atomi smart Smart WiFi User manual

Sma WiFi
Ceiling Fan
Let’s get staed!
QuickSta Guide
v1.12/21

2
READ AND SAVE ALL INSTRUCTIONS BEFORE USING.
WARNING
1. To reduce the risk of fire, electrical shock, or personal injury, mount fan directly from building structure
and/or an outlet box marked acceptable for fan suppo of 70 lbs (31.8 kg) and use the screws
provided in the bags C1, C2 or C3, or use the ones provided with the outlet box.
2. To avoid possible electrical shock, before installing or servicing your fan, disconnect the power by
turning o the circuit breakers to the outlet box and associated wall switch location. If you cannot
lock the circuit breakers in the o position, securely fasten a prominent warning device, such as a tag,
to the service panel.
3. To reduce the risk of electric shock, this fan must be installed with an isolating wall control/switch.
4. To reduce the riskof personal injury, do not bend the blades when installing or cleaning the fan. Do not
inse foreign objects in between rotating fan blades.
5. Chemical burn hazard. Keep baeries away from children. If a new or used baery is swallowed or
enters the body, it can cause severe internal burns and can lead to death in as lile as 2 hours.
Always completely secure the baery compament. If the baery compament does not close
securely, stop using the product, remove the baeries, and keep it away from children. If you think
baeries might have been swallowed or placed inside any pa of the body, seek immediate medical
aention. Dispose of cells properly and keep away from children. Even used cells may cause injury.
6. Do not aempt to recharge non-rechargeable baeries. Remove exhausted baeries from the
product.
7. All wiring must be in accordance with national and local electrical codes. It is highly recommended
that you use a qualified electrician.
Caution: modifications not approved by the pay responsible for compliance could void user’s
authority to operate the equipment.
FOR YOUR SAFETY
Mounting to high ceilings?
Maximize your comfo by choosing the right accessory downrod length foryour ceiling.
If you have an angled ceiling, you may need a longer downrod.
Visit www.atomisma.com to find additional downrod options.

3
WHAT’S IN THE BOX
Light ring (x1) Bag B1
Standard
mounting bracket (x1)
Bag A
Blade screw (x10)
Paper washer (x11)
LED board (x1)
Fan blade (x3)
Ceiling fan (x1) Glass shade (x1)12” downrod (x1) Angled canopy (x1)
Bag E1
Remote control (x1)
Remote control mount (x1)
Bag D
Wire nut (x3)
Bag E2
Remote control mount screw (x2)
Remote control mount anchor (x2)
On/O
On/OTimer
4H
Brightness
Warm Cool
Speed
Brightness
Speed
Bag B2
Angled
mounting bracket (x1)
Bag C3
Concrete anchor (x2)
Bag C2
Long mounting screw (x4)
Washer (x4)
Anchor (x4)
Bag C1
Sho mounting screw (x4)
Washer (x4)
Anchor (x4)

4
SELECT YOUR INSTALLATION LOCATION
Measure room dimensions
Check the outlet box
30 inches
from blade tip
to nearest wall
or obstruction
7 feet from
boom
edge of
blade to
the floor
The fan must be secured to the building structure or
a fan-rated outlet box capable of suppoing 32kg (70Lbs).
TOOLS NEEDED FOR INSTALLATION
Ladder Screwdriver Wire strippers Drill
(If applicable) (If mounting to a suppo structure or
concrete. Only concrete-compatible
screws are included.)

5
Angled Mounting
Flush Mounting Standard Mounting
CEILING FAN MOUNTING OPTIONS
Unpack and inspect the fan carefully to be ceain all pas are included.
Angled bracket
maximum angle =
35 degrees
Standard bracket
maximum angle =
15 degrees
Pre-assembled. The Atomi Sma Ceiling Fan
comes already prepped for this installation option.
Ceiling Outlet Box Ceiling Outlet Box
Ceiling Outlet Box
12” Downrod
(minimum)

6
INSTALLING THE BLADES
1
One at a time, inse each blade into the slot on the fan structure.
Secure each blade with the screws and washers found in bag A.
FOR THIS STEP YOU WILL NEED
A
BAG

7
FOR THIS STEP YOU WILL NEED
ASSEMBLING THE LIGHT FIXTURE
2
1
2
Remove the three screws as shown in the drawing.
Pass the connector through the
center hole of the light ring and
the LED board.

8
3
4
Connect the white plug from the housing structure to the white plug in the LED board.
Align the keyhole slots in the light ring and the LED board with the
keyhole slots in the housing area. Inse the screws and tighten them.
WARNING
PREVENT FAN FALLING INJURY OR
DEATH. Make sure all three screws
are tight to secure the trim ring to
the mounting plate.

9
INSTALLING THE BRACKETS
3
Only use the provided Atomi Sma ceiling bracket that comes with your fan.
Pickwhich installation option (below) that works best for your location.
Remove any existing bracket from your ceiling prior to installation.
Standard Bracket Angled Bracket
Secure the bracket to the ceiling using the washers and screws found in bag C1, C2 or C3,
according to the type of suppo structure you are installing the ceiling fan on to.
ATTENTION: for this installation, you must use the
included 12” downrod oryou may need a longer
one. Visit www.atomisma.com to find additional
downrod options. In step 4, you will find the
instructions to replace the downrod.
WARNING
PREVENT POSSIBLE ELECTRIC SHOCK. Before installing your
fan, disconnect the power by turning o the circuit breakers
to the outlet box associated with the wall switch location.
B1
BAG
B2
BAG
Up to 15°
Between
15° to 35°
Angled bracket
maximum angle =
35 degrees
Standard bracket
maximum angle =
15 degrees

10 Standard or Angled Mounting
1
Detach the red, white, and blackwires from the
wire splier. Unplug the white and blackwires.
Li the canopy and funnel.
REPLACING THE DOWNROD (OPTIONAL)
4
This step is for Standard and Angled Mounting only.
For the Flush Mounting (pre-assembled) go to Step 5.
If you have a longer downrod from Atomi Sma, please, follow the same instructions.
2
FOR THIS STEP YOU WILL NEED
12” DOWNROD
WARNING
PREVENT FAN FALLING INJURY OR DEATH:
• ALWAYS tighten screws with a screwdriver or a drill.
• DO NOT hand tighten screws.
• CHECK the screws are tight using screwdrivers each time you change fan direction.
If you are using the
Angled Bracket,
please use the
Angled Canopy
when prompted on
the next page.

11
Locate and remove the clip and pin.
Loose the screws and remove the downrod, canopy, and funnel.
3
4
2
3
1

12
7
Remove the clip and pin from the new downrod.
Inse the canopy and funnel
into the downrod, passing all
wires through the downrod.
Keep the canopy and funnel up
and inse the pin and clip.
5
6
2
3
1
2
1

13
9
10
Tighten the screws.
Re-aach the wires to the wire splier, matching the colors. Plug the white and blackwires.
Slide down the funnel.
Note: Use the canopy to place the exceeded wires.
8

14
HANGING THE FAN
5
Li and carefully hang the fan on the mounting bracket.

15
WIRING THE FAN
6
Carefully follow these steps to get your fan wired safely and quickly.
If you are unfamiliar with wiring or uncomfoable doing it yourself, please contact a qualified electrician.
1
Slide the remote receiver between the mounting bracket and the top of the downrod.
FOR THIS STEP YOU WILL NEED
D
BAG
WARNING
THE CEILING FAN MUST BE GROUNDED.
If the ground wire for the installation site
is not present oryou’re unsure what this
means, immediately STOP installation
and consult a qualified electrician.
WARNING
WIRING MUST BE UP TO CODE. All wiring
must be in accordance with national and
local electrical codes. If you are unfamiliar
with wiring or in doubt, consult a
qualified electrician.

16
2
1
3
2
2.1
Connect the BLACK
(ungrounded) wire from the
RECEIVER to the BLACK
wire from the CEILING.
2.3
Connect the GREEN
(grounded) wire from the FAN
to the GREEN OR BARE wire
from the CEILING.
2.2
Connect the WHITE
wire from the RECEIVER
to the WHITE wire from
the CEILING.
HAVE EXTRA WIRING?
Turn the wires upward and push them carefully back through the hanger
bracket into the outlet box. Spread the wires apa, with the grounded wires on
one side of the outlet box and the ungrounded wires on the other side of the
outlet box. Make sure that the wires are still aached to the wire nuts.
Push the bare metal ends of the wires together and slide a wire nut over them.
Twist the wire nut clockwise until tight.
Give it a gentle pull to ensure none of the wires come apa.

17
INSTALLING THE CANOPY
7
2
1
Li the canopy into place so that the screw
holes are aligned with the housing holes.
Fit the canopy in place as shown (1) and
turn it clockwise.
Tighten the screws.
FOR THIS STEP YOU WILL NEED

18
INSTALLING THE GLASS SHADE
8
12
3
Li the glass shade and align the notches in the
glass shade with the tabs in the light ring.
Aach the glass shade by liing and turning it
clockwise one-third of a full turn until it stops.
NOTE: Check to ensure proper engagement.
Turn on the circuit breakers to the outlet box associated with the wall switch location, then turn on the wall
switch and checkif the Atomi Sma WiFi Ceiling Fan stas flashing white light.
If it does not flash a white light, please, check all wiring connections for any wrong connections.
If it does flash a white light, please, proceed to the next step.
WARNING
PREVENT GLASS FALLING.
Make sure that glass is
properly secured.

19
USING THE REMOTE CONTROL
9
Control buons
Note: Requires 2 AAA baeries (not included).
Light Switch
Press to turn the light ON/OFF
Warm
Press to increase the white light
warmness by 10%. Hold the buon to
quickly increase to maximum levels
+ Speed
Press to increase the fan speed (Low,
Medium, High). Hold the buon to
quickly increase to High
Fan Switch
Press to turn the fan ON/OFF
- Speed
Press to decrease the fan speed (Low,
Medium, High). Hold the buon to
quickly decrease to Low
+ Brightness
Press to increase the light brightness
by10%. Hold the buon to quickly
increase to maximum levels
Cool
Press to increase the white light
coolness by 10%. Hold the buon to
quickly increase to maximum levels
- Brightness
Press to decrease the light brightness
by10%. Hold the buon to quickly
decrease to minimum levels
4H
Press to quickly add a 4-hourTimer to
turn o your ceiling fan blades
FOR THIS STEP YOU WILL NEED
E1
BAG
On/O
On/O Timer
4H
Brightness
Warm Cool
Speed
Brightness
Speed

20
1
1
2
32
Remove the screws from your light switch cover
(Do not remove the cover).
Place the Remote Control Mount
on the wall and make the guide
holes with a pencil.
Place the Remote Control Mount over the cover
and aach it with the cover’s screws.
Aach the Remote Control Mount
to the wall with the included
screws and anchors.
Drill holes for the included
anchors (if applicable).
Aaching to an existing light switch
Note: This is only compatible with toggle switches.
Mounting it to the wall
E2
BAG
