Asus M2r32-mvp - motherboard

Motherboard

M2R32-MVP

iiii

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form

or by any means, except documentation kept by the purchaser for backup purposes, without the

express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or

altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the

serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR

IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS

DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS

OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS

HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR

ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR

INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND

SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY

OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL,

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identification or

explanation and to the owners’ benefit, without intent to infringe.

E2717E2717

E2717

First Edition V1First Edition V1

First Edition V1

July 2006July 2006

July 2006

iiiiii

iii

Contents

Notices ............................................................................................... vii

Safety information ............................................................................ viii

About this guide ................................................................................. ix

M2R32-MVP specifications summary .................................................. xi

Chapter 1:Chapter 1:

Chapter 1: Product introductionProduct introduction

Product introductionProduct introduction

Product introduction

1.1 Welcome! .............................................................................. 1-1

1.2 Package contents ................................................................. 1-1

1.3 Special features .................................................................... 1-2

1.3.1 Product highlights................................................... 1-2

1.3.2 Innovative ASUS features ....................................... 1-4

Chapter 2:Chapter 2:

Chapter 2: Hardware informationHardware information

Hardware informationHardware information

Hardware information

2.1 Before you proceed .............................................................. 2-1

2.2 Motherboard overview .......................................................... 2-2

2.2.1 Placement direction ................................................ 2-2

2.2.2 Screw holes ............................................................ 2-2

2.2.3 Motherboard layout ................................................ 2-3

2.2.4 Layout Contents ..................................................... 2-4

2.3 Central Processing Unit (CPU) .............................................. 2-6

2.3.1 Installing the CPU.................................................... 2-6

2.3.2 Installing the heatsink and fan ................................ 2-8

2.4 System memory ................................................................. 2-11

2.4.1 Overview ............................................................... 2-11

2.4.2 Memory Configurations ......................................... 2-12

2.4.3 Installing a DDR2 DIMM ......................................... 2-14

2.4.4 Removing a DDR2 DIMM ........................................ 2-14

2.5 Expansion slots ................................................................... 2-15

2.5.1 Installing an expansion card .................................. 2-15

2.5.2 Configuring an expansion card.............................. 2-15

2.5.3 Interrupt assignments .......................................... 2-16

2.5.4 Two PCI slots ........................................................ 2-17

2.5.5 Two PCI Express x1 slots ...................................... 2-17

2.5.6 Two PCI Express x16 slots ................................... 2-17

iviv

Contents

2.6 Jumper ............................................................................... 2-19

2.7 Connectors ......................................................................... 2-22

2.7.1 Rear panel connectors .......................................... 2-22

2.7.2 Internal connectors ............................................... 2-24

Chapter 3:Chapter 3:

Chapter 3: Powering upPowering up

Powering upPowering up

Powering up

3.1 Starting up for the first time................................................ 3-1

3.2 Powering off the computer .................................................. 3-2

3.2.1 Using the OS shut down function ........................... 3-2

3.2.2 Using the dual function power switch .................... 3-2

Notices

Federal Communications Commission StatementFederal Communications Commission Statement

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions:

•

This device may not cause harmful interference, and

•

This device must accept any interference received including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with

manufacturer’s instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment to an outlet on a circuit different from that to

which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications StatementCanadian Department of Communications Statement

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise

emissions from digital apparatus set out in the Radio Interference

Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with CanadianThis class B digital apparatus complies with Canadian

This class B digital apparatus complies with Canadian

ICES-003.ICES-003.

ICES-003.

The use of shielded cables for connection of the monitor to the graphics

card is required to assure compliance with FCC regulations. Changes or

modifications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate

this equipment.

vivi

Safety information

Electrical safetyElectrical safety

Electrical safety

•

To prevent electrical shock hazard, disconnect the power cable from

the electrical outlet before relocating the system.

•

When adding or removing devices to or from the system, ensure that

the power cables for the devices are unplugged before the signal cables

are connected. If possible, disconnect all power cables from the existing

system before you add a device.

•

Before connecting or removing signal cables from the motherboard,

ensure that all power cables are unplugged.

•

Seek professional assistance before using an adapter or extension cord.

These devices could interrupt the grounding circuit.

•

Make sure that your power supply is set to the correct voltage in your

area. If you are not sure about the voltage of the electrical outlet you

are using, contact your local power company.

•

If the power supply is broken, do not try to fix it by yourself. Contact a

qualified service technician or your retailer.

Operation safetyOperation safety

Operation safety

•

Before installing the motherboard and adding devices on it, carefully read

all the manuals that came with the package.

•

Before using the product, make sure all cables are correctly connected

and the power cables are not damaged. If you detect any damage,

contact your dealer immediately.

•

To avoid short circuits, keep paper clips, screws, and staples away from

connectors, slots, sockets and circuitry.

•

Avoid dust, humidity, and temperature extremes. Do not place the

product in any area where it may become wet.

•

Place the product on a stable surface.

•

If you encounter technical problems with the product, contact a qualified

service technician or your retailer.

The symbol of the crossed out wheeled bin indicates that the product

(electrical and electronic equipment) should not be placed in municipal

waste. Please check local regulations for disposal of electronic products.

viivii

vii

About this guide

This user guide contains the information you need when installing and

configuring the motherboard.

How this guide is organizedHow this guide is organized

How this guide is organized

This guide contains the following parts:

••

•Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introduction

This chapter describes the features of the motherboard and the new

technology it supports.

••

•Chapter 2: Hardware informationChapter 2: Hardware information

Chapter 2: Hardware informationChapter 2: Hardware information

Chapter 2: Hardware information

This chapter lists the hardware setup procedures that you have to

perform when installing system components. It includes description of

the switches, jumpers, and connectors on the motherboard.

••

•Chapter 3: Powering upChapter 3: Powering up

Chapter 3: Powering upChapter 3: Powering up

Chapter 3: Powering up

This chapter describes the power up sequence, the vocal POST

messages, and ways of shutting down the system.

Where to find more informationWhere to find more information

Where to find more information

Refer to the following sources for additional information and for product

and software updates.

1.1.

1. ASUS websitesASUS websites

ASUS websitesASUS websites

ASUS websites

The ASUS website provides updated information on ASUS hardware

and software products. Refer to the ASUS contact information.

2.2.

2. Optional documentationOptional documentation

Optional documentationOptional documentation

Optional documentation

Your product package may include optional documentation, such as

warranty flyers, that may have been added by your dealer. These

documents are not part of the standard package.

viiiviii

viii

Conventions used in this guideConventions used in this guide

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the

following symbols used throughout this manual.

DANGER/WARNING:DANGER/WARNING:

DANGER/WARNING: Information to prevent injury to yourself

when trying to complete a task.

CAUTION:CAUTION:

CAUTION: Information to prevent damage to the components

when trying to complete a task.

NOTE:NOTE:

NOTE: Tips and additional information to help you complete a

task.

IMPORTANT:IMPORTANT:

IMPORTANT: Instructions that you MUST follow to complete a

task.

TypographyTypography

Typography

Bold textBold text

Bold text Indicates a menu or an item to select.

Italics

Used to emphasize a word or a phrase.

<Key> Keys enclosed in the less-than and greater-than sign means

that you must press the enclosed key.

Example: <Enter> means that you must press the Enter or

Return key.

<Key1+Key2+Key3> If you must press two or more keys simultaneously, the

key names are linked with a plus sign (+).

Example: <Ctrl+Alt+D>

Command Means that you must type the command exactly as shown,

then supply the required item or value enclosed in

brackets.

Example: At the DOS prompt, type the command line:

afudos /i[filename]

afudos /iM2R32-MVP.ROM

ixix

M2R32-MVP specifications summary

CPUCPU

CPU

ChipsetChipset

Chipset

System busSystem bus

System bus

MemoryMemory

Memory

Expansion slotsExpansion slots

Expansion slots

CrossFire™CrossFire™

CrossFire™

StorageStorage

Storage

High DefinitionHigh Definition

High Definition

AudioAudio

Audio

LANLAN

LAN

IEEE 1394aIEEE 1394a

IEEE 1394a

USBUSB

USB

BIOS featuresBIOS features

BIOS features

(continued on the next page)

Socket AM2 for AMD Athlon™ 64 X2/Athlon™ 64 FX/

Athlon™ 64/Sempron™ processor

AMD64 architecture enables simultaneous 32- and

64-bit computing

Supports AMD Cool ‘n’ Quiet™ Technology

Supports AMD HyperTransport™ Technology

Supports AMD Live!™ Ready

ATI™ CrossFire™ Xpress 3200/ATI™ SB600

2000/1600 MT/s

Dual-channel memory architecture

4 x 240-pin DIMM sockets support up to 8 GB

unbufferred ECC/non-ECC 800/667/533 MHz DDR2

memory modules

2 x PCI Express™ x16 slots with CrossFire support at full

x16, x16 mode

2 x PCI Express™ x1 slots

2 x PCI slots

Supports ATI CrossFire™ graphics cards (both at x16

mode)

ATI SB600 Southbridge supports:

- 1 x IDE connector for two Ultra DMA

133/100/66/33 hard disks

- 4 x Serial ATA I/II 3.0 Gb/s hard disks with RAID 0,

RAID 1, and RAID 0+1

JMicron

360 SATA controller supports:

- 1 x External Serial ATA 3.0Gb/s hard disk (SATA On-

the-Go)

SoundMAX

ADI 1988A 8-channel High Definition Audio

CODEC

Supports Multi-streaming and Universal Audio Jack

Coaxial S/PDIF Out port on the rear panel

Marvell

88E8001 Gigabit LAN controller, featuring

AI NET2

VIA VT6308P controller supports:

- 1 x IEEE 1394a connector at mid-board

- 1 x IEEE 1394a connector at rear-board

Supports up to 10 USB 2.0/1.1 ports

8 Mb Flash ROM, AMI BIOS, PnP, DMI2.0, SM BIOS 2.3,

WfM2.0

Stack Cool 2

ASUS SATA On-the-Go (External Serial ATA port on the

rear panel)

Noise Filter

ASUS EZ DIY:

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 2

- ASUS Q-Connector

ASUS MyLogo2

ASUS Q-Fan2 Technology

Intelligent overclocking tools:

- AI NOS™ (Non-delay Overclocking System)

- AI Overclocking (intelligent CPU frequency tuner)

- ASUS PEG Link (automatic performance tuning for

single/dual graphics cards)

- AI Clock Skew

ASUS O.C. Profile: overclocking configuration-sharing

tool

Precision Tweaker supports:

- DIMM voltage: 12-step DRAM voltage control

- Core voltage: Adjustable CPU voltage at 0.025 V

increment

Stepless Frequency Selection(SFS) allows:

- FSB tuning from 200 MHz to 400 MHz at 1 MHz increment

- PCI Express frequency tuning from 100 MHz to

150 MHz at 1 MHz increment

Overclocking protection:

- ASUS C.P.R. (CPU Parameter Recall)

1 x PS/2 mouse port

1 x PS/2 keyboard port

1 x LAN (RJ-45) port

4 x USB 2.0/1.1 ports

1 x IEEE1394a port

1 x Coaxial S/PDIF Out port

1 x External Serial ATA port

1 x Serial (COM) port

8-Channel audio ports

WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, Chassis

Intrusion, PXE, and RPL

M2R32-MVP specifications summary

ASUS specialASUS special

ASUS special

featuresfeatures

features

OverclockingOverclocking

Overclocking

Rear panelRear panel

Rear panel

ManageabiityManageabiity

Manageabiity

(continued on the next page)

xixi

3 x USB 2.0 connectors for six additional USB 2.0 ports

1 x Floppy disk drive connector

1 x IDE connector

4 x SATA connectors

1 x IEEE1394a connector

1 x CD audio in connector

1 x S/PDIF Out connector

1x CPU/2 x Chassis/1 x Power fan connectors

1 x 24-pin EATX power connector

1 x 4-pin ATX 12 V power connector

Chassis intrusion connector

Front panel High Definition Audio connector

System panel connector

Drivers

ASUS PC Probe II

ASUS Update

Anti-virus software (OEM version)

ATX form factor: 12 in x 9.6 in (30.5 cm x 24.5 cm)

InternalInternal

Internal

connectorsconnectors

connectors

Support CDSupport CD

Support CD

contentscontents

contents

Form factorForm factor

Form factor

*Specifications are subject to change without notice.

M2R32-MVP specifications summary

xiixii

xii

Product

information

This chapter describes the

motherboard features and the new

technologies it supports

ASUS A8R32-MVP DELUXEASUS A8R32-MVP DELUXE

ASUS A8R32-MVP DELUXE

Chapter summary

1.1 Welcome! .............................................................................. 1-1

1.2 Package contents ................................................................. 1-1

1.3 Special features .................................................................... 1-2

ASUS M2R32-MVPASUS M2R32-MVP

ASUS M2R32-MVP 1-11-1

1-11-1

1-1

1.1 Welcome!

Thank you for buying an ASUSThank you for buying an ASUS

Thank you for buying an ASUS

®®

M2R32-MVP motherboard!M2R32-MVP motherboard!

M2R32-MVP motherboard!

The motherboard delivers a host of new features and latest technologies,

making it another standout in the long line of ASUS quality motherboards!

Before you start installing the motherboard, and hardware devices on it,

check the items in your package with the list below.

1.2 Package contents

Check your motherboard package for the following items.

MotherboardMotherboard

Motherboard ASUS M2R32-MVP motherboard

CablesCables

Cables 1 x Floppy disk drive signal cable

1 x Ultra DMA cable 133/100/66 cable

2 x Serial ATA cables

1 x 2-port Serial ATA power cable

1 x 2-port USB 2.0 module

AccessoriesAccessories

Accessories I/O shield

1 x ASUS Q-Connector set (USB, IEEE1394a, system

panel; retail version only)

Application CDsApplication CDs

Application CDs ASUS motherboard support CD

DocumentationDocumentation

Documentation User guide

If any of the above items is damaged or missing, contact your retailer.

1-21-2

1-2 Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introduction

1.3 Special features

1.3.11.3.1

1.3.1 Product highlightsProduct highlights

Product highlightsProduct highlights

Product highlights

Latest processor technologyLatest processor technology

Latest processor technology

The motherboard supports AMD socket AM2 single-core Athlon 64/

Sempron and dual-core Athlon 64 X2/Athlon 64 FX processors with 2MB/

1MB/512KB L2 cache, which is based on 64-bit architecture. It features

2000/1600 MT/s HyperTransport Bus, dual-channel un-buffered DDR2 800

memory support and AMD Cool ‘n’ Quiet Technology. See page 2-6 for

details.

ATI CrossFire™ Xpress 3200ATI CrossFire™ Xpress 3200

ATI CrossFire™ Xpress 3200

The motherboard features ATI CrossFire™ Xpress 3200 support, delivering

improved overclocking and optimal PCI Express device performance. The

combined multi-GPU power boosts image quality and rendering speed for

the highest quality images. With its optimized peer-to-peer and general link

performance GPU sharing, you are a step ahead in graphics and gaming

effects. The chipset allows higher antialiasing, anisotropic filtering, sharing,

and texture settings. The ATI CrossFire™ Xpress 3200 also comes with the

ATI Catalyst™ Control Center that allows you to get real-time 3D-rendered

previews of adjustments to your display configurations and advanced 3D

settings.

PCI Express™ interfacePCI Express™ interface

PCI Express™ interface

The motherboard fully supports PCI Express, the latest I/O interconnect

technology that speeds up the PCI bus. PCI Express features point-to-point

serial interconnections between devices and allows higher clockspeeds by

carrying data in packets. This high speed interface is software compatible

with existing PCI specifications. See page 2-18 for details.

Gigabit LAN solutionGigabit LAN solution

Gigabit LAN solution

The motherboard comes with the Marvell

88E8001 Gigabit LAN controller

to provide the total solution for your networking needs, LAN, and file

sharing requirements. See page 2-23 for details.

ASUS M2R32-MVPASUS M2R32-MVP

ASUS M2R32-MVP 1-31-3

1-31-3

1-3

Serial ATA 3.0 Gb/s technology and SATA-On-The-GoSerial ATA 3.0 Gb/s technology and SATA-On-The-Go

Serial ATA 3.0 Gb/s technology and SATA-On-The-Go

The motherboard fully supports the Serial ATA II 3.0 Gb/s technology

through the Serial ATA interfaces and the ATI

SB 600 chipset. The Serial

ATA 3.0 Gb/s specification provides twice the bandwidth of the current

Serial ATA products with a host of new features, including Power

Management (PM) Implementation Algorithm. Serial ATA allows for thinner,

more flexible cables with lower pin count and reduced voltage required.

Leveraging these Serial ATA 3.0 Gb/s features is the SATA-On-The-Go.

Supported by the JMicron

Serial ATA controller, the Serial ATA 3.0 Gb/s

connector (on the rear panel) provides smart setup and hot-plug function.

See pages 2-24 and 2-26 for details.

8-channel high definition audio8-channel high definition audio

8-channel high definition audio

Onboard is the ADI

AD1988A High Definition Audio 8-channel audio

CODEC. This CODEC is fully-compliant with Intel

High Definition Audio

standard (192 KHz, 24-bit audio). With the CODEC, 8-channel audio ports,

and S/PDIF interfaces, you can connect your computer to home theater

decoders to produce crystal-clear digital audio.

IEEE 1394a supportIEEE 1394a support

IEEE 1394a support

The IEEE 1394a interface provides high-speed and flexible PC connectivity

to a wide range of peripherals and devices compliant to IEEE 1394a

standards. The IEEE 1394a interface allows up to 400 Mbps transfer rates

through simple, low-cost, high-bandwidth asynchronous (real-time) data

interfacing between computers, peripherals, and consumer electronic

devices such as camcorders, VCRs, printers,TVs, and digital cameras. See

page 2-30 for details.

USB 2.0 technologyUSB 2.0 technology

USB 2.0 technology

The motherboard implements the Universal Serial Bus (USB) 2.0

specification, dramatically increasing the connection speed from the

12 Mbps bandwidth on USB 1.1 to a fast 480 Mbps on USB 2.0. USB 2.0 is

backward compatible with USB 1.1. See pages 2-24 and 2-29 for details.

1-41-4

1-4 Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introduction

1.3.21.3.2

1.3.2 Innovative ASUS featuresInnovative ASUS features

Innovative ASUS featuresInnovative ASUS features

Innovative ASUS features

ASUS Stack Cool 2ASUS Stack Cool 2

ASUS Stack Cool 2

ASUS Stack Cool 2 is a fan-less and zero-noise cooling solution that lowers

the temperature of critical heat generating components. The motherboard

uses a special design on the printed circuit board (PCB) to dissipate heat

that critical components generate.

AI NET2AI NET2

AI NET2

The AI NET2 is a BIOS-based diagnostic tool that detects and reports

Ethernet cable faults and shorts. With this utility, you can easily monitor

the condition of the Ethernet cable(s) connected to the LAN (RJ-45)

port(s). During the bootup process, AI NET2 immediately diagnoses the

LAN cable(s) and reports shorts and faults up to 100 meters at 1 meter

accuracy.

Precision TweakerPrecision Tweaker

Precision Tweaker

This feature allows you to fine tune the CPU/memory/Northbridge voltage

and gradually increase the memory Front Side Bus (FSB) and PCI Express

frequency at 1MHz increment to achieve maximum system performance.

AI NOS™ (Non-Delay Overclocking System)AI NOS™ (Non-Delay Overclocking System)

AI NOS™ (Non-Delay Overclocking System)

ASUS Non-delay Overclocking System™ (NOS) is a technology that

auto-detects the CPU loading and dynamically overclocks the CPU speed

only when needed. See page 4-19 for details.

Noise FilterNoise Filter

Noise Filter

This feature detects repetitive and stationary noises (non-voice signals)

like computer fans, air conditioners, and other background noises then

eliminates it in the incoming audio stream while recording.

ASUS M2R32-MVPASUS M2R32-MVP

ASUS M2R32-MVP 1-51-5

1-51-5

1-5

PEG Link Mode for two graphics cardsPEG Link Mode for two graphics cards

PEG Link Mode for two graphics cards

This feature enhances your PCI Express graphics card performance, allowing

the motherboard to automatically adjust the PCI Express graphics link mode

to the correct frequency based on the system configuration. Four

additional settings are available for overclocking the PEG Link Mode.

ASUS Q-Fan 2 technologyASUS Q-Fan 2 technology

ASUS Q-Fan 2 technology

The ASUS Q-Fan 2 technology smartly adjusts the CPU and chassis fans

speed according to the system loading to ensure quiet, cool, and efficient

operation.

ASUS CrashFree BIOS 3ASUS CrashFree BIOS 3

ASUS CrashFree BIOS 3

The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data

from a USB flash disk containing the BIOS file. This utility saves users the

cost and hassle of buying a replacement BIOS chip.

ASUS EZ Flash 2ASUS EZ Flash 2

ASUS EZ Flash 2

EZ Flash 2 is a user-friendly BIOS update utility. Simply press the predefined

hotkey to launch the utility and update the BIOS without entering the OS.

Update your BIOS easily without preparing a bootable diskette or using an

OS-based flash utility.

Q-ConnectorQ-Connector

Q-Connector

The ASUS Q-Connector allows you to connect or disconnect chassis front

panel cables in one easy step with one complete module. This unique

adapter eliminates the trouble of plugging in one cable at a time, making

connection quick and accurate.

ASUS O.C. ProfileASUS O.C. Profile

ASUS O.C. Profile

The motherboard features the ASUS BIOS Profile that allows users to

conveniently store or load multiple BIOS settings. The BIOS settings can be

stored in the CMOS or a separate file, giving users freedom to share and

distribute their favorite settings.

1-61-6

1-6 Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introductionChapter 1: Product introduction

Chapter 1: Product introduction

ASUS Multi-language BIOSASUS Multi-language BIOS

ASUS Multi-language BIOS

The multi-language BIOS allows you to select the language of your choice

from the available options. The localized BIOS menus allow easier and faster

configuration.

ASUS MyLogo2™ASUS MyLogo2™

ASUS MyLogo2™

ASUS My Logo2™ is the new feature present in the motherboard that

allows you to personalize and add style to your system with customizable

and animated boot logos.

C.P.R. (CPU Parameter Recall)C.P.R. (CPU Parameter Recall)

C.P.R. (CPU Parameter Recall)

The C.P.R. feature of the motherboard BIOS allows automatic re-setting to

the BIOS default settings in case the system hangs due to overclocking.

When the system hangs due to overclocking, C.P.R. eliminates the need to

open the system chassis and clear the RTC data. Simply shut down and

reboot the system, and the BIOS automatically restores the CPU default

setting for each parameter.
