AT&T 1480 User manual

USER’S MANUAL
Part 2
Please also read
Part 1 — Important
Product Information
© 2002 Advanced American Telephones. All rights reserved.
AT&T and the Globe Design are trademarks of AT&T Corp. licensed to Advanced American Telephones.
2.4 GHz Corded Cordless Telephone
with Caller ID/Call Waiting 1480
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page ii

© 2002 Advanced American Telephones.
All rights reserved.
AT&T and the Globe Design are
trademarks of AT&T Corp. licensed to
Advanced American Telephones.
Printed in China. Issue 3AT&T 09/03
Visit us at www.telephones.att.com
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page iii

CONTENTS
BEFORE YOU BEGIN . . . . . . . . . . .1
About the Base and the Charger . . . .1
Choosing the Best Location . . . . . . . .1
About Caller ID with Call Waiting . . .1
About Call History . . . . . . . . . . . . . . .2
INSTALLATION. . . . . . . . . . . . . . . .3
Base Installation . . . . . . . . . . . . . . . .3
Handset Charger Installation . . . . . . .7
Belt Clip . . . . . . . . . . . . . . . . . . . . . .9
Headset . . . . . . . . . . . . . . . . . . . . . . .9
TELEPHONE OPERATION
AT THE BASE . . . . . . . . . . . . . . . . .10
Make, Answer, or End a Call . . . . . .10
Hold . . . . . . . . . . . . . . . . . . . . . . . .10
Mute . . . . . . . . . . . . . . . . . . . . . . . 10
Redial . . . . . . . . . . . . . . . . . . . . . . .10
Flash . . . . . . . . . . . . . . . . . . . . . . . .10
Speaker Volume. . . . . . . . . . . . . . . .10
Page/Intercom . . . . . . . . . . . . . . . . .10
Base Ringer Volume Switch . . . . . . .10
TELEPHONE OPERATION
AT THE HANDSET . . . . . . . . . . . . . . .11
Answer a Call . . . . . . . . . . . . . . . . .11
Make a Call . . . . . . . . . . . . . . . . . . .11
End a Call . . . . . . . . . . . . . . . . . . . .11
Hold . . . . . . . . . . . . . . . . . . . . . . . .11
Redial . . . . . . . . . . . . . . . . . . . . . . .11
Flash/Call Waiting . . . . . . . . . . . . . .11
Page/Intercom . . . . . . . . . . . . . . . . .11
Change Channel . . . . . . . . . . . . . . .11
Handset Volume . . . . . . . . . . . . . . .11
Handset Ringer
Style/Battery Save . . . . . . . . . . . .12
Temporary Tone Dialing
(Base or Handset) . . . . . . . . . . . .12
Operating Range . . . . . . . . . . . . . . .13
Display Screen Messages
(Handset and Base) . . . . . . . . . . .13
TELEPHONE MEMORY
AT THE BASE OR HANDSET . . . . . . . . . .14
Store a Number /Name
in the Directory . . . . . . . . . . . . . .14
Edit a Number/Name Stored
in the Directory . . . . . . . . . . . . . .15
Delete a Number/Name Stored
in the Directory . . . . . . . . . . . . . .16
Dial a Number from the Directory . .16
CALLER ID OPERATION . . . . . . . .17
About Call History . . . . . . . . . . . . . .17
Review Call History . . . . . . . . . . . . .17
Delete Records from
Call History . . . . . . . . . . . . . . . . .18
Dial a Displayed Number . . . . . . . .18
Store a Call History Record
in the Directory . . . . . . . . . . . . . .19
Display Screen Messages . . . . . . . . .19
Turn Off the Base
NEW CALL Indicator . . . . . . . . . .19
ANSWERING SYSTEM OPERATION
AT THE BASE . . . . . . . . . . . . . . . . .20
Audible Indicators . . . . . . . . . . . . . .20
Set the Clock . . . . . . . . . . . . . . . . . .20
About Mailboxes . . . . . . . . . . . . . . .20
About Announcements . . . . . . . . . .20
Record Your Announcement . . . . . .21
Answering System Feature Setup . . .22
Feature Summary . . . . . . . . . . . . . . .22
Listen to, Save & Delete Messages . .23
Play Messages. . . . . . . . . . . . . . . . . .23
Delete Messages . . . . . . . . . . . . . . .23
Adjust Playback Volume. . . . . . . . . .23
Call Screening/Intercept . . . . . . . . . .24
Record a Memo . . . . . . . . . . . . . . . .24
Message Window Display . . . . . . . .24
ANSWERING SYSTEM OPERATION
AT TOUCH TONE PHONE . . . . . . . . . . .25
Connect with the
Answering System . . . . . . . . . . . .25
Voice Menu. . . . . . . . . . . . . . . . . . .25
Remote Access Commands . . . . . . .25
BATTERIES . . . . . . . . . . . . . . . . .27
Charge the Handset Battery Pack . . .27
Replacing the Handset
Battery Pack . . . . . . . . . . . . . . . .28
IN CASE OF DIFFICULTY . . . . . . . .29
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page v

BEFORE YOU BEGIN
1
About the Base and the Charger
This product provides you with a base station with corded handset, a
cordless handset, and a handset charger. You’ll need to connect the base
to both AC power and a modular telephone jack. You’ll connect the
handset charger to AC power only. For more information, please see
INSTALLATION in this User’s Manual.
Choosing the Best Location
Choose a location for the base near an electrical outlet and a telephone
jack. This phone requires a modular telephone jack and a standard
electrical outlet (110v AC) not controlled by a wall switch. For optimum
performance, install the base on the highest floor of your home and away
from other cordless telephones.
NOTE: 2.4 GHz Digital Spread Spectrum telephones may cause
interference with this telephone.
About Caller ID with Call Waiting
This product has a Caller ID with Call Waiting feature that works with
service from your local phone service provider.
Caller ID with Call Waiting lets you see who’s calling before you answer
the phone, even when you’re on another call.
You may need to change your phone service to use this feature. Contact
your phone service provider if:
•You have both Caller ID and Call Waiting, but as separate services
(you may need combined service)
•You have only Caller ID service, or only Call Waiting service
•You don’t subscribe to any Caller ID or Call Waiting services.
You can also use this product with regular Caller ID service, and you can use
this product’s other features without subscribing to either Caller ID or
combined Caller ID with Call Waiting service. To turn off this phone’s Caller
ID with Call Waiting feature, see the FEATURE SETUP section of this manual.
There are fees for Caller ID services, and they may not be available in all areas.
This phone can provide information only if both you and the caller are in
areas offering Caller ID service and if both telephone companies use
compatible equipment.
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 1

About Call History
This phone assigns each incoming call a number from 1 to 90. The most
recent call will have the lowest number. When the memory is full, the
oldest call information is deleted to make room for new incoming call
information.
If you answer a call before information appears on the screen, it may not
be in the call history.
Call history information is stored independently at the base and at each
handset. If you make changes to call records in one location, other history
lists are not affected.
BEFORE YOU BEGIN
2
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 2

3Connect the power cord.
The ANSWER ON/OFF light goes on,
and CL flashes in the Message Window.
4Check for dial tone.
Lift the handset; you should hear a dial
tone.
Base Installation
Table/Desk
INSTALLATION
3
Standard
electrical outlet
Modular
telephone
jack
2Connect the telephone line cord.
1Connect the corded handset to the base
Use only the power cord
supplied with this product.
If you need a replacement,
call 1 800 222–3111.
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 3

INSTALLATION
4
Wall Mount
1Remove the adapter from under the base as shown.
2Reverse handset tab.
3Connect the telephone line cord to the jack labeled TEL LINE
on the back of the base.
4Connect the power cord to the jack labeled DC IN on the back
of the base.
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 4

INSTALLATION
5
5Wrap the telephone
line cord around the
posts on the bottom
of the base.
6Replace the adapter
on the base so the
larger end is toward
the bottom as shown.
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 5

INSTALLATION
6
7Connect the corded handset to the base.
8Connect the telephone line cord to the modular telephone jack.
9Plug the power cord into the electrical outlet.
The ANSWER ON/OFF light goes on, and CL flashes in the Message
Window.
Use only the power cord supplied with this product. If you need
a replacement, call 1 800 222–3111.
10 Mount the base on the wall.
11 Check for dial tone.
Lift the handset; you should hear a dial tone.
a) Align holes
on base with
mounting
studs on wall
jack.
b) Pull base down on
mounting studs until
it locks into place.
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 6

7
INSTALLATION
Handset Charger Installation
1Connect the power cord. Feed the
power cord through the strain-relief
channel on the bottom of the handset
charger. Then plug the cord into an
electrical outlet not controlled by a
wall switch.
CHARGING
Light: on
when
handset is in
charging
stand
2Install the handset battery.
Use NiCd Replacement Battery 3301, SKU# 91076 or to increase your
current talk time use the NiMH Replacement Battery 2414, SKU# 23403.
b) Align two holes in
plug with socket
pins, and snap the
plug into place.
d) Replace cover by
sliding it up into
place.
a) Remove battery
compartment
cover by pressing
on the
indentation
and sliding
downward.
c) Place battery pack in
compartment with
the wires in the
lower left corner,
along the bottom of
the battery pack.
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 7

INSTALLATION
8
3Charge the handset battery.
•Place the handset in the remote charging stand.
The CHARGING light goes on.
•Charge the battery at least 12 hours.
4Check for dial tone.
•After the batteries are charged, lift the handset and
press P;you should hear a dial tone.
5Set the time and date displayed on handset screen.
If you subscribe to Caller ID service, the date and time will
be set automatically with the first incoming call.
If you do not have Caller ID service, you can set the date
and time manually.
•Press G,then press >until DATE/TIME
is displayed. Press S.
•The month is flashing. Use <and >to select
the current month. Press S.
•The day is flashing. Use <and >to select
the correct day. Press S.
•The hour is flashing. Use <and >to select
the current hour. Press S.
•The minute is flashing. Use <and >to select
the correct minute. Press S.
•AM or PM is flashing. Use <and >to choose between
AM and PM.Press S.
6Set the phone for tone or pulse dialing (base only).
•Press Pon base.
•Press <or >until DIAL MODE:TONE is displayed,
then press S.
•Use <and >to select the correct setting.
•Press Sto save the setting.
NOTE: Install the base unit and spare handset charger away from
electronic equipment, such as personal computers, television sets or
microwave ovens. Avoid excessive heat, cold, dust or moisture.
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 8

9
INSTALLATION
Headset
You can use this telephone with any
industry standard 2.5 mm headset
(purchased separately). For best
results, use an AT&T 2.5 mm headset.
Plug the headset into the jack
located on the left side of the
handset (under the small rubber flap).
Do not force the connection make
sure it fits securely.
Belt Clip
Attach belt clip to the cordless handset (optional).
To attach To remove
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 9

10
TELEPHONE OPERATION
AT THE BASE
Speaker Volume
While on a call, use to
adjust the volume of
what you hear.
Mute
Press Mto
prevent your caller
from hearing you (you
can hear your caller).
Press again to deactivate.
MUTE light is on when
Mute is activated.
Base Ringer Volume Switch
Use to adjust how loudly the
base rings.
Display Dial
Press to dial the number
currently displayed on screen.
Make, Answer,
or End a Call
Press K.When
calling, use the base
keypad to dial or enter
a memory location.
SPEAKER light is on
when call is connected.
—OR—
Hold
Press Hto put a call
on hold. The IN USE
light flashes. To return to
the call, press K.
NOTE: When Hold is
active, pressing Pon
handset will also return
you to the call.
Flash
Access subscriber services while on a call.
Redial
Press to call the last
number dialed at the
base (up to 32 digits).
Page/Intercom
1Press and release to signal someone at the handset. A paging tone sounds.
2When the person at the handset presses I,the handset and base can
communicate without tying up the phone line.
3Press again or press oon handset to disconnect.
On steadily:
handset or base
speakerphone is in use
Flashing slowly:
a call is on hold
Press to enter programming mode.
Press to return to idle state
1Dial the number.
Use <to make
corrections.
2Press d to
place the call.
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 10

11
Make a Call
Press P,then
dial the number
— OR —
Dial the number
(use <to
backspace and
correct digits), then
press Pto call.
Flash/
Call Waiting
Access special
telephone company
subscriber services.
Redial
Press P,then
press Rto call
last number dialed
(up to 32 digits).
TELEPHONE OPERATION
AT THE HANDSET
End a Call
Press O
— OR —
Place handset in
handset charger.
Exit
programming.
Cancel a page.
Handset Volume
While on a call,
adjust volume
of what you hear.
Hold
Press to put a call
on hold. Press again
to release hold
— OR —
Lift the handset of
an extension.
Page/Intercom
1Press and release to
signal someone at
the base. A paging
tone sounds.
2When the person at the
base presses I,the handset
and base can communicate without
tying up the phone.
3Press Oor press Ion base to disconnect.
Answer a Call
Press any key
except O.
Change Channel
Switch to a clearer
channel while on a call.
Enter programming
while not on a call.
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 11

12
Handset Ringer Style/Battery Save
You can select from four different handset ringer styles, or turn the
ringer off and extend the battery life.
1Make sure the handset is off.
2Press Gto enter programming mode.
3Press >until the screen displays RINGER:.
4Press S.The screen displays the current setting.
5Press <or >to select 1,2,3,4,or OFF.You will hear a
sample of each ring.
6Press Sto choose the displayed ringer setting.
Temporary Tone Dialing (Base or Handset)
If you have dial pulse (rotary) service, you can change from dial pulse
to touch tone dialing during a call by pressing *.This is useful if you
need to send touch tone signals for access to telephone banking or
long-distance services.
1Dial the number.
2Press *.Buttons pressed after this send touch tone signals.
3After you hang up, the phone automatically returns to
dial pulse (rotary) service.
Headset
You can use this telephone with any
industry standard 2.5 mm headset
(purchased separately). For best
results, use an AT&T 2.5 mm headset.
Plug the headset into the jack
located on the left side of the
handset (under the small rubber flap).
Do not force the connection make
sure it fits securely.
TELEPHONE OPERATION
AT THE HANDSET
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 12

13
TELEPHONE OPERATION
AT THE HANDSET
Operating Range
This cordless telephone operates within the maximum power allowed by
the Federal Communications Commission (FCC). Even so, this handset and
base can communicate over only a certain distance — which can vary with
the locations of the base and handset, the weather, and the construction of
your home or office. For best performance, keep the base antenna fully
upright.
If you receive a call while you are out of range, the handset might not
ring — or if it does ring, the call might not connect when you press P.
Move closer to the base, then press Pto answer the call.
If you move out of range during a phone conversation, you might
hear noise or interference. To improve reception, move closer to the base.
If you move out of range without pressing O,your phone will be
left “off the hook.” To hang up properly, walk back into range, periodically
pressing O.
Display Screen Messages (Handset and Base)
Screen Displays: When:
RINGING There is a call coming in.
CONNECTING The handset is waiting for a dial tone.
PHONE ON The handset is in use.
PAGING The base is paging the handset.
HOLD There is a call on hold.
BATTERY LOW The battery needs to be recharged.
(Handset only)
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 13

14
TELEPHONE DIRECTORY
AT THE BASE OR HANDSET
The base and cordless handset can each store 50 telephone numbers with
names, each up to 24 digits long. Directory information is stored
independently at the base and cordless handset. Changes made to entries
at one location do not affect the other directory. Entries are stored
alphabetically. For consistency with Caller ID entries, you may wish to
enter last names first.
Note: Press Oat any time to exit directory.
Store a Number/Name in the Directory
1Press Pon the base or Gat the handset.
The screen displays DIRECTORY.
2Press S.The screen displays ENTER NAME.
3Using the chart below, enter up to 15 characters for the name
you’re storing with the number. Use <to backspace and make
corrections; use >to advance and add a space.
Presses
Dial Key 1 23456
11
2ABC2
3DEF 3
4GH I 4
5JKL5
6MNO 6
7PQRS 7
8TUV8
9WX Y Z 9
00
**
#&’ ,-.#
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 14

15
TELEPHONE DIRECTORY
AT THE BASE OR HANDSET
4When you finish entering the name, press S.
The screen displays ENTER NUMBER.
5Enter the telephone number. Use <to backspace and make
a correction. Press rto store a pause in the dialing
sequence.
—OR—
Press rto display the last number dialed from
this phone.
6Press S.If you are using the base, you are now done. If you
are using the handset, the screen displays DISTINCT RING? and
the current setting.
7Press <or >to change the setting. Choose Y(for Yes) if you
wish the phone to alert you to calls from this number by changing
to a distinctive ringing pattern after the first ring. Choose N(for
NO) for a normal ringing pattern.
8Press Sto confirm your selection. If you chose Yin Step 7,a
Dwill be displayed with the directory entry.
Note: When memory is full the screen displays MEMORY FULL,an error
tone sounds, and you will not be able to store a new number until you
delete a stored number.
Edit a Number/Name Stored in the Directory
1Press >(DIR). The screen displays DIRECTORY.
2Press <or >to scroll alphabetically through entries
stored in memory
—OR—
Press the dial pad key for the first letter of the entry you
want to edit.
3When the screen displays the number you want to edit, press
S.Then press <or >until EDIT flashes.
4Press S.The screen displays the name and number. The
flashing cursor appears at the end of the name. Use <,>and
the dial pad keys to edit the name. Press Sto move on to
edit the number. Press Sto move to edit the Distinctive
Ring setting.
5Press Sto save the edited information.
EEDDIITTDIAL ERASE
973-555-0123
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 15

16
Delete a Number/Name Stored in the Directory
1Press >(DIR). The screen displays DIRECTORY.
2Press <or >to scroll alphabetically through entries
stored in memory
—OR—
Press the dial pad key for the first letter of the entry you
want to delete.
3When the screen displays the number you want to delete, press
S.Then press <or >until ERASE flashes.
4Press S.The screen displays ERASE NO YES and the number.
The current choice flashes.
5Press <or >until YES flashes.
6Press S.You’ll hear a series of beeps confirming the deletion.
Dial a Number from the Directory
1Press >(DIR). The screen displays DIRECTORY.
2Press <or >to scroll alphabetically through entries
stored in memory
—OR—
Press the dial pad key for the first letter of the entry you
want to dial.
3When the screen displays the number you want to dial, press
Pon the handset or don the base to dial
the number
—OR—
Press S.Then press <or >until DIAL flashes.
4Press S.The phone automatically dials the number.
EDIT DDIIAALLERASE
973-555-0123
EDIT DIAL EERRAASSEE
973-555-0123
TELEPHONE DIRECTORY
AT THE BASE OR HANDSET
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 16

17
About Call History
This phone assigns each incoming call a number from 1 to 90. The most
recent call will have the highest number. When the memory is full, the
oldest call information is deleted to make room for new incoming call
information.
For each call that comes in, the screen displays the following information
between the first and second rings:
•Your caller’s name (15 letters are sent by your telephone
company)
• The caller’s area code and telephone number
• The time and date of the call
• The position of the call in call history.
If you answer a call before the information appears on the screen, it will
not be in the call history.
Note: Press Oon the handset or on the base at any time to
exit call history.
Review Call History
The screen displays call information for about 15 seconds after it has been
received.
1Press <(CID) to view call history. The screen displays
2Use <and >to scroll through records in call history.
NEW 02 OLD 00
12/23 10:34AM
CALLER ID OPERATION
Caller’s name
Caller’s
telephone
number
Date of call Time of call Position of call
in call history
Caller’s name
Caller’s
telephone
number
Date of call Time of call Position of call
in call history
91-5824-70-00_ATT1480_R0 9/15/03 2:47 PM Page 17
