Atmel AT85RFD-07 User manual

AT85RFD-07 Getting Started
..............................................................................................
User Guide

AT85RFD-07 Getting Started User Guide 1
7712–MP3–02/07
Table of Contents
Section 1
Introduction ........................................................................................... 1-1
1.1 Atmel Registration.....................................................................................1-1
Section 2
Package Download............................................................................... 2-3
2.1 Web Site download ...................................................................................2-3
2.2 Nand Flash Download...............................................................................2-3
2.3 Package Content ......................................................................................2-4
Section 3
Tools Install........................................................................................... 3-5
3.1 Requirement .............................................................................................3-5
3.2 In System Programming............................................................................3-5
3.2.1 MusicPlayerIsp ...................................................................................3-5
3.2.2 SUN JRE ............................................................................................3-8
3.3 USB Devices Installation...........................................................................3-8
3.3.1 AT85C51SND3B ISP USB device......................................................3-8

AT85RFD-07 Getting Started User Guide 1-1
7712A–MP3–02/07
Section 1
Introduction
The AT85RFD-07 Starter Kit is designed to give designers a quick start to develop code
on the AT85C51SND3Bx as well as for prototyping and testing of new designs.
1.1 Atmel
Registration
In order to keep posted on any new information concerning the AT85C51SND3Bx prod-
ucts (new firmware delivery, new tool version, …) register at the following address:
http://support.norway.atmel.com/bin/customer
As soon as you are registered, edit your preferences and ‘check’ the 8051 radio button
in the e-mail notification section.

AT85RFD-07 Getting Started User Guide 2-3
7712A–MP3–02/07
Section 2
Package Download
The Nand Flash memory of the AT85RFD-07 is delivered pre-programmed with the
demo firmware and AT85C51SND3B documentation. Since the board is manufactured
in large quantities, the package may be out of date. It is strongly recommended to down-
load the latest version of the AT85C51SND3B package from our web site.
The following paragraphs explain how to retrieve the package from the web site or from
the Nand Flash memory.
2.1 Web Site
download
1. Connect to:
https://www.atmel-nantes.fr/.mp3/at85c51snd3b
User Name is: atmelmp3
Password is: snd3pass
2. Copy the at85c51snd3b.zip file to your PC.
3. Unzip the package to your local hard drive.
2.2 Nand Flash
Download
1. Connect the USB cable to the player and to a PC.
The demonstration firmware starts and enters the mass-storage application:
A new USB device is installed and a removable disk is mounted in the explorer:
Note: The disk letter may differ.
The AT85RFD-07 disk corresponds to the on-board Nand Flash memory.

Package Download
2-4 AT85RFD-07 Getting Started User Guide
7712A–MP3–02/07
2. Open the AT85RFD-07 disk, its content is as follows:
The Atmel directory contains the AT85C51SND3B package.
The Update directory is the location where to place the update package for the auto-
matic firmware upgrade feature (see firmware user’s guide).
3. Copy the Atmel directory to your local hard drive.
2.3 Package Content The package content is the following:
...... Development kit package
............. Dev-kit user’s guides
............. Link to dev-kit firmware
............. Hardware package
...... Reference design package
............. Ref-dsn user’s guides
............. Link to ref-dsn firmware
............. Hardware package
...... Link to datasheet on Atmel web site
...... Firmware packages
............. Firmware user’s guide & application notes
...... Development tools
............. Atmel font generator
............. Atmel in system programming
............. Atmel on-chip debug
.....................OCD dongle recovery tool
.....................Flip tool for dongle upgrade
.....................Keil debug drivers
............. Atmel screen generator
............. USB mass-storage drivers (Win98, Linux)
............. Freeware USB bench32 tool
...... Training material
............. Hands-on tutorial
............. Whole AT85C51SND3Bx presentations

AT85RFD-07 Getting Started User Guide 3-5
7712A–MP3–02/07
Section 3
Tools Install
3.1 Requirement Firmware has been developed and debugged using the Keil
®
µvision IDE. It is a project
oriented fully integrated environment including debugger and advanced compiling and
linking options like code banking.
In order to start development with AT85C51SND3B, it is required that the Keil environ-
ment is installed on the PC.
3.2 In System
Programming
The in system programming install consists of:
Atmel MusicPlayerIsp Tool
Sun
™
Java Run time Environment if necessary
3.2.1 MusicPlayerIsp To install the Atmel MusicPlayerIsp, go to “Atmel\at85c51snd3b\Tools\In System Pro-
gramming” directory and execute music-player-isp-X_Y_Z.exe; where X_Y_Z is the tool
revision number.
Press Next to proceed

Tools Install
3-6 AT85RFD-07 Getting Started User Guide
7712A–MP3–02/07
Read and accept the licence agreement
Select the installation directory (use the proposed default)

Tools Install
AT85RFD-07 Getting Started User Guide 3-7
7712A–MP3–02/07
Validate the information
The installation starts…

Tools Install
3-8 AT85RFD-07 Getting Started User Guide
7712A–MP3–02/07
Do not restart your computer, exit the current session and log-in again
Start MusicPlayerIsp to check Java runtime installation
If the following pop-up appears, proceed with the SUN
™
JRE installation
3.2.2 SUN JRE To install the JRE, go to “Atmel\at85c51snd3b\Tools\In System Programming” directory
and click on the “Sun JRE download” URL shortcut.
Follow the install procedure of the SUN JRE.
3.3 USB Devices
Installation
In order to complete the installation, the AT85C51SND3B ISP USB device must be
installed.
3.3.1 AT85C51SND3B ISP
USB device
A USB removable mass-storage disk will be installed after plug-in.
– Press the ISP button
– Plug the board to a PC using the USB cable
A new USB device is installed and one removable disk is mounted in the explorer:
Note: The disk letter may differ.
