Asus P3V133 User manual

®
P3V133
PC133 Motherboard
USER’S MANUAL

ASUS P3V133 User’s Manual
2
USER'S NOTICE
Product Name: ASUS P3V133
Manual Revision: 1.02 E507
Release Date: February 2000
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form
or by any means, except documentation kept by the purchaser for backup purposes, without the
express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EI-
THER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WAR-
RANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FORAPARTICULAR
PURPOSE. IN NO EVENT SHALLASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR
AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUEN-
TIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS,
LOSS OF USE OR DATA, INTERRUPTION OF BUSINESSAND THE LIKE), EVEN IFASUS
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Product warranty or service will not be extended if: (1) the product is repaired, modified or al-
tered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the
serial number of the product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trademarks
or copyrights of their respective companies, and are used only for identification or explanation
and to the owners’ benefit, without intent to infringe.
• VIAand Apollo Pro133 are trademarks of VIA Technologies, Inc.
• Intel, LANDesk, Pentium, and Celeron are trademarks of Intel Corporation.
• IBM and OS/2 are registered trademarks of International Business Machines.
• Symbios is a registered trademark of Symbios Logic Corporation.
• Windows and MS-DOS are registered trademarks of Microsoft Corporation.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
• Trend and ChipAwayVirus are trademarks of Trend Micro, Inc.
The product name and revision number are both printed on the product itself. Manual revisions
are released for each product design represented by the digit before and after the period of the
manual revision number. Manual updates are represented by the third digit in the manual revision
number.
For previous or updated manuals, BIOS, drivers, or product release information, contact ASUS at
http://www.asus.com.tw or through any of the means indicated on the following page.
SPECIFICATIONSAND INFORMATIONCONTAINED INTHISMANUALAREFURNISHED
FORINFORMATIONALUSEONLY,ANDARESUBJECTTOCHANGEATANYTIMEWITH-
OUTNOTICE,ANDSHOULD NOTBE CONSTRUEDASACOMMITMENTBYASUS.ASUS
ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURA-
CIES THAT MAYAPPEAR IN THIS MANUAL, INCLUDING THE PRODUCTSAND SOFT-
WARE DESCRIBED IN IT.
Copyright © 2000 ASUSTeK COMPUTER INC. All Rights Reserved.

ASUS P3V133 User’s Manual 3
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC. (Asia-Pacific)
Marketing
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel):[phone] (English)
Fax: [phone]
Email: [email protected]
WWW: www.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL (America)
Marketing
Address: 6737 Mowry Avenue, Mowry Business Center, Building 2
Newark, CA 94560, USA
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
Email: [email protected]
WWW: www.asus.com
FTP: ftp.asus.com/Pub/ASUS
ASUS COMPUTER GmbH (Europe)
Marketing
Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
Fax: [phone]
Email: [email protected] (for marketing requests only)
Technical Support
Hotline: MB/Others: [phone] Notebook: [phone]
Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
WWW: www.asuscom.de
FTP: ftp.asuscom.de/pub/ASUSCOM

ASUS P3V133 User’s Manual
4
CONTENTS
1. INTRODUCTION 7
1.1 How This Manual Is Organized ................................................... 7
1.2 Item Checklist .............................................................................. 7
2. FEATURES 8
2.1 The ASUS P3V133 ...................................................................... 8
2.1.1 Specifications ..................................................................... 8
2.1.2 Special Features................................................................ 10
2.1.3 Performance Features ....................................................... 10
2.1.4 Intelligence ....................................................................... 11
2.2 P3V133 Motherboard Components ........................................... 12
3. HARDWARE SETUP 14
3.1 P3V133 Motherboard Layout .................................................... 14
3.2 Layout Contents ......................................................................... 15
3.3 Hardware Setup Steps ................................................................ 16
3.4 Motherboard Settings ................................................................. 16
3.5 System Memory (DIMM) .......................................................... 20
3.6 Central Processing Unit (CPU) .................................................. 23
3.6.1 Quick CPU Installation Procedure ................................... 23
3.6.2 Attaching the Heatsink ..................................................... 24
3.6.3 Installing the Universal Retention Mechanism ................ 24
3.6.4 Installing the Processor .................................................... 26
3.6.6 Recommended Heatsinks for Slot 1 Processors ............... 27
3.6.5 Removing the Processor ................................................... 27
3.6.7 ASUS Smart Thermal Solutions....................................... 28
3.6.8 Precautions ....................................................................... 29
3.7 Expansion Cards ........................................................................ 30
3.8 External Connectors ................................................................... 32
3.9 Starting Up the First Time.......................................................... 41
4. BIOS SETUP 42
4.1 Managing and Updating Your BIOS .......................................... 42
4.1.1 Upon First Use of the Computer System.......................... 42
4.1.2 Updating BIOS Procedures (only when necessary) ......... 43
4.2 BIOS Setup Program.................................................................. 45
4.2.1 BIOS Menu Bar................................................................ 46
4.2.2 Legend Bar ....................................................................... 46

ASUS P3V133 User’s Manual 5
CONTENTS
4.3 Main Menu ................................................................................. 48
4.3.1 Primary & Secondary Master/Slave ................................. 49
4.4 Advanced Menu ......................................................................... 54
4.4.1 Chip Configuration........................................................... 56
4.4.2 I/O Device Configuration ................................................. 58
4.4.3 PCI Configuration ............................................................ 60
4.4.4 Shadow Configuration ...................................................... 63
4.5 Power Menu ............................................................................... 64
4.5.1 Power Up Control............................................................. 66
4.5.2 Hardware Monitor ............................................................ 68
4.6 Boot Menu ................................................................................. 69
4.7 Exit Menu................................................................................... 71
5. SOFTWARE SETUP 73
5.1 Operating Systems ..................................................................... 73
5.1.1 Windows 98 First Time Installation ................................. 73
5.2 P3V Series Motherboard Support CD........................................ 74
5.3 ASUS PC Probe Setup ............................................................... 75
5.4 Adobe Acrobat Reader ............................................................... 76
5.5 Install VIA 4 in 1 Driver ............................................................ 77
5.6 Install PC-Cillin ......................................................................... 78
5.7 Uninstalling Programs................................................................ 79
6. SOFTWARE REFERENCE 81
6.1 ASUS PC Probe ......................................................................... 81
7. APPENDIX 87
7.1 ASUS S370-133 CPU Card ....................................................... 87
7.1.1 Using the ASUS S370-133 ............................................... 87
7.1.2 Setting up the ASUS S370-133 ........................................ 88
7.1.3 ASUS S370-133 Jumper Settings..................................... 88
7.2 ASUS PCI-L101 Fast Ethernet Card ......................................... 89
7.2.1 Features ............................................................................ 90
7.2.2 Software Driver Support .................................................. 90
7.2.3 Questions and Answers .................................................... 90
7.3 Glossary ..................................................................................... 91

ASUS P3V133 User’s Manual
6
FCC & DOC COMPLIANCE
FederalCommunications CommissionStatement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with manufacturer's instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interfer-
ence by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! Any changes or modifications to this product not expressly ap-
proved by the manufacturer could void any assurances of safety or performance
and could result in violation of Part 15 of the FCC Rules.
Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the
Federal Register, National Archives and Records Administration, U.S. Government Printing Office.
CanadianDepartment ofCommunications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.
CetappareilnumériquedelaclasseBestconformeàlanormeNMB-003duCanada.

ASUS P3V133 User’s Manual 7
1.1 How This Manual Is Organized
This manual is divided into the following sections:
1. INTRODUCTION Manual information and checklist
2. FEATURES Production information and specifications
3. HARDWARE SETUP Instructions on setting up the motherboard.
4. BIOS SETUP Instructions on setting up the BIOS
5. SOFTWARE SETUP Instructions on setting up the included software
6. SOFTWARE REFERENCE Reference material for the included software
7. APPENDIX Optional items and general reference
1.2 Item Checklist
Check that your package is complete. If you discover damaged or missing items,
contact your retailer.
(1) ASUS Motherboard
(1) Universal Retention Mechanism for SECC2/SECC/SEPP processors
(1) Ribbon cable for master and slave UltraDMA/66 or UltraDMA/33 IDE drives
(1) Ribbon cable for (1) 5.25”and (2) 3.5”floppy disk drives
(1) Bag of spare jumper caps
(1) Support CD with drivers and utilities
(1) This Motherboard User’s Manual
ASUS IrDA-compliant infrared module (optional)
ASUS S370 Series CPU cards (optional)
ASUS PCI-L101 Wake-On-LAN 10/100 Ethernet Card (optional)
1. INTRODUCTION
1. INTRODUCTION
Manual / Checklist

8ASUS P3V133 User’s Manual
2.1 The ASUS P3V133
The ASUS P3V133 motherboard is carefully designed for the demanding PC user
who wants advanced features processed by the fastest processors.
2.1.1 Specifications
•Latest Intel Processor Support
Intel Pentium
®
III 100MHz FSB, Katmai core SECC2
Intel Pentium
®
III B 133MHz FSB, Katmai core SECC2
Intel Pentium
®
III E 100MHz FSB, Coppermine core SECC2
Intel Pentium
®
III EB 133MHz FSB, Coppermine core SECC2
Intel Pentium
®
II 100MHz/66MHz FSB SECC
Intel Celeron™III 66MHz FSB SEPP
•VIAApollo Pro133 Chipset: Features the VIAVT82C693A system controller
and VIA VT82C596B PCI to ISA bridge with support for AGP 2x mode; 133/
100/66MHz Front Side Bus (FSB); and UltraDMA/66 / UltraDMA/33.
•PC133 Memory / VCM Support: Equipped with three Dual Inline Memory
Module (DIMM) sockets to support Intel PC133/PC100-compliant (8, 16, 32,
64, 128, 256, or 512MB) or NEC’s Virtual Channel (VC) SDRAMs up to 1.5GB.
VC SDRAMs is a new DRAM core architecture that dramatically improves the
memory system’s ability to service multimedia requirements.
•Multi-Cache: Supports processors with 512, 256, 128, or 0KB Pipelined Burst
Level 2 cache.
•AGP Slot: Supports AGP cards for high performance, component level inter-
connection targeted at 3D graphical applications supporting 133MHz 2X mode.
•UltraDMA/66 Support: Comes with an onboard PCI Bus Master IDE control-
ler with two connectors that support four IDE devices on two channels. Sup-
ports UltraDMA/66, UltraDMA/33, PIO Modes 3 & 4 and Bus Master IDE
DMA Mode 2, and Enhanced IDE devices, such as DVD-ROM, CD-ROM, CD-
R/RW, LS-120, and Tape Backup drives.
•Wake-On-LAN Connector: Supports Wake-On-LAN activity through an op-
tional ASUS PCI-L101 10/100 Fast Ethernet PCI card (see 7. Appendix).
•Wake-On-Ring Connector: Supports Wake-On-Ring activity through a PCI
modem card that supports a WOR connector.
•PC Health Monitoring: Provides an easy way to examine and manage system
status information, such as CPU and systerm voltages, temperatures, and fan
status through the onboard hardware ASUS ASIC and the bundled ASUS PC
Probe.
2. FEATURES
Specifications
2. FEATURES

ASUS P3V133 User’s Manual 9
2. FEATURES
2. FEATURES
Specifications
•SMBus:Features the System Management Bus interface, which is used to physi-
cally transport commands and information between SMBus devices.
•PCI/ISAExpansion Slots:Provides four 32-bit PCI (Rev. 2.2) expansion slots,
which can support Bus Master PCI cards, such as SCSI or LAN cards (PCI
supports up to 133MB/s maximum throughput) and three 16-bit ISA slots.
•Super Multi-I/O: Provides two high-speed UART compatible serial ports and
one parallel port with EPP and ECP capabilities. UART2 can also be directed
from COM2 to the Infrared Module for wireless connections.
•Enhanced ACPI & Anti-Boot Virus Protection: Programmable BIOS (Flash
EEPROM),offeringenhancedACPI forWindows 98compatibility, built-infirm-
ware-based virus protection, and autodetection of most devices for virtually au-
tomatic setup.
•IrDA: Supports an optional infrared port module for wireless interface.
•Concurrent PCI: Concurrent PCI allows multiple PCI transfers from PCI mas-
ter busses to the memory and processor.
•Universal Retention Mechanism: Supports a Pentium®III / II processor pack-
aged in a Single Edge Contact Cartridge (SECC2/SECC) or a Celeron™proces-
sor packaged in a Single Edge Processor Package (SEPP).
•Smart BIOS: 2MB firmware provides Vcore and CPU/SDRAM frequency ad-
justments, boot block write protection, and HD/SCSI/MO/ZIP/CD/Floppy boot
selection.
•Integrated Infrared Support: Integrated IR supports an optional remote con-
trol package for wireless interfacing with external peripherals, personal gad-
gets, or an optional remote controller.

10 ASUS P3V133 User’s Manual
2. FEATURES
Performance
2. FEATURES
2.1.2 Special Features
•ACPI Ready: Advanced Configuration Power Interface (ACPI) provides more
Energy Saving Features for operating systems that support OS Direct Power
Management (OSPM) functionality. With these features implemented in the OS,
PCs can be ready around the clock, yet satisfy all the energy saving standards.
To fully utilize the benefits of ACPI, anACPI-supported OS, such as Windows
98 must be used.
•Easy Installation: Incorporates BIOS that supports autodetection of hard disk
drives, PS/2 mouse, and Plug and Play devices to make the setup of hard disk
drives, expansion cards, and other devices virtually automatic.
•PC’98 Compliant: Both the BIOS and hardware levels of ASUS smart series
motherboards meet PC’98 compliancy. The new PC’98 requirements for sys-
tems and components are based on the following high-level goals: Support for
Plug and Play compatibility and power management for configuring and man-
aging all system components, and 32-bit device drivers and installation proce-
dures for Windows95/98/NT.
•Symbios SCSI BIOS: Supports optional ASUS SCSI controller cards through
the onboard SYMBIOS firmware.
2.1.3 Performance Features
•Concurrent PCI: Concurrent PCI allows multiple PCI transfers from PCI mas-
ter busses to the memory and processor.
•High-Speed Data Transfer Interface: IDE transfers using UltraDMA/33 Bus
Master IDE can handle rates up to 33MB/s. This motherboard with its chipset
and support for UltraDMA/66 doubles the UltraDMA/33 burst transfer rate to
66.6MB/s. UltraDMA/66 is backward compatible with both DMA/33 and DMA
and with existing DMA devices and systems so there is no need to upgrade
current EIDE/IDE drives and host systems. (UltraDMA/66 requires a 40-pin
80-conductor cable to be enabled and/or for UltraDMA Mode 4.)
•SDRAMOptimized Performance:Supports thenew generationmemory - Syn-
chronous Dynamic RandomAccess Memory (SDRAM) which increases the data
transfer rate to 1066MB/s max using PC133-compliant SDRAM.

ASUS P3V133 User’s Manual 11
2. FEATURES
2. FEATURES
Intelligence
2.1.4 Intelligence
•Auto Fan Off: The system fans will power off automatically even in sleep
mode. This function reduces both energy consumption and system noise, and is
an important feature in implementing silent PC systems.
•Dual Function Power Button: Pushing the power button for less than 4 sec-
onds when the system is in the working state places the system into one of two
states: sleep mode or soft-off mode, depending on the BIOS or OS setting (see
PWR Button < 4 Secs in 4.5 Power Menu). When the power button is pressed
for more than 4 seconds, the system enters the soft-off mode regardless of the
BIOS setting.
•Fan Status Monitoring and Alarm: To prevent system overheat and system
damage, the CPU, power supply, and system fans can be monitored for RPM
and failure. All fans are set for its normal RPM range and alarm thresholds.
•PS/2Keyboard/MousePower Up:Keyboard/Mouse Power Up can be enabled
or disabled to allow the computer to be powered on by either pressing the space
bar, Ctrl-Esc, or Power keys (see 4.5.1 Power Up Control).
•Message LED (requiresACPI OS support): Turbo LEDs now act as informa-
tion providers. Through the way a particular LED illuminates, the user can de-
termine if there are messages waiting in the mailbox.Asimple glimpse provides
useful information to the user.
•Remote Ring On (requires modem): This allows a computer to be turned on
remotely through an internal or external modem. With this benefit on-hand, users
can access vital information from their computers from anywhere in the world!
•System Resources Alert: Today’s operating systems such as Windows 95/98/
NT and OS/2, require much more memory and hard drive space to present enor-
mous user interfaces and run large applications. The system resource monitor
will warn the user before the system resources are used up to prevent possible
application crashes. Suggestions will give the user information on managing
their limited resources more efficiently.
•Temperature Monitoring and Alert: CPU temperature is monitored by the
ASUSASIC through the CPU’s internal thermal diode (on Pentium III, Pentium
II (Deschutes), and PPGA370 Celeron in conjunction with theASUS S370-D or
S370-L CPU card) to prevent system overheat and system damage.
•Voltage Monitoring andAlert: System voltage levels are monitored to ensure
stable voltage to critical motherboard components. Voltage specifications are
more critical for future processors, so monitoring is necessary to ensure proper
system configuration and management.
•Chassis Intrusion Detection: Supports chassis-intrusion monitoring through
the ASUS ASIC. A chassis intrusion event is kept in memory on battery power
for more protection.

12 ASUS P3V133 User’s Manual
2. FEATURES
2. FEATURES
MB Components
2.2 P3V133 Motherboard Components
See opposite page for locations.
Location
Processor Support Slot 1 for Coppermine/Katmai/Mendecino Processors ...... 2
66MHz to 150MHz bus support
(16 external clock settings)
Chipsets VIA VT82C693A System Controller.............................. 3
VIAVT82C596B PCI to ISA Bridge ............................. 9
2 Mbit Programmable Flash EEPROM ........................ 12
Multi-I/O and Keyboard Controller.............................. 14
Main Memory Maximum 1.5GB support
3 DIMM Sockets ............................................................4
PC133 SDRAM support
Expansion Slots 4 PCI Slots .................................................................... 13
3 ISA Slot...................................................................... 10
1 Accelerated Graphics Port (AGP) Slot ...................... 16
System I/O 2 IDE Connectors (UltraDMA33 Support) ....................6
1 Floppy Disk Driver Connector ....................................5
1 Serial COM1 Connector ............................................ 19
1 Serial COM2 Connector ............................................ 17
1 Parallel Port Connector.............................................. 18
2 USB Connectors ........................................................ 20
1 PS/2 Mouse Connector ....................................(Top) 21
1 PS/2 Keyboard Connector ........................ (Bottom) 21
3D Graphics VIA VT82C693A System Controller.............................. 3
Network Feature Wake-On-LAN Connector ............................................ 15
Wake-On-Ring Connector .............................................. 7
Hardware Monitoring Hardware Monitor ........................................................ 11
3 Fan Power and Speed Monitoring Connectors
Power ATX Power Supply Connector ....................................... 1
Form Factor ATX, 19.2cm x 30.5cm (7.6”x 12”)

ASUS P3V133 User’s Manual 13
2. FEATURES
2. FEATURES
Component Locations
P3V133 Motherboard Components Locations
6431
20
18
16
15
13
17
11
12
19
21
8
10
52
14
7
9

14 ASUS P3V133 User’s Manual
3. HARDWARE SETUP
3.1 P3V133 Motherboard Layout
FLOPPY
SECONDARY
IDE
PRIMARY
IDE
CPU_FAN
Accelerated Graphics Port
PCI Slot 4
ISA Slot 3
VIA
VT82C596B
PCIset
VIA
VT82C693A
Chipset
2Mb Flash EEPROM (Programable BIOS)
PWR_FAN
CHA_FAN
Hardware
Monitor
ATX Power Connector
PANEL
IR
IDE LED
R
WOL_CON
FREQ MULT
BF2
BF3
BF1
BF0
CLRTC
BUS FREQ
FS1
FS2
FS0
ISA Slot 1
ISA Slot 2
PCI Slot 3
PCI Slot 2
PCI Slot 1
KBPWR
ASUS
ASIC
SMB
JTPWR
CHASIS
JTCPU
FS3
VIO
MS0
WOR
P3V133
CPU Slot 1
DIMM Socket 3 (64/72 bit, 168 pin module) DIMM Socket 1 (64/72 bit, 168 pin module) DIMM Socket 2 (64/72 bit, 168 pin module)
0 1 2 3 4 5
Row
USB
PS2
KBMS
TOP:
USB 1
BOTTOM:
USB 2
TOP:
Mouse
BOTTOM:
Keyboard
Parallel Port
COM1
COM2
CR2032 3V
Lithium Cell
(CMOS Power)
VCORE
MS1
Multi-I/O
19.2cm (7.6in)
30.5cm (12.0in)
Motherboard Layout
3. H/W SETUP

ASUS P3V133 User’s Manual 15
3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) KBPWR p. 16 Keyboard Power Up Setting (Disable/Enable)
2) VIO p. 17 I/O Voltage Setting (Normal/Test)
3) VCORE p. 17 Core Voltage Setting (Normal/Test)
4) FS0, FS1, FS2, FS3 p. 18 CPU External Clock (BUS) Frequency Selection
5) MS0, MS1 p. 18 CPU:PCI Bus Frequency Setting
6) BF0, BF1, BF2, BF3 p. 19 CPU Core:BUS Frequency Multiple
Expansion Slots/Sockets
1) System Memory p. 20 System Memory Support
2) DIMM1, DIMM2 p. 21 DIMM Memory Module Support
3) Slot 1 p. 23 CPU Support
4) SLOT1, SLOT2, SLOT3 p. 30 16-bit ISA Bus Expansion Slots
*
5) PCI1,PCI2,PCI3,PCI4 p. 30 32-bit PCI Bus Expansion Slots
6) AGP p.31 Accelerated Graphics Port
Hardware Monitor
1) JTPWR, JTCPU p. 28 Thermal Sensor Connectors
Connectors
1) PS2KBMS p. 32 PS/2 Mouse Port Connector (6 pin-female)
2) PS2KBMS p. 32 PS/2 Keyboard Port Connector (6-pin female)
3) PARALLEL p. 33 Parallel (Printer) Port Connector (25-pin female)
4) COM1, COM2 p. 33 Serial Port COM1 & COM2 (two 9-pin male)
5) USB p. 33 Universal Serial BUS Port Connectors 1 & 2 (Two 4-pin female)
6) Primary/Secondary IDE p. 34 Primary/Secondary IDE Connectors (Two 40-1 pins)
7) FLOPPY p. 34 Floppy Drive Port Connector (34 pins)
8) IDELED p. 35 IDE LED Activity Light (2 pins)
9) WOR p. 35 Wake-On-Ring Connector (2 pins)
10) CHA_, PWR_, CPU_FAN p. 36 Chassis, Power Supply, CPU Fan Power Lead (3 pins)
11) WOL_CON p. 37 Wake-On-LAN Connector (3 pins)
12) IR p. 37 Infrared Port Module Connector (5 pins)
13) SMB p. 38 SMBus Connector (3 pins)
14) ATXPWR p. 39 ATX Motherboard Power Connector (20 pins)
15) CHASIS p. 39 Chassis Intrusion Alarm Lead (4-1 pins)
16) PWR.LED ( PANEL ) p. 40 System Power LED Lead (3-1 pins)
17) KEYLOCK ( PANEL ) p. 40 Keyboard Lock Switch Lead (2 pins)
18) SPEAKER (PANEL) p. 40 System Warning Speaker Connector (4 pins)
19) MSG.LED (PANEL) p. 40 System Message LED (2 pins)
20) SMI (PANEL) p. 40 System Management Interrupt Lead (2 pins)
21) PWR.SW (PANEL) p. 40 ATX Power / Soft-Off Switch Lead (2 pins)
22) RESET (PANEL) p. 40 Reset Switch Lead (2 pins)
*
The optional onboard hardware monitor uses the address 290H-297H so legacy ISA cards
must not use this address otherwise conflicts will occur.
Layout Contents
3. H/W SETUP

16 ASUS P3V133 User’s Manual
3. HARDWARE SETUP
Layout Contents
3. H/W SETUP
3.3 Hardware Setup Steps
Before using your computer, you must complete the following steps:
1. Check Motherboard Settings
2. Install Memory Modules
3. Install the Central Processing Unit (CPU)
4. Install Expansion Cards
5. Connect Ribbon Cables, Panel Wires, and Power Supply
6. Setup the BIOS Software
3.4 Motherboard Settings
This section explains in detail how to change your motherboard’s function settings
through the use of switches and/or jumpers.
Jumpers
1. Keyboard Power Up Setting (KBPWR)
This allows you to disable or enable the keyboard power up function. Set to
Enable if you want to use your keyboard (by pressing <Spacebar>) to power up
your computer. This feature requires an ATX power supply that can supply at
least 300mA on the +5VSB lead. The default is set to Disable because not all
computers have the appropriateATX power supply.Your computer will not func-
tion if you set this to Enable and if you do not have the rightATX power supply.
KBPWR
P3V133 Keyboard Power Up
Disable
(Default)
1
2
3
Enable
1
2
3
R
P3V133
WARNING! Computer motherboards and expansion cards contain very delicate
Integrated Circuit (IC) chips. To protect them against damage from static electric-
ity, you should follow some precautions whenever you work on your computer.
1. Unplug your computer when working on the inside.
2. Use a grounded wrist strap before handling computer components. If you do
not have one, touch both of your hands to a safely grounded object or to a
metal object, such as the power supply case.
3. Hold components by the edges and try not to touch the IC chips, leads or
connectors, or other components.
4. Place components on a grounded antistatic pad or on the bag that came with
the component whenever the components are separated from the system.

ASUS P3V133 User’s Manual 17
3. HARDWARE SETUP
Motherboard Settings
3.H/WSETUP
2. I/O Voltage Setting (VIO)
This jumper allows you to select the voltage supplied to the DRAM, chipset,
AGP, and the CPU’s I/O buffer.
P3V133 Input/Output Voltage Selection
VIO
R
P3V133
Test
1
2
3
1
2
3
Normal
(Default)
IMPORTANT: Setting this jumper to Test may reduce system life. Leave on de-
fault setting of Normal.
3. Voltage Regulator Output Setting (VCORE)
This jumper sets the core voltage supplied to the microprocessor.
P3V133 CPU Core Voltage Selection
VCORE
R
P3V133
Test 1
2
3
1
2
3
Normal
(Default)
WARNING! Using a higher voltage Test may help when overclocking but may
result in the shortening of your computer component’s life. It is strongly recom-
mended that you leave both the VIO and VCORE jumpers on their default settings.

18 ASUS P3V133 User’s Manual
3. HARDWARE SETUP
Motherboard Settings
3. H/W SETUP
5. CPU:PCI Bus Frequency Multiple Selection (MS0, MS1)
This option sets the frequency ratio between the CPU bus frequency and the PCI
bus frequency. The default sets the CPU bus frequency to be twice of the PCI
bus frequency.
P3V133 CPU:PCI Frequency Multiple Selection
123
123
MS0
MS1
MS0
MS1
CPU Bus Frequency
=PCI Bus Frequency X2
(Default)
CPU Bus Frequency
=PCI Bus Frequency X4
123
123
MS0
MS1
MS0
MS1
CPU Bus Frequency
=PCI Bus Frequency X3
(Reserved)
R
P3V133
IMPORTANT: The CPU:PCI Bus Frequency Multiple must be set in conjunc-
tion with the CPU Bus Frequency. Otherwise, your system will not start. For
example, if your CPU’s Bus Frequency is 66MHz, the CPU:PCI Bus Frequency
Multiple should be 2-3 (MS0), 2-3 (MS1), unless otherwise indicated. See table
on opposite page for the combinations.
4. CPU Bus Frequency Selection (FS0, FS1, FS2, FS3)
This option tells the clock generator what frequency to send to the CPU, DRAM, and
motherboard chipset. This allows the selection of the CPU’s External frequency (or
BUS Clock). The BUS Clock multiplied by the BUS Multiple equals the CPU’s Inter-
nal frequency (the advertised CPU speed).
P3V133 CPU External
Frequency Selection
105MHz
35MHz
123
103.00MHz
34.33MHz
123
100.30MHz
33.43MHz
123
83.30MHz
41.65MHz
123
75.0MHz
37.5MHz
123
FS1
FS2
FS0
FS3
66.8MHz
33.4MHz
123
CPU
PCI
CPU
PCI 110.00MHz
36.67MHz112.00MHz 37.33MHz115.00MHz 38.33MHz 120MHz 40MHz 124MHz 31MHz 124.00MHz 41.33MHz
123 123 123 123 123123
FS1
FS2
FS0
FS3
133.0MHz
33.3MHz 133.00MHz 44.33MHz 140MHz 35MHz 150.0MHz 37.5MHz
123 123 123 123
FS1
FS2
FS0
FS3
CPU
PCI
R
P3V133

ASUS P3V133 User’s Manual 19
3. HARDWARE SETUP
Motherboard Settings
3. H/W SETUP
NOTE: Overclocking your processor is not recommended. It may result in a slower
speed. Voltage Regulator Output Selection (VID) is not required for Pentium III/II
processors because they send VID signals directly to the onboard power regulator.
Set the jumpers by the Internal speed of your processor as follows:
(CPU BUS Freq.) (Freq. Multiple) CPU:PCI
Intel CPU Model Freq. Mult. BUS F.FS0 FS1 FS2 FS3 BF0 BF1 BF2 BF3 MS0 MS1
Pentium III 733MHz 5.5x 133MHz [1-2] [1-2] [1-2] [1-2] [1-2] [1-2] [1-2] [2-3] [2-3] [1-2]
Pentium III 667MHz 5.0x 133MHz [1-2] [1-2] [1-2] [1-2] [2-3] [1-2] [1-2] [2-3] [2-3] [1-2]
Pentium III 700MHz 7.0x 100MHz [1-2] [1-2] [1-2] [2-3] [2-3] [1-2] [2-3] [1-2] [1-2] [2-3]
Pentium III 650MHz 6.5x 100MHz [1-2] [1-2] [1-2] [2-3] [1-2] [2-3] [2-3] [1-2] [1-2] [2-3]
Pentium III 600MHz 6.0x 100MHz [1-2] [1-2] [1-2] [2-3] [2-3] [2-3] [2-3] [1-2] [1-2] [2-3]
Pentium III 550MHz 5.5x 100MHz [1-2] [1-2] [1-2] [2-3] [1-2] [1-2] [1-2] [2-3] [1-2] [2-3]
Pentium III 500MHz 5.0x 100MHz [1-2] [1-2] [1-2] [2-3] [2-3] [1-2] [1-2] [2-3] [1-2] [2-3]
Pentium II/III 450MHz 4.5x 100MHz [1-2] [1-2] [1-2] [2-3] [1-2] [2-3] [1-2] [2-3] [1-2] [2-3]
Pentium II 400MHz 4.0x 100MHz [1-2] [1-2] [1-2] [2-3] [2-3] [2-3] [1-2] [2-3] [1-2] [2-3]
Pentium II 350MHz 3.5x 100MHz [1-2] [1-2] [1-2] [2-3] [1-2] [1-2] [2-3] [2-3] [1-2] [2-3]
Celeron 466MHz 7.0x 66MHz [1-2] [1-2] [2-3] [2-3] [2-3] [1-2] [2-3] [1-2] [2-3] [2-3]
Celeron 433MHz 6.5x 66MHz [1-2] [1-2] [2-3] [2-3] [1-2] [2-3] [2-3] [1-2] [2-3] [2-3]
Celeron 400MHz 6.0x 66MHz [1-2] [1-2] [2-3] [2-3] [2-3] [2-3] [2-3] [1-2] [2-3] [2-3]
Pentium II/Celeron 333MHz 5.0x 66MHz [1-2] [1-2] [2-3] [2-3] [2-3] [1-2] [1-2] [2-3] [2-3] [2-3]
Pentium II/Celeron 300MHz 4.5x 66MHz [1-2] [1-2] [2-3] [2-3] [1-2] [2-3] [1-2] [2-3] [2-3] [2-3]
Pentium II/Celeron 266MHz 4.0x 66MHz [1-2] [1-2] [2-3] [2-3] [2-3] [2-3] [1-2] [2-3] [2-3] [2-3]
Pentium II 233MHz 3.5x 66MHz [1-2] [1-2] [2-3] [2-3] [1-2] [1-2] [2-3] [2-3] [2-3] [2-3]
6. CPU Core:BUS Frequency Multiple (BF0, BF1, BF2, BF3)
This option sets the frequency multiple between the Internal frequency of the
CPU and the CPU’s External frequency. These must be set in conjunction with the
CPU Bus Frequency.
P3V133 CPU Core:BUS
Frequency Multiple
BF2
BF1
BF3
BF0
4.0X (4/1)3.5X (7/2)3.0X (3/1)2.5x (5/2)2.0x (2/1)
BF2
BF1
BF3
BF0
213 213 213 213 213
R
P3V133
4.5X (9/2)
213
7.0X (7/1)
213
BF2
BF1
BF3
BF0
5.0X (5/1) 5.5x (11/2) 6.0x (6/1) 6.5X (13/2)
213 213 213 213
7.5X (15/2)
213
8.0X (8/1)
213
For updated processor settings, visit theASUS web site (see ASUS CONTACT INFORMATION)

20 ASUS P3V133 User’s Manual
3. HARDWARE SETUP
System Memory
3.H/WSETUP
3.5 System Memory (DIMM)
This motherboard uses only Dual Inline Memory Modules (DIMMs). Three sockets
are available for 3.3Volt (power level) unbuffered Synchronous Dynamic Random
Access Memory (SDRAM) of either 8, 16, 32, 64, 128, 256, or 512MB to form a
memory size between 8MB to 1.5GB. One side (with memory chips) of the DIMM
takes up one row on the motherboard. This motherboard also supports NEC’s Virtual
Channel (VC) SDRAMs.
To utilize the chipset’s Error Checking and Correction (ECC) feature, you must use a
DIMM module with 9 chips per side (standard 8 chips/side + 1 ECC chip).
Memory speed setup is recommended through SDRAM Configuration in 4.4.1
Chip Configuration.
IMPORTANT (see General DIMM Notes below for more)
•SDRAMs used must be compatible with the current Intel PC133 SDRAM
specification.
•DO NOT attempt to mix SDRAMs with VC SDRAMs.
Install memory in any combination as follows:
DIMM Location 168-pin DIMM Total Memory
Socket 1 (Rows 0&1) SDRAM 8, 16, 32, 64, 128, 256, 512MB x1
Socket 2 (Rows 2&3) SDRAM 8, 16, 32, 64, 128, 256, 512MB x1
Socket 3 (Rows 4&5) SDRAM 8, 16, 32, 64, 128, 256, 512MB x1
Total System Memory (Max 1.5GB) =
NOTES
•DIMMs that have more than 18 chips are not supported on this motherboard.
•ForthesystemCPU busto operate100MHz, useonly PC100-compliantDIMMs.
•ASUS motherboards support SPD (Serial Presence Detect) DIMMs. This is the
memory of choice for best performance vs. stability.
•SDRAM chips are generally thinner with higher pin density than EDO (Extended
Data Output) chips.
•BIOS shows SDRAM memory on bootup screen.
•Single-sided DIMMs come in 16, 32, 64, 128, or 256MB; double-sided come in 32,
64, 128, 256, or 512MB.
