Atom 855 Instruction manual

HAND BLOWER
WORKSHOP MANUAL
PAGE 1
ACN 000 583 924
For more details visit our Atom website: www.atomindustries.com
Phone: [phone] Fax: [phone]
Email: [email protected]
Remove cylinder cover 3 Torx-20 screws. For GX-25, place
blade screwdriver under base of cover (above recoil starter)
and click cover off.
Remove handle cover by undoing 5 Torx-20 screws.
Lift out cable, or switch and switch wire.
MANUAL 780
To replace throttle cable, switch or switch wires
Fig. 101
To remove handle assembly
Fig. 102
Remove bracket holding cable
and wire (bracket not fitted on
# 831 model 2-Stroke Blower)
Reverse procedure to instal
new cable, or switch and
switch wire.
Hint: When refitting cylinder
cover, screw up lowest screw
first.
Fig. 103
Fig. 104
Use Torx-20 screwdriver, or long T-20 powered bit, which
fits into 3 recessed handle holes to undo 3 captivated
screws which attached the AV springs to casings.
Unscrew in sequence .
When refitting handle assembly, screw up in sequence
for easier completion.
1 2 3
1
2
3
For all Atom Blower models
1 2 3

To replace fan or to remove engine
PAGE 2
Fig. 105
Fig. 106
Remove handle assembly
as shown in Figs. 103 and
104.
Undo 2 Torx-20 screws
and holding lower
handle (and front fan cover).
Remove screw (near air
cleaner) from bracket (holds
air grill).
Remove front fan cover
assembly (including air
grill and bracket).
Fig. 107
5
45
4
6
Unscrew 2
Torx-25 screws
holding fan
To remove engine,
after removing fan,
unclip engine end
of switch wires,
detach throttle
cable to carburettor.
Honda engines
remove engine by
unscrewing 3 Torx-25
screws with washers.
For 2-Stroke engines
unscrew 4 Torx-25
screws with washers.
When refitting
engines use low
strength loctite or
similar on all 5 (or 6)
Torx-25 screws (on
engine and/or fan).
6
To remove muffler
Fig. 108
Remove blower tube and cylinder cover
(3x Torx-20 screws). Detach handle assy as
shown in Figs 103 & 104, and manoeuvre
cable and switch wire out of large slot
(where screwdriver is shown above).
Muffler now accessible for removal.
Atom products, including developments of AIRLIFT
®and BLOWMASTER ® blowers, blower anti-vibration handle system,
SMARTFAN ®impellers, and DRILLMASTER ®engine powered drills with automatic reverse gear and rotary throttle control, are
extensively protected by many Patents Pending, Patents, Registered Designs, and Registered Shapes and many Trade Marks including
Atom Trade Mark 1,463,4000. Additionally, US Patent No. 8,210,272-B2 tiller construction also covers and protects Atom Lawn
Edger construction.
Registration No. 1470990 is a REGISTERED SHAPE of the Atom Lawn Edger consisting of three dimensional shape of lawn edgers
having a ground engaging wheel supporting a motor or engine and a pair of handles in a wheelbarrow-like configuration.
Atom has a policy of continuous product improvement and development and reserves the right to modify the design and appearance
of products without notice.
Atom Industries is a division of Solo Industries Pty Ltd – an Australian owned company that invents, designs and manufactures unique
and outstanding products for local tough and hard Australian conditions with a history of international award winning gold medals,
great backup and service since 1961.

08-07-14 1
MODEL NO: 831, 855
MODEL NO: 831, 855MODEL NO: 831, 855
MODEL NO: 831, 855 PART NO: 20831, 20855
PART NO: 20831, 20855PART NO: 20831, 20855
PART NO: 20831, 20855
Key
Key Key
Key
Part No
Part No Part No
Part No
Substitute
Substitute Substitute
Substitute
Part No
Part NoPart No
Part No Des ription
Des riptionDes ription
Des ription
Key
Key Key
Key
Part No
Part No Part No
Part No
Substitute
Substitute Substitute
Substitute
Part No
Part NoPart No
Part No Des ription
Des riptionDes ription
Des ription
Key
Key Key
Key
Part No
Part No Part No
Part No
Substitute
Substitute Substitute
Substitute
Part No
Part NoPart No
Part No Des ription
Des riptionDes ription
Des ription
1 21775 MANUAL ALL MODELS(PDF) 31 64160 BL THROTTLE CABLE
240650 SCREW M5 x 36mm 32 64161 BL RUBBER FOOT
340651 SCREW M6 x 16mm 33 64162 PUSH BUTTON SWITCH
448101 OIL 80ML (Honda GX-25) 34 64165 BL SPRING RET CAM
563219 LABEL HOT MOTOR/OIL CLEAN 35 64166RN BL CABLE RETAINER
663319 LABEL BL ANTI VIBRATION 36 64167 PLUG SPANNER TUBE H
7 LABEL
863322 LABEL BL WARN SYMBOLS 38 64172 BL AV SPRING
9 LABEL BL START 39 64193 WASHER WAVE 14.5 x 10 x 0.3
10 63328 ENGINE BL HONDA 40 64194 SCREW T20 x 19.50 SELF TAP
11 63457 WASHER 6.4x12.5x1.5 ZP 41 64354 LABEL BL STOP CRUISE
12 63953B TAG-MADE IN AUSTRALIA 42 63405AB ASSY ATOM ENG 26FC3
13 64133 SPRING BL COVER
14 64134BN BL IMPELLER HONDA
14 64135BN BL IMPELLER ATOM
15 64136GN BL EXT MAIN CASING ATOM
15 64136RN BL EXT MAIN CASING HONDA
16 64137RN BL INT CASING H
16 64138GN BL INT CASING ATOM
17 64139WN BL AIR INTAKE COVER
18 64140WE BL STAND HANDLE
19 64146WP BL HANDLE LH
20 64147WP BL HANDLE RH
21 64148RN BL ENGINE COWL H
22 64149RN BL PLUG COV HONDA
23 64150RN BL THROTTLE TRIGGER
24 64151RN BL CRUISE CONTR CAM
25 64152RN BL CRUISE CONTR LEVER
26 64153RN BL CABLE ELBOW
27 64154WPE BL NOZZLE MAIN
28 64157RN BL HINGE CLAMP
29 64158WPE BL NOZZLE FISHTAIL
30 64159 BL SWITCH WIRE
30 64159 BL SWITCH WIRE
