AT&T PagePac Plus Quick start guide

463-248-201
Issue 1
3/1/93
PagePacPlus Controller
Installation and Use

Copyright 1993 AT&T
All Rights Reserved
Written/Printed in U.S.A.
AT&T 463-248-201
011722051-000
Issue 1, March 1993
Notice
Every effort was made to ensure that the information in this guide was complete and accurate at the time of printing.
However, information is subject to change.
Federal Communications Commission (FCC) and Canadian Dept. of Communications Interference Notice
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15
of the FCC rules and D.O.C. regulations. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction guide, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to clause
harmful interference, in which case the user will have to correct the interference at his or her own expense. For
additional FCC interference, registration, and repair information, see the
Installation Guide.
Trademarks
PAGEPAC, PAGEPAC PLUS, and AMPLICENTER are a trademark of Harris Corporation.
Warranty
AT&T provides a limited warranty for this product. Refer to “AT&T Limited Warranty and Limitation of
Liability” in Appendix A.
Ordering Information
The order number for this book is 463-248-201. To order copies of this book, call 1-800-432-6600 in the U.S. and
1-800255-1242 in Canada. For more information on how to order this and other system reference materials, see
“Reference Materials,
‘‘ in “About This Guide.”
For information on ordering replacement parts, accessories, and
other compatible equipment, refer to “Product Ordering Information,” in Section 1.
Support Telephone Numbers
AT&T provides a toll-free customer helpline 24 hours a day.
In the U.S., call the AT&T Helpline at 1-800-628-2888 if you need assistance when installing, programming, or
using your system. For service or technical assistance in Canada, call one of the following Technical Assistance
Centers:
Eastern Canada and Ottawa
1800363-1882
Ontario:
1-800-3874268
Central and Western Canada:
1-800-663-9817
VG—3/93—2.4M

Contents
1.
Overview
1-1
■
■
■
■
■
■
About This Guide
How to Use This Guide
Installation Steps
Connectivity Chart
Product Safety Labels
Terminology
Reference Materials
How to Comment on This Guide
Shipping Container Contents
Ordering Information
Features and Capabilities
Specifications
■
■
■
■
■
■
1-3
1-3
1-4
1-6
1-8
1-8
1-8
1-8
1-9
1-9
1-10
1-12
2.
Hardware Configuration
■ Power
■ Tone Generator
■ Circuit Protection
■ Mounting
■ Universal Approvals
■ Controls, Indicators,
■ Auxiliary Equipment
2-1
2-2
2-2
2-2
2-2
2-2
Switches and Connectors
2-3
2-6
iii

3.
Installing the Hardware
3-1
■
■
■
■
■
■
■
Important Safety Information
Example System Setup
Mounting PagePac Plus Components
Zone Configurations
Speaker Connections
Paging Zone Connections
Contact Closure Zone Connections
Switch Settings
Interconnection Considerations
Communication System Interface
Music Source Interface
Programming Overview
Testing System
3-3
3-4
3-8
3-11
3-11
3-11
3-15
3-15
3-16
3-18
3-20
3-20
3-20
■
■
■
■
■
■
4.
Maintenance and Customer Support
■ In Case of Difficulty
■ Power Failure Operation
■ Common Problems
■ Troubleshooting
4-1
4-2
4-2
4-3
4-3
A.
FCC Statement/Registration and Warranty Information
A-1
B.
Feedback Form
B-1
IN
Index
IN-1
iv

Tables
1.
Overview
1-1
1-1. PagePac Plus Connectivity Chart
1-6
1-2. Controller Specifications
1-12
4.
Maintenance and Customer Support
4-1
4-1. Troubleshooting
4-4
v

Figures
1. Overview 1-1
1-1. Hardware Installation Steps 1-5
1-2. PagePac Plus System Components 1-11
2. Hardware Configuration
2-1. Controller, Amplicenter, and Zone Expansion Unit
Back Panels
2-1
2-5
3.Installing the Hardware
3-1.
3-2.
3-3.
3-4.
3-5.
3-6.
3-7.
70 Volt Constant Voltage Distribution
Controller System Setup
Hybrid System Setup
Wall Mounted Hardware
Rack Mounted Hardware
Speaker Zone Wiring to Controller
System
Contact Closure Zone Wiring to Controller
Setup
3-1
3-5
3-6
3-7
3-9
3-10
3-12
3-14
vi

Overview
1
Overview 1-1

“This page intentionally left blank”

The following subsections give a summary of the PagePac Plus controller
features, system components, and auxiliary equipment.
About This Guide
How to Use This Guide
The PagePac Plus Paging Controller Installation and Use Guide explains
the features of the PagePac Plus Controller, how to install and configure
the controller, installation of the PagePac Plus amplicenter, and interface
to communication system and other auxiliary equipment. For programming
instructions, refer to the PagePac Plus Programming and Operation Guide.
It is intended that PagePac Plus be installed by a trained telephone, audio,
or electrical installer with basic electronic knowledge. PagePac Plus
conforms to common installation practices and preferences found within
the Telcom Electrical and Commercial Sound installers manual.
■
■
■
■
Overview. Before beginning hardware installation, review and
understand the Zone Map filled out in the PagePac Plus Programming
and Operation Guide. It determines how the hardware is to be
installed and set.
If you are installing the system for the first time, you should read the
entire guide before getting started to familiarize yourself with the
features.
Hardware Configuration. This section describes and illustrates the
various PagePac Plus components (controller, zone expansion units,
and Amplicenter amplifiers, D20, D100, and D300).
System Installation. This section provides instructions for mounting
the PagePac Plus hardware on a wall or in a standard 19“ equipment
rack. Complete, detailed instructions for connection and operation with
telephone systems, music source, speakers, and any control device
inputs or outputs is provided. Hardware switch settings are given for
various zone applications. A programming overview is presented.
Maintenance and Customer Support. This section gives some basic
troubleshooting tips if a zone does not operate properly after
installation and programming. Should a problem arise which requires
technical assistance beyond the information provided in this guide, call:
AT&T Technical Support, 1-800-552-3293
AT&T National Technical Marketing, 1-800-222-1313
AT&T National Service Assistance Center, 1-800-628-8888.
Overview 1-3

Installation Steps
1.
2.
3.
4.
NOTE: The numbers in these
5.
steps match the numbers in
figure 1-1.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
Determine PagePac Plus features to be used in the facility. Refer to
the Zone Map and Zone Configuration Tables filled out in the
Programmer’s Guide.
Verify Zone Map information matches facility wiring diagram.
Pull cables.
Mount the PagePac Plus components [Amplicenter, Controller and
Zone Expansion Unit(s)], to either the wall, cabinet or a rack.
Make the connection between the Controller and Amplicenter, and
Controller and Zone Expansion Unit (if any).
Set the DIP switches on the Zone Expansion Unit(s) [if needed].
Using the Zone Configuration Table, set the Zone Option Switches
on the Controller and the Zone Expansion Unit(s) to the correct
settings.
Set the Controllers Telephone Mode Selection Switch to the correct
position for the host telephone system.
If the system is used in the Constant Voltage Distribution Mode (i.e.
70 volt speakers), make connection and set the Amplicenter
Telephone Mode Selection Switch to the Dry Loop 600 Ohm position.
Connect all necessary feature inputs (microphone, night bell, etc.,).
Using the Zone Map Table, connect speakers, remote amps and
inputs to the proper zones.
Power up the system.
Check LED’s on PagePac Plus system for proper operation.
Make the telephone connection.
Perform Programming.
Test system:
A – Audio paging Zones
B – Contact Closure Output Zones
C – Contact Closure Input Zones.
1-4 Overview

Figure 1-1. Hardware Installation Steps
Overview 1-5
0
0
ALL MODULES
POWER INPUT
@ 0
100-250 VAG
60Hz, 1 amp
0 0
RS-232 TO PC
(8)
@
CONTROLLER
ZONE EXPANSION
UNIT# 1
0
POWER, CONTROL, & AUDIO (TYPICAL)
0
MUSIC INPUT
NIGHT BELL
@
"TIENDANT
ACCESS
INPUT
@
TELEPHONE
SYSTEM
iNTERFACE
,-----+----ZONE
t=-----+-----,r----r-....., OPTION
r---..-=-=-=~==-=""'=-1 SWITCHES
(TYPICAL)

Connectivity Chart
The Connectivity chart gives the trunk interface requirements for the host
systems listed. This information is then used to set the telephone mode
function switch on the PagePac Plus Controller.
Table 1-1. PagePac Plus Connectivity Chart
System
2000
Merlin Plus Merlin 206/820 Merlin 1030/3070 Merlin II Merlin Legend
Mode C.O.
Line C.O.
Line Page
PortC.O.
Line Page
Module
C.O.
Line Service
Module C.O.
Line Analog
Station C.O.
Line Analog
Station
Loop
Start
Ground
Start
Dry
Loop
(Hi Z)
Dry
Loop
(600Ω)
Yes Yes
Note 1
——
— — —————
————
No
Yes
—
Yes
Note 1 Note 1
— — —
—
No —
——
Spirit 308/616 Spirit
1224/2448 Partner Plus Partner II
Mode C.O.
Line Page
PortC.O. Line C.O. Line Analog
Station Page
PortC.O.
LineAnalog
Station Page
Port
Loop
Yes —
Yes
Start
Ground
— — —
Start
Dry
— —
Loop
(Hi Z)
——
—
Dry —
No —
Loop
No
Yes —
— —
——
Yes
— Yes —
Note 1
—— — —
—— — —
—— — —
—
Yes — —
— — ——
— — — —
Yes ——Yes
Note 2
Note 2
1-6 Overview

Table 1-1. PagePac Plus Connectivity Chart (continuation Page 1)
System 25 System 75/G1/G3I Definity System 85/G2
ModeC.O. Line Analog
Station Aux.
Port C.O.
Line Analog
Station Aux. Port C.O.
Line Analog
Station Aux.
Port
Loop
Start Yes——Yes——Yes ——
Ground
Start YesYes Yes
——————
Dry
Loop
(Hi Z)
—————————
Dry
Loop
(600 Ω)
Yes
Note 2
Yes
Note 2
Yes
Note 2
——————
Comkey 416, 718
1434 and 2152
Horizon Dimension
Mode C.O. Line Intercom C.O. Line Analog
Station Intercom C.O.Line Analog
Station Aux.
Port
Loop Yes —
Yes
Start
Ground
— —
Yes
Start
Dry
— — —
Loop
(Hi Z)
Dry
—
No —
Loop
(600 Ω)
— Indicates a non applicable connection
NOTES:
— —
Yes — —
— —
Yes ——
Yes ——
Yes —
—
No — —
Yes
Note 2
1. Two pound keys (##) must be pressed for one pound key (#) to be sent to the controller when dialing
from a multi-button set.
2. A 2 pair RJ-11 cord must be used to interface wit the Controller.
Overview 1-7

Product Safety Labels
This guide contains several product safety labels, identified by a
CAUTION - Indicates the presence of a hazard that will or can cause
minor personal injury or property damage if the hazard is not avoided.
WARNING - Indicates the presence of a hazard that can cause
severe or fatal personal injury if the hazard is not avoided.
Carefully read the WARNING label in section 2, Installation. Opening the
system units wiII expose you to hazardous voltages, which can cause
severe personal injury or death.
Also, read “Safety Instruction” at the beginning of section 2, Installation.
Terminology
This guide uses standard telephony, audio, and electronics terminology
used in describing paging features, hardware, and telecommunication
system interface.
Reference Materials
For PagePac Pius programming instructions, refer to the PagePac PIuS
Programming and Operation Guide. See the PagePac Plus Amplicenter
and Zone Expansion Unit Service Manuals for specific information on
those products.
To order additional reference materials, call the AT&T Customer
Information Center:
In the U.S. 1800432-6600
In Canada: 1800255-1242
How to Comment on This Guide
A feedback form is located at the end of this guide. If the feedback form is
missing, send your comments and recommendations for changes to:
J. Dean
AT&T
99 Jefferson Road (Room 2A-25)
Parsippany, NJ 07054
FAX: [phone]
1-8 Overview

Shipping Container Contents
The following items should be found in the PagePac Plus Controller
shipping container. If something is missing, notify your local dealer.
■
■
■
Controller unit, including plastic, snap on cover.
Mounting hardware (screws and brackets)
Cables, preterminated, 8-pin modular (18“ long)
Cord, preterminated, RJ11 (18“ long)
Programming Guide
This Installation Guide
■
■
■
Ordering Information
Equipment is available from many AT&T sources. Contact any of the
following for sales information and advice on the equipment that would
best meet your needs:
AT&T Catalog Sales 1 800 451-2100
AT&T Sales Office 1 800 247-7000
AT&T Phone Center Store
1 800 222-3111
AT&T Authorized Dealer 1 800 247-1212.
Overview 1-9

Features and Capabilities
NOTE: The Programming and ■
Operation Guide details the
features of the controller. Also,
refer to the PagePac Plus
Amplicenter and Zone Expansion
Unit Service Manuals for specific
information on those products.
■
■
The following list provides an overview of the features of the PagePac
Plus system, illustrated in figure 1-1, along with additional application
capabilities.
Controller—Connects up to 8 zones and controls entire system.
Provides easy telco access compatible to all AT&T Communication
Systems.
Zone Expansion Unit—Enables 16 extra zones, up to three units may
be connected.
Amplicenter—The amplicenter amplifies the page in increments of 20
watts (D20), 100 watts (D100), or 300 watts (D300) for a 70V constant
voltage distribution system.
Features-Combines simplicity of use with a wide range of paging
system features, including:
— Attendant (microphone) Access
— Attendant override for emergency paging
— Night Bell
— Password access security codes built-in
— Priority levels for various access methods built-in
(phone, microphones, tones, doors, etc.)
— Talk-back (2-way paging)
— Automatic volume control to accommodate paging
and talkback clarity
— Door Phone/ Door Control
— Remote amplifier Control
— Switch-closure inputs to enable tones
(for example) alarm system interface
— Switch-closure outputs to turn on
(for example) the exterior lighting
— Background Music
— Shelf, wall, cabinet, or rack mounting
— PC or telephone programming access
Can be re-programmed easily from any telephone in the system, or
using a PC.
■
1-10 Overview

Figure 1-2. PagePac Plus System Components
Overview 1-11
5"
-<
t
1 II
3~
:l
AMPLICENTER 020, 0100, 0300 PEG 5328-020, -100, -300
PagePacPW
--------- &CUJ[;)Od<S~[ij\1@7 0200 __
1"
3 ..........
2
16 " --------~
CONTROLLER
'---- PEG 5323-100
ZONE EXPANSION UNIT
'----- PEG 5335-100
19 II
MOUNTNG
BRACKETS

Specifications
Table 1-2. Controller Specifications
Capacities■ The Controller connects up to 8 zones of audio output (including talkback) and contact
closure inputs or outputs.
Dimensions and ■ 3-1/2’’ high x 19“ wide x 4-1/4” deep
Weights (assembled, approx.) 1 lb.
Switch Fabric ■ Full digital, nonblocking
Electrical ■ 1 Amp ■ Dissipation of power (30 watts at normal operation)
■342 BTU’s/hour at peak; 103 BTU’s/hour at normal
■ Contact closure output switching capability: 50V at 1 amp
Temperature ■ 0 to +50 deg. C. operational;
Range: ■ -40 to +66 deg. C. storage and shipment
Humidity Range:
■ 5% to 9% (non-condensing) storage/shipment and operation
Altitude: ■sea level to 10,000 ft. operational (1048 to 648 millibars);
(air pressure) ■40,000 ft. max. shipment
Environmental
■ Locate in an area free of excess moisture, corrosive gases, dust, and chemicals.
Interconnect 8-position, 5 Amp contact rating, locking, keyed, 22AWG wire, housing material 94V-2, U.L.
Cable (power, ■ and C.S.A. listed, providing 70.7 Vrms (4), common ground, +15 VDC and -28 VDC
audio, and control
signal from
Controller)
1-12 Overview

Hardware Configuration
2
Hardware Configuration 2-1

The PagePac Plus Controller can be installed to operate in several
different ways: as a constant-voltage 70.7 volt distribution system, a
multi-controller system, or a hybrid system. In any of the configurations, a
PagePac Plus amplicenter D20, D100, or D300 is required and the
interconnection between the control unit and the amplicenter must be
made. See “Example System Setup.”
Power
Two DC voltages derived from the PagePac Plus D-series amplicenter
(required) via the interconnect cable (provided with the Controller) are the
source for all power required by the PagePac Plus control unit and any
attached Zone Expansion Units (optional).
The front panel Power On LED on the controller lights steady to indicate
power is on and the unit is operating properly. A blinking indicator means
that the unit is malfunctioning or that the unit is in reset.
Tone Generator
The PagePac Plus controller has the ability to generate several distinctive
tones such as siren, chime, dial tone, error tone, confirmation tones,
beeps, and night bell. These tones may be sent to either the paging
amplicenter or to the telephone interface.
Circuit Protection
Complete thermal and short circuit protection with automatic reset.
Mounting
Capable of mounting into a EIA 19“ cabinet, free standing rack, or wall
mounting. Refer to the Installation chapter.
2-2 Hardware Configuration
