Motherboard
TUF GAMING
X570-PLUS/BR
ii
E15928
First Edition V1
September 2019
Copyright © 2019 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
Offer to Provide Source Code of Certain Software
This product contains copyrighted software that is licensed under the General Public License (“GPL”),
under the Lesser General Public License Version (“LGPL”) and/or other Free Open Source Software
Licenses. Such software in this product is distributed without any warranty to the extent permitted by the
applicable law. Copies of these licenses are included in this product.
Where the applicable license entitles you to the source code of such software and/or other additional data,
you may obtain it for a period of three years after our last shipment of the product, either
(1) for free by downloading it from https://www.asus.com/support/
or
(2) for the cost of reproduction and shipment, which is dependent on the preferred carrier and the location
where you want to have it shipped to, by sending a request to:
ASUSTeK Computer Inc.
Legal Compliance Dept.
15 Li Te Rd.,
Beitou, Taipei 112
Taiwan
In your request please provide the name, model number and version, as stated in the About Box of the
product for which you wish to obtain the corresponding source code and your contact details so that we
can coordinate the terms and cost of shipment with you.
The source code will be distributed WITHOUT ANY WARRANTY and licensed under the same license as
the corresponding binary/object code.
This offer is valid to anyone in receipt of this information.
ASUSTeK is eager to duly provide complete source code as required under various Free Open Source
Software licenses. If however you encounter any problems in obtaining the full corresponding source
code we would be much obliged if you give us a notication to the email address [email protected], stating
the product and describing the problem (please DO NOT send large attachments such as source code
archives, etc. to this email address).
iii
Contents
Safety information....................................................................................................... v
About this guide......................................................................................................... vi
TUF GAMING X570-PLUS/BR specications summary ........................................ viii
Package contents...................................................................................................... xii
Installation tools and components......................................................................... xiii
Chapter 1: Product Introduction
1.1 Motherboard overview............................................................................... 1-1
1.1.1 Before you proceed..................................................................... 1-1
1.1.2 Motherboard layout ..................................................................... 1-2
1.1.3 Central Processing Unit (CPU) ................................................... 1-4
1.1.4 System memory .......................................................................... 1-4
1.1.5 Expansion slots........................................................................... 1-6
1.1.6 Onboard LEDs ........................................................................... 1-8
1.1.7 Jumpers ...................................................................................... 1-9
1.1.8 Internal connectors.................................................................... 1-10
Chapter 2: Basic Installation
2.1 Building your PC system...........................................................................2-1
2.1.1 Motherboard installation.............................................................. 2-1
2.1.2 CPU installation........................................................................... 2-3
2.1.3 CPU heatsink and fan assembly installation............................... 2-4
2.1.4 DIMM installation......................................................................... 2-6
2.1.5 ATX power connection................................................................ 2-7
2.1.6 SATA device connection............................................................. 2-7
2.1.7 Front I/O connector ..................................................................... 2-8
2.1.8 Expansion card installation ......................................................... 2-9
2.1.9 M.2 installation .......................................................................... 2-10
2.2 Motherboard rear and audio connections ............................................. 2-11
2.2.1 Rear I/O connection .................................................................. 2-11
2.2.2 Audio I/O connections............................................................... 2-12
2.3 Starting up for the rst time.................................................................... 2-15
2.4 Turning off the computer ........................................................................ 2-15
Chapter 3: BIOS Setup
3.1 Knowing BIOS ............................................................................................ 3-1
3.2 BIOS setup program .................................................................................. 3-2
3.2.1 EZ Mode...................................................................................... 3-3
3.2.2 Advanced Mode .......................................................................... 3-4
3.2.3 Q-Fan Control ............................................................................. 3-7
iv
3.3 My Favorites ............................................................................................... 3-9
3.4 Main menu ................................................................................................ 3-11
3.5 Ai Tweaker menu......................................................................................3-11
3.6 Advanced menu ....................................................................................... 3-12
3.6.1 AMD fTPM Conguration .......................................................... 3-12
3.6.2 CPU Conguration .................................................................... 3-12
3.6.3 NB Conguration....................................................................... 3-12
3.6.4 SATA Conguration .................................................................. 3-13
3.6.5 Onboard Devices Conguration................................................ 3-14
3.6.6 APM Conguration.................................................................... 3-14
3.6.7 PCI Subsytem Settings ............................................................. 3-15
3.6.8 USB Conguration .................................................................... 3-15
3.6.9 HDD/SSD SMART Information ................................................. 3-15
3.6.10 NVMe Conguration.................................................................. 3-15
3.6.11 Network Stack Conguration..................................................... 3-15
3.7 Monitor menu ........................................................................................... 3-16
3.8 Boot menu ................................................................................................ 3-16
3.9 Tool menu................................................................................................. 3-17
3.9.1 ASUS EZ Flash 3 Utility ............................................................ 3-17
3.9.2 ASUS User Prole..................................................................... 3-18
3.9.3 ASUS SPD Information............................................................. 3-18
3.9.4 ASUS Armoury Crate................................................................ 3-18
3.10 Exit menu.................................................................................................. 3-18
3.11 Updating BIOS.......................................................................................... 3-19
3.11.1 EZ Update................................................................................. 3-19
3.11.2 ASUS EZ Flash 3...................................................................... 3-20
3.11.3 ASUS CrashFree BIOS 3.......................................................... 3-22
Chapter 4: RAID Support
4.1 AMD RAID Array congurations............................................................... 4-1
4.1.1 RAID denitions .......................................................................... 4-1
Appendix
Notices .................................................................................................................... A-1
ASUS contact information...................................................................................... A-5
v
Safety information
Electrical safety
• To prevent electrical shock hazards, disconnect the power cable from the electrical outlet
before relocating the system.
• When adding or removing devices to or from the system, ensure that the power cables
for the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you add a device.
• Before connecting or removing signal cables from the motherboard, ensure that all
power cables are unplugged.
• Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.
• Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied service
technician or your retailer.
Operation safety
• Before installing the motherboard and adding devices on it, carefully read all the manuals
that came with the package.
• Before using the product, ensure all cables are correctly connected and the power
cables are not damaged. If you detect any damage, contact your dealer immediately.
• To avoid short circuits, keep paper clips, screws, and staples away from connectors,
slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Do not place the product in any area
where it may become wet.
• Place the product on a stable surface.
• If you encounter technical problems with the product, contact a qualied service
technician or your retailer.
vi
About this guide
This user guide contains the information you need when installing and conguring the
motherboard.
How this guide is organized
This guide contains the following parts:
• Chapter 1: Product Introduction
This chapter describes the features of the motherboard and the new technology it
supports. It includes description of the switches, jumpers, and connectors on the
motherboard.
• Chapter 2: Basic Installation
This chapter lists the hardware setup procedures that you have to perform when
installing system components.
• Chapter 3: BIOS Setup
This chapter tells how to change system settings through the BIOS Setup menus.
Detailed descriptions of the BIOS parameters are also provided.
• Chapter 4: RAID Support
This chapter describes the RAID congurations.
Where to nd more information
Refer to the following sources for additional information and for product and software
updates.
1. ASUS website
The ASUS website (www.asus.com) provides updated information on ASUS hardware
and software products.
2. Optional documentation
Your product package may include optional documentation, such as warranty yers,
that may have been added by your dealer. These documents are not part of the
standard package.
vii
Conventions used in this guide
To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.
DANGER/WARNING: Information to prevent injury to yourself when trying to
complete a task.
CAUTION: Information to prevent damage to the components when trying to
complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
NOTE: Tips and additional information to help you complete a task.
Typography
Bold text Indicates a menu or an item to select.
Italics
Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than sign
means that you must press the enclosed key.
Example: <Enter> means that you must press the Enter or
Return key.
<Key1> + <Key2> + <Key3> If you must press two or more keys simultaneously, the key
names are linked with a plus sign (+).
viii
TUF GAMING X570-PLUS/BR specications summary
(continued on the next page)
CPU
AM4 socket for AMD Ryzen™ 3rd and 2nd Generation/ 2nd and 1st Gen
AMD Ryzen™ with Radeon™ Vega Graphics Processors
Supports up to 16 cores*
* Due to the CPU limitations, CPU cores supported vary by processor.
** Refer to www.asus.com for the AMD CPU support list.
Chipset AMD X570 Chipset
Memory
AMD Ryzen™ 3rd Generation Processors
- 4 x DIMM, max. 128GB, DDR4 4400(O.C.)/3466(O.C.)/3400(O.C.)/3
200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz,
un-buffered memory
AMD Ryzen™ 2nd Generation Processors
- 4 x DIMM, max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3
200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz,
un-buffered memory
AMD Ryzen™ 2nd and 1st Generation with Radeon™ Vega
Graphics Processors
- 4 x DIMM, max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933(O.C.)/2
800(O.C.)/2666/2400/2133 MHz, un-buffered memory
Dual channel memory architecture
ECC Memory (ECC mode) support varies by CPU.
* The maximum memory frequency supported varies by processor. Refer to
www.asus.com for the Memory QVL (Qualied Vendors List).
Expansion slots
AMD Ryzen™ 3rd Generation Processors
1 x PCIe 4.0/3.0 x16 slot (at x16 mode)
AMD Ryzen™ 2nd Generation Processors
1 x PCIe 3.0 x16 slot (at x16 mode)
AMD Ryzen™ 2nd and 1st Generation with Radeon™ Vega
Graphics Processors
1 x PCIe 3.0/2.0 x16 slot (at x8 mode)
AMD X570 chipset
- 1 x PCIe 4.0 x16 slot (max. at x4 mode)
- 3 x PCIe 4.0 x1 slots
Graphics
Integrated Graphics in the AMD Ryzen™ 2nd and 1st Generation
with Radeon™ Vega Graphics
Multi-VGA output support: HDMI and DisplayPort ports
- Supports HDMI 1.4b with max. resolution of 4096 x 2160 @24Hz
- Supports DisplayPort with max. resolution of 4096 x 2304 @60Hz
Multi-GPU support
AMD Ryzen™ 3rd and 2nd Generation / AMD Ryzen™ 2nd and 1st
Generation with Radeon™ Vega Graphics Processors
Supports AMD 2-Way CrossFireX™ Technology
LAN
Realtek®L8200A
- ASUS Turbo LAN Utility
- TUF LANGuard
ix
(continued on the next page)
Storage
AMD Ryzen™ 3rd Generation Processors
- 1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110
storage devices support (SATA & PCIE 4.0 x 4 mode)
AMD Ryzen™ 2nd Generation / Ryzen™ 2nd and 1st Generation
with Radeon™ Vega Graphics Processors
- 1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110
storage devices support (SATA & PCIE 3.0 x 4 mode)
AMD X570 Chipset:
- 1 x M.2_2 socket 3 with M key, type 2242/2260/2280/22110
storage devices support (SATA & PCIE 4.0 x 4 mode)
- 8 x SATA 6Gb/s ports
- Supports Raid 0, 1, 10
Audio
Realtek® S1200A 8-channel High Denition Audio CODEC
- Exclusive DTS Custom for GAMING Headsets
- Audio Shielding: Ensures precision analog/digital separation and
greatly reduces multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right
channels to guard the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and
immersive sound with exceptional clarity and delity
- Supports jack-detection and front panel jack-retasking
- Audio Cover: Effective shielding preserves the integrity of audio
signals to ensure best quality
USB
- 3 x USB 3.2 Gen 2 (up to 10Gbps) ports at back panel (2 x Type-A
ports; 1 x Type-C port)
- 6 x USB 3.1 Gen 1 ports at mid-board (2 ports at mid-board, 4
ports at back panel)
- 4 x USB 2.0 ports at mid-board
ASUS Unique Features
ASUS TUF PROTECTION
- ASUS SafeSlot - Protect your graphics card Investment
- ASUS ESD Guard: Enhanced ESD protection
- ASUS LANGuard: Protects against LAN surges, lightning
strikes and static-electricity discharges!
- ASUS Overvoltage Protection: World-class circuit-protecting
power design
- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for
greater durability!
- ASUS DIGI+ VRM
TUF ENGINE! Power Design
- TUF Components (Choke, Cap.; certied by military-standard)
AURA
- Aura Lighting Control
- Aura RGB Strip Headers
ASUS EPU
- EPU
TUF GAMING X570-PLUS/BR specications summary
x
(continued on the next page)
TUF GAMING X570-PLUS/BR specications summary
ASUS Unique Features
ASUS Exclusive Features
- ASUS Ai Charger
- ASUS AI Suite 3
ASUS EZ DIY
- ASUS UEFI BIOS EZ Mode
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
ASUS Q-Design
- ASUS Q-DIMM
- ASUS Q-Slot
- ASUS Q-LED
ASUS Quiet Thermal
Solution
- ASUS FAN Xpert 4
- Stylish Design: MOS Heat-sink with dual thermal pads design,
PCH Fan, PCH and M.2 Heatsink
Back I/O Ports
1 x PS/2 keyboard/ mouse combo port
1 x HDMI port
1 x DisplayPort port
1 x LAN (RJ-45) port
3 x USB 3.2 Gen 2 ports (2 x Type-A ports; 1 x Type C port)
4 x USB 3.2 Gen 1 ports
5 x Audio jacks + 1 x Optical S/PDIF out
Internal I/O Ports
1 x USB 3.2 Gen 1 connector supports additional 2 USB ports
2 x USB 2.0/1.1 connectors support additional 4 USB ports
8 x SATA 6 Gb/s connectors
1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110 storage
devices support (SATA & PCIE 4.0/3.0 x 4 mode)
1 x M.2_2 socket 3 with M key, type 2242/2260/2280/ 22110 storage
devices support (SATA & PCIE 4.0 x 4 mode)
1 x Addressable RGB Header
2 x AURA RGB headers
1 x CPU Fan connector (4-pin) for both DC mode and PWM mode
1 x CPU OPT Fan connector (4-pin)
1 x AIO_PUMP connector (4-pin)
3 x Chassis Fan connectors (4-pin) for both 3-pin (DC mode) and
4-pin (PWM mode) coolers control
1 x Front panel audio connector (AAFP)
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x 4-pin EATX 12V power connector
1 x System panel connector
1 x COM connector
1 x SPI_TPM header (14-1pin)
1 x Clear CMOS jumper (2-pin)
