ATN PS-22 User manual

operator’s manual
Important Export Restrictions! Commodities,
products, technologies and services contained in
this manual are subject to one or more of the export
control laws and regulations of the U.S. Government
and they fall under the control jurisdiction of either the
US Department of State or the US BIS-Department
of Commerce. It is unlawful and strictly prohibited
to export, or attempt to export or otherwise transfer
or sell any hardware or technical data or furnish any
service to any foreign person, whether abroad or
in the United States, for which a license or written
approval of the U.S. Government is required, without
first obtaining the required license or written approval
from the Department of the U.S. Government having
jurisdiction.DiversioncontrarytoU.S.lawisprohibited.
NIGHT VISION FRONT SIGHT
ATN PS-22
ATN PS-22
OPERATOR’S MANUAL (REV. 8, JULY 2012)

The information in this manual furnished for information use only, is subject to
change without notice, is not to be construed as a commitment by ATN Corp.
ATN Corp. assumes no responsibility or liability for any errors or inaccuracies
that may appear in this book.
© 2012 ATN Corp. All right reserved.
Register your product warranty online at
www.atncorp.com/warranty

a
SAFETY SUMMARY
CAUTIONS
• The ATN PS-22 is a precision optical instrument and must be han-
dled carefully at all times to prevent damage.
• Do not scratch the external lens surfaces or touch them with your
fingers.
• To protect the image intensifier, keep the lens cap on the objective
lens when the sight is not in use or when checked out in daylight
conditions.
• The IR illuminator is the light that is invisible to the unaided eye
for use during conditions of extreme darkness. However, the light
from the illuminator can be detected by others when using night
vision devices.
• If you use the rubber eyecaps for a long period of time, you may
suffer skin inflammation. If you develop any symptoms, consult a
doctor immediately.
WARNING
Do not carry batteries in pockets containing metal objects such as
coins, keys, etc. Metal objects can cause the batteries to short cir-
cuit and become very hot.
THIS PRODUCT CONTAINS NATURAL RUBBER LATEX
WHICH MAY CAUSE ALLERGIC REACTIONS.
CAUTION:

b
WARNING
Toxic Material
The image intensifier’s phosphor screen contains toxic materi-
als.
• If an image intensifier breaks, be extremely careful to avoid
inhaling the phosphor screen material. Do not allow the mate-
rial to come in contact with the mouth or open wounds on the
skin.
• If the phosphor screen material contacts your skin, wash it off
immediately with soap and water.
• If you inhale/swallow any phosphor screen material, drink a lot
of water, induce vomiting, and seek medical attention as soon
as possible.
WARNING
Do not use contaminated light suppressor. They must be
replaced.

c
EQUIPMENT LIMITATIONS
To avoid physical and equipment damage when using the
ATN PS-22, carefully read and understand the following safety
precautions.
• The equipment requires some night light (moonlight, starlight,
etc.) to operate. The level of performance depends upon the
level of light.
• Night light is reduced by passing cloud cover, while operating
under trees, in building shadows, etc.
• The equipment is less effective viewing into shadows and other
darkened areas.
• The equipment is less effective through rain, fog, sleet, snow
or smoke.
• The equipment will not “see” through dense smoke.

i
TABLE OF CONTENTS
pg.
SAFETY SUMMARY a
SECTION I. INTRODUCTION 1-1
1.1. General 1-2
1.1.1. Sight 1-2
1.1.2. Reports 1-2
1.1.3. Storage 1-2
1.1.4. Warranty 1-3
1.2. Description and Data 1-5
1.2.1. Description 1-5
1.2.2. PS-22 Standard Components
and Optional Equipment 1-8
SECTION II. OPERATING INSTRUCTIONS 2-1
2.1. Installation Procedures 2-2
2.1.1. Battery Installation 2-2
2.1.2. Instalation on MIL-STD-1913/Picatiny Rail 2-2
2.1.3. Attachment to Day Scope Objective 2-3
2.1.4. 7/8” Weaver Mount 2-6
2.1.5. Adapter for A.R.M.S. Mounts 2-7
2.1.6. Picatinny Rail 2-8
2.1.7. Platform Ring 2-8
2.1.8. Long Rail Adapter 2-9
2.1.9. B.A.M. System 2-9
2.1.10.Remote Control 2-12
2.1.11. IR450 Illuminator 2-12
2.1.12. Mounting Examples 2-14
2.2. Operating Procedures 2-16
2.2.1. General 2-16
2.2.2. Controls 2-16
2.2.3. Operating Procedures 2-17
2.2.4. Operating with Remote Controle 2-18
2.2.5. Operating with IR450 Illuminator 2-19
2.2.6. Preparation for Storage 2-19

ii
SECTION III. MAINTENANCE INSTRUCTIONS 3-1
3.1. Preventive Maintenance Checks
and Services (PMCS) 3-2
3.1.1. Preventive Maintenance Checks and
Services Table 3-2
3.1.2. Inspection Criteria for Proper Image
Intensifier Operation 3-6
3.1.3. Flashing, Flickering, or Intermittent Operation 3-3
3.1.4. Cosmetic Blemishes 3-3
3.2. Troubleshooting 3-10
3.2.1. General 3-10
3.2.2. Troubleshooting Procedures 3-10
3.3. Maintenance Procedures 3-11
3.3.1. PS-22 Maintenance 3-11
3.3.2. Cleaning Procedures 3-11
3.3.3. Tube Maintenance / Replacement 3-12
Appendix A. Estimation of Ambient
Illumination Level A-1
Appendix B. Spare Parts List B-1
Appendix C. How to Select Scope Mounting System C-1
For Technical Information INFO-1

iii

1-1
SECTION I
INTRODUCTION

1-2
1.1 GENERAL INFORMATION
1.1.1. SIGHT
This manual contains instructions for use in operating and main-
taining the ATN PS-22 Night Vision Front Sight. Throughout this
manual, the ATN PS-22 will be referred to as the sight or the
PS-22 or NVFS.
1.1.2. REPORTS
Reports from the user on recommendations for improvements are
encouraged. Send reports to the address below.
American Technologies Network Corp.
1341 San Mateo Avenue
South San Francisco, CA 94080
[phone]
[phone]
[phone] fax
www.atncorp.com
[e-mail]
1.1.3. STORAGE
Storage of the PS-22 should be done in the factory packing and
after a thorough PMCS as outlined in Section 4 of this manual.
This will ensure the sight remains in mission ready condition dur-
ing storage. Battery should be stored separately from the sight.
The PS-22 should not be placed on the floor, in any area exposed
to high temperatures or direct sunlight. Presence of acid and al-
kaline vapor, as well as of other aggressive admixtures in the air
is unacceptable.

1-3
1.1.4. WARRANTY
2 YEAR PRODUCT WARRANTY
This product is guaranteed to be free from manufacturing defects in
material and workmanship under normal use for a period of 2 (two)
years from the date of purchase. In the event a defect that is covered
by the foregoing warranty occurs during the applicable period stated
above, ATN, at its option, will either repair or replace the product, and
such action on the part of ATN shall be the full extent of ATN’s liability,
and the Customer’s sole and exclusive remedy. This warranty does not
cover a product (a) used in other than its normal and customary man-
ner; (b) subjected to misuse; (c) subjected to alterations, modifications
or repairs by the Customer of by any party other than ATN without prior
written consent of ATN; (d) special order or “close-out” merchandise or
merchandise sold “as-is” by either ATN or the ATN dealer; or (e) mer-
chandise that has been discontinued by the manufacturer and either
parts or replacement units are not available due to reasons beyond the
control of ATN. ATN shall not be responsible for any defects or damage
that in ATN’s opinion is a result from the mishandling, abuse, misuse,
improper storage or improper operation, including use in conjunction
with equipment which is electrically or mechanically incompatible with
or of inferior quality to the product, as well as failure to maintain the
environmental conditions specified by the manufacturer.CUSTOMER
IS HEREBY NOTIFIED THAT OPERATION OF THE EQUIPMENT
DURING DAYLIGHT HOURS OR UNDER ANY EXCESSIVE LIGHT
CONDITIONS MAY PERMANENTLY DAMAGE THE INTERNAL
COMPONENTS OF THE UNIT AND SAID DAMAGE WILL NOT BE
COVERED UNDER THIS WARRANTY. This warranty is extended only
to the original purchaser. Any breach of this warranty shall be waived
unless the customer notifies ATN at the address noted below within the
applicable warranty period.
The customer understands and agrees that except for the foregoing
warranty, no other warranties written or oral, statutory, expressed or
implied, including any implied warranty of merchantability or fitness for
a particular purpose, shall apply to the product. All such implied warran-
ties are hereby and expressly disclaimed.
LIMITATION OF LIABILITY
ATN will not be liable for any claims, actions, suits, proceedings, costs,
expenses, damages or liabilities arising out of the use of this product.
Operation and use of the product are the sole responsibility of the Cus-
tomer. ATN’s sole undertaking is limited to providing the products and
services outlined herein in accordance with the terms and conditions of
this Agreement. The provision of products sold and services performed
by ATN to the Customer shall not be interpreted, construed, or regard-
ed, either expressly or implied, as being for the benefit of or creating

1-4
any obligation toward any third party of legal entity outside ATN and the
Customer; ATN’s obligations under this Agreement extend solely to the
Customer.
ATN’s liability hereunder for damages, regardless of the form or
action, shall not exceed the fees or other charges paid to ATN by
the customer or customer’s dealer. ATN shall not, in any event, be
liable for special, indirect, incidental, or consequential damages,
including, but not limited to, lost income, lost revenue, or lost prof-
it, whether such damages were foreseeable or not at the time of
purchase, and whether or not such damages arise out of a breach
of warranty, a breach of agreement, negligence, strict liability or
any other theory of liability.
PRODUCT WARRANTY REGISTRATION
In order to validate the warranty on your product, ATN must receive a
completed Product Warranty Registration Card for each unit or com-
plete warranty registration on our website at www.atncorp.com. Please
complete the included form and immediately mail it to our Service Cen-
ter: ATN Corporation, 1341 San Mateo Avenue, South San Francisco,
CA 94080.
OBTAINING WARRANTY SERVICE
To obtain warranty service on your unit, End-user must notify ATN ser-
vice department by calling 800-910-2862 or 650-989-5100 or via e-mail
[e-mail] to receive a Return Merchandise Authorization
number (RMA).
When returning please take or send the product, postage paid, with a copy
of your sales receipt to our service center, ATN Corporation at the address
noted above. All merchandise must be fully insured with the correct post-
age; ATN will not be responsible for improper postage or, missing or dam-
aged merchandise during shipment.
When sending product back, please clearly mark the RMA# on the out-
side of the shipping box. Please include a letter that indicates your RMA#,
Name, Return Address, reason for service return, Contact information such
as valid telephone numbers and/or e-mail address and proof of purchases
that will help us to establish the valid start date of the warranty. Product
merchandise returns that do not have an RMA listed may be refused or a
significant delay in processing may occur.
Estimated Warranty service time is 10-20 business days. End-user/cus-
tomer is responsible for postage to ATN for warranty service. ATN will cov-
er return postage/shipping to continental USA end-users/customers after
warranty repair only if product is covered by aforementioned warranty. ATN
will return product after warranty service by domestic UPS ground and/
or domestic mail. Any other requested, required or international shipping
method the postage/shipping fee will be the responsibility of the end-user/
customer.

1-5
1.2. DESCRIPTION AND DATA
1.2.1. DESCRIPTION
A. Purpose
The PS-22 is an effective night vision system that mounts forward
of an existing riflescope/spotting scope (further referred to as a
scope) adding night vision capabilities to daytime target acquisi-
tion platform. Advisable dayscope magnification is 1X to 6X (2.5X
to 4X is optimum). The sight is installed and removed without af-
fecting boresight (permanent boresight alignment).
NOTE
The PS-22 can be installed also forward of viewfinders of va-
rious instruments to widen operating illumination range.
B. Principle of Operation
The PS-22 operation is based on the principle of electron-optical
intensification of light. The input fast catadioptric lens collects
available ambient light from source such as the moon, stars and
skyglow and focuses it on the image intensifier tube photocath-
ode. The tube amplifies the light and produces the viewable im-
age projected by the output lens from the tube screen into the
dayscope lens. Thus the sight provides the capability for operator
to see through the scope at night.
C. Features
The PS-22 has the following important features:
• Available with 2+, CGT, HPT or 3rd generation image intensi-
fier tube.
• Powered by a single CR 123A battery.
• Adjusts for lens focus.
• Is mounted on MIL-STD-1913/Picatinny rail or dayscope lens.
• Equipped with remote control.
• Automatic Brightness Control System always keeps the IIT
brightness level constant, even under unsteady brightness
conditions.

1-6
NOTE
Automatic Brightness Control System do not protect a device
from damage by bright light sources (a fire, headlights of the
automobile, lanterns, etc.). Do not point the device at a bright
light source.
• Is submersible to 10 m for 30 minutes.
• Filled with dry nitrogen to prevent internal fogging.
D. System Limitations
The PS-22 is an effective night vision system designed for night
operations but does have following limitations:
• The sight requires some night light (moonlight, starlight, etc.)
to operate. Night light is reduced by such factors as passing
cloud cover and objects that produce shadows.
• The sight is less effective viewing through rain, fog, sleet,
snow, smoke.
• Under starlight conditions low contrast environments (such as
snow-covered territory, sandy deserts, large bodies of water or
grassy hills) degrade visibility thereby disguising or masking
changes in terrain.
• Under too low-light conditions the sight looses some of the
resolution that it has under full moon.

1-7
TABLE 1-1. SYSTEM DATA
ITEM DATA
Magnification Unity (1X)
Boresight Characteristics:
Accuracy Factory aligned to ½ MOA or better
Retention Permanent to within 1 MOA or better
Repeatability Within ½ MOA
System Resolution subject to Tube Resolution:
36 to 44 lp/mm 0.38 mrad/lp
45 to 54 lp/mm 0.30 mrad/lp
55 to 64 lp/mm 0.25 mrad/lp
Over 65 lp/mm 0.21 mrad/lp
TABLE 1-2. MECHANICAL DATA
ITEM DATA
Dimensions without mount
(Length x Width x Height) 150 mm x 80 mm x 72 mm
Weight:
without Battery with QRM mount 0.64 kg
with Remote Control, Light
Suppressor and Battery 0.7 kg
Height of the Sight Axis above Arm Rail:
with Issued Mount 40 mm
with A.R.M.S.#19 ACOG Mount 49 mm
TABLE 1-3. ELECTRICAL DATA
ITEM DATA
Battery 123A Lithium
Consumption Current 26 mA
Cell Life at 20 ˚C 50 hours
NOTE
CR 123A batteries are “dead” at 2.5 VDC under load.

1-8
TABLE 1-4. OPTICAL DATA
ITEM DATA
Objective Lens Focal Length 80 mm
Objective Lens F/number 1:1.44
Focus Range 10 m to infinity
Field of View 12˚
Output Lens Exit Pupil Diameter 21 mm
TABLE 1-5. ENVIRONMENTAL DATA
ITEM DATA
Operating Temperature -40 to +50 ˚C
Storage Temperature -50 to +50 ˚C
Humidity 95 %, 25 ˚C to 40 ˚C for 48 hours
Illumination Required Natural night illumination (overcast star-
light to moonlight)
Immersion 10 m for 30 minutes
1.2.2. PS-22 STANDARD COMPONENTS AND
OPTIONAL EQUIPMENT
The PS-22 standard components are shown in Figure 1-1 and pre-
sented in Table 1-6.
FIGURE 1-1. PS-22 STANDARD COMPONENTS
17
6
10
9
35
4
11 12
2
13
8

1-9
TABLE 1-6. PS-22 STANDARD COMPONENTS
ITEM DESCRIPTION QTY
1Front Lens Cap 1
2ATN PS-22 Night Vision Front Sight 1
3Back Cap 1
4Light Supressor for the Scopes with 30-42 mm Lens Diameter 1
5Light Supressor for Trijicon ACOG Scopes 1
6Light Supressor for the Scopes with 42-63 mm Lens Diameter 1
7Remote Control 1
8Picatinny Quick Release Mount 1
9Picatinny Rail 1
10 CR123A Type Battery 1
11 IR Illuminator IR450 Kit 1
12 Operator’s Manual 1
13 Shipping/Storage Case 1
IR450-B4 IR Illuminator Kit is shown in Figure 1-2 and listed in
Table 1-7.
FIGURE 1-2. IR450 IR ILLUMINATOR KIT
TABLE 1-7. IR450 KIT
ITEM DESCRIPTION QTY
1IR450-B4 Illuminator 1
2CR123A Type Battery 1
31,5 mm Allen Key 1
4IR450 Wrench 1
21 3 4

1-10
Optional items are shown in Figure 1-3 and listed in Table 1-8.
FIGURE 1-3. PS-22 OPTIONAL EQUIPMENT
TABLE 1-8. PS-22 OPTIONAL EQUIPMENT
ITEM DESCRIPTION ITEM #
1Scope Mounting System #1 ACDNPS22SM01
2Scope Mounting System #2 ACDNPS22SM02
3Scope Mounting System #3 ACDNPS22SM03
4Scope Mounting System #4 ACDNPS22SM04
5Scope Mounting System #6 ACDNPS22SM06
6Boresight Attachment Mount (B.A.M.) ACDNPS22BM01
7Adapter for A.R.M.S. Mount COWSPSAM
87/8” Weaver Mount ACDNPS22WVR
9Long Rail Adapter ACWSLRADPT
10 Platform Ring ACWSRTRA
1 (2, 3, 4, 5)
8
10
9
6
7

2-1
SECTION II
OPERATING INSTRUCTIONS

2-2
2.1. INSTALLATION PROCEDURES
2.1.1. BATTERY INSTALLATION
CAUTION
Ensure the function switch
is in the off position before
installing a battery.
Install the battery as follows:
1. Unscrew the battery com-
partment cap.
2. Install the battery into the
battery compartment. Fol-
low battery symbol on the
sight body (Figure 2-1).
3. Replace the battery com-
partment cap.
2.1.2. INSTALLATION ON MIL-STD-1913/
PICATINNY RAIL
NOTE
The optical axis of the PS-22 and the riflescope should be
matched. Difference of the axes position more than 3 mm is
not recommended. Measure the height of the riflescope axis
above the rail. Observe Table 1-2 for the sight axis height above
the rail. If the difference in the axis heights of the PS-22 and rif-
lescope is more than 3 mm it is necessary to replace riflescope
mounting rings or monoblock by proper ones.
Install the PS-22 on MIL-STD-1913 rail as follows:
1. Take off the output lens cap (Figure 1-1, 4) and put it into the
storage case.
2. Remove the light suppressor from the storage case. Put it on in
place of the out put lens cap.
3. To open the sight Quick Release Mount , slide the cam latch for-
ward (Figure 2-2, arrow A) and turn the cam backward (arrow B).
4. Place the sight onto MIL-STD-1913 rail. Be sure to engage the
recoil lug into the groove on the top mounting surface of the
FIGURE 2-1.
BATTERY INSTALLATION
BATTERY
COMPARTMENT
CAP
BATTERY
+
-
