ATN Night Trek User manual

u s e r ` s g u i d e

NIGHT VISION
SPOTTING SCOPE
Important Export Restrictions! Commodities, prod-
ucts, technologies and services contained in this manual
are subject to one or more of the export control laws and
regulations of the U.S. Government and they fall under the
control jurisdiction of either the US Department of State
or the US BIS-Department of Commerce. It is unlawful
and strictly prohibited to export, or attempt to export or
otherwise transfer or sell any hardware or technical data
or furnish any service to any foreign person, whether
abroad or in the United States, for which a license or writ-
ten approval of the U.S. Government is required, without
first obtaining the required license or written approval
from the Department of the U.S. Government having
jurisdiction. Diversion contrary to U.S. law is prohibited.

The information in this manual furnished for information use only, is subject to change without notice, is not to be construed
as a commitment by ATN Corp.
ATN Corp. assumes no responsibility or liability for any errors or inaccuracies that may appear in this book.
©2006 ATN Corp. All right reserved.

• Powerful 5x magnification
• High resolution Gen 1+,Image intensifier tube
• Built in Flood infrared illuminator
• Lightweight
• Water and fog resistant
• Limited Lifetime warranty

Total Darkness Technology............Standard
Magnification............................................ 5X
Intensifier Tube..............High Res. 1st Gen +
Detection Range .......................150 m/yards
Recognition Range....................100 m/yards
Lens System.......................... F1:1.2, 50 mm
FOV ......................................................... 10°
Diopter Adjustment................................... ±4
Resolution ......................................40 lp/mm
Power Supply .........Two 1.5 Volt Battery(AA)
Range Of Focus ....................1.5 m to Infinity
Battery Life ................................10-20 Hours
Operating Temperature ........ -25°C to +40°C
Dimensions ........ 240 mm X 60 mm X 80 mm
............................................10” X 2.3” X 3.2”
Weight ......................................0.52Kg/18Oz

The Night Trek has the highest magnification of a
1st generation monocular available. An amazing
5x power combined with a compact, ergonomic
design makes the Night Trek an excellent unit for
your night vision needs.
A 5x magnification all glass lens system com-
bined with a high quality 1st generation + light
intensifier tube gives you a bright and sharp
image in any dark situation you may find yourself
in. A free long-range infrared illuminator is also
included to let you see even in total darkness.
Do not let darkness impair your vision for a
moment longer. Whether you are camping, boat-
ing, observing wildlife or surveying your property
for intruders the Hight Trek night vision device
lets you see what goes bump in the night.
The Hight Trek Night Vision Monocular is a com-
plex opticoelectronic system for individual use.
The device consists of an objective lens assembly,
eyepiece and a body. The body contains 1st Gen.+
image intensifier tube assembly with an integrated
high voltage power source and the three volt bat-
tery housing. When installing the battery one
should keep in mind that the battery polarity should
coincide with the diagram on the body next to the
battery housing cap.
Objective lens protective cover is intended to
protect objective lens from dust and scratches.
It also will act as a daylight filter, allowing you to
test the scope in daylight or other bright light situ-
ations. The pinhole in the center of the protective
cover allows a user to check an operation ability
of the device in daylight conditions.
NOTE: Do not test the scope in daylight conditions
even with the daylight filter/lens cap on for more
than ten (10) minutes.
Power switch
IR illuminator
IR illuminator power
5 Diopter
Battery
housing
F1:1.2, f50mm
front lens system

2

• Take the monocular out of the case.
• Put power switch and IR illuminator power switch
in OFF-position.
• Install the batteries into the housing with the
polarity order as shown on the scope. Battery
Type: 1.5 Volt , AA .
• Turn on the devise by turning the power switch
into the ON-position. The greenish-lit screen of
the image tube (when looking through the eye-
piece) means that the image tube is powered.
Do not turn the unit on in the daytime without the
protective lens cap on. You should see green
glow in the eyepiece.
• Observe the scene and adjust the diopter for op-
timal image clarity.
• Turn lens to obtain a sharp image of viewed ob-
jects.
• You may now enter a dark environment or simply
shut the lights off in order to darken the room.
• Next, remove the lens cap/daylight filter. Adjust
the front lens for the distance of the focus. You
should not have to readjust the diopter.
NOTE: We suggest that you focus the diopter
during daylight with the filter on.
NOTE: The front lens should be readjusted as you
view objects at different distances.

Infra-red (IR) illuminators, are common to night
vision. The IR light greatly enhances the per-
formance of the Hight Trek while remaining
almost totally invisible to the naked eye. The IR
illuminator on the Hight Trek is located next to the
front lens.
Slide the switch to turn on or off the IR illumina-
tor.
It is important to remember that the IR illuminator
is simply an infra red light source, and like any
light source, it may loose its effectiveness over a
great distance.


• Always remember to turn off the Night Trek when
it is not in use. If you do not plan on using your
unit for a period of more than 10 days, you should
remove the batteries.
• Keep lens cap/daylight filter on when not in
use.
• Avoid contact with dust, steam, and gas.
• The Night Trek is not harmful to the user or the
environment.
• Do not disassemble except to clean the front
lens and the eyepiece: it will void your war-
ranty.
• Evaluate the scopes function by looking through
it in a lit environment with the daylight filter lens
cap on. Never use in daylight without the daylight
filter lens cap on. Do not surpass ten minutes of
testing.
• Never point the Night Trek at a bright light
source. If the scope shuts off automatically after
directing it at a bright light source, turn the unit
off and wait 1 - 2 minutes before turning the unit
back on.
• Adverse atmospheric conditions such as fog,
smog, or haze and a lack of ambient light (moon
or starlight) may diminish the effective viewing
distance. All technical data for this unit was com-
piled in a controlled environment.
• If you use the rubber eyecaps for a long period
of time, you may suffer skin inflammation. If you
develop any symptoms, consult a doctor imme-
diately.

Q: Flashes, flickers or clicking occur while oper-
ating
S: If it occurs within the first five minutes of insert-
ing new batteries, it is normal and the device
will resume normal operation soon thereafter. If
it occurs for more than 10 minutes, contact for
service instructions.
Q: Dark spots on screen.
S: These are either cosme tic blemishes in the
intensifier tube or dust particles.
Q: Screen becomes darker than at previous use.
S: Replace batteries. If problem persists, contact
your dealer or other authorized service repre-
sentative for service instructions.
Q: Image not clear.
S: Adjust objective lens, and/or the eyepiece.
such implied warranties are hereby and expressly
disclaimed.



ATN Limited Lifetime Warranty is limited to the prod-
uct being free of manufacturer defects in materials
and workmanship. In regards to night vision products
the image intensifier tube is warranted to be free from
manufacturer defects for a period of 2 years (defects
do not include minor black spots or blemishes in
viewing area). ATN will repair or replace said prod-
ucts or part thereof which upon inspection by ATN are
found to be defective in materials or workmanship.
As a condition to the obligation of ATN to repair or
replace said product, the product must be returned to
ATN together with proof-of-purchase satisfactory to
ATN. This warranty does not cover damages caused
by misuse or improper handling. This warranty is null
and void if modification or maintenance is provided
by parties other than ATN Corp. In the event a de-
fect that is covered by the foregoing warranty occurs
during the applicable period stated above, ATN, at its
option, will either repair or replace the product, and
such action on the part of ATN shall be the full ex-
tent of ATN’s liability, and the Customer’s sole and
exclusive remedy. This warranty does not cover a
product (a) used in other than its normal and custom-
ary manner; (b) subjected to misuse; (c) subjected to
alterations, modifications or repairs by the Customer
of by any party other than ATN without prior written
consent of ATN; (d) special order or “close-out” mer-
chandise or merchandise sold “as-is” by either ATN
or the ATN dealer; or (e) merchandise that has been
discontinued by the manufacturer and either parts or
replacement units are not available due to reasons
beyond the control of ATN. ATN shall not be respon-
sible for any defects or damage that in ATN’s opinion
is a result from the mishandling, abuse, misuse, im-
proper storage or improper operation, including use
in conjunction with equipment which is electrically or
mechanically incompatible with or of inferior quality
to the product, as well as failure to maintain the envi-
ronmental conditions specified by the manufacturer.
CUSTOMER IS HEREBY NOTIFIED THAT OPERA-
TION OF THE EQUIPMENT DURING DAYLIGHT
HOURS OR UNDER ANY EXCESSIVE LIGHT CON-
DITIONS MAY PERMANENTLY DAMAGE THE IN-
TERNAL COMPONENTS OF THE UNIT AND SAID
DAMAGE WILL NOT BE COVERED UNDER THIS
WARRANTY. This warranty is extended only to the
original purchaser. Any breach of this warranty shall
be waived unless the customer notifies ATN at the
address noted below within the applicable warranty
period.
The customer understands and agrees that except
for the foregoing warranty, no other warranties writ-
ten or oral, statutory, expressed or implied, including
any implied warranty of merchantability or fitness for
a particular purpose, shall apply to the product. All
such implied warranties are hereby and expressly
disclaimed.

ATN will not be liable for any claims, actions,
suits, proceedings, costs, expenses, damages or li-
abilities arising out of the use of this product. Opera-
tion and use of the product are the sole responsibility
of the Customer. ATN’s sole undertaking is limited to
providing the products and services outlined herein
in accordance with the terms and conditions of this
Agreement. The provision of products sold and serv-
ices performed by ATN to the Customer shall not be
interpreted, construed or regarded, either expressly
or implied, as being for the benefit of or creating any
obligation toward any third party of legal entity out-
side ATN and the Customer; ATN’s obligations under
this Agreement extend solely to the Customer. ATN’s
liability hereunder for damages, regardless of
the form or action, shall not exceed the fees or
other charges paid to ATN by the customer or
customer’s dealer. ATN shall not, in any event, be
liable for special, indirect, incidental or conse-
quential damages, including, but not limited to,
lost income, lost revenue or lost profit, whether
such damages were foreseeable or not at the
time of purchase, and whether or not such dam-
ages arise out of a breach of warranty, a breach
of agreement, negligence, strict liability or any
other theory of liability.

In order to validate the warranty on your product, ATN
must receive a completed Product Warranty Regis-
tration Card for each unit. Please complete the form
below and immediately mail it to our Service Center:
ATN Corporation, 1341 San Mateo Avenue, South
San Francisco CA 94080. Products qualifying for
warranty repair will be either repaired or replaced
within 10 business days of receipt of merchandise
unless the customer is notified otherwise.

To obtain warranty service on your unit, take or send
the product, postage paid, with a copy of your sales
receipt to our service center, ATN Corporation at the
address noted above. All merchandise must be fully
insured with the correct postage; ATN will not be re-
sponsible for improper postage or, missing or dam-
aged merchandise during shipment.
For customer service and technical support,
please contact
American Technologies Network Corp.
North American Office
1341 San Mateo Avenue
South San Francisco, CA 94080
Toll Free Phone: [phone]
Phone: [phone]; fax: [phone]
European Office
phone: [phone], fax: 44(0) 845-
3349142
The following countries can use our
toll free number 00 800 9102-8620
Austria, France, Germany, Holland, Italy, Spain,
Sweden, Switzerland
www.atncorp.com
