Asus P8B WS User manual

Motherboard
P8B WS

ii
E6384
First Edition
February 2011
Copyright © 2011 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.

iii
Contents
Notices......................................................................................................... vi
Safety information .................................................................................... viii
About this guide ......................................................................................... ix
.............................................................. xi
Chapter 1: Product introduction
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Special features............................................................................ 1-2
1.3.1 Product highlights ........................................................... 1-2
1.3.2 ASUS Workstation Exclusive Features........................... 1-3
1.3.3 ASUS features ................................................................ 1-4
Chapter 2: Hardware information
2.1 Before you proceed ..................................................................... 2-1
2.2 Motherboard overview................................................................. 2-2
2.2.1 Motherboard layout ......................................................... 2-2
2.2.2 Layout contents............................................................... 2-3
2.2.3 Central Processing Unit (CPU) ....................................... 2-4
2.2.4 System memory .............................................................. 2-5
2.2.5 Expansion slots............................................................. 2-10
2.2.6 Onboard switches ......................................................... 2-12
2.2.7 Onboard LEDs .............................................................. 2-15
2.2.8 Jumper .......................................................................... 2-18
2.2.9 Internal connectors ....................................................... 2-20
2.3 Building your computer system ............................................... 2-30
2.3.1 Additional tools and components to build a PC system 2-30
2.3.2 CPU installation ............................................................ 2-31
2.3.3 CPU heatsink and fan assembly installation................. 2-33
2.3.4 DIMM installation .......................................................... 2-35
2.3.5 Motherboard installation................................................ 2-36
2.3.6 ATX Power connection.................................................. 2-38
2.3.7 SATA device connection................................................ 2-39
2.3.8 Front I/O Connector ...................................................... 2-40
2.3.9 Expension Card installation .......................................... 2-41

iv
Contents
2.3.10 Rear panel connection .................................................. 2-42
2.3.11 Audio I/O connections................................................... 2-43
 ...................................................... 2-46
2.5 Turning off the computer........................................................... 2-47
Chapter 3: BIOS setup
3.1 Knowing BIOS .............................................................................. 3-1
3.2 BIOS setup program .................................................................... 3-1
3.2.1 EZ Mode ......................................................................... 3-2
3.2.2 Advanced Mode .............................................................. 3-3
3.3 Main menu .................................................................................... 3-5
3.4 Ai Tweaker menu.......................................................................... 3-8
3.5 Advanced menu ......................................................................... 3-13
3.5.1 Trusted Computing........................................................ 3-13
3.5.2 CPU Conguration ........................................................ 3-14
3.5.3 System Agent Conguration ......................................... 3-16
3.5.4 PCH Conguration ........................................................ 3-17
3.5.5 SATA Conguration ....................................................... 3-17
3.5.6 USB Conguration ........................................................ 3-19
3.5.7 Onboard Devices Conguration.................................... 3-20
3.5.8 APM .............................................................................. 3-22
3.6 Monitor menu ............................................................................. 3-24
3.7 Boot menu .................................................................................. 3-27
3.8 Tool menu ................................................................................... 3-28
3.8.1 ASUS EZ Flash Utility ................................................... 3-28
3.8.2 ASUS O.C. Prole......................................................... 3-29
3.8.3 Asus SPD Information................................................... 3-30
3.9 Exit menu.................................................................................... 3-31
3.10 Updating BIOS............................................................................ 3-32
3.10.1 ASUS Update utility ...................................................... 3-33
3.10.2 ASUS EZ Flash Utility ................................................... 3-36
3.10.3 ASUS CrashFree BIOS 3 utility .................................... 3-37
3.10.4 ASUS BIOS Updater..................................................... 3-38

v
Contents
Chapter 4: Software support
4.1 Installing an operating system ................................................... 4-1
4.2 Support DVD information ............................................................ 4-1
4.2.1 Running the support DVD ............................................... 4-1
4.2.2 Obtaining the software manuals ..................................... 4-2
4.3 Software information ................................................................... 4-3
4.3.1 AI Suite II ........................................................................ 4-3
4.3.2 EPU................................................................................. 4-4
4.3.3 FAN Xpert ....................................................................... 4-5
4.3.4 Probe II ........................................................................... 4-6
4.3.5 Sensor Recorder............................................................. 4-7
4.3.6 Ai Charger+..................................................................... 4-8
4.3.7 Audio congurations ....................................................... 4-9
  .................................................................. 4-11
4.4.1 RAID denitions .............................................................4-11
4.4.2 Installing Serial ATA hard disks ..................................... 4-12
4.4.3 Setting the RAID item in BIOS ...................................... 4-12
4.4.4 Intel®Rapid Storage Technology Option ROM utility .... 4-12
4.5 Creating a RAID driver disk....................................................... 4-16
4.5.1 Creating a RAID driver disk without entering the OS.... 4-16
4.5.2 Creating a RAID driver disk in Windows®...................... 4-16
4.5.3 Installing the RAID driver
during Windows®OS installation................................... 4-17
4.5.4 Using a USB oppy disk drive....................................... 4-18
Chapter 5: Multiple GPU technology support
5.1 ATI®CrossFireX™ technology .................................................... 5-1
5.1.1 Requirements.................................................................. 5-1
5.1.2 Before you begin............................................................. 5-1
5.1.3 Installing CrossFireX graphics cards .............................. 5-2
5.1.4 Installing the device drivers............................................. 5-3
5.1.5 Enabling the ATI®CrossFireX™ technology ................... 5-3
5.2 NVIDIA®CUDA™ technology ...................................................... 5-5
5.2.1 Requirements.................................................................. 5-5
5.2.2 Installing CUDA-ready graphics cards ............................ 5-5

vi
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with manufacturer’s
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
The use of shielded cables for connection of the monitor to the graphics card is
required to assure compliance with FCC regulations. Changes or modications
to this unit not expressly approved by the party responsible for compliance
could void the user’s authority to operate this equipment.

vii
REACH
Complying with the REACH (Registration, Evaluation, Authorization, and
Restriction of Chemicals) regulatory framework, we published the chemical
substances in our products at ASUS website at http://csr.asus.com/english/
REACH.htm.
ASUS Recycling/Takeback Services
ASUS recycling and takeback programs come from our commitment to the highest
standards for protecting our environment. We believe in providing solutions for you
to be able to responsibly recycle our products, batteries, other components as well
as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm
for detailed recycling information in different regions.
DO NOT throw the motherboard in municipal waste. This product has been
designed to enable proper reuse of parts and recycling. This symbol of the
crossed out wheeled bin indicates that the product (electrical and electronic
equipment) should not be placed in municipal waste. Check local regulations for
disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste.
This symbol of the crossed out wheeled bin indicates that the battery should not
be placed in municipal waste.

viii
Safety information
Electrical safety
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing devices to or from the system, ensure that the power
cables for the devices are unplugged before the signal cables are connected. If
possible, disconnect all power cables from the existing system before you add
a device.
• Before connecting or removing signal cables from the motherboard, ensure
that all power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord.
These devices could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you
are not sure about the voltage of the electrical outlet you are using, contact
your local power company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied
service technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all
the manuals that came with the package.
• Before using the product, ensure all cables are correctly connected and the
power cables are not damaged. If you detect any damage, contact your dealer
immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in
any area where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied
service technician or your retailer.

ix

Refer to the following sources for additional information and for product and
software updates.
1. ASUS websites
The ASUS website provides updated information on ASUS hardware and
software products. Refer to the ASUS contact information.
2. Optional documentation
Your product package may include optional documentation, such as warranty
yers, that may have been added by your dealer. These documents are not
part of the standard package.
About this guide
This user guide contains the information you need when installing and conguring
the motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product introduction
This chapter describes the features of the motherboard and the new
technology it supports.
• Chapter 2: Hardware information
This chapter lists the hardware setup procedures that you have to perform
when installing system components. It includes description of the switches,
jumpers, and connectors on the motherboard.
• Chapter 3: BIOS setup
This chapter tells how to change system settings through the BIOS Setup
menus. Detailed descriptions of the BIOS parameters are also provided.
• Chapter 4: Software support
This chapter describes the contents of the support DVD that comes with the
motherboard package and the software.
• Chapter 5: Multiple GPU technology support
This chapter describes how to install and congure multiple ATI®
CrossFireX™ and NVIDIA®SLI™ graphics cards.

x
DANGER/WARNING: Information to prevent injury to yourself
when trying to complete a task.
CAUTION: Information to prevent damage to the components
when trying to complete a task.
NOTE: Tips and additional information to help you complete a
task.
IMPORTANT: Instructions that you MUST follow to complete a
task.
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following
symbols used throughout this manual.
Typography
Bold text Indicates a menu or an item to select.
Italics Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign
means that you must press the enclosed key.
Example: <Enter> means that you must press the
Enter or Return key.
<Key1+Key2+Key3> If you must press two or more keys simultaneously, the
key names are linked with a plus sign (+).
Example: <Ctrl+Alt+Del>
Command Means that you must type the command exactly as
shown, then supply the required item or value enclosed
in brackets.
Example: At the DOS prompt, type the command line:
BUPDATER /iP8BWS.ROM

xi
P8B WS specications summary
CPU LGA1155 socket for Intel®2nd Generation Core™ i3
desktop processor
LGA 1155 socket for Intel®XEON E3-1200 series server/
workstation processor
Supports 32nm CPU
* Supports Intel®Turbo Boost Technology 2.0
** Refer to www.asus.com for Intel CPU support list
Chipset Intel®C206 Chipset
Memory 4 x DIMM, max. 32GB, DDR3 1333/1066 MHz,
ECC/non-ECC, un-buffered memory
Dual channel architecture
Support Intel Extreme Memory Prole (XMP)
**Refer to www.asus.com or this user manual for the
Memory QVL(Qualied Vendors Lidts).
Expansion Slots 1 x PCIe 2.0 x16 (@ x16 or x8)
1 x PCIe 2.0 x16 (@ x8)
2 x PCIe 2.0 x16 (@ x4)
1 x PCIe 2.0 x1 (@ x1)
1 x PCI
VGA Output Multi-VGA output support: DVI-I and RGB ports
Supports DVI with max. resolution 1920 x 1200@60Hz
Supports RGB with max. resolution 2048 x 1536@75Hz
Maximum shared memory of 1748 MB
Multi-GPU support Supports ATI®Quad-GPU CrossFireX™ Technology
Storage Intel®C206 Chipset
- 2 x SATA 6.0 Gb/s ports (gray)2 x SATA 6.0 Gb/s ports (gray)
- 4 x SATA 3.0 Gb/s ports (blue)4 x SATA 3.0 Gb/s ports (blue)
- IntelIntel®Rapid Storage Technology supports RAID 0,
1, 5 and 101, 5 and 10
LAN 2 x Intel®82574L GbE LAN
- Support teaming function
1394 VIA VT6308S controller supports 2 x1394a port
USB USB 3.0 controller
- 2 x USB 3.0 ports (Blue, at back panel)
Intel®C206 Chipset
- 14 x USB 2.0 ports (8 ports at mid-board, 6 ports at
back panel)
(continued on the next page)

xii
Audio Realtek® ALC892 8-Channel High Denition Audio
CODEC
- BD Audio Layer Content Protection
- Supports Jack-Detection, Multi-streaming and Front
Panel Jack-Retasking
- Optical S/PDIF out port at back I/O
ASUS Unique Features GPU Boost with switch
ASUS Power Design
- 8+2 Phase Power Design
ASUS EPU
- EPU, EPU switch
ASUS Exclusive Features
- MemOK!
- AI Suite II
- Anti Surge
- ASUS EFI BIOS EZ Mode featuring friendly
graphics user interface
ASUS Quiet Thermal Solution
- ASUS Fanless Design: Heat-sink solution
- ASUS Fan Xpert
ASUS EZ DIY
- ASUS Q-Connector
- ASUS CrashFree BIOS 3
- ASUS EZ Flash Utility
ASUS Q-Design ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
ASUS Q-Slot
ASUS Q-DIMM
Workstation Unique
Features
4 PCIe x 16 slots
G.P. Diagnosis Card bundled
Quick Gate: 2 vertical USB 2.0 on board
ASUS SASsaby series Cards support
ASUS WS Diag. LED
BIOS Features 32 Mb Flash ROM, EFI AMI BIOS, PnP, DMI2.0, WfM2.0,
SM BIOS 2.6, ACPI 2.0a, Multi-language BIOS, ASUS EZ
Flash Utility, ASUS CrashFree BIOS 3
Back Panel I/O Ports PS/2 KB/MS port
S/PDIF Out (Optical and Coxial)
6 x USB 2.0/1.1 ports
2 x USB 3.0/2.0 ports
1 x IEEE1394a
2 x Lan Connector
1 x DVI-I
1 x 8-channel Audio I/O
(continued on the next page)
P8B WS specications summary

xiii
Internal I/O Connectors 24-pin ATX Power connector
8-pin ATX +12V Power connector
CPU fan with PWM control
Chassis fan1 with Q-fan control
Chassis fan2 with Q-fan control
Chassis fan3 with Q-fan control
PWR fan
AAFP connector
1 x COM port connector
2 x USB connectors support additional 4 USB ports
2 x USB 2.0/1.1 vertical ports
TPM header
S/PDIF Out header
1 x MemOK! Button
20-pin front panel connector
Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
OS Win7 32/64 bit,Vista 32/64 bit and WinXP 32/64bit,
Server 2003 32/64bit, Server 2008 32/64bit and Server
2008 R2 64bit
Form Factor ATX Form Factor, 12"x 9.6" (30.5cm x 24.5cm)

P8B WS specications summary

xiv

1
Chapter 1: Product
introduction
This chapter describes the motherboard
features and the new technologies
it supports.

ASUS P8B WS
Chapter summary 1
1.1 Welcome! ...................................................................................... 1-1
1.2 Package contents......................................................................... 1-1
1.3 Special features............................................................................ 1-2

ASUS P8B WS 1-1
1.1 Welcome!
Thank you for buying an ASUS P8B WS motherboard!
The motherboard delivers a host of new features and latest technologies, making it
another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard, and hardware devices on it, check the
items in your package with the list below.
If any of the above items is damaged or missing, contact your retailer.
1.2 Package contents
Check your motherboard package for the following items.
Motherboard ASUS P8B WS
I/O modules 1 x USB 2.0 (2 ports) + eSATA (1 port) module
Cables 2 x Serial ATA 6.0 Gb/s signal cables
2 x Serial ATA 3.0 Gb/s power cables
4 x Serial ATA 3.0 Gb/s cables
1 x COM port cable
Accessories 1 x ASUS Q-Shield (I/O shield)
1 x ASUS 2-in-1 Q-Connector Kit (Retail version only)
1 x G.P. Diagnosis Card (Retail version only)
Application DVD ASUS motherboard support DVD
Documentation User guide

1-2 Chapter 1: Product Introduction
1.3 Special features
1.3.1 Product highlights
Green ASUS
This motherboard and its packaging comply with the European Union’s Restriction
on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision
of creating environment-friendly and recyclable products/packagings to safeguard
consumers’ health while minimizing the impact on the environment.
LGA1155 Intel®Sandy Bridge Processor Ready
This motherboard supports the latest Intel®Sandy Bridge processors in the
LGA1155 package, with memory and PCI Express controllers integrated to support
2-channel (4 DIMM) DDR3 memory and 20 PCI Express 2.0 lanes. This provides
great graphics performance. Intel®Sandy Bridge processors are among the most
powerful and energy efcient CPUs in the world.
C206
The Intel®C206 Express is the latest single-chipset design that supports the
new socket 1155 Intel®Core™ i3 2nd generation processors, and Intel®XEON®
E3 server processors. It improves performance by utilizing serial point-to-point
links, allowing for increased bandwidth and stability. Additionally, the C206 comes
with 2 SATA 6Gb/s and 4 SATA 3Gb/s ports for faster data retrieval, doubling the
bandwidth of current bus systems. C206 supports ECC function and Sandy Bridge
processor that supports 20 PCI Express 2.0 lanes. Moreover, Intel®C206 Express
Chipset also supports iGPU function.
PCIe 2.0
Double Speed; Double Bandwidth
This motherboard supports the latest PCIe 2.0 devices for double speed and
bandwidth that enhances system performance.
Dual-Channel DDR3 1333/ 1066 support
The motherboard supports DDR3 memory that features data transfer rates
of 1333/1066 MHz to meet the higher bandwidth requirements of the latest
3D graphics, multimedia, and Internet applications. The dual-channel DDR3
architecture enlarges the bandwidth of your system memory to boost system
performance.
SATA 6Gb/s Supports
The Intel®C206 Chipset natively supports next-generation Serial ATA (SATA)
storage interface, this motherboard delivers up to 6.0 Gb/s data transfer rates.
Additionally, get enhanced scalability, faster data retrieval, double the bandwidth of
current bus systems.

ASUS P8B WS 1-3
USB 3.0 Support
Experience ultra-fast data transfers at 4.8Gbps with USB 3.0--the latest
connectivity standard. Built to connect easily with next-generation components and
peripherals, USB 3.0 transfers data 10X faster and is also backward compatible
with USB 2.0 components.
GPU Boost
Go to the Limit with iGPU Level Up!
GPU Boost accelerates the integrated GPU for extreme graphics performance. The
user-friendly interface facilitates exible frequency adjustments. It easily delivers
stable system-level upgrades for every use.
EPU

Tap into the world's rst real time PC power saving engine through a simple
onboard switch or AI Suite II utility. Get total system power savings by
automatically detecting current PC loadings and intelligently moderating power
consumption. This also reduces fan noise and extends component longevity!
1.3.2 ASUS Workstation Exclusive Features
Diverse CPU and Memory supported
The motherboard provides dual use for CPU and memory, which support Intel®E3
series server processors and Core i3 2nd generation desktop processors. Users
can choose DDR3 un-buffered non-ECC memory which is widely available in the
PC market, or more stable and reliable DDR3 un-buffered ECC memory. P8B WS
provide you exible options on CPU and memory to meet diverse needs.
Built-in Dual Intel Server-Class Gigabit LAN
For more reliable networking, the P8B WS features built-in dual Intel server-class
Gigabit LAN. It uses lower CPU utilization, increasing throughput to achieve
outstanding performance as well as better support for diverse operating systems.
Besides, Intel® 82574L chipset has certication of VMware to support virtualization
technology.
Quad-GPU CrossFireX Support!
P8B WS can support ATI CrossFireX technology, up to Quad-GPUs. The
motherboard features the most powerful Intel C206 platform to optimizes PCIe
allocation. Expect a brand-new gaming style you’ve never experienced before!

1-4 Chapter 1: Product Introduction
CUDA parallel computing power supported
The motherboard will achieve outstanding and dependable performance in the
role of a Personal Supercomputer when working in tangent with discrete CUDA
technology—providing unprecedented return on investment. Users can count on
up to 4 Tesla GPUs that are plugged into P8B WS for intensive parallel computing
on tons of data, which delivers nearly 4 teraops of performance. It is the best
choice to work as a personal supercomputer on your desk instead of a computer
cluster in a room.
Quick Gate
Quick Gate is a vertical USB connector on the motherboard, allowing you to install
USB devices directly with no messy cables. This stops important data storage
devices from breaking off unexpectedly. This unique design provides a convenient
and safe way to install data and applications on your PC.
Diag. LED
Diag. LED checks key components (CPU, DRAM, VGA card, and HDD) in
sequence during motherboard booting process. If an error is found, the LED next
to the error device will continue lighting until the problem is solved. This usr-friendly
design provides an intuitional way to locate the root problem within a second.
G.P. Diagnosis Card (Bundled)
Bundled with the P8B WS, the G.P. Diagnosis card double checks the system by
effortlessly and quickly providing precise info every time you switch on your PC.
1.3.3 ASUS features
8+2 Phase Power Design
To fully unleash the latest Intel®Sandy Bridge CPU´s potential, this motherboard
has adopted a brand new 8-phase VRM power design. It delivers high power
efciency and supreme overclocking ability. Furthermore, high quality power
components can effectively lower system temperature to ensure longer component
lifespan. This motherboard also features an extra 2-phase power dedicated to
integrated memory controller.
MemOK!
Any Memory is A-OK!
MemOK! quickly ensures memory boot compatibility. This remarkable memory
rescue tool requires a mere push of a button to patch memory issues. MemOK!
determines failsafe settings and dramatically improves your system boot success.
Get your system up and running in no time!
