Atheros Lite-On WN6603AH User manual

Atheros 802.11n
Adapter
Model AR5B97
802.11n Adapter
June. 2009

© 2000–2006 by Atheros Communications, Inc. All rights reserved.
A HEROS, the Atheros logo, 5-UP, Driving the Wireless Future, Atheros Driven, Atheros urbo
Mode, and the Air is Cleaner at 5-GHz are trademarks of Atheros Communications, Inc. All other
trademarks are the property of their respective holders.
Notice
he information in this document has been carefully reviewed and is believed to be accurate. Nonetheless,
this document is subject to change without notice, and Atheros Communications, Inc. (Atheros) assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment
to update or to keep current the contained information, or to notify a person or organization of any
updates. Atheros reserves the right to make changes, at any time, in order to improve reliability, function
or design and to attempt to supply the best product possible. Atheros does not represent that products
described herein are free from patent infringement or from any other third party right.
No part of this document may be reproduced, adapted or transmitted in any form or by any means,
electronic or mechanical, for any purpose, except as expressly set forth in a written agreement signed by
Atheros. Atheros or its affiliates may have patents or pending patent applications, trademarks, copyrights,
maskwork rights or other intellectual property rights that apply to the ideas, material and information
expressed herein. No license to such rights is provided except as expressly set forth in a written agreement
signed by Atheros.
A HEROS MAKES NO WARRAN IES OF ANY KIND WI H REGARD O HE CON EN OF HIS
DOCUMEN . IN NO EVEN SHALL A HEROS BE LIABLE FOR DIREC , INDIREC , SPECIAL,
INCIDEN AL SPECULA ORY OR CONSEQUEN IAL DAMAGES ARISING FROM HE USE OR
INABILI Y O USE HIS PRODUC OR DOCUMEN A ION, EVEN IF ADVISED OF HE POSSIBLI Y
OF SUCH DAMAGES. IN PAR ICULAR, A HEROS SHALL NO HAVE LIABILI Y FOR ANY
HARDWARE, SOF WARE, OR DA A RANSMI ED OR O HERWISE USED WI H HE PRODUC ,
INCLUDING HE COS S OF REPAIRING, REPLACING, IN EGRA ING, INS ALLING OR
RECOVERING SUCH HARDWARE, SOF WARE OR DA A. A HEROS SPECIFICALLY DISCLAIMS
HE IMPLIED WARRAN IES OF MERCHAN IBILI Y AND FI NESS FOR A PAR ICULAR PURPOSE
AS HEY MIGH O HERWISE APPLY O HIS DOCUMEN AND O HE IDEAS, MA ERIAL AND
INFORMA ION EXPRESSED HEREIN.

Atheros Communications, Inc. •iii
COMPANY CONFIDENTIAL Feb. 2009
Document Conventions
Text Conventions
bold Bold type within paragraph text indicates commands, file names,
directory names, paths, output, or returned values.
Example: he DK_Client package will not function unless you
use the wdreg_install batch file.
italic Within commands, italics indicate a variable that the user must
specify.
Example: mem_alloc size_in_bytes
itles of manuals or other published documents are also set in
italics.
Courier
he Courier font indicates output or display.
Example:
Error:Unable to allocate memory for transfer!
Menu he Menu character tag is used for menu items.
Example: Choose Edit > Copy.
[ ]
Within commands, items enclosed in square brackets are optional
parameters or values that the user can choose to specify or omit.
{ } Within commands, items enclosed in braces are options from
which the user must choose.
| Within commands, the vertical bar separates options.
… An ellipsis indicates a repetition of the preceding parameter.
> he right angle bracket separates successive menu selections.
Example: Start > Programs > DK > wdreg_install.
Notices
NOTE: This message denotes neutral or positive information that calls out
important points to the text. A note provides information that may apply only
in special cases.

iv • Atheros Communications, Inc.
Dec 2007 COMPANY CONFIDENTIAL
Revision History
Revision Description of Changes
Feb. 2009 Initial Release

Atheros Communications, Inc. •v
COMPANY CONFIDENTIAL Feb. 2009
Contents
Introduction.......................................................................................................... 7
System Requirements .................................................................................... 7
Profile Management............................................................................................. 7
Create or Modify a Configuration Profile .................................................... 7
Remove a Configuration Profile ................................................................... 8
Auto Profile Selection Management ................................................................... 8
Switching to a Different Configuration Profile .................................................. 9
Import and Export Profiles .................................................................................. 9
Importing a Profile ............................................................................................... 9
Exporting a Profile ............................................................................................... 9
CP/IP Configuration ......................................................................................... 9
Configuring the CP/IP Address for the network device: ............................... 9
General ab......................................................................................................... 10
Advanced ab..................................................................................................... 10
Security ab ........................................................................................................ 11
Using EAP- LS Security.............................................................................. 12
Using EAP- LS Security ........................................................................... 12
Using PEAP (EAP-G C) Security............................................................... 13
Using PEAP-MSCHAP V2 Security............................................................ 14
Using LEAP Security ................................................................................... 15
Configuring LEAP.............................................................................................. 15
Pre-Shared Encryption Keys.............................................................................. 16
Defining pre-shared encryption keys:............................................................... 16
Overwriting an Existing Static WEP Key.......................................................... 16
Disabling Static WEP.......................................................................................... 16
Using WPA Passphrase Security....................................................................... 17
Zero Configuration............................................................................................. 17
Wireless Network Configuration ...................................................................... 17
Check the Status Information or Diagnostics................................................... 18

vi • Atheros Communications, Inc.
Dec 2007 COMPANY CONFIDENTIAL
Current Status...............................................................................................18
Adapter Information Button ..............................................................................19
Diagnostics ab...................................................................................................19
ransmitted Frames............................................................................................20
Received Frames .................................................................................................20
Scan Available Networks ...................................................................................20
Connecting to a different network.....................................................................20
Display Settings ..................................................................................................22
ACU ools ...........................................................................................................22
ray Icon..............................................................................................................23
Color ....................................................................................................................24
Quality .................................................................................................................24
RSSI*.....................................................................................................................24
Ad Hoc Mode......................................................................................................24
Ad Hoc Mode Profile Configuration ..........................................................24
Infrastructure (Access Point) Mode...................................................................25
Infrastructure (Access Point) Mode Profile Configuration........................25
Uninstall an Old Driver......................................................................................26
Additional Security Features .............................................................................26
Message Integrity Check (MIC) .........................................................................26
Advanced Status Information............................................................................27
Compliance..........................................................................................................28
Industry Canada Notice: ................................................... 錯誤
錯誤錯誤
錯誤! 尚未定義書籤
尚未定義書籤尚未定義書籤
尚未定義書籤。
。。
。
Avis de Conformité à la Réglementation d’Industrie Canada:...錯誤
錯誤錯誤
錯誤! 尚未定義
尚未定義尚未定義
尚未定義
書籤
書籤書籤
書籤。
。。
。
European Community — CE Notice: ................................................................28

Atheros Communications, Inc. •7
COMPANY CONFIDENTIAL Feb. 2009
Introduction
he Atheros 802.11n Adapter supports 802.11bg operation. he card uses the Atheros
Client Utility (ACU) which is a user-mode utility designed to edit and add profiles for
selected Atheros network interface adapters.
System Requirements
Laptop/ PC containing:
32-bit PCI Express Bus
32 MB memory or greater
300 MHz processor or higher
Microsoft Windows 2000, Windows Millennium Edition, Windows 98 Second
Edition, Windows XP, or Windows N 4.0 (with Service Pack 6)
Profile Management
Configure the wireless network adapter (wireless card) from the Profile Management tab
of the Atheros Client Utility.
Add a profile
Edit a profile
Import a Profile
Export a Profile
Order profiles
Switch to a different profile
Remove a profile
Connect to a Different
Network
he wireless network adapter works in either infrastructure mode (which uses an access
point) or ad hoc mode (a group of stations participating in the wireless LAN).
Create or Modify a Configuration Profile
o add a new configuration profile, click New on the Profile Management tab. o modify
a configuration profile, select the configuration from the Profile list and click the Modify
button.
he Profile Management dialog box displays the General tab. In profile management:
Edit the General tab.
Edit the Security tab.
Edit the Advanced tab.
o configure a profile for ad hoc or access point (infrastructure) mode, edit the Network
ype field on the Advanced tab.
Note that the ACU only allows the creation of 16 configuration profiles. After the
creation of 16 profiles, clicking the New button displays an error message. Remove an
old profile or modify an existing profile for a new use.

8 • Atheros Communications, Inc.
COMPANY CONFIDENTIAL
Remove a Configuration Profile
1. Go to the Profile Management tab.
2. Select the profile to remove from the list of configuration profiles.
3. Click the Remove button.
Auto Profile Selection Management
Including a profile in the auto selection feature allows the wireless adapter to
automatically select that profile from the list of profiles and use it to connect to the
network.
Including a profile in auto profile selection:
1. On the Profile Management tab, click the Order Profiles button.
2. he Auto Profile Selection Management window appears, with a list of all created
profiles in the Available Profiles box.
3. Highlight the profiles to add to auto profile selection, then click Add. he profiles
appear in the Auto Selected Profiles box.
Ordering the auto selected profiles:
1. Highlight a profile in the Auto Selected Profiles box.
2. Click Move Up, Move Down, or Remove as appropriate. he first profile in the Auto
Selected Profiles box has highest priority, and the last profile has lowest priority.
3. Click OK.
4. Check the Auto Select Profiles box.
5. Save the modified configuration file.
When auto profile selection is enabled by checking Auto Select Profiles on the Profile
Management tab, the adapter scans for an available network. he profile with the
highest priority and the same SSID as one of the found networks is the one that is used
to connect to the network. If the connection fails, the adapter tries the next highest
priority profile that matches the SSID, and so on.
With auto profile selection enabled, the wireless adapter scans for available networks.
he highest priority profile with the same SSID as a found network is used to connect to
the network. On a failed connection, the adapter tries with the next highest priority
profile.

Atheros Communications, Inc. •9
COMPANY CONFIDENTIAL Feb. 2009
Switching to a Different Configuration Profile
1. o switch to a different profile, go to the Profile Management tab.
2. Click on the profile name in the Profile List.
3. Click the Activate button.
he Profile List provides icons that specify the operational state for that profile. he list
also provides icons that specify the signal strength for that profile.
Import and Export Profiles
Importing a Profile
1. From the Profile Management tab, click the Import button. he Import Profile
window appears.
2. Browse to the directory where the profile is located.
3. Highlight the profile name.
4. Click Open. he imported profile appears in the profiles list.
Exporting a Profile
1. From the Profile Management tab, highlight the profile to export.
2. Click the Export button. he Export Profile window appears.
3. Browse to the directory to export the profile to.
4. Click Save. he profile is exported to the specified location.
TCP/IP Configuration
Configuring the TCP/IP Address for the network device:
1. After configuring the wireless network adapter properties, open the Control Panel and
open Network and Dial-up Connections.
2. Find the Local Area Connection associated with the wireless network adapter. Right-
click that connection, and click Properties.
3. Select Internet Protocol ( CP/IP) and click Properties.
4. Click the radio button Use the following IP address, then enter an IP address and Subnet
mask. Assigning an IP address and Subnet mask allows stations to operate in access
point mode (infrastructure mode) or in ad hoc mode and to have Internet access. Default
gateway and DNS server information is also required. IP configuration information
(DHCP to assign the IP address, gateway and DNS server IP addresses) is usually
obtained from the corporate I staff.
5. Click OK to finish.

10 • Atheros Communications, Inc.
COMPANY CONFIDENTIAL
General Tab
In the Atheros Client Utility, access the General tab by clicking New or Modify on the
Profile Management tab. Edit the fields in the General tab to configure the configuration
profile. Make sure to also edit the Security and Advanced tabs.
Profile Name
Identifies the configuration profile. his name must be
unique. Profile names are not case sensitive.
Client Name
Identifies the client machine.
Network Names (SSIDs)
he IEEE 802.11 wireless network name. his field has a
maximum limit of 32 characters.
Configure up to three SSIDs (SSID1, SSID2, and SSID3).
Advanced Tab
In the Atheros Client Utility, access the Advanced tab by clicking New or Modify on the
Profile Management tab, then clicking the Advanced tab in Profile Management. Edit
the fields in the Advanced tab of Profile Management to configure the profile.
Transmit
Power Level
Selects the transmit power level in mW. Actual transmit power may be
limited by hardware.
Power Save
Mode
Specify:
Maximum mode causes the access point to buffer incoming messages
for the wireless adapter. he adapter periodically polls the access
point to see if any messages are waiting.
Normal uses maximum when retrieving a large number of packets,
then switches back to power save mode after retrieving the packets.
Off turns power saving off, thus powering up the wireless adapter
continuously for a short message response time.
Network Type
Specifies the network as either infrastructure or ad hoc.
802.11b
Preamble
Specifies the preamble setting in 802.11b. he default setting is Short &
Long (access point mode), which allows both short and long headers in
the 802.11b frames. he adapter can only use short radio headers if the
access point supports and uses them. Set to Long Only to override
allowing short frames.
Authentication
Mode
Select the mode the wireless adapter uses to authenticate to an AP:
Auto causes the adapter to attempt authentication using shared, but
switches it to open authentication if shared fails.
Open enables an adapter to attempt authentication regardless of its
WEP settings. It will only associate with the access point if the WEP
keys on both the adapter and the access point match.
Shared only allows the adapter to associate with access points that
have the same WEP key.

Atheros Communications, Inc. •11
COMPANY CONFIDENTIAL Feb. 2009
For infrastructure (access point) networks, click the Preferred APs button to specify up to
four access points to which the adapter should attempt to associate.
Security Tab
In the Atheros Client Utility, access the Security tab by clicking New or Modify on the
Profile Management tab. Click the Security tab in the Profile Management window.
Edit the fields in the Security tab of Profile Management to configure the profile. o
define the security mode, select the radio button of the desired security mode. Make sure
to also edit the General and Advanced tabs.
WPA/WPA2
Enables the use of Wi-Fi Protected Access (WPA).
Choosing WPA/WPA2 opens the WPA/WPA2 EAP drop-down
menu. he options include:
EAP-FAS
EAP- LS
EAP- LS
PEAP (EAP-G C)
PEAP (EAP-MSCHAP V2)
LEAP
WPA/WPA2
Passphrase
Enables WPA/WPA2 Passphrase security. Click on the Configure
button and fill in the WPA/WPA2 Passphrase.
802.1x
Enables 802.1x security. his option requires I administration.
Choosing 802.1x opens the 802.1x EAP type drop-down menu. he
options include:
EAP-FAS
EAP- LS
EAP- LS
PEAP (EAP-G C)
PEAP (EAP-MSCHAP V2)
LEAP
If the access point that the wireless adapter is associating to has
WEP set to Optional and the client has WEP enabled, make sure that
Allow Association to Mixed Cells is checked on the Security ab to
allow association. Note: If the Lock checkbox is checked, you cannot
change any values in this profile. See your system administrator.
Pre-Shared Key
(Static WEP)
Enables the use of pre-shared keys that are defined on both the
access point and the station.
o define pre-shared encryption keys, choose the Pre-Shared Key
radio button and click the Configure button to fill in the Define Pre-
Shared Keys window.
If the access point that the wireless adapter is associating to has
WEP set to Optional and the client has WEP enabled, make sure that
Allow Association to Mixed Cells is checked on the Security ab to

12 • Atheros Communications, Inc.
COMPANY CONFIDENTIAL
allow association.
None
No security (not recommended).
Using EAP-TLS Security
o use EAP- LS security In the Atheros Client Utility, access the Security tab in the
Profile Management window.
1. On the Security tab, choose the WPA radio button.
OR: On the Security tab, choose the 802.1x radio button.
2. Choose EAP- LS from the drop-down menu.
Enabling EAP-TLS security:
o use EAP- LS security, the machine must already have the EAP- LS certificates
downloaded onto it. Check with the I manager.
1. If EAP- LS is supported, choose EAP- LS from the drop-down menu on the right,
then click the Configure button.
2. Select the appropriate certificate authority from the list. he server/domain name
and the login name are filled in automatically from the certificate information. Click
OK.
3. Click OK.
4. Activate the profile.
Using EAP-TTLS Security
o use EAP security In the Atheros Client Utility, access the Security tab in the Profile
Management window.
1. On the Security tab, choose the WPA/WPA2 radio button.
OR: On the Security tab, choose the 802.1x radio button.
2. Choose EAP- LS from the drop-down menu.
Enabling EAP-TTLS security:
o use EAP- LS security, the machine must already have the EAP- LS certificates
downloaded onto it. Check with the I manager.
1. If EAP- LS is supported, choose EAP- LS from the drop-down menu on the right,
then click the Configure button.
2. Select the appropriate certificate from the drop-down list and click OK.
3. Specify a user name for EAP authentication:
Check Use Windows User Name to use the Windows user name as the EAP user
name.
OR: Enter an EAP user name in the User Name field to use a separate user name
and password and start the EAP authentication process.
4. Click Advanced and:
Leave the server name field blank for the client to accept a certificate from any
server with a certificate signed by the authority listed in the Network Certificate
Authority drop-down list. (recommended)

Atheros Communications, Inc. •13
COMPANY CONFIDENTIAL Feb. 2009
Enter the domain name of the server from which the client will accept a
certificate.
Change the login name if needed.
5. Click OK.
6. Enable the profile.
Using PEAP (EAP-GTC) Security
o use PEAP (EAP-G C) security In the Atheros Client Utility, access the Security tab in
the Profile Management window.
1. On the Security tab, choose the WPA radio button.
OR: On the Security tab, choose the 802.1x radio button.
2. Choose PEAP (EAP-G C) from the drop-down menu.
To use PEAP (EAP-GTC) security, the server must have WPA-PEAP certificates, and the
server properties must already be set. Check with the I manager.
1. Click the Configure button.
2. o avoid the need to log on again after resuming operation (for example, after your
computer goes into standby or hibernate mode), check Always Resume the Secure
Session.
3. Select the appropriate network certificate authority from the drop-down list.
4. Specify a user name for inner PEAP tunnel authentication:
Check Use Windows User Name to use the Windows user name as the PEAP
user name.
OR: Enter a PEAP user name in the User Name field to use a separate user name
and start the PEAP authentication process.
5. Choose oken or Static Password, depending on the user database.
Note that oken uses a hardware token device or the Secure Computing Sof oken
program (version 1.3 or later) to obtain and enter a one-time password during
authentication.
6. Click Settings... and:
Leave the server name field blank for the client to accept a certificate from any
server with a certificate signed by the authority listed in the Network Certificate
Authority drop-down list. (recommended)
Enter the domain name of the server from which the client will accept a
certificate.
he login name used for PEAP tunnel authentication fills in automatically as
PEAP-xxxxxxxxxxxx, where xxxxxxxxxxxx is the computer's MAC
address. Change the login name if needed.
7. Click OK.
8. Enable the profile.

14 • Atheros Communications, Inc.
COMPANY CONFIDENTIAL
Using PEAP-MSCHAP V2 Security
o use PEAP-MSCHAP V2 security In the Atheros Client Utility, access the Security tab
in the Profile Management window.
1. On the Security tab, choose the WPA radio button.
OR: On the Security tab, choose the 802.1x radio button.
2. Choose PEAP (EAP-MSCHAP V2) from the drop-down menu.
To use PEAP (EAP-MSC AP V2) security, the server must have WPA-PEAP certificates,
and the server properties must already be set. Check with the I manager.
1. Click the Configure button.
2. Select the appropriate certificate from the drop-down list.
3. Specify a user name for inner PEAP tunnel authentication:
Check Use Windows User Name to use the Windows user name as the PEAP
user name.
OR: Enter a PEAP user name in the User Name field to use a separate user name
and start the PEAP authentication process.
4. Click Advanced and:
Leave the server name field blank for the client to accept a certificate from any
server with a certificate signed by the authority listed in the Network Certificate
Authority drop-down list. (recommended)
Enter the domain name of the server from which the client will accept a
certificate.
he login name used for PEAP tunnel authentication fills in automatically as
PEAP-xxxxxxxxxxxx, where xxxxxxxxxxxx is the computer's MAC
address. Change the login name if needed.
5. Click OK.
6. Enable the profile.

Atheros Communications, Inc. •15
COMPANY CONFIDENTIAL Feb. 2009
Using LEAP Security
o use security In the Atheros Client Utility, access the Security tab in the Profile
Management window. LEAP security requires that all infrastructure devices (e.g. access
points and servers) are configured for LEAP authentication. Check with the I manager.
Configuring LEAP
On the Security tab, choose the WPA radio button. Choose WPA-LEAP from the
drop-down menu.
OR: On the Security tab, choose the 802.1x radio button. Choose LEAP from the
drop-down menu.
1. Click the Configure button.
2. Specify a user name and password. Select to Use emporary User Name and
Password by choosing the radio button:
Check Use Windows User Name to use the Windows user name as the LEAP
user name.
OR: Check Manually Prompt for LEAP User Name and Password to
manually login and start the LEAP authentication process.
Select to Use Saved User Name and Password by choosing the radio button:
Specify the LEAP user name, password, and domain to save and use.
3. Enter the user name and password.
4. Confirm the password.
5. Specify a domain name:
Check the Include Windows Logon Domain with User Name setting to pass
the Windows login domain and user name to the RADIUS server. (default)
OR: Enter a specific domain name.
6. If desired, check No Network Connection Unless User Is Logged In to force the
wireless adapter to disassociate after logging off.
7. Enter the LEAP authentication timeout time (between 30 and 500 seconds) to
specify how long LEAP should wait before declaring authentication failed, and
sending an error message. he default is 90 seconds.
8. Click OK.
9. Enable the profile.

16 • Atheros Communications, Inc.
COMPANY CONFIDENTIAL
Pre-Shared Encryption Keys
Defining pre-shared encryption keys:
1. Click the Pre-Shared Key (Static WEP) radio button on the Security tab.
2. Click the Configure button.
3. Fill in the fields in the Define Pre-Shared Keys dialog box:
Key Entry
Determines the entry method for an encryption key: hexadecimal (0-9,
A-F), or ASCII text (all keyboard characters except spaces).
Encryption
Keys
Selects the default encryption keys used. Only allows the selection for
a shared First, Second, hird, or Fourth key whose corresponding
field has been completed.
WEP Keys
(1-4)
Defines a set of shared encryption keys for network configuration
security. At least one Shared Key field must be populated to enable
security using a shared key.
Click on the radio button to set the key as the default encryption key.
WEP Key
Size
Defines the size for each encryption key. he options include:
64-bit (enter 10 digits for hexadecimal, 5 ASCII characters)
128-bit (enter 26 digits for hexadecimal, 13 digits for ASCII)
152-bit (enter 32 digits hexadecimal, 16 digits for ASCII)
4. Click OK for the changes to take effect.
Overwriting an Existing Static WEP Key
1. Click the Pre-Shared Key radio button on the Security tab.
2. Click on Configure.
3. In the window, all existing static WEP keys are displayed as asterisks for security
reasons. Click in the field of the existing static WEP key to overwrite.
4. Delete the asterisks in that field.
5. Enter a new key.
6. Make sure to select the ransmit Key button to the left of this key is selected for the
key to transmit packets.
7. Click OK.
Disabling Static WEP
o disable static WEP for a particular profile, Select any other security option on the
Profile Management tab to automatically disable static WEP
OR: choose None on the Security tab to disable security, and click OK (not
recommended).

Atheros Communications, Inc. •17
COMPANY CONFIDENTIAL Feb. 2009
Using WPA Passphrase Security
o use WPA Passphrase security In the Atheros Client Utility, access the Security tab in
the Profile Management window.
1. On the Security tab, choose the WPA Passphrase radio button.
2. Click on the Configure button.
3. Fill in the WPA Passphrase.
4. Click OK.
Zero Configuration
his section describes the operation of the Atheros Client Utility (ACU) and Windows
XP Wireless Configuration Service (WZCS).
Wireless Network Configuration
he Windows WZCS is a service that manages the wireless connection in a largely
dynamic way. Only minimal connection information must be identified and configured.
o set Zero Configuration on Windows XP, take the following steps:
1. In Windows XP, open the Wireless Network Configuration Properties dialog box.
2. Select the check box “Use Windows to configure my wireless network settings” to set
Zero Configuration.
When this check box is selected, Windows XP takes control of these settings for all
configuration profiles:
SSID
Security keys
Ad hoc settings
Note that Windows XP takes control of these settings for all configuration profiles, thus users can
not ( create new profiles with different settings while using Windows Zero onfiguration.
he Zero Configuration settings override all configuration profiles, even when you select
other options. However, the ACU does still control the following settings when Zero
Configuration is set:
Power settings
Active/Passive scanning (where applicable)
ransmit power
Wireless band
Short/Long preamble (802.11b)
When Zero Configuration is in use, a pop-up message is displayed on the ACU when
you attempt to create or edit a configuration profile from the Profile Management tab of
the ACU.

18 • Atheros Communications, Inc.
COMPANY CONFIDENTIAL
o turn Zero Configuration off on Windows XP, take the following steps:
1. In Windows XP, open the Wireless Network Configuration Properties dialog box.
2. Clear the check box “Use Windows to configure my wireless network settings” to set
Zero Configuration. When this check box is cleared, all profile settings are controlled
by the configuration profile, which is set up from the ACU Profile Management tab.
Check the Status Information or Diagnostics
he Atheros client utility includes a number of tools to display current diagnostics and
status information.
Check current status
Check driver information
Check receive and transmit diagnostics
Current Status
he Current Status tab contains general information about the program and its
operations. he Current Status tab does not require any configuration. he following
table describes the items found on the Current Status screen.
Profile Name
he name of the current selected configuration profile. Set up the
configuration name on the General tab.
Link Status
Shows whether the station is associated to the wireless network.
Wireless Mode
Displays the wireless mode. Configure the wireless mode on the
Advanced tab.
IP Address
Displays the computer's IP address.
Network Type
he type of network the station is connected to. Options include:
Infrastructure (access point)
Ad Hoc
Configure the network type on the Advanced tab.
Current Channel
Shows the currently connected channel.
Server Based
Authentication
Shows whether server based authentication is used.
Data Encryption
Displays the encryption type the driver is using. Configure the
encryption type on the Security tab.
Signal Strength
Shows the strength of the signal.
Click the Advanced button to see the advanced status diagnostics.

Atheros Communications, Inc. •19
COMPANY CONFIDENTIAL Feb. 2009
Adapter Information Button
he Adapter Information button contains general information about the network
interface card (the wireless network adapter) and the network driver interface
specification (NDIS) driver. Access the adapter information from the Diagnostics tab.
Card Name
Name of the wireless network adapter.
MAC Address
MAC address of the wireless network adapter.
Driver
Driver name and path of the wireless network adapter driver.
Driver Version
Version of the wireless network adapter driver.
Driver Date
Creation date of the wireless network adapter driver.
Client Name
Name of the client computer.
Diagnostics Tab
he ACU Diagnostics tab provides allows retrieval of receive and transmit statistics. he
Diagnostics tab does not require any configuration. It lists these receive and transmit
diagnostics for frames received by or transmitted by the wireless network adapter:
Multicast packets transmitted and received
Broadcast packets transmitted and received
Unicast packets transmitted and received
otal bytes transmitted and received
he Adapter Information button has general information about the wireless network
adapter and NDIS driver. he Advanced Statistics button to shows statistics for
diagnostics for frames received by or transmitted to the wireless network adapter:

20 • Atheros Communications, Inc.
COMPANY CONFIDENTIAL
Transmitted Frames
Frames transmitted
OK
Frames retried
Frames dropped
No ACK frames
ACK frames
R S frames
Clear-to-send (C S)
frames
No C S frames
Retried R S frames
Retried data frames
Received Frames
Frames received OK
Beacons
Frames with errors
CRC errors
Encryption errors
Duplicate frames
AP mismatches
Data rate mismatches
Authentication time-out
Authentication rejects: the number of AP authentication
failures received by the wireless network adapter
Association time-out
Association rejects: the number of AP authentication rejects
received by the wireless network adapter
Standard MIC OK
Standard MIC errors
CKIP MIC OK
CKIP MIC errors
Scan Available Networks
Scan Available NetworksScan Available Networks
Scan Available Networks
Click the Scan button on the Profile Management tab to scan for available infrastructure
and ad hoc networks. On this list, click Refresh to refresh the list at any time.
Connecting to a different network
Highlight a network name and click the Activate button to connect an available
network. If no configuration profile exists for that network, the Profile Management
window opens to the General tab. Fill in the profile name and click OK to create the
configuration profile for that network.
Infrastructure
(AP) Network
Connected
Infrastructure
(AP) Network
