Atlona AT-HDF30SR User manual

AtlonA
Miniature Multimode Fiber Optic HDMI
Extension Kit
AT-HDF30SR
User Manual

TABLE OF CONTENTS
1. Introduction .................................................. 1
2. Features .................................................. 1
3. Specication .................................................. 2
4. Package Contents .................................................. 2
5. Operation .................................................. 3
6. Audio .................................................. 3
7. Serial Data .................................................. 3
8. RS-422 Serial Data .................................................. 3
9. Connection Diagram .................................................. 4
10. Safety Information .................................................. 5
11. Warranty .................................................. 6
12. Atlona Product Registration .................................................. 7

INTRODUCTION
1
Atlona Technologies’ new AT-HDF30S (Transmitter) and AT-HDF30R ( Receiver ) units are low cost, Fi-
ber Optic HDMI baluns. This extremely small and high performance solution will carry HDMI audio/video
signal, bi-directional stereo audio and 2 channels of RS-232 through one multimode ber. This Mini-HDMI
ber optic transmitter allows any HD video source to extend signal up to 400m at WUXGA (1920x1200 @
60Hz) and supports HDTV resolution up 1080p. Multiple signals can run through a single conduit without
crosstalk or interference . Along with being HDCP compliant, this unit is capable of transmitting DVI video
signal with an Atlona DVI-to-HDMI adapter.
Atlona’s AT-HDF30SR is equipped with advanced digital ber optic technology allowing for self adjust-
ment with no com¬pression, bit reduction, or signal degradation. These units support 12-bit color depth
and have an 8dB input equalizer, which compensates losses over 5m (16ft). With this self-adjustment and
no power cord needed, quick and easy set up is as simple as plug and play.
The AT-HDF30S is compatible with other Atlona products including the AT-DVIF30R and AT-RGBF30R
(for non HDCP signal only ). Using one of these units on the receiver end will not only transmit signal, but
also convert from HDMI-to-RGB/YPbPr/DVI in a single setup. This extension kit is the perfect solution for
Video Wall Presentations and all Digital Signage applications due to its long range, conversion ability, and
lossless signal transmission.
• HDMI v1.3 Compliant
• Supported signals:
Digital Audio Video
Bi-Directional Stereo Audio
Channel RS232
• Supported resolutions at 400M ( 1320FT )
PC : 1920x1200 (60Hz)
HDTV: 1080p/1080i/720p
• Supports HDCP/DDC Content
• No loses, no degradations, no crosstalk
• One Multimode ( SC type ) Fiber
• 12-bit color depth and 8dB equalizer
• MAC/PC compatible
• High secure signal transfer
• Compatible with AT-DVIF30R and AT-RGBF30R
FEATURES:

SPECIFICATIONS:
Video
Resolution Up to 1080p@60Hz or
1920x1200@60Hz
Connector HDMI Female Plug
Protocol HDCP/DDC Capable
Audio
Channel Capacity 2
Operating Mode Unbalanced (Stereo Audio),
Bi-directional
Input/Output Impedance 10k/50 Ohms (Stereo Audio)
Max. Input/Output Level 5 dBu/4Vpp (Stereo Audio)
Magnitude Freq. Re-
sponse
20Hz to 20kHz @ -3dB
THD+N >70 @ 1k Hz (Stereo Audio)
Connector Terminal Block
Optical
Fiber Type Multimode
Number of Fibers 1
Connector SC
Serial Data
Channel Capacity 2
Signal Format RS-232
Data Rate Up to 57.6kbaud
Connector Terminal Block
Physical
Dimension (H x W x D) 0.75” x 2.75” x 3.0”
Power Level (max.) +5VDC @ 1.0A
Operating Temperature 0 to +50oC
Humidity 0 to 95% RH, non-condensing
• AT-HDF30S x 1
(Units Sold Separately)
• AT-HDF30R x 1
• Operation Manual x 1
2
PACKAGE CONTENTS:

2 3
1. Make sure, if plugged into a source, the power is off before proceeding with the ber optic installation.
2. Connect (SC type) Multimode ber from Sender unit to Receiver by connecting one unit’s ber optical
port to the others.
3. Connect the AT-HDF30SR (Transmitter) HDMI video input to the HDMI video source.
4. Next, connect the AT-HDF30SR (Receiver) HDMI video output directly to the HDMI video receiver
using proper HDMI cable.
Atlona’s AT-HDF30SR audio interface supports two channel high delity transmissions. Two separate
mono channels or one stereo channel can be transmitted in each direction while the Line-level audio
signals remain connected to the units.
When SENDING the audio signal, connect two cables to the “AUDIO OUTPUT” connectors of the line-
level source. On the HDF30SR, connect the other end of the cables to the front panel terminal block
connectors labeled “AUDIO IN”. For stereo channels, be sure to match the cables at both ends (L to L,
R to R).
When RECEIVING the audio signal, label and connect two twisted-pair cables to the “AUDIO INPUT”
connectors of the line level audio receiver. On the AT-HDF30SR, connect the other end of the cables to
the front panel terminal connectors labeled “AUDIO OUT”. If using stereo channels, be sure to match
the cables at both ends (L to L, R to R).
Atlona’s AT-HDF30SR units can be used for RS-232 interface as well as transmits two channels of un-
balanced data signals
1. Connect one serial computer data cable to the the RS-232 device.
2. Next, Connect the other end of cable to the front panel data terminal connector on the
AT-HDF30SR.
Atlona’s AT-HDF30SR units transmit a single channel of differential data signals which are compatible
with RS-422 electrical signals
1. Connect one data cable to the RS-422 device.
2. Next, connect the other end of this cable to the front panel RS-422 terminal connector on the
AT-HDF30SR.
OPERATION:
AUDIO:
SERIAL DATA:
RS-422 SERIAL DATA:

4
CONNECTION DIAGRAM
RS-232 (2)
Stereo Audio
HDMI Source
HDMI Cable
AT-HDF30S
Fiber Cable
RS-232 (2)
Stereo Audio
AT-HDF30R
HDMI Cable
HDMI Display
RS-232 (2)
Stereo Audio
AT-DVIF30R
DVI Cable
DVI Monitor
... or
Stereo Audio
AT-RGBF30R
VGA or YPbPr
Display
RS-232 (2)
... or

5
SAFETY INFORMATION
Safeguards
To reduce the risk of electric shock, do not
expose this product to rain or moisture.
If the wall plug does not t into your local
power socket, hire an electrician to replace
your obsolete socket.
Do not modify the wall plug.
Doing so will void the warranty and safety
features.
This equipment should be installed near
the socket outlet and the device should
be easily accessible in case it requires
disconnection.
Precautions
FCC Regulations state that any
unauthorized changes or modications to
this equipment not expressly approved by
the manufacturer could void the
user’s authority to operate this
equipment.
Operate this product using only the
included external power supply. Use of
other power supplies could impair
performance, damage the product or cause
res.
In the event of an electrostatic discharge,
this device may automatically turn off. If this
occurs, unplug the device, and plug it back
in.
Protect and route power cords so they will
not be stepped on or pinched by anything
placed on or against them. Be especially
careful of plug-ins, or cord exit points from
this product.
Avoid excessive humidity, sudden
temperature changes or temperature
extremes.
Keep this product away from wet locations
such as bathtubs, sinks, laundries, wet
basements and swimming pools.
Use only accessories recommended by
ATLONA to avoid re, shock or other
hazards.
Unplug the product before cleaning. Use
a damp cloth for cleaning. Do not use
cleaning uid or aerosols, which could
enter the unit and cause damage, re or
electrical shock. Some substances may
also mar the nish of the product.
Never open or remove unit panels or make
any adjustments not described in this
manual. Attempting to do so could expose
you to dangerous electrical shock or other
hazards. It may also cause damage to your
AT-HDF30SR. Opening the product will void
the warranty.
Do not attempt to service the unit. Instead
disconnect it and contact your Authorized
ATLONA reseller or contact ATLONA
directly.
4

6
WARRANTY
1. LIMITED WARRANTY
Atlona Technologies warrants that (a) its products (the “Product”) will perform substantially in accordance with the
accompanying written materials for a period of 3 YEARS from the date of receipt and (b) that the Product will be
free from defects in materials and workmanship under normal use and service for a period of 3 years. In the event
applicable law imposes any implied warranties, the implied warranty period is limited to 3 years from the date of
receipt. Some jurisdictions do not allow such limitations on duration of an implied warranty, so the above limitation
may not apply to Customer.
2. CUSTOMER REMEDIES
Atlona Technologies and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technolo-
gies’ option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet
this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. This Limited
Warranty is void if failure of the Product has resulted from accident, abuse, or misapplication. Any replacement Prod-
uct will be warranted for the remainder of the original warranty period or 3 year, whichever is longer.
3. NO OTHER WARRANTIES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, ATLONA TECHNOLOGIES AND ITS SUPPLI-
ERS DISCLAIM ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, WITH
REGARD TO THE PRODUCT AND ANY RELATED WRITTEN MATERIALS. THIS LIMITED WARRANTY GIVES
CUSTOMER SPECIFIC LEGAL RIGHTS. CUSTOMER MAY HAVE OTHER RIGHTS DEPENDING ON THE JU-
RISDICTION.
4. NO LIABILITY FOR DAMAGES
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL ATLONA TECHNOLO-
GIES OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING WITHOUT LIMITA-
TION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES FOR PERSONAL INJURY, LOSS
OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, OR ANY OTHER
PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO USE THIS PRODUCT, EVEN IF ATLONA
TECHNOLOGIES HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN ANY CASE, ATLONA
TECHNOLOGIES’ AND ITS SUPPLIERS’ ENTIRE LIABILITY UNDER ANY PROVISION OF THIS AGREEMENT
SHALL BE LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU FOR THE PRODUCT. BECAUSE SOME JU-
RISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR
INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.
ATLONA
2151 O’toole Ave, Ste D
San Jose CA 95131
Toll Free: 1-877-536-3976
International: 408-954-8782
FAX: [phone]
Website: www.atlona.com
E-MAIL: [email protected]

6 7
ATLONA PRODUCT REGISTRATION
Thank you for purchasing this Atlona product — we hope you’ll enjoy it.
We also hope that you’ll take a few moments to register your new purchase. Registration creates an ownership
record if your product is lost or stolen and helps ensure you’ll receive notication of performance issues and rm-
ware updates.
At Atlona, we respect and protect your privacy and assure you that your registration information is completely
secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited
warranty rights.
To register go to www.atlona.com/registration
