Accele RVM430DVR User manual

4.3” Rearview Mirror
with camera & 2 Video in DVR
ELECTRONICS INC.
RVM430DVR
Specs :
Rearview mirror with 4.3” widescreen LCD
Two Video DVR built in
Video 1 Built in Camera ,140 degree (ippable to front or back)
Video 2 Camera video input (to record driver or backup camera)
Recording HD 720P 30fps - Format H 264
Auto ignition or motion detect recording
SD card 32GB max.
“G” sensor also built in for auto record and save function
Camera 2 video input
example from backup camera or
add camera to monitor driver, etc
Second camera
not included
Camera 1 built in to record driving
DVR built in

ELECTRONICS INC.
RVM430DVR
P roduct Introduction:
T his product is a professional high definition Driving R ecorder. It has many outstanding features, High
Definition dual channel videlo record, support CVBS signal input ( used for automatic rearview parking ),
ACC automotive electronic circuit design (support power off memory), 4.3 inch T FT LC D Panel, motion
detection record and professional installation.
F unction Introduc tion:
4.3 inc h TF T LC D P anel
1/2 inc h HD C MOS , 140 ° wide-a ngle lens , F ocal length R ange: >10cm
Built-in microphone and HIF I S peaker
R ecord R esolution:
HD: 720P 1280x720 at 30 fps
VGA: 640x480 at 30 fps
S upport AV input, can connect backup camera for car parking
Video F ormat: H2.64
Support S D(S DHC ) card up to 32GB, can record continuously
Power Voltage: 6-18V, s upport ACC circuit to protect car power
E nsure safety reversinging, image displayed automatically when reversing
Power-off Memory F unction
Motion detection function
Humanized function settings: According to Users’ requirements, you can choose s ingle or double
record, automatically start up, screen dormant or not, Motion detection record on or off and the
crash strength settings
Particular Introduce: Due to the unit installed on the windscreen with strong sunlight ,for security
consideration, the device does not have lithium ba ttery, only support professional installation

ELECTRONICS INC.
RVM430DVR
P roduct Appearance
Front
Back
1. Upward 2. Main Menu 3. Downward 4. P ower On/Off 5. OK/P a use
6. Mode/P hotograph S witc h/Pla yback 7 . B ack&F orth C amera S witch/P IP
8. S D C ard S lot 9.R ese t 10. P ower Light 11. MINI US B

ELECTRONICS INC.
RVM430DVR
Rearview Mirror Installation Instructions
Bracket and the Adapter kit:
Bracket 1 Adapter kit
1. The bracket 1 can suit for many original cars, such as Lexus, Toyota XLE, Camry, Prado, Previa, Crown,
Corolla, Reiz, Buick Regal, GL8, Ford Mondeo, Focus, Mazda6, Honda Odyssey, NISSAN, Chevrolet,
etc. Because the original pedestal can match the bracket 1 (Picture 1)
2. When the bracket can not suit for the pedestal, please use the Adapter kit to cover the original pedestal
for installation.(Picture 2)
Adapter kit installation instructions:
1. Use ethanolto clean the windscreen. (The place for install the adapter kit)
2. Tear offf the membrane of the double sided adhesive tape on the adapter kit.
4. Paste the adapter kit on the windscreen and install the bracket on the adapter kit. (Picture 2)
Attentions:
1. In order to ensure a solid paste, please install the device after 1 hour.
Installation Picture for Reference:
Picture 1
Original pedestal Install the bracket on the pedestal
Picture 2
Cover the original pedestal Install the bracket on the adapter kit

ELECTRONICS INC.
RVM430DVR
F unction Operation:
1. P ress P ower O n/O ff to turn on or turn off the model
2. R ecording D ura tion: Use MODE to choose R ecording D ura tion on the MA IN ME NU.
Users ca n choos e 1 min/2 min/5 min/Turn off mode . F or e xa mple, c hooing 1 min,
recording time will be 1 min, then the model will recording a new whe n come to 1 min.
And the file in the S D will be 1 min.
3. R ecording Mode: F irstly, e nsure the model has a S D card, then use MODE to c hoose
R ecording Mode on the MA IN ME NU. P ress OK to s tart record whe n c hoose the fro nt
camera. If c hoose back camera , users s hould connect the back camera cable firstly.
While if c hoose dual camera , both cameras will be record a t the same time. Users can
s witch the camera image by V 1/V2.
4. P hotograph: S witc h to P hotograph Mode by MODE button. P ress OK to take photos.
Use ME NU for settings under the P hotograph Mode.
5. P layback: Use MODE to s witc h to P la yback Mode. B oth photos a nd videos ca n be
played by using the P la yback button.
6. Night V is ion F unction: Turn on the infrared lamp of the ME NU. W he n c hoose
AUTOMAT IC , the infrared lamp will be turn o n/off a utomatically according to outside
light strength.
7. Motion Detection: In the ME NU, you can choose to turn on or turn off the Motion
Detection func tion. W he n this function turn on, the mode l will recording when
s omething moving in the came ra. While stop recording if the objec t s top. T his func tion
can s a ve the capacity of the memory card.
8. G_S ens or F unction: In order to c heck a nd obtain evidence, the mode l will sa ve the file
compulsive ly while do not covered by others when car s uffer a serious s trike or cras h.
T his cras h s tre ngth can be detached to High, Middle, Low a nd Turn off four mode.
9. S creen sa ve r:S et s creen s ave r time in the ME NU, s creen will turn off a fter the time you
choose.P ress a ny key to wake up the scree n.

ELECTRONICS INC.
RVM430DVR
C able C onnec tion
P arameters
I m a g e
S e nsor
E ffective P ixels Approx. 1.3 Mega Pixels (1280x960)
Output Pixels Approx. 1.3 Mega Pixels
L e n s
Focal Length Lens f= 2.6mm
F No. F= 2.0
L C D D i spl a y
4.3” TFT-LCD
F o c u sin g Type Fixed
E x po sure
Control Programmed AE
Compens ation ±3E V (1 E V s teps )
IS O E quivalent Auto
L E D
Modes Auto / Off/ON
W h i te B a la n c e
Auto/Daylight/Cloudy/ Tungs ten /Fluores cent/
S ho oti n g
S till Image Modes : S ingle Image up to 3M (interpolated)
HD 720P HD: 1280x1440 30fps 8Mbps
S D: 1280x480 30fps 6Mbps
A udio
Mic and S peaker(Mono)E quipped
S to ra ge
Media Internal memory: no internal memory
E xternal memory: s upporting S DHC C ard up to 32GB
File Format S till Image: JP E G
Movie Clip: H.264 MOV
Image S ize
(1M): 1280*800
(2M): 1600*1200 by interpolation
(3M): 2000*1500 by interpolation
L a ngu a ge
E nglish/Chines e/Korean/Japanes e/R us sian/Korean
I n te rfa c e
MINI US B 2.0
P ow e r S ou rc e
C AR POWE R
