ATV NVR4P User manual

NVR4P (PoE)
4 Channel Network
Video Recorder
INSTRUCTION MANUAL
Please read this manual thoroughly before use, and keep it handy for future reference.
Model : NVR4P

WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PROCUCT TO
RAIN OR MOISTURE. DO NOT INSERTANY METALLIC OBJECT THROUGH THE VENTILATION
GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT.
CAUTION
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated "dangerous voltage" within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
PRECAUTIONS
Safety -------------------------------------- Installation -------------------------------
Should any liquid or solid object fall into the
cabinet, unplug the unit and have it checked by
the qualified personnel before operating it any
further.
Unplug the unit from the wall outlet if it is not
going to be used for several days or more. To
disconnect the cord, pull it out by the plug. Never
pull the cord itself.
Allow adequate air circulation to prevent internal
heat build-up. Do not place the unit on surfaces
(rugs, blankets, etc.) or near materials (curtains,
draperies) that may block the ventilation holes.
Height and vertical linearity controls located at the
rear panel are for special adjustments by qualified
personnel only.
Do not install the unit in an extremely hot or
humid place or in a place subject to excessive
dust, mechanical vibration.
The unit is not designed to be waterproof.
Exposure to rain or water may damage the unit.
Cleaning ---------------------------------
Clean the unit with a slightly damp soft cloth.
Use a mild household detergent. Never use
strong solvents such as thinner or benzene as
they might damage the finish of the unit.
Retain the original carton and packing materials
for safe transport of this unit in the future.
2

FCC COMPLIANCE STATEMENT
INFORMATION TO THE USER:THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF
THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION
AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE
RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH
THE INSTRUCTION MANUAL, MAY CAUSE HARM
FUL INTERFERENCE TO RADIO
COMMUNICATIONS.
CAUTION:
CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY
RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
THIS CLASS ADIGITALAPPARATUS COMPLIES WITH CANADIAN ICES-003.
CET APPAREIL NUMÉRIQUE DE LA CLASSE A EST CONFORME À LA NORME NMB-003 DU
CANADA.
CE COMPLIANCE STATEMENT
WARNING:
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
3

IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been moisture, does not
operate normally, or has been dropped.
15. CAUTION – THESE SERVICING INSTRUCTIONS ARE FOR USE BY QUALIFIED
SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE
OPERATING INSTRUCTIONS UNLESS YOU ARE QUALIFIED TO DO SO.
16. Use satisfying clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2
power source only.
17. ITE is to be connected only to PoE networks without routing to the outside plant.
4

Contents
Chapter 1. Introduction ------------------------------------------------------------------------------------------------- 10
1.1 Description ------------------------------------------------------------------------------------------------------------- 10
1.2 Components ------------------------------------------------------------------------------------------------------------ 10
1.3 Key Features ----------------------------------------------------------------------------------------------------------- 10
1.4 Basic Security System Configuration ----------------------------------------------------------------------------- 12
1.5 Front Panel View and Keypads------------------------------------------------------------------------------------- 13
1.6 Rear Panel View-------------------------------------------------------------------------------------------------------- 13
1.7 IR Remote Control ---------------------------------------------------------------------------------------------------- 14
Chapter 2. Installation --------------------------------------------------------------------------------------------------- 15
2.1 HDD Installation ------------------------------------------------------------------------------------------------------- 15
2.2 Network Connection Setup --------------------------------------------------------------------------------------- 16
2.2.1 Using a Static IP Address -------------------------------------------------------------------------------------- 16
2.2.2 Using a Dynamic IP Address -------------------------------------------------------------------------------- 16
2.2.3 Router Configuration ------------------------------------------------------------------------------------------ 17
2.2.3.1 WAN Setting ----------------------------------------------------------------------------------------------------- 17
2.2.3.2 DHCP & IP Address Setting --------------------------------------------------------------------------------- 17
2.2.3.3 Virtual Server Setting ---------------------------------------------------------------------------------------- 18
STARTING THE SYSTEM ---------------------------------------------------------------------------------------------- 19
LIVE MENU DESCRIPTION ------------------------------------------------------------------------------------------- 20
SYSTEM INFORMATION ----------------------------------------------------------------------------------------------- 21
LIVE MENU NAVIGATING USING THE MOUSE ----------------------------------------------------------------- 22
LIVE MENU NAVIGATING USE THE REMOTE CONTROL --------------------------------------------------- 23
Chapter 3. Main Menu Setup ----------------------------------------------------------------------------------------- 24
3.1. Video/Audio Setup ---------------------------------------------------------------------------------------------------- 25
3.1.1. Camera (Channel) Name and Display ---------------------------------------------------------------------- 25
3.1.2. IP Camera Registration ------------------------------------------------------------------------------------------- 27
3.1.3. IP Camera Setup ------------------------------------------------------------------------------------------------- 30
3.1.4. Monitor ---------------------------------------------------------------------------------------------------- 34
3.1.5. Sequence/Events Display --------------------------------------------------------------------------------- 35
3.1.6. OSD/Display Position ---------------------------------------------------------------------------------------------- 36
3.1.7. Screen Mode -------------------------------------------------------------------------------------------------------- 37
3.2. Record Setup --------------------------------------------------------------------------------------------------------- 38
3.2.1. Record Policy -------------------------------------------------------------------------------------------------------- 38
5

3.2.2. RECORDING SCHEDULE SETUP ---------------------------------------------------------------------------- 39
3.2.3. Holiday ------------------------------------------------------------------------------------------------------------- 40
3.2.4. Event Record Duration --------------------------------------------------------------------------------------- 41
3.2.5. Record Option ----------------------------------------------------------------------------------------------------- 41
3.3. Device Setup ----------------------------------------------------------------------------------------------------------- 42
3.3.1. Storage ---------------------------------------------------------------------------------------------------------------- 43
3.3.2. Sensor/Video Loss Detection Setup --------------------------------------------------------------------------- 44
3.3.3. Alarm Schedule ----------------------------------------------------------------------------------------------------- 45
3.3.4. PTZ ---------------------------------------------------------------------------------------------------------------- 46
3.3.5. System Controller/Printer Device ------------------------------------------------------------------------------- 46
3.3.6. POS/ATM Device --------------------------------------------------------------------------------------------------- 47
3.3.7. Video Analysis ------------------------------------------------------------------------------------------------------- 48
3.4. System Setup ---------------------------------------------------------------------------------------------------------- 48
3.4.1. Date/Time ------------------------------------------------------------------------------------------------------------- 49
3.4.2. Signal/Language ---------------------------------------------------------------------------------------------------- 49
3.4.3. Config ---------------------------------------------------------------------------------------------------------------- 50
3.4.4. Log Information ----------------------------------------------------------------------------------------------- 51
3.4.5. Authorization Management ----------------------------------------------------------------------------------- 51
3.4.5.1. ADMIN --------------------------------------------------------------------------------------------------------- 52
3.4.5.2. GROUP -------------------------------------------------------------------------------------------------------- 52
3.4.5.3. USER -------------------------------------------------------------------------------------------------------- 53
3.4.5.4. SETUP --------------------------------------------------------------------------------------------------------- 54
3.5. Network Setup --------------------------------------------------------------------------------------------------------- 55
3.5.1. Connection --------------------------------------------------------------------------------------------------------- 55
3.5.2. Port --------------------------------------------------------------------------------------------------------------------- 58
3.5.3 ID & Password ---------------------------------------------------------------------------------------------------- 59
3.5.4. DDNS ------------------------------------------------------------------------------------------------------------------ 60
3.5.5. NAT Traversal ------------------------------------------------------------------------------------------------------- 61
3.5.6. Email/SNS ------------------------------------------------------------------------------------------------------------ 62
3.5.6.1. Email/SNS: SMTP ----------------------------------------------------------------------------------------------- 63
3.5.6.2. Email/SNS: Event ------------------------------------------------------------------------------------------------ 63
3.5.6.3. Email/SNS: Schedule ------------------------------------------------------------------------------------------- 64
3.5.6.4. Email/SNS: Recipient ------------------------------------------------------------------------------------------- 64
3.6. Backup Setup ---------------------------------------------------------------------------------------------------------- 65
Chapter 4. Search Menu Setup --------------------------------------------------------------------------------------- 67
4.1. Time Search --------------------------------------------------------------------------------------------------------- 67
4.2. Event Search -------------------------------------------------------------------------------------------------------- 69
4.3. Protect ------------------------------------------------------------------------------------------------------------------ 69
6

4.4. Capture ------------------------------------------------------------------------------------------------------------------ 70
4.5. POS/ATM Device ------------------------------------------------------------------------------------------------------ 71
4.6. Video Analysis --------------------------------------------------------------------------------------------------------- 71
Chapter 5. General Operation ----------------------------------------------------------------------------------------- 72
5.1. Mouse Menu -------------------------------------------------------------------------------------------------------- 72
5.1.1. Screen Mode -------------------------------------------------------------------------------------------------------- 73
4-Split ----------------------------------------------------------------------------------------------------------------- 73
PIP --------------------------------------------------------------------------------------------------------------------- 73
Auto Sequence ----------------------------------------------------------------------------------------------------- 73
5.1.2. Audio On/Off --------------------------------------------------------------------------------------------------------- 74
5.1.3. Zoom ------------------------------------------------------------------------------------------------------------------ 74
5.1.4. Freeze ----------------------------------------------------------------------------------------------------------------- 75
5.1.5. Stop Alarm ------------------------------------------------------------------------------------------------------------ 75
5.1.6. Record Stop ---------------------------------------------------------------------------------------------------------- 75
5.1.7. Play -------------------------------------------------------------------------------------------------------------------- 76
5.1.8. Search (See Chapter 4) ------------------------------------------------------------------------------------------- 76
5.1.9. Backup ---------------------------------------------------------------------------------------------------------------- 76
5.1.10. Main Menus (See Chapter 3) ---------------------------------------------------------------------------------- 77
5.1.11. Information ---------------------------------------------------------------------------------------------------------- 77
5.1.12. IP Cam Info -------------------------------------------------------------------------------------------------------- 77
5.1.13. EZ (Easy) Setup ------------------------------------------------------------------------------------------------ 78
5.1.14. Shut Down ---------------------------------------------------------------------------------------------------------- 78
5.1.15. Hide/Show Launcher --------------------------------------------------------------------------------------------- 78
5.1.16. Log Out -------------------------------------------------------------------------------------------------------------- 79
5.2. Live Launcher --------------------------------------------------------------------------------------------------------- 79
5.2.1. Control Button Description --------------------------------------------------------------------------------------- 80
5.3. Playback Launcher --------------------------------------------------------------------------------------------------- 81
5.3.1. Control Buttons ------------------------------------------------------------------------------------------------------ 82
5.3.2. Playback & Trap Mode ------------------------------------------------------------------------------------------- 83
5.4. PTZ Control ------------------------------------------------------------------------------------------------------------- 84
Chapter 6. Protect Video/Audio Files ------------------------------------------------------------------------------- 87
6.1. Protect Registration -------------------------------------------------------------------------------------------------- 87
6.2. Playback and Remove Protected File --------------------------------------------------------------------------- 87
6.3. Protected File Backup ----------------------------------------------------------------------------------------------- 88
Chapter 7. Capture Video Still Image ------------------------------------------------------------------------------- 89
7.1. Still Image capture----------------------------------------------------------------------------------------------------- 89
7

7.2. Retrieve and view Captured Images -------------------------------------------------------------------------- 89
7.3. Remove Captured Images -------------------------------------------------------------------------------------- 90
7.4. Backup Captured Image ----------------------------------------------------------------------------------------- 91
Chapter 8. Web Viewer – Connect to NVR via Internet Explorer ------------------------------------------ 92
8.1. System Requirement ---------------------------------------------------------------------------------------------- 92
8.1.1. Network Environment -------------------------------------------------------------------------------------- 92
8.2. Web Viewer-Getting Started ------------------------------------------------------------------------------------- 92
8.2.1. Connect NVR via Web Browser using Direct IP -------------------------------------------- 92
8.2.2 General Web Viewer Operation ------------------------------------------------------------------------- 93
8.2.3. Calendar and Time Search ------------------------------------------------------------------------------ 94
8.2.4. PTZ Control --------------------------------------------------------------------------------------------------------- 95
8.2.5. Connect to NVR via Web Browser using URL -------------------------------------------------------------- 95
Chapter 9. Web Viewer Setup/Web Configuration -------------------------------------------------------------- 96
9.1. Web Configuration -------------------------------------------------------------------------------------------------- 96
9.1.1. Video/Audio ---------------------------------------------------------------------------------------------------------- 96
9.1.1.1. Camera ----------------------------------------------------------------------------------------------------------- 96
9.1.1.2. IP Registration ----------------------------------------------------------------------------------------------- 96
9.1.1.3. IP Camera Setup ------------------------------------------------------------------------------------------- 97
9.1.1.4. Monitor --------------------------------------------------------------------------------------------------------- 97
9.1.1.5. Sequence/Event Display ---------------------------------------------------------------------------------- 97
9.1.1.6. OSD/Display Position ------------------------------------------------------------------------------------- 98
9.1.2. Record ---------------------------------------------------------------------------------------------------------------- 98
9.1.2.1. Policy ------------------------------------------------------------------------------------------------------------- 98
9.1.2.2. Schedule ------------------------------------------------------------------------------------------------------ 98
9.1.2.3. Holiday--------------------------------------------------------------------------------------------------------------- 99
9.1.2.4. Event Record Duration ----------------------------------------------------------------------------------------- 99
9.1.2.5. Record Option ---------------------------------------------------------------------------------------------------- 99
9.1.3. Device --------------------------------------------------------------------------------------------------------------- 100
9.1.3.1 Sensor Detection ------------------------------------------------------------------------------------------------ 100
9.1.3.2. Video Loss Detection ---------------------------------------------------------------------------------------- 100
9.1.3.3. Alarm Schedule ------------------------------------------------------------------------------------------------ 100
9.1.3.4 PTZ ----------------------------------------------------------------------------------------------------- 101
9.1.3.5. System Controller -------------------------------------------------------------------------------------------- 101
9.1.3.6. Storage ----------------------------------------------------------------------------------------------------------- 101
9.1.4. System ------------------------------------------------------------------------------ 102
9.1.4.1. Date/Time ------------------------------------------------------------------------------------------------------ 102
9.1.4.2. Time Synchronization Setup--------------------------------------------------------------------------------- 102
8

9.1.4.3. Signal/Language ------------------------------------------------------------------------------------------------ 102
9.1.4.4. System Information -------------------------------------------------------------------------------------------- 103
9.1.4.5. Authorization Management ---------------------------------------------------------------------------------- 103
9.1.5. Network -------------------------------------------------------------------------------- 105
9.1.5.1. Connection ------------------------------------------------------------------------------------------------------- 105
9.1.5.2. Port --------------------------------------------------------------------------------------------------------- 105
9.1.5.3. DDNS ------------------------------------------------------------------------------------------------------- 105
9.1.5.4. Email/SNS ---------------------------------------------------------------------------------------------- 106
Appendix
Product Specifications ----------------------------------------------------------------------------------------- 109
System Keyboard ------------------------------------------------------------------------------------------------------ 111
POS Configuration ----------------------------------------------------------------------------------------------------- 115
ATM Configuration ----------------------------------------------------------------------------------------------------- 117
Network Troubleshooting---------------------------------------------------------------------------------------------- 118
Terms/Icon Glossary --------------------------------------------------------------------------------------------------- 121
NVR Icon Reference -------------------------------------------------------------------------------------------------- 122
How to download Windows Media Player 10+ or VLC Media Player and play AVI files ------------- 123
Dashboard ----------------------------------------------------------------------------------------------------------------124
9

Chapter 1. Introduction
1.1. Description
This manual applies to the 4 channel network video recorder. (Model: NVR4P)
The network video recorder supports up to 4 network cameras. The NVR can record high quality Full
HD images onto the maximum capacity of hard disk drives.
The network recorder is extremely straightforward to install and setup, as it detects network cameras
and defines the parameters of each through a dedicated configuration wizard. You can start
monitoring instantly, as the images are automatically assigned to a layout menu.
Based on embedded Linux and high performance, the network NVRs are fully featured for security
surveillance and remote monitoring needs.
1.2. Components
The system comes with the following components:
Network Video Recorder unit
IR Remote Control
DC Power Adapter
Power Cable
AAA Battery x 2
HDD Brackets
Screw Packet
Installation CD including NC-Titanium Software, Installation Guide and User Manual
Note:Check your package to make sure that you received the complete system, including all
components shown above.
1.3. Key Features
The NVR is the most competitive device developed for all industrial applications. In addition to its
sleek professional design, it is very reliable and cost effective. Most of all, its real time and crystal
clear picture quality with small recording file size and powerful remote control function will become the
standard to which other security systems are judged. Also, its VCA (video content analysis) function
will offer you the advanced security environment.
Major features include:
►Real time live, real time recording
►4 channels IP camera support (4port High PoE camera input)
►PENTAPLEX: simultaneous Live, Recording, Playback, Backup, Network
►Extremely small recording file size using H.264 compression technology
►Adjustable recording frame rate, resolution and picture quality
►Video /Audio data backup via USB 2.0 or CMS
►Support Authentic Video Image Player
►High speed network transmission
►Dynamic / Static IP address support, Own Client (ATVisionIP or CMS Software) support
►Remote recording, still image capturing and printing
►Multiple NVRs and multiple clients support for CMS application
10

►PTZ camera control by RS-485 and via network
►Independent color adjustment for each camera input and VGAoutput
►USB Mouse and IR remote control unit for user interface
►Self-diagnosis system and Hardware Watchdog: error checking and restoring functions
►Powerful event search function (Search by manual, schedule, motion, sensor, network or all)
►Pre-Alarm Recording for motions and sensors
►Protect Video/Audio files from HDD Overwrite
►Still image capturing and printing during live or playback
►System & Event Log files management
►Configuration data copy to other channels for easy setup
►Configuration file Export / Import for easy installation of multiple NVRs
►Control of minimum recording dates by channel
►Mobile (I-Phone, Android, Black Berry, Symbian and Windows mobile) phone support
►E-Map support
►POS/ATM support
►Video Analysis support
Notice:
The information in this manual was current when published. The manufacturer reserves the
right to revise and improve its products. All specifications are therefore subject to change
without notice.
11

1.4. Basic Security System Configuration
Smartphone
Alarm Out
NO Devices
DC 30V 1A max
AC 125V 0.5A max
Sensor Inputs
NC/NO Devices scalable
TTL Level Input
DC Power
Adapter
LOCAL
NETWORK OR
INTERNET
Client Software
Web Browser
WebViewer
HDMI Monitor
VGA Monitor
External HDD
Keyboard-Controller
Fan
Power
Switch
Amplified
Speaker
12

1.5. Front Panel View
1. USB 2.0 Port (x2): Connect USB mouse or USB memory device for file backup or firmware upgrade.
2. REC LED: Recording indicator.
3. IR REMOTE CONTROL SENSOR: Receives all incoming signals from the remote control
4. POWER LED: DVR/NVR power indicator
1.6. Rear Panel View
Note:
* Available Input/Output connectors and features are different from each model (part). Please contact
distributors to check the exact part number with your desired Input/Out connectors and features.
This manual describes all possible Input/Output connectors and features of this series.
1
2 3 4
13

1.7. IR Remote Control
1. Audio: ON/ OFF function.
2. REC (Record): Start/stop manual recording.
3. Number Buttons: Select camera (channel) number.
4. ID SEL: Allows you to select ID setting.
5. ID: Displays current ID.
6. Info: It will display system information.
7. Print: Allows you to Print image either in Live or Playback Mode.
8. Navigate Buttons:
◀
Left ▲ Up
▶
Right ▼ Down :
9. Enter : To select and save the menu and parameter change.
10. Menu: Enter or exit the menu.
11. Return: Directs you back to the previous menu. In Live Mode,
this button will log you out.
12. Mode: Change the display mode to different split screen.
13. Freeze: Freezes images. (Only in Live Mode).
14. Zoom: Zoom in/out the video when the channel is single
display mode.
15. Bookmark: It will list all the files that was bookmarked.
16. EZ Setup: You’ll be able to setup your system with simple
pages.
17. K-Lock: Locks any keys from functioning.
18. Alarm: Turns the Alarm off.
19. Backup: Backups up desired data.
20. PTZ: Control PTZ camera(s) connected to your DVR/NVR.
21. Preset: A preset is a set of specific target points of a PTZ
camera.
22.Tele: Zooms in on a specific area when using the PTZ function.
23. Wide: Zooms out of that specific area when using the PTZ
function.
24. Search: Go to recorded file search menu.
25. Pause : Pause a video during playback mode.
26. Protect: You can protect recorded data from HDD overwriting.
27. Capture: You can capture video image either in Playback
Mode or Live Mode.
28. REW: Rewind (select speeds from 2x4x8x16x32x64 for faster
rewind).
29.
▶
Play: Play a recorded file.
30.
■
Stop: Stop playback.
31. FF: Fast forward (select speeds from 2x4x8x16x32x64).
ID Setting Instruction:
1) Press down ID SEL button for 2 seconds to start the ID Setting Mode
2) Input any 2 digits to set ID.
3) Once the 2 digits are selected, press enter.
* If no action is taken within the 2 second allowed time period, it will automatically exit you
from the ID Setting.
Installing batteries
1. Remove the battery cover by sliding in the direction of the arrow.
2. Insert twoAAA batteries according to directions provided.
3. Replace the battery cover by sliding in the direction of the arrow.
14

Chapter 2. Installation
2.1. HDD Installation
Before Installation
We recommend setting the current time on your NVR before HDD Installation.
Please make sure that the power of NVR is switched off before starting installation.
Step 1. Make sure the NVR power is switched OFF
Step 2. Open the top cover of NVR using a cross screw driver.
Step 3. Take out the HDD mounting plate from NVR.
Step 4. Place HDD(s) on the mounting plate and mount it with screws.
Step 5. Replace the mounting plate into the NVR and fix it with screws.
Step 6. Attach the data and power cable to HDD(s) correctly.
Step 7. Replace the top cover of NVR and fix it with screws.
After HDD installation
Step 8. Turn the NVR power ON.
Step 9. NVR will detect HDD(s) during the booting and will format HDD(s).
Step 10. After HDD formatting, NVR will be automatically rebooted and will be ready to work
with HDD(s).
15

2.2. Network Connection Setup
2.2.1. Using a Static IP Address
You can use the Static IP address, Subnet Mask and Gateway address provided by your ISP
(Internet Service Provider) for your NVR. The Gateway address is the IP address of your
broadband modem.
2.2.2. Using a Dynamic IP Address
You can use a router with your Dynamic IP broadband modem. In this case, you should set the
configuration of a router properly for network connection between NVR and Net/Web Viewer.
Please follow the instructions in next section to configure your router correctly.
If your Broadband Modem does not support internal loop back (port forwarding) function and you
want to monitor NVR using a PC located in same Intranet, you should use Direct IP instead of
DDVRLS in the connection menu of NetViewer. If your PC is located outside of Intranet, you can
use both DDVRLS and Direct IP to connect to NVR even though your Broadband Modem has
limited features.
Internet
Home/Office Network Internet
16

2.2.3. Router Configuration
If your NVR is connected to the network through a router, you should configure router properly.
There are 3 steps as follows.
1. WAN Setting 2. DHCP Setting 3. Virtual Server Setting
2.2.3.1. WAN Setting
When you connect to your Router, you
can find menu for WAN setting. Please
confirm the WAN setting. If you are using
DSL service, you should select PPPoE,
and you will be directed to a sub-menu to
type in DSL user name and password.
2.2.3.2. DHCP & IP Address Setting
To assign a unique private IP address to
NVR in your intranet environment
automatically, you can enable DHCP
option in the Network Setup menu of your
NVR and your Router. In this case, you
can skip the procedures described on
this page.
We recommend assigning IP address to
NVR manually to prevent unexpected
change of IP address.
*A router from D-Link is quoted as an example in this manual. The images of setup menu above may
not always match another router’s setup menu.
If you have any problem with DHCP function or want to assign the private IP address, please
disable DHCP option in the Network Setup menu of your NVR and check the starting and ending
IP used by DHCP server of the Router. You can assign any private IP address to your NVR
even if it is out of the DHCP range, but the IP address should match with the one entered in
the Network Setup menu of your NVR.
17

2.2.3.3. Virtual Server Setting
You should register your NVR as a virtual server. Please enter the information into IP address
field of the router (e.g. 192.168.0.110).
Protocol Type should be TCP. Private/Public Port numbers should be the same with the Port
numbers assigned in NVR. You can change port numbers in Network Setup menu to avoid conflict
with other network servers.
Your NVR uses 3 port numbers and the default Port numbers are 9350~1 and 80. 9350~1 are
for controlling the video, audio and commands of Net Viewer, and 80 is for Web Viewer. You need to
register 3 port numbers into the router as network servers. Please make sure that your router does
not block those port numbers to/from the NVR with filter and firewall features.
18

STARTING THE SYSTEM
When power is turned on, you will see the initializing screen and it may take up to one minute to
complete. After initializing is complete, a live screen will appear.
To log in, right click any area on the screen and a live menu will appear. Click to any menu and it will
prompt you to the login dialog.
Enter ID and Password by using the virtual keyboard and click OK. By default, the ID is set at “admin”
and the Password is set at “admin”
19

LIVE MENU DESCRIPTION
1 SCREEN MODE Can select how you would like to view screen
2 AUDIO ON/OFF Option to have the audio on or off
3 FREEZE Can freeze Playback or Live scene
4 STOP ALARM Stops the alarm output and the event monitoring. Refer to
"Event Monitoring"
5 RECORD STOP Starts/stops the standard recording
6 PLAY Plays the search result (data).
7 SEARCH Can search for recorded data
8 BACKUP Can backup data via USB drive
9 MAIN MENU Access the main menu. Refer to the Using the DVR section
10 INFORMATION This menu will display system information
11 IP CAM INFO It will display you IP camera information
12 EZ SETUP (EASY) You’ll be able to setup your system with simple pages
13 SHUT DOWN Will allow you to completely shut down the unit
14 HIDE LAUNCHER Hides the launcher.
15 LOGOUT You can log out.
20
