AU Tool X500 User manual

Trademark
AUTOOL Technology Co, Ltd. has registered its trademarks in different
countries, the trademark is . With regard to the other
trademark, service logo, domain, icon and company name mentioned in
this manual, they shall all belong to AUTOOL and its other affiliated
company, in other countries without the registration yet of these
trademark, service logo, domain name, icon and company name of
AUTOOL, here we announce they are owned by AUTOOL. Any company
or person shall not use the trademark, service logo, domain name, icon
and company name of AUTOOL before getting approved by AUTOOL with
written certificates. Please visit our website www.autooltech.com or
email at [e-mail] to contact us.
1. Attention
Non- technical person shall not change, disassemble or repair the
product, otherwise all losses caused by this shall be bared by the
user himself.
Please do not scratch, bend, twist or stretch the wires. Do not place
the wires in high temperature. Do not press hard or decompose the
on-board charging adapter.
Please do not place nails, pins, and other small debris on the
charging port, in order to avoid damaging the charging connector.
Do not place the product in unstable place such as high altitude area,

slope, or shelf.
This product is powered by electricity and should not be used as a
toy for children.
To avoid short circuit, do not immerse the product in water or other
liquid.
Please try to use the power supply and power cord supplied by
manufacturer as standard.
Please do not expose this product to strong light or high temperature
when it’s not at use.
2. Product introduction
Autool X500 smart on-board HUD is a head-up display device that
connects the ECU of car and mobile phone. This product is installed
above the dashboard and displays the navigation information of the car
or mobile phone on the HUD through Bluetooth transmission. The
display, including speed, fuel consumption, water temperature, etc., it
allows driver to focus on the road ahead, providing the driver with a
safer and more technological driving experience.
3. Installation and Power

1) Insert the OBD plug into the OBD port of vehicle.
2) Start the vehicle and plug the other end of the OBD power cable into
the power socket on the back of the HUD.
* The vehicle’s OBD port is generally at the locations as shown in the
picture. Tips: The Bluetooth HUD will start automatically after the
vehicle starts, and the main unit will automatically shut down when the
vehicle is off. On some vehicles the shutdown may delay for 3-5 minutes.
3) Fix the HUD on the soft rubber base first, or attach the base with the
3M adhesive piece attached to fix it.
4) Place the HUD above the dashboard, select and confirm a position
where the screen information is shown clear.
5) Open the downloaded Anavi navigation software,click on the HUD in
the upper left corner for Bluetooth connection, the software will
automatically scan data to AUTOOLX500, click it to connect to the HUD
main unit. After the connection is successful, the connection will be
made automatically.

HUD parameter setting- Click the setting icon in the lower right corner
to enter the Setting function, and then click HUD Setting to enter the
setting.
7) Download offline map- Click the setting icon in the lower right corner
to enter the Setting function, and then click Offine Map to enter the

offline map downloading. Select the country and region you need to
download for offline map.
4. Warranty and Service
There are 3 years’ warranty for AUTOOL product main unit and 1 year
warranty for the accessories since the day the customers have received
the product parcel.
Warranty Access
Repair or replace the equipment will be done according to the specific
fault conditions;
We guarantee that all replacement parts, accessories or equipment are
brand new;
When there is a product breakdown that can not be solved within 90

days, customer should provide video and pictures as proof, we will bear
the freight cost and provide customer the accessories in need to replace.
After receiving the product for more than 90 days, the customer shall
bear the freight cost, we will provide the accessory for free to replace.
Warranty not Covered in Conditions Listed Below:
Product is bought through non-official AUTOOL purchase channel.
Product failure is caused by incorrect use of the product, use for other
wrong purpose or human factors.
Disclaimer: The AUTOOL Technology Co, Ltd. reserves the right to change
product designs and specifications without prior notice. The physical
appearance and color may differ from those shown in the instruction
manual. Please refer to the actual product. If you have any question,
please contact the dealer or the Autool service center. The company
have the final explanation right of product and shall not bear any
consequences due to misunderstanding.
