p.35 Infrared Module Connectors (10-1 pins)
17) COM2 p.35 Serial COM2 Port Header (10-1 pins)
18) SMB p.36 SMBus Connector (5-1 pins)
19) LCDTV0/LCDTV1 p.36 LCD-TV Headers (Two 14 pins) (optional)
20) MIC2 p.36 Internal Microphone Connector (3 pins)
21) VIDEO/CD1/MODEM p.37 Internal Audio Connectors (Three 4-pins)
Layout Contents
3. H/W SETUP

16 ASUS CUW(E)-FX User’s Manual
3. HARDWARE SETUP
Layout Contents
3. H/W SETUP
22) FRONTUSB p.37 Front Panel USB Header (10-1 pin block)
23) SPKR p.38 Headphone True-Level Line Out Header (3-pins)
24) ACHA p.38 Chassis Intrusion Lead (2-pins)
25) ATXPWR p.39 ATX Power Supply Connector (20 pins)
26) JTPWR p.39 Thermal Sensor Connector (2 pins)
27) KEYLOCK (PANEL) p.40 System Power LED Lead (3-1 pins)
28) KEYLOCK (PANEL) p.40 Keyboard Lock Switch Lead (2 pins)
29) SPEAKER (PANEL) p.40 System Warning Speaker Connector (4 pins)
30) RESET (PANEL) p.40 Reset Switch Lead (2 pins)
31) PWR (PANEL) p.40 ATX Power / Soft-Off Switch Lead (2 pins)
32) SMI (PANEL) p.40 System Management Interrupt Switch Lead (2 pins)
33) LED (PANEL) p.40 System Message LED (2 pins)

17
3. HARDWARE SETUP
ASUS CUW(E)-FX User’s Manual
Motherboard Settings
3. H/W SETUP
3.3 Hardware Setup Procedure
Before using your computer, you must complete the following steps:
• Check Motherboard Settings
• Install Memory Modules
• Install the Central Processing Unit (CPU)
• Install Expansion Cards
• Connect Ribbon Cables, Panel Wires, and Power Supply
WARNING! Make sure that you unplug your power supply when adding or
removing system components. Failure to do so may cause severe damage to
your motherboard, peripherals, and/or components. The onboard LED (see 3.1
Motherboard Layout for location) when lit acts as a reminder that the system is
in suspend or soft-off mode and not powered OFF.
3.4 Motherboard Settings
This section explains in detail how to change your motherboard’s function settings
through the use of switches and/or jumpers.
WARNING! Computer motherboards and expansion cards contain very delicate
Integrated Circuit (IC) chips. To protect them against damage from static electric-
ity, you should follow some precautions whenever you work on your computer.
1. Unplug your computer when working on the inside.
2. Use a grounded wrist strap before handling computer components. If you do
nothave one, touch both of your hands to a safely grounded object or to a metal
object, such as the power supply case.
3. Hold components by the edges and try not to touch the IC chips, leads or con-
nectors, or other components.
4. Placecomponentsona grounded antistatic pad oronthebagthat came with the
component whenever the components are separated from the system.

18 ASUS CUW(E)-FX User’s Manual
3. HARDWARE SETUP
Motherboard Settings
3. H/W SETUP
1) OnboardAudio Codec Setting (CODEC)
available on audio model only
The onboard audio CODEC may be enabled or disabled using all of these jump-
ers. Disable the onboard audio CODEC if you are using a PCI audio card on any
of the expansion slots or a primaryAMR on theAMR slot (seeAMR Slot later in
this section). If using a PCI audio expansion card, OnboardAC’97Audio Con-
troller in 4.4.2 I/O Device Configuration must also be disabled.
Setting CODEC
Enable [1-2] [1-2] [1-2] [1-2] (default)
Disable [2-3] [2-3] [2-3] [2-3]
®
CUW(E)-FX
CUW(E)-FX Audio Codec Setting DisableEnable
1
2
3
1
2
3
SPK
ADN# AUD_EN1
AUD_EN2
SPK
ADN# AUD_EN1
AUD_EN2
2) PCI 3 Volt Setting (PCI3VSBSEL)
This jumper allows you to select the voltage supplied to PCI devices. If you
have PCI devices that require auxiliary power, set this jumper to Enable 3 VSB.
Setting PCI3VBSEL
+3 VSB [1-2] (default)
+3 Volt [2-3]
®
CUW(E)-FX
CUW(E)-FX PCI 3 Volt Selection
+3 VSB
PCI3VSBSEL
+3 Volt
123
123

19
3. HARDWARE SETUP
ASUS CUW(E)-FX User’s Manual
Motherboard Settings
3. H/W SETUP
3) Safe Mode Setting (SAFE_MD)
Usually socket 370 processors have locked frequency multiples. In this case,
there is no way to exceed the specified multiple whether through motherboard
settings or BIOS setup. With unlocked socket 370 processors, exceeding the
specified multiple is possible through BIOS setup. Exceeding the specified mul-
tiple may result in hanging during bootup. If this occurs, enable Safe Mode to
force a multiple of 2 in order to enter BIOS setup to correct the problem.
Setting SAFE_MD
Disable [1-2] (default)
Safe Mode [2-3]
®
CUW(E)-FX
Disable
(Default) Safe Mode
SAFE_MD
CUW(E)-FX Safe Mode Setting
1
2
3
1
2
3
4) Automatic Timeout Reboot Setting (NO_REBOOT)
The motherboard is set so that when the BIOS detects a hang (timeout) during
bootup, the motherboard will automatically reboot. If rebooting is repeating in-
effectively, set this jumper to No Reboot to disable auto-reboot.
Setting NO_REBOOT
Disable [1-2] (default)
No Reboot [2-3]
®
CUW(E)-FX
Disable
(Default) No Reboot
NO_REBOOT
CUW(E)-FX Reboot Setting
1
2
3
1
2
3

20 ASUS CUW(E)-FX User’s Manual
3. HARDWARE SETUP
Motherboard Settings
3. H/W SETUP
5) Onboard LAN Setting (LAN_EN)
The onboard LAN may be enabled/disabled with this jumper.
Setting LAN_EN
Enable [1-2] (default)
Disable [2-3]
®
CUW(E)-FX
CUW(E)-FX LAN Setting
Enable
(Default) Disable
123 123
LAN_EN
6) Onboard LAN Power Setting (LANPWR)
The onboard LAN power may be set to +3 Volt or +3VSB. Select +3Volt if you
do not have a power supply with 720mAstandby power. Selecting +3 VSB will
allow the use of Wake-on-LAN but may not allow system wakeup if the power
supply’s standby power is insufficient.
Setting LANPWR
+3 Volt [2-3] (default)
+3 VSB [1-2]
®
CUW(E)-FX
CUW(E)-FX LAN Power Setting
+3 VSB
LANPWR
+3 Volt
(Default)
123
123
