Atomos Connect User manual

CONNECT
FOR ATOMOS NINJA V / NINJA V+

Checklist
q 1 x Atomos CONNECT
q 1 x AtomX SSDmini Handle
q 1 x MasterCaddy III with screws
q 1 x RF Antenna
q 2 x WiFi Antenna with black caps
q 5 x Antenna colored caps:
White/Red/Yellow/Black/Green
q 3 x Antenna mount covers
q 1 x Antenna Pouch
q 1 x 3.5mm to 3.5mm cable
q 1 x Quick Start Guide
Firmware Update
To use the Atomos CONNECT with your NINJA V/V+ device,
ensure you have the latest rmware installed.
Visit atomos.com/support to download the latest rmware for
your device.
Connect
To attach the Atomos CONNECT to a NINJA V / V+, gently
slide it into the AtomXpansion Port until it clicks into place. To
remove, press the battery release button on the NINJA V / V+.
Power up
The Atomos CONNECT can be powered by the DC Power
Supply and Battery Eliminator that were supplied with your
NINJA V / V+, or alternatively you can use compatible
batteries. Connecting a power source to the CONNECT
supplies power for both NINJA V / V+ and CONNECT.
Battery
To connect a compatible battery, place the battery in front
of the retaining lug, align with the connectors and slide the
battery into the slot until it clicks into place.
Ensure NP-F / L-Series type batteries.
Tapping the battery icon in the top right of your NINJA V/V+
screen will allow you to accurately see remaining battery life.
Refer to the NINJA V/V+ User Manual for more information.
Battery Eliminator
To connect the Battery Eliminator, follow the same procedure
as the battery and lock it into position. Once the Battery
Eliminator is in place, secure the DC power supply to the DC
jack. Alternatively, the optional Atomos D-Tap to DC Barrel
Coiled Cable (ATOMDTPCB2) can be used to connect to a
D-Tap power source.
ATOMOS Support
Download User Manual, technical specifications and firmware
updates, calibrate devices, supported cameras and media
atomos.com/support
ATOMOS Academy
Discover how ATOMOS products enhance
your filmmaking and content creation
atomos.com/academy
my.atomos.com
Activate codecs/features for registered products, learn from
tutorials and download user manuals and firmware updates.
my.atomos.com/account
Register your Atomos Products
Register your products to ensure you receive notification about
the latest compatible firmware updates and new features.
my.atomos.com/register

a. RJ45 Ethernet Port
1Gbe Ethernet for a high-speed robust hardwired network
connection.
b. RF Antenna Connector
Connect the supplied RF antenna for Timecode sync
functionality.
c. Tally Light
Red Tally light on the rear of the unit indicates active
recording.
d. SDI Connector
The SDI input connector is 12G compliant and
backwards compatible.
e. WiFi Antennas
Connect the two supplied WiFi antennas in this position.
Wi-Fi 6 provides high performance wireless connection
and mobile hotspot support for connection
f. Battery Slot
Attach NP-F / L-Series batteries or a Battery Eliminator to
supply power.
g. Battery Release
Press and slide an attached power source away from the
unit to remove it.
h. Thumb screws
Use the provided thumb screws to securely attach the
CONNECT to the left side of your NINJA V / V+.
WARNING - Take care not to overtighten
the thumb screws.
WARNING - Master Caddy II does not t into
the NINJA V/NINJA V+ media slot when
ATOMOS CONNECT is attached.
Physical features Physical features
IN 12G
c. Tally light g. Battery release
b. RF Antenna
Connector
RF Antenna
d. SDI Connectora. RJ45 Ethernet Port
f. Battery Slot h. Thumbscrews
h. Thumbscrews
e.WiFi Antennas

Warranty & Conditions CONT.
Safety Instructions
Your ATOMOS product has been designed to a high standard, but there
are some things you should be aware of that will prolong the life of the unit
and for your own safety.
Using your ATOMOS product safely
Although your ATOMOS product is very lightweight compared to all the
devices it replaces, it is still a solid object that could cause injury if misused.
• Always make sure that your ATOMOS product is mounted securely and
is unable to fall onto anyone nearby. This is especially important when
there are children present who might be tempted to pull on cables.
• Always ensure that cables that run to tyour ATOMOS product are clearly
visible and do not present a trip hazard.
• Do not place on uneven or unstable surfaces.
• Do not insert anything but a Master Caddy III, AtomX SSDmini or CFast
II adapter in the drive slot on the rear of your ATOMOS product.
• Do not touch the screen with sharp, metallic or abrasive objects.
• Do not expose to strong electrical or magnetic elds.
• Do not expose to liquids, rain or moisture.
• Do not dispose of your ATOMOS product in municipal waste and do not
incinerate it, always follow local regulations for safe disposal.
Notifications
Contains FCC ID: PD9AX210NG | AYV-AGLU02
Contains IC ID: 1000M-AX210NG | 10427A-AGLU02
USA
WARNING: This product contains the chemical lead (Pb) which is known
to the State of California to cause cancer.
For more information, visit p65warnings.ca.gov
CAUTION: Regulations of the FCC and FAA prohibit airborne operation
of radio-frequency wireless devices because their signals could interfere
with critical aircraft instruments.
Warranty & Conditions
Notice
Copyright © 2022 ATOMOS Limited (‘referred to as ATOMOS’). All rights
reserved. All information in this document is subject to change without
notice. No part of the document may be reproduced or transmitted in any
form, or by any means, electronic or mechanical, including photocopying
or recording, without the express written permission of ATOMOS. A
reference to ATOMOS includes its related entities, subsidiaries and parent
company.
Trademarks
ATOMOS, ATOMOS CONNECT and AirGlu are registered trademarks of
ATOMOS. All other trademarks are the property of their respective holders.
International Hardware Limited Warranty (1 Year Standard)
ATOMOS warrants that:
• The main product, or any external accessories, will be free from defects in
materials and workmanship for a period of 1 year from the date of purchase.
If during the warranty period the product is shown to be defective ATOMOS
may at its option:
a) replace the goods or supply equivalent ones, b) repair the goods, c) pay
the cost of replacing the goods or of acquiring equivalent ones or d) paying
the cost of having the goods repaired; The customer must notify ATOMOS
of any defect in the goods in writing prior to the expiry of the warranty
periods set out above. The customer will be solely responsible for returning
the goods to ATOMOS or its authorized distributor. Upon acceptance of a
warranty claim by ATOMOS, where ATOMOS repairs or replaces the goods,
it will be responsible for reasonable shipping costs incurred in sending the
goods to the Customer, provided that customer is located in a country in
which ATOMOS has an authorized distributor or repair center or agent.
Warranty Exclusions
This warranty applies only to defects in workmanship and does not cover
defects caused by:
• A failure to comply with the then current operating instructions issued by
ATOMOS;
• Neglect;
• Improper or negligent acts or omissions;
• Unauthorized repairs or attempted repairs;
• Tampering with or modication of the goods;
• Connection to incompatible equipment or power sources;
• Exposure to water or weather;
• Exposure to magnetic elds or corrosive liquids or substances;
EXCEPT AS STATED IN THIS WARRANTY, ATOMOS, IT’S VENDORS,
AGENTS, RESELLERS AND DISTRIBUTORS DISCLAIM IN THEIR
ENTIRETY ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION ALL WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. THE REMEDIES OUTLINED
IN THIS WARRANTY ARE THE EXCLUSIVE REMEDY A CUSTOMER HAS
ARISING FROM DEFECTIVE GOODS WHICH ARE SUBJECT TO THE
WARRANTY. ATOMOS DOES NOT WARRANT THAT THE GOODS WILL
OPERATE IN A MANNER WHICH IS ERROR FREE, OR UNINTERRUPTED.
THE GOODS ARE NOT INTENDED TO BE THE PRIMARY OR ONLY
DATA STORAGE DEVICE FOR DATA – CUSTOMERS ARE SOLELY
RESPONSIBLE FOR BACK UP AND PROTECTION OF DATA.
Software License Agreement
IMPORTANT, PLEASE READ CAREFULLY. THIS IS A LICENSE AGREEMENT.
This ATOMOS software, related documentation, any included sample images
and other les (the “Software”), is protected by copyright laws and international
copyright treaties, as well as other intellectual property laws and treaties. The
Software is licensed, not sold.
This End User License Agreement (“EULA”) is a legal agreement between
you (either an individual or a single entity) and ATOMOS with regard to the
copyrighted Software provided with this EULA. Use of the Software provided to
you by ATOMOS in whatever form or media, will constitute your acceptance of
these terms, unless separate terms are provided by the software supplier, in which
case certain additional or different terms may apply. If you do not agree with the
terms of this EULA, do not download, install copy or use the Software. By installing,
copying or otherwise using the Software, you agree to be bound to the terms of
this EULA. If you do not agree to the terms of this EULA, ATOMOS is unwilling to
license the Software to you.
1. Eligible licensees. This Software is available for license solely to purchasers of
the ATOMOS product, who have purchased a unit manufactured by ATOMOS
and purchased through an ATOMOS authorized reseller, with no right of
duplication or further distribution, licensing or sub-licensing.
2. License Grant. ATOMOS grants you a personal, non-transferable and
non-exclusive right to use the copy of the Software provided with this EULA.
You agree you will not copy the Software except as necessary to use it with
the ATOMOS product. You agree that you may not copy the written materials
accompanying the Software. Modifying, reverse engineering, translating, renting,
copying, transferring or assigning all or part of the Software or any rights granted
hereunder, to any other persons or reverse engineering the hardware on which
the Software runs, is strictly prohibited. The software is license, not sold. You
acknowledge that no title to intellectual property in the Software is transferable to
you. You further acknowledge that title and full ownership rights to the Software will
remain the exclusive property of ATOMOS and/ or its suppliers, and you will not
acquire any rights to the Software, except as expressly set forth above. All copies
of the software will contain the same proprietary notices as contained in or on the
Software. All title and copyrights in and to the Software (including but not limited
to any images, animations, video, audio, text incorporated), the accompanying
printed materials, and any copies of the Software are owned by ATOMOS or its
suppliers.
3. Reverse engineering. You agree that you will not attempt, and if you are
a corporation, you will use your best efforts to prevent your employees and
contractors from attempting to reverse compile, derive circuits, modify, translate
or disassemble the Software and/or the ATOMOS product in whole or in part.
Any failure to comply with the above or any other terms and conditions contained
herein will result in the automatic termination of this license and the reversion of the
rights granted hereunder by ATOMOS.
ATOMOS reserves the right to terminate this license without prejudice to
any additional recourse ATOMOS may have against you if you violate any
of its terms and conditions.

GET STARTED
