Atomos SHINOBI 7 User manual

QUICK START GUIDE
SHINOBI 7
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
SHINOBI_7_QSG_1
重量：
A0
葉数 1 ／ 1 尺度： 1:1
図面番号：
名称：
改訂
図面測定不可
材料：
日 付
署 名
名 前
バリ取り、鋭角の除去
仕上げ：
指示なき場合：
寸法はミリメータとする
表面粗さ：
公差 ：
寸法 ：
角度 ：
品 管
製 産
承 認
検 図
製 図

2
Contents
Thank you for purchasing the Atomos Shinobi 7, utilizing
professional HD-SDI and HDMI connectivity to monitor up to
professional 4Kp60 (via HDMI) and 1080p60 (via 3G-SDI).
The class leading AtomHDR monitor lets you visualize
10+ stops of dynamic range, with 2200nits brightness for
daylight viewing and 10-bit processing for smooth gradations.
Please take the time to read through this Quick Start Guide
and register your product for free updates.
DOWNLOAD THE FULL
SHINOBI 7 USER MANUAL
www.atomos.com/support
Introduction
Introduction........................ 2
Checklist .......................... 3
You will also need .................. 3
AtomX Accessories ................ 3
Getting started ..................... 4
Connect and Power-up ............. 4
Input............................... 5
Physical features ................... 6
Touchscreen/User Interface ........ 8
Monitor assist tools ................ 9
Warranty & Conditions ............. 10
Notications ...................... 11

3
You will also need (sold separately)
SDI Cable
SDI cables are robust physically and electrically. You should
rarely have problems with signal transmission unless your cables
are either damaged or too long. Please remember that SDI
cables use locking connectors and will not simply pull out if they
are pulled or tripped over. They are therefore a signicant trip
hazard, and also a hazard to your equipment, which may be
damaged if the cables are mishandled or of a low grade. Please
ensure you test and check your SDI cables; for longer runs
cables of a Belden 1694A specication are recommended.
HDMI Cable
Atomos have a range of HDMI cables with die cast connectors
and coiled cables in a range of lengths and connections (sold
separately).
Checklist
q 1 x Shinobi 7
q 1 x AC Power Adaptor
q 1 x Quick Start Guide
Accessories
Atomos have a range of accessories tailored to usage with
the Shinobi 7. Visit your nearest Atomos reseller to discover
the range of available accessories that will get you up and
running enhance your production workow.
Batteries and power:
- ATOMOS 5200mAh 4 Cell NPF Style Battery NP-770
- ATOMOS 7800mAh 6 Cell NPF Style Battery NP-970
- ATOMOS Fast Battery Charger with Multi plug PSU
- ATOMOS Power Kit for all Atomos 5” & 7”
Monitor Recorders
Cables:
- ATOMOS AtomFLEX HDMI 4K60p Full to Full
(30cm/40cm/50cm)
- ATOMOS AtomFLEX HDMI 4K60p Full to Micro
(30cm/40cm/50cm)
- HDMI Coiled cable 4Kp30 Full to Full (30cm/50cm)
- HDMI Coiled cable 4Kp30 Full to Micro (30cm/50cm)

4
Connect and power-up
Battery
Shinobi 7 provides dual battery slots that combined with the
DC input allow for continuous power operation. With both
batteries connected Shinobi 7 will draw power from them
simultaneously, if a battery is removed it will automatically
switch over to the second battery or the DC power input.
This allows you to swap out a depleted battery without having
to shut down the monitor.
Touching the battery icons in the top right of your screen
will allow you to accurately see remaining battery life.
Refer to the User Manual for more information.
AC/DC Power
Alternatively power your Shinobi from mains power using the
included AC Power Adaptor. Simply attached the AC power
adaptor to mains power, carefully attach to the DC port on the
Shinobi 7 and rotate the locking nut to secure.
The DC input port can also be used with the optional Atomos
DTAP to DC cable (ATOMDTPCB2) to supply power to the
Shinobi 7 from a DTAP power output.
Battery indicators will show that no batteries are attached and
the unit is being powered via DC power input.
Power
You can power the device using the supplied AC power
supply, but if you plan to use a battery we recommend you
fully charge before use.
Choosing the right battery for your application
Battery time
(Based on 7.4V)
Monitor mode
2600mAh - 1.0hr
5200mAh - 2.0hrs
7800mAh - 3.5hrs
We recommend using Atomos NP-F series batteries.
Getting started

Input
Access Input Menu
IN
To access the Input Menu simply tap the INPUT (IN) area
located in the top left of the Shinobi screen.
Choose signal - HDMI or SDI
SOURCE
Displays the input source currently connected to the Shinobi,
simply tap to toggle between HDMI & SDI inputs. You can have
both HDMI and SDI inputs connected at the same time and
use this menu to toggle between active inputs.
Shinobi 7 - Quick Start Guide 5
HDMI
or SDI
VIDEO INPUT

A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
SHINOBI_7_6view
重量：
A0
葉数 1 ／ 1 尺度： 1:1
図面番号：
名称：
改訂
図面測定不可
材料：
日 付
署 名
名 前
バリ取り、鋭角の除去
仕上げ：
指示なき場合：
寸法はミリメータとする
表面粗さ：
公差 ：
寸法 ：
角度 ：
品 管
製 産
承 認
検 図
製 図
Battery
release
On/O
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
SHINOBI_7_6view
重量：
A0
葉数 1 ／ 1 尺度： 1:1
図面番号：
名称：
改訂
図面測定不可
材料：
日 付
署 名
名 前
バリ取り、鋭角の除去
仕上げ：
指示なき場合：
寸法はミリメータとする
表面粗さ：
公差 ：
寸法 ：
角度 ：
品 管
製 産
承 認
検 図
製 図
Remote/Calibration
port
Headphone/
audio out
SD
Card
Slot
1/4” screw hole
1/4” screw hole
On/O and Screen Lock
To turn the Shinobi 7 on, press the power button. To shut down,
hold the button for at least 4 seconds (until unit turns off).
SDI In
The SDI inputs support 3G in both level A and B standards.
SDI Out
This is for connection to an external monitor or other device with an
SDI input. It carries a loop-through of the incoming SDI (limited to
3G 1080p60) or HDMI signal in monitor and standby mode.
HDMI In
HDMI input connection to the Shinobi 7 supports up to 4Kp60.
HDMI Out
HDMI output connection from the Shinobi 7 supports up to 4Kp60.
Remote Calibration Port
The Shinobi 7 screen can be calibrated using the X-Rite i1Display
Pro. To connect you will need a USB to serial cable. (ATOMCAB004)
Battery Release
Press the release buttons and slide batteries upwards to remove.
Headphone / Audio out
Standard 3.5mm audio output for audio monitoring.
Screw Holes / Mounts + LockPin Holes (Arri)
1/4” screw hole top and bottom.
SD Card Slot
Use SD cards to load LUTs and/or update rmware.
Physical features

A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
SHINOBI_7_6view
重量：
A0
葉数 1 ／ 1 尺度： 1:1
図面番号：
名称：
改訂
図面測定不可
材料：
日 付
署 名
名 前
バリ取り、鋭角の除去
仕上げ：
指示なき場合：
寸法はミリメータとする
表面粗さ：
公差 ：
寸法 ：
角度 ：
品 管
製 産
承 認
検 図
製 図
Battery
Slot 1
Battery
release
Battery
Slot 2 Ventilation
SDI In
SDI Out
HDMI In
HDMI
Out
Port A
USB
DC Power
In
Port B
RJ45
SD Cards
Ensure correct
orientation when
inserting SD cards.
Never force the SD
card. If having difculty
check the orientation
of card is correct.
Card should be
formatted in FAT32.
Physical features
Shinobi 7 - Quick Start Guide 7

8
Touchscreen / User Interface
Settings
Press to access settings for
monitoring tools
MON (Monitor)
Tap to reveal monitoring
features. Tap again to hide.
Monitor features
See next page
VIDEO INPUT GAMMA BATTERYMONITORING MODEOUTPUT

9
Zoom 1:1
Punch in and check
critical focus across 4K
images.
Zoom x2
Punch in and check
critical focus.
Zoom x4
Punch in and check
critical focus (x4).
Focus Peaking
Ensure your recordings are
always in focus.
Zebra Pattern
Use Zebra to check
exposure and set exposure
levels.
False Color
A visualization of exposure
across the image
Luma Waveform
A great way to visualize
the dynamic range of your
image.
RGB Parade
Monitor the level of red,
green and blue from an
input source.
RGB Overlay
Monitor the level of red,
green and blue from an
input source.
RGB Histogram
Visualize the distribution of
colors in an image.
Analysis
Show video, waveform,
histogram and vectorscope
simultaneously.
Vectorscope
This is useful for checking
if an image is under or over
saturated.
Vectorscope Zoom
8x of the center of the
vectorscope. Useful when
setting white balance.
Histogram
Visualize your exposure
over the entire image.
Blue Only Exposure
Observe the noise content
of a video image.
Frame Guides
Frame guides for Cinema,
TV and social media.
Safe Areas
Action area and title safe
areas displayed.
Anamorphic Desqueeze
Allows you to correctly
view images when using
anamorphic lenses
MON
Monitor assist tools
MON
MON
MON
MON
MON
MON
MON
MON
MON

10
Warranty & Conditions
Notice
Copyright © 2021 ATOMOS Global Pty Ltd (‘referred to as ATOMOS’). All
rights reserved. All information in this document is subject to change without
notice. No part of the document may be reproduced or transmitted in any
form, or by any means, electronic or mechanical, including photocopying or
recording, without the express written permission of ATOMOS. A reference
to ATOMOS includes its related entities, subsidiaries and parent company.
Trademarks
Shinobi 7 / ATOMOS are registered trademarks of ATOMOS Pty Ltd. Apple,
the Apple logo, AppleShare, AppleTalk, FireWire, iPod, iPod Touch, Mac,
and Macintosh are registered trademarks of Apple Inc. Final Cut Pro,
QuickTime and the QuickTime Logo are trademarks of Apple Inc. All other
trademarks are the property of their respective holders.
International Hardware Limited Warranty
(1 Year Standard/3 Years if registered)
ATOMOS warrants that:
• The main product, not including the IPS screen, or any external accessories,
will be free from defects in materials and workmanship for a period of 1 year
from the date of purchase; or 3 years upon completion of product registration
within 1 year from the date of purchase at www.atomos.com
• The TFT/LCD, batteries, case and master caddies will be free from defects in
materials and workmanship for a period of 1 year from the date of purchase
regardless of registration. This warranty is exclusively for the benet of the
original purchaser and is not assignable or transferable.
If during the warranty period the product is shown to be defective ATOMOS
may at its option:
a) replace the goods or supply equivalent ones, b) repair the goods, c) pay
the cost of replacing the goods or of acquiring equivalent ones and d)paying
the cost of having the goods repaired; The customer must notify ATOMOS
of any defect in the goods in writing prior to the expiry of the warranty periods
set out above. The customer will be solely responsible for returning the goods
to ATOMOS or its authorized distributor. Upon acceptance of a warranty
claim by ATOMOS, where ATOMOS repairs or replaces the goods, it will
be responsible for reasonable shipping costs incurred in sending the goods
to the Customer, provided that customer is located in a country in which
ATOMOS has an authorized distributor or repair center or agent.
Warranty Exclusions
This warranty applies only to defects in workmanship and does not cover
defects caused by:
• A failure to comply with the then current operating instructions issued by
ATOMOS;
• Neglect;
• Improper or negligent acts or omissions;
• Unauthorized repairs or attempted repairs;
• Tampering with or modication of the goods;
• Connection to incompatible equipment or power sources;
• Exposure to water or weather;
• Exposure to magnetic elds or corrosive liquids or substances;
EXCEPT AS STATED IN THIS WARRANTY, ATOMOS, IT’S VENDORS,
AGENTS, RESELLERS AND DISTRIBUTORS DISCLAIM IN THEIR
ENTIRETY ALL OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION ALL WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
THE REMEDIES OUTLINED IN THIS WARRANTY ARE THE EXCLUSIVE
REMEDY A CUSTOMER HAS ARISING FROM DEFECTIVE GOODS
WHICH ARE SUBJECT TO THE WARRANTY. ATOMOS DOES NOT
WARRANT THAT THE GOODS WILL OPERATE IN A MANNER WHICH
IS ERROR FREE, OR UNINTERRUPTED. THE GOODS ARE NOT
INTENDED TO BE THE PRIMARY OR ONLY DATA STORAGE DEVICE
FOR DATA – CUSTOMERS ARE SOLELY RESPONSIBLE FOR BACK UP
AND PROTECTION OF DATA.
Software License Agreement
IMPORTANT, PLEASE READ CAREFULLY. THIS IS A LICENSE AGREEMENT.
This ATOMOS software, related documentation, any included sample images
and other les (the “Software”), is protected by copyright laws and international
copyright treaties, as well as other intellectual property laws and treaties. The
Software is licensed, not sold.
This End User License Agreement (“EULA”) is a legal agreement between you
(either an individual or a single entity) and ATOMOS with regard to the copyrighted
Software provided with this EULA. Use of the Software provided to you by
ATOMOS in whatever form or media, will constitute your acceptance of these
terms, unless separate terms are provided by the software supplier, in which case
certain additional or different terms may apply. If you do not agree with the terms of

11
this EULA, do not download, install copy or use the Software. By installing, copying
or otherwise using the Software, you agree to be bound to the terms of this EULA.
If you do not agree to the terms of this EULA, ATOMOS is unwilling to license the
Software to you.
1. Eligible licensees. This Software is available for license solely to purchasers of
the ATOMOS Shinobi 7, who have purchased a unit manufactured by ATOMOS
Shinobi 7 and purchased through an ATOMOS authorized reseller, with no right of
duplication or further distribution, licensing or sub-licensing.
2. License Grant. ATOMOS grants you a personal, non-transferable and
non-exclusive right to use the copy of the Software provided with this EULA.
You agree you will not copy the Software except as necessary to use it with the
ATOMOS Shinobi 7. You agree that you may not copy the written materials
accompanying the Software. Modifying, reverse engineering, translating, renting,
copying, transferring or assigning all or part of the Software or any rights granted
hereunder, to any other persons or reverse engineering the hardware on which
the Software runs, is strictly prohibited. The software is license, not sold. You
acknowledge that no title to intellectual property in the Software is transferable to
you. You further acknowledge that title and full ownership rights to the Software will
remain the exclusive property of ATOMOS and/ or its suppliers, and you will not
acquire any rights to the Software, except as expressly set forth above. All copies
of the software will contain the same proprietary notices as contained in or on the
Software. All title and copyrights in and to the Software (including but not limited to
any images, animations, video, audio, text incorporated), the accompanying printed
materials, and any copies of the Software are owned by ATOMOS or its suppliers.
3. Reverse engineering. You agree that you will not attempt, and if you are
a corporation, you will use your best efforts to prevent your employees and
contractors from attempting to reverse compile, derive circuits, modify, translate or
disassemble the Software and/or the ATOMOS Shinobi 7 in whole or in part. Any
failure to comply with the above or any other terms and conditions contained herein
will result in the automatic termination of this license and the reversion of the rights
granted hereunder by ATOMOS.
ATOMOS reserves the right to terminate this license without prejudice to
any additional recourse ATOMOS may have against you if you violate any
of its terms and conditions.
Notifications
USA
WARNING: This product contains the chemical lead (Pb)
which is known to the State of California to cause cancer.
For more information, visit p65warnings.ca.gov

© Atomos 2021. TM ® All trademarks and registered trademarks are the property of their respective owners.
For more detailed instructions and important up-to-date information regarding
Shinobi 7 please download the complete Shinobi 7 User Manual from:
www.atomos.com/support
atomos.com
