Atlas ATS100 Series Operator's manual

1/2
AtlasSound.com
TELEPHONE: [phone]
FAX [phone]
©2009 Atlas Sound L.P. All rights reserved. Atlas Sound is a trademark of Atlas Sound L.P. All other trademarks are the property of their respective owners. All specs are subject to change without notice. ATS002960 RevC 1/09
ATS100 Series
Garden Speakers
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
Key Features
• DownwardFiringSpeakerWillNotCollectDustorCondensation
• RuggedConstructionCanSupportUpTo250lbs
• EasyBayonetAttachmentofHeadUnitToBase,EnablesInstallation
ofBaseDuringExcavationandInstallationofHeadUnitAfter
LandscapingHasBeenCompleted
• Availablein70.7Vor8ΩVersions
• EasyConduitInstallationinLargeandSmallBaseWithDedicated
MountingPads
• SpeakerProtectedByTripleLayerGrille
• SmallBase(ATS100GS)hasDrillPointsfor4"Square,2-GangEO
Box,or1-GangBoxMountingtoaDeckorSlab
ATS100 Series Instructions
To Install Large Base:
1. Makesureyouhaveapathtoburywireconnectedtospeaker.
2. Digahole8"deepx30"diameter.
3. Runwiretohole.
4. Attachconduitorglandnuttoflatsonbase.
5. Bringinwireandleavesufficientcableforadequateserviceloop
(minimum18")toreachheadunit.
6. Fillbasewithcleandirtorsandtowithin2"-3"oftopforoptimum
bassperformance.
7. Coverwithprovidedtemporarylidandattachwithprovided
1"screwsifheadunitisnottobeattachedimmediately.
8. Backfilldirttobase.Topofbaseshouldbe2"–3"aboveground.
To Install Small Base:
If Using an EO Box:
1. Install1-Gang,2-Gang,or4"x4"boxflushtomountingsurface.
2. Cutoutscribedlineonbottomofbasefor1-or2-gangbox.
3. Drillappropriateholesinbase(outer4holesfor4"x4",inner4for
2-gang,or1setof2innerfor1-gang).
4. Installwiringinbox.
5. Setbaseonboxandattachwithscrews.
If Using Conduit:
1. Mountbasetosurfacewithappropriatescrewsthroughthebase
bottom.
2. Attachconduitandbringinwire.Provideforsurfaceloop(minimum
18").
3. Coverwithprovidedtemporarylidandattachwithprovided1"
screwsifheadunitisnottobeattachedimmediately.
Large Base
Small Base
Head Unit

2/2
AtlasSound.com
TELEPHONE: [phone]
FAX [phone]
©2009 Atlas Sound L.P. All rights reserved. Atlas Sound is a trademark of Atlas Sound L.P. All other trademarks are the property of their respective owners. All specs are subject to change without notice. ATS002960 RevC 1/09
ATS100 Series
Garden Speakers
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
To Install Head Unit on Base:
1. Removetemporarycover,ifpresent.Retainscrews.
2. 70.7V Version:Attachthepurplewirefromtheheadunitto
thepositiveinputwireandtheblacktothenegative.
8 ΩVersion:Attachthebrownwirefromtheheadunitto
thepositiveinputwireandthegreentothenegative.
3. Lineupthe3“feet”ontheheadunitwiththeholesinthebase.
4. Pushtheheadunitdownintotheholesandturnclockwisetolock
theheadunitinplace.
5. Puta1"Phillips-headscrew(suppliedwiththebase)throughthelock-
ingscrewaccessholetosecureandpreventremovalbyunauthor-
izedpersons.
6. Putstick-onlogocoveroveraccesshole.(SeeFigure1)
7. Selecttransformertapwattage(70.7VVersionOnly)usingadimeor
smallscrewdrivertoadjuststeppedswitch.(Switchislocatedonthe
undersideofthe“domed”sectionoftheheadunitnearouteredge.)
Insertredweatherprotection“plug”intorecessedswitchcavity
usingthumbtopressthecapintoplace.(SeeFigure2)
ATS100 SERIES Specifications
FrequencyResponse 43Hz–20kHz(±7dB)
Sensitivity(1W/1M) 89.5dB(HalfSpaceReference)
PowerHandling 70WattsRMS
HorizontalDispersion 360°
Speaker Coaxial8",Polypropylene/KevlarConewith
RubberSurround,
1⁄2"MylarDomeTweeter,
11⁄2"VoiceCoil,21ozMagnet
Transformer (70.7VVersionOnly)8,16,&32Watts,with
anExternalSwitch
Dimensions
LargeBaseWidth 175⁄8"(448mm)
LargeBaseLength 175⁄8"(448mm)
LargeBaseHeight 207⁄8"(531mm)
SmallBaseDiameter 151⁄8"(384mm)
SmallBaseHeight 131⁄8"(334mm)
HeadUnitWeight 13.2lbs(5.99Kg)
SmallBaseWeight 2.4lbs(1.09Kg)
LargeBaseWeight 6.4lbs(2.9Kg)
Head Unit
Figure 1
Figure 2
