Atwood Hydraulic Brake Actuator Replacement Kits
HYDRAULIC BRAKE
ACTUATOR REPLACEMENT
KITS
Effective 11/93
MPD 85091
INSTALLATION INSTRUCTIONS
KIT KIT
NUMBER DESCRIPTION INCLUDES
85830 Shock Absorber Replacement Kit 4, 28 - 2 ea., 29 - 2 ea., 30, 24
85837 Master Cylinder Push Rod Kit 3, 7, 14 - 4 ea., 16, 17,24,6,8,34
87478 Cap Replacement Kit 15
85841 Master Cylinder Replacement Kit 6, 7, 14 - 4 ea.
85842 Shoulder Bolt Replacement Kit 20,21,24,25,26,27
85844 Release Handle Replacement Kit 5,18,22,23,24 - 3 ea., 19
85849 Stop & Spring Assembly Replacement Kit 9, 11, 12, 28 - 2 ea., 29 - 2 ea., 30
85852 Push Rod Assembly Replacement Kit 3,7,14 - 4 EA., 16, 17,24,34
84258 Boot Replacement Kit 8
