Atdec A-dec 301 User manual

Air Motor
000OM-DM0906EN
A-dec 301
INSTRUCTIONS
FOR USE
Please read these Instructions For Use
carefully before use, and file for future
reference. MADE IN JAPAN

1
1 User and Indications for Use
User: Qualified Professionals (Dentist/Dental hygienist)
Indications for Use:
Air Motor is intended for the following application(s):
A connection equipment to transfer energy (rotation, air, water,
light) required for handpieces.
The device is used in combination in tooth restoration,
periodontics and endodontics.
For identification of symbols, refer to the “12.
Symbol” section on page 16 and Regulatory
Information, Specifications, and Warranty
document (p/n 86.0221.00), which is available in
the Resource Center at www.a-dec.com.
2 Precautions for Handling and Operation
• Please read these precautions carefully and use only as
intended or instructed.
• Safety instructions are intended to avoid potential hazards that
could result in personal injury or damage to the device. Safety
instructions are classified as follows in accordance with the
seriousness of the risk.
Class Degree of Risk
WARNING
Hazard that could result in serious injury or
damage to the device if the safety instructions
are not correctly followed.
CAUTION
Hazard that could result in light or moderate
injury or damage to the device if the safety
instructions are not correctly followed.

2
NOTICE
General product specification information
highlighted to avoid product malfunction and
performance reduction.
WARNING
• Clean and lubricate the motor immediately
(within 1 hour) after each treatment to remove
residue. Failure to properly maintain the motor
may cause infection, product failure or
overheating, leading to burn injuries. (Refer to “7.
Post-use Maintenance”.)
CAUTION
• Read this Instructions For Use before use to fully understand
the product functions and file for future reference.
• When operating the product, always consider the safety of the
patient.
• Users are responsible for the operational control, maintenance
and continual inspection of this product.
• Prior to clinical use, inspect the motor. Check for vibration,
noise and overheating. If any abnormalities are found, stop
using the motor immediately and contact your Authorized
A-dec Dealer. (Refer to “6. Check Before Treatment”.)
• Do not disassemble or alter the motor except as described in
this Instructions For Use.
• Do not allow any impact to the product. Do not drop the
product. Deformation may cause the motor to fail during use.
• Operators and all others in the area must wear eye protection
and a mask when operating this motor.

3
CAUTION
• Should the motor function abnormally during use, stop using
the motor immediately and contact your Authorized A-dec
Dealer.
• Do not use the following fluids to wipe, immerse or clean the
product; strong/super acid water, strong acid/alkaline
chemicals, chlorine containing solutions, solvents such as
benzine or thinner.
• The motor is delivered in a non-sterile condition and must be
autoclaved prior to use.
• Perform regular function and maintenance checks. (Refer to
“9. Periodical Maintenance Checks”.)
• If the motor has not been used for a long period, rotate the
motor and check for noise, vibration and overheating before
use.
• To avoid clinical downtime, A-dec recommends that you keep
a spare to replace one that breaks during treatment.
CAUTION
• U.S. Federal law restricts this device to sale by or on the order
of a licensed physician.
NOTICE
• Repairs of this product are only to be performed by authorized
service technicians according to A-dec requirements. Contact
your Authorized A-dec Dealer if repairs are necessary.

4
3 Preparation for Use
3-1 Setting of Air & Water Supply Pressure
Measure the supply pressure
at the motor/hose connection
point and set the pressure to
the value specified on the
specification table (Fig. 1).
Fig. 1
Chip Air Pressure
Exhaust Air
Pressure
Water
Pressure
Hose
Drive Air
Pressure
Please contact your local dealer for Multi Gauge Z109400.
WARNING
• Do not exceed the optimum pressure specified
on the specification table.
CAUTION
• Do not use air contaminated by dust, moisture or oil.
3-2 Connecting and Disconnecting the Motor
3-2-1 Connecting
1) Insert the motor correctly
into the hose connector
and tighten the hose nut
(Fig. 2).
2) Make sure the motor is
connected firmly to the
hose (Fig. 3).
Fig. 2
Motor Hose Nut
Fig. 3
Motor Hose
Multi Gauge

5
3-2-2 Disconnecting
Loosen the hose nut and
remove the motor from the
hose (Fig. 4).
Fig. 4
Hose Nut
Motor
CAUTION
• If the connection to the hose is loose, the motor may pop out
during treatment, causing injury to the patient’s mouth, face,
etc., and injury to the operator.
4 Connecting and Disconnecting the Handpiece from the Motor
4-1 Connecting
1) Insert the handpiece
directly into the motor (Fig.
5).
2) Confirm that the
handpiece is firmly
connected to the motor.
Fig. 5
Handpiece Motor

6
4-2 Disconnecting
Hold the motor and the handpiece, then pull apart. (Fig. 5)
CAUTION
• Do not connect or disconnect the handpiece until the motor
has completely stopped.
• Make sure that the motor and handpiece are securely
connected. The motor and coolant air pressure may cause
the handpiece to jump out of the motor, which could result
in injury.
• Connect ONLY to E type handpieces (ISO 3964 (EN ISO
3964)).
5 Forward / Reverse Rotation
1) Forward Rotation: Turn the
FWD/REV Change Ring to “F”.
(Fig. 6)
2) Reverse Rotation: Turn the
FWD/REV Change Ring to “R”.
(Fig. 7)
3) When the FWD/REV Change
Ring is positioned at the
middle of “F” and “R” , the
drive air is interrupted and the
motor does not rotate. (Fig. 8)
Fig. 6
Fig. 7
Fig. 8
FWD/REV
Change Ring
“F”: Forward Rotation
“R”: Reverse Rotation

7
6 Check Before Treatment
Follow the check below before use. If any abnormalities are
found, stop using the handpiece immediately and contact your
Authorized A-dec Dealer.
1) Connect the handpiece and make sure that it is securely
connected.
2) Rotate the motor for about one minute at the maximum
rotation speed. During rotation, check for abnormalities such
as abnormal rotation, vibration, noise.
3) After the motor rotation has completely stopped, touch the
motor to confirm there is not heating abnormally.
7 Post-use Maintenance
After each patient, maintain the product as follows.
WARNING
• To ensure cleaning and sterilization efficacy, use
only the following procedures for reprocessing.
• Follow any additional local directives, standards,
and guidelines for cleaning and sterilization.
• Clean and lubricate the motor immediately
(within 1 hour) after each treatment to remove
residue. Failure to properly maintain the motor
may cause infection, product failure, overheating
leading to burn injuries.

8
7-1 Cleaning at point-of use
CAUTION
• Do not use the following liquids to wipe, immerse, or clean
the product: strong/super acid water, strong acid/alkaline
chemicals, chlorine-containing solutions, solvents such as
benzine or thinner.
• Do not immerse A-dec instruments in disinfectant solution
or clean in ultrasonic devices.
1) Always wear protective
gloves, a mask, and
protective goggles for
safety purposes and to
minimize the risk of
infection. (Fig. 9)
Fig. 9
2) Remove the bur. (Fig. 10)
Fig. 10
3) Wipe the exterior of the
handpiece and motor clean
using a cloth moistened
with disinfectant or ethanol
with a concentration of
60-90%. (Fig. 11)
When using disinfectant,
follow the instructions
given by the manufacturer
of the disinfectant.
Fig. 11

9
Use a state-sanctioned disinfectant with proven
bactericidal, fungicidal, and virucidal properties.
The following disinfectants can be used in the United
States and Canada.
CaviCide®, CaviWipes®(manufactured by Metrex)
4) Remove the handpiece
from the motor and remove
the motor from the hose
(Fig. 12).
For reprocessing of the
handpiece, refer to the
Instructions For Use of the
handpiece’s manufacturer.
Fig. 12
Handpiece
Motor
Hose
5) Carry the motor to the
decontamination area.
7-2 Cleaning and Drying
Perform cleaning and drying using the manual or automatic
method.
Manual Method (Cleaning and Drying the Exterior)
Wash the motor under running water following the procedures
below.
(Water condition: ≤100°F (38°C), ≥1 gal/min (3.5L/min);
water should be of the same quality as drinking water)
1) Brush the exterior of
motors under running tap
water using a soft bristled
brush for one minute (Fig.
13).
Fig. 13
2) Rinse the motors under running tap water for 20 seconds.

10
3) Remove any moisture from the motor with compressed air
and wipe off any external moisture using a dry lint free
cloth.
Under appropriate lighting (natural office lighting, 500 lx or
higher), inspect the motor for blood or other debris. If any
visible debris remains, repeat the process until the motor is
visually clean.
4) Wipe the exterior of the
motor clean using a cloth
moistened with disinfectant
or ethanol with a
concentration of 60-90%
(Fig. 14).
Fig. 14
When using disinfectant, follow the instructions given by the
manufacturer of the disinfectant.
Use a state-sanctioned disinfectant with proven bactericidal,
fungicidal, and virucidal properties.
The following disinfectants can be used in the United States
and Canada.
CaviCide®, CaviWipes®(manufactured by Metrex)
After cleaning, if residual moisture is present, wipe it off with
a dry cloth or blow it off with compressed air (≤50psi
(0.35MPa)) until there is no moisture in the interior and
exterior.
When blowing off with compressed air, cover the motor with a
cloth to prevent scattering of water. Proceed to “7-3
Lubrication”.

11
7-3 Lubrication
■PANA SPRAY Plus (Lubricating the Interior)
1) Attach a tip nozzle* to the
nozzle of the PANA SPRAY
Plus.
* Tip nozzle is the accessory of
the PANA SPRAY Plus.
2) Shake the can 3 or 4 times,
and insert the tip nozzle
into the drive air port of the
motor while holding the
motor with a cloth.
Drive air
port
Exhaust air port
Fig. 15
Tip Nozzle
3) Hold the motor and spray for approximately 2-3 seconds.
Apply lubricant until it expels from the exhaust air port for
at least 2 seconds. (Fig. 15)
Please contact your local dealer for PANA SPRAY Plus Z182600.
CAUTION
• Hold the spray can upright.
• Firmly hold the motor to prevent it slipping when spray
pressure is applied.

12
7-4 Packaging, Sterilizing, and Drying
1) Insert the motor into an FDA-approved sterilization pouch
that conforms to ISO 11607-1 (EN ISO 11607-1), and seal
the pouch.
2) Perform steam sterilization with the following conditions.
Type Gravity Displacement Dynamic Air Removal
Temperature 270°F (132°C) 270°F (132°C)
Full Cycle Time 15 min 4 min
Drying Time 30 min 30 min
CAUTION
• Use an FDA-approved steam sterilizer to perform
sterilization.
• Follow local rules, regulations, and guidelines regarding the
reprocessing of devices.
• Do not touch the product immediately after steam
sterilization as it will be very hot and must remain in a
sterile condition.
• Do not perform steam sterilization on the product with
other instruments even when it is in a pouch. This is to
prevent possible discoloration and damage to the product
from chemical residue on other instruments.
• Clean and lubricate the motor prior to sterilization. If blood
remains on the internal surface it can become clotted and
cause product failure.
• Do not heat or cool the product too quickly. Rapid change
in temperature could cause damage to the product.

13
CAUTION
• Be sure to use sterilizers that can perform sterilization no
higher than 275°F (135°C). In some sterilizers, the
chamber temperature may exceed 275°F (135°C). Do not
use these sterilizers as failure of the motor could occur.
Contact the sterilizer manufacturer for detailed information
about cycle temperatures.
• Steam sterilization is recommended for the product. The
validity of other sterilization methods (such as plasma
sterilization or EOG sterilization) is not confirmed.
7-5 Storage
Store the product in a dry, clean location.
CAUTION
• After the sterilization and drying cycles are complete,
remove the motor immediately from the sterilizer to store it.
• Store the product in a well ventilated place out of direct
sunlight and within the range of temperature, humidity and
pressure specified in “10. Specifications”.
• Sterilization is not guaranteed after the sterilization
retention period specified by the manufacturer and seller of
the sterilization pouch has elapse.
If the sterilization retention period has elapsed, perform
sterilization again with a new sterilization pouch.

14
8 Maintenance
If a deteriorated O-ring makes
it difficult to attach the
handpiece, replace the O-ring.
Using a needle or other pointed
tool, remove defective O-ring
from the motor insert section,
and fit new O-ring into the
O-ring groove. (Fig. 16)
Fig. 16
O-ring
54.0804.00
9 Periodical Maintenance Checks
Perform periodical maintenance checks every three months,
referring to the checklist below. If any abnormalities are found,
contact your Authorized A-dec Dealer.
Points to check Details
Rotation
Rotate the motor and check for
abnormalities such as abnormal rotation,
vibration, noise, and overheating.
Connection Check the connection between the motor
and the handpiece for any problems.

15
10 Specifications
Model 301
Hose Connection Type ISO 9168 (EN ISO 9168) Type 2 (Midwest 4 hole)
Handpiece Connection Type E Type ISO 3964 (EN ISO 3964)
Rotation Speed 19,800 - 24,200rpm (36psi (0.25MPa))
Breakdown Torque ≥1.5N·cm (36psi (0.25MPa))
Drive Air Pressure 29 - 36psi (0.20 - 0.25MPa)
Air Consumption <66NL/min (36psi (0.25MPa))
Use Environment Temperature: 50 - 95°F (10 - 35°C), Humidity: 30 - 75% (No Condensation)
Transportation and Store
Environment Temperature: 14 - 122°F (-10 - 50°C), Humidity: 10 - 85%, Pressure: 500 - 1,060hPa
NOTE Specifications are subject to change without notice. Requirements may vary depending on your location. For more
information, contact your authorized A-dec dealer.

16
11 Warranty
IMPORTANT For warranty, electrical specifications,
identification of symbols, and other regulatory
requirements, see the Regulatory Information, Specifications, and
Warranty document (p/n 86.0221.00), which is available in the
Resource Center at www.a-dec.com.
12 Symbol
State of being fixed.

17
13 Disposing product
To avoid the health risks of operators handling the disposal of
medical equipment, as well as the risks of environmental
contamination caused thereof, a surgeon or a dentist is required
to confirm the equipment is sterile. Ask specialist firms who are
licensed to dispose of specially controlled industrial wastes, to
dispose the product for you.

Manufactured for A-dec
2601 Crestview Drive Newberg, Oregon 97132 United States
Tel: [phone] within USA/CAN Tel: [phone] outside USA/CAN
www.a-dec.com
Issued Date: 2021
Specifications are subject to change without notice.
Copyright 2021 A-dec, inc. All rights reserved.
