Audi QVL-A6 LE-V6 User manual

AUDI A6 LE with Touch Screen
(with MMI version)
-. MODEL: QVL-A4L-V6
-. Product Code : A4L-0904-223
-. MODEL: QVL-A６LE-V6
-. Product Code : AD-0905-001
Last Updated Date : 26th. May. 2009

-. AUDI A6 Feature…………………………………….….….….3
-. Precaution……………………………………………...............4
-. Main Spec………………………………………........………....5
-. System Composition……………………………...………….6
-. Outline Dimension………………………….............….……7
-. External Look…………………………………………....…......8
-. Connector Pin Assignment…………………............…....11
-. DIP SW …………………………………………....………..……12
-. REMOTE CONTROL…………………………….……………..13
-. MMI Button ……………………..……………....………..……14
-. OSD Menu…………………..…………….......…………………16
-. OSD (On Screen Display) ……………….......……..………18
-. Factory Mode……………………..………………........………22
-. Rear Parking Guide Line……………………….....…………23
-. Touch Calibration……………....……..….......………………24
-. IR Memory……………………………......……………………..25
-. DMB, DVD Model Selection………………......…………..27
-. Product Part List…………………………….…………………28
-. Installation Structure……………….…………………...…...29
-. FAQ……………………………….…………………….……...…...30
INDEX

-AUDI A6 LE Feature
- Control DVD, NAVI by touch (Optional)
- Remote button value copy function (Refer to page no. 24)
(Only available in models with remote)
- More convenient installation via sub-board.
- Plug & Play by LVDS cable
- Own positioning function on RGB&AV mode.

-Precaution
- You must keep the car key taken off from the car while you work
this and finally, connect power of the interface.
- When to connect the interface cable, you must keep the power
cable taken off.
- You must work this at the environment without any static electricity
or damages.
- All of process on this installation should be done by professionals.
- You must not break the labels attached on the board, if it’s broken,
no warranty.
- When you receive this package you have to check whether there’s
any parts not included and you have to contact us right away.
- Our repair service do not accept any problems caused by user’s
any fault or carelessness.

1. Input Spec. (MULTI VIDEO INTERFACE)
-. 1 x Analog R,G,B,Csync
-. 1 x CVBS(REAR CAMERA) Input. (Rear camera source)
- 2 x A/V (NTST & PAL) Input.
-. 1 x LCD Input (Car system Input)
2. Output Spec.
-. 2 X CVBS OUTPUT (Video Out for installing Headrest monitor)
-. 1 x Audio OUTPUT
-. 1 X LCD OUTPUT(LCD Operation)
3. Electric Power Spec.
- Input Power : 8VDC ~ 24VDC
- Consumption Power : 12WATT, Max
4. Switching AV Source
- Possible to skip AV source while switching Mode (AV source) by DIP S/W
(Refer to the DIP S/W page)
- By remote control
- By toggle switch
- By Touch (Optional)
-Main Spec.

A/V OUT HEADREST
MONITOR
LVDS In/Out
Touch Input
Car Input
MCU
VIDEO
CIRCUIT VIDEO
MUX
POWER
CIRCUIT TOUCH
A/V
1
A/V
2
CVBS
(Rear Camera)
Power Input
(+8VDC~+24VDC)
DIP S/W NAVI
Remote Control Switch for source toggle AUDI
Original Monitor
DVD
DMB
-System Composition
NAVI

-Outline Dimension
130mm * 105mm * 20mm
20mm
130mm
105mm

RGB(IN)
-External Look
TOUCH
OUT
LCD-OUT
POWER/CANAV(IN/OUT)MODE
LCD-IN
RemoteDIP S/WLED IR
OUT
NAVI
TOUCH

LCD-OUT LCD-IN
RGB(IN
)
DIP S/W A/V(IN/OUT)LED MODERemote IR OUT POWER
-External Look

NAVI
Touch
Touch
OUT
-External Look

Connector Pin Assignment
* Power Cable
FILTER
& FUSE BOX
1m
SAFE
ACC : 12v~24V
GND
REAR-C
MMI

-DIP SW
#PIN FUNCTION DIP S/W Selection
1 RGB INPUT MUTE ON : Skipping RGB Mode
OFF : RGB Display
2 A/V 1 MUTE ON : Skipping A/V 1
OFF : A/V1 Display
3 A/V 2 MUTE ON : Skipping A/V 2
OFF : A/V2 Display
4N.C N.C
5N.C
6N.C
7Rear Mode
ON : External Rear Camera
OFF : OEM Rear Camera
8OEM Navi Mute
ON : In case of OEM Navi installed
OFF : In case of OEM Navi not installed
※DIP S/W Use Example
[AUDI A6LE]
-. Use Input Mode : A/V3(DVD),
Navigation (RGB)
-. Rear Camera : When to be installed
on CVBS
-. When original Navi is not installed
▷ DIP S/W : 1 ÆON
▷ DIP S/W : 2,3 ÆON
(INPUT MODE SKIP)
▷ DIP S/W : 4 ÆOFF (enable A/V3)
▷ DIP S/W : 5 ÆOFF (ON)
▷ DIP S/W : 6 ÆOFF (ON)
▷ DIP S/W : 7 ÆON (enable CVBS4)
▷ DIP S/W : 8 ÆOFF
※ ON : DOWN, OFF : UP

-REMOTE CONTROL
POWER & PIP: N.C
MENU : OSD operation
OK : Select
▲: Up
▼ : Down
◀ : Left, Long press - Factory Mode operation
▶: Right
*FACTORY MODE (Interface setting)
: Operated by long press with ◀ button or
Pressing UP→DOWN→UP→MENU in order

-MMI BUTTON
⑤
⑥
⑦
⑧
⑨
⑩
<NAVIGATION>
①Up
②Down
③ Zoom In
④ Zoom Out
⑤ Short press : OK
Long press : Menu window
⑥ Short press : Return
Long Press : Present Place
⑦ Short Press : Destination
Long Press : Night mode
⑧When DIP S/W No. 8 is ON : OEM →
OEM Navi → RGB (Navi) → AV1 → AV2
⑨Left
⑩Right
①
②
③
④
⑤
⑥
⑦
⑧
⑨⑩
<DVD, CMMB>
⑤OK
⑨ Move to right
⑩Move to left
※ Once moves jog-shuttle button, DVD,
CMMB (DMB) OSD menu appears.

-MMI BUTTON
<MMI Button Setting>
- In MMI Button Setting mode as left picture, select one of
Menus would like to save.
EX) For “POWER” button
1. Once Select OK button of remote in OSD menu, the marked
point in left picture blinks.
2. When the left marked point blinks, Press “POWER” button of
your remote.
3. As soon as the “Power” button is pressed, it’s button value is
displayed in the screen, it will be saved automatically.
4. As the same procedure, you can save other buttons.
• Short Press
Long Press
- Whether press ◀ button of remote or press UP→DOWN→UP→MENU in order to get
factory menu, and then select “IR MEMORY” in UTIL menu.
- IR MEMORY has DMB, NAVI menu, if choosing NAVI IR, the below image appears.

-OSD Menu : DVD (Optional)
※ For DVD OSD Menu operated, DVD must be connected with AV1 and DVD IR
wire of RGB cable has to be wired with DVD’s remote sensor.
On AV1 mode, once touch the screen, Menu
window appears like left picture. If no action
for 5 sec or touch any other parts of the
screen, this will disappear.
When selecting “INPUT”, Menu window for
mode switching appears like the below
picture.
When the Menu appears as left picture, you
can switch to as desired by touch.

-OSD Menu : DBM, NAVI
On AV2 mode, once touch the screen, Menu
window appears like left picture. If no action
for 5 sec or touch any other parts of the
screen, this will disappear.
When selecting “INPUT”, Menu window for
mode switching appears like the below
picture.
※ We support 2 languages (English, Chinese), you can select language on OSD Menu

-OSD(On Screen Display)
· Analog RGB Mode · Video Mode
IMAGE Menu
- BRIGHTNESS
- CONTRAST
- SATURATION
-HUE
- SHARPNESS
- USER IMAGE
※OSD Menu : Operated by “MENU” button of remote.

OSD(On Screen Display)
· Analog RGB Mode · Video Mode
OSD Menu
- LANGUAGE : Language Select of DVD, DMB OSD (ENGLISH, Chinese)
-TRANSPARENT
- H_POSITION
- V_POSITION

OSD(On Screen Display)
UTIL Menu :
- USER RESET : Initializing all set values of navi or DVD
· Analog RGB Mode · Video Mode
