Asus KGPE-D16 User manual

Motherboard
KGPE-D16

ii
E8847
Revised Edition V3
November 2013
Copyright © 2013 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form or by any means,
except documentation kept by the purchaser for backup purposes, without the express written permission
of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND
SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY
OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,
INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.

iii
Contents
Notices........................................................................................................ vii
Safety information .................................................................................... viii
About this guide .......................................................................................... x
KGPE-D16 specications summary......................................................... xii
Chapter 1: Product introduction
1.1 Welcome! ...................................................................................... 1-3
1.2 Package contents......................................................................... 1-3
1.3 Serial number label...................................................................... 1-4
1.4 Special features............................................................................ 1-4
1.4.1 Product highlights ........................................................... 1-4
1.4.2 Innovative ASUS features ............................................... 1-6
Chapter 2: Hardware information
2.1 Before you proceed ..................................................................... 2-3
2.2 Motherboard overview................................................................. 2-6
2.2.1 Placement direction ........................................................ 2-6
2.2.2 Screw holes .................................................................... 2-6
2.2.3 Motherboard layouts ....................................................... 2-7
2.2.4 Layout contents............................................................... 2-8
2.3 Central Processing Unit (CPU) ................................................. 2-10
2.3.1 Installing the CPU ......................................................... 2-10
2.3.2 Installing the CPU heatsink and fan.............................. 2-13
2.4 System memory ......................................................................... 2-16
2.4.1 Overview ....................................................................... 2-16
2.4.2 Memory Congurations................................................. 2-17
2.4.3 Installing a DIMM .......................................................... 2-19
2.4.4 Removing a DIMM ........................................................ 2-19
2.5 Expansion slots.......................................................................... 2-20
2.5.1 Installing an expansion card ......................................... 2-20
2.5.2 Conguring an expansion card ..................................... 2-20
2.5.3 Interrupt assignments ................................................... 2-21
2.5.4 MIO/PCIE slot ............................................................... 2-22
2.5.5 PCI Express x16 slots (x16 link; x8 link) ....................... 2-22
2.5.6 PCI slot ......................................................................... 2-22
2.5.7 PIKE slot ....................................................................... 2-22

iv
Contents
2.5.8 Installing an ASUS PIKE RAID card ............................. 2-23
2.5.9 Installing ASMB4 management board........................... 2-24
2.5.10 Connecting the thermal sensor cable ........................... 2-24
2.5.11 Installing the audio card ................................................ 2-25
2.6 Jumpers ...................................................................................... 2-26
2.7 Connectors ................................................................................. 2-31
2.7.1 Rear panel connectors.................................................. 2-31
2.7.2 Internal connectors ....................................................... 2-32
Chapter 3: Powering up
3.1 Starting up for the rst time........................................................ 3-3
3.2 Powering off the computer.......................................................... 3-4
3.2.1 Using the OS shut down function.................................... 3-4
3.2.2 Using the dual function power switch.............................. 3-4
Chapter 4: BIOS setup
4.1 Managing and updating your BIOS ............................................ 4-3
4.1.1 ASUS EZ Flash 2 utility................................................... 4-3
4.1.2 BUPDATER utility............................................................ 4-4
4.1.3 ASUS CrashFree BIOS 3 utility ...................................... 4-6
4.2 BIOS setup program .................................................................... 4-7
4.2.1 BIOS menu screen.......................................................... 4-8
4.2.2 Menu bar......................................................................... 4-8
4.2.3 Navigation keys............................................................... 4-8
4.2.4 Menu items ..................................................................... 4-9
4.2.5 Submenu items ............................................................... 4-9
4.2.6 Conguration elds ......................................................... 4-9
4.2.7 Pop-up window ............................................................... 4-9
4.2.8 Scroll bar......................................................................... 4-9
4.2.9 General help ................................................................... 4-9
4.3 Main menu .................................................................................. 4-10
4.3.1 System Time [xx:xx:xx] ................................................. 4-10
4.3.2 System Date [Day xx/xx/xxxx]....................................... 4-10
4.3.3 SATA1–6 ........................................................................4-11
4.3.4 Storage Conguration ................................................... 4-12
4.3.5 System Information ....................................................... 4-13

v
Contents
4.4 Advanced menu ......................................................................... 4-15
4.4.1 CPU Conguration ........................................................ 4-15
4.4.2 Chipset Conguration ................................................... 4-17
4.4.3 Onboard Devices Conguration.................................... 4-27
4.4.4 USB Conguration ........................................................ 4-28
4.4.5 PCIPnP ......................................................................... 4-29
4.4.6 Event Log Conguration ............................................... 4-29
4.5 Server menu ............................................................................... 4-30
4.6 Power menu................................................................................ 4-32
4.6.1 Suspend Mode [Auto] ................................................... 4-32
4.6.2 Repost Video on S3 Resume [No] ................................ 4-32
4.6.3 ACPI 2.0 Support [ACPI v2.0]....................................... 4-32
4.6.4 ACPI APIC support [Enabled] ....................................... 4-32
4.6.5 APM Conguration........................................................ 4-33
4.6.6 Hardware Monitor ......................................................... 4-34
4.7 Boot menu .................................................................................. 4-36
4.7.1 Boot Device Priority ...................................................... 4-36
4.7.2 Hard Disk Drives; CDROM Drives ................................ 4-36
4.7.3 Boot Settings Conguration .......................................... 4-37
4.7.4 Security ......................................................................... 4-38
4.8 Tools menu ................................................................................. 4-40
4.9 Exit menu.................................................................................... 4-41
Chapter 5: RAID conguration
5.1 Setting up RAID............................................................................ 5-3
5.1.1 RAID denitions .............................................................. 5-3
5.1.2 Installing hard disk drives................................................ 5-4
5.1.3 Setting the RAID item in BIOS ........................................ 5-4
5.2 FastBuild Utility............................................................................ 5-5
5.2.1 Creating a RAID set ........................................................ 5-6
5.2.2 Deleting a RAID set ...................................................... 5-12
5.2.3 Viewing the Drive Assignment....................................... 5-14
5.2.4 Viewing the Controller Conguration............................. 5-15

vi
Contents
Chapter 6: Driver installation
6.1 RAID driver installation ............................................................... 6-3
6.1.1 Creating a RAID driver disk ............................................ 6-3
6.1.2 Installing the RAID controller driver ................................ 6-5
6.2 AMD®processor driver installation .......................................... 6-15
6.3 LAN driver installation............................................................... 6-16
6.4 ATI SM Bus controller driver installation................................. 6-20
6.5 Display driver installation ......................................................... 6-21
6.6 Management applications and utilities installation ................ 6-24
6.6.1 Running the support DVD ............................................. 6-24
6.6.2 Drivers menu................................................................. 6-24
6.6.3 Utilities menu ................................................................ 6-25
6.6.4 Make disk menu............................................................ 6-25
6.6.5 Contact information....................................................... 6-25
Appendix: Reference information
A.1 KGPE-D16 block diagram............................................................A-3

vii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with manufacturer’s instructions, may
cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modications
to this unit not expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
REACH
Complying with the REACH (Registration, Evaluation, Authorization, and Restriction
of Chemicals) regulatory framework, we publish the chemical substances in our
products at ASUS REACH website at http://csr.asus.com/english/REACH.htm.

viii
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing devices to or from the system, ensure that the
power cables for the devices are unplugged before the signal cables are
connected. If possible, disconnect all power cables from the existing system
before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure
that all power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord.
These devices could interrupt the grounding circuit.
• Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using,
contact your local power company.
• If the power supply is broken, do not try to x it by yourself. Contact a
qualied service technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all
the manuals that came with the package.
• Before using the product, make sure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in
any area where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied
service technician or your retailer.

ix
Australia statement notice
From 1 January 2012 updated warranties apply to all ASUS products, consistent with
the Australian Consumer Law. For the latest product warranty details please visit
http://support.asus.com. Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a replacement or refund for a
major failure and compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major failure.
If you require assistance please call ASUS Customer Service 1300 2787 88 or visit
us at http://support.asus.com
DO NOT throw the motherboard in municipal waste. This product has been
designed to enable proper reuse of parts and recycling. This symbol of the crossed
out wheeled bin indicates that the product (electrical and electronic equipment)
should not be placed in municipal waste. Check local regulations for disposal of
electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste. This
symbol of the crossed out wheeled bin indicates that the battery should not be
placed in municipal waste.

x
About this guide
This user guide contains the information you need when installing and conguring
the motherboard.
How this guide is organized
This user guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new
technologies it supports.
• Chapter 2: Hardware information
This chapter lists the hardware setup procedures that you have to perform
when installing system components. It includes description of the switches,
jumpers, and connectors on the motherboard.
• Chapter 3: Powering up
This chapter describes the power up sequence and ways of shutting down
the system.
• Chapter 4: BIOS setup
This chapter tells how to change system settings through the BIOS Setup
menus. Detailed descriptions of the BIOS parameters are also provided.
• Chapter 5: RAID conguration
This chapter provides instructions for setting up, creating, and conguring
RAID sets using the available utilities.
• Chapter 6: Driver installation
This chapter provides instructions for installing the necessary drivers for
different system components.
Where to nd more information
Refer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and
software products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty
yers, that may have been added by your dealer. These documents are not
part of the standard package.

xi
Conventions used in this guide
To make sure that you perform certain tasks properly, take note of the following
symbols used throughout this manual.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-
than sign means that you must press the
enclosed key.
Example: <Enter> means that you must press
the Enter or Return key.
<Key1+Key2+Key3> If you must press two or more keys
simultaneously, the key names are linked with
a plus sign (+).
Example: <Ctrl+Alt+Del>
Command Means that you must type the command
exactly as shown, then supply the required
item or value enclosed in brackets.
Example: At the DOS prompt, type the
command line: format A:/S
DANGER/WARNING: Information to prevent injury to yourself
when trying to complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
NOTE: Tips and additional information to help you complete a
task.
IMPORTANT: Instructions that you MUST follow to complete a
task.

xii
KGPE-D16 specications summary
Processor Support / System Bus 2 x socket G34 (LGA 1944)
4/8/12/16 Core AMD®Opteron™ 6300 Series
4/8/12/16 Core AMD®Opteron™ 6200 Series
8/12 Core AMD®Opteron™ 6100 Series
* Please check http://www.asus.com/
server_workstation/ for the latest update
HyperTransport™ Technology 3.0,
6.4 GT/s per link (triple link)
Core Logic Northbridge: AMD®SR5690
Southbridge: AMD®SP5100
Form Factor SSI EEB, 12” x 13”
ASUS Features Fan Speed
Control
V
Rack Ready
(Rack and
Pedestal dual
use)
V
Memory Total Slots 16 (4-channel per CPU)
Capacity Maximum up to 256GB (RDIMM)
Maximum up to 64GB (UDIMM)
Memory Type DDR3 800/1066/1333/1600 UDIMM with ECC / non
ECC
DDR3 800/1066/1333/1600 RDIMM
* DDR3 1600 can only be supported with AMD®
Opteron™ 6300/6200 series processor
Memory Size 1GB, 2GB, 4GB, 8GB, 16GB (RDIMM)
1GB, 2GB, 4GB (UDIMM)
Expansion Slots
(follow SSI
Location #)
Total PCI/PCI-X/
PCI-E Slots
6
Slot Location 1 1 x PCI 32bit/33 MHz
Slot Location 2 1 x PCI-E x16 (Gen2 x8 Link)
Slot Location 3 1 x PCI-E x16 (Gen2 x16 Link)
(Auto switch to x8 Link if slot 2 is occupied )
Slot Location 4 1 x PCI-E x8 (Gen2 x4 Link)
Slot Location 5 1 x PCI-E x16 (Gen2 x16 Link)
Slot Location 6 1 x PCI-E x16 (Gen2 x16 Link for 1U FH/FL Card)
(Auto turn off if slot 5 is occupied; MIO supported )
Additional Slot 1 1* PIKE Slot for Stroage expansion
(continued on the next page)

xiii
KGPE-D16 specications summary
Storage SATA Controller AMD®SP5100:
6 SATA2 300MB/s ports
PROMISE®SW RAID (For Linux/Windows)
Supports software RAID 0, 1, 10 & 5
SAS Controller Optional:
ASUS PIKE 1064E 4-port SAS RAID card
ASUS PIKE 1068E 8-port SAS RAID card
ASUS PIKE 1078 8-port SAS HW RAID card
ASUS PIKE 6480 8-port SAS RAID card
ASUS PIKE 2008 8-port SAS2 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS2 6G RAID card with
RAID 5
Networking LAN 2 x Intel 82574L
1 x Mgmt LAN
Graphic VGA Aspeed AST2050 8MB
Onboard I/O
Connectors
PSU Connector 24-pin SSI power connector + 8-pin SSI 12V + 8-pin
SSI 12V power connector
USB
Connectors
4 (support 7 USB port)
(One for internal Type A USB connector )
Management
Connector
Onboard socket for optional management card
Fan Header 8 x 4pin
SMBus 2
Chassis Intruder 1
Serial Port
Header
1
TPM Header 1
1394 Header 1
Rear I/O
Connectors
External Serial
Port
1
External USB
Port
2
VGA Port 1
RJ-45 2 + 1 Management Port
PS/2 KB/Mouse 1
(continued on the next page)

xiv
KGPE-D16 specications summary
Management
Solution
Out of Band
Remote
Management
Optional ASMB4-iKVM for KVM-over-Internet
Monitoring CPU
Temperature
V
FAN RPM V
Environment Operation temperature: 10℃—35℃
Non operation temperature: -40℃—70℃
Non operation humidity: 20%—90%
(Non condensing)
*Specications are subject to change without notice.
DO NOT touch the Northbridge chipset! The Northbridge chipset may become
overheated. Remember to provide sufcinet air ow to keep the system stable.

1
Chapter 1: Product
introduction
This chapter describes the motherboard
features and the new technologies it supports.

ASUS KGPE-D16
Chapter summary 1
1.1 Welcome! ...................................................................................... 1-3
1.2 Package contents......................................................................... 1-3
1.3 Serial number label...................................................................... 1-4
1.4 Special features............................................................................ 1-4

ASUS KGPE-D16 1-3
1.1 Welcome!
Thank you for buying an ASUS®KGPE-D16 motherboard!
The motherboard delivers a host of new features and latest technologies, making it
another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the
items in your package with the list below.
1.2 Package contents
Check your motherboard package for the following items.
If any of the above items is damaged or missing, contact your retailer.
Standard Gift Box Pack Standard Bulk Pack
Cables SATA data cable 6 --
Accessories IO shield 1 1
Application CD Support CD 1 1
Documentation User Guide 1 1
Packing Qty. 1pcs per carton 10pcs per carton
Optional items Description
PIKE 1064E LSI 4 port SAS RAID card
PIKE 1068E LSI 8 port SAS RAID card
PIKE 1078 LSI 8 port SAS RAID card with Hardware RAID 5, 6, 50, 60
PIKE 6480 Marvell 8 port SAS RAID card
PIKE 2008 LSI 8 port SAS2 RAID card
ASMB4-iKVM Remote Management solution provides KVM over IP solution.
ASUS MIO audio card Discrete 8 channel audio card provides clearest high quality
sounds

1-4 Chapter 1: Product introduction
1.4 Special features
1.4.1 Product highlights
Latest processor technology
This motherboard supports the latest AMD®Opteron™ 6300/6200/6100 series
processors in LGA 1944 package with integrated memory controller to support
4-channel (8 DIMM per CPU) DDR3 memory. AMD®Opteron™ 6300/6200/6100
series processor supports AMD®HyperTransport™ technology with a system bus
of up to 6.4GT/s per link. AMD®Opteron™ 6300/6200/6100 series processor is the
one of the most powerful and energy-efcient CPUs in the world.
AMD 4-16 Core Architecture
The motherboard supports AMD 4-16 core processors with discrete L2 cache
structure for each core and shared L3 cache to meet demands for more powerful
computing.
HyperTransport™ technology 3.0 (HT3)
HyperTransport™ technology 3.0 (HT3) is a high-speed, low latency, point-to-
point link designed to improve the overall system balance and scalability with the
maximum interconnect rate of 6.4GT/s.
1.3 Serial number label
Before requesting support from the ASUS Technical Support team, you must take
note of the motherboard's serial number containing 12 characters xxS2xxxxxxxx
shown as the gure below. With the correct serial number of the product, ASUS
Technical Support team members can then offer a quicker and satisfying solution
to your problems.
xxS2xxxxxxxx
KGPE-D16 Made
in
China
合格

ASUS KGPE-D16 1-5
DDR3 memory support
The KGPE-D16 supports UDIMM and RDIMM DDR3 memory that features
data transfer rates of 1600/1333/1066/800 MHz to meet the higher bandwidth
requirements of server and workstation applications. The 4-channel DDR3 architecture
boosts system performance, eliminating bottlenecks. Furthermore, the supply voltage
for the memory is reduced from 1.8 V for DDR2 to just 1.5V for DDR3. This voltage
reduction limits the power consumption and heat generation of DDR3 which makes it
an ideal memory solution.
PCI Express™ interface
The motherboard fully supports PCI Express, the latest I/O interconnect
technology that speeds up the PCI bus. PCI Express features point-to-point serial
interconnections between devices and allows higher clockspeeds by carrying data
in packets. This high speed interface is software compatible with existing PCI
specications.
82574L LAN Solution
The motherboard comes with dual Gigabit LAN controllers and ports which provide
a total solution for your networking needs. The onboard Intel 82574L Gigabit LAN
controllers use the PCI Express interface and could achieve network throughput
close to Gigabit bandwidth.
Serial ATA II technology
The motherboard supports the Serial ATA II 3 Gb/s technology through the
Serial ATA interface and Intel ICH10R chipset. The Serial ATA II specication
provides twice the bandwidth of the current Serial ATA products with a host of new
features, including Native Command Queuing (NCQ), Power Management (PM)
Implementation Algorithm, and Hot Swap. Serial ATA allows thinner, more exible
cables with lower pin count and reduced voltage requirements.
USB 2.0 technology
The motherboard implements the Universal Serial Bus (USB) 2.0 specication,
dramatically increasing the connection speed from the 12 Mbps bandwidth on USB
1.1 to a fast 480 Mbps on USB 2.0. USB 2.0 is backward compatible with USB 1.1.
Temperature, fan, and voltage monitoring
The CPU temperature is monitored to prevent overheating and damage. The
system fan rotations per minute (RPM) is monitored for timely failure detection.
The chip monitors the voltage levels to ensure stable supply of current for critical
components.

1-6 Chapter 1: Product introduction
1.4.2 Innovative ASUS features
ASUS Fan Speed technology
The ASUS Fan Speed technology smartly adjusts the fan speeds according to the
system loading to ensure quiet, cool, and efcient operation.
PIKE (Proprietary I/O Kit Expansion)
PIKE is an on-demand upgrade kit for users. This ASUS unique feature enables
users to choose their preferred I/O solutions. ASUS provides multiple SAS
solutions for different segments and purposes and PIKE saves lots of validation
efforts and hardware cost for end users. Moreover, the special patent design offers
multiple I/O solutions without occupying the Slot 6 in 1U system.
ASUS MIO Audio card
Enjoy high-end sound quality! The ASUS MIO audio card is a discrete 8-channel
high denition audio (High Denition Audio previously codenamed Azalia) CODEC
enable clearest high quality audio output, jack-sensing feature, retasking functions,
and multi-streaming technology that simultaneously send different audio streams to
different destinations.
