Atag CM4574M User manual

Instructions for use
Coffee machine
CM4574M

EN 2
EN Instructions for use EN 3 - EN 38
Pictograms used
Important information
Tip

EN 3
CONTENTS
Your coffee machine
Introduction 4
Description of the appliance 5
Touch keys and symbols 8
Operation
Before first use 10
Set your appliance to ‘On’ 12
Set your appliance to ‘Standby’ and ‘Off’ 12
Important tips and tricks when you make coffee 13
Make coffee using coffee beans 13
Make coffee using pre-ground coffee 14
Adjust the grind level 14
Make milk-based hot drinks 15
Customise beverages 16
Supply a beverage that is customised 16
Customise a user profile 16
Supply hot water or steam 17
Settings
Settings menu 18
Maintenance
Clean your appliance 20
Clean the hot water spout 21
Clean the internal tubes of the milk container and the nozzle 21
Clean all components of the milk container 22
Clean the appliance’s internal circuit 23
Clean the coffee grounds container 23
Clean the drip tray 24
Clean the inside of the coffee machine 24
Clean the water tank 25
Clean the coffee spouts 25
Clean the pre-ground coffee funnel 25
Descale the appliance 26
Set the water hardness 28
Install a water softener filter 28 Replace a water softener filter
29
Remove a water softener filter 29
Clean the brewing unit / infuser once a month 30
Clean the brewing unit / infuser twice a year 31

EN 4
Use the milk cleaner 34
Trouble shooting
Trouble shooting 36
Environmental aspects
Disposal of packaging and appliance 38

YOUR COFFEE MACHINE
EN 5
Introduction
Congratulations on your choice of this Atag coffee machine. This product was designed with
simple operation and optimum comfort in mind.
This manual describes the best way to use this coffee machine. In addition to information on
operation, you will also find background information that may come in handy when using the
appliance.
Please read the separate safety instructions carefully before
using the appliance!
Read this manual before using the appliance and keep it in a safe place for future use.
Installation instructions are supplied separately.

YOUR COFFEE MACHINE
EN 6
Description of the appliance

YOUR COFFEE MACHINE
EN 7

YOUR COFFEE MACHINE
EN 8
1. Lid bean container

YOUR COFFEE MACHINE
EN 9
2. Bean container
3. Ground coffee funnel (with lid) 23
4. Knob to adjust the grind level
5. Power cord
6. IEC connector
7. Area for the measuring spoon
8. Cup warming area
9. Service door
10. Brewing unit
11. On/Standby button
12. Control panel
13. Lighting
14. Main switch
15. Area for accessories (left and right)
16. Cup tray
17. Coffee grounds container
18. Drip tray with level indicator
19. Coffee spouts (adjustable height)
20. Cup lights
21. Hot water connection nozzle
22. Water tank
23. Hot water spout
24. Cover connection nozzle
25. Lid with milk frother
26. Frothed milk spout (adjustable)
27. Milk froth adjustment knob
28. Milk intake tube
29. Release button
30. Milk container
31. Thermal casing
32. Measuring spoon for pre-ground coffee 32
Maintenance set
• ‘Total Hardness Test’ indicator paper
• Descaler
• Water softener filter (certain models only)
• Cleaning brush / cleaning cloth
• Milk cleaner
• O-rings and lubricating grease
25
26
27
29
28
30
31

YOUR COFFEE MACHINE
EN 10
Touch keys and symbols
Touch keys
My profile
Customise several beverage.
• See chapter ‘Customise beverages’.
Settings
• See chapter ‘Settings menu’.
User profile
• See chapter ‘Supply a beverage that is customised’.
Customise a user profile
• See chapter ‘Customise a user profile’.
Aroma
Touch this key (several times) to select ‘Pre-ground’ or to select the
aroma.
Quantity
Touch this key (several times) to select the coffee quantity.
Scroll left/right
Touch these keys until the correct variable is shown on the display.
OK
Stop
Escape
Cancel or go back one step.
• Values will not be saved.
Next
Plus (+)
Adapt the aroma when you customise a beverage.
Minus (-)
Adapt the aroma when you customise a beverage.

YOUR COFFEE MACHINE
EN 11
Start
Enter
Enter a menu.
2x
Supply twice the amount of espresso.
• This touch key is shown on the display for a few seconds at the start
of preparing espresso.
Touch keys
Extra
Increase the quantity after you received your beverage.
On/Off
Setting is ‘off’.
On/Off
Setting is ‘on’.
Symbols
My aroma (if programmed) / Standard
Pre-ground
Extra light
Light
Medium
Strong
Extra strong
My quantity (if programmed) / Standard
Small
Medium
Large
Extra large

YOUR COFFEE MACHINE
EN 12
Settings saved
Default value
Auto start function enabled
Energy saving enabled
Filter enabled

OPERATION
EN 13
Before first use
Remove the packaging. Make sure the product is complete and undamaged. Check if all
accessories are present. Do not use the appliance if it is visibly damaged. Contact the service
department if there are any problems.
Coffee has been used to test the appliance in the factory. Therefore it is completely
normal that there are traces of coffee in the mill.
Customise the water hardness as soon as possible. Obey the instructions in chapter ‘Set
the water hardness’.
To improve the performance of your appliance, we recommend installing a water softener
filter. If your model is not provided with a filter, you can purchase one from the service
department.
Always use clean and cold tap water, bottled water without added minerals or distilled
water suitable for consumption.
The first time you use the appliance, the water circuit is empty. The appliance could be
very noisy. The noise becomes less when the circuit fills with water.
The first time you use the appliance, you need to make 4-5 cups of coffee before it starts
to give results that are satisfactory.
When making the first 5-6 beverages, it is normal to hear the noise of boiling water. This
noise becomes less during use.
Pull the appliance forward to get access to the main switch, the area for accessories and
the lid of the bean container. Pull the coffee spouts forward to open the service door.

OPERATION
EN 14
The appliance goes to standby automatically. It is now ready for normal use.
Danger of burns
During rinsing, a little hot water flows out of the coffee spouts. Avoid contact with splashes
of water. Do not let the appliance stay unattended while hot water is being supplied.
Set your appliance to ‘On’
The appliance is ready to use if it has reached the correct temperature.
The primary screen is shown.
Attention
Each time the appliance is set to ‘On’, it performs an automatic preheat and rinse cycle.
This cycle cannot be interrupted. The appliance is ready for use only after completion of this
cycle.

OPERATION
EN 15
Tip
Put a cup under the spouts. Collect the hot water from the rinse cycle to warm the cup.
Important!
Do not push the main switch while the appliance is set to ‘On’.
Set your appliance to ‘Standby’ and ‘Off’
Please note
If you do not use the appliance for a long period, set the appliance to ‘Off’.
Important tips and tricks when you make coffee
• The supply of coffee can be stopped at any moment.
• As soon as the supply has ended, you can increase the quantity of coffee.
• You can customise beverages.
• Adjust the grind level if the coffee is supplied a drop at a time or too weak and not creamy
enough.
• Make a hotter coffee:
▷Perform a rinse cycle and warm the cups with the hot water from the rinse cycle.
▷Supply hot water to warm the cups.
▷Use the cup warmer setting to warm the cups.
▷Increase the coffee temperature.
• Lower the spouts to the cup as near as possible. This makes the coffee more creamy.
• After the coffee supply, the aroma setting and the quantity setting are reset to the ‘original
recipe’.

OPERATION
EN 16
• Once a beverage has been made, the appliance is ready to make the next beverage.
Make coffee using coffee beans
Important!
Do not use green, caramelised or candied coffee beans. They could make the coffee mill
unusable.
Espresso 2x Espresso
Make coffee using pre-ground coffee
Important!
• Only add pre-ground coffee when the appliance is set to ‘On’. Otherwise, the coffee
could spread through the inside of the appliance and damage it.
• Only make one cup of coffee at a time. Do not use more than 1 measuring spoon.
• Make sure the funnel is not blocked (see chapter ‘Maintenance’).

OPERATION
EN 17
Tip
Espresso 2x Espresso
Adjust the grind level
The coffee mill is set by default to prepare coffee correctly. It should not require regulating initially.
However, you can adjust the grind level:
• if the coffee is supplied too slowly or not at all.
▷Turn the knob one click clockwise in the direction of 7.
• for a stronger, creamier coffee.
▷Turn the knob one click anti-clockwise in the direction of 1.
• Only turn the knob when the coffee mill is operating (during the start
of the coffee preparation). Turn the knob one click at a time. When you have made at least 2
cups of coffee, turn the knob another click if the adjustment did not give the desired result.
Make milk-based hot drinks
• Use skimmed or partially skimmed milk at refrigerator temperature (about 5 °C) to get a
richer denser froth.

OPERATION
EN 18
Dial
position
Description
Recommended for…
No froth
Caffe latte / Hot milk
Min. froth
Latte macchiato
Max. froth
Cappuccino / Frothed milk
Customise beverages
Customise several beverage settings for the user profile that is shown in the primary screen.
• Touch the user profile key to select another user profile.

OPERATION
EN 19
Supply a beverage that is customised
Make sure the primary screen shows the correct user profile. If you select a beverage that has
been customised for this profile, it will be supplied with the customised saved settings.
If you select the guest profile, beverages will be
supplied with the default settings.
2
x
The order in which all the beverages for a user profile are displayed is based on the
frequency of selection.
Important!
You cannot use this touch key when the guest profile is shown on the display.
2
x
Customise a user profile

OPERATION
EN 20
Supply hot water or steam
volume.
• For a creamier froth, rotate the cup with slow movements up and down.
Please note!
Clean the hot water spout each time you used it to froth milk (see chapter ‘Maintenance’).
