SHOWCASE
Key Features
• Custom Designed for Easy Product Access
• Integrated Vertical Lighting in Each Post
• Electronic Temperature Control With
Digital Readout
• Automatic Defrost and Heated Drain Pan
• Adjustable Dual Position Shelves
• High Impact Graphics Available
Model
SHOWCASE 27 1/2
(700)
27 1/2
(700)
55 7/8
(1420)
24 1/4
(615)
264
(120)
22 1/4
(565)
31
(790)
9 3/4
(275) 115.60.1 12 1/22
LD HL D H
NA
Shelves Amps HP
Capacity
cu.ft (lt)
Crated
Weight
lbs (kg)
Power
(V-Hz-Ph)
Exterior Dimensions
inches (mm)
Interior Dimensions
inches (mm)
Doors
OPEN AIR COOLERS

REFRIGERATION SOLUTIONS
3235 Industry Drive • Suite C
North Charleston, SC 29418
Phone: [phone]
Toll Free: 800-905-4768
Fax: [phone]
Toll Free Fax: [phone]
www.atcgroup.net
[email protected]
WARRANTY
One year warranty on
all parts and labor and
an additional 4 year
prorated warranty on
compressor.
Details
SHOWCASE
Technical Drawing
Electrical
Ready for connection to 115V/60Hz
single phase 20 amp dedicated
outlet.
Includes an 8’ cord and plug set.
Refrigeration System
Self-contained environmentally-
friendly refrigeration system
using CFC-free R404A refrigerant.
Self-contained heated drain pan
and condensate evaporation
system.
Automatic self-defrost cycle.
Electronic temperature control with
digital readout maintains
34ºF to 41ºF (1ºC to 5ºC).
Bottom mounted refrigeration
unit slides out for easy
maintenance and service.
Recommended
Operating Conditions
This unit is best suited for an
environment where temperatures
remain below 80ºF (24ºC) and
humidity does not exceed 55%.
Open Air models should not be
installed in any area where the
air curtain will be frequently
disrupted. This includes
placement near an HVAC vent,
open doorway, or fan.
Areas with direct sunlight should
also be avoided.
Options
208-230V/ 50Hz
Custom Graphics
Additional Shelves
Pricing Strips
3” heavy duty casters
Various Cabinet Colors
27 1/2 (700)
55 7/8 (1420)
27 1/2 (700)
Cabinet Construction
Exterior: Galvanized metal cabinet
with impact resistant extruded plastic
accent panels – gray.
Large low-E double pane tempered
thermal glass side panels for increased
product visibility.
Interior: Epoxy powder coated steel for
increased durability and easy cleaning.
High-density, CFC-Free, polyurethane
insulation.
Low profile fixed wheels allow for easy
movement of unit and facilitate cleaning
of surrounding area.
Shelving
Two (2) heavy duty epoxy powder coated
steel shelves:
- Upper: 24” x 11 ¾” (610 x 300)
- Lower: 24” x 14 ¾” (610 x 376)
All shelves are dual position allowing for
horizontal or gravity fed positions, and are
adjustable in 1” increments.
Designed to allow use of shelf pricing
strips.
Lighting
Fluorescent vertical lights mounted in
each post provide for maximum
illumination of products.
Utilizes T8 bulbs and an electronic ballast
for increased energy efficiency and
extended life.
NEMA 5-15R
